*: You can also test the switch by using the self-diagnosis function (mode 2). (See page
.)
UNDER-DASH
FUSE/RELAY BOX
TURN SIGNAL/HAZARD RELAY
COMBINATION LIGHT SWITCH*
Test, page
DASH LIGHTS BRIGHTNESS
CONTROLLER*
Controller Test,
page
Lighting System
Component Location Index
Automatic Lighting System: When the combination light switch is in the "AUTO" position, the automatic lighting control
unit turns on the headlights, all other exterior lights, and the instrument panel lights when the ambient light is low. The
control unit receives signals from the automatic lighting sensor, which senses the lux (illumination) level outside the vehi-
cle, and it controls the lights by means of the lighting relay and taillight relay.
NOTE: The exterior lights (other than the headlights) circuit is included with the fog lights circuit. While in the "AUTO"
mode, when the exterior lights are turned off, the fog lights are turned off automatically.
While in the "AUTO" mode, the light will remain on when the ignition switch is turned off.
They will turn off automatically when the driver's door is opened.
• FOG LIGHT SWITCH
HIGH BEAM INDICATOR LIGHT
Bulb Locations, page
TURN SIGNAL INDICATOR LIGHT
DRL INDICATOR LIGHT (Canada)
Bulb Locations, page
HAZARD WARNING SWITCH
