58

uu

Child Safety

u

Safety of Infants and Small Children

Safe Driving

Safety of Infants and Small Children

An infant must be properly restrained in a rear-facing, reclining child seat until the
infant reaches the seat manufacturer’s weight or height limit for the seat, and the
infant is at least one year old.

■

Positioning a rear-facing child seat

Child seats must be placed and secured in a
rear seating position.

When properly installed, a rear-facing child seat may prevent the driver or a front
passenger from moving their seat all the way back, or from locking their seat-back
in the desired position. Make sure that there is no contact between the child seat
and the seat in front of it.

It can also interfere with proper operation of the passenger’s advanced front airbag
system.

2

Airbags

 P. 41

If this occurs, we recommend that you install the child seat directly behind the front
passenger’s seat, move the seat as far forward as needed, and leave it unoccupied.
Or, you may wish to get a smaller rear-facing child seat.

■

Protecting Infants

1

Protecting Infants

Many experts recommend use of a rear-facing seat
for a child up to two years old if the child’s height and
weight are appropriate for a rear-facing seat.

Rear-facing child seats should never be installed in a
forward-facing position.

Always refer to the child seat manufacturer’s
instructions before installation.

Do not allow a front seat to rest against a child seat
installed in a rear seating position:
The weight sensor in the front seat may not correctly
detect the actual weight of the occupant.

3

WARNING

Placing a rear-facing child seat in the front
seat can result in serious injury or death
during a crash.

Always place a rear-facing child seat in the
rear seat, not the front.

Continued

59

uu

Child Safety

u

Safety of Infants and Small Children

Safe Driving

If a child is at least one year old and has exceeded the weight and height limitations
of a rearward-facing child seat, the child should be properly restrained in a firmly
secured forward-facing child seat until they exceed the weight and height
limitations for the forward-facing child seat.

■

Forward-facing child seat placement

We strongly recommend placing a forward-
facing child seat in a rear seating position.

Placing a forward-facing child seat in the front seat can be hazardous, even with
advanced front airbags that automatically turn the passenger’s front airbag off. A
rear seat is the safest place for a child.

■

Protecting Smaller Children

1

Protecting Smaller Children

Educate yourself about the laws and regulations
regarding child seat use where you are driving, and
follow the child seat manufacturer’s instructions.

3

WARNING

Placing a forward-facing child seat in the
front seat can result in serious injury or
death if the front airbag inflates.

If you must place a forward-facing child
seat in front, move the vehicle seat as far
back as possible, and properly restrain the
child.

uu

Child Safety

u

Safety of Infants and Small Children

60

Safe Driving

Most child seats are LATCH-compatible (Lower Anchors and Tethers for CHildren).
Some have a rigid-type connector while others have a flexible-type connector. Both
are equally easy to use. Some existing and previously owned child seats can only be
installed using the seat belt. Whichever type you choose, follow the child seat
manufacturer’s use and care instructions including recommended expiration dates
as well as the instructions in this manual. Proper installation is key to maximizing
your child’s safety.

In seating positions and vehicles not equipped with LATCH, a LATCH-compatible
child seat can be installed using the seat belt and a top tether for added security.
This is because all child seats are required to be designed so that they can be secured
with a lap belt or the lap part of a lap/shoulder belt. In addition, the child seat
manufacturer may advise that a seat belt be used to attach a LATCH-compatible seat
once a child reaches a specified weight. Please read the child seat owner’s manual
for proper installation instructions.

■

Important consideration when selecting a child seat

Make sure the child seat meets the following three requirements:

•

The child seat is the correct type and size for the child.

•

The child seat is the correct type for the seating position.

•

The child seat is compliant with Federal Motor Vehicle Safety Standard 213 or
Canadian Motor Vehicle Safety Standard 213.

■

Selecting a Child Seat

1

Selecting a Child Seat

Installation of a LATCH-compatible child seat is
simple.

LATCH-compatible child seats have been developed
to simplify the installation process and reduce the
likelihood of injuries caused by incorrect installation.

Continued

61

uu

Child Safety

u

Safety of Infants and Small Children

Safe Driving

A LATCH-compatible child seat can be installed in the second row seats. A child seat
is attached to the lower anchors with either the rigid or flexible type of connectors.

1.

Locate the lower anchors under the marks.

■

Installing a LATCH-Compatible Child Seat

1

Installing a LATCH-Compatible Child Seat

3

WARNING

Never attach two child seats to the same
anchor. In a collision, one anchor may not
be strong enough to hold two child seat
attachments and may break, causing
serious injury or death.

Models with second row captain seat

Marks

Marks

Models with second row bench seat

uu

Child Safety

u

Safety of Infants and Small Children

62

Safe Driving

2.

Place the child seat on the vehicle seat, then
attach the child seat to the lower anchors
according to the instructions that came
with the child seat.

u

When installing the child seat, make sure
that the lower anchors are not
obstructed by the seat belt or any other
object.

Rigid Type

Lower Anchors

Flexible Type

1

Installing a LATCH-Compatible Child Seat

For your child’s safety, when using a child seat
installed using the LATCH system, make sure that the
child seat is properly secured to the vehicle.
A child seat that is not properly secured will not
adequately protect a child in a crash and may cause
injury to the child or other vehicle occupants.

63

uu

Child Safety

u

Safety of Infants and Small Children

Continued

Safe Driving

Second row captain seat

3.

Put the outer head restraint to its upper-
most position, then route the tether strap
between the head restraint legs, and secure
the tether strap hook to the anchor. Make
sure the strap is not twisted.

3.

Put the outer head restraint to its upper
most position, then route the tether strap
outside the head restraint legs, and secure
the tether strap hook to the anchor. Make
sure the strap is not twisted.

4.

Tighten the tether strap as instructed by the
child seat manufacturer.

5.

Make sure the child seat is firmly secured by
rocking it forward and back and side to
side; little movement should be felt.

6.

Make sure any unused seat belt that a child
can reach is buckled, the lockable retractor
is activated, and the belt is fully retracted
and locked.

2

Protecting Child Passengers

 P. 56

Straight Top Tether Type

Tether Strap Hook

Anchor

Tether Strap Hook

Anchor

Other Top Tether Type

Straight Top Tether Type

Other Top Tether Type

All Types

64

uu

Child Safety

u

Safety of Infants and Small Children

Safe Driving

Second row bench seat

3.

Put the outer head restraint to its
uppermost position, then route the tether
strap between the head restraint legs, and
secure the tether strap hook to the anchor.
Make sure the strap is not twisted.

3.

Put the outer head restraint to its upper
most position, then route the tether strap
outside the head restraint legs, and secure
the tether strap hook to the anchor. Make
sure the strap is not twisted.

3.

Put the center head restraint to its lowest
position, then route the tether strap over
the top of the head restraint and secure the
tether strap hook to the anchor. Make sure
the strap is not twisted.

Tether Strap Hook

Anchor

Straight Top Tether Type

Tether Strap Hook

Anchor

Other Top Tether Type

Outer position

Straight Top Tether Type

Outer position

Other Top Tether Type

Center position

65

uu

Child Safety

u

Safety of Infants and Small Children

Continued

Safe Driving

4.

Tighten the tether strap as instructed by the
child seat manufacturer.

5.

Make sure the child seat is firmly secured by
rocking it forward and back and side to
side; little movement should be felt.

6.

Make sure any unused seat belt that a child
can reach is buckled, the lockable retractor
is activated, and the belt is fully retracted
and locked.

2

Protecting Child Passengers

 P. 56

All positions

uu

Child Safety

u

Safety of Infants and Small Children

66

Safe Driving

A child seat can be installed with a lap/shoulder belt in any rear seat or, if absolutely
necessary, the front passenger seat.

1.

Place the child seat on the vehicle seat.

2.

Route the seat belt through the child seat
according to the seat manufacturer’s
instructions, and insert the latch plate into
the buckle.

u

Insert the latch plate fully until it clicks.

3.

Slowly pull the shoulder part of the belt all
the way out until it stops. This activates the
lockable retractor.

4.

Let the seat belt retract a few inches and
check that the retractor has switched
modes by pulling on the webbing. It should
not pull out again until it is reset by
removing the latch plate from the buckle.

u

If you are able to pull the shoulder belt
out, the lockable retractor is not
activated. Slowly pull the seat belt all the
way out, and repeat steps 3 – 4.

■

Installing a Child Seat with a Lap/Shoulder Seat Belt

1

Installing a Child Seat with a Lap/Shoulder Seat Belt

A child seat that is not properly secured will not
adequately protect a child in a crash and may cause
injury to the child or other vehicle occupants.

Continued

67

uu

Child Safety

u

Safety of Infants and Small Children

Safe Driving

5.

Grab the shoulder part of the seat belt near
the buckle, and pull up to remove any slack
from the lap part of the belt.

u

When doing this, place your weight on
the child seat and push it into the vehicle
seat.

6.

Make sure the child seat is firmly secured by
rocking it forward and back and side to
side; less than one inch of movement
should occur near the seat belt.

7.

Make sure any unused seat belt that a child
can reach is buckled, the lockable retractor
is activated, and the belt is fully retracted
and locked.

1

Installing a Child Seat with a Lap/Shoulder Seat Belt

To deactivate a lockable retractor, release the buckle
and allow the seat belt to wind up all the way.

uu

Child Safety

u

Safety of Infants and Small Children

68

Safe Driving

A tether anchorage point is provided behind
each second and third row seating position.
If you have a child seat that comes with a
tether but can be installed with a seat belt, the
tether may be used for additional security.

■

Adding Security with a Tether

1

Adding Security with a Tether

Always use a tether for forward-facing child seats
when using the seat belt or lower anchors.

Models with second row captain seat

Tether Anchorage Points

Tether Anchorage Points

Models with second row bench seat

Tether Anchorage Points

Third row seat

69

uu

Child Safety

u

Safety of Infants and Small Children

Continued

Safe Driving

■

Using a second row anchor

1.

Put the outer head restraint to its upper-
most position, then route the tether strap
between the head restraint legs, and secure
the tether strap hook to the anchor. Make
sure the strap is not twisted.

1.

Put the outer head restraint to its upper
most position, then route the tether strap
outside the head restraint legs, and secure
the tether strap hook to the anchor. Make
sure the strap is not twisted.

Models with second row captain seat

Anchor

Tether Strap Hook

Tether Strap Hook

Anchor

Other Top Tether Type

Straight Top Tether Type

Outer positions

Straight Top Tether Type

Outer positions

Other Top Tether Type

70

uu

Child Safety

u

Safety of Infants and Small Children

Safe Driving

1.

Put the center head restraint to its lowest
position, then route the tether strap over
the top of the head restraint and secure the
tether strap hook to the anchor. Make sure
the strap is not twisted.

2.

Tighten the tether strap as instructed by the
child seat manufacturer.

Anchor

Models with second row bench seat

Tether Strap Hook

Tether Strap Hook

Anchor

Other Top Tether Type

Straight Top Tether Type

Center position of second row bench seat

All positions

71

uu

Child Safety

u

Safety of Infants and Small Children

Safe Driving

■

Using a third row anchor

1.

Pull up the head restraint and push
rearwards until it latches, then route the
tether strap through the head restraint legs.
Make sure the strap is not twisted.

1.

Pull up the head restraint and push
rearwards until it latches, then route the
tether strap outside the head restraint legs.
Make sure the strap is not twisted.

2.

Open the anchor cover.

3.

Secure the tether strap hook to the anchor.

4.

Tighten the tether strap as instructed by the
child seat manufacturer.

Other Top Tether Type

Tether Strap Hook

Anchor

Third row seat

Straight Top Tether Type

Anchor

Tether Strap Hook

Straight Top Tether Type

Other Top Tether Type

All Types

72

uu

Child Safety

u

Safety of Larger Children

Safe Driving

Safety of Larger Children

The following pages give instructions on how to check proper seat belt fit, what kind
of booster seat to use if one is needed, and important precautions for a child who
must sit in front.

When a child is too big for a child seat, secure the child in a rear seat using the lap/
shoulder seat belt. Have the child sit upright and all the way back, then answer the
following questions.

■

Checklist

•

Do the child’s knees bend comfortably over
the edge of the seat?

•

Does the shoulder belt cross between the
child’s neck and arm?

•

Is the lap part of the seat belt as low as
possible, touching the child’s thighs?

•

Will the child be able to stay seated like this
for the whole trip?

If you answer yes to all these questions, the child is ready to wear the lap/shoulder
seat belt correctly. If you answer no to any question, the child needs to ride on a
booster seat until the seat belt fits properly without a booster seat.

■

Protecting Larger Children

■

Checking Seat Belt Fit

1

Safety of Larger Children

3

WARNING

Allowing a child age 12 or under to sit in
front can result in injury or death if the
passenger’s front airbag inflates.

If a larger child must ride in front, move the
vehicle seat as far to the rear as possible,
have the child sit up properly and wear the
seat belt properly, using a booster seat if
needed.

73

uu

Child Safety

u

Safety of Larger Children

Safe Driving

If a lap/shoulder seat belt cannot be used
properly, position the child in a booster seat in
the rear seat. For the child’s safety, check that
the child meets the booster seat
manufacturer’s recommendations.

Your vehicle has a rear seat where children can be properly restrained. If you ever
have to carry a group of children, and a child must ride in front:

•

Make sure you read and fully understand the instructions and safety information
in this manual.

•

Move the front passenger seat as far back as possible.

•

Have the child sit upright and well back in the seat.

•

Check that the seat belt is properly positioned so that the child is secure in the
seat.

■

Monitoring child passengers

We strongly recommend that you keep an eye on child passengers. Even older, more
mature children sometimes need to be reminded to fasten their seat belts and sit up
properly.

■

Booster Seats

1

Booster Seats

When installing a booster seat, make sure to read the
instructions that came with it, and install the seat
accordingly.
There are high- and low-type booster seats. Choose a
booster seat that allows the child to wear the seat
belt correctly.

Some U.S. states and Canadian provinces and
territories require children to use a booster seat until
they reach a given age or weight (e.g. 6 years or 60
lbs). Be sure to check current laws in the state or
province, or territory where you intend to drive.

■

Protecting Larger Children-Final Checks
