20

Quick

 Referenc

e Guide

Climate Control System

(P 156)

● Press the AUTO button to activate the climate control system.

● Press the

 button to turn the system on or off.

● Press the

 button to defrost the windshield.

Passenger side Temperature Control
Buttons

 (Windshield Defroster) Button

Driver side
Temperature Control
Buttons

 (Recirculation) Button

 (CLIMATE) Button

 (ON/OFF) Button

AUTO Button

Audio/Information Touch Screen

SYNC (Synchronized) Button

Air flows from floor and
windshield defroster vents.
Air flows from floor vents.
Air flows from floor and
dashboard vents.
Air flows from dashboard vents.
MID vents provide supplemental
air to the lower body of the
occupant(s). MID vents can be
used together with any other
vent mode.

17 NSX-31T6N6000.book  20 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

21

Quick

 Referenc

e Guide

Features

(P 161)

Audio system

(P 166)

Audio/Information Screen

 (Power/Audio) Icon

VOL (Volume) Icons

 (Day/Night) Icon

For navigation system operation

() See the Navigation System Manual

 (Home) Icon

 (Menu) Icon

 (Back) Icon

 (App List) Icon

*

*

* Not available on all models

17 NSX-31T6N6000.book  21 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

22

Quick

 Referenc

e Guide

Audio Remote Controls

(P 165)

● SOURCE Button

Press to change the audio mode: FM/
SiriusXM®

*

/USB/iPod/Pandora®

*

/Apps

*

/

Bluetooth® Audio/Audio Apps

*

.

● Left Selector Wheel

Roll to adjust the volume up/down.
Radio:Move right or left to change the

preset station.
Move and hold to select the next
or previous strong station.

USB device:

Move right or left to skip to the
beginning of the next song or
return to the beginning of the
current song.
Move and hold to change a folder.

Left Selector Wheel

SOURCE Button

17 NSX-31T6N6000.book  22 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

23

Quick

 Referenc

e Guide

Driving

(P 297)

Electronic Gear Selector

(P 314)

● Select

(

P and depress the brake pedal when turning on the power.

Park
Press the

(

P button.

Used when parking or before turning the power on or off.
Transmission is locked.

Reverse
Press back the

(

R button.

Used when reversing.
Neutral
Press the

(

N button.

Used to keep the transmission disengaged from the engine and motor.

Drive/Manual
Each time you press the

 button, the mode switches between D (drive) and M (manual) mode.

●

Normal driving (gears change between 1st and 9th automatically)

●

Temporarily driving in the sequential mode

●

Driving in the sequential mode

D/M

D (Drive)

M (Manual)

Gear Position Indicator/Gear
Selection Indicator
The gear position indicator, the
gear selection indicator and the
shift button indicator indicate
the current gear selection.

Gear Position Indicator

Shift Button
Indicator

● Gear selection

Gear Selection Indicator

* Not available on all models

17 NSX-31T6N6000.book  23 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

24

Quick

 Referenc

e Guide

Paddle Shifters

(P322)

Paddle shifters allow you to shift gears much like a manual transmission (1st through 9th). This is useful for regenerative braking.
You cannot shift up or down while in EV mode.

When the transmission is in

(

D

 (D-paddle shift mode)

The vehicle will go into the sequential mode momentarily, and the gear selection
indicator becomes more prominent.
The sequential mode is automatically canceled and the gear selection indicator
returns to ordinary display under the following conditions.

•

Hold the

(

+ paddle shifter for a few seconds.

•

Once you start traveling at a constant speed.

•

The vehicle comes to a complete stop.

•

When you change to another IDS mode.

The sequential mode automatically shifts under following condition

•

Accelerator pedal depressed beyond the click.

•

Engine speed reaches near the tachometer’s red zone.

•

Engine speed reaches idle speed while deceleration.

When the transmission is in M (Manual) mode

The vehicle will go into the sequential mode, and the gear position indicator goes
off and only the gear selection indicator is displayed.
You can cancel this mode by pressing the

 button, pulling the

(

+ paddle

shifter for a few seconds or changing IDS mode to QUIET. When the sequential
mode is canceled, the display is changed from only the gear selection indicator to
both of the gear position indicator and the gear selection indicator.
The transmission automatically shifts up from 1st to 2nd and does not
automatically shift up between 2nd and 9th gear.

D/M

Gear Position Indicator

Shift Down

(

-

Paddle Shifter

Shift Up

(

+

Paddle Shifter

Gear Selection Indicator

Gear Selection Indicator

Gear Selection Indicator

Gear Position Indicator

D (Drive)

D-Paddle

M (Manual)

17 NSX-31T6N6000.book  24 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

25

Quick

 Referenc

e Guide

VSA® OFF Button

(P 334)

● The Vehicle Stability Assist (VSA®) system

helps stabilize the vehicle during
cornering, and helps maintain traction
while accelerating on loose or slippery
road surfaces.

● VSA® comes on automatically every time

you turn on the power system.

Tire Pressure Monitoring
System (TPMS)

(P 339)

● The TPMS monitors tire pressure.

● The TPMS is turned on automatically

every time you turn on the power system.

Refueling

(P 357)

a

Press the fuel fill
door release button.

b

After refueling,
wait for about five
seconds before
removing the filler
nozzle.

Fuel requirement:

Unleaded premium gasoline with a pump octane
number 91 or higher

Fuel tank capacity: 15.6 US gal (59.0 liters)

Wait for five seconds

17 NSX-31T6N6000.book  25 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

26

Quick

 Referenc

e Guide

Maintenance

(P 361)

Press the hatch release button on the
driver’s door.

Lights

(P387)

● Inspect all lights regularly.

Under the Hatch

(P372)

● Check engine oil and engine coolant.

Add when necessary.

Tires

(P393)

● Inspect tires and wheels regularly.

● Check tire pressures regularly.

● Install winter tires for winter driving.
Handling Summer Only tires and Ultra High Performance
(UHP) tires in low ambient temperatures.

2 Cold Weather Driving (P402)

17 NSX-31T6N6000.book  26 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

27

Quick

 Referenc

e Guide

Under the Hood

(P371)

● Check inverter coolant.

● Check brake fluid.

● Check the 12-volt battery condition monthly.

Lights

(P387)

● Inspect all lights regularly.

Wiper Blades

(P390)

● Replace blades if they leave

streaks across the windshield.

a

Pull the hood release handle under the corner of the
dashboard.

b

Locate the hood latch lever, push the lever and lift
the hood.

c

When finished, close the hood and make sure both
right and left latches are firmly locked in place.

17 NSX-31T6N6000.book  27 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

28

Quick

 Referenc

e Guide

Handling the Unexpected

(P 417)

Flat Tire

(P 419)

● Park in a safe location and repair the flat

tire using the temporary tire repair kit.

Indicators Come On

(P 438)
● Identify the indicator and consult the

owner’s manual.

Power System Won’t Start

(P 431)
● If the 12-volt battery is dead, jump start

using a booster battery.

Blown Fuse


(P 443)

● Check for a blown fuse if an electrical

device does not operate.

Overheating

(P 436)

● Park in a safe location. If you do not see

steam under the hatch, open the hatch,
and let the power system and the engine
cool down.

Emergency Towing

(P 448)
● Call a professional towing service if you

need to tow your vehicle.

17 NSX-31T6N6000.book  28 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

29

Quick

 Referenc

e Guide

What to Do If

Why do the doors lock
after I unlocked the doors?

If you do not open the doors within 30 seconds, the doors are
relocked automatically for security.

Why does the beeper
sound when I open the
driver’s door?

The beeper sounds when:

●

The power mode is in ACCESSORY.

●

The exterior lights are left on.

Why does the beeper
sound when I start driving?

The beeper sounds when the driver and/or passenger are not
wearing their seat belts.

Why do I hear a screeching
sound when I apply the
brake pedal?

The brake pads may need to be replaced. Have your vehicle
inspected by an authorized Acura NSX dealer.

Pressing the electric
parking brake switch does
not release the parking
brake. Why?

Press the electric parking brake switch with the brake pedal
depressed.

Models with iron brake discs

17 NSX-31T6N6000.book  29 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

30

Quick

 Referenc

e Guide

Depressing the accelerator
pedal does not release the
parking brake
automatically. Why?

●

Fasten the driver’s seat belt.

●

Check if the transmission is in

(

P

 or

(

N

. If so, select any other

position.

Why does the gear position
automatically change to

(

P



when I open the driver's
door to check for parking
space lines when
reversing?

●

Fasten the driver’s seat belt.

●

Close the driver's door and manually change the gear
position.

u

When opening the driver’s door



(P 317)

17 NSX-31T6N6000.book  30 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

31

Safe Driving

You can find many safety recommendations throughout this chapter, and throughout this manual.

For Safe Driving

Important Safety Precautions.............. 32
Your Vehicle’s Safety Features............ 34
Safety Checklist ................................. 35

Seat Belts

About Your Seat Belts ........................ 36
Fastening a Seat Belt .......................... 39
Seat Belt Inspection............................ 42

Airbags

Airbag System Components ............... 43
Types of Airbags ................................ 46
Front Airbags (SRS) ............................ 46

Driver’s Knee Airbag .......................... 50
Side Airbags....................................... 52
Side Curtain Airbags .......................... 54
Airbag System Indicators.................... 55
Airbag Care ....................................... 57

Child Safety

Protecting Child Passengers ............... 58
Safety of Infants and Small Children... 60
Safety of Larger Children ................... 65

Exhaust Gas Hazard

Carbon Monoxide Gas ....................... 67

Safety Labels

Label Locations .................................. 68

17 NSX-31T6N6000.book  31 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

32

Safe Driving

For Safe Driving

The following pages explain your vehicle’s safety features and how to use them
properly. The safety precautions below are ones that we consider to be among the
most important.

Important Safety Precautions

■

Always wear your seat belt

A seat belt is your best protection in all types of collisions. Airbags are designed to
supplement seat belts, not replace them. So even though your vehicle is equipped
with airbags, make sure you and your passenger always wear your seat belts, and
wear them properly.

■

Your vehicle is not recommended for child passengers

The National Highway Traffic Safety Administration and Transport Canada
recommend that all children ages 12 and under be properly restrained in a back
seat. Since this vehicle does not have a back seat, we strongly recommend that you
do not carry any child who is not large enough and mature enough to ride in front.

■

Be aware of airbag hazards

While airbags can save lives, they can cause serious or fatal injuries to occupants
who sit too close to them, or are not properly restrained. Infants, young children,
and short adults are at the greatest risk. Be sure to follow all instructions and
warnings in this manual.

■

Don’t drink and drive

Alcohol and driving don’t mix. Even one drink can reduce your ability to respond to
changing conditions, and your reaction time gets worse with every additional drink.
So don’t drink and drive, and don’t let your friends drink and drive, either.

1

Important Safety Precautions

Some states, provinces and territories prohibit the use
of cell phones other than hands-free devices by the
driver while driving.

Never carry an infant in a rear-facing child seat in this
vehicle.
If an older child must ride in this vehicle, follow all
child safety instructions and warnings in this manual.

2 Child Safety P. 58

17 NSX-31T6N6000.book  32 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

33

uu

For Safe Driving

u

Important Safety Precautions

Safe Driving

■

Pay appropriate attention to the task of driving safely

Engaging in cell phone conversation or other activities that keep you from paying
close attention to the road, other vehicles, and pedestrians could lead to a crash.
Remember, situations can change quickly, and only you can decide when it is safe to
divert some attention away from driving.

■

Control your speed

Excessive speed is a major factor in crash injuries and deaths. Generally, the higher
the speed, the greater the risk, but serious injuries can also occur at lower speeds.
Never drive faster than is safe for current conditions, regardless of the maximum
speed posted.

■

Keep your vehicle in safe condition

Having a tire blowout or a mechanical failure can be extremely hazardous.
To reduce the possibility of such problems, check your tire pressures and condition
frequently, and perform all regularly scheduled maintenance.

17 NSX-31T6N6000.book  33 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

34

uu

For Safe Driving

u

Your Vehicle’s Safety Features

Safe Driving

Your Vehicle’s Safety Features

The following checklist will help you take an active role in protecting yourself and
your passenger.

1

Your Vehicle’s Safety Features

Your vehicle is equipped with many features that
work together to help protect you and your
passenger during a crash.

Some features do not require any action on your part.
These include a strong framework that forms a safety
cage around the passenger compartment, front and
rear crush zones, a collapsible steering column, and
tensioners that tighten the seat belts in a sufficient
crash.

However, you and your passenger cannot take full
advantage of these features unless you remain seated
in the correct position and always wear your seat
belts. In fact, some safety features can contribute to
injuries if they are not used properly.

6

7

9

10

11

12

Safety Cage
Crush Zones
Seats and Seat-Backs
Head Restraints
Collapsible Steering Column
Seat Belts
Front Airbags

Side Curtain Airbags
Door Locks

Side Airbags

Seat Belt Tensioners

7

7

10

10

9

9

11

11

6

12

8

Knee Airbag

8

17 NSX-31T6N6000.book  34 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

35

uu

For Safe Driving

u

Safety Checklist

Safe Driving

Safety Checklist

For the safety of you and your passenger make a habit of checking these items each
time before you drive.
• After everyone has entered the vehicle, be sure both doors are closed and locked.

Locking the doors helps prevent an occupant from being ejected and an outsider
from unexpectedly opening a door.

2 Locking/Unlocking the Doors from the Inside P. 115

• Adjust your seat to a position suitable for driving. Be sure the seats are adjusted

as far to the rear as possible while allowing the driver to control the vehicle.
Sitting too close to a front airbag can result in serious or fatal injury in a crash.

2 Adjusting the Seats P. 144

• Always wear your seat belt, and make sure you wear it properly. Confirm that any

passenger is properly belted as well.

2 Fastening a Seat Belt P. 39

• If you choose to ignore our warnings and carry a child in this vehicle, make every

effort to protect them by properly using a seat belt or a child seat according to the
child’s age, height, and weight.

2 Child Safety P. 58

1

Safety Checklist

If the Door Open or Door And Trunk Open
message appears on the driver information interface,
a door and/or the trunk (hatch) is not completely
closed. Close both doors and the trunk (hatch) tightly
until the message disappears.

2 Driver Information Interface Warning and

Information Messages P. 88

17 NSX-31T6N6000.book  35 ページ  ２０１６年４月２２日　金曜日　午後３時４４分
