Acura RL (1996-2004 year). Manual - part 158

2004 American Honda Motor Co., Inc.

167. Right Side of Engine Comp. (Left Sim.) (’99-’04)

HEADLIGHT
CONNECTOR B
(HIGH BEAM)
(3-BLK)

HEADLIGHT
CONNECTOR A
(LOW BEAM)
(2-GRY)

2004 American Honda Motor Co., Inc.

168. Behind Left Kick Panel (Fuse Box Rem.) (’99-’04)

SECURITY
DIODE

2004 American Honda Motor Co., Inc.

169. Behind Left Kick Panel (Back of Fuse Box) (’99-’04)

HEADLIGHT
DIODE
(BEHIND)

2004 American Honda Motor Co., Inc.

170. Right of Steering Column (’99-’04)

FRONT
SEAT
HEATER
RELAY
