Acura RL (1996-2004 year). Manual - part 123

2004 American Honda Motor Co., Inc.

27. In Under-hood Relay Box C

RADIATOR
FAN
RELAY

GAUGE
RELAY

A/T REVERSE
RELAY

2004 American Honda Motor Co., Inc.

28. In Under-hood Relay Box C (‘96-‘97)

ABS REAR
FAIL-SAFE
RELAY

POWER WINDOW
MASTER SWITCH
RELAY

ABS FRONT
FAIL-SAFE
RELAY

2004 American Honda Motor Co., Inc.

29. Front of Engine Compt. (Battery Tray Removed)

ALTERNATOR

G1

T102
(Behind)

2004 American Honda Motor Co., Inc.

30. Left Side of Engine Compartment

C124
(2-GRY)

C309
(2-ORN)
