14-309
A
C
B
6 x 1.0 mm
12 N·m (1.2 kgf·m, 8.7 lbf·ft)
6 x 1.0 mm
12 N·m
(1.2 kgf·m, 8.7 lbf·ft)
A
8. Install the transmission range switch (A) gently on
the selector control shaft (B) with holding the N
position with the 2.0 mm (0.08 in.) blade (C).
9. Tighten the bolts on the transmission range switch
while you continue to hold the N position. Do not
move the transmission range switch when
tightening the bolts. Remove the feeler gauge.
10. Connect the connector securely, then install the
transmission range switch cover (A).
11. Turn the ignition switch ON (II). Move the shift lever
through all gear positions, and check the
transmission range switch synchronization with the
A/T gear position indicator.
12. Check that the engine can start in P and N positions,
and cannot start in any other shift lever position.
13. Check that the back-up lights come on when the
shift lever is in the R position.
14. Allow the wheels to rotate freely, then start the
engine, and check the shift lever operation.
