22-148
22-148
Power Windows
Resetting the Power Window
Control Unit
Passenger’s Window Motor Test
A
UP
DOWN
Terminal
Direction
1
2
Resetting the power window control unit is required
after performing the following procedures:
• Disconnecting the battery
• Removing the No. 6 (7.5 A) and/or the No. 23 (20 A)
fuses in the under-dash fuse/relay box
• Disconnecting the driver’s door wire harness
• Disconnecting the power window control unit
1. Turn the ignition switch ON (II).
2. Move the driver’s window all the way down
holding the driver’s switch in the AUTO DOWN
position; when the window reaches the bottom,
hold the driver’s window switch in the AUTO
DOWN position for 2 seconds.
3. Move the driver’s window all the way up holding
the driver’s switch in the AUTO UP position; when
the window reaches the top, hold the driver’s
window switch in the UP position for 2 seconds.
4. If the window does not work in AUTO, repeat steps
1 through 3.
1. Remove the passenger’s door panel (see page
20-5).
2. Disconnect the 2P connector (A) from the
passenger’s power window motor.
3. Test the motor in each direction by connecting
battery power and ground according to the table.
To prevent damage to the motor, disconnect
one lead as soon as the motor stops running.
4. If the motor does not run or fails to run smoothly,
replace it.
Terminal side of
male terminals
