Acura MDX Hybrid (2017 year). Manual - part 2

20

Quick

 Referenc

e Guide

Climate Control System

(P214)

● Press the AUTO button to activate the climate control system.

● Press the

 button to turn the system on or off.

● Press the

 button to defrost the windshield.

The climate control system is voice operable. See the Navigation System Manual for
complete details.

Driver’s Side
Temperature
Control Switch

Air flows from floor and
windshield defroster vents.

Air flows from floor vents.

Air flows from floor and
dashboard vents.

Air flows from dashboard vents.

AUTO Button

Passenger’s Side
Temperature
Control Switch

 (On/Off) Button

Driver’s Side
Temperature Icon

Passenger’s Side
Temperature Icon

On Demand
Multi-Use
Display

TM

 (Windshield Defroster) Button

A/C (Air
Conditioning) and
SYNC
(Synchronized) Icon

Recirculation/
Fresh Air Mode
Icon

Fan Control Icon

REAR (Rear Climate
Control) Icon

Vent Mode
Control Icon

Rear Climate Control

(P225)

● Press the AUTO button to activate the

rear climate control system.

● Press the

 button to turn the system

on or off.

Audio System

For navigation system operation

() See

the Navigation System Manual

Rear Temperature
Control Buttons

 /



(Fan Control)
Button

AUTO Button

 (On/Off)

Button

Mode Control Button

Air flows from the rear floor vents.

Air flow from the rear console
vents and floor vents.

Air flows from the rear console vents.

17 ACURA MDX E-AWD-31TRX6000.book  20 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

21

Quick

 Referenc

e Guide

Driving

(P229)

Electronic Gear Selector

(P247)

● Always depress the brake pedal before selecting

(

P or changing the gear position from

(

P.

● Select

(

P and depress the brake pedal when turning on the power.

Park
Press the

(

P button.

Used when parking or before
turning the power on or off.
Transmission is locked.

Reverse
Pull back the

(

R button.

Used when reversing.

Neutral
Press the

(

N button.

Transmission is not locked.

Drive
Press the

(

D button.

Used for normal driving.
D-paddle shift mode can be used.

Gear Position Indicator
The gear position indicator and the
shift button indicator indicate the
current gear selection.

Gear Position Indicator

Shift Button
Indicator

● Gear selection

S Position
Press the

(

D button twice.

Sequential shift mode can be used.

17 ACURA MDX E-AWD-31TRX6000.book  21 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

22

Quick

 Referenc

e Guide

Paddle Shifters

(P254)

● Paddle shifters allow you to shift gears much like a manual

transmission (1st through 7th). This is useful for regenerative
braking.

● D-paddle shift mode: The

transmission will shift back to
automatic mode once the
system detects that the vehicle
is cruising.

● Sequential mode gear selection:

Holds the selected gear, and the
M (sequential mode) indicator
comes on.

● The sequential mode gear

selection is shown in the
instrument panel.

Gear Position Indicator

Shift Down

(

-

Paddle Shifter

Shift Up

(

+

Paddle Shifter

Selected Gear Number

M Indicator

17 ACURA MDX E-AWD-31TRX6000.book  22 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

23

Quick

 Referenc

e Guide

VSA® On and Off

(P288)

● The vehicle stability assist (VSA®) system

helps stabilize the vehicle during
cornering and helps maintain traction
while accelerating on loose or slippery
road surfaces.

● VSA® comes on automatically every time

you turn on the power system.

● To partially disable or fully restore VSA®

function, press and hold the button until
you hear a beep.

Collision Mitigation
Braking System

TM



(CMBS

TM

) OFF Button

(P307)
● When a possible collision is likely

unavoidable, the CMBS

TM

 can help you to

reduce the vehicle speed and the severity
of the collision.

● To turn the CMBS

TM

 on or off, press and

hold the button until you hear a beep.

Tire Pressure Monitoring System (TPMS) with Tire
Fill Assist

(P294, 416)

● The TPMS monitors tire pressure.

● TPMS is turned on automatically every time you turn on the power system.

● TPMS fill assist provides audible and visual guidance during tire pressure adjustment.

Refueling

(P327)

a

Press the fuel fill door
release button.

b

After refueling, wait for
about five seconds
before removing the
filler nozzle.

Fuel recommendation: Unleaded premium gasoline with a pump octane

number 91 or higher

Fuel tank capacity: 19.4 US gal (73.3 ℓ)

Wait for five seconds

17 ACURA MDX E-AWD-31TRX6000.book  23 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

24

Quick

 Referenc

e Guide

AcuraWatch

TM

AcuraWatch

TM

 is a driver support system

which employs the use of two distinctly
different kinds of sensors, a radar sensor
located in the front grille and a front sensor
camera mounted to the interior side of the
windshield, behind the rear view mirror.

The camera is located
behind the rearview
mirror.

Front Sensor
Camera

Radar Sensor

The radar sensor is in
the front grille.

Adaptive Cruise Control
(ACC) with Low Speed
Follow (LSF)

(P259)

Helps maintain a constant vehicle speed and
a set following interval behind a vehicle
detected ahead of yours and, if the detected
vehicle comes to a stop, can decelerate and
stop your vehicle, without you having to
keep your foot on the brake or the
accelerator.

Road Departure
Mitigation (RDM) System

(P274)

Alerts and helps to assist you when the
system detects a possibility of your vehicle
unintentionally crossing over detected lane
markings.

Lane Keeping Assist
System (LKAS)

(P279)

Provides steering input to help keep the
vehicle in the middle of a detected lane and
provides tactile and visual alerts if the
vehicle is detected drifting out of its lane.

Collision Mitigation
Braking System

TM



(CMBS

TM

)

(P307)

Can assist you when there is a possibility of
your vehicle colliding with a vehicle or a
pedestrian detected in front of yours. The
CMBS

TM

 is designed to alert you when a

potential collision is determined, as well as
to reduce your vehicle speed to help
minimize collision severity when a collision is
deemed unavoidable.

17 ACURA MDX E-AWD-31TRX6000.book  24 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

25

Quick

 Referenc

e Guide

Maintenance

(P331)

Under the Hood

(P339)

● Check engine oil, engine coolant, windshield washer fluid

and inverter coolant. Add when necessary.

● Check brake fluid.

● Check the 12-volt battery condition monthly.

a

Pull the hood release handle under the corner of the
dashboard.

b

Locate the hood latch lever, pull it up, and then raise the
hood. Once you have raised the hood slightly, you can
release the lever.

c

When finished, close the hood and make sure it is firmly
locked in place.

Lights

(P352)

● Inspect all lights regularly.

Wiper Blades

(P357)

● Replace blades if they leave streaks

across the windshield.

Tires

(P361)

● Inspect tires and wheels regularly.

● Check tire pressures regularly.

● Install snow tires for winter

driving.

17 ACURA MDX E-AWD-31TRX6000.book  25 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

26

Quick

 Referenc

e Guide

Handling the Unexpected

(P383)

Flat Tire

(P385)

● Park in a safe location and repair the flat

tire using the tire repair kit.

● Park in a safe location and replace the

flat tire with the compact spare tire
located under the cargo area.

Indicators Come On

(P412)

● Identify the indicator and consult the

owner’s manual.

Vehicles with tire repair kit

Vehicles with compact spare tire

Power System Won’t
Start

(P404)

● If the battery is dead, jump start using a

booster battery.

Blown Fuse

(P418)

● Check for a blown fuse if an electrical

device does not operate.

Overheating

(P409)

● Park in a safe location. If you do not see

steam under the hood, open the hood,
and let the engine cool down.

Emergency Towing

(P427)

● Call a professional towing service if you

need to tow your vehicle.

17 ACURA MDX E-AWD-31TRX6000.book  26 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

27

Quick

 Referenc

e Guide

What to Do If

Why do I hear an operating
noise when applying the
brakes?

This can occur when the ABS activates, and does not indicate a
problem. Apply firm, steady pressure on the brake pedal. Never
pump the brake pedal.

2 Anti-lock Brake System (ABS) (P305)

The rear door cannot be
opened from inside the
vehicle. Why?

Check if the childproof lock is in the
lock position. If so, open the rear
door with the outside door handle.
To cancel this function, slide the
lever upwards to the unlock
position.

17 ACURA MDX E-AWD-31TRX6000.book  27 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

28

Quick

 Referenc

e Guide

Why do the doors lock
after I unlocked the doors?

If you do not open the doors within 30 seconds, the doors are
relocked automatically for security.

Why does the beeper
sound when I open the
driver’s door?

The beeper sounds when:

●

The power mode is in ACCESSORY.

●

The exterior lights are left on.

Why does the beeper
sound when I start driving?

The beeper sounds when the driver and/or front passenger are
not wearing their seat belts.

Pulling the electric parking
brake switch does not
release the parking brake.
Why?

Pull the electric parking brake switch with the brake pedal
depressed.

I’m seeing an amber
indicator of a tire with an
exclamation point. What is
that?

The Tire Pressure Monitoring System (TPMS) needs attention.
Check tire pressure.

2 If the Low Tire Pressure/TPMS Indicator Comes On or Blinks (P416)

17 ACURA MDX E-AWD-31TRX6000.book  28 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

29

Quick

 Referenc

e Guide

Depressing the accelerator
pedal does not release the
parking brake
automatically. Why?

●

Fasten the driver’s seat belt.

●

Check if the transmission is in

(

P

 or

(

N

. If so, select any other

position.

Why does the gear position
automatically change to

(

P



when I open the driver’s
door to check for parking
space lines when
reversing?

●

Fasten the driver’s seat belt.

●

Close the driver’s door and manually change the gear
position.

u

When opening the driver’s door



(P250)

Why do I hear a screeching
sound when I apply the
brake pedal?

The brake pads may need to be replaced. Have your vehicle
inspected by a dealer.

Unleaded gasoline with a
Pump Octane Number
(PON) of 91 or higher is
recommended.
Is it possible to use
unleaded gasoline with a
Pump Octane Number
(PON) of 87 or lower on
this vehicle?

Unleaded gasoline with a Pump Octane Number (PON) of 91 or
higher is recommended.
Use of lower octane gasoline can cause occasional metallic
knocking noise in the engine and will result in decreased engine
performance.
Use of gasoline with a pump octane less than 87 can lead to
engine damage.

17 ACURA MDX E-AWD-31TRX6000.book  29 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

32

Safe Driving

For Safe Driving

The following pages explain your vehicle’s safety features and how to use them
properly. The safety precautions below are ones that we consider to be among the
most important.

Important Safety Precautions

■

Always wear your seat belt

A seat belt is your best protection in all types of collisions. Airbags are designed to
supplement seat belts, not replace them. So even though your vehicle is equipped
with airbags, make sure you and your passengers always wear your seat belts, and
wear them properly.

■

Restrain all children

Children ages 12 and under should ride properly restrained in a back seat, not the
front seat. Infants and small children should be restrained in a child seat. Larger
children should use a booster seat and a lap/shoulder seat belt until they can use the
belt properly without a booster seat.

■

Be aware of airbag hazards

While airbags can save lives, they can cause serious or fatal injuries to occupants
who sit too close to them, or are not properly restrained. Infants, young children,
and short adults are at the greatest risk. Be sure to follow all instructions and
warnings in this manual.

■

Don’t drink and drive

Alcohol and driving don’t mix. Even one drink can reduce your ability to respond to
changing conditions, and your reaction time gets worse with every additional drink.
So don’t drink and drive, and don’t let your friends drink and drive, either.

1

Important Safety Precautions

Some states, provinces and territories prohibit the use
of cell phones other than hands-free devices by the
driver while driving.

17 ACURA MDX E-AWD-31TRX6000.book  32 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

33

uu

For Safe Driving

u

Important Safety Precautions

Safe Driving

■

Pay appropriate attention to the task of driving safely

Engaging in cell phone conversation or other activities that keep you from paying
close attention to the road, other vehicles, and pedestrians could lead to a crash.
Remember, situations can change quickly, and only you can decide when it is safe to
divert some attention away from driving.

■

Control your speed

Excessive speed is a major factor in crash injuries and deaths. Generally, the higher
the speed, the greater the risk, but serious injuries can also occur at lower speeds.
Never drive faster than is safe for current conditions, regardless of the maximum
speed posted.

■

Keep your vehicle in safe condition

Having a tire blowout or a mechanical failure can be extremely hazardous.
To reduce the possibility of such problems, check your tire pressures and condition
frequently, and perform all regularly scheduled maintenance.

17 ACURA MDX E-AWD-31TRX6000.book  33 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

34

uu

For Safe Driving

u

Important Handling Information

Safe Driving

Important Handling Information

Your vehicle has higher ground clearance than a passenger vehicle designed for use
only on pavement. Higher ground clearance has many advantages for off-highway
driving. It allows you to travel over bumps, obstacles, and rough terrain. It also
provides good visibility so you can anticipate problems earlier.

These advantages come at some cost. Because your vehicle is taller and rides higher
off the ground, it has a higher center gravity making it more susceptible to tripping
or roll over if you make abrupt turns. Utility vehicles have a significantly higher
rollover rate than other types of vehicles. In a rollover crash, an unbelted person is
significantly more likely to die than a person wearing a seat belt. As a reminder,
make sure you and your passengers always wear seat belts.

1

Important Handling Information

For information on how to reduce the risk of rollover,
read:

2 Driving Guidelines for Your Utility Vehicle

P. 245

2 Off-Highway Driving Guidelines P. 237

Failure to operate your vehicle correctly might result
in a crash or a rollover.

17 ACURA MDX E-AWD-31TRX6000.book  34 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

35

uu

For Safe Driving

u

Your Vehicle’s Safety Features

Safe Driving

Your Vehicle’s Safety Features

The following checklist will help you take an active role in protecting yourself and
your passengers.

1

Your Vehicle’s Safety Features

Your vehicle is equipped with many features that
work together to help protect you and your
passengers during a crash.

Some features do not require any action on your part.
These include a strong steel framework that forms a
safety cage around the passenger compartment,
front and rear crush zones, a collapsible steering
column, and tensioners that tighten the front seat
belts in a sufficient crash.

However, you and your passengers cannot take full
advantage of these features unless you remain seated
in the correct position and always wear your seat
belts. In fact, some safety features can contribute to
injuries if they are not used properly.

6

7

8

9

10

12

Safety Cage
Crush Zones
Seats and Seat-Backs
Head Restraints
Collapsible Steering Column
Seat Belts
Front Airbags

Side Curtain Airbags
Door Locks

Side Airbags

11

Seat Belt Tensioners

6

7

8

9

9

10

11

11

12

7

Knee Airbag

10

17 ACURA MDX E-AWD-31TRX6000.book  35 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

36

uu

For Safe Driving

u

Safety Checklist

Safe Driving

Safety Checklist

For the safety of you and your passengers, make a habit of checking these items
each time before you drive.
• After everyone has entered the vehicle, be sure all doors and the tailgate are

closed and locked. Locking the doors and the tailgate helps prevent an occupant
from being ejected and an outsider from unexpectedly opening a door or the
tailgate.

2 Locking/Unlocking the Doors from the Inside P. 147

• Adjust your seat to a position suitable for driving. Be sure the front seats are

adjusted as far to the rear as possible while allowing the driver to control the
vehicle. Sitting too close to a front airbag can result in serious or fatal injury in a
crash.

2 Adjusting the Seats P. 187

• Adjust head restraints to the proper position. Head restraints are most effective

when the center of the head restraint aligns with the center of your head. Taller
persons should adjust their head restraint to the highest position.

2 Adjusting the Front and Second Row Outer Head Restraint Positions P. 193

• Always wear your seat belt, and make sure you wear it properly. Confirm that any

passengers are properly belted as well.

2 Fastening a Seat Belt P. 40

• Protect children by using seat belts or child seats according to a child’s age, height

and weight.

2 Child Safety P. 60

1

Safety Checklist

If the door and/or tailgate open message appears on
the multi-information display (MID), a door and/or
the tailgate is not completely closed. Close all doors
and the tailgate tightly until the message disappears.

2 Multi-Information Display (MID) Warning

and Information Messages P. 99

17 ACURA MDX E-AWD-31TRX6000.book  36 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

37

Continued

Safe Driving

Seat Belts

About Your Seat Belts

Seat belts are the single most effective safety device because they keep you
connected to the vehicle so that you can take advantage of many built-in safety
features. They also help keep you from being thrown against the inside of the
vehicle, against any passengers, or out of the vehicle. When worn properly, seat
belts also keep your body properly positioned in a crash so that you can take full
advantage of the additional protection provided by the airbags.

In addition, seat belts help protect you in almost every type of crash, including:
- frontal impacts
- side impacts
- rear impacts
- rollovers

■

Lap/shoulder seat belts

All six or seven seating positions are equipped with lap/shoulder seat belts with
emergency locking retractors. In normal driving the retractor lets you move freely
while keeping some tension on the belt. During a collision or sudden stop the
retractor locks to restrain your body.
The front passenger’s, second row and third row seat belts also have a lockable
retractor for use with child seats.

2 Installing a Child Seat with a Lap/Shoulder Seat Belt P. 68

1

About Your Seat Belts

Seat belts cannot completely protect you in every
crash. But in most cases, seat belts can reduce your
risk of serious injury.

Most states and all Canadian provinces and territories
require you to wear seat belts.

The emergency locking retractor may lock if you lean
forward too quickly. Slower movements will allow
the belt to extend fully without locking.

3

WARNING

Not wearing a seat belt properly increases
the chance of serious injury or death in a
crash, even though your vehicle has
airbags.

Be sure you and your passengers always
wear seat belts and wear them properly.

17 ACURA MDX E-AWD-31TRX6000.book  37 ページ  ２０１７年１月２０日　金曜日　午後２時５３分
