RAM 5500 Chassis Cab (2021 year). Manual in english - page 1

10

SYMBOLS KEY

If you do not read this entire Owner’s Manual, you may miss important

information. Observe all Cautions and Warnings.

VAN CONVERSIONS/CAMPERS

The New Vehicle Limited Warranty does not apply to body modifications or

special equipment installed by van conversion/camper manufacturers/

body builders. US residents refer to the Warranty Information, Section

2.1.C. Canadian residents refer to the “What Is Not Covered” section of

the Warranty Information. Such equipment includes video monitors,

DVD/Blu-Ray™, heaters, stoves, refrigerators, etc. For warranty coverage

and service on these items, contact the applicable manufacturer.
Operating instructions for the special equipment installed by the

conversion/camper manufacturer should also be supplied with your

vehicle. For any additional instructions, please contact your conversion/

camper manufacturer.
To obtain dimensional and technical specifications for your vehicle,

refer to the Body Builder’s Guide at https://www.ramtrucks.com/

ram-commercial/body-builders-guide.html.

VEHICLE MODIFICATIONS/ALTERATIONS

WARNING!

These statements are against operating

procedures that could result in a collision,

bodily injury and/or death.

CAUTION!

These statements are against procedures that

could result in damage to your vehicle.

NOTE:

A suggestion which will improve installation,

operation, and reliability. If not followed, may

result in damage.

TIP:

General ideas/solutions/suggestions on easier

use of the product or functionality.

PAGE REFERENCE

ARROW

Follow this reference for additional information

on a particular feature.

FOOTNOTE

Supplementary and relevant information

pertaining to the topic.

WARNING!

Any modifications or alterations to this vehicle could seriously affect its

roadworthiness and safety and may lead to a collision resulting in

serious injury or death.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

11

SYMBOL GLOSSARY

Some car components have colored labels with symbols indicating

precautions to be observed when using this component. It is important

to follow all warnings when operating your vehicle. See below for the

definition of each symbol

Red Warning Lights

Seat Belt Reminder Warning Light

Air Bag Warning Light

Brake Warning Light

Hood Open Warning Light

Vehicle Security Warning Light — If Equipped

Engine Coolant Temperature Warning Light

Battery Charge Warning Light

Oil Pressure Warning Light

Oil Temperature Warning Light

Electronic Throttle Control (ETC) Warning Light

Electric Power Steering (EPS) Fault Warning Light

Trailer Brake Disconnected Warning Light

Transmission Temperature Warning Light — If

Equipped

Door Open Warning Light

Red Warning Lights

1

-------------------------------------------------------------------------------------------------------------------------------------------------------------

12

Yellow Warning Lights

Adaptive Cruise Control (ACC) Fault Warning

Light — If Equipped

Engine Check/Malfunction Indicator Warning

Light (MIL)

Electronic Stability Control (ESC) Active Warning

Light — If Equipped

Electronic Stability Control (ESC) OFF Warning

Light — If Equipped

Low Washer Fluid Warning Light — If Equipped

Low Fuel Warning Light

Low Coolant Level Warning Light

Loose Fuel Filler Cap Warning Light — If

Equipped

Tire Pressure Monitoring System (TPMS)

Warning Light — If Equipped

Anti-Lock Brake System (ABS) Warning Light

Service Forward Collision Warning (FCW)

Light — If Equipped

Service 4WD Warning Light — If Equipped

Cruise Control Fault Warning Light

Yellow Warning Lights

-------------------------------------------------------------------------------------------------------------------------------------------------------------

13

Yellow Indicator Lights

Forward Collision Warning (FCW) Off Indicator

Light — If Equipped

TOW/HAUL Indicator Light

Trailer Merge Assist Indicator Light — If

Equipped

Cargo Light — If Equipped

Snowplow Mode Indicator Light — If Equipped

Cold Ambient Derate Mode Indicator Light — If

Equipped

Diesel Exhaust Brake Indicator Light — If

Equipped

4WD Lock Indicator Light

4WD Low Indicator Light — If Equipped

4WD High Indicator Light — If Equipped

NEUTRAL Indicator Light — If Equipped

Low Diesel Exhaust Fluid (DEF) Indicator Light —

If Equipped

Wait To Start Light — If Equipped

Water In Fuel Indicator Light — If Equipped

Yellow Indicator Lights

1

-------------------------------------------------------------------------------------------------------------------------------------------------------------

14

Green Indicator Lights

Adaptive Cruise Control (ACC) Set With Target

Light — If Equipped

Adaptive Cruise Control (ACC) Set With No

Target Detected Indicator Light — If Equipped

Automatic Diesel Exhaust Brake Indicator

Light — If Equipped

ECO Mode Indicator Light — If Equipped

Park/Headlight On Indicator Light

Front Fog Indicator Light — If Equipped

Turn Signal Indicator Lights

Cruise Control Set Indicator Light — If Equipped

White Indicator Lights

Adaptive Cruise Control (ACC) Ready Light — If

Equipped

Cruise Control Ready Indicator

Set Speed Display

Blue Indicator Lights

High Beam Indicator Light

Green Indicator Lights

-------------------------------------------------------------------------------------------------------------------------------------------------------------

15

GETTING TO KNOW YOUR VEHICLE

KEYS

K

EY

F

OB

Your vehicle is equipped with a key fob which

supports Remote Keyless Entry (RKE) (if

equipped) and Keyless Enter-N-Go (if equipped).
If the vehicle is equipped with remote power

door locks, the key fob allows you to lock or

unlock all doors, as well as activate the Panic

Alarm, from distances up to approximately 66 ft

(20 m). The key fob does not need to be pointed

at the vehicle to activate the system.

NOTE:



The key fob’s wireless signal may be blocked

if the key fob is located next to a mobile

phone, laptop, or other electronic device.

This may result in poor performance.



The key fob should not be placed next to the

wireless charging pad (if equipped).



In the ON/RUN position, all key fob buttons

will work until the vehicle reaches 2 mph

(4 km/h).

Key Fob

In case the ignition switch does not change with

the push of a button, the key fob may have a low

or fully depleted battery. A low key fob battery

can be verified by referring to the instrument

cluster, which will display directions to follow.

To Lock/Unlock The Doors

If the vehicle is equipped with remote power

door locks, push and release the unlock button

on the key fob once to unlock the driver’s door.

Push the unlock button twice within five

seconds to unlock all doors. If the vehicle is

equipped with remote power door locks, push

and release the lock button on the key fob to

lock all doors.

1 — Unlock
2 — Lock
3 — Remote Start
4 — PANIC
5 — Emergency Key

2

-------------------------------------------------------------------------------------------------------------------------------------------------------------

16

GETTING TO KNOW YOUR VEHICLE

When the doors are unlocked, the turn signals

will flash and the illuminated entry system will

be activated. When the doors are locked, the

turn signals will flash and the horn will chirp.
All doors can be programmed to unlock on the

first push of the unlock button. The horn chirp

when the lock button is pushed can be

programmed on/off within Uconnect Settings

Replacing The Battery In The Key Fob

The replacement battery model is one CR2450

battery.

NOTE:



Customers are recommended to use a

battery obtained from Mopar. Aftermarket

coin battery dimensions may not meet the

original OEM coin battery dimensions.



Perchlorate Material — special handling

may apply. See www.dtsc.ca.gov/hazard

ouswaste/perchlorate for further information.



Do not touch the battery terminals that are

on the back housing or the printed circuit

board.

1. Remove the emergency key (1) by pushing

and holding the release button (2) located

on the side of the key fob while pulling the

emergency key out with your other hand.

Emergency Key Removal

2. Hold the key fob with the button side facing

down, and locate the small rectangular gap

on the left side between the housing and

the back cover of the key fob. Use a small

screw driver (or similar tool) to pry open the

left side of the fob cover while applying

pressure until the cover snaps open.

3. Next, locate the gap on the right side of the

key fob, which is positioned further to the

edge than the left side gap. Pry open the

right side, and remove the back cover.

4. Remove the battery by using your thumb to

slide the battery downward and back

toward the key ring.

Key Fob Battery Location

NOTE:

When replacing the battery, ensure the (+) sign

on the battery is facing upward. Avoid touching

the new battery with your fingers. Skin oils may

cause battery deterioration. If you touch a

battery, clean it with rubbing alcohol.

1 — Emergency Key
2 — Emergency Key Release Button

-------------------------------------------------------------------------------------------------------------------------------------------------------------

GETTING TO KNOW YOUR VEHICLE

17

5. Replace the battery by using your thumb to

push down and slide the battery under the

small lip on the top edge of the opening.

Key Fob Battery Replacement

6. To assemble the key fob case, line up the

top edge of the back cover with the top of

the fob, and press the edges into the

interlocking hinges until all edges snap

together with no large visual gaps.

7. Reinsert the emergency key until it locks

into place.

NOTE:

The key fob battery should only be replaced by

qualified technicians. If the battery requires

replacement, see an authorized dealer.

Programming And Requesting Additional

Key Fobs

Programming the key fob may be performed by

an authorized dealer.

NOTE:



Once a key fob is programmed to a vehicle, it

cannot be re-purposed and reprogrammed to

another vehicle.



Only key fobs that are programmed to the

vehicle electronics can be used to start and

operate the vehicle. Once a key fob is

programmed to a vehicle, it cannot be

programmed to any other vehicle.

Duplication of key fobs may be performed at an

authorized dealer. This procedure consists of

programming a blank key fob to the vehicle

electronics. A blank key fob is one that has

never been programmed.

NOTE:

When having the Sentry Key Immobilizer system

serviced, bring all vehicle keys with you to an

authorized dealer

SENTRY KEY

The Sentry Key Immobilizer system prevents

unauthorized vehicle operation by disabling the

engine. The system does not need to be armed

or activated. Operation is automatic, regardless

of whether the vehicle is locked or unlocked.
The system uses a key fob, keyless push button

ignition and a Radio Frequency (RF) receiver

to prevent unauthorized vehicle operation.

Therefore, only key fobs that are programmed

to the vehicle can be used to start and operate

the vehicle. The system cannot reprogram a key

fob obtained from another vehicle.
After placing the ignition switch in the ON/RUN

position, the vehicle security light will turn on for

three seconds for a bulb check. If the light

remains on after the bulb check, it indicates

that there is a problem with the electronics.

In addition, if the light begins to flash after the

WARNING!



Always remove the key fobs from the

vehicle and lock all doors when leaving the

vehicle unattended.



For vehicles equipped with Keyless

Enter-N-Go — Ignition, always remember to

place the ignition in the OFF mode.

2

-------------------------------------------------------------------------------------------------------------------------------------------------------------

18

GETTING TO KNOW YOUR VEHICLE

bulb check, it indicates that someone

attempted to start the engine with an invalid key

fob. In the event that a valid key fob is used to

start the engine but there is an issue with the

vehicle electronics, the engine will start and

shut off after two seconds.
If the vehicle security light turns on during

normal vehicle operation (vehicle running for

longer than 10 seconds), it indicates that there

is a fault in the electronics. Should this occur,

have the vehicle serviced as soon as possible by

an authorized dealer.

All of the key fobs provided with your new

vehicle have been programmed to the vehicle

electronics

IGNITION SWITCH

K

EYLESS

P

USH

B

UTTON

I

GNITION

This feature allows the driver to operate the

ignition switch with the push of a button as long

as the Remote Keyless Entry key fob is in the

passenger compartment.
The Keyless Push Button Ignition has four

operating positions; three of which are labeled

and will illuminate when in position. The three

positions are OFF, ACC, and ON/RUN. The fourth

position is START. During START, RUN will

illuminate.

NOTE:

In case the ignition switch does not change with

the push of a button, the key fob may have a low

or depleted battery. In this situation, a back up

method can be used to operate the ignition

switch. Put the nose side (side opposite of

the emergency key) of the key fob against the

START/STOP ignition button, with your foot

applied on the brake pedal, and push to

operate the ignition switch.

Keyless Push Button Ignition

The push button ignition can be placed in the

following modes:
OFF



The engine is stopped.



Some electrical devices (e.g. central locking,

alarm, etc.) are still available.

CAUTION!

The Sentry Key Immobilizer system is not

compatible with some aftermarket remote

starting systems. Use of these systems may

result in vehicle starting problems and loss of

security protection.

1 — OFF
2 — ACC (Accessory)
3 — ON/RUN

-------------------------------------------------------------------------------------------------------------------------------------------------------------

GETTING TO KNOW YOUR VEHICLE

19

(Continued)

ACC



Engine is not started.



Some electrical devices are available

(e.g. power windows etc.).

RUN



Driving position.



All the electrical devices are available

(e.g. climate controls, heated seats, etc.).

START



The engine will start.

In case the ignition switch does not change with

the push of a button, the key fob may have a low

or depleted battery. In this situation, a back up

method can be used to operate the ignition

switch. Put the nose side (side opposite of the

emergency key) of the key fob against the

START/STOP ignition button and push to

operate the ignition switch.

Back Up Starting Method

NOTE:



The key fob may not be detected by the

vehicle Keyless Enter-N-Go system if it is

located next to a mobile phone, laptop or

other electronic device; these devices may

block the key fob’s wireless signal and

prevent the Keyless Enter-N-Go system from

starting the vehicle.



For more information on the engine starting

procedure, see

WARNING!



When exiting the vehicle, always remove

the key fob from the vehicle and lock your

vehicle.



Never leave children alone in a vehicle, or

with access to an unlocked vehicle.



Allowing children to be in a vehicle unat

-

tended is dangerous for a number of

reasons. A child or others could be seriously

or fatally injured. Children should be

warned not to touch the parking brake,

brake pedal or the gear selector.



Do not leave the key fob in or near the vehicle,

or in a location accessible to children, and do

not leave the ignition of a vehicle equipped with

Keyless Enter-N-Go in the ON/RUN mode.

A child could operate power windows, other

controls, or move the vehicle.



Do not leave children or animals inside

parked vehicles in hot weather. Interior heat

build-up may cause serious injury or death.

CAUTION!

An unlocked vehicle is an invitation for

thieves. Always remove key fob from the

vehicle and lock all doors when leaving the

vehicle unattended.

WARNING!

(Continued)

2

-------------------------------------------------------------------------------------------------------------------------------------------------------------

20

GETTING TO KNOW YOUR VEHICLE

(Continued)

REMOTE START — IF EQUIPPED

(GASOLINE)

This system uses the key fob to start

the engine conveniently from outside

the vehicle while still maintaining

security. The system has a range of

approximately 300 ft (91 m).
Remote start is used to defrost windows in cold

weather, and to reach a comfortable climate in

all ambient conditions before the driver enters

the vehicle.

NOTE:

Obstructions between the vehicle and the key

fob may reduce this range

H

OW

T

O

U

SE

R

EMOTE

S

TART

Push and release the Remote Start button on the

key fob twice within five seconds. The parking

lights will flash, vehicle doors will lock, and the

horn will chirp twice (if programmed). Once the

vehicle has started, the engine will run for

15 minutes.
Pushing the remote start button a third time

shuts the engine off.
To drive the vehicle, push the unlock button,

insert the key into the ignition, and turn to the

ON/RUN position.

NOTE:



With Remote Start, the engine will only run

for 15 minutes.



Remote Start can only be used twice.



If an engine fault is present or fuel level is

low, the vehicle will start and then shut down

in 10 seconds.



The parking lights will turn on and remain on

during Remote Start mode.



For security, power window operation is

disabled when the vehicle is in the Remote

Start mode.



The ignition must be placed in the ON/RUN

position before the Remote Start sequence

can be repeated for a third cycle.



If your power door locks were unlocked,

Remote Start will automatically lock the

doors.

WARNING!



Do not start or run an engine in a closed

garage or confined area. Exhaust gas

contains Carbon Monoxide (CO) which is

odorless and colorless. Carbon Monoxide is

poisonous and can cause serious injury or

death when inhaled.



Keep key fobs away from children. Opera

-

tion of the Remote Start System, windows,

door locks or other controls could cause

serious injury or death.

WARNING!

(Continued)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

GETTING TO KNOW YOUR VEHICLE

21

All of the following conditions must be met

before the engine will remote start:



Gear selector in PARK



Doors closed



Hood closed



Hazard switch off



Brake switch inactive (brake pedal not pushed)



Battery at an acceptable charge level



PANIC button not pushed



Fuel meets minimum requirement



System not disabled from previous remote

start event



Vehicle Security system not active



Malfunction Indicator Light is not illuminated

T

O

E

XIT

R

EMOTE

S

TART

M

ODE

To drive the vehicle after starting the Remote

Start system, push and release the START/STOP

ignition button while pressing the brake pedal

prior to the end of the 15 minute cycle.
The Remote Start system will turn the engine off

with another push and release of the Remote

Start button on the key fob, or if the engine is

allowed to run for the entire 15 minute cycle.

Once the ignition is placed in the ON/RUN

position, the climate controls will resume the

previously set operations (temperature, blower

control, etc.).

NOTE:



For vehicles equipped with the Keyless

Enter-N-Go — Passive Entry feature, the

message “Remote Start Active — Push Start

Button” will display in the instrument cluster

display until you push the START/STOP igni

-

tion button.



To avoid unintentional shutdowns, the

system will disable for two seconds after

receiving a valid Remote Start request.

R

EMOTE

S

TART

F

RONT

D

EFROST

A

CTIVATION

— I

F

E

QUIPPED

When remote start is active, and the outside

ambient temperature is 40°F (4.5°C) or below, the

system will automatically activate front defrost for

15 minutes or less. The time is dependent on the

ambient temperature. Once the timer expires, the

system will automatically adjust the settings

depending on ambient conditions. See “Remote

Start Comfort Systems — If Equipped” in the next

section for detailed operation.

R

EMOTE

S

TART

C

OMFORT

S

YSTEMS

—

I

F

E

QUIPPED

When remote start is activated, the front and

rear defrost will automatically turn on in cold

weather. The heated steering wheel and driver

heated seat feature will turn on if programmed

in the comfort menu screen within Uconnect

Settings

page 228. In warm weather, the

driver vented seat feature will automatically

turn on when the remote start is activated and

is programmed in the comfort menu screen.

The vehicle will adjust the climate control

settings depending on the outside ambient

temperature.

2

-------------------------------------------------------------------------------------------------------------------------------------------------------------

22

GETTING TO KNOW YOUR VEHICLE

Automatic Temperature Control (ATC) — If

Equipped
The climate controls automatically adjust to an

optimal temperature and mode, dependent on

the outside ambient temperature. When the

ignition is placed in the ON/RUN position, the

climate controls will resume their previous

settings.
Manual Temperature Control (MTC) — If

Equipped



In ambient temperatures of 40°F (4.5°C) or

below, the climate settings will default to

maximum heat, with fresh air entering the

cabin. If the front defrost timer expires, the

vehicle will enter Mix Mode.



In ambient temperatures from 40°F (4.5°C)

to 78°F (26°C), the climate settings will be

based on the last settings selected by the

driver.



In ambient temperatures of 78°F (26°C) or

above, the climate settings will default to MAX

A/C, Bi-Level mode, with Recirculation on.

For more information on ATC, MTC, and climate

control settings, see

NOTE:

These features will stay on through the duration

of remote start, or until the ignition is placed in

the ON/RUN position. The climate control

settings will change, and exit the automatic

defaults, if manually adjusted by the driver

while the vehicle is in remote start mode.

This includes turning the climate controls off

using the OFF button.

R

EMOTE

S

TART

A

BORT

M

ESSAGE

The following messages will display in the

instrument cluster display if the vehicle fails to

remote start or exits remote start prematurely:



Remote Start Cancelled — Door Open



Remote Start Cancelled — Hood Open



Remote Start Cancelled — Fuel Low



Remote Start Cancelled — System Fault



Remote Start Disabled — Start Vehicle to Reset

The instrument cluster display message stays

active until the ignition is placed in the ON/RUN

position.

REMOTE START — IF EQUIPPED (DIESEL)

This system uses the key fob to start

the engine conveniently from outside

the vehicle while still maintaining

security. The system has a range of

approximately 300 ft (91 m).
Remote start is used to defrost windows in cold

weather, and to reach a comfortable climate in

all ambient conditions before the driver enters

the vehicle.

NOTE:



Obstructions between the vehicle and the

key fob may reduce this range.



The Remote Start system will wait for the

Wait To Start Light

page 114 to extinguish

before cranking the engine. This allows time

for the intake heater to preheat the incoming

air, and is normal operation in cold weather.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

GETTING TO KNOW YOUR VEHICLE

23

H

OW

T

O

U

SE

R

EMOTE

S

TART

Push and release the Remote Start button on the

key fob twice within five seconds. The vehicle

doors will lock, the parking lights will flash, and

the horn will chirp twice (if programmed). Then,

the engine will start, and the vehicle will remain

in the Remote Start mode for a 15 minute cycle.
Pushing the remote start button a third time

shuts the engine off.
To drive the vehicle, push the unlock button,

insert the key into the ignition, and turn to the

ON/RUN position.
All of the following conditions must be met

before the engine will remote start:



Gear selector in PARK



Doors closed



Hood closed



Hazard switch off



Brake switch inactive (brake pedal not

pressed)



Battery at an acceptable charge level



PANIC button not pushed



Fuel meets minimum requirement



Water In Fuel Indicator Light is not illuminated



Wait To Start Light is not illuminated



Malfunction Indicator Light (MIL) is not illumi

-

nated

For additional functions of the Remote Start

system, see

VEHICLE SECURITY SYSTEM — IF EQUIPPED

The Vehicle Security system monitors the

vehicle doors and ignition for unauthorized

operation. When the Vehicle Security system is

activated, interior switches for door locks are

disabled. If something triggers the alarm, the

Vehicle Security system will provide the

following audible and visible signals:



The horn will pulse



The turn signals will flash



The vehicle security light in the instrument

cluster will flash

T

O

A

RM

T

HE

S

YSTEM

Follow these steps to arm the Vehicle Security

system:

1. Make sure the vehicle’s ignition is placed

in the OFF position.



For vehicles equipped with Keyless Entry,

make sure the vehicle’s keyless ignition

system is OFF.

WARNING!



Do not start or run an engine in a closed

garage or confined area. Exhaust gas

contains Carbon Monoxide (CO) which is

odorless and colorless. Carbon Monoxide is

poisonous and can cause serious injury or

death when inhaled.



Keep key fobs away from children. Opera

-

tion of the Remote Start System, windows,

door locks or other controls could cause

serious injury or death.

2

-------------------------------------------------------------------------------------------------------------------------------------------------------------

24

GETTING TO KNOW YOUR VEHICLE

2. Perform one of the following methods to

lock the vehicle:



Push the lock button on the interior

power door lock switch with the driver

and/or passenger door open.



Push the lock button on the exterior

Passive Entry Door Handle with a valid

key fob available in the same exterior

zone



Push the lock button on the key fob.

3. If any doors are open, close them.

The Vehicle Security system will set when you

use the power door locks, or use the key fob to

lock the doors. After all the doors are locked

and closed, the vehicle security light, in the

instrument panel cluster, will flash rapidly for

about 16 seconds to indicate that the alarm is

being set. After the alarm is set, the vehicle

security light will flash at a slower rate to

indicate that the system is armed.

T

O

D

ISARM

T

HE

S

YSTEM

The Vehicle Security system can be disarmed

using any of the following methods:

1. Push the unlock button on the key fob.

2. Grab the Passive Entry Door Handle with a

valid key fob within 5 ft (1.5 m) of the

Passive Entry door handle (if equipped)

3. Cycle the ignition out of the OFF position.

The Vehicle Security system is designed to

protect your vehicle. However, you can create

conditions where the system will give you a false

alarm. If one of the previously described arming

sequences has occurred, the Vehicle Security

system will arm regardless of whether you are in

the vehicle or not. If you remain in the vehicle

and open a door, the alarm will sound. If this

occurs, disarm the Vehicle Security system.
If the Vehicle Security system is armed and the

battery becomes disconnected, the Vehicle

Security system will remain armed when the

battery is reconnected; the exterior lights will

flash, and the horn will sound. If this occurs,

disarm the Vehicle Security system.

R

EARMING

O

F

T

HE

S

YSTEM

If something triggers the alarm, and no action is

taken to disarm it, the Vehicle Security system

will turn the horn off after 29 seconds,

five seconds between cycles, and up to eight

cycles if the trigger remains active. The Vehicle

Security system will then rearm itself.

S

ECURITY

S

YSTEM

M

ANUAL

O

VERRIDE

The Vehicle Security system will not arm if you

lock the doors using the manual door lock.

DOORS

M

ANUAL

D

OOR

L

OCKS

The power door locks can be manually locked

from inside the vehicle by using the door lock

knob. To lock each door, push the door lock

knob on each door trim panel downward.

To unlock the front doors, pull the inside door

handle to the first detent. To unlock the rear

doors, pull the door lock knob on the door trim

panel upward. If the lock knob is down when the

door is closed, the door will lock. Therefore,

make sure the key fob is not inside the vehicle

before closing the door.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

GETTING TO KNOW YOUR VEHICLE

25

(Continued)

Door Lock Knob

P

OWER

D

OOR

L

OCKS

— I

F

E

QUIPPED

The power door lock switches are located on

each front door panel. Push the switch to lock or

unlock the doors.

Power Door Lock Switches

The driver’s door will unlock automatically if the

keys are found inside the vehicle when the door

lock button on the front door panel is used to

lock the door. This will occur for two attempts.

Upon the third attempt, the doors will lock even

if the key is inside.

WARNING!



Do not leave children or animals inside

parked vehicles in hot weather. Interior

heat build-up may cause serious injury or

death.



For personal security and safety in the

event of an collision, lock the vehicle doors

as you drive as well as when you park and

leave the vehicle.



Before exiting a vehicle, always shift the

automatic transmission into PARK, apply

the parking brake, turn the vehicle OFF,

remove the key fobs from vehicle, and lock

all doors. and lock your vehicle.



Never leave children alone in a vehicle,

or with access to an unlocked vehicle.

Leaving children in a vehicle unattended is

dangerous for a number of reasons. A child

or others could be seriously or fatally injured.

Children should be warned not to touch the

parking brake, brake pedal or the gear

selector.



Allowing children to be in a vehicle unat

-

tended is dangerous for a number of

reasons. A child or others could be seriously

or fatally injured. Children should be

warned not to touch the parking brake,

brake pedal or the gear selector.



Do not leave the key fob in or near the

vehicle, or in a location accessible to chil

-

dren, and do not leave the ignition of a

vehicle equipped with Keyless Enter-N-Go

in the ACC or ON/RUN mode. A child could

operate power windows, other controls, or

move the vehicle.

WARNING!

(Continued)

2

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Content .. 1 2 ..

///////////////////////////////////////
