*01 01 *02 *03 S6M6A01E34116317031KBAT00 − − − − 12-7 Clutch Master Cylinder Replacement C B A C B D A C B A C A UP 1 3 mm (0.04 0.12 in.) 1 3 mm (0.04 0.12 in.) LEFT B NOTE: • Use fender covers to a void damaging painted surfaces. • Do not spill brake fluid on the vehicle; it may damage the paint; if brake fluid does contact the paint, wash it 1. Remove the brake fluid from the clutch master cylinder reservoir with a syringe. 2. Pry out the lock pin (A), and pull the pedal pin (B) out of the yoke. Remove the master cylinder 3. Remove the clutch master cylinder (A), and pull it toward the middle of the engine compartment. 4. Disconnect reservoir hose (D) from the clutch master cylinder reservoir. Plug the end of the 5. Remove the clutch master cylinder (A). 6. Remove the O-ring (B) and the clutch master cylinder seal (C) from the master cylinder. 7. Install the clutch master cylinder in the reverse order of removal. Install a new O-ring and new lock NOTE: When attaching the reservoir hose to the (cont’d) 05/06/27 18:07:56 61S6M040_120_0009 |
