Acura RL (1996-2004 year). Manual - part 122

2004 American Honda Motor Co., Inc.

23. Left Front of Engine Compartment

UNDER-HOOD
RELAY BOX C

UNDER-HOOD
RELAY BOX A

2004 American Honda Motor Co., Inc.

24. In Under-hood Relay Box A

RADIATOR FAN
MAIN RELAY

WINDSHIELD WIPER
INTERMITTENT RELAY

CONDENSER
FAN RELAY

2004 American Honda Motor Co., Inc.

25. In Under-hood Relay Box A

USA ’99-’04:
SECURITY HORN RELAY
’96-’98 CANADA:
LOW BEAM CUT RELAY

REAR
WINDOW
DEFOGGER
RELAY

A/C COMPRESSOR
CLUTCH RELAY

LOW BEAM
CUT RELAY
(’00-’04
CANADA)

2004 American Honda Motor Co., Inc.

26. In Under-hood Relay Box C

FRONT
FOG LIGHT
RELAY

TCS
FAIL-SAFE
RELAY
(’96-’99)
SUB
THROTTLE
MOTOR
FAIL-SAFE
RELAY
(’00-’04)

WINDSHIELD
WIPER MOTOR
RELAY
