316











Reporting Safety Defects

14 ACURA TSX 5D-31TL76300.book  316 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

Inf
o

rmati

o

n

TOC

In the U.S.

If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform
the National Highway Traffic Safety Administration (NHTSA) in addition to notifying American Honda Motor Co., Inc.

If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it
may order a recall and remedy campaign. However, NHTSA cannot become involved in individual problems between you, your dealer,

or American Honda Motor Co., Inc.

To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at 1-888-327-4236 (TTY: 1-800-424-9153);

 go to http://www.safercar.gov

;

 or write to:  Administrator, NHTSA,

 1200 New Jersey Avenue, SE.,

Washington, DC 20590.

 You can also obtain othe r information about motor vehicle safety from  http://www.safercar.gov.

In Canada

If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform
Honda Canada Inc. and you may also inform Transport Canada.

If Transport Canada receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of
vehicles, it may lead to a recall and remedy campaign. However, Transport Canada cannot become involved in individual problems
between you, your dealer, or Honda Canada Inc.

To contact Transport Canada’s Defect Investigations and Recalls Division, you may call 1-800-333-0510. For more information on
reporting safety defects or about motor vehicle safety, go to http://www.tc.gc.ca/roadsafety

.

.

2014 TSX Sport Wagon

317

Continued









Emissions Testing

Testing of Readiness Codes

Your vehicle uses “readiness codes,” as part of its onboard self diagnostic system.
Some states refer to these codes during testing to see if your vehicle’s emissions
components are working properly.

The codes may not be read if you go through the testing just after the battery has
gone dead or been disconnected.

To check if they are set, turn the ignition switch to ON

 (

w , without starting the

engine. The malfunction indicator lamp will come on for several seconds. If it then
goes off, the readiness codes are set. If it blinks five times, the readiness codes are
not set.

If you are required to have your vehicle tested before the readiness codes are ready,
prepare the vehicle for retesting by doing the following:

1. Fill the gas tank to approximately 3/4 full.

2. Park the vehicle and leave the engine off for 6 hours or more.

3. Make sure the ambient temperature is between 40 °F and 95 °F (4 °C and 35 °C).

4. Start the engine without touching the accelerator pedal, and let it idle for

20 seconds.

5. Keep the vehicle in

 (

P . Increase the engine speed to 2,000 rpm, and hold it there

until the temperature gauge rises to at least 1/4 of the scale (about 3 minutes).

6. Let the engine idle with your foot off the accelerator for 20 seconds.

1

Testing of Readiness Codes

The readiness codes are erased when the battery is
disconnected, and set again only after several days of
driving under a variety of conditions.

If a testing facility determines that the readiness
codes are not set, you may be requested to return at
a later date to complete the test.

If the testing facility determines the readiness codes
are still not set, see a dealer.

14 ACURA TSX 5D-31TL76300.book  317 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

Inf
o

rmati

o

n

TOC

2014 TSX Sport Wagon

318

uu

Emissions Testing

u

Testing of Readiness Codes











7. Select a nearby, lightly traveled major highway where you can maintain a speed

of 50 to 60 mph (80 to 97 km/h) for at least 20 minutes. Drive on the highway in

 (

D . Do not use cruise control. When traffic allows, drive for 90 seconds without

moving the accelerator pedal. (Vehicle speed may vary slightly; this is okay.) If you
cannot do this for a continuous 90 seconds because of traffic conditions, drive for
at least 30 seconds, then repeat it two more times (for a total of 90 seconds).

8. Drive in city/suburban traffic for at least 10 minutes. When traffic conditions

allow, let the vehicle coast for several seconds without using the accelerator pedal
or the brake pedal.

9. Park the vehicle and leave the engine off for 30 minutes.

14 ACURA TSX 5D-31TL76300.book  318 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

Inf
o

rmati

o

n

TOC

2014 TSX Sport Wagon

319

Continued









Warranty Coverages

Your new vehicle is covered by these warranties:

New Vehicle Limited Warranty – covers your new vehicle, except for the
emissions control systems and accessories, against defects in materials and
workmanship.

Emissions Control Systems Defects Warranty and Emissions Performance
Warranty – these two warranties cover your vehicle’s emissions control systems.
Time, mileage, and coverage are conditional. Please read your warranty booklet for
exact information.

Seat Belt Limited Warranty – a seat belt that fails to function properly is covered
by a limited warranty. Please read your warranty booklet for details.

Rust Perforation Limited Warranty – all exterior body panels are covered for
rust-through from the inside for the specified time period with no mileage limit.

Accessory Limited Warranty – Acura accessories are covered under this warranty.
Time and mileage limits depend on the type of accessory and other factors. Please
read your warranty booklet for details.

Replacement Parts Limited Warranty – covers all Acura replacement parts
against defects in materials and workmanship.

14 ACURA TSX 5D-31TL76300.book  319 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

TOC

Inf
o

rmati

o

n

TOC

2014 TSX Sport Wagon

320

uu

Warranty Coverages

u











Replacement Battery Limited Warranty – provides prorated coverage for a
replacement battery purchased from a dealer.

Replacement Muffler Lifetime Limited Warranty – provides coverage for as
long as the purchaser of the muffler owns the vehicle.

Restrictions and exclusions apply to all these warranties. Please read the Acura
warranty information booklet that came with your vehicle for precise information on
warranty coverages. Your vehicle’s original tires are covered by their manufacturer.
Tire warranty information is in a separate booklet.

14 ACURA TSX 5D-31TL76300.book  320 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

Inf
o

rmati

o

n

TOC

2014 TSX Sport Wagon

321









Authorized Manuals

Manuals can be purchased from Helm Incorporated. You can order a manual by
phone at (800) 782-4356 (credit card orders only), or online at www.helminc.com.

14 ACURA TSX 5D-31TL76300.book  321 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

Inf
o

rmati

o

n

TOC

2014 TSX Sport Wagon

322











Client Service Information

Acura dealer personnel are trained professionals.

They should be able to answer all your questions. If you encounter a problem that
your dealership does not solve to your satisfaction, please discuss it with the
dealership’s service manager or general manager. If you are dissatisfied with the
decision made by the dealership’s management, contact Acura Client Relations.

U.S. Owners:

American Honda Motor Co., Inc.
Acura Client Relations
Mail Stop 500-2N-7E
1919 Torrance Blvd.
Torrance, CA 90501-2746
Tel: (800) 382-2238

In Puerto Rico and the U.S. Virgin Islands:

Bella International
P.O. Box 190816
San Juan, PR 00919-0816
Tel: (787) 620-7546

1

Client Service Information

When you call or write, please give us the following
information:

•

Vehicle Identification Number

2 Vehicle Identification Number (VIN)

P. 314

•

Date of purchase

•

Odometer reading of your vehicle

•

Your name, address, and telephone number

•

A detailed description of the problem

•

Name of the dealer who sold the vehicle to you

14 ACURA TSX 5D-31TL76300.book  322 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

Inf
o

rmati

o

n

TOC

2014 TSX Sport Wagon

Index

323

Index

ABS (Anti-lock Brake System)..................

218

Accessories and Modifications ................

225

Accessory Power Sockets .........................

135

Active Head Restraints.............................

125

Additives

Coolant ..................................................

242

Engine Oil ...............................................

237

Washer ...................................................

246

Additives, Engine Oil ...............................

237

Adjusting

Armrest ..................................................

127

Front Seats..............................................

119

Head Restraints.......................................

121

Headlights ..............................................

247

Mirrors....................................................

117

Rear Seats...............................................

126

Steering Wheel .......................................

116

Temperature .............................................

77

Air Conditioning System (Climate Control

System)....................................................

141

Changing the Mode................................

141

Defrosting the Windshield and



Windows ..............................................

142

Dust and Pollen Filter ..............................

271

Recirculation/Fresh Air Mode...................

141

Sensor ....................................................

144

Synchronized Mode ................................

143

Using Automatic Climate Control............

141

Air Pressure ......................................

260

,

313

Airbags ........................................................

34

Advanced Airbags .....................................

40

Airbag Care ...............................................

48

Event Data Recorder ..................................

19

Front Airbags (SRS) ....................................

37

Indicator........................................

45

,

67

,

70

Passenger Airbag Off Indicator ..................

46

Sensors......................................................

34

Side Airbag Cutoff System .........................

43

Side Airbag Off Indicator ...........................

47

Side Airbags ..............................................

41

Side Curtain Airbags ..................................

44

AM/FM Radio ............................................

152

Anti-lock Brake System (ABS) ..................

218

Indicator....................................................

66

Armrest .....................................................

127

Audio System ............................................

146

Adjusting the Sound................................

151

Auxiliary Input Jack ..................................

148

Error Messages ........................................

167

General Information ................................

169

MP3/WMA/AAC ......................................

162

Recommended CDs .................................

170

Recommended Devices ............................

172

Remote Controls .....................................

150

Security Code ..........................................

148

Theft Protection.......................................

148

USB Adapter Cable ..................................

147

USB Flash Drives ......................................

172

Authorized Manuals.................................

321

Auto Door Lock/Unlock..............................

93

Customize...........................................

80

,

82

Automatic Lighting ..................................

108

Automatic Transmission...........................

202

Creeping .................................................

202

Fluid........................................................

244

Kickdown................................................

202

Operating the Shift Lever...................

13

,

204

Sequential Shift Mode .............................

205

Shift Lever Does Not Move ......................

296

Shifting ...................................................

203

Auxiliary Input Jack..................................

148

Average Fuel Economy ..............................

77

Average Speed ...........................................

78

Battery ......................................................

268

Charging System Indicator.................

65

,

299

Jump Starting..........................................

294

Maintenance (Checking the Battery)........

268

Maintenance (Replacing) .........................

270

Belts (Seat) ..................................................

26

Beverage Holders .....................................

134

Bluetooth® Audio .....................................

165

Bluetooth® HandsFreeLink®.....................

175

Booster Seats (For Children) ......................

60

Brake System ............................................

216

Anti-lock Brake System (ABS)...................

218

Brake Assist System .................................

219

Fluid........................................................

245

14 ACURA TSX 5D-31TL76300.book  323 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

A     B     C     D     E     F     G     H     I     J     K     L     M     N     O     P     Q     R     S     T     U     V     W     X     Y     Z

A

B

2014 TSX Sport Wagon

324

Foot Brake ...............................................

217

Indicator ............................................

64

,

301

Parking Brake ..........................................

216

Brightness Control (Instrument Panel) ....

112

Bulb Replacement.....................................

247

Back-Up Lights.........................................

252

Brake Light, Taillight, Rear Turn Signal Light

and Rear Side Marker Lights...................

251

Fog Lights................................................

248

Front Turn Signal/Parking/Side Marker



Lights.....................................................

249

Headlights ...............................................

247

High-Mount Brake Light ..........................

251

License Plate ............................................

253

Side Turn Signal/Emergency Indicator



Lights.....................................................

250

Bulb Specifications....................................

312

Carbon Monoxide Gas................................

61

Cargo Hooks..............................................

137

Carrying Cargo..................................

191

,

193

CD Player ...................................................

156

Certification Label ....................................

314

Changing Bulbs.........................................

247

Charging System Indicator .................

65

,

299

Child Safety .................................................

49

Childproof Door Locks ...............................

93

Child Seat ....................................................

49

Booster Seats.............................................

60

Child Seat for Infants.................................

51

Child Seat for Small Children.....................

52

Installing a Child Seat with a Lap/Shoulder



Seat Belt..................................................

56

Larger Children .........................................

59

Rear-facing Child Seat ...............................

51

Selecting a Child Seat................................

53

Using a Tether...........................................

58

Childproof Door Locks ...............................

93

Cleaning the Exterior ...............................

274

Cleaning the Interior................................

272

Client Service Information .......................

322

Climate Control System............................

141

Changing the Mode ................................

141

Defrosting the Windshield and



Windows...............................................

142

Dust and Pollen Filter...............................

271

Recirculation and Fresh Air Mode ............

141

Sensors ...................................................

144

Synchronized Mode.................................

143

Using Automatic Climate Control ............

141

Clock............................................................

86

Coat Hook.................................................

136

Compact Spare Tire ..........................

287

,

313

Compass ....................................................

187

Console Compartment .............................

131

Controls.......................................................

85

Coolant (Engine) ......................................

242

Adding to the Radiator............................

243

Adding to the Reserve Tank.....................

242

Overheating ............................................

297

Temperature Gauge ..................................

74

Creeping (Automatic Transmission)........

202

Cruise Control ..........................................

207

Indicator ...................................................

71

Cup Holders..............................................

134

Customized Features .................................

79

Daytime Running Lights ..........................

109

Dead Battery ............................................

294

Defrosting the Windshield and 

Windows .................................................

142

Detachable Shelf ......................................

130

Devices that Emit Radio Waves ...............

315

Dimming

Headlights ..............................................

107

Rear View Mirror.....................................

117

Dipstick (Engine Oil) ................................

238

Directional Signals (Turn Signal) .............

107

Door Mirrors.............................................

117

Doors ..........................................................

87

Auto Door Lock ........................................

93

Auto Door Unlock .....................................

93

Door and Tailgate Open Indicator .......

25

,

68

Keys..........................................................

87

Locking/Unlocking the Doors from the



Inside ................................................

10

,

91

Locking/Unlocking the Doors from the



Outside ...................................................

89

Lockout Prevention System .......................

90

14 ACURA TSX 5D-31TL76300.book  324 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

Index

A     B     C     D     E     F     G     H     I     J     K     L     M     N     O     P     Q     R     S     T     U     V     W     X     Y     Z

C

D

2014 TSX Sport Wagon

325

Driving ......................................................

189

Automatic Transmission ..........................

202

Braking ...................................................

216

Cruise Control ........................................

207

Shifting Gear ..........................................

203

Starting the Engine .................................

199

Driving Position Memory System ............

114

Dust and Pollen Filter ..............................

271

Elapsed Time ..............................................

78

Electric Power Steering (EPS) System

Indicator ...........................................

68

,

301

Electronic Stability Control (ESC) ............

210

Emergency................................................

308

Emissions Testing (Readiness Codes) ......

317

Engine.......................................................

314

Coolant ..................................................

242

Jump Starting .........................................

294

Oil ..........................................................

237

Starting...................................................

199

Switch Buzzer .........................................

106

Engine Coolant ........................................

242

Adding to the Radiator ...........................

243

Adding to the Reserve Tank ....................

242

Overheating............................................

297

Temperature Gauge..................................

74

Engine Oil.................................................

237

Adding ...................................................

239

Checking ................................................

238

Displaying Oil Life ....................................

231

Low Oil Pressure Indicator..................

64

,

299

Recommended Engine Oil........................

237

EPS (Electric Power Steering) 

System ...............................................

68

,

301

Exhaust Gas Hazard (Carbon Monoxide) ..

61

Exterior Care (Cleaning) ...........................

274

Exterior Mirrors ........................................

117

Features.....................................................

145

Filters

Dust and Pollen .......................................

271

Oil ...........................................................

240

Flat Tire .............................................

278

,

287

Floor Mats .................................................

273

Fluids

Automatic Transmission...........................

244

Brake.......................................................

245

Engine Coolant........................................

242

Windshield Washer..................................

246

Fog Light Indicator .....................................

70

Folding Down the Rear Seats ..................

126

Foot Brake.................................................

217

Front Airbags (SRS) .....................................

37

Front Seats ................................................

119

Adjusting.................................................

119

Fuel ......................................................

14

,

221

Economy .................................................

224

Gauge .......................................................

74

Instant Fuel Economy ................................

77

Low Fuel Indicator .....................................

66

Range .......................................................

77

Recommendation ....................................

221

Refueling.................................................

221

Fuel Economy ...........................................

224

Fuel Fill Cap ........................................

14

,

223

Message..................................................

300

Fuel Fill Door ......................................

14

,

222

Unable to Unlock ....................................

309

Fuses..........................................................

303

Inspecting and Changing.........................

307

Locations.................................................

303

Gasoline (Fuel)

Economy .................................................

224

Gauge.......................................................

74

Information .............................................

221

Low Fuel Indicator .....................................

66

Refueling.................................................

221

Gauges ........................................................

74

Gear Shift Lever Positions

Automatic Transmission ..........................

203

Glass (care)................................................

275

Glove Box..................................................

130

Halogen Bulbs ..................................

247

,

248

14 ACURA TSX 5D-31TL76300.book  325 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

Index

A     B     C     D     E     F     G     H     I     J     K     L     M     N     O     P     Q     R     S     T     U     V     W     X     Y     Z

E

G

F

G

H

2014 TSX Sport Wagon

326

Handling the Unexpected ........................

277

HandsFreeLink® (HFL) ...............................

175

Help Features...........................................

176

HFL Buttons .............................................

175

HFL Status Display....................................

176

Making a Call ..........................................

181

Menus .....................................................

177

Muting a Call...........................................

182

Phone Setup ............................................

179

Phonebook ..............................................

183

Receiving a Call .......................................

182

Sending Numbers or Names During a



Call........................................................

182

Transferring a Call ...................................

182

Hazard Warning Button...............................

2

Head Restraints.........................................

121

Headlights .................................................

107

Aiming ....................................................

247

Automatic Operation ...............................

108

Dimming .........................................

107

,

109

Operating ................................................

107

Heated Door Mirrors ................................

113

Heaters (Seat)............................................

139

HFL (HandsFreeLink®) ...............................

175

High-Beam Indicator ..................................

69

HomeLink® Universal Transceiver ............

173

Identification Numbers ............................

314

Engine and Transmission..........................

314

Vehicle Identification ...............................

314

Ignition Switch .........................................

106

Illumination Control.................................

112

Knob.......................................................

112

Immobilizer System ..................................

100

Indicator....................................................

70

Indicators ....................................................

64

ABS (Anti-lock Brake System).....................

66

Charging System ...............................

65

,

299

Cruise Control...................................

71

,

208

Cruise Main.......................................

71

,

207

Door and Tailgate Open ......................

25

,

68

EPS (Electric Power Steering) System ..

68

,

301

Fog Light...................................................

70

High-Beam ................................................

69

Immobilizer System ...................................

70

Lights On ..................................................

69

Low Fuel ...................................................

66

Low Oil Pressure................................

64

,

299

Low Tire Pressure/TPMS.............

68

,

212

,

214

Maintenance Minder

TM

............................

231

Malfunction Indicator Lamp...............

65

,

300

Parking Brake and Brake System........

64

,

301

Seat Belt Reminder ..............................

27

,

66

Security System Alarm ...............................

71

Side Airbag Off ...................................

47

,

70

Supplemental Restraint System............

45

,

67

System Message........................................

69

Transmission .............................................

65

Turn Signal................................................

69

VSA® (Vehicle Stability Assist) 

System ............................................

67

,

210

VSA® OFF..........................................

67

,

211

Information ..............................................

311

Information Buttons ..................................

75

Instant Fuel Economy ................................

77

Instrument Panel........................................

63

Brightness Control ..................................

112

Interior Lights...........................................

128

Interior Rearview Mirror .........................

117

Jack (Wheel Nut Wrench) ........................

290

Jump Starting ...........................................

294

Key Number Tag ........................................

88

Keyless Lockout Prevention.......................

90

Keys.............................................................

87

Lockout Prevention ...................................

90

Number Tag..............................................

88

Rear Door Won’t Open .............................

93

Remote Transmitter ..................................

89

Retractable Master Keys ............................

87

Types and Functions..................................

87

Valet Key ..................................................

88

Won’t Turn ...............................................

17

Kickdown (Automatic Transmission) ......

202

14 ACURA TSX 5D-31TL76300.book  326 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

Index

A     B     C     D     E     F     G     H     I     J     K     L     M     N     O     P     Q     R     S     T     U     V     W     X     Y     Z

I

K

J

2014 TSX Sport Wagon

327

LATCH (Child Seats) ...................................

54

Lights ................................................

107

,

247

Automatic...............................................

108

Bulb Replacement ...................................

247

Daytime Running Lights ..........................

109

Fog Lights ...............................................

109

High-Beam Indicator .................................

69

Interior....................................................

128

Light Switches.........................................

107

Lights On Indicator....................................

69

Turn Signals ............................................

107

Load Limits ...............................................

193

Locking/Unlocking .....................................

87

Auto Door Lock/Unlock.............................

93

Childproof Door Locks ..............................

93

From Inside ...............................................

91

From Outside ............................................

89

Keys..........................................................

87

Lockout Prevention System .......................

90

Using a Key...............................................

90

Lockout Prevention System .......................

90

Low Battery Charge .................................

299

Low Fuel Indicator .....................................

66

Low Oil Pressure Indicator.................

64

,

299

Lower Anchors ...........................................

54

Lubricant Specifications Chart ................

313

Luggage (Maximum Load Limit) .............

193

Maintenance .............................................

227

Battery ....................................................

268

Brake Fluid ..............................................

245

Cleaning..................................................

272

Climate Control .......................................

271

Coolant ...................................................

242

Maintenance Minder

TM

............................

231

Oil ...........................................................

238

Precautions..............................................

228

Radiator ..................................................

243

Remote Transmitter .................................

270

Replacing Light Bulbs...............................

247

Safety ......................................................

229

Service Items ...........................................

233

Tires ........................................................

259

Transmission Fluid ...................................

244

Under the Hood ......................................

235

Malfunction Indicator Lamp ..............

65

,

300

Map Lights ................................................

128

Maximum Load Limit ...............................

193

Meters, Gauges...........................................

74

Mirrors.......................................................

117

Adjusting.................................................

117

Automatic Dimming ................................

117

Door........................................................

117

Exterior....................................................

117

Interior Rearview .....................................

117

Modifications (and Accessories) ..............

225

Moonroof..................................................

105

MP3 ...................................................

156

,

162

Multi-Information Display .........................

75

Numbers (Identification)..........................

314

Odometer ...................................................

76

Oil (Engine)...............................................

237

Adding....................................................

239

Checking.................................................

238

Displaying Oil Life....................................

231

Low Oil Pressure Indicator .................

64

,

299

Recommended Engine Oil .......................

237

Viscosity ..................................................

237

Opening/Closing

Hood.......................................................

236

Moonroof ...............................................

105

Power Windows ......................................

102

Tailgate .....................................................

94

Outside Temperature Display....................

77

Overheating..............................................

297

Paddle Shifters (Sequential Shift 

Mode)................................................

13

,

205

Panic Mode ...............................................

101

Parking......................................................

220

Parking Brake ...........................................

216

14 ACURA TSX 5D-31TL76300.book  327 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

Index

A     B     C     D     E     F     G     H     I     J     K     L     M     N     O     P     Q     R     S     T     U     V     W     X     Y     Z

L

M

N

O

P   Q

2014 TSX Sport Wagon

328

Parking Brake and Brake System 

Indicator ............................................

64

,

301

Passenger Airbag Off Indicator .................

46

Passing Indicators .....................................

107

Power Windows........................................

102

Precautions While Driving........................

201

Rain.........................................................

201

Pregnant Women .......................................

32

Puncture (Tire) ..................................

278

,

287

Radiator.....................................................

243

Radio (AM/FM)..........................................

152

Radio Data System (RDS)..........................

153

Range ..........................................................

77

RDS (Radio Data System)..........................

153

Readiness Codes (Emissions Testing) .......

317

Rear Defogger/Heated Door Mirror 

Button......................................................

113

Rear Seats (Folding Down).......................

126

Rearview Mirror (Automatic Dimming) ..

117

Refueling...................................................

221

Fuel Gauge ............................................

8

,

74

Gasoline ..........................................

221

,

312

Low Fuel Indicator .....................................

66

Regulations ...............................

214

,

262

,

315

Remote Transmitter....................................

89

Replacement

Battery.....................................................

270

Bulbs .......................................................

247

Fuses.......................................................

303

Tires ........................................................

265

Wiper Blade Rubber ................................

255

Reporting Safety Defects .........................

316

Resetting a Trip Meter ...............................

76

Retractable Master Keys ............................

87

Reverse Tilt Mirror....................................

118

Safe Driving ................................................

21

Safety Check ...............................................

25

Safety Labels...............................................

62

Safety Message...........................................

20

Seat Belts ....................................................

26

Adjusting the Shoulder Anchor..................

30

Automatic Seat Belt Tensioners .................

28

Checking...................................................

33

Detachable Anchor....................................

31

Fastening ..................................................

29

Installing a Child Seat with a Lap/Shoulder



Seat Belt..................................................

56

Pregnant Women ......................................

32

Reminder ..................................................

27

Warning Indicator ...............................

27

,

66

Seat Heaters..............................................

139

Seats ..........................................................

119

Adjusting ................................................

119

Driver’s Seat Lumbar Support ..................

123

Front Seats ..............................................

119

Rear Seats ...............................................

126

Seat Heaters ...........................................

139

Security System ........................................

100

Immobilizer System Indicator.....................

70

Security System Alarm Indicator ................

71

SEL/RESET Knob..........................................

75

Select Lever ........................................

13

,

203

Operation .........................................

13

,

204

Releasing ................................................

296

Won’t Move ...........................................

296

Selecting a Child Seat ................................

53

Selector Knob (Audio) .............................

149

Sequential Shift Mode.............................

205

Setting the Clock........................................

86

Shift Lever ..........................................

13

,

203

Shift Position Indicator ............................

204

Shifting (Transmission) ............................

203

Shoulder Anchor ........................................

30

Side Airbags ...............................................

41

Cutoff System ...........................................

43

Off Indicator .............................................

43

Side Curtain Airbags ..................................

44

Side Storage Compartment.....................

133

Snow Tires ................................................

267

Spare Tire .........................................

287

,

313

Spark Plugs ...............................................

312

Specifications ...........................................

312

Specified Fuel ...................................

221

,

312

Speedometer ..............................................

74

SRS Airbags (Airbags) ................................

37

Starting the Engine..................................

199

Does Not Start ........................................

293

14 ACURA TSX 5D-31TL76300.book  328 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

Index

A     B     C     D     E     F     G     H     I     J     K     L     M     N     O     P     Q     R     S     T     U     V     W     X     Y     Z

R

S

2014 TSX Sport Wagon

329

Engine Switch Buzzer..............................

106

Jump Starting .........................................

294

Steering Wheel ........................................

116

Adjusting ................................................

116

Stopping ...................................................

220

Sunglasses Holder ....................................

138

Supplemental Restraint System (SRS) .......

37

Switches (Around the Steering 

Wheel) ............................................

2

,

3

,

106

SYNC Mode ..............................................

143

System Message Indicator .........................

69

Tachometer ................................................

74

Tailgate.......................................................

94

Unable to Open ......................................

310

Temperature ..............................................

77

Gauge ........................................................

8

Outside Temperature Display ....................

77

Temperature Sensor ................................

144

Tie-down Anchors ....................................

137

Time (Setting).............................................

86

Tire Pressure Monitoring System 

(TPMS).....................................................

212

Indicator ...........................................

68

,

302

Tire Repair Kit ..........................................

278

Tires ..........................................................

259

Air Pressure.....................................

260

,

313

Checking and Maintaining ......................

259

Inspection ...............................................

259

Labeling ..................................................

260

Puncture (Flat Tire)...........................

278

,

287

Regulations .............................................

262

Rotation ..................................................

266

Spare Tire ........................................

287

,

313

Tire Chains ..............................................

267

Tire Repair Kit ..........................................

278

Wear Indicators .......................................

264

Winter.....................................................

267

Tonneau Cover .........................................

140

Tools ..........................................................

278

Towing a Trailer .......................................

195

Equipment and Accessories .....................

196

Load Limits ..............................................

195

Towing Your Vehicle ................................

198

Emergency ..............................................

308

TPMS (Tire Pressure Monitoring 

System) ....................................................

212

Indicator............................................

68

,

302

Transmission .............................................

203

Automatic ...............................................

203

Fluid ........................................................

244

Number...................................................

314

Sequential Shift Mode .............................

205

Shift Position Indicator .............................

204

Trip Meter ...................................................

76

Trip/Reset Switch ........................................

76

Troubleshooting .......................................

277

Blown Fuse..............................................

303

Brake Pedal Vibrates ..................................

17

Buzzer Sounds When Opening Door..........

18

Emergency Towing..................................

308

Engine Won’t Start..................................

293

Noise When Braking..................................

18

Overheating ............................................

297

Premium Gasoline ...........................

221

,

312

Puncture/Flat Tire ............................

278

,

287

Rear Door Won’t Open........................

17

,

93

Select Lever Won’t Move.........................

296

Warning Indicators ....................................

64

Turn Signals ..............................................

107

Indicators (Instrument Panel) .....................

69

Under-floor Storage Area........................

132

Unlocking the Doors ..................................

89

Unlocking the Front Doors from the 

Inside .........................................................

10

USB Adapter Cable...........................

146

,

147

USB Flash Drives .......................................

172

Valet Key.....................................................

88

Vanity Mirrors...............................................

5

Vehicle Identification Number ................

314

Vehicle Stability Assist (VSA®)..................

210

Off Button...............................................

211

Off Indicator..............................................

67

System Indicator........................................

67

Ventilation ..............................................

141

14 ACURA TSX 5D-31TL76300.book  329 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

Index

A     B     C     D     E     F     G     H     I     J     K     L     M     N     O     P     Q     R     S     T     U     V     W     X     Y     Z

T

U

V

2014 TSX Sport Wagon

330

Viscosity (Oil).....................................

237

,

313

VSA® (Vehicle Stability Assist) ..................

210

Warning and Information Messages .........

72

Warning Indicator On/Blinking................

299

Warning Labels ...........................................

62

Warranties (Warranty Manual provided

separately)...............................................

319

Watts .........................................................

312

Wear Indicators (Tire)...............................

264

Window Washers......................................

110

Adding/Refilling Fluid...............................

246

Switch .....................................................

110

Windows (Opening and Closing).............

102

Windshield ................................................

110

Cleaning..................................................

275

Defrosting/Defogging ..............................

142

Washer Fluid............................................

246

Wiper Blades ...........................................

255

Wipers and Washers ................................

110

Winter Tires...............................................

267

Snow Tires...............................................

267

Tire Chains ..............................................

267

Wipers and Washers .................................

110

Checking and Replacing Wiper Blades .....

255

WMA .................................................

156

,

162

Worn Tires.................................................

259

XM® Radio ................................................

154

14 ACURA TSX 5D-31TL76300.book  330 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

Index

A     B     C     D     E     F     G     H     I     J     K     L     M     N     O     P     Q     R     S     T     U     V     W     X     Y     Z

W

X   Y   Z

2014 TSX Sport Wagon
