Acura RL (1996-2004 year). Manual - part 156

2004 American Honda Motor Co., Inc.

159. Center of Dash

NAVIGATION
DISPLAY
UNIT
(’96-’03)

FOG LIGHT
SWITCH

HAZARD
WARNING
SWITCH

2004 American Honda Motor Co., Inc.

160. Left Front of Trunk (’96-’03)

NAVIGATION
UNIT

2004 American Honda Motor Co., Inc.

161. Right Front of Trunk (’96-’03)

NAVIGATION
SERVICE
CHECK
CONNECTOR
(2-GRY)

2004 American Honda Motor Co., Inc.

162. Left Front of Engine Compartment

FRONT SEAT
HEATER RELAY
(‘98)
or
ACCESSORY POWER
SOCKET RELAY
(’99-’04)

HORN
RELAY
(’98-’04)

ABS
FAIL-SAFE
RELAY
(’98-’99)

TAILLIGHT
RELAY
(LOCATION)
(’99-’04)
