Acura CSX. Manual - part 405

ＳＮＲ９ＡＣ７Ｋ８０１０００Ｒ２１１１ＦＡＡＴ００

−

DTC 21-11:

DTC 22-11:

DTC 23-11:

DTC 24-11:

YES

DTC

Appropriate

Magnetic

Encoder

Note

YES

19-125

Right-front Magnetic Encoder

(Wheel Bearing) Malfunction (Pulse Missing)

Left-front Magnetic Encoder

(Wheel Bearing) Malfunction (Pulse Missing)

Right-rear Magnetic Encoder

(Wheel Bearing) Malfunction (Pulse Missing)

Left-rear Magnetic Encoder

(Wheel Bearing) Malfunction (Pulse Missing)

1. Turn the ignition switch to ON (II).

2. Clear the DTC with the HDS.

3. Test-drive the vehicle at 20 km/h (13 mph) or more,

and go a distance of 100 m (328 ft) or more.

NOTE: Drive the vehicle on the road, not on a lift.

4. Check for DTCs with the HDS.

Go to step 5.

Intermittent failure, the system is OK at this

time. Check for loose terminals between the wheel
speed sensor 2P connector and the VSA modulator-
control unit 37P connector. Refer to intermittent
failures troubleshooting (see page 19-98).

5. Turn the ignition switch to LOCK (0).

6. Inspect the appropriate magnetic encoder for

damage, debris, and correct installation.

21-11

Right-front

Remove the
driveshaft outboard
joint from the
appropriate wheel
hub (see page 18-15).

22-11

Left-front

23-11

Right-rear

Remove the hub
bearing unit
(see page 18-32).

24-11

Left-rear

Remove the debris from the magnetic

encoder, or replace the wheel bearing (front) or the
hub bearing unit (rear):

• Front: Replace the front wheel bearing (see page

18-18).

• Rear: Replace the rear hub bearing unit (see page

18-32).

Clean off debris from the appropriate

magnetic encoder surface on the wheel bearing or
the hub bearing unit, then go to step 1, and recheck.
If the DTC is still present, replace the appropriate
wheel bearing or hub bearing unit.

Is DT C 21-11, 22-11, 23-11, and/ or 24-11
indicated?

Is the magnetic encoder sur f ace OK ?

08/08/21 15:05:53 61SNR030_190_0125

ＳＮＲ９ＡＣ７Ｋ８０１０００Ｒ２５１１ＦＡＡＴ００

−

DTC 25-11:

DTC 25-12:

DTC 25-13:

DTC 25-16:

DTC 25-18:

DTC 25-21:

DTC 26-11:

DTC 26-12:

DTC 26-13:

YES

19-126

VSA System Components

Yaw Rate Sensor Internal Circuit

Malfunction (Initial)

Yaw Rate Sensor Internal Circuit

Malfunction (Open, Short)

Yaw Rate Sensor Communication

Error

Yaw Rate/Lateral Acceleration

Sensor Internal Circuit Malfunction (Keep
Alive Memory (KAM) Error)

Yaw Rate/Lateral Acceleration

Sensor Internal Circuit Malfunction

Yaw Rate Sensor Neutral Position

Malfunction

Lateral Acceleration Sensor

Internal Circuit Malfunction (Initial)

Lateral Acceleration Sensor

Internal Circuit Malfunction (Open, Short)

Lateral Acceleration Sensor

Communication Error

1. Turn the ignition switch to ON (II).

2. Clear the DTC with the HDS.

3. Turn the ignition switch to LOCK (0), then turn it to

ON (II) again.

4. Check for DTCs with the HDS.

Replace the yaw rate-lateral acceleration

sensor (see page 19-169).

Intermittent failure, the system is OK at this

time.

Is DT C 25-11, 25-12, 25-13, 25-16, 25-18, 25-21,
26-11, 26-12, or 26-13 indicated?

08/08/21 15:05:53 61SNR030_190_0126

ＳＮＲ９ＡＣ７Ｋ８０１０００Ｒ２５１４ＦＡＡＴ００

ＳＮＲ９ＡＣ７Ｋ８０１０００Ｒ２５１９ＦＡＡＴ００

−

DTC 25-14:

DTC 25-15:

DTC 25-17:

DTC 25-19:

DTC 25-23:

YES

19-127

Yaw Rate/Lateral Acceleration

Sensor Circuit High Voltage

Yaw Rate/Lateral Acceleration

Sensor Circuit Low Voltage

Yaw Rate/Lateral Acceleration

Sensor Power Source Voltage Malfunction

Yaw Rate/Lateral Acceleration

Sensor Startup Time Malfunction

Yaw Rate Sensor Circuit

Intermittent Interruption

1. Turn the ignition switch to ON (II).

2. Clear the DTC with the HDS.

3. Turn the ignition switch to LOCK (0), then turn it to

ON (II) again.

4. Check for DTCs with the HDS.

If DTC 61-01, 61-21, 61-22, 61-23, and/or

62-21 is indicated at the same time, check the
battery performance (see page 22-67), and do the
alternator and regulator circuit troubleshooting first
(see page 4-28). If DTC 61-01, 61-21, 61-22, 61-23,
and/or 62-21 is not indicated at the same time,
replace the yaw rate-lateral acceleration sensor
(see page 19-169).

Intermittent failure, the system is OK at this

time.

1. Turn the ignition switch to ON (II).

2. Clear the DTC with the HDS.

3. Turn the ignition switch to LOCK (0), then turn it to

ON (II) again.

4. Wait 60 seconds or more.

5. Check for DTCs with the HDS.

Replace the yaw rate-lateral acceleration

sensor (see page 19-169).

Intermittent failure, the system is OK at this

time.

Is DT C 25-14, 25-15, or 25-17 indicated?

Is DT C 25-19 or 25-23 indicated?

08/08/21 15:05:53 61SNR030_190_0127

ＳＮＲ９ＡＣ７Ｋ８０１０００Ｒ２５２２ＦＡＡＴ００

ＳＮＲ９ＡＣ７Ｋ８０１０００Ｒ２５２４ＦＡＡＴ００

−

DTC 25-22:

DTC 25-24:

DTC 25-25:

DTC 26-24:

DTC 26-25:

YES

19-128

VSA System Components

Yaw Rate Sensor Stuck

Yaw Rate Sensor Gain Low

Yaw Rate Sensor Gain High

Lateral Acceleration Sensor Gain

Low

Lateral Acceleration Sensor Gain

High

1. Turn the ignition switch to ON (II).

2. Clear the DTC with the HDS.

3. Test-drive the vehicle at 10 km/h (7 mph) or more.

NOTE: Drive the vehicle on the road, not on a lift.

4. Check for DTCs with the HDS.

Go to step 5.

If any other DTCs are indicated, go to the

indicated DTCs troubleshooting. If DTCs are not
indicated, there was an intermittent failure, the
system is OK at this time.

5. Test-drive the vehicle. Check the YAW RATE S in

the VSA DATA LIST with the HDS while driving in
corners.

Intermittent failure, the system is OK at this

time.

Replace the yaw rate-lateral acceleration

sensor (see page 19-169).

1. Turn the ignition switch to ON (II).

2. Clear the DTC with the HDS.

3. Test-drive the vehicle at 15 km/h (10 mph) or more.

NOTE: Drive the vehicle on the road, not on a lift.

4. Check for DTCs with the HDS.

Replace the yaw rate-lateral acceleration

sensor (see page 19-169).

Intermittent failure, the system is OK at this

time.

Is DT C 25-22 indicated?

Does the indicated value change?

Is DT C 25-24, 25-25, 26-24, or 26-25 indicated?

08/08/21 15:05:54 61SNR030_190_0128
