01 SNR9AA1E10411619641MAAT00 01 SNR9AA1E10411619621KBAT10 − − Standard: 0.05 0.15 mm (0.002 0.006 in.) 14-356 14-356 A/T Differential Backlash Inspection Differential Carrier and Final Driven A B C B A B 103 N·m (10.5 kgf·m, 75.9 lbf·ft) 1. Install both axles into the differential, and place the axles on V-blocks (A). 2. Measure the backlash of the pinion gears (B) using a dial indicator (C). 3. If the backlash is out of standard, replace the differential carrier. NOTE: Inspect and adjust the carrier bearing preload 1. Remove the final driven gear (A) from the differential carrier (B). NOTE: The final driven gear bolts have left-hand 2. Install the final driven gear on the differential carrier in the direction shown. Tighten the bolts to 08/08/21 14:52:43 61SNR030_140_0358 |
