245

Features

Audio System Basic Operation

You can use the audio system for 30 minutes when the power mode to VEHICLE OFF
(LOCK) with the driver’s door closed, the system will then turn off automatically.
If you want to keep using it, we recommend that you turn the power mode to
ACCESSORY or ON.

 VOL/AUDIO (Volume/Power) Knob:

Push to turn the audio system on and off. Turn
to adjust the volume when audio system is on.

/

 (Seek/Skip) Buttons: Press to

change station, channel, song or file.

 (Back) Button: Press to go back to the

previous display when it is displayed.

 (Home) Button: Press to go to the home

screen.

 (Cards List) Button: Press to display the

cards list of the secondary information area on
the audio/information screen.

2 Secondary Information Area P. 252

True Touchpad A: Click or swipe the pad
with your finger, or move your finger along
the pad to operate the primary information
area on the audio/information screen.
True Touchpad B: Click or swipe the pad
with your finger to operate the secondary
information area on the audio/information
screen.

1

Audio System Basic Operation

True Touchpad Operation

2 True Touchpad Operation P. 246

Primary Information Area

2 Primary Information Area P. 249

Secondary Information Area

2 Secondary Information Area P. 252

 (Home) Button

 (Back) Button

True Touchpad A

 (Cards List) Button

Audio/Information Screen

/

 (Seek/

Skip) Buttons

 VOL/AUDIO (Volume/

Power) Knob

True Touchpad B

19 ACURA RDX-31TJB6000.book  245 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

246

uu

Audio System Basic Operation

u

True Touchpad Operation

Features

True Touchpad Operation

You can operate the system using your finger(s) on the true touchpad.

■

Click

Lightly press true touchpad A to select an
item.

■

Press and hold

Press and hold to initiate edit mode
throughout the system.

■

Swipe

Swipe or drag your finger in various directions
to operate each screen.

■

True Touchpad A Operation

1

True Touchpad Operation

True Touchpad Operation

•

Some items may be grayed out during driving to
reduce the potential for distraction.

•

You can select them when the vehicle is stopped or
use voice commands.

•

Wearing gloves may limit or prevent true touchpad
response.

•

Some electronics like inverters may cause slow
response while using the true touchpad.

You can operate the true touchpad using gloves
when you set the Touchpad Sensitivity setting to
High. However, the insulated gloves can not be
operated the true touchpad.

2 Customized Features P. 332

19 ACURA RDX-31TJB6000.book  246 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

247

uu

Audio System Basic Operation

u

True Touchpad Operation

Continued

Features

■

Flick

Flick (or drag) your finger up/down or left/
right to scroll in lists or change pages
throughout the system.

■

Hand-writing a character

Move your finger quickly to trace a character
on the true touchpad.

■

Swipe with two fingers

Swipe (or drag) two fingers across the screen
to move the map.

Models with navigation system

19 ACURA RDX-31TJB6000.book  247 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

248

uu

Audio System Basic Operation

u

True Touchpad Operation

Features

■

Click

Lightly press (click) the true touchpad to select
a card.

■

Swipe

Swipe or drag your finger up or down to select
an item.

■

Flick

Flick up or down to cycle through card
displayed in the secondary information area.

■

True Touchpad B Operation

19 ACURA RDX-31TJB6000.book  248 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

249

uu

Audio System Basic Operation

u

Audio/Information Screen

Continued

Features

Audio/Information Screen

Displays each mode status. From this display, you can go to various setup options.

■

Switching the display

Press the

 (home) button to go to the home screen.

Select the following icons on the home screen or All Apps list.

■

Primary Information Area

1

Audio/Information Screen

All Apps list
You can select any of the apps from the All Apps list.
To display the All Apps list, place your finger on the
true touchpad and swipe right.

2 Home Screen P. 254

You can add or remove any of the apps in the home
screen through the All Apps list.

2 To add app icons to the home screen and

the head-up display

*

 P. 255

Home Screen

Models without navigation system

Models with navigation system

Primary Information Area

* Not available on all models

19 ACURA RDX-31TJB6000.book  249 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

250

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

■

Navigation

*

Displays the navigation screen.

2 Refer to the Navigation System Manual

■

Phone

Displays the HFL information.

2 Bluetooth® HandsFreeLink® P. 358

■

FM Radio/AM Radio/SiriusXM/USB Audio/Bluetooth Audio/AUX Input

Displays the each audio information.

■

Settings

Enters the customizing menu screen.

2 Customized Features P. 332

■

Apple CarPlay

Displays the Apple CarPlay screen.

2 Apple CarPlay

TM

 P. 303

■

System Updates

Updates the software version of the audio system.

2 System Updates P. 263

■

Messages

Displays the text message screen.

2 Text Message P. 376

* Not available on all models

19 ACURA RDX-31TJB6000.book  250 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

251

uu

Audio System Basic Operation

u

Audio/Information Screen

Continued

Features

■

AT&T HotSpot

Displays the AT&T Hotspot screen.

■

AcuraLink

Displays the AcuraLink screen.

2 AcuraLink® P. 387

19 ACURA RDX-31TJB6000.book  251 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

uu

Audio System Basic Operation

u

Audio/Information Screen

252

Features

You can see the audio, HFL information, navigation mini map

*

, and clock

information on the secondary information area using the true touchpad B.

■

Switching the card

Swipe up or down the true touchpad B to cycle through the following screen.

■

Secondary Information Area

1

Secondary Information Area

SiriusXM® radio service notifications are displayed in
the secondary information area.

Secondary Information Area

1

Switching the card

The card in the secondary information area will
change depending on the screen displayed in the
primary information area.

Now Playing Audio

Navigation

*

Clock

* Not available on all models

19 ACURA RDX-31TJB6000.book  252 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

253

uu

Audio System Basic Operation

u

Audio/Information Screen

Continued

Features

You can also switching the screen by following procedure.

1. Press the

 (cards list) button.

2. Select an item then press the true touchpad

B.

19 ACURA RDX-31TJB6000.book  253 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

uu

Audio System Basic Operation

u

Audio/Information Screen

254

Features

■

To change to a next screen

Swiping true touchpad A left or right takes you to the next screen.

■

Home Screen

1

Home Screen

The home screen has 2 pages. You can add up to 8
pages.

Press the

 (home) button to go directly back to

the first page of the home screen from any page.

Current page position

True Touchpad A

Swipe left to go to
the additional pages
of the home screen.

Swipe right to
display the All Apps
screen.

19 ACURA RDX-31TJB6000.book  254 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

Continued

255

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

■

To add app icons to the home screen and the head-up display

*

You can add app icons to the home screen and the head-up display.

1. Press the

 (home) button.

2. Swipe right to display the All Apps screen.
3. Go to an app on the list, then press and

hold true touchpad A.

4. From the pop-up menu, select Add to

Home Page or Add to Heads-Up
Display

*

.

u

The

 icon or HUD

*

 appears next to

the app on the list when the
corresponding icon has been added to
the home screen or head-up display.

1

To add app icons to the home screen and the head-up display

*

Pre-installed apps may not start up normally. If this
occurs, you need to reset the system.

2 Defaulting All the Settings P. 354

If you perform Factory Data Reset, it may reset all
the settings to their factory default.

2 Defaulting All the Settings P. 354

In case those apps still do not startup normally, even
after Factory Data Reset, contact your dealer.

Each item with HUD is listed on the head-up display
menu.

If you want to hidden the item from the head-up
display menu, select Remove from Heads-Up
Display.

Models with head-up display

* Not available on all models

19 ACURA RDX-31TJB6000.book  255 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

uu

Audio System Basic Operation

u

Audio/Information Screen

256

Features

■

To add shortcut icons to the home screen and the head-up display

*

Shortcut icons for items stored in Favorite can be added to the home screen and the
head-up display.

1. Select a favorite item, then press and hold

true touchpad A.

u

A pop-up menu will appear on the
screen.

2. Select Add to Home Page or Add to

Heads-Up Display

*

.

u

A short cut icon will be added to the
home screen or the head-up display.

1

To add shortcut icons to the home screen and the head-up
display

*

You can add an icon to the head-up display directly
from the home screen. Select an icon on the home
screen, then press and hold the true touchpad A.
After that, select Add to Heads-Up Display, and
then press the

 (back) button or the

 (home)

button to confirm the change.
Note that icons for Messages, Settings, and
System Update cannot be added to the head-up
display.

Models with head-up display

* Not available on all models

19 ACURA RDX-31TJB6000.book  256 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

Continued

257

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

■

To move icons on the home screen

You can change the location of the icons on the home screen.

1. Select the icon you want to move, then

press and hold true touchpad A.

u

The screen will change to the
customization screen.

2. Drag the icon to where you want it to be

and then press and hold the true touchpad
A.

u

The icon will be repositioned and the
screen will remain in the customization
mode.

u

After you drag the icon, keep your finger
on the true touchpad A and then press
down. If you release your finger before
pressing the true touchpad A, the icon
will remain in its original place.

u

If you want to reposition the icon on
another page of the home screen, swipe
the true touchpad A.

3. Press the

 (back) button or the



(home) button to confirm the change.

1

To move icons on the home screen

Press and hold

 (home) button to switches to the

customization screen.

Select and hold.

Drag and drop.

19 ACURA RDX-31TJB6000.book  257 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

uu

Audio System Basic Operation

u

Audio/Information Screen

258

Features

■

To remove icons from the home screen and the head-up display

*

You can remove icons from the home screen and the head-up display.

1. From the home screen, select the icon that

you want to remove, then press and hold
true touchpad A.

u

The screen will switch to the
customization screen.

2. Go to Remove from Home Page or

Remove from Heads-Up Display

*

 and

press the true touchpad A.

u

The icon will be removed from the home
screen or the head-up display, and the
screen will remain in the customization
mode.

3. Press the

 (back) button or the



(home) button to confirm the change.

You can also remove an icon from the home
screen or head-up display directly from the All
Apps list.
1. Go to an item you want to remove, then

press and hold the true touchpad A.

2. Go to Remove from Home Page or

Remove from Heads-Up Display

*

 and

press the true touchpad A.

u

The icon will be removed from the home
screen or the head-up display.

3. Press the

 (back) button or the



(home) button to confirm the change.

1

To remove icons from the home screen and the head-up display

*

Removing an icon from the home screen does not
result in the deletion of the corresponding app.

Press and hold

 (home) button to switches to the

customization screen.

If you remove a shortcut icon from the home screen,
the function of selected icon also remove from the
head-up display.

Models with head-up display

Select and hold.

* Not available on all models

19 ACURA RDX-31TJB6000.book  258 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

259

uu

Audio System Basic Operation

u

Audio/Information Screen

Continued

Features

1. Select the system status area, then press

true touchpad B.

u

The status items will appear in the
primary information area.

2. Select an item to see the details.

u

Select Dismiss to delete the detail.

u

Press the

 (back) button or select

status area again to close the status list.

■

Status Area

System Status Area

Status Items

19 ACURA RDX-31TJB6000.book  259 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

uu

Audio System Basic Operation

u

Audio/Information Screen

260

Features

You can use the hand-writing input feature by using the true touchpad A when
searching for various items of the audio system (e.g., music, route of the navigation,
phonebook contact).

1. Write letters or numbers using the true

touchpad A.

u

Search results appear on the screen.

2. Press the true touchpad A.

u

If you re-enter letters or numbers, select
the input area on the upper side of the
screen.

3. Select a desired item, and then press the

true touchpad A.

■

Searching Screen

1

Searching Screen

Delete a letter or number
Swipe left the true touchpad A to delete a letter or a
number.
Input a space
Swipe right the true touchpad A to input a space.

You can inputting letters or numbers by using on
screen keyboard. Select KEYBOARD on the upper
right of the screen.
When you return to hand-writing input screen, select
HANDWRITING.

You can inputting letters or numbers by using voice
control operation. Select

 icon on the upper left of

the screen.

Input Area

19 ACURA RDX-31TJB6000.book  260 ページ  ２０１８年４月２６日　木曜日　午後４時５１分
