Acura RDX (2019 year). Manual - part 8

117

uu

Indicators

u

Multi-Information Display Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears when the distance between your vehicle
and the vehicle ahead of you is too close while ACC
with LSF is in operation.

●

ACC with LSF has been automatically canceled.

2 Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF) P. 455

●

Appears when pressing the RES/+ or SET/– button
while the distance between your vehicle and the
vehicle ahead of you is too close.

●

ACC with LSF cannot be set.

2 Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF) P. 455

●

Appears when the parking brake is applied
automatically while ACC with LSF is in operation.

●

ACC with LSF has been automatically canceled.

2 Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF) P. 455

2 Parking Brake P. 486

●

Appears when pressing the RES/+ or SET/– button
while the parking brake is applied.

●

ACC with LSF cannot be set.

2 Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF) P. 455

2 Parking Brake P. 486

19 ACURA RDX-31TJB6000.book  117 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

118

uu

Indicators

u

Multi-Information Display Warning and Information Messages

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears if ACC with LSF is canceled while your
vehicle is automatically stopped by ACC with LSF.

●

Immediately depress the brake pedal.

●

Appears when pressing the RES/+ or SET/– button
while the vehicle is moving and the brake pedal is
depressed.

●

ACC with LSF cannot be set.

2 Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF) P. 455

• Appears if the VSA® or traction control function

operates while ACC is in operation.

●

ACC has been automatically canceled.

2 Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF) P. 455

19 ACURA RDX-31TJB6000.book  118 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

119

uu

Indicators

u

Multi-Information Display Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears when the driver’s seat belt is unfastened
while your vehicle is automatically stopped by ACC
with LSF.

●

ACC with LSF has been automatically canceled.

2 Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF) P. 455

●

Appears when pressing the RES/+ or SET/– button
while the driver’s seat belt is unfastened.

●

ACC with LSF cannot be set.

2 Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF) P. 455

●

Appears when the transmission is put into any
position other than

(

D or

(

S while ACC with LSF is

in operation.

●

ACC with LSF has been automatically canceled.

2 Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF) P. 455

●

Appears when pressing the SET/– button while the
transmission is in any position other than

(

D or

(

S.

●

ACC with LSF cannot be set.

2 Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF) P. 455

19 ACURA RDX-31TJB6000.book  119 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

120

uu

Indicators

u

Multi-Information Display Warning and Information Messages

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears when the vehicle is stopped on a very steep
slope while ACC with LSF is in operation.

●

ACC with LSF has been automatically canceled.

2 Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF) P. 455

●

Appears when pressing the RES/+ or SET/– button
while the vehicle is stopped on a very steep slope.

●

ACC with LSF cannot be set.

2 Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF) P. 455

19 ACURA RDX-31TJB6000.book  120 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

121

uu

Indicators

u

Multi-Information Display Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears if anything covers the radar sensor cover
and prevents the sensor from detecting a vehicle in
front.

●

May appear when driving in bad weather (rain,
snow, fog, etc.)

●

When the radar sensor gets dirty, stop your vehicle in a
safe place, and wipe off dirt using a soft cloth.

●

Have your vehicle checked by a dealer if the message
does not disappear even after you clean the sensor
cover.

2 Radar Sensor P. 485

●

Appears if the temperature inside the front sensor
camera is too high and the ACC with LSF, LKAS and
auto high-beam cannot be activated.

●

Use the climate control system to cool down the
camera.

●

Disappears - The camera has been cooled down and
the systems are activated normally.

2 Front Sensor Camera P. 483

●

Appears if the area around the front sensor camera is
blocked by dirt, mud, etc and be prevented from
detecting a vehicle in front.

●

May appear when driving in bad weather (rain,
snow, fog, etc.)

●

When the front window gets dirty, stop your vehicle in
a safe place, and wipe it off with a soft cloth.

●

Have your vehicle checked by a dealer if the message
does not disappear even after you cleaned the area
around the camera.

2 Front Sensor Camera P. 483

●

Appears when the LKAS is in operation, or the LKAS
button is pressed, but there is a problem with a
system related to the LKAS. The LKAS cancels
automatically. The beeper sounds simultaneously.

●

If any other system indicators come on, such as the
VSA®, ABS and brake system, take appropriate action.

2 Indicators P. 74

19 ACURA RDX-31TJB6000.book  121 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

122

uu

Indicators

u

Multi-Information Display Warning and Information Messages

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Blinks when you fail to steer the vehicle. The beeper
sounds simultaneously.

●

Operate the steering wheel to resume the LKAS.

●

Appears when the vehicle is driving out of a detected
lane. The steering wheel vibrates rapidly.

●

Keep the vehicle within the lane you are driving.

2 Lane Keeping Assist System (LKAS) P. 471

●

Appears when the vehicle is driving out of a detected
lane.

- The steering wheel vibrates rapidly when the

vehicle is drifting out of a detected lane.

- The steering wheel vibrates rapidly when the

vehicle is drifting out of a detected lane. The system
also steers the vehicle to help you remain within
your driving lane.

●

Keep the vehicle within the lane you are driving.

2 Road Departure Mitigation (RDM) System P. 479

●

You can change the setting for the road departure
mitigation system. Normal, Wide and Warning Only
can be selected.

2 Customized Features P. 332

Lane Keeping Assist System (LKAS)

Road Departure Mitigation (RDM) System

When you selected Warning Only

When you selected Normal or Wide

19 ACURA RDX-31TJB6000.book  122 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

123

uu

Indicators

u

Multi-Information Display Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears if there is a problem with the fuel pump
system.

●

Set the power mode to OFF for a while, then set the
power mode to ON. The message disappears if there is
no problem. If the message appears again, take your
vehicle to a dealer.

●

Appears if there is a problem with the engine
management system.

●

Set the power mode to OFF for a while, then set the
power mode to ON. The message disappears if there is
no problem. If the message appears again, take your
vehicle to a dealer.

●

Appears if there is a problem with the ignition
system.

●

Set the power mode to OFF for a while, then set the
power mode to ON. The message disappears if there is
no problem. If the message appears again, take your
vehicle to a dealer.

●

Appears if there is a problem with the seat heaters.

●

Turn off the seat heaters until the message disappears.
If the message appears again, take your vehicle to a
dealer.

19 ACURA RDX-31TJB6000.book  123 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

124

uu

Indicators

u

Multi-Information Display Warning and Information Messages

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears if there is a problem with the climate control
system.

●

Turn off the climate control system until the message
disappears. If the message appears again, take your
vehicle to a dealer.

Message

Condition

Explanation

●

Appears when you unlock and open the driver’s door
while the engine is running by remote engine start.

2 Remote Engine Start

*

 P. 413

Message

Condition

Explanation

●

Appears if there is a problem with the adaptive
damper system.

●

Have your vehicle checked by a dealer. Your vehicle will
have normal damping ability without the adaptive
damper feature.

Models with remote engine start

Models with head-up display

* Not available on all models

19 ACURA RDX-31TJB6000.book  124 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

125

uu

Indicators

u

Multi-Information Display Warning and Information Messages

In

strum

e

nt Pa

nel

Message

Condition

Explanation

• Appears if there is a problem with the parking sensor

system.

• Check if the area around the sensor(s) is covered with

mud, ice, snow, etc. If the indicator(s) stays on or the
beeper does not stop even after you clean the area,
have the system checked by a dealer.

• Appears if there are obstacles around the sensors.

• Check for obstacles near your vehicle to make sure it is

safe to park.

Models with parking sensor system

19 ACURA RDX-31TJB6000.book  125 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

126

In

strum

e

nt Pa

nel

Gauges and Displays

Gauges

Gauges include the speedometer, tachometer, fuel gauge, and related indicators.
They are displayed when the power mode is in ON.

Displays your driving speed in mph (U.S.) or km/h (Canada).

Shows the number of engine revolutions per minute.

Displays the amount of fuel left in the fuel tank.

Displays the temperature of the engine coolant.

■

Speedometer

■

Tachometer

■

Fuel Gauge

■

Temperature Gauge

1

Fuel Gauge

NOTICE

You should refuel when the reading approaches

.

Running out of fuel can cause the engine to misfire,
damaging the catalytic converter.

The actual amount of remaining fuel may differ from
the fuel gauge reading.

E

1

Temperature Gauge

NOTICE

Driving with the temperature gauge pointer in the
upper zone can cause serious engine damage. Pull
safely to the side of the road and allow engine
temperature to return to normal.

2 Overheating P. 606

19 ACURA RDX-31TJB6000.book  126 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

127

uu

Gauges and Displays

u

Multi-Information Display

Continued

In

strum

e

nt Pa

nel

Multi-Information Display

The multi-information display shows the odometer, trip meter, outside temperature
indicator, and other gauges.
It also displays important messages such as warnings and other helpful information.

Shows the total number of miles or kilometers that your vehicle has accumulated.

Shows the outside temperature in Fahrenheit (U.S.) or Celsius (Canada).

■

Adjusting the outside temperature display

Adjust the temperature reading by up to ±5°F or ±3°C if the temperature reading
seems incorrect.
Use the customized features in the audio/information screen to correct the
temperature.

2 Customized Features P. 332

■

Sub Display

■

Odometer

■

Outside Temperature

Odometer

Outside Temperature

Compass

*

Dynamic Mode

1

Outside Temperature

The temperature sensor is in the front bumper.
Road heat and exhaust from another vehicle can
affect the temperature reading when your vehicle
speed is less than 19 mph (30 km/h).

It may take several minutes for the display to be
updated after the temperature reading has stabilized.

* Not available on all models

19 ACURA RDX-31TJB6000.book  127 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

uu

Gauges and Displays

u

Multi-Information Display

128

In

strum

e

nt Pa

nel

Shows the current traveling direction of the vehicle.

Shows the current dynamic mode.

2 Integrated Dynamics System P. 426

Shows the current speed limit based on
information compiled through the navigation
system.

■

Compass

*

■

Dynamic Mode

■

Speed Limit Information

*

1

Speed Limit Information

*

The speed limit displayed on the screen may differ to
the actual speed limit.
The speed limit for some roads is not displayed.

* Not available on all models

19 ACURA RDX-31TJB6000.book  128 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

129

uu

Gauges and Displays

u

Multi-Information Display

Continued

In

strum

e

nt Pa

nel

Roll the right selector wheel to view different types of content.

■

Switching the Display

1

Switching the Display

If a warning initially appears, you can - after reading
it - press the right selector wheel to proceed
immediately to the content or to any other
warning(s).

Right Selector Wheel

Warning
Messages

Trip Computer

Speed/
Distance Units

Tire Pressure
for Each Tire

Maintenance

Navigation

*

Sport Gauge
Settings

SH-AWD®

*

Minimal

* Not available on all models

19 ACURA RDX-31TJB6000.book  129 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

130

uu

Gauges and Displays

u

Multi-Information Display

In

strum

e

nt Pa

nel

Move the right selector wheel to the right or left to switch between trip computer A
and trip computer B.

■

Trip meter

Shows the total number of miles or kilometers driven since the last reset. Meters A
and B can be used to measure two separate trips.

Resetting a trip meter
To reset the trip meter, display it, press and hold the right selector wheel.

u

The trip meter is reset to 0.0.

■

Trip Computer

Trip Computer A

Trip Meter

Range

Average Fuel Economy

Instant Fuel Economy

19 ACURA RDX-31TJB6000.book  130 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

Continued

131

uu

Gauges and Displays

u

Multi-Information Display

In

strum

e

nt Pa

nel

■

Average fuel economy (Avg. Fuel)

Shows the estimated average fuel economy of each trip meter in mpg or l/100 km.
The display is updated at set intervals. When a trip meter is reset, the average fuel
economy is also reset.

■

Instant fuel economy

Shows the instant fuel economy as a bar graph in mpg or l/100 km.

■

Range

Shows the estimated distance you can travel on the remaining fuel. This estimated
distance is based on the vehicle’s current fuel economy.

1

Average fuel economy (Avg. Fuel)

You can change when the average fuel economy is
reset.

2 Customized Features P. 332

19 ACURA RDX-31TJB6000.book  131 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

uu

Gauges and Displays

u

Multi-Information Display

132

In

strum

e

nt Pa

nel

Display Audio shows you turn-by-turn
directions to your destination.

When the navigation system is not providing
driving guidance, an image of a compass
appears in the multi-information display.

2 Refer to the navigation system

■

Navigation

*

1

Navigation

*

You can cancel the driving guidance by pressing and
holding the right selector wheel.

A confirmation screen appears when Apple CarPlay
navigation route is active.

You can select whether to have the turn-by-turn
display come on or not during the route guidance.

2 Customized Features P. 332
2 To Change Head-Up Display Content P. 140

Compass

Turn-By-Turn Driving Directions

* Not available on all models

19 ACURA RDX-31TJB6000.book  132 ページ  ２０１８年４月２６日　木曜日　午後４時５１分
