DTC 3-3
CAUTION: Whenever the ignition switch is ON (II), or
has been turned OFF for less than 3 minutes, be careful
not to bump the SRS unit or the side impact sensor; the
airbags could accidentally deploy and cause damage or
injuries.
Try to reproduce the SRS indicator light:
1. Erase the DTC memory (see page
).
2. Turn the ignition switch ON (II), and check that the SRS
indicator light comes on for about 6 seconds, and then
goes off.
Check for a short to another wire in the SRS floor harness:
1. Disconnect the negative battery cable, and wait for 3
minutes.
2. Disconnect the driver's and front passenger's side airbag
connectors, then disconnect the front passenger's airbag
connector (see page
).
3. Disconnect the SRS floor harness 18P connector from
).
4. Disconnect the special tool from the SRS floor har-
).
5. Check resistance between the No. 4 and No. 5 terminals
of the SRS floor harness 18P connector. There should be
1 or more.
Intermittent failure, system is OK at this time. See
Troubleshooting Intermittent Failures on page
Check for a short to another wire in the driver's seat belt
tensioner:
1. Disconnect the negative battery cable, and wait for 3
minutes.
2. Disconnect the left side wire harness 2P connector from the
driver's seat belt tensioner 2P connector (see page
).
3. Connect the special tool to the left side wire harness
).
4. Reconnect the negative battery cable.
5. Erase the DTC memory (see page
).
).
Short to another wire in the driver's seat belt tensioner;
replace the driver's seat belt (see page
).
Faulty SRS unit; replace the SRS unit (see page
).
Check for a short to another wire in the left side wire har-
ness:
1. Disconnect the negative battery cable, and wait for 3
minutes.
2. Disconnect the SRS floor harness 2P connector from the left
side wire harness 2P connector (see page
).
3. Connect the special tool to the SRS floor harness 2P
connector (see page
).
4. Reconnect the negative battery cable.
5. Erase the DTC memory (see page
).
6. Read the DTC (see page
).
