2. Remove rear scuff plate.

Installation

Rear hatch trim

1. Positon rear hatch trim.

2. Install rear hatch trim.

3. Install assist handle.

4. Install high-mounted stop light assembly.

Installation

Rear quarter trim

1. Position rear quarter trim.

2. Install two screws and one fastener on rear quarter trim.

3. Install trunk end trim.

Installation

Rear scuff plate

1. Position rear scuff plate.

2. Press in rear scuff plate.

Body (Interior and Exterior)

Interior - Interior Trim

Body (Interior and Exterior)

  2001 > 1.8L DOHC >



Component

Trim is a plastic component thermoses molding and is used to cover interior of vehicle. It assists vehicle insulation by
covering it in addition to hiding vehicle metal frame. It also acts as a sound barrier.
It is used on all four doors of vehicle door opening sills, A, B, and C pillars, front side, rear side and end trim. All door trim on
vehicle includes pull handle. Each trim on front two doors provides a pocket for keeping maps, etc.
