Acura RLX (2018 year). Manual - part 19

297

Continued

Features

Customized Features

Use the audio/information screen to customize certain features.

■

How to customize

Select your desired setting item by pressing the SETTINGS button, then rotating



while the power mode is in ON and the vehicle is at a complete stop. Press

.

1

Customized Features

When you customize setting, make sure that the
vehicle is at a complete stop and shift to

(

P.

To customize other features, rotate

, move

,  ,

 or  , and press

.

2 List of customizable options P. 306

Settings menu

Navi Settings

System Settings

Audio Settings

Camera Settings

Phone Settings

Vehicle Settings

Info Settings

SETTINGS Button

Audio/Information Screen

18 ACURA RLX E-AWD-31TY36400.book  297 ページ  ２０１７年７月２０日　木曜日　午後６時８分

298

uu

Customized Features

u

Features

■

Customization flow

Song By Voice

Song By Voice Phonetic Modification

Phonebook Phonetic Modification

Press the SETTINGS button.







Guidance Volume

Voice Prompt



Guidance Volume

Verbal Reminder

Brightness

Contrast

Black Level











Bluetooth Status

Bluetooth Device List

Edit Pairing Code



Default

Sound/

Beep

Display

System

Settings

Bluetooth

Voice Reco

Sync Display Brightness



Sound Volume



Opening

18 ACURA RLX E-AWD-31TY36400.book  298 ページ  ２０１７年７月２０日　木曜日　午後６時８分

299

uu

Customized Features

u

Continued

Features

System Device Information

Factory Data Reset



Background Color

Header Clock Display

Clock Reset

Auto Time Zone

Auto Daylight

Clock

Clock Adjustment

Clock Format

Clock







Units

Language

Operation Restriction Tips

Others





Wallpaper

Clock/Wallpaper

Type

18 ACURA RLX E-AWD-31TY36400.book  299 ページ  ２０１７年７月２０日　木曜日　午後６時８分

300

uu

Customized Features

u

Features

“Trip B” Reset Timing

Language Selection

Adjust Outside Temp. Display









Forward Collision Warning Distance

ACC Forward Vehicle Detect Beep



Turn By Turn Display

Default

Memory Position Link



Door Unlock Mode

Keyless Access Light Flash







Interior Light Dimming Time

Headlight Auto Off Timer

Auto Light Sensitivity

Vehicle

Settings

Driver

Assist

System

Setup

Keyless

Access

Setup

Lighting

Setup

Keyless Access Beep

Lane Keeping Assist Suspend Beep

Blind Spot Info

Easy Entry/Exit

Auto Seatbelt Tension



Driving

Position

Setup

Display Speed Unit

Reactive Force Pedal

Head-up Warning

Road Departure Mitigation Setting

Remote Start System On/Off



Reverse Alert Tone



“Trip A” Reset Timing

Meter/

Head-up

Display

Setup

Walk Away Auto Lock

18 ACURA RLX E-AWD-31TY36400.book  300 ページ  ２０１７年７月２０日　木曜日　午後６時８分

301

uu

Customized Features

u

Continued

Features



Fixed Guideline

Dynamic Guideline





Default

Rear

Camera

Cross Traffic Monitor

*1: Models with multi-view rear camera



Maintenance Reset

Maintenance Info.



Wiper Action

Wiper

Setup



Key And Remote Unlock Mode

Keyless Lock Answer Back

Security Relock Timer

Auto Door Lock

Auto Door Unlock





Door

Setup

Auto Folding Door Mirror



Camera

Settings

*1

18 ACURA RLX E-AWD-31TY36400.book  301 ページ  ２０１７年７月２０日　木曜日　午後６時８分

302

uu

Customized Features

u

Features



Fixed Guideline

Dynamic Guideline





Default

Guidelines

Cross Traffic Monitor



Automatically show

camera after reverse

Default camera mode in

forward

Preferences

Default camera mode in

reverse

Show camera when

decelerating

Clear parking guideline

automatically

Display

*2: Models with surround view camera system





Camera

Settings

*2

Surround

View

Camera

18 ACURA RLX E-AWD-31TY36400.book  302 ページ  ２０１７年７月２０日　木曜日　午後６時８分

303

uu

Customized Features

u

Continued

Features



Add Bluetooth

Device

Disconnect

Default





Phone

Connect Phone



Edit Bluetooth

Device

Add Bluetooth

Device



Bluetooth Device

List

Edit Speed Dial

Auto Transfer

Auto Answer

Ring Tone

Automatic Phone Sync

Use Contact Photo



Default



Default

Enable Text/Email

Select Account

New Text/Email Alert



Text/Email



Phone

Settings





Navi

Settings

See the Navigation System Manual.

18 ACURA RLX E-AWD-31TY36400.book  303 ページ  ２０１７年７月２０日　木曜日　午後６時８分

304

uu

Customized Features

u

Features

Auto Daylight

Clock Reset

Info Screen Preference



Clock Format

Auto Time Zone







Clock/Wallpaper Type

Clock Adjustment

Clock

Default

Others

Info

Settings

AcuraLink Subscription Status





AcuraLink Msg Notice

Delete AcuraLink Message

AcuraLink



18 ACURA RLX E-AWD-31TY36400.book  304 ページ  ２０１７年７月２０日　木曜日　午後６時８分

305

uu

Customized Features

u

Continued

Features





Default

Source Select Popup

HD Radio Mode

*, *1

Cover Art

*1

Connect Bluetooth Audio Device

*1

Bluetooth Device List

*1

Recording from CD

*1

Recording Quality

*1

HDD Info

*1

Update Gracenote Album Info

*1

Delete all HDD Data

*1





*1: May change depending on your currently selected source.

CD/HDD

Bluetooth

Other



Audio

Settings

* Not available on all models

18 ACURA RLX E-AWD-31TY36400.book  305 ページ  ２０１７年７月２０日　木曜日　午後６時８分

306

uu

Customized Features

u

Features

■

List of customizable options

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

System
Settings

Display

Sync Display Brightness

Selects whether the display brightness
synchronizes with the instrument panel brightness.

On

*1

/Off

Brightness

Changes the brightness of the audio/information
screen.

—

Contrast

Changes the contrast of the audio/information
screen.

—

Black Level

Changes the black level of the audio/information
screen.

—

Sound/
Beep

Guidance Volume

Changes the volume of the audio speakers.

0 ~ 6

*1

 ~ 11

Verbal Reminder

Turns the verbal reminders on and off.

On

*1

/Off

Voice
Reco

Voice Prompt

Turns the voice prompt on and off.

On

*1

/Off

Song By Voice

Turns the Song By Voice

TM

 on and off.

2 Song By Voice

TM

 (SBV) P. 262

On

*1

/Off

Song By Voice Phonetic
Modification

Modifies a voice command for music stored in the
HDD or an iPod.

2 Phonetic Modification P. 264

—

Phonebook Phonetic
Modification

Modifies a voice command for the phonebook.

2 Phonebook Phonetic Modification P. 346

—

Guidance Volume

Changes the volume of the voice prompt.

0 ~ 6

*1

 ~ 11

18 ACURA RLX E-AWD-31TY36400.book  306 ページ  ２０１７年７月２０日　木曜日　午後６時８分

307

uu

Customized Features

u

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

System
Settings

Blue-
tooth

Bluetooth Status

Turns the Bluetooth® on and off.

On

*1

/Off

Bluetooth Device List

Pairs a new phone to HFL, edits and deletes a
paired phone, and creates a security PIN.

2 Phone Setup P. 332

—

Edit Pairing Code

Changes a pairing code.

2 To change the pairing code setting P. 334

Random/Fixed

*1

Opening

Sound Volume

Changes the volume of the system’s startup
sound.

0 ~ 6

*1

 ~ 11

Clock

Clock/
Wallpaper
Type

Clock

Changes the clock display type.

Analog/Digital

*1

/

Small Digital/Off

Wallpaper

• Changes the wallpaper type.
• Imports an image file for a new wallpaper.
• Deletes an image file for a wallpaper.

2 Wallpaper Setup P. 228

Blank/Galaxy

*1

/

Metallic

Clock Adjustment

Adjusts Clock.

2 Clock P. 128

—

Clock Format

Selects the digital clock display from 12H to 24H.

12H

*1

/24H

Auto Time Zone

Sets the navigation system to automatically
adjust the clock when driving through different
time zones.

On

*1

/Off

18 ACURA RLX E-AWD-31TY36400.book  307 ページ  ２０１７年７月２０日　木曜日　午後６時８分

308

uu

Customized Features

u

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

System
Settings

Clock

Auto Daylight

Sets the navigation system to automatically adjust
the clock (“spring ahead” or “fall back” by one
hour) when a daylight saving time change occurs.

On

*1

/Off

Clock Reset

Resets the settings of all items in the Clock group.

—

Others

Units

Changes the distance unit on the navigation map
screen.

mile

*1

/km (U.S.)

mile/km

*1

 (Canada)

Language

Changes the display language.

English

*1

/Français/

Español

Operation Restriction Tips

Alerts you when manual control of the system is
disabled to prevent distraction while driving. Only
voice commands are available.

On

*1

/Off

Background Color

Changes the background color of the audio/
information screen and the On Demand Multi-Use
Display

TM

.

Blue

*1

/Amber/Red/

Green

Header Clock Display

Selects whether the clock display comes on.

On/Off

*1

System Device Information

Displays the system/device information.

—

Factory Data Reset

Resets all the settings to their factory default.

2 Defaulting All the Settings P. 321

—

Default

Cancels /Resets all customized items in the
System Settings group as default.

Default/OK

18 ACURA RLX E-AWD-31TY36400.book  308 ページ  ２０１７年７月２０日　木曜日　午後６時８分

309

uu

Customized Features

u

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Vehicle
Settings

Driver
Assist
System
Setup

Forward Collision Warning
Distance

Changes at which distance the CMBS

TM

 alerts.

Long/Normal

*1

/Short

Head-up Warning

Turns the head-up warning on and off.

On

*1

/Off

ACC Forward Vehicle
Detect Beep

Causes the system to beep when the system
detects a vehicle, or when the vehicle goes out of
the ACC with LSF range.

On/Off

*1

Road Departure Mitigation
Setting

Changes the setting for the road departure
mitigation system.

Narrow/Normal

*1

/

Wide/Warning Only

Lane Keeping Assist
Suspend Beep

Causes the system to beep when the LKAS is
suspended.

On/Off

*1

Blind Spot Info

Changes the setting for the blind spot
information.

Audible And Visual
Alert

*1

/Visual Alert/

Off

Reactive Force Pedal

Change the amount of the accelerator pedal
resistance force.

High Force/Low
Force

*1

18 ACURA RLX E-AWD-31TY36400.book  309 ページ  ２０１７年７月２０日　木曜日　午後６時８分

310

uu

Customized Features

u

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Vehicle
Settings

Meter/
Head-
up
Display
Setup

Language Selection

Changes the displayed language on the multi-
information display.

English

*1

/Français/

Español

Adjust Outside Temp.
Display

Adjusts the temperature reading by a few degrees.

-5°F ~ ±0°F

*1

 ~ +5°F

(U.S.)
-3°C ~ ±0°C

*1

 ~ +3°C

(Canada)

“Trip A” Reset Timing

Changes the setting of how to reset trip meter A,
average fuel economy A, average speed A, and
elapsed time A.

When Refueled/
IGN Off/Manually
Reset

*1

“Trip B” Reset Timing

Changes the setting of how to reset trip meter B,
average fuel economy B, average speed B, and
elapsed time B.

When Refueled/
IGN Off/Manually
Reset

*1

Reverse Alert Tone

Turns the reverse alert tone on and off.

On

*1

/Off

Turn By Turn Display

Selects whether the turn-by-turn display comes on
during the route guidance.

On

*1

/Off

Display Speed Unit

Changes the speed unit for ACC with LSF on the
multi-information display, and the speed unit on
the head-up display.

km/h/mph

*1

(U.S.)
km/h

*1

/mph

(Canada)

18 ACURA RLX E-AWD-31TY36400.book  310 ページ  ２０１７年７月２０日　木曜日　午後６時８分

311

uu

Customized Features

u

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Vehicle
Settings

Driving
Position
Setup

Memory Position Link

Turns the driving position memory system on and
off.

On

*1

/Off

Easy Entry/Exit

Moves the seat fully rearward and steering wheel
fully up when you get in/get out of the vehicle.
Changes the setting for this feature.

Seat & Steering
Wheel

*1

/Seat Only/

Steering Wheel
Only/Off

Auto Seatbelt Tension

Turns the auto seat belt tension setting for the
seat belt e-pretensioner on and off.

On

*1

/Off

Keyless
Access
Setup

Door Unlock Mode

Changes which doors unlock when you grab the
driver’s door handle.

Driver Door Only

*1

/

All Doors

Keyless Access Light Flash

Causes some exterior lights to flash when you
unlock/lock the doors.

On

*1

/Off

Keyless Access Beep

Causes the beeper to sound when you unlock/
lock the doors.

On

*1

/Off

Remote Start System On/
Off

Turns the remote engine start feature on and off.

On

*1

/Off

Walk Away Auto Lock

Changes the settings for the auto lock function
when you walk away from the vehicle.

On/Off

*1

18 ACURA RLX E-AWD-31TY36400.book  311 ページ  ２０１７年７月２０日　木曜日　午後６時８分

312

uu

Customized Features

u

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Vehicle
Settings

Lighting
Setup

Interior Light Dimming
Time

Changes the length of time the interior lights stay
on after you close the doors.

60seconds/
30seconds

*1

/

15seconds

Headlight Auto Off Timer

Changes the length of time the exterior lights stay
on after you close the driver’s door.

60seconds/
30seconds/
15seconds

*1

/

0seconds

Auto Light Sensitivity

Changes the timing for the headlights to come on.

Max/High/Mid

*1

/

Low/Min

Door
Setup

Auto Door Lock

Changes the setting for when the doors
automatically lock.

With Vehicle
Speed

*1

/Shift from

P/Off

Auto Door Unlock

Changes the setting for when the doors
automatically unlock.

All Doors When
Driver’s Door
Opens

*1

/All Doors

When Shifted to
Park/All Doors
When Ignition
Switched Off/Off

Key And Remote Unlock
Mode

Sets up either the driver’s door or all doors to
unlock on the first push of the remote.

Driver Door

*1

/All

Doors

Keyless Lock Answer Back

LOCK/UNLOCK- The exterior lights flash.
LOCK (2nd push)- The beeper sounds.

On

*1

/Off

18 ACURA RLX E-AWD-31TY36400.book  312 ページ  ２０１７年７月２０日　木曜日　午後６時８分
