Acura RLX (2018 year). Manual - part 16

Continued

249

uu

Audio System Basic Operation

u

Playing Hard Disk Drive (HDD) Audio

Features

When Recording from CD is set to Auto, the songs on music CDs are automatically
recorded to the HDD the first time you play each disc. You can then play the songs
directly from the HDD.

2 Customized Features P. 297

1. Press the MENU button.
2. Rotate

 to select Cancel Record to HDD, then press

.

When Recording from CD is set to Manual, the songs on music CDs can be
manually recorded to the HDD.
1. Press the MENU button.
2. Rotate

 to select Rec to HDD, then press

.

■

Recording a Music CD to HDD

1

Recording a Music CD to HDD

You can add tracks to user playlists, where you can
mix and match tracks from other CDs recorded on
the HDD.

2 Editing an Album or Playlist P. 252
2 Editing Track Information P. 255

If you turn the power system off or the audio system
is turned off while recording a CD, there may be
pauses between songs when you play back from the
HDD.

Repeat, random, and scan functions are not available
during recording.

You can play music from other sources (e.g.,
SiriusXM®, HDD, etc.) while recording.

Please note that there is no compensation offered in
the case of unsuccessful recording of audio data or
the loss of audio data due to any cause whatsoever.

Clearing the HDD
Any music tracks stored on the HDD can be deleted.

2 Deleting all HDD Data P. 322

■

Stop Recording

■

Recording a CD Manually

Album AAA

Artist AAA

10

01’23”

Track AAA

01

Recording Indicator

Recording

Ready to record

18 ACURA RLX E-AWD-31TY36400.book  249 ページ  ２０１７年７月２０日　木曜日　午後６時８分

uu

Audio System Basic Operation

u

Playing Hard Disk Drive (HDD) Audio

250

Features

1. Press the MENU button.
2. Rotate

 to select Music Search, then

press .

3. Rotate

, move

 or

, then press

 to

select a track from the Music Search list.

u

Title information is displayed if found in
the Gracenote® Album Info (Gracenote®
Media Database) stored on the HDD.

u

The HDD has two types of playlists:
original playlists and user playlists. An
original playlist is automatically created
for each album when a music CD is
recorded. You can customize up to six
user playlists provided on the HDD by
adding tracks from your original playlists.

You can also select a track by the following
procedure.
1. Rotate

 or press

 to display the song

list.

2. Rotate

, move

 or

, then press

 to

select a track from the list.

■

How to Select a Track from the Music Search List

1

How to Select a Track from the Music Search List

You can control the HDD audio using voice
commands.

2 Voice Control Operation P. 232
2 Song By Voice

TM

 (SBV) P. 262

Music tracks recorded on HDD cannot be recorded
onto CDs or other devices.

Tracks are recorded at four times the playback speed
using ultra-efficient compression technology;
therefore, sound quality may vary slightly from the
original.

If the HDD is ever replaced, all music data is lost and
cannot be recovered.

If there is a problem, you may see an error message
on the display.

2 Hard Disk Drive (HDD) Audio P. 275

18 ACURA RLX E-AWD-31TY36400.book  250 ページ  ２０１７年７月２０日　木曜日　午後６時８分

Continued

251

uu

Audio System Basic Operation

u

Playing Hard Disk Drive (HDD) Audio

Features

You can select scan, repeat, and random modes when playing a track.

1. Press the MENU button.
2. Rotate

 to select Scan or Random/

Repeat, then press

.

3. Rotate

 to select a mode, then press

.

1. Select Scan, Random or Repeat.

2 Playing Hard Disk Drive (HDD) Audio

P. 248

2. Select a mode.

■

To turn off a play mode

1. Press the MENU button.
2. Rotate

 to select the mode you want to turn off, then press

.

1. Select Scan, Random or Repeat.

2 Playing Hard Disk Drive (HDD) Audio P. 248

2. Select the mode you want to turn off.

■

How to Select a Play Mode

1

How to Select a Play Mode

Play Mode Menu Items
Scan
Scan Albums: Provides a 10-second sampling of the
first track in each album.
Scan Tracks: Provides a 10-second sampling of all
tracks on the HDD.

Random/Repeat
The following menu items vary depending on the
category you selected by the Music Search list.
Repeat Artist: Repeats all tracks in the current artist.
Repeat Album: Repeats all tracks in the current
album.
Repeat Track: Repeats the current track.
Random in Artist: Plays all tracks in the current artist
in random order.
Random in Album: Plays all tracks in the current
album in random order.
Random All Tracks: Plays all tracks in random order.

Random/Repeat is selected.

Interface Dial

On Demand Multi-Use Display

TM

Interface Dial

On Demand Multi-Use Display

TM

18 ACURA RLX E-AWD-31TY36400.book  251 ページ  ２０１７年７月２０日　木曜日　午後６時８分

uu

Audio System Basic Operation

u

Playing Hard Disk Drive (HDD) Audio

252

Features

Change the playlist name, album name, genre, and track order of the current
playlist. You can also delete tracks, playlists, and albums.

■

Editing an album

1. Press the MENU button.
2. Rotate

 to select Edit/Delete, then press

.

3. Rotate

to

select

Albums, then press

.

u

The pop-up menu appears on the screen.

4. Rotate

 to select an album that you want

to edit or delete, then press

.

5. To edit an album name:

Rotate

 to select Edit Name, then press

.

u

Enter the name using the interface dial or
the On Demand Multi-Use Display

TM

.

To delete an album:
Rotate

 to select Delete, then press

.

To edit track information or delete a track:
Rotate

 to select List Tracks, then press

.

2 Editing Track Information P. 255

■

Editing an Album or Playlist

1

Editing an Album or Playlist

The maximum number of songs in each of the six
user playlists is 999. Adding new songs overwrites
the oldest songs.

The maximum number of original playlists is 999 with
a maximum of 99 songs in each playlist.

Each album CD counts as an original playlist. Adding
a track from a user playlist into the same user playlist
will cause the track to appear twice in the playlist.

Deleting an album (original playlist) also deletes the
album tracks you have stored in any user playlists.

Deleting a user playlist or deleting all tracks from a
user playlist does not remove the playlist folder.
The folder retains the playlist name and artist
information.

Select

 to enter symbols.

 Icon

18 ACURA RLX E-AWD-31TY36400.book  252 ページ  ２０１７年７月２０日　木曜日　午後６時８分

253

uu

Audio System Basic Operation

u

Playing Hard Disk Drive (HDD) Audio

Continued

Features

■

Editing a playlist

1. Press the MENU button.
2. Rotate

 to select Edit/Delete, then press

.

3. Rotate

 to select Playlists, then press

.

u

The pop-up menu appears on the screen.

4. Rotate

 to select a playlist that you want

to edit or delete, then press

.

5. To edit a playlist name:

Rotate

 to select Edit Name, then press

.

u

Enter the name using the interface dial or
the On Demand Multi-Use Display

TM

.

To delete a playlist:
Rotate

 to select Delete, then press

.

To edit track information or delete a track:
Rotate

 to select List Tracks, then press

.

2 Editing Track Information P. 255

18 ACURA RLX E-AWD-31TY36400.book  253 ページ  ２０１７年７月２０日　木曜日　午後６時８分

254

uu

Audio System Basic Operation

u

Playing Hard Disk Drive (HDD) Audio

Features

■

Creating a new playlist

1. Press the MENU button.
2. Rotate

 to select Edit/Delete, then press

.

3. Rotate

 to select Playlists, then press

.

4. Rotate

 to select Create New Playlist,

then press

.

u

Enter the name using the interface dial or
the On Demand Multi-Use Display

TM

,

then select tracks from the Music
Search list.

18 ACURA RLX E-AWD-31TY36400.book  254 ページ  ２０１７年７月２０日　木曜日　午後６時８分

255

uu

Audio System Basic Operation

u

Playing Hard Disk Drive (HDD) Audio

Continued

Features

Change the track title, artist name, genre and composer. You can also delete tracks.

1. Press the MENU button.
2. Rotate

 to select Edit/Delete, then press

.

3. Rotate

 to select Tracks, then press

.

4. Rotate

 to select a track you want to edit

or delete, then press

.

u

The pop-up menu appears on the screen.

5. To edit track information:

Rotate

 to select Edit Name, then press

.

u

Enter the track name, track artist, etc.
using the interface dial or the On
Demand Multi-Use Display

TM

. Move  ,

rotate

 to select OK, then press

.

To delete a track:
Rotate

 to select Delete, then press

.

■

Editing Track Information

18 ACURA RLX E-AWD-31TY36400.book  255 ページ  ２０１７年７月２０日　木曜日　午後６時８分

256

uu

Audio System Basic Operation

u

Playing Hard Disk Drive (HDD) Audio

Features

Music information (album name, artist name, genre) can be acquired by accessing
the Gracenote® Album Info.

1. Press the MENU button.
2. Rotate

 to select Edit/Delete, then press

.

3. Rotate

to

select

Albums, then press

.

4. Rotate

 to select an album you want to

edit, then press

.

u

The pop-up menu appears on the screen.

5. Rotate

 to select Edit Name, then press

.

6. Move

to

select

Get Music Info, then

press .

u

The system starts to access the
Gracenote® Album Info.

■

Displaying Music Information

18 ACURA RLX E-AWD-31TY36400.book  256 ページ  ２０１７年７月２０日　木曜日　午後６時８分

257

uu

Audio System Basic Operation

u

Playing Hard Disk Drive (HDD) Audio

Features

Update the Gracenote® Album Info (Gracenote® Media Database) that is included
with the navigation system.

1. Insert the update disc into the disc slot or

connect the USB flash drive that includes
the update.

2. Press the SETTINGS button in the HDD

mode.

3. Rotate

 to select Audio Settings, then

press .

4. Move

or

to

select

the

CD/HDD tab.

5. Rotate

 to select Update Gracenote

Album Info, then press

.

6. Rotate

 to select Update by CD or

Update by USB, then press

.

u

The system starts updating and the
confirmation message appears on the
screen. Press

 to finish.

■

Updating Gracenote® Album Info

1

Updating Gracenote® Album Info

To acquire updated files:

•

Consult a dealer.

•

U.S.: Visit www.acura.com.

•

Canada: Visit www.acura.ca.

Once you perform an update, any information you
edited before will be overwritten or erased.

18 ACURA RLX E-AWD-31TY36400.book  257 ページ  ２０１７年７月２０日　木曜日　午後６時８分

258

uu

Audio System Basic Operation

u

Playing an iPod

Features

Playing an iPod

Connect the iPod using your USB connector to the USB port, then select the iPod
mode.

2 USB Port P. 213

Audio/Information Screen

MENU Button
Press to display the menu items.

Album Bar
Select to search for an album.

Source
Select to change an audio source.

Skip/Seek Icons
Select

 or

 to change songs.

Select and hold to move rapidly
within a song.

More
Select to display the menu items.

 (Power) Button

Press to turn the audio system
on and off.

BACK Button
Press to go back to the previous display.

Interface Dial/ENTER Button
Press and turn to select an item, then
press to set your selection.
Move up, down, right and left to select
secondary menu.

USB Indicator
Appears when an iPod is connected.

Album Art

On Demand Multi-Use Display

TM

VOL (Volume) Knob (Pushed out)
Turn to adjust the volume.

Album Art Icon

Repeat
Select to use a repeat feature.

Play/Pause Icon
Select to resume or play a song.
Shuffle
Select to use a shuffle feature.

18 ACURA RLX E-AWD-31TY36400.book  258 ページ  ２０１７年７月２０日　木曜日　午後６時８分

Continued

259

uu

Audio System Basic Operation

u

Playing an iPod

Features

1. Select the album bar.

u

The image of the current album is displayed.

2. Select

 or

 icon to search for an album.

u

When the album image you are looking for appears, select it to play.

■

How to Select an Album

1

How to Select an Album

This function may not be available depending on
models or versions.

Select

 to go back to the previous screen.

X

Select an album
image.

Select the
album bar.

Album Bar

Album Image

18 ACURA RLX E-AWD-31TY36400.book  259 ページ  ２０１７年７月２０日　木曜日　午後６時８分

uu

Audio System Basic Operation

u

Playing an iPod

260

Features

1. Press the MENU button.
2. Rotate

 to select Music Search, then

press .

3. Rotate

, move

 or

, then press

 to

select a song from the Music Search list.

You can also select a song by the following
procedure.
1. Rotate

 or press

 to display the song

list.

2. Rotate

, move

 or

, then press

 to

select a song from the list.

■

How to Select a Song from the Music Search List

1

How to Select a Song from the Music Search List

You can control an iPod using voice commands.

2 Voice Control Operation P. 232
2 Song By Voice

TM

 (SBV) P. 262

Available operating functions vary on models or
versions. Some functions may not be available on the
vehicle’s audio system.

If there is a problem, you may see an error message
on the audio/information screen.

2 iPod/USB Flash Drive P. 276

18 ACURA RLX E-AWD-31TY36400.book  260 ページ  ２０１７年７月２０日　木曜日　午後６時８分

261

uu

Audio System Basic Operation

u

Playing an iPod

Features

You can select repeat and shuffle modes when playing a file.

1. Press the MENU button.
2. Rotate

 to select Shuffle/Repeat, then

press .

3. Rotate

 to select a mode, then press

.

1. Select Shuffle or Repeat.

2 Playing an iPod P. 258

2. Select a mode.

■

To turn off a play mode

1. Press the MENU button.
2. Rotate

 to select the mode you want to turn off, then press

.

1. Select Shuffle or Repeat.

2 Playing an iPod P. 258

2. Select the mode you want to turn off.

■

How to Select a Play Mode

1

How to Select a Play Mode

Play Mode Menu Items
Repeat Song: Repeats the current track.
Shuffle Albums: Plays all available albums in a
selected list (playlists, artists, albums, songs, genres,
or composers) in random order.
Shuffle All Songs: Plays all available files in a
selected list (playlists, artists, albums, songs, genres,
or composers) in random order.

Interface Dial

On Demand Multi-Use Display

TM

Interface Dial

On Demand Multi-Use Display

TM

18 ACURA RLX E-AWD-31TY36400.book  261 ページ  ２０１７年７月２０日　木曜日　午後６時８分

262

uu

Audio System Basic Operation

u

Song By Voice

TM

 (SBV)

Features

Song By Voice

TM

 (SBV)

Use SBV to search for and play music from your HDD or iPod using voice commands.

■

To enable SBV

1. Press the SETTINGS button.
2. Rotate

 to select System Settings, then

press .

3. Move

 or

 to select the Voice Reco

tab.

4. Rotate

 to select Song By Voice, then

press .

5. Rotate

 to select On or Off, then press

.

1

Song By Voice

TM

 (SBV)

Setting options:

•

On (factory default): Song By Voice

TM

 commands

are available.

•

Off: Disable the feature.

18 ACURA RLX E-AWD-31TY36400.book  262 ページ  ２０１７年７月２０日　木曜日　午後６時８分

Continued

263

uu

Audio System Basic Operation

u

Song By Voice

TM

 (SBV)

Features

■

Searching for music using SBV

1. Set the Song By Voice setting to On.
2. Press the

 (Talk) button and say “Music

Search” to activate the SBV feature for the
HDD and iPod.

3. Press the

 button and say a command.

u

Example 1: Say “(List) ‘Artist A’“ to view a
list of songs by that artist. Select the
desired song to start playing.

u

Example 2: Say “Play ‘Artist A’“ to start
playing songs by that artist.

4. To cancel SBV, press the

 (hang-up/

back) button on the steering wheel. The
selected song continues playing.

Once you have canceled this mode, you need
to press the

 button and say “Music Search”

again to re-activate this mode.

1

Searching for music using SBV

 Song By Voice

TM

 Commands List

2 Song By Voice Commands P. 236

NOTE:
Song By Voice

TM

 commands are available for tracks

stored on the HDD or iPod.

You can add phonetic modifications of difficult
words so that it is easier for SBV to recognize artists,
songs, albums, and composers in voice commands.

2 Phonetic Modification P. 264

18 ACURA RLX E-AWD-31TY36400.book  263 ページ  ２０１７年７月２０日　木曜日　午後６時８分

uu

Audio System Basic Operation

u

Song By Voice

TM

 (SBV)

264

Features

Add phonetic modifications of difficult or foreign words so that it is easier for SBV
to recognize artists, songs, albums, and composers in voice commands when
searching for music on the HDD or iPod.

1. Press the SETTINGS button.
2. Rotate

 to select System Settings,

then press

.

3. Move

 or

 to select the Voice Reco

tab.

4. Rotate

 to select Song By Voice

Phonetic Modification, then press

.

5. Move   and rotate

 to select New

Modification, then press

.

6. Rotate

 to select HDD or iPod, then

press .

■

Phonetic Modification

1

Phonetic Modification

Phonetic Modification is grayed out when Song By
Voice is set to Off.

You can store up to 2,000 phonetic modification
items.

18 ACURA RLX E-AWD-31TY36400.book  264 ページ  ２０１７年７月２０日　木曜日　午後６時８分
