2002-2004 Models
DTC
D
Indicator
MIL
Detection Item
Page
(1)
14-13
DTC Troubleshooting Index
NOTE: Record all freeze data and review General Troubleshooting Information (see page 14-3) before you
troubleshoot.
P0710 (28)
Blinks
OFF
ATF temperature sensor
(see page 14-88)
P0715 (15)
Blinks
ON
Input shaft (mainshaft) speed sensor
(see page 14-90)
P0720 (9)
Blinks
ON
Output shaft (countershaft) speed sensor
(see page 14-94)
P0730 (41)
OFF
ON
Shift control system
(see page 14-98)
P0740 (40)
OFF
ON
Lock-up control system
(see page 14-99)
P0745 (76)
Blinks
ON
Mechanical problem in hydraulic system
(see page 14-100)
P0748 (16)
Blinks
ON
A/T clutch pressure control solenoid valve A
(see page 14-101)
P0750 (70)
Blinks
ON
Mechanical problem in hydraulic system
(see page 14-103)
P0753 (7)
Blinks
ON
Shift solenoid valve A
(see page 14-105)
P0758 (8)
Blinks
ON
Shift solenoid valve B
(see page 14-107)
P0763 (22)
Blinks
ON
Shift solenoid valve C
(see page 14-109)
P0768 (60)
Blinks
ON
Shift solenoid valve D
(see page 14-111)
P0773 (61)
Blinks
ON
Shift solenoid valve E
(see page 14-113)
P0775 (77)
Blinks
ON
Mechanical problem in hydraulic system
(see page 14-115)
P0778 (23)
Blinks
ON
A/T clutch pressure control solenoid valve B
(see page 14-116)
P0780 (45)
Blinks
ON
Mechanical problem in hydraulic system
(see page 14-118)
P0795 (78)
Blinks
ON
Mechanical problem in hydraulic system
(see page 14-120)
P0798 (29)
Blinks
ON
A/T clutch pressure control solenoid valve C
(see page 14-122)
P0840 (25)
Blinks
OFF
2nd clutch transmission fluid pressure switch
(see page 14-124)
P0845 (26)
Blinks
OFF
3rd clutch transmission fluid pressure switch
(see page 14-126)
P1705 (5)
Blinks
ON
Transmission range switch (short circuit)
(see page 14-128)
P1706 (6)
OFF
ON
Transmission range switch (open)
(see page 14-132)
P1709 (24)
Blinks
ON
Transmission gear selection switch
(see page 14-134)
P1717 (62)
Blinks
OFF
Transmission range switch (R position circuit)
(see page 14-137)
(1): The DTC in parentheses is the flash code the D indicator indicates when the date link connector is connected to
the HDS, and in the SCS mode.
(2): This code is caused by an electrical circuit problem and cannot be caused by a mechanical problem in the
transmission.
(2)
(2)
(2)
(2)
(2)
(2)
(2)
(2)
(2)
(2)
(2)
(2)
(2)
(2)
