IN CASE OF EMERGENCY

395

-W

HEEL

RIVE

ODELS

FCA US LLC recommends towing your vehicle with

all four wheels OFF the ground using a flatbed.
If flatbed equipment is not available, and the

transmission is operable, the vehicle may be towed

(with front wheels on the ground) under the

following conditions:



The transmission must be in NEUTRAL (N).

Instructions on shifting the transmission to

NEUTRAL (N) when the engine is OFF

page 392.



The towing speed must not exceed 30 mph

(48 km/h).



The towing distance must not exceed 30 miles

(48 km).

If the transmission is not operable, or the vehicle

must be towed faster than 30 mph (48 km/h) and

farther than 30 miles (48 km), tow with the rear

wheels OFF the ground. An acceptable method to

tow the vehicle on a flatbed are as follows:



Using a suitable steering wheel stabilizer to hold

the front wheels in the straight position with the

rear wheels raised and the front wheels ON the

ground.

OUR

-W

HEEL

RIVE

ODELS

FCA US LLC recommends towing with all wheels

OFF the ground.

CAUTION!



Do not use sling type equipment when towing.

Vehicle damage may occur.



When securing the vehicle to a flatbed truck,

do not attach to front or rear suspension

components. Damage to your vehicle may

result from improper towing.

CAUTION!

Towing this vehicle in violation of the above

requirements can cause severe transmission

damage. Damage from improper towing is not

covered under the New Vehicle Limited

Warranty.

CAUTION!



Front or rear wheel lifts must not be used (if

the remaining wheels are on the ground).

Internal damage to the transmission or

transfer case will occur if a front or rear wheel

lift is used when towing.



Towing this vehicle in violation of the above

requirements can cause severe transmission

and/or transfer case damage. Damage from

improper towing is not covered under the New

Vehicle Limited Warranty.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

396

IN CASE OF EMERGENCY

MERGENCY

OOKS

—

QUIPPED

Your vehicle may be equipped with emergency tow

hooks.

Emergency Tow Hooks

NOTE:

For off-road recovery, it is recommended to use

both of the front tow hooks to minimize the risk of

damage to the vehicle.

ENHANCED ACCIDENT RESPONSE SYSTEM

(EARS)

This vehicle is equipped with an Enhanced

Accident Response System.
This feature is a communication network that

takes effect in the event of an impact

page 356.

EVENT DATA RECORDER (EDR)

This vehicle is equipped with an event data

recorder (EDR). The main purpose of an EDR is to

record data that will assist in understanding how a

vehicle’s systems performed under certain crash

or near crash-like situations, such as an air bag

deployment or hitting a road obstacle

page 357.

WARNING!



Do not use a chain for freeing a stuck vehicle.

Chains may break, causing serious injury or

death.



Stand clear of vehicles when pulling with tow

hooks. Tow straps may become disengaged,

causing serious injury.

CAUTION!

Tow hooks are for emergency use only, to rescue

a vehicle stranded off road. Do not use tow

hooks for tow truck hookup or highway towing.

You could damage your vehicle.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

397

SERVICING AND MAINTENANCE

SCHEDULED SERVICING — GASOLINE

ENGINE

Your vehicle is equipped with an automatic oil

change indicator system. The oil change indicator

system will remind you that it is time to take your

vehicle in for scheduled maintenance.
Based on engine operation conditions, the oil

change indicator message will illuminate. This

means that service is required for your vehicle.

Operating conditions such as frequent short-trips,

trailer tow, and extremely hot or cold ambient

temperatures will influence when the “Oil Change

Required” message is displayed. Have your vehicle

serviced as soon as possible, within the next

500 miles (805 km).

An authorized dealer will reset the oil change

indicator message after completing the scheduled

oil change. If a scheduled oil change is performed

by someone other than an authorized dealer, the

message can be reset by referring to the steps

described under Instrument Cluster Display

page 115.

NOTE:

Under no circumstances should oil change

intervals exceed 10,000 miles (16,000 km),

12 months or 350 hours of engine run time,

whichever comes first. The 350 hours of engine

run or idle time is generally only a concern for fleet

customers.

Once A Month Or Before A Long Trip:



Check engine oil level.



Check windshield washer fluid level.



Check tire pressure and look for unusual wear

or damage. Rotate tires at the first sign of irreg

ular wear, even if it occurs before the oil indi

cator system turns on.



Check the fluid levels of the coolant reservoir,

brake master cylinder, and fill as needed.



Check function of all interior and exterior lights.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

398

SERVICING AND MAINTENANCE

AINTENANCE

LAN

Refer to the Maintenance Plan for required maintenance. More frequent maintenance may be needed in severe conditions, such as dusty areas and very short

trip driving. In some extreme conditions, additional maintenance not specified in the maintenance schedule may be required.

NOTE:

Using white lithium grease, lubricate the door hinge roller pivot joints twice a year to prevent premature wear.

At Every Oil Change Interval As Indicated By Oil Change Indicator System:



Change the oil and filter.



Rotate the tires at the first sign of irregular wear, even if it occurs before the oil indicator system turns on.



Inspect the battery and clean and tighten terminals as required.



Inspect the CV/Universal joints.



Inspect the brake pads, shoes, rotors, drums, and hoses.



Inspect the engine cooling system protection and hoses.



Inspect the exhaust system.



Inspect the engine air cleaner if using in dusty or off-road conditions, replace the engine air cleaner, as necessary.



Inspect and replace the Evaporative System Fresh Air Filter as necessary; replacement may be more frequent if vehicle is operated in extreme dusty condi

tions.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SERVICING AND MAINTENANCE

399

Mileage or time passed (whichever

comes first)

20,000

30,000

40,000

50,000

60,000

70,000

80,000

90,000

100,000

110,000

120,000

130,000

140,000

150,000

Or Years:

Or Kilometers:

32,000

48,000

64,000

80,000

96,000

112,000

128,000

144,000

160,000

176,000

192,000

208,000

224,000

240,000

Additional Inspections
Inspect the CV/Universal joints.

Inspect front suspension, tie rod ends,

and replace if necessary.

Inspect the front and rear axle surfaces.

If gear oil leakage is suspected, check

the fluid level. If using your vehicle for

police, taxi, fleet, off-road or frequent

trailer towing, change axle fluid.

Inspect the brake linings, replace as

necessary.

Inspect transfer case fluid.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

400

SERVICING AND MAINTENANCE

Additional Maintenance
Replace cabin air filter.

To be replaced every 12,000 mi (19,000 km).

For severe dusty driving conditions,

inspect and replace the Evaporative

System Fresh Air Filter as necessary;

replacement may be more frequent

depending on conditions.

Replace engine air cleaner.

If equipped with Stop/Start, replace

accessory drive belt with OEM grade

Mopar® belt.

Replace spark plugs.

Flush and replace the engine coolant at

10 years or 150,000 miles (240,000 km)

whichever comes first.

Inspect the transfer case fluid, change for

any of the following: police, taxi, fleet, or

frequent trailer towing.

Mileage or time passed (whichever

comes first)

20,000

30,000

40,000

50,000

60,000

70,000

80,000

90,000

100,000

110,000

120,000

130,000

140,000

150,000

Or Years:

Or Kilometers:

32,000

48,000

64,000

80,000

96,000

112,000

128,000

144,000

160,000

176,000

192,000

208,000

224,000

240,000

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SERVICING AND MAINTENANCE

401

Change the transfer case fluid.

Inspect and replace PCV valve if

necessary.

1. The spark plug change interval is mileage-based only; yearly intervals do not apply.

Mileage or time passed (whichever

comes first)

20,000

30,000

40,000

50,000

60,000

70,000

80,000

90,000

100,000

110,000

120,000

130,000

140,000

150,000

Or Years:

Or Kilometers:

32,000

48,000

64,000

80,000

96,000

112,000

128,000

144,000

160,000

176,000

192,000

208,000

224,000

240,000

WARNING!



You can be badly injured working on or around a motor vehicle. Do only service work for which you have the knowledge and the right equipment. If you have

any doubt about your ability to perform a service job, take your vehicle to a competent mechanic.



Failure to properly inspect and maintain your vehicle could result in a component malfunction and effect vehicle handling and performance. This could

cause an accident.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

402

SERVICING AND MAINTENANCE

SCHEDULED SERVICING — DIESEL ENGINE

Your vehicle is equipped with an automatic oil

change indicator system. The oil change indicator

system will remind you that it is time to take your

vehicle in for scheduled maintenance.
Based on engine operation conditions, the oil

change indicator message will illuminate. This

means that service is required for your vehicle.

Operating conditions such as frequent short-trips,

trailer tow, extremely hot or cold ambient

temperatures will influence when the “Oil Change

Required” message is displayed. Have your vehicle

serviced as soon as possible, within the next

500 miles (805 km).

An authorized dealer will reset the oil change

indicator message after completing the scheduled

oil change. If a scheduled oil change is performed

by someone other than an authorized dealer, the

message can be reset by referring to the steps

described under Instrument Cluster Display

page 115.

NOTE:

Under no circumstances should oil change

intervals exceed 10,000 miles (16,000 km) or

12 months, whichever comes first.

Once A Month Or Before A Long Trip:



Check engine oil level.



Check windshield washer fluid level.



Check the tire inflation pressures and look for

unusual wear or damage.



Check the fluid levels of the coolant reservoir,

brake master cylinder, and power steering, and

fill as needed.



Check function of all interior and exterior lights.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SERVICING AND MAINTENANCE

403

AINTENANCE

LAN

— D

IESEL

UEL

B5 B

IODIESEL

Refer to the Maintenance Schedules for required maintenance.

NOTE:

Using white lithium grease, lubricate the door hinge roller pivot joints twice a year to prevent premature wear.

At Every Oil Change Interval As Indicated By Oil Change Indicator System:



Change oil and filter.



Completely fill the Diesel Exhaust Fluid tank.



Drain water from fuel filter assembly.



Rotate the tires at the first sign of irregular wear, even if it occurs before the oil indicator system turns on.



Inspect battery and clean and tighten terminals as required.



Inspect the CV/Universal joints.



Inspect brake pads, shoes, rotors, drums, hoses and parking brake.



Inspect engine cooling system protection and hoses.



Inspect exhaust system.



Inspect engine air cleaner filter if using in dusty or off-road conditions. Replace engine air cleaner, as necessary.

At Every Second Oil Change Interval As Indicated By Oil Change Indicator System:



Change fuel filter.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

404

SERVICING AND MAINTENANCE

Mileage or time passed (whichever comes first)

10,000

20,000

30,000

40,000

50,000

60,000

70,000

80,000

90,000

100,000

110,000

120,000

130,000

140,000

150,000

Or Years:

Or Kilometers:

16,000

32,000

48,000

64,000

80,000

96,000

112,000

128,000

144,000

160,000

176,000

192,000

208,000

224,000

240,000

Additional Inspections
Completely fill the Diesel Exhaust Fluid tank.

Inspect the CV/Universal joints.

Inspect front suspension, tie rod ends, and replace if necessary.

Inspect the front and rear axle fluid. If gear oil leakage is

suspected, check the fluid level. If using your vehicle for police,

taxi, fleet, off-road or frequent trailer towing change the axle

fluid.

Inspect the brake linings, parking brake function.

Additional Maintenance
Replace cabin air filter.

To be replaced every 12,000 mi (19,000 km).

Drain water from fuel filter assembly.

Replace fuel filter and drain water from the fuel filter assembly.

Fuel filter replacement intervals should be every second oil change and must not exceed

20,000 miles (32,000 km) if using diesel fuel up to B5.

Replace engine air cleaner.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SERVICING AND MAINTENANCE

405

Flush and replace the engine coolant at 10 years or

150,000 miles (240,000 km) whichever comes first.

Replace accessory drive belt(s).

Inspect the transfer case fluid, change for any of the following:

police, taxi, fleet, or frequent trailer towing.

Change transfer case fluid.

1. Under normal conditions the diesel fuel filter should be replaced every 20,000 miles (32,000 km) (every other oil change). If the vehicle is being used in severe operating conditions,

or in certain geographical areas of the country (Pennsylvania, New York, Ohio, Maryland, West Virginia, Arkansas, Oklahoma, Kansas, Iowa, Missouri and Nebraska) due to fuel

cleanliness issues, it’s recommended to replace the fuel filter every 10,000 miles (16,000 km).

Mileage or time passed (whichever comes first)

10,000

20,000

30,000

40,000

50,000

60,000

70,000

80,000

90,000

100,000

110,000

120,000

130,000

140,000

150,000

Or Years:

Or Kilometers:

16,000

32,000

48,000

64,000

80,000

96,000

112,000

128,000

144,000

160,000

176,000

192,000

208,000

224,000

240,000

-------------------------------------------------------------------------------------------------------------------------------------------------------------

406

SERVICING AND MAINTENANCE

DDITIONAL

AINTENANCE

— B6 T

B20 B

IODIESEL

NOTE:



Under no circumstances should oil change inter

vals exceed 8,000 miles (12,875 km) or six

months, whichever comes first when using

biodiesel blends greater than 5% (B5).



The owner is required to monitor mileage for

B6-B20 biodiesel, the automatic oil change indi

cator system does not reflect the use of

biofuels.



Fuel filter change interval is maintained at every

second oil change. This is especially important

with biodiesel usage.

For more information on using biodiesel

page 475.

WARNING!



You can be badly injured working on or around

a motor vehicle. Do only service work for which

you have the knowledge and the right equip

ment. If you have any doubt about your ability

to perform a service job, take your vehicle to a

competent mechanic.



Failure to properly inspect and maintain your

vehicle could result in a component malfunc

tion and effect vehicle handling and perfor

mance. This could cause an accident.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

RAM 1500 (2022 year). Manual in english - page 25
