Fig. 41: Identifying Armrest, Cover With Mounting Bolt Location
Courtesy of KIA MOTORS AMERICA, INC.

4. Remove the seat back panel (A).

Fig. 42: Removing Seat Back Panel
Courtesy of KIA MOTORS AMERICA, INC.

5. Remove the hog-ring clips (A).



2008 Kia Sedona EX

2008 ACCESSORIES & BODY, CAB Seat - Sedona



Microsoft



Monday, May 24, 2010 3:50:58 PM

Page 25

© 2006 Mitchell Repair Information Company, LLC.

Fig. 43: Identifying Hog-Ring Clips
Courtesy of KIA MOTORS AMERICA, INC.

6. Remove the headrest and headrest guide.

7. After removing the hog-ring clips (A) on the front of seat back remove the seat back cover (B).

Fig. 44: Identifying Hog-Ring Clips And Seat Back Cover
Courtesy of KIA MOTORS AMERICA, INC.

8. Installation is the reverse of removal.

NOTE:



To prevent wrinkles, make sure the material is stretched evenly over
the cover (A) before securing the hog-ring clips (B)



Replace the hog-ring clips with new ones using special tool (C).



2008 Kia Sedona EX

2008 ACCESSORIES & BODY, CAB Seat - Sedona



Microsoft



Monday, May 24, 2010 3:50:58 PM

Page 26

© 2006 Mitchell Repair Information Company, LLC.

Fig. 45: Identifying Cover, Hog-Ring Clips And Special Tool
Courtesy of KIA MOTORS AMERICA, INC.

SEAT CUSHION COVER REPLACEMENT

1. Remove the seat assembly. See REPLACEMENT.

2. Remove the recliner cover. See RECLINER COVER REPLACEMENT.

3. Loosen the mounting bolts, then remove the seat back assembly (A).

Fig. 46: Identifying Seat Back Assembly And Auto Tumble Cable
Courtesy of KIA MOTORS AMERICA, INC.

4. Loosen the mounting bolts, then remove the seat cushion (A).



2008 Kia Sedona EX

2008 ACCESSORIES & BODY, CAB Seat - Sedona



Microsoft



Monday, May 24, 2010 3:50:58 PM

Page 27

© 2006 Mitchell Repair Information Company, LLC.

Fig. 47: Identifying Seat Cushion With Mounting Bolt Location
Courtesy of KIA MOTORS AMERICA, INC.

5. Remove the recliner cable (A).

Fig. 48: Identifying Recliner Cable
Courtesy of KIA MOTORS AMERICA, INC.

6. Loosen the mounting screw (A), then disconnect the scuff band (B).
