Acura MDX (2020 year). Manual in english - page 32

509

uu

When Driving

u

Road Departure Mitigation (RDM) System

Driving

■

Roadway conditions

•

Driving on a snowy or wet roadway (obscured lane marking, vehicle tracks,
reflected lights, road spray, high contrast).

•

Driving on a road with temporary lane markings.

•

Faint, multiple, or varied lane markings are visible on the roadway due to road
repairs or old lane markings.

•

The roadway has merging, split, or crossing lines (e.g., such as at an intersection
or crosswalk).

•

The lane markings are extremely narrow, wide, or changing.

•

The vehicle in front of you is driving near the lane lines.

•

The road is hilly or the vehicle is approaching the crest of a hill.

•

Driving on rough or unpaved roads, or over bumpy surfaces.

•

When objects on the road (curb, guard rail, pylons, etc.) are recognized as white
lines (or yellow lines).

•

Driving on roads with double lines.

■

Vehicle conditions

•

Headlight lenses are dirty or the headlights are not properly adjusted.

•

The outside of the windshield is streaked or blocked by dirt, mud, leaves, wet
snow, etc.

•

The inside of the windshield is fogged.

•

The camera temperature gets too high.

•

An abnormal tire or wheel condition (wrong sized, varied size or construction,
improperly inflated, compact spare tire

*

, etc.).

•

The vehicle is tilted due to a heavy load or suspension modifications.

•

When tire chains are installed.

•

The vehicle is towing a trailer.

* Not available on all models

510

uu

When Driving

u

Lane Keeping Assist System (LKAS)

Driving

Lane Keeping Assist System (LKAS)

Provides steering input to help keep the vehicle in the middle of a detected lane and
provides tactile and visual alerts if the vehicle is detected drifting out of its lane.

1

Lane Keeping Assist System (LKAS)

Important Safety Reminders

The LKAS is for your convenience only. It is not a
substitute for your vehicle control. The system does
not work if you take your hands off the steering
wheel or fail to steer the vehicle.

2

Multi-Information Display Warning and
Information Messages

 P. 115

Do not place objects on the instrument panel.
Objects may reflect on the windshield and prevent
correct detection of the traffic lanes.

The LKAS only alerts you when lane drift is detected
without a turn signal in use. The LKAS may not detect
all lane markings or lane departures; accuracy will
vary based on weather, speed, and lane marker
condition. It is always your responsibility to safely
operate the vehicle and avoid collisions.

The LKAS is convenient when it is used on freeways.

The LKAS may not work properly or may work
improperly under the certain conditions:

2

LKAS Conditions and Limitations

 P. 516

The LKAS may not function as designed while driving
in frequent stop and go traffic, or on roads with
sharp curves.

You can read about handling information for the
camera equipped with this system.

2

Front Sensor Camera

 P. 487

When you operate the turn signals to change lanes, the system is suspended, and
resumes after the signals are off.
If you make a lane change without operating the turn signals, the LKAS alerts
activate, and torque is applied to the steering.

■

Front Sensor

Camera

Monitors the lane
lines

■

Tactile and visual alerts

Rapid vibrations on the steering
wheel and a warning display alert
you that the vehicle is drifting out
of a detected lane.

■

Steering input assist

The system applies torque to the steering to keep the vehicle between the left and
right lane lines. The applied torque becomes stronger as the vehicle gets closer to
either of the lane lines.

Continued

511

uu

When Driving

u

Lane Keeping Assist System (LKAS)

Driving

Provides assistance to keep the vehicle in the center of the lane. When the vehicle
nears a white or yellow line, steering force of the electric power steering will become
stronger.

When the vehicle enters the warning area, the LKAS alerts you with slight steering
wheel vibration as well as a warning display.

■

Lane Keep Support Function

1

Lane Keeping Assist System (LKAS)

When it fails to detect lanes, the system will
temporarily be canceled. When a lane is detected, the
system will recover automatically.

■

Lane Departure Warning Function

Warning Area

Warning Area

uu

When Driving

u

Lane Keeping Assist System (LKAS)

512

Driving

The system can be used when the following conditions are met.

•

The lane in which you are driving has detectable lane markers on both sides, and
your vehicle is in the center of the lane.

•

The vehicle is traveling between about 45 and 90 mph (72 and 145 km/h).

•

You are driving on a straight or slightly curved road.

•

The turn signals are off.

•

The brake pedal is not depressed.

•

The wipers are not in continuous operation.

■

How to activate the system

1.

Press the

MAIN

 button.

u

The LKAS is on in the MID.
The system is ready to use.

2.

Press the LKAS button.

u

Lane outlines appear on the MID.
The system is activated.

■

When the System can be Used

1

When the System can be Used

If the vehicle drifts toward either left or right lane line
due to the system applying torque, turn off the LKAS
and have your vehicle checked by a dealer.

MAIN

 Button

LKAS Button

Continued

513

uu

When Driving

u

Lane Keeping Assist System (LKAS)

Driving

3.

Keep your vehicle near the center of the
lane while driving.

u

The dotted outer lines change to solid
ones once the system starts operating
after detecting the left and right lane
markings.

To cancel the LKAS:
Press the

MAIN

 or LKAS button.

The LKAS is turned off every time you stop the
engine, even if you turned it on the last time
you drove the vehicle.

■

To Cancel

1

To Cancel

Pressing the

MAIN

 button also turns ACC with Low

Speed Follow on and off.

MAIN

 Button

LKAS Button

514

uu

When Driving

u

Lane Keeping Assist System (LKAS)

Driving

■

The system operation is suspended if
you:

•

Set the wipers to continuous operation.

u

Turning the wipers off resumes the
LKAS.

•

Set the wiper switch to

AUTO

 and the

wipers operate continuously.

u

The LKAS resumes when the wipers stop
or operate intermittently.

•

Decrease the vehicle speed to about 40
mph (64 km/h) or less.

u

Increasing the vehicle speed to about 45
mph (72 km/h) or more resumes the
LKAS.

•

Depress the brake pedal.

u

The LKAS resumes and starts detecting
the lane lines again once you release the
brake pedal.

When the LKAS is suspended,
the lane lines on the MID
change to contour lines, and the
beeper sounds (if activated).

Models with automatic intermittent wipers

All models

515

uu

When Driving

u

Lane Keeping Assist System (LKAS)

Continued

Driving

■

The LKAS may automatically be suspended when:

•

The system fails to detect lane lines.

•

The steering wheel is quickly turned.

•

You fail to steer the vehicle.

•

Driving through a sharp curve.

•

Driving at a speed in excess of approximately 90 mph (145 km/h).

Once these conditions no longer exist, the LKAS automatically resumes.

■

The LKAS may automatically be canceled when:

•

The camera temperature gets extremely high or low.

•

The camera behind the rearview mirror, or the area around the camera, including
the windshield, gets dirty.

•

The ABS or VSA

®

 system engages.

The beeper sounds if the LKAS is automatically canceled.

516

uu

When Driving

u

Lane Keeping Assist System (LKAS)

Driving

The system may not detect lane markings and therefore may not keep the vehicle in
the middle of a lane under certain conditions, including the following:

■

Environmental conditions

•

Driving in bad weather (rain, fog, snow, etc.).

•

Sudden changes between light and dark, such as an entrance or exit of a tunnel.

•

There is little contrast between lane lines and the roadway surface.

•

Driving into low sunlight (e.g., at dawn or dusk).

•

Strong light is reflected onto the roadway.

•

Driving in the shadows of trees, buildings, etc.

•

Shadows of adjacent objects are parallel to lane markings.

•

Roadway objects or structures are misinterpreted as lane markers.

•

Reflections on the interior of the windshield.

•

Driving at night or in a dark condition such as a tunnel.

■

LKAS Conditions and Limitations

517

uu

When Driving

u

Lane Keeping Assist System (LKAS)

Driving

■

Roadway conditions

•

Driving on a snowy or wet roadway (obscured lane marking, vehicle tracks,
reflected lights, road spray, high contrast).

•

Driving on a road with temporary lane markings.

•

Faint, multiple, or varied lane markings are visible on the roadway due to road
repairs or old lane markings.

•

The roadway has merging, split, or crossing lines (e.g., such as at an intersection
or crosswalk).

•

The lane markings are extremely narrow, wide, or changing.

•

The vehicle in front of you is driving near the lane lines.

•

The road is hilly or the vehicle is approaching the crest of a hill.

•

Driving on rough or unpaved roads, or over bumpy surfaces.

•

When objects on the road (curb, guard rail, pylons, etc.) are recognized as white
lines (or yellow lines).

•

Driving on roads with double lines.

■

Vehicle conditions

•

Headlight lenses are dirty or the headlights are not properly adjusted.

•

The outside of the windshield is streaked or blocked by dirt, mud, leaves, wet
snow, etc.

•

The inside of the windshield is fogged.

•

The camera temperature gets too high.

•

An abnormal tire or wheel condition (wrong sized, varied size or construction,
improperly inflated, compact spare tire

*

, etc.).

•

The vehicle is tilted due to a heavy load or suspension modifications.

•

The vehicle is towing a trailer.

* Not available on all models

518

uu

When Driving

u

Vehicle Stability Assist

®

 (VSA

®

), aka Electronic Stability Control (ESC), System

Driving

Vehicle Stability Assist

®

 (VSA

®

), aka Electronic

Stability Control (ESC), System

VSA

®

 helps to stabilize the vehicle during cornering if the vehicle turns more or less

than what was intended. It also assists in maintaining traction on slippery surfaces.
It does so by regulating engine output and selectively applying the brakes.

When VSA

®

 activates, you may notice that the

engine does not respond to the accelerator.
You may also notice some noise from the
hydraulic system. You will also see the
indicator blink.

■

VSA

®

 Operation

1

Vehicle Stability Assist

®

 (VSA

®

), aka Electronic Stability Control

(ESC), System

The VSA

®

 may not function properly if tire type and

size are mixed. Make sure to use the same size and
type of tire, and the air pressures as specified.

When the VSA

®

 system indicator comes on and stays

on while driving, there may be a problem with the
system. While this may not interfere with normal
driving, have your vehicle checked by a dealer
immediately.

VSA

®

 cannot enhance stability in all driving situations

and does not control the entire braking system. You
still need to drive and corner at speeds appropriate
for the conditions and always leave a sufficient
margin of safety.

The main function of the VSA

®

 system is generally

known as Electronic Stability Control (ESC). The
system also includes a traction control function.

VSA

®

 System

Indicator

519

uu

When Driving

u

Vehicle Stability Assist

®

 (VSA

®

), aka Electronic Stability Control (ESC), System

Driving

This button is on the driver side control panel.
To partially disable VSA

®

 functionality/

features, press and hold it until you hear a
beep.

Your vehicle will have normal braking and
cornering ability, but traction control function
will be less effective.

To restore VSA

®

 functionality/features, press

the

(VSA

®

 OFF) button until you hear a

beep.

VSA

®

 is turned on every time you start the

engine, even if you turned it off the last time
you drove the vehicle.

■

VSA

®

 On and Off

1

Vehicle Stability Assist

®

 (VSA

®

), aka Electronic Stability Control

(ESC), System

In certain unusual conditions when your vehicle gets
stuck in shallow mud or fresh snow, it may be easier
to free it with the VSA

®

 temporarily switched off.

When the

 button is pressed, the traction control

function becomes less effective. This allows for the
wheels to spin more freely at low speed. You should
only attempt to free your vehicle with the VSA

®

 off if

you are not able to free it when the VSA

®

 is on.

Immediately after freeing your vehicle, be sure to
switch VSA

®

 on again. We do not recommend driving

your vehicle with the VSA

®

 system switched off.

You may hear a motor sound coming from the
engine compartment while system checks are being
performed immediately after starting the engine or
while driving. This is normal.

VSA

®

 OFF Indicator

520

uu

When Driving

u

Agile Handling Assist

Driving

Agile Handling Assist

Lightly brakes each of the front and rear wheels, as needed, when you turn the
steering wheel, and helps support the vehicle’s stability and performance during
cornering.

1

Agile Handling Assist

The agile handling assist cannot enhance stability in
all driving situations. You still need to drive and
corner at speeds appropriate for the conditions and
always leave a sufficient margin of safety.

When the VSA

®

 system indicator comes on and stays

on while driving, the agile handling assist does not
activate.

You may hear a sound coming from the engine
compartment while the agile handling assist is
activated. This is normal.

521

uu

When Driving

u

Super Handling-All Wheel Drive

TM

 (SH-AWD

®

)

*

Driving

Super Handling-All Wheel Drive

TM

 (SH-AWD

®

)

*

The system controls and transfers varying amounts of engine torque to each wheel
in accordance with the driving conditions.

SH-AWD

®

 helps to enhance driving stability, and lets you handle situations like

slippery surfaces, such as on wet, icy, or snowy roads, better than when driving with
two wheel drive. However, the system does not help to enhance braking. Be
precautious about the following:

•

It is still your responsibility to drive safely when you steer, accelerate, and apply
brakes.

•

Leave a sufficient margin when braking on slippery surfaces.

1

Super Handling-All Wheel Drive

TM

 (SH-AWD

®

)

*

The SH-AWD

®

 system may not function properly if

tire type and size are mixed.
Make sure to use the same size and type of tire, and
the air pressures as specified.

2

Tire and Wheel Replacement

 P. 608

Do not continuously spin the front tires of your
vehicle. Continuously spinning the front tires can
cause damage to the transmission and SH-AWD

®



unit.

If the

SH-AWD

 indicator blinks while driving, it

indicates the differential temperature is too high. If
this happens, pull to the side of the road when it is
safe, change the gear position to

(

P

, and idle the

engine until the indicator goes out.

* Not available on all models

522

uu

When Driving

u

Tire Pressure Monitoring System (TPMS) with Tire Fill Assist

Driving

Tire Pressure Monitoring System (TPMS) with Tire
Fill Assist

Monitors the tire pressure while you are
driving. If your vehicle’s tire pressure becomes
significantly low, the low tire pressure/TPMS
indicator comes on and a message appears on
the MID.

1

Tire Pressure Monitoring System (TPMS) with Tire Fill Assist

Conditions such as low ambient temperature and
altitude change directly affect tire pressure and can
trigger the low tire pressure/TPMS indicator to come
on.

2

If the Low Tire Pressure/TPMS Indicator
Comes On or Blinks

 P. 660

Tire pressure checked and inflated in:

•

Warm weather can become under-inflated in
colder weather.

•

Cold weather can become over-inflated in warmer
weather.

The low tire pressure/TPMS indicator will not come
on as a result of over inflation.

The TPMS audibly and visually informs you of
changes in tire pressure of the individual tire that you
are adjusting using audible and visual indications.

If a change in tire pressure has been significant, the
system beeps and the hazard lights flash continuously
for five seconds when the specified tire pressure is
reached. Stop filling the tire.

Low Tire Pressure/
TPMS Indicator

523

uu

When Driving

u

Tire Pressure Monitoring System (TPMS) with Tire Fill Assist

Driving

To select the tire pressure monitor, set the power
mode to ON, and roll the multi-function
steering-wheel controls until you see the tire
pressure screen.

The pressure for each tire is displayed in psi
(U.S.) or kPa (Canada).

Tire Pressures Low

 is displayed when a tire

has significantly low pressure. The specific tire
is displayed on the screen.

■

Tire Pressure Monitor

1

Tire Pressure Monitor

The pressure displayed on the MID can be slightly
different from the actual pressure as measured by a
gauge. If there is a significant difference between the
two values, or if the low tire pressure/TPMS indicator
and the message on the MID do not go off after you
have inflated the tire to the specified pressure, have
the system checked by a dealer.

Tire Pressure Monitor Problem

 may appear if you

drive with the compact spare tire

*

, or there is a

problem with the TPMS.

* Not available on all models

524

uu

When Driving

u

Tire Pressure Monitoring System (TPMS) - Required Federal Explanation

Driving

Tire Pressure Monitoring System (TPMS) - Required
Federal Explanation

Each tire, including the spare (if provided), should be checked
monthly when cold and inflated to the inflation pressure
recommended by the vehicle manufacturer on the vehicle placard
or tire inflation pressure label.

(If your vehicle has tires of a different size than the size indicated
on the vehicle placard or tire inflation pressure label, you should
determine the proper tire inflation pressure for those tires.)

As an added safety feature, your vehicle has been equipped with
a tire pressure monitoring system (TPMS) that illuminates a low
tire pressure telltale

when one or more of your tires is significantly under-inflated.

Accordingly, when the low tire pressure telltale illuminates, you
should stop and check your tires as soon as possible, and inflate
them to the proper pressure.

Driving on a significantly under-inflated tire causes the tire to
overheat and can lead to tire failure. Under-inflation also reduces
fuel efficiency and tire tread life, and may affect the vehicle’s
handling and stopping ability.
