19. Disconnect generator B-terminal connector and C121 from generator.

20. Remove both right and left splash with three bolts and three fasteners each.

21. Loosen power steering pump lock bolt (A), nut (B), (C) and remove tension from power steering (P/S) pump and/or

air conditioning (A/C) compressor drive belt by turn adjusting bolt(D).

22. Remove P/S pump and/or A/C compressir drive belt.

23. Remove P/S pump lock bolt (A), nut (C) and remove P/S pump.

24. Position P/S pump away from engine and affix it with wire.

25. Disconnect lower radiator hose.

26. Remove four A/C compressir bolts and remove A/C compressor.

27. Position A/C compressor away from engine and affix it with wire.

28. Disconnect ground strap from top of transaxle.

29. Disconnnect input/turbine speed sensor connector(A/T).

30. Disconnect back-up light switch connector (M/T).

31. Disconnect vehicle speed sensor connector.

32. Remove U-clop from selector cable to transaxle linkage (A/T).

33. Remove nut and washer from transaxle linkage(A/T).

34. Remove manual transaxle linkage and extension bar (M/T).

35. Remove clutch release cylinder and pipe (M/T).

36. Disconnect transaxle ranges switch connector (A/T).

37. Disconnect solenoid valve connector (A/T).

38. Disconnect two ATF cooler hose (A/T).

39. Remove both front wheels (four lug nuts each).

40. Disconnect oxygen sensor connector.

41. Remove front exhaust pipe.

42. Remove both right and left tie rod ends from steering knuckles by removing one cotter pin and one nut each.

43. Remove both right and left stabilizer control link from bracket aggached to shock absorber after remove the control

link nut.

44. Remove pinch bolt and nut from both right and left ball joints.

45. Remove both right and left ball joints from steering knuckles.

46. Gently pry both driveshafts from transaxle.

47. Disconnect B-terminal connector and S-terminal connector from starter.
