74

Safe Driving

Exhaust Gas Hazard

Carbon Monoxide Gas

The engine exhaust from this vehicle contains carbon monoxide, a colorless,
odorless, and highly toxic gas. As long as you properly maintain your vehicle, carbon
monoxide gas will not get into the interior.

■

Have the exhaust system inspected for leaks whenever

•

The exhaust system is making an unusual noise.

•

The exhaust system may have been damaged.

•

The vehicle is raised for an oil change.

When you operate a vehicle with the tailgate open, airflow can pull exhaust gas into
the interior and create a hazardous condition. If you must drive with the tailgate
open, open all the windows and set the climate control system as shown below.

1.

Select the fresh air mode.

2.

Select the

 mode.

3.

Set the fan speed to high.

4.

Set the temperature control to a comfortable setting.

Adjust the climate control system in the same manner if you sit in your parked
vehicle with the engine running.

1

Carbon Monoxide Gas

An enclosed area such as a garage can quickly fill up
with carbon monoxide gas.
Do not run the engine with the garage door closed.
Even when the garage door is open, drive out of the
garage immediately after starting the engine.

3

WARNING

Carbon monoxide gas is toxic.

Breathing it can cause unconsciousness and
even kill you.

Avoid any enclosed areas or activities that
expose you to carbon monoxide.

75

Safe Driving

Safety Labels

Label Locations

These labels are in the locations shown. They warn you of potential hazards that can cause serious injury or death. Read these labels
carefully.

If a label comes off or becomes hard to read (except for the U.S. dashboard label which may be removed by the owner), contact a dealer
for a replacement.

Radiator Cap

U.S. models only

Dashboard

Air Conditioner System
U.S. models

Sun Visor

U.S. models

Canadian models

U.S. models only

Sun Visor

78

In

strum

e

nt Pa

nel

Indicators

Indicator

Name

On/Blinking

Explanation

Message

Brake System
Indicator (Red)

●

Comes on for a few seconds
when you set the power mode to
ON, then goes off.

●

Comes on when the brake fluid
level is low.

●

Comes on if there is a problem
with the brake system.

●

Comes on while driving

 - Check the brake

fluid level.

2

What to do when the indicator comes on
while driving

 P. 658

●

Comes on along with the ABS indicator

 -

Have your vehicle checked by a dealer.

2

If the Brake System Indicator (Red)
Comes On

 P. 658

U.S.

Canada

(Red)

79

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Brake System
Indicator (Amber)

●

Comes on for a few seconds
when you set the power mode to
ON, then goes off.

●

Comes on if there is a problem
with a system related to braking
other than the conventional
brake system.

●

Comes on while driving

 - Have your vehicle

checked by a dealer.

●

With this indicator on, your vehicle still has
normal braking ability.

●

Comes on if there is a problem
with the automatic brake hold
system.

2

Automatic Brake Hold

 P. 533

U.S.

Canada

(Amber)

U.S.

Canada

U.S.

Canada

80

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Electric Parking
Brake Indicator

●

Comes on for a few seconds
when you set the power mode to
ON, then goes off.

●

Comes on when the parking
brake is applied, and goes off
when it is released.

●

Comes on for about 15 seconds
then goes off when you push the
electric parking brake switch with
the power mode in OFF.

●

Comes on for about 15 seconds
then goes off when you set the
power mode to OFF with the
parking brake applied.

●

Blinks and the electric parking brake
system indicator comes on at the same
time

 - There is a problem with the electric

parking brake system. The parking brake may
not be set.

●

Comes on when you pull the
electric parking brake switch
without depressing the brake
pedal.

●

Depress the brake pedal to release the parking
brake.

2

Parking Brake

 P. 529

Electric Parking
Brake System
Indicator

●

Comes on for a few seconds
when you set the power mode to
ON, then goes off.

●

Comes on if there is a problem
with the electric parking brake
system.

●

Comes on while driving

 - Avoid using the

parking brake and have your vehicle checked
by a dealer immediately.

2

If the Electric Parking Brake System
Indicator Comes On

 P. 659

U.S.

Canada

81

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Automatic Brake
Hold System
Indicator

●

Comes on for a few seconds
when you set the power mode to
ON, then goes off.

●

Comes on when the automatic
brake hold system is on.

2

Automatic Brake Hold

 P. 533

Automatic Brake
Hold Indicator

●

Comes on for a few seconds
when you set the power mode to
ON, then goes off.

●

Comes on when the automatic
brake hold is activated.

2

Automatic Brake Hold

 P. 533

—

U.S.

Canada

82

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Low Oil Pressure
Indicator

●

Comes on when you set the
power mode to ON, and goes off
when the engine starts.

●

Comes on when the engine oil
pressure is low.

●

Comes on while driving

 - Immediately stop

in a safe place.

2

If the Low Oil Pressure Indicator Comes
On

 P. 656

Malfunction
Indicator Lamp

●

Comes on when you set the
power mode to ON, and goes off
either when the engine starts or
after several seconds if the
engine did not start. If “readiness
codes” have not been set, it
blinks five times before it goes
off.

●

Comes on if there is a problem
with the emissions control
systems.

●

Blinks when a misfire in the
engine’s cylinders is detected.

●

Readiness codes are part of the on board
diagnostics for the emissions control systems.

2

Testing of Readiness Codes

 P. 681

●

Comes on while driving

 - Have your vehicle

checked by a dealer.

●

Blinks while driving

 - Stop in a safe place

where there are no flammable objects. Stop
the engine for 10 minutes or more, and wait
for it to cool down. Then, take your vehicle to
a dealer.

2

If the Malfunction Indicator Lamp Comes
On or Blinks

 P. 657

Charging System
Indicator

●

Comes on when you set the
power mode to ON, and goes off
when the engine starts.

●

Comes on when the battery is
not charging.

●

Comes on while driving

 - Turn off the

climate control system and rear defogger in
order to reduce electricity consumption.

2

If the Charging System Indicator Comes
On

 P. 656

83

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Gear Position
Indicator

●

Indicates the current gear
selection.

2

Shifting

 P. 472

—

M

 (sequential

mode) Indicator/
Sequential Mode
Gear Selection
Indicator

●

Comes on when the manual
sequential shift mode is applied.

2

Sequential Mode

 P. 478

—

84

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Transmission
System Indicator

●

The indicated current gear
selection blinks if there is a
problem with the transmission
system.

●

Avoid sudden start and acceleration, and stop
in a safe place immediately.
Have your vehicle checked by a dealer.

●

All the gear positions may light
for several seconds, and go off.

●

When all the gear positions light, immediately
stop your vehicle in a safe place.

●

Indicators go off if there is no problem.
However, even if they go off, take your vehicle
to a dealer for inspection.

●

The indicated current gear
selection or all the gear positions
blink if there is a problem with
the transmission system, and the
vehicle no longer moves.

●

Immediately stop in a safe place.

2

Emergency Towing

 P. 670

●

Have your vehicle checked by a dealer.

●

The indicated current gear
selection or all the gear positions
blink if you cannot select

(

P

 due

to the transmission system
failure.

●

The engine can be activated as a temporary
measure.

2

If the Transmission System Indicator
Blinks along with the Warning Message



P. 661

●

Set the parking brake when parking.

●

Have your vehicle checked by a dealer
immediately.

85

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Seat Belt
Reminder
Indicator

●

Comes on and the beeper sounds
if you are not wearing a seat belt
when you set the power mode to
ON.

●

If the front passenger is not
wearing a seat belt, the indicator
comes on about a few seconds
later.

●

Blinks while driving if either you
and/or the front passenger has
not fastened a seat belt. The
beeper sounds and the indicator
blinks at regular intervals.

●

The beeper stops and the indicator goes off
when you and the front passenger fasten their
seat belts.

●

Stays on after you and/or the front
passenger has fastened the seat belt(s)

 -

A detection error may have occurred in the
sensor. Have your vehicle checked by a dealer.

2

Seat Belt Reminder

 P. 34

Low Fuel Indicator

●

Comes on when the fuel reserve
is running low (approximately 2.5
U.S. gal./9.5 Liter left).

●

Blinks if there is a problem with
the fuel gauge.

●

Comes on

 - Refuel your vehicle as soon as

possible.

●

Blinks

 - Have your vehicle checked by a

dealer.

86

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Anti-lock Brake
System (

ABS

)

Indicator

●

Comes on for a few seconds
when you set the power mode to
ON, then goes off.

●

If it comes on at any other time,
there is a problem with the ABS.

●

Stays on constantly

 - Have your vehicle

checked by a dealer. With this indicator on,
your vehicle still has normal braking ability but
no anti-lock function.

2

Anti-lock Brake System (ABS)

 P. 535

Supplemental
Restraint System
Indicator

●

Comes on for a few seconds
when you set the power mode to
ON, then goes off.

●

Comes on if a problem with any
of the following is detected:

-

Supplemental restraint system

-

Side airbag system

-

Side curtain airbag system

-

Seat belt tensioner

●

Stays on constantly or does not come on
at all

 - Have your vehicle checked by a dealer.

Auto High-Beam
Indicator

●

Comes on when all the operating
conditions of the Auto high-
beam are met.

2

Auto High-Beam

 P. 176

—

87

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Vehicle Stability
Assist

®

 (VSA

®

)

System Indicator

●

Comes on for a few seconds
when you set the power mode to
ON, then goes off.

●

Blinks when VSA

®

, or trailer

stability assist is active.

●

Comes on if there is a problem
with the VSA

®

, hill start assist,

trailer stability assist or brake
lighting system.

●

Stays on constantly

 - Have your vehicle

checked by a dealer.

2

Vehicle Stability Assist

®

 (VSA

®

), aka

Electronic Stability Control (ESC), System



P. 518

2

Trailer Stability Assist

 P. 459

2

Hill start assist system

 P. 469

●

When

Trailer Stability Assist Problem

 is

displayed on the MID, the VSA

®

 does not

activate.

Vehicle Stability
Assist

®

 (VSA

®

) OFF

Indicator

●

Comes on for a few seconds
when you set the power mode to
ON, then goes off.

●

Comes on when you partially
disable VSA

®

.

2

VSA

®

 On and Off

 P. 519

—

88

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Speed-sensitive
Electric Power
Steering (EPS)
System Indicator

●

Comes on when you set the
power mode to ON, and goes off
when the engine starts.

●

Comes on if there is a problem
with the EPS system.

●

Stays on constantly or does not come on
at all

 - Have your vehicle checked by a dealer.

2

If the Speed-Sensitive Electric Power
Steering (EPS) System Indicator Comes
On

 P. 658

Low Tire Pressure/
TPMS Indicator

●

Comes on for a few seconds
when you set the power mode to
ON, then goes off.

●

Comes on if the tire pressure of
any of the tires becomes
significantly low.

●

Blinks for about one minute, and
then stays on if there is a problem
with the TPMS, or when a spare
tire

*

 is temporarily installed.

●

Comes on while driving

 - Stop in a safe

place, check tire pressures, and inflate the
tire(s) if necessary.

●

Blinks and remains on

 - Have your vehicle

checked by a dealer. If the vehicle is fitted with
a spare, get your regular tire repaired or
replaced and put back on your vehicle as soon
as you can.

Turn Signal and
Hazard Warning
Indicators

●

Blinks when you operate the turn
signal lever.

●

Blink along with all turn signals
when you press the hazard
warning button.

●

Does not blink or blinks rapidly

2

Replacing Light Bulbs

 P. 593

—

High Beam
Indicator

●

Comes on when the high beam
headlights are on.

—

—

* Not available on all models

89

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Lights On
Indicator

●

Comes on when the light switch
in a position other than

OFF

 or

when the switch is set to

AUTO



and the exterior lights come on.

●

If you set the power mode to ACCESSORY or
VEHICLE OFF (LOCK) while the exterior lights
are on, a chime sounds when the driver’s door
is opened.

—

Fog Light
Indicator

*

●

Comes on when the fog lights
are on.

—

—

Immobilizer
System Indicator

●

Comes on briefly when you set
the power mode to ON, then
goes off.

●

Comes on if the immobilizer
system cannot recognize the key
information.

●

Blinks

 - You cannot start the engine. Set the

power mode to VEHICLE OFF (LOCK), then
select the ON mode again.

●

Repeatedly blinks

 - The system may be

malfunctioning. Have your vehicle checked by
a dealer.

●

Do not attempt to alter this system or add
other devices to it. Electrical problems can
occur.

—

* Not available on all models

90

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Security System
Alarm Indicator

●

Blinks when the security system
alarm has been set.

2

Security System Alarm

 P. 162

—

System Message
Indicator

●

Comes on for a few seconds
when you set the power mode to
ON, then goes off.

●

Comes on along with a beep
when a problem is detected. A
system message on the MID
appears at the same time.

●

While the indicator is on, roll the multi-
function steering wheel control to see the
message again.

●

Refer to the Indicators information in this
chapter when a system message appears on
the MID. Take the appropriate action for the
message.

●

The MID does not return to the normal screen
unless the warning is canceled, or the multi-
function steering-wheel controls is rolled.

—

91

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Keyless Access
System Indicator

●

Comes on for a few seconds
when you set the power mode to
ON, then goes off.

●

Comes on as soon as a problem is
detected in the keyless access
system or keyless starting system.

●

Have your vehicle checked by a dealer.

Super Handling-
All Wheel Drive

TM



(

SH-AWD

®

)

Indicator

*

●

Comes on for a few seconds
when you set the power mode to
ON, then goes off.

●

Comes on if there is a problem
with the SH-AWD

®

 system.

●

Blinks when the differential
temperature is too high.

●

Stays on constantly

 - The engine drives the

front wheels only in this state. Have your
vehicle checked by a dealer.

●

Blinks while driving

 - Stop in a safe place,

put the transmission into

(

P

, and idle the

engine until the indicator goes off. If the
indicator does not stop blinking, take your
vehicle to a dealer.

2

Super Handling-All Wheel Drive

TM

 (SH-

AWD

®

)

*

 P. 521

* Not available on all models
