Acura RLX (2018 year). Manual - part 20

313

uu

Customized Features

u

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Vehicle
Settings

Door
Setup

Security Relock Timer

Changes the time it takes for the doors to relock
and the security system to set after you unlock
the vehicle without opening any door.

90seconds/
60seconds/
30seconds

*1

Auto Folding Door Mirror

Changes how you can fold the door mirrors.

Auto Fold With
Keyless

*1

/Manual

Only

Wiper
Setup

Wiper Action

Changes the setting for the automatic
intermittent wipers in the AUTO position.

Rain Sensing

*1

/

Intermittent/Speed
Sensitive

Mainte-
nance
Info.

Maintenance Reset

Resets the engine oil life display when you have
performed the maintenance service.

—

Default

Cancels/Resets all customized items in the
Vehicle Settings group as default.

Default/OK

Camera
Settings

Rear
Camera

Fixed Guideline

Selects whether the fixed guidelines come on the
rear camera monitor.

On

*1

/Off

Dynamic Guideline

Selects whether the dynamic guidelines come on
the rear camera monitor.

On

*1

/Off

Default

Cancels/Resets all customized items in the Rear
Camera group as default.

Default/OK

Cross Traffic Monitor

Turns the cross traffic monitor feature on and off.

On

*1

/Off

Models with
multi-view
rear camera

18 ACURA RLX E-AWD-31TY36400.book  313 ページ  ２０１７年７月２０日　木曜日　午後６時８分

314

uu

Customized Features

u

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Camera
Settings

Surround
View
Camera

Guidelines

Fixed
Guideline

Sets whether to turn on the reference line display.

On

*1

/Off

Dynamic
Guideline

Sets whether to turn on the projection line display.

On

*1

/Off

Preferences

Automatically
show camera
after reverse

Sets the rear view to be automatically switched to
the front view when the gear is shifted out of

(

R.

On

*1

/Off

Default
camera mode
in forward

Selects which screen to display when the surround
view camera system is turned on while the vehicle
is moving forward.

Front Ground
View

*1

/Last Used/

Front Blind View/
Side View

Default
camera mode
in reverse

Sets which screen to display when the surround
view camera system is turned on while the vehicle
is reversing.

Rear Ground
View

*1

/Last Used/

Rear View/Rear
Wide View

Models with
surround
view camera
system

18 ACURA RLX E-AWD-31TY36400.book  314 ページ  ２０１７年７月２０日　木曜日　午後６時８分

315

uu

Customized Features

u

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Camera
Settings

Surround
View
Camera

Preferences

Show camera
when
decelerating

Sets the screen to automatically return to the
camera view at vehicle speeds of 7 mph (12 km/
h) or lower. The screen can return only when the
display has been switched to the audio/
information screen at the vehicle speed of over 9
mph (15 km/h).

On

*1

/Off

Clear parking
guidance
automatically

Turns the parking guide lines on and off.

On

*1

/Off

Display

Adjusts the screen’s preferences.

—

Default

Cancels/Resets all customized items in the
Camera Settings group as default.

Default/OK

Cross Traffic Monitor

Turns the cross traffic monitor feature on and off.

On

*1

/Off

Models with
surround
view camera
system

18 ACURA RLX E-AWD-31TY36400.book  315 ページ  ２０１７年７月２０日　木曜日　午後６時８分

316

uu

Customized Features

u

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Phone
Settings

Phone

Connect Phone

Pairs a new phone to HFL, connects or disconnects
a paired phone.

2 Phone Setup P. 332

—

Bluetooth Device List

Pairs a new phone to HFL, edits or deletes a paired
phone, or creates a security PIN.

2 Phone Setup P. 332

—

Edit Speed Dial

Edits, adds or deletes a speed dial entry.

2 Phone Setup P. 332

—

Auto Transfer

Sets calls to automatically transfer from your
phone to HFL when you enter the vehicle.

On

*1

/Off

Auto Answer

Sets whether to automatically answer an incoming
call after about four seconds.

On/Off

*1

Ring Tone

Selects the ring tone.

Fixed/Mobile
Phone

*1

/Off

Automatic Phone Sync

Sets a phonebook data to be automatically
imported when a phone is paired to HFL.

On

*1

/Off

Use Contact Photo

Displays a caller’s picture on an incoming call
screen.

On

*1

/Off

18 ACURA RLX E-AWD-31TY36400.book  316 ページ  ２０１７年７月２０日　木曜日　午後６時８分

317

uu

Customized Features

u

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Phone
Settings

Text/
Email

Enable Text/Email

Turns the text/e-mail message function on and
off.

On

*1

/Off

Select Account

Selects a text/e-mail message account.

—

New Text/Email Alert

Selects whether a pop-up alert comes on the
screen when HFL receives a new text/e-mail
message.

On/Off

*1

Default

Cancels/Resets all customized items in the Phone
Settings group as default.

Default/OK

18 ACURA RLX E-AWD-31TY36400.book  317 ページ  ２０１７年７月２０日　木曜日　午後６時８分

318

uu

Customized Features

u

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Info
Settings

Acura
Link

AcuraLink Msg Notice

Selects whether newly received AcuraLink
messages to be displayed.

On

*1

/Off

Delete AcuraLink Message

Deletes AcuraLink messages.

—

AcuraLink Subscription
Status

Displays your current AcuraLink subscription
status.

—

Clock

Clock/
Wallpaper
Type

Clock

See System Settings on  P. 306 to  P. 308.

Wallpaper

Clock Adjustment

Clock Format

Auto Time Zone

Auto Daylight

Clock Reset

Other

Info Screen Preference

Selects the top menu when the INFO button is
pressed.
• Info Top- A brief menu pops up.
• Info Menu- A full menu pops up.
• Off- A menu does not pop up.

Info Top/Info
Menu

*1

/Off

Default

Cancels/Resets all customized items in the Info
Settings group as default.

Default/OK

18 ACURA RLX E-AWD-31TY36400.book  318 ページ  ２０１７年７月２０日　木曜日　午後６時８分

319

uu

Customized Features

u

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Audio
Settings

CD/
HDD

Recording from CD

Selects whether the songs on music CDs are
automatically recorded to the HDD.

Auto

*1

/Manual

Recording Quality

Selects the quality of the music files recorded to
the HDD.

Standard

*1

/High

HDD Info

Displays the HDD capacity.

—

Update Gracenote Album
Info

Updates the Gracenote® Album Info (Gracenote®
Media Database).

Update by CD/
Update by USB

Delete All HDD Data

2 Deleting all HDD Data P. 322

—

Bluetooth

Bluetooth Device List

Edits or deletes a Bluetooth® Audio device paired
to HFL.

—

Connect Bluetooth Audio
Device

Connects, disconnects or pairs a Bluetooth®
Audio device to HFL.

—

CD mode

CD mode

HDD mode

CD or HDD mode

HDD mode

Bluetooth® Audio, Pandora®

*

 or

Aha

TM

 mode

Bluetooth® Audio, Pandora®

*

 or

Aha

TM

 mode

* Not available on all models

18 ACURA RLX E-AWD-31TY36400.book  319 ページ  ２０１７年７月２０日　木曜日　午後６時８分

320

uu

Customized Features

u

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Audio
Settings

Other

Source Select Popup

Selects whether the list of selectable audio sources
comes on when the AUDIO button is pressed.

On/Off

*1

HD Radio Mode

*

Selects whether the audio system automatically
switches to the digital radio waves or receives the
analogue waves only.

Auto

*1

/Analog

Cover Art

Turns on and off the cover art display.

On

*1

/Off

Default

Cancels/Resets all customized items in the Audio
Settings group as default.

Default/OK

AM/FM mode

CD (MP3/WMA/AAC), iPod, USB,
Pandora®

*

 or Aha

TM

 mode

* Not available on all models

18 ACURA RLX E-AWD-31TY36400.book  320 ページ  ２０１７年７月２０日　木曜日　午後６時８分

321

uu

Customized Features

u

Defaulting All the Settings

Features

Defaulting All the Settings

You can reset all the menu and customized settings as the factory defaults.

1. Press the SETTINGS button.
2. Rotate

 to select System Settings, then

press .

3. Move

or

to

select

the

Others tab.

4. Rotate

 to select Factory Data Reset,

then press

.

u

The pop-up menu appears on the screen.

5. Rotate

 to select Yes, then press

.

u

The confirmation message will appear.

6. Rotate

 to select Yes, then press



again to reset the settings.

u

The confirmation message will appear.
Press

 to select OK.

1

Defaulting All the Settings

When you transfer the vehicle to a third party, reset
all settings to default and delete all personal data.

The following settings will be reset:

•

Routing & Guidance: Rerouting, Unverified Area
Routing, Traffic Rerouting, Edit Waypoint Search
Area, Guidance Mode, Street Name Guidance

•

Route Preference

•

Audio preset settings

•

Phonebook entries

•

Other display and each item settings.

18 ACURA RLX E-AWD-31TY36400.book  321 ページ  ２０１７年７月２０日　木曜日　午後６時８分

322

uu

Customized Features

u

Deleting all HDD Data

Features

Deleting all HDD Data

You can reset all the menu and customized settings, and delete all music data on the
HDD.

1. Turn on the audio system and select the

HDD mode.

2. Press the SETTINGS button.
3. Rotate

 to select Audio Settings, then

press .

4. Move

 or

 to select the CD/HDD tab.

5. Rotate

 to select Delete all HDD Data,

then press

.

u

The confirmation message will appear.

6. Rotate

 to select Yes, then press

.

18 ACURA RLX E-AWD-31TY36400.book  322 ページ  ２０１７年７月２０日　木曜日　午後６時８分

323

Features

HomeLink® Universal Transceiver

The HomeLink® Universal Transceiver can be programmed to operate up to three
remote controlled devices around your home, such as garage doors, lighting, or
home security systems.

Refer to the safety information that came with your garage door opener to test that
the safety features are functioning properly. If you do not have the safety
information, contact the manufacturer.

Before programming HomeLink, make sure that people and objects are out of the
way of the garage or gate to prevent potential injury or damage.

When programming a garage door opener, park just outside the garage door’s
path.

■

Important Safety Precautions

1

HomeLink® Universal Transceiver

Before programming HomeLink to operate a garage
door opener, confirm that the opener has an external
entrapment protection system, such as an “electronic
eye,” or other safety and reverse stop features. If it
does not, HomeLink may not be able to operate it.

18 ACURA RLX E-AWD-31TY36400.book  323 ページ  ２０１７年７月２０日　木曜日　午後６時８分

324

uu

HomeLink® Universal Transceiver

u

Training HomeLink

Features

Training HomeLink

If it is necessary to erase a previously entered
learned code:
• Press and hold the two outside buttons for

about 20 seconds, until the red indicator
blinks. Release the buttons, and proceed to
step 1.

• If you are training the second or third

button, go directly to step 1.

The instructions on the next page should work for most gate or garage openers, but
may not work for all. For detailed instructions about your specific remote opener,
visit http://www.homelink.com or call (800) 355-3515.

Red Indicator

18 ACURA RLX E-AWD-31TY36400.book  324 ページ  ２０１７年７月２０日　木曜日　午後６時８分

325

uu

HomeLink® Universal Transceiver

u

Training HomeLink

Features

■

Training a Button

1

Training HomeLink

Retraining a Button
If you want to retrain a programmed button for a
new device, you do not have to erase all button
memory. You can replace the existing memory code
using this procedure:

1. Press and hold the desired HomeLink button

until the HomeLink indicator begins to blink.

2. Continue to hold the HomeLink button and

follow steps 1 - 3 under “Training a Button.”

Indicator remains on
for about 25 secs.

Standard transmitter

Indicator blinks rapidly for
2 secs, then remains on for
about 23 secs.

Rolling code transmitter

Erasing Codes
To erase all the codes, press and hold the two outside
buttons until the HomeLink indicator begins to blink
(about 10 to 20 secs). You should erase all codes
before selling the vehicle.

If you have any problems, see the device’s
instructions, visit www.homelink.com, or call
HomeLink at (800) 355-3515.

HomeLink® is a registered trademark of Gentex
Corporation.

4.

a.

3.

2.

5.

a.

b.

1. Position the remote transmitter you wish to link 1 to 3 inches (3 - 8 cm) from the

HomeLink button you want to program.

Press and hold the desired HomeLink button and the button on
the remote transmitter. Does the HomeLink indicator (LED)
blink after 10 secs?

Press and hold the
programmed HomeLink
button for about a sec.
Does the device (garage
door opener) work?

Press and hold the remote and the HomeLink
button at the same time. Then, while
continuing to hold the HomeLink button,
press and release the button on the remote
every 2 secs.
Does the LED blink within 20 secs?

Training
Complete

Press and hold the HomeLink button again.

Press and hold the HomeLink
button again.
The remote-controlled device
should operate.

Training Complete

The remote has a rolling code. Press the
“learn” button on the remote-controlled
device (e.g. garage door opener).

Within 30 secs, press and hold the
programmed HomeLink button for 2 secs.

HomeLink indicator blinks for 2 secs,

then remains on.

HomeLink LED

is on.

YES

NO

YES

YES

NO

NO

18 ACURA RLX E-AWD-31TY36400.book  325 ページ  ２０１７年７月２０日　木曜日　午後６時８分

326

Features

Bluetooth® HandsFreeLink®

Bluetooth® HandsFreeLink® (HFL) allows you to place and receive phone calls using
your vehicle’s navigation system, without handling your cell phone.

Using HFL

 (Pick-up) button: Press to go to the Speed Dial/Call History on the multi-

information display or the head-up display, or to answer an incoming call.

 (Hang-up/back) button: Press to end a call, to cancel a command or to

clear the phone information on the multi-information display or the head-up display.

 (Talk) button: Press to give HFL voice commands.

PHONE button: Press to go directly to the Phone screen.
Interface dial: Rotate

 to select an item on the screen, then press

. Move

,

,   or   to select secondary menu.

■

HFL Buttons

1

Bluetooth® HandsFreeLink®

Place your phone where you can get good reception.

To use HFL, you need a Bluetooth-compatible cell
phone. For a list of compatible phones, pairing
procedures, and special feature capabilities:

•

U.S.: Visit www.Handsfreelink.com/Acura, or call
1-888-528-7876.

•

Canada: For more information on smartphone
compatibility, call 1-888-528-7876.

To use HFL, the Bluetooth setting must be On.

2 Customized Features P. 297

Voice control tips:

•

Aim the vents away from the ceiling and close the
windows, as noise coming from them may interfere
with the microphone.

•

Press and release the

 button when you want to

call a number using a stored voice tag, a
phonebook name, or a number. Speak clearly and
naturally after a beep.

•

If the microphone picks up voices other than yours,
the command may be misinterpreted.

•

To change the volume level, use the audio system’s
volume knob or the remote audio controls on the
steering wheel.

State or local laws may prohibit the operation of
handheld electronic devices while operating a
vehicle.

Talk Button

Volume up

Microphone

Hang-up/Back Button

Pick-up
Button

Volume down

Interface
Dial

PHONE
Button

18 ACURA RLX E-AWD-31TY36400.book  326 ページ  ２０１７年７月２０日　木曜日　午後６時８分

327

uu

Bluetooth® HandsFreeLink®

u

Using HFL

Features

The audio/information screen notifies you when there is an incoming call.

Certain manual functions are disabled or
inoperable while the vehicle is in motion.
You cannot select a grayed-out option until
the vehicle is stopped.

Only previously stored speed dial entries with
voice tags, phonebook names, or numbers
can be called using voice commands while the
vehicle is in motion.

2 Speed Dial P. 343

■

HFL Status Display

1

Bluetooth® HandsFreeLink®

Bluetooth® Wireless Technology
The Bluetooth® word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc., and any
use of such marks by Honda Motor Co., Ltd., is under
license. Other trademarks and trade names are those
of their respective owners.

HFL Limitations
An incoming call on HFL will interrupt the audio
system when it is playing. It will resume when the call
is ended.

If you receive a call while using the audio system, the
system resumes its operation an after ending the call.

1

HFL Status Display

The information that appears on the audio/
information screen varies between phone models.

You can change the system language.

2 Customized Features P. 297

■

Limitations for Manual Operation

Bluetooth® Indicator
Comes on when your phone
is connected to HFL.

Signal Strength

HFL Mode

Battery Level
Status

Roam Status

Caller’s Name

Caller’s Number

Disabled Option

18 ACURA RLX E-AWD-31TY36400.book  327 ページ  ２０１７年７月２０日　木曜日　午後６時８分

328

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

HFL Menus

The power mode must be in ACCESSORY or ON to use HFL.

■

Phone Settings screen

1. Press the SETTINGS button.
2. Rotate

 to select Phone Settings, then

press .

1

HFL Menus

To use HFL, you must first pair your Bluetooth-
compatible cell phone to the system while the vehicle
is parked.

Some functions are limited while driving. A message
appears on the screen when the vehicle is moving
and the operation is canceled.

Edit the user name of a paired phone.

Phone

Edit Device

Name

Connect

Phone

*1

Bluetooth

Device List



(Existing

entry list)

*1



Replace This

Device

Add Bluetooth

Device

Disconnect a paired phone from the system.

Connect a phone to the system.

*1: Appears when a phone has already been paired to HFL.

Disconnect



(Existing entry list)





Pair a phone to the system.

Edit PIN



Create a security PIN for a paired phone.

Replace a previously paired phone with a
new phone.

Delete This

Device

Delete a previously paired phone.









Add Bluetooth

Device

Pair a phone to the system.



18 ACURA RLX E-AWD-31TY36400.book  328 ページ  ２０１７年７月２０日　木曜日　午後６時８分
