01 02 03 S6M6AZHJ18513415017KBAT00 Special Tools Required Speed nut removal ’05-06 Models 20-93 Front Bumper Lower Grille Replacement 6 x 1.0 mm 6 x 1.0 mm C B D A B Fastener Locations : Bolt, 1 A : Bolt, 2 B Fastener Locations : Screw, 4 B : Speed nut, 3 C A D B C C C B B B E KTC trim tool set SOJATP2014 NOTE: • Put on gloves to protect your hands. avoid damage when prying components. • Take care not to scratch the front bumper. 1. Remove the front bumper (see page 20-91). 2. Remove the license plate. 3. Remove the bolts (A, B), then remove the license plate base (C) from the front bumper (D). 4. From the back of the front bumper (A), remove the screws (B), and release the speed nuts (C) securing (cont’d) 05/06/27 18:24:29 61S6M040_200_0094 |
