Acura RLX (2018 year). Manual - part 14

217

uu

Audio System Basic Operation

u

On Demand Multi-Use Display

TM

Continued

Features

On Demand Multi-Use Display

TM

Use the On Demand Multi-Use Display

TM

 to operate the audio system.

Select Source, then select an icon on the source list to switch the audio source.

Select More to display the menu items.

■

Selecting an Audio Source

1

On Demand Multi-Use Display

TM

Icons that appear on the screen vary by the source
selected.

Select

 to go back to the previous screen.

Use the

/

/

/

 icons to turn the page.

X

1

Selecting an Audio Source

You can change the order of source icons displayed.

1. Select Source, ,

then

Edit Order.

2. Select two icons, then select Done.
The locations of these icons are switched.
To go back to the original display order, select
Default.

■

Displaying the Menu Items

Select Source.

Source List Icons

Select More.

Menu Items

18 ACURA RLX E-AWD-31TY36400.book  217 ページ  ２０１７年７月２０日　木曜日　午後６時８分

uu

Audio System Basic Operation

u

On Demand Multi-Use Display

TM

218

Features

You can preset the settings of four categories
(Places, Phone, Climate, Audio) from
Shortcuts.

■

Shortcuts

1

Shortcuts

The preset memory is cleared when it is disconnected
from the power source, such as when the 12-volt
battery is disconnected or goes dead.

Shortcuts Icon

18 ACURA RLX E-AWD-31TY36400.book  218 ページ  ２０１７年７月２０日　木曜日　午後６時８分

Continued

219

uu

Audio System Basic Operation

u

On Demand Multi-Use Display

TM

Features

■

Places

You can store up to six addresses, and the home address for your preset
destinations.

To store an address on the selected preset
number:
1. Select Shortcuts.
2. Select Places.
3. Select Edit or No Entry.

u

If you select No Entry, go to step 6.

4. Select Add.

u

All the six preset icons appear.

5. Select the preset number to which you

want to store an address.

6. The screen changes to a list of addresses

stored in your address book.

7. Select an address you want to store as a

preset.

To enter one of the preset addresses, or
Home as your destination:
1. Select Shortcuts.
2. Select Places.
3. Select a preset number or Home.

u

The system starts to calculate the route
to your selected destination.

1

Places

See the Navigation System Manual for how to store
address book entries, and enter your home address.

18 ACURA RLX E-AWD-31TY36400.book  219 ページ  ２０１７年７月２０日　木曜日　午後６時８分

220

uu

Audio System Basic Operation

u

On Demand Multi-Use Display

TM

Features

To delete a preset address:
1. Select Shortcuts.
2. Select Places.
3. Select Edit.
4. Select Delete.
5. Select the preset number with the destination you want to delete.

18 ACURA RLX E-AWD-31TY36400.book  220 ページ  ２０１７年７月２０日　木曜日　午後６時８分

Continued

221

uu

Audio System Basic Operation

u

On Demand Multi-Use Display

TM

Features

■

Phone

You can preset five speed dial entries, and make a call from one of the preset
numbers, or call history when the phone is paired and connected to the vehicle’s
Bluetooth® HandsFreeLink® (HFL) system.

2 Phone Setup P. 332

To preset a speed dial:
1. Select Shortcuts.
2. Select Phone.
3. Select Speed Dial.
4. Select Edit or No Entry.

u

If you select No Entry, go to step 6.

5. Select Add.

u

Five presets appear. Select a No Entry
preset or an existing preset.

u

The screen changes to a list of previously
stored speed dial entries.

6. Select a number you want to store as a

shortcut.

To make a call from a speed dial entry:
1. Select Shortcuts.
2. Select Phone.
3. Select Speed Dial.
4. Select a preset number.

u

Dialing starts automatically.

1

Phone

Dial icon
You can make a call using the keyboard on the On
Demand Multi-Use Display

TM

 to input numbers.

2 To make a call using a phone number

P. 353

18 ACURA RLX E-AWD-31TY36400.book  221 ページ  ２０１７年７月２０日　木曜日　午後６時８分

uu

Audio System Basic Operation

u

On Demand Multi-Use Display

TM

222

Features

To delete a speed dial:
1. Select Shortcuts.
2. Select Phone.
3. Select Speed Dial.
4. Select Edit.
5. Select Delete.
6. Select the preset number with the phone number you want to delete.

To make a call from call history:
1. Select Shortcuts.
2. Select Phone.
3. Select Call History.
4. Select a phone number.

u

Dialing starts automatically.

1

Phone

The call history displays the last six dialed, received, or
missed calls.

18 ACURA RLX E-AWD-31TY36400.book  222 ページ  ２０１７年７月２０日　木曜日　午後６時８分

Continued

223

uu

Audio System Basic Operation

u

On Demand Multi-Use Display

TM

Features

■

Audio

You can store up to six radio stations, and HDD audio album/play lists when playing
AM, FM, or SiriusXM® radio, or HDD audio.

To preset a station or song:
1. Tune to a radio station or select a song from

HDD audio.

2 Playing AM/FM Radio P. 237
2 Playing SiriusXM® Radio P. 242
2 Playing Hard Disk Drive (HDD) Audio

P. 248

2. Select Shortcuts.
3. Select Audio.
4. Select Edit or No Entry.

u

If you select No Entry, go to step 6.

5. Select Add.
6. Select the preset icon you want to store the

station or song to.

To play a preset station or song:
1. Select Shortcuts.
2. Select Audio.
3. Select a preset icon.

To delete a preset station or song:
1. Select Shortcuts.
2. Select Audio.
3. Select Edit.
4. Select Delete.
5. Select the preset icon with the radio station

or a song you want to delete.

1

Audio

You can also preset a station or song by pressing and
holding the preset icon you want to store that station
or song after step 3.

18 ACURA RLX E-AWD-31TY36400.book  223 ページ  ２０１７年７月２０日　木曜日　午後６時８分

uu

Audio System Basic Operation

u

On Demand Multi-Use Display

TM

224

Features

1. Select More, then Sound.
2. Use

(

+,

(

- or other icons to adjust the

setting.

1. Select More, then Screen Settings.
2. Use

(

+,

(

- or other icons to adjust the

setting.

■

Adjusting the Sound

1

Adjusting the Sound

Select Off, Low, Mid or High for the SVC setting.

2 Adjusting the Sound P. 230

Instead of using

(

+,

(

- or icons, you can also touch

the point where your desired setting is.

You can also adjust the sound by selecting

 on

the On Demand Multi-Use Display

TM

.

■

Changing the Screen Settings

1

Changing the Screen Settings

The following are adjustable screen settings:

•

Sync Display Brightness

Selects whether the screen brightness synchronizes
with the instruments panel brightness.

•

Brightness

•

Contrast

•

Black Level

•

Display

Changes between the daytime or nighttime modes.

•

Beep

Mutes a beep that sounds every time you touch the
screen.

•

Keyboard

Changes the on-screen keyboard from the
alphabetical order to the qwerty type.

•

Vibration

Turns on and off the vibration when you touch the
screen.

•

Fade Timer

Sets the screen black out timing.

Instead of using

(

+,

(

- or icons, you can also touch

the point where your desired setting is.

18 ACURA RLX E-AWD-31TY36400.book  224 ページ  ２０１７年７月２０日　木曜日　午後６時８分

225

uu

Audio System Basic Operation

u

Audio/Information Screen

Continued

Features

Audio/Information Screen

Displays the audio status and wallpaper. From this screen, you can go to various
setup options.

Press the NAV, PHONE, INFO and AUDIO buttons to go to the corresponding
display.

■

Switching the Display

Audio

Info

Navigation

Phone

AUDIO
Button

NAV
Button

PHONE
Button

INFO
Button

Models with surround view camera
system

Models without surround view
camera system

AUDIO
Button

NAV
Button

PHONE
Button

INFO
Button

18 ACURA RLX E-AWD-31TY36400.book  225 ページ  ２０１７年７月２０日　木曜日　午後６時８分

226

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

■

Audio

Shows the current audio information.

■

Navigation

Shows the navigation screen.

2 Refer to the Navigation System Manual

■

Phone

Shows the HFL information.

2 Bluetooth® HandsFreeLink® P. 326

■

Info

Shows the Trip Computer or Clock/Wallpaper and other information. Rotate



to select an item, then press

.

■

Trip computer (Current Drive)

Shows the range, instant and average fuel economy, and EV/total drive of the
current trip, as well as the average fuel economy from your last trip.

■

Trip computer (History of Trip A)

Shows the range, average fuel economy and distances traveled for the current trip, as well
as the average fuel economy and distances traveled during the last three driving cycles.
Each time you reset the trip meter A, the information on the display updates. The
history of the previous three driving cycles is kept.

■

Deleting the history manually

1. Move   on the History of Trip A screen to select Delete History, then press

.

2. You will receive a confirmation message on the screen. Rotate

 to select Yes,

then press

.

■

Clock/Wallpaper

Shows a clock screen or an image you import.

18 ACURA RLX E-AWD-31TY36400.book  226 ページ  ２０１７年７月２０日　木曜日　午後６時８分

Continued

227

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

■

Power Distribution Monitor

Consists of two monitoring displays, one that
indicates the vehicle’s power flow, and the
other, the torque distribution.

1

Power Distribution Monitor

The power distribution monitor is also displayed on
the head-up display. See Power Distribution
Monitor on  P. 124 for details.

While the vehicle is stationary with the engine
running, the following may appear on the display.

The High Voltage battery charge level gauge shows
the current High Voltage battery charge level.
The amount shown here is the same level as the
gauge amount shown in the instrument panel.

2  High Voltage Battery Charge Level Gauge

P. 113

High Voltage
Battery
Charge Level
Gauge

Engine Icon

Torque
Indicator

Torque
Indicator

Power Flow Indicator

18 ACURA RLX E-AWD-31TY36400.book  227 ページ  ２０１７年７月２０日　木曜日　午後６時８分

uu

Audio System Basic Operation

u

Audio/Information Screen

228

Features

You can change, store, and delete the wallpaper on the audio/information screen.

■

Import wallpaper

You can import up to three images, one at a time, for wallpaper from a USB flash
drive.

1. Connect the USB flash drive to the USB port.

2 USB Port P. 213

2. Press the SETTINGS button.
3. Rotate

 to select System Settings, then

press .

4. Move

 or

 to select the Clock tab.

5. Rotate

 to select Clock/Wallpaper

Type, then press

.

6. Move

 to select Wallpaper.

u

The screen will change to the wallpaper
list.

7. Move   to select Add New Wallpaper, then

press .

8. Rotate

 to select a desired picture.

u

The preview is displayed on the left side
on the screen.

9. Press

, then move   to select Start

Import.

u

The confirmation message will appear.
Then the display will return to the
wallpaper list.

■

Wallpaper Setup

1

Wallpaper Setup

•

When importing wallpaper files, the image must be
in the USB flash drive’s root directory.
Images in a folder cannot be imported.

•

The file name must be fewer than 64 characters.

•

The file format of the image that can be imported
is BMP (bmp) or JPEG (jpg).

•

The individual file size limit is 6 MB.

•

The maximum image size is 1,680 x 936 pixels. If
the image size is less than 420 × 234 pixels, the
image is displayed in the middle of the screen with
the extra area appearing in black.

•

Up to 255 files can be selected.

•

If the USB flash drive does not have any pictures,
the No files detected message appears.

18 ACURA RLX E-AWD-31TY36400.book  228 ページ  ２０１７年７月２０日　木曜日　午後６時８分

229

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

■

Select wallpaper

1. Press the SETTINGS button.
2. Rotate

 to select System Settings, then press

.

3. Move

 or

 to select the Clock tab.

4. Rotate

 to select Clock/Wallpaper Type, then press

.

5. Move

to

select

Wallpaper.

u

The screen changes to the wallpaper list.

6. Rotate

 to select a desired wallpaper.

u

The preview is displayed on the left side on the screen.

7. Press .

u

The pop-up menu appears on the screen.

8. Rotate

 to select Set, then press

.

u

The display will return to the wallpaper list.

■

Delete wallpaper

1. Press the SETTINGS button.
2. Rotate

 to select System Settings, then press

.

3. Move

 or

 to select the Clock tab.

4. Rotate

 to select Clock/Wallpaper Type, then press

.

5. Move

to

select

Wallpaper.

u

The screen changes to the wallpaper list.

6. Rotate

 to select a wallpaper that you want to delete, then press

.

u

The preview is displayed on the left side on the screen.

7. Press .

u

The pop-up menu appears on the screen.

8. Rotate

 to select Delete, then press

.

u

The confirmation message will appear.

9. Rotate

 to select Yes, then press

 to delete completely.

u

The display will return to the wallpaper list.

1

Wallpaper Setup

From the pop-up menu, rotate

 to select Preview

and press

 to see a preview at full-size screen.

To go back to the previous screen, press

 to select

OK, or press the BACK button.

When the file size is large, it takes a while to be
previewed.

18 ACURA RLX E-AWD-31TY36400.book  229 ページ  ２０１７年７月２０日　木曜日　午後６時８分

230

uu

Audio System Basic Operation

u

Adjusting the Sound

Features

Adjusting the Sound

1. Press the MENU button.
2. Rotate

 to select Sound, then press

.

Rotate

 to scroll through the following

choices:

1

Adjusting the Sound

The SVC has four modes: Off, Low, Mid, and High.
SVC adjusts the volume level based on the vehicle
speed. As you go faster, audio volume increases. As
you slow down, audio volume decreases.

DTS Neural Surround is a trademark of DTS, Inc.

2 Adjusting the Sound P. 224

On Demand Multi-Use Display

TM

MENU Button

Speed-sensitive
Volume
Compensation

Bass

Treble

Fader

Balance

Subwoofer

SVC

Center

DTS Neural

Surround

18 ACURA RLX E-AWD-31TY36400.book  230 ページ  ２０１７年７月２０日　木曜日　午後６時８分

231

uu

Audio System Basic Operation

u

Display Setup

Features

Display Setup

You can change the brightness or color theme of the audio/information screen.

1. Press the SETTINGS button.
2. Rotate

 to select System Settings, then

press .

3. Move

or

to

select

the

Display tab.

4. Rotate

to

select

Brightness, then press

.

5. Rotate

 to adjust the setting.

1. Press the SETTINGS button.
2. Rotate

 to select System Settings, then

press .

3. Move

or

to

select

the

Others tab.

4. Rotate

 to select Background Color,

then press

.

5. Rotate

 to select the setting you want,

then press

.

■

Changing the Screen Brightness

1

Changing the Screen Brightness

You can change the Contrast and Black Level
settings in the same manner.

■

Changing the Screen’s Color Theme

18 ACURA RLX E-AWD-31TY36400.book  231 ページ  ２０１７年７月２０日　木曜日　午後６時８分

232

uu

Audio System Basic Operation

u

Voice Control Operation

Features

Voice Control Operation

Your vehicle has a voice control system that allows hands-free operation of most of
the navigation system functions.
The voice control system uses the

 (Talk) and

 (hang-up/back) buttons on

the steering wheel and a microphone near the map lights on the ceiling.

To achieve optimum voice recognition when using the voice control system:
• Make sure the correct screen is displayed for the voice command that you are

using.
The system recognizes only certain commands. Available voice commands.

2 Voice Portal Screen P. 233

• Close the windows and moonroof.
• Adjust the dashboard and side vents so air does not blow onto the microphone

on the ceiling.

• Speak clearly in a clear, natural speaking voice without pausing between words.
• Reduce any background noise if possible. The system may misinterpret your

command if more than one person is speaking at the same time.

• Refer to the Voice Help feature.

2 Refer to the Navigation System Manual

■

Voice Recognition

1

Voice Control Operation

When you press the

 button, a helpful prompt asks

what you would like to do. Press and release the



button again to bypass this prompt and give a
command.

1

Voice Recognition

The voice control system can only be used from the
driver’s seat because the microphone unit removes
noises from the front passenger’s side.

18 ACURA RLX E-AWD-31TY36400.book  232 ページ  ２０１７年７月２０日　木曜日　午後６時８分
