Fig. 59: Cutting Out Sealant Using Sealant Cutting Tool
Courtesy of KIA MOTORS AMERICA, INC.

4. Remove the windshield (A) carefully using the glass holder (B) (09861-31100).

Fig. 60: Removing Windshield Using Glass Holder
Courtesy of KIA MOTORS AMERICA, INC.

INSTALLATION

1. With a knife, scrape the old adhesive smooth to a thickness of about 2mm (0.08 in.) on the bonding

surface around the entire windshield opening flange:



2008 Kia Sedona EX

2008 ACCESSORIES & BODY, CAB Interior - Sedona



Microsoft



Monday, May 24, 2010 4:05:49 PM

Page 43

© 2006 Mitchell Repair Information Company, LLC.



Do not scrape down to the painted surface of the body; damaged paint will interfere with proper
bonding.



Remove the rubber dam and fasteners from the body.



Mask off surrounding surfaces before painting.

2. Clean the bonding surface with a sponge dampened in alcohol. After cleaning, keep oil, grease and water

from getting on the clean surface.

3. Install the windshield (A) upper molding (B) and fasteners (C). Do not allow any gaps.

Fig. 61: Identifying Windshield, Upper Molding And Fasteners
Courtesy of KIA MOTORS AMERICA, INC.

4. Install the spacer (A) install the windshield glass (B) temporarily with making sure to position them on

the center, and then place the alignment mark (C).

5. Remove the windshield.



2008 Kia Sedona EX

2008 ACCESSORIES & BODY, CAB Interior - Sedona



Microsoft



Monday, May 24, 2010 4:05:49 PM

Page 44

© 2006 Mitchell Repair Information Company, LLC.

Fig. 62: Identifying Windshield Glass And Alignment Mark
Courtesy of KIA MOTORS AMERICA, INC.

6. With a sponge, apply a light coat of body primer to the original adhesive remaining around the windshield

opening flange. Let the body primer dry for at least 10 minutes.



Do not apply glass primer to the body, and be careful not to mix up glass and body primer sponges.



Never touch the primed surfaces with your hands.



Mask off the dashboard before painting the flange.

Fig. 63: Identifying Body Primer Applying Area
Courtesy of KIA MOTORS AMERICA, INC.

7. Apply a light coat of glass primer to the outside of the fasteners.

NOTE:



Never touch the primed surface with your hand. If you do, the
adhesive may not bond to the glass Properly, causing a leak after the



2008 Kia Sedona EX

2008 ACCESSORIES & BODY, CAB Interior - Sedona



Microsoft



Monday, May 24, 2010 4:05:49 PM

Page 45

© 2006 Mitchell Repair Information Company, LLC.

Fig. 64: Identifying Applying Area Of Glass Primer To Outside Of Fasteners
Courtesy of KIA MOTORS AMERICA, INC.

8. Pack adhesive into the cartridge without air pockets to ensure continuous delivery. Put the cartridge in a

caulking gun, and run a bead of adhesive (A) around the edge of the windshield (B) between the fastener
and molding as shown. Apply the adhesive within 30 minutes after applying the glass primer.

Make a slightly thicker bead at each corner.

windshield glass is installed.



Do not apply body primer to the glass.



Keep water, dust, and abrasive materials away from the primer.
