Intel 64 and IA-32 Architectures. Software Developer’s Manual (Collection, 2023) - page 2





INSTRUCTION FORMAT
Table 2-8. VEX.vvvv to register name mapping
General-Purpose Register
Valid in Legacy/Compatibility
VEX.vvvv
Dest Register
(If Applicable)1
32-bit modes?2
1111B
XMM0/YMM0
RAX/EAX
Valid
1110B
XMM1/YMM1
RCX/ECX
Valid
1101B
XMM2/YMM2
RDX/EDX
Valid
1100B
XMM3/YMM3
RBX/EBX
Valid
1011B
XMM4/YMM4
RSP/ESP
Valid
1010B
XMM5/YMM5
RBP/EBP
Valid
1001B
XMM6/YMM6
RSI/ESI
Valid
1000B
XMM7/YMM7
RDI/EDI
Valid
0111B
XMM8/YMM8
R8/R8D
Invalid
0110B
XMM9/YMM9
R9/R9D
Invalid
0101B
XMM10/YMM10
R10/R10D
Invalid
0100B
XMM11/YMM11
R11/R11D
Invalid
0011B
XMM12/YMM12
R12/R12D
Invalid
0010B
XMM13/YMM13
R13/R13D
Invalid
0001B
XMM14/YMM14
R14/R14D
Invalid
0000B
XMM15/YMM15
R15/R15D
Invalid
NOTES:
1. See Section 2.6, “VEX Encoding Support for GPR Instructions” for additional details.
2. Only the first eight General-Purpose Registers are accessible/encodable in 16/32b modes.
The VEX.vvvv field is encoded in bit inverted format for accessing a register operand.
2.3.6
Instruction Operand Encoding and VEX.vvvv, ModR/M
VEX-encoded instructions support three-operand and four-operand instruction syntax. Some VEX-encoded
instructions have syntax with less than three operands, e.g., VEX-encoded pack shift instructions support one
source operand and one destination operand).
The roles of VEX.vvvv, reg field of ModR/M byte (ModR/M.reg), r/m field of ModR/M byte (ModR/M.r/m) with
respect to encoding destination and source operands vary with different type of instruction syntax.
The role of VEX.vvvv can be summarized to three situations:
VEX.vvvv encodes the first source register operand, specified in inverted (1’s complement) form and is valid for
instructions with 2 or more source operands.
VEX.vvvv encodes the destination register operand, specified in 1’s complement form for certain vector shifts.
The instructions where VEX.vvvv is used as a destination are listed in Table 2-9. The notation in the “Opcode”
column in Table 2-9 is described in detail in section 3.1.1.
VEX.vvvv does not encode any operand, the field is reserved and should contain 1111b.
Table 2-9. Instructions with a VEX.vvvv destination
Opcode
Instruction mnemonic
VEX.128.66.0F 73 /7 ib
VPSLLDQ xmm1, xmm2, imm8
VEX.128.66.0F 73 /3 ib
VPSRLDQ xmm1, xmm2, imm8
VEX.128.66.0F 71 /2 ib
VPSRLW xmm1, xmm2, imm8
VEX.128.66.0F 72 /2 ib
VPSRLD xmm1, xmm2, imm8
VEX.128.66.0F 73 /2 ib
VPSRLQ xmm1, xmm2, imm8
VEX.128.66.0F 71 /4 ib
VPSRAW xmm1, xmm2, imm8
Vol. 2A
2-17
INSTRUCTION FORMAT
Opcode
Instruction mnemonic
VEX.128.66.0F 72 /4 ib
VPSRAD xmm1, xmm2, imm8
VEX.128.66.0F 71 /6 ib
VPSLLW xmm1, xmm2, imm8
VEX.128.66.0F 72 /6 ib
VPSLLD xmm1, xmm2, imm8
VEX.128.66.0F 73 /6 ib
VPSLLQ xmm1, xmm2, imm8
The role of ModR/M.r/m field can be summarized to two situations:
ModR/M.r/m encodes the instruction operand that references a memory address.
For some instructions that do not support memory addressing semantics, ModR/M.r/m encodes either the
destination register operand or a source register operand.
The role of ModR/M.reg field can be summarized to two situations:
ModR/M.reg encodes either the destination register operand or a source register operand.
For some instructions, ModR/M.reg is treated as an opcode extension and not used to encode any instruction
operand.
For instruction syntax that support four operands, VEX.vvvv, ModR/M.r/m, ModR/M.reg encodes three of the four
operands. The role of bits 7:4 of the immediate byte serves the following situation:
Imm8[7:4] encodes the third source register operand.
2.3.6.1
3-byte VEX byte 1, bits[4:0] - “m-mmmm”
Bits[4:0] of the 3-byte VEX byte 1 encode an implied leading opcode byte (0F, 0F 38, or 0F 3A). Several bits are
reserved for future use and will #UD unless 0.
Table 2-10. VEX.m-mmmm interpretation
VEX.m-mmmm
Implied Leading Opcode Bytes
00000B
Reserved
00001B
0F
00010B
0F 38
00011B
0F 3A
00100-11111B
Reserved
(2-byte VEX)
0F
VEX.m-mmmm is only available on the 3-byte VEX. The 2-byte VEX implies a leading 0Fh opcode byte.
2.3.6.2
2-byte VEX byte 1, bit[2], and 3-byte VEX byte 2, bit [2]- “L”
The vector length field, VEX.L, is encoded in bit[2] of either the second byte of 2-byte VEX, or the third byte of 3-
byte VEX. If “VEX.L = 1”, it indicates 256-bit vector operation. “VEX.L = 0” indicates scalar and 128-bit vector
operations.
The instruction VZEROUPPER is a special case that is encoded with VEX.L = 0, although its operation zero’s bits
255:128 of all YMM registers accessible in the current operating mode.
See the following table.
2-18
Vol. 2A
INSTRUCTION FORMAT
Table 2-11. VEX.L interpretation
VEX.L
Vector Length
0
128-bit (or 32/64-bit scalar)
1
256-bit
2.3.6.3
2-byte VEX byte 1, bits[1:0], and 3-byte VEX byte 2, bits [1:0]- “pp”
Up to one implied prefix is encoded by bits[1:0] of either the 2-byte VEX byte 1 or the 3-byte VEX byte 2. The prefix
behaves as if it was encoded prior to VEX, but after all other encoded prefixes.
See the following table.
Table 2-12. VEX.pp interpretation
pp
Implies this prefix after other prefixes but before VEX
00B
None
01B
66
10B
F3
11B
F2
2.3.7
The Opcode Byte
One (and only one) opcode byte follows the 2 or 3 byte VEX. Legal opcodes are specified in Appendix B, in color.
Any instruction that uses illegal opcode will #UD.
2.3.8
The ModR/M, SIB, and Displacement Bytes
The encodings are unchanged but the interpretation of reg_field or rm_field differs (see above).
2.3.9
The Third Source Operand (Immediate Byte)
VEX-encoded instructions can support instruction with a four operand syntax. VBLENDVPD, VBLENDVPS, and
PBLENDVB use imm8[7:4] to encode one of the source registers.
2.3.10 Intel® AVX Instructions and the Upper 128-bits of YMM registers
If an instruction with a destination XMM register is encoded with a VEX prefix, the processor zeroes the upper bits
(above bit 128) of the equivalent YMM register. Legacy SSE instructions without VEX preserve the upper bits.
2.3.10.1 Vector Length Transition and Programming Considerations
An instruction encoded with a VEX.128 prefix that loads a YMM register operand operates as follows:
Data is loaded into bits 127:0 of the register
Bits above bit 127 in the register are cleared.
Thus, such an instruction clears bits 255:128 of a destination YMM register on processors with a maximum vector-
register width of 256 bits. In the event that future processors extend the vector registers to greater widths, an
instruction encoded with a VEX.128 or VEX.256 prefix will also clear any bits beyond bit 255. (This is in contrast
with legacy SSE instructions, which have no VEX prefix; these modify only bits 127:0 of any destination register
operand.)
Programmers should bear in mind that instructions encoded with VEX.128 and VEX.256 prefixes will clear any
future extensions to the vector registers. A calling function that uses such extensions should save their state before
calling legacy functions. This is not possible for involuntary calls (e.g., into an interrupt-service routine). It is
recommended that software handling involuntary calls accommodate this by not executing instructions encoded
Vol. 2A
2-19
INSTRUCTION FORMAT
with VEX.128 and VEX.256 prefixes. In the event that it is not possible or desirable to restrict these instructions,
then software must take special care to avoid actions that would, on future processors, zero the upper bits of vector
registers.
Processors that support further vector-register extensions (defining bits beyond bit 255) will also extend the
XSAVE and XRSTOR instructions to save and restore these extensions. To ensure forward compatibility, software
that handles involuntary calls and that uses instructions encoded with VEX.128 and VEX.256 prefixes should first
save and then restore the vector registers (with any extensions) using the XSAVE and XRSTOR instructions with
save/restore masks that set bits that correspond to all vector-register extensions. Ideally, software should rely on
a mechanism that is cognizant of which bits to set. (E.g., an OS mechanism that sets the save/restore mask bits
for all vector-register extensions that are enabled in XCR0.) Saving and restoring state with instructions other than
XSAVE and XRSTOR will, on future processors with wider vector registers, corrupt the extended state of the vector
registers - even if doing so functions correctly on processors supporting 256-bit vector registers. (The same is true
if XSAVE and XRSTOR are used with a save/restore mask that does not set bits corresponding to all supported
extensions to the vector registers.)
2.3.11 Intel® AVX Instruction Length
The Intel AVX instructions described in this document (including VEX and ignoring other prefixes) do not exceed 11
bytes in length, but may increase in the future. The maximum length of an Intel 64 and IA-32 instruction remains
15 bytes.
2.3.12 Vector SIB (VSIB) Memory Addressing
In Intel® Advanced Vector Extensions 2 (Intel® AVX2), an SIB byte that follows the ModR/M byte can support VSIB
memory addressing to an array of linear addresses. VSIB addressing is only supported in a subset of Intel AVX2
instructions. VSIB memory addressing requires 32-bit or 64-bit effective address. In 32-bit mode, VSIB addressing
is not supported when address size attribute is overridden to 16 bits. In 16-bit protected mode, VSIB memory
addressing is permitted if address size attribute is overridden to 32 bits. Additionally, VSIB memory addressing is
supported only with VEX prefix.
In VSIB memory addressing, the SIB byte consists of:
The scale field (bit 7:6) specifies the scale factor.
The index field (bits 5:3) specifies the register number of the vector index register, each element in the vector
register specifies an index.
The base field (bits 2:0) specifies the register number of the base register.
Table 2-13 shows the 32-bit VSIB addressing form. It is organized to give 256 possible values of the SIB byte (in
hexadecimal). General purpose registers used as a base are indicated across the top of the table, along with corre-
sponding values for the SIB byte’s base field. The register names also include R8D-R15D applicable only in 64-bit
mode (when address size override prefix is used, but the value of VEX.B is not shown in Table 2-13). In 32-bit
mode, R8D-R15D does not apply.
Table rows in the body of the table indicate the vector index register used as the index field and each supported
scaling factor shown separately. Vector registers used in the index field can be XMM or YMM registers. The left-
most column includes vector registers VR8-VR15 (i.e., XMM8/YMM8-XMM15/YMM15), which are only available in
64-bit mode and does not apply if encoding in 32-bit mode.
2-20
Vol. 2A
INSTRUCTION FORMAT
Table 2-13. 32-Bit VSIB Addressing Forms of the SIB Byte
r32
EAX/
ECX/
EDX/
EBX/
ESP/
EBP/
ESI/
EDI/
R8D
R9D
R10D
R11D
R12D
R13D1
R14D
R15D
(In decimal) Base =
0
1
2
3
4
5
6
7
(In binary) Base =
000
001
010
011
100
101
110
111
Scaled Index
SS
Index
Value of SIB Byte (in Hexadecimal)
VR0/VR8
*1
00
000
00
01
02
03
04
05
06
07
VR1/VR9
001
08
09
0A
0B
0C
0D
0E
0F
VR2/VR10
010
10
11
12
13
14
15
16
17
VR3/VR11
011
18
19
1A
1B
1C
1D
1E
1F
VR4/VR12
100
20
21
22
23
24
25
26
27
VR5/VR13
101
28
29
2A
2B
2C
2D
2E
2F
VR6/VR14
110
30
31
32
33
34
35
36
37
VR7/VR15
111
38
39
3A
3B
3C
3D
3E
3F
VR0/VR8
*2
01
000
40
41
42
43
44
45
46
47
VR1/VR9
001
48
49
4A
4B
4C
4D
4E
4F
VR2/VR10
010
50
51
52
53
54
55
56
57
VR3/VR11
011
58
59
5A
5B
5C
5D
5E
5F
VR4/VR12
100
60
61
62
63
64
65
66
67
VR5/VR13
101
68
69
6A
6B
6C
6D
6E
6F
VR6/VR14
110
70
71
72
73
74
75
76
77
VR7/VR15
111
78
79
7A
7B
7C
7D
7E
7F
VR0/VR8
*4
10
000
80
81
82
83
84
85
86
87
VR1/VR9
001
88
89
8A
8B
8C
8D
8E
8F
VR2/VR10
010
90
91
92
93
94
95
96
97
VR3/VR11
011
98
89
9A
9B
9C
9D
9E
9F
VR4/VR12
100
A0
A1
A2
A3
A4
A5
A6
A7
VR5/VR13
101
A8
A9
AA
AB
AC
AD
AE
AF
VR6/VR14
110
B0
B1
B2
B3
B4
B5
B6
B7
VR7/VR15
111
B8
B9
BA
BB
BC
BD
BE
BF
VR0/VR8
*8
11
000
C0
C1
C2
C3
C4
C5
C6
C7
VR1/VR9
001
C8
C9
CA
CB
CC
CD
CE
CF
VR2/VR10
010
D0
D1
D2
D3
D4
D5
D6
D7
VR3/VR11
011
D8
D9
DA
DB
DC
DD
DE
DF
VR4/VR12
100
E0
E1
E2
E3
E4
E5
E6
E7
VR5/VR13
101
E8
E9
EA
EB
EC
ED
EE
EF
VR6/VR14
110
F0
F1
F2
F3
F4
F5
F6
F7
VR7/VR15
111
F8
F9
FA
FB
FC
FD
FE
FF
NOTES:
1. If ModR/M.mod = 00b, the base address is zero, then effective address is computed as [scaled vector index] + disp32. Otherwise the
base address is computed as [EBP/R13]+ disp, the displacement is either 8 bit or 32 bit depending on the value of ModR/M.mod:
MOD
Effective Address
00b
[Scaled Vector Register] + Disp32
01b
[Scaled Vector Register] + Disp8 + [EBP/R13]
10b
[Scaled Vector Register] + Disp32 + [EBP/R13]
2.3.12.1
64-bit Mode VSIB Memory Addressing
In 64-bit mode VSIB memory addressing uses the VEX.B field and the base field of the SIB byte to encode one of
the 16 general-purpose register as the base register. The VEX.X field and the index field of the SIB byte encode one
of the 16 vector registers as the vector index register.
In 64-bit mode the top row of Table 2-13 base register should be interpreted as the full 64-bit of each register.
2.4
INTEL® ADVANCED MATRIX EXTENSIONS (INTEL® AMX)
Intel® AMX instructions follow the general documentation convention established in previous sections. Additionally,
Intel® Advanced Matrix Extensions use notation conventions as described below.
In the instruction encoding boxes, sibmem is used to denote an encoding where a ModR/M byte and SIB byte are
used to indicate a memory operation where the base and displacement are used to point to memory, and the index
Vol. 2A
2-21
INSTRUCTION FORMAT
register (if present) is used to denote a stride between memory rows. The index register is scaled by the sib.scale
field as usual. The base register is added to the displacement, if present.
In the instruction encoding, the ModR/M byte is represented several ways depending on the role it plays. The
ModR/M byte has 3 fields: 2-bit ModR/M.mod field, a 3-bit ModR/M.reg field and a 3-bit ModR/M.r/m field. When all
bits of the ModR/M byte have fixed values for an instruction, the 2-hex nibble value of that byte is presented after
the opcode in the encoding boxes on the instruction description pages. When only some fields of the ModR/M byte
must contain fixed values, those values are specified as follows:
If only the ModR/M.mod must be 0b11, and ModR/M.reg and ModR/M.r/m fields are unrestricted, this is
denoted as 11:rrr:bbb. The rrr correspond to the 3-bits of the ModR/M.reg field and the bbb correspond to the
3-bits of the ModR/M.r/m field.
If the ModR/M.mod field is constrained to be a value other than 0b11, i.e., it must be one of 0b00, 0b01, or
0b10, then the notation !(11) is used.
If the ModR/M.reg field had a specific required value, e.g., 0b101, that would be denoted as mm:101:bbb.
NOTE
Historically this document only specified the ModR/M.reg field restrictions with the notation /0 ... /7
and did not specify restrictions on the ModR/M.mod and ModR/M.r/m fields in the encoding boxes.
2.5
INTEL® AVX AND INTEL® SSE INSTRUCTION EXCEPTION CLASSIFICATION
To look up the exceptions of legacy 128-bit SIMD instruction, 128-bit VEX-encoded instructions, and 256-bit VEX-
encoded instruction, Table 2-14 summarizes the exception behavior into separate classes, with detailed exception
conditions defined in sub-sections 2.5.1 through 2.6.1. For example, ADDPS contains the entry:
“See Exceptions Type 2”
In this entry, Type2” can be looked up in Table 2-14.
The instruction’s corresponding CPUID feature flag can be identified in the fourth column of the Instruction
summary table.
Note: #UD on CPUID feature flags=0 is not guaranteed in a virtualized environment if the hardware supports the
feature flag.
NOTE
Instructions that operate only with MMX, X87, or general-purpose registers are not covered by the
exception classes defined in this section. For instructions that operate on MMX registers, see
Section 23.25.3, “Exception Conditions of Legacy SIMD Instructions Operating on MMX Registers”
in the Intel® 64 and IA-32 Architectures Software Developer’s Manual, Volume 3B.
2-22
Vol. 2A
INSTRUCTION FORMAT
Table 2-14. Exception Class Description
Floating-Point
Exception Class
Instruction set
Mem arg
Exceptions (#XM)
AVX,
16/32 byte explicitly
Type 1
None
Legacy SSE
aligned
AVX,
16/32 byte not explicitly
Type 2
Yes
Legacy SSE
aligned
AVX,
Type 3
< 16 byte
Yes
Legacy SSE
AVX,
16/32 byte not explicitly
Type 4
No
Legacy SSE
aligned
AVX,
Type 5
< 16 byte
No
Legacy SSE
Type 6
AVX (no Legacy SSE)
Varies
(At present, none do)
AVX,
Type 7
None
None
Legacy SSE
Type 8
AVX
None
None
F16C
8 or 16 byte, Not explicitly
Yes
Type 11
aligned, no AC#
AVX2 Gathers
Not explicitly aligned, no
No
Type 12
AC#
See Table 2-15 for lists of instructions in each exception class.
Vol. 2A
2-23
INSTRUCTION FORMAT
Table 2-15. Instructions in each Exception Class
Exception Class
Instruction
Type 1
(V)MOVAPD, (V)MOVAPS, (V)MOVDQA, (V)MOVNTDQ, (V)MOVNTDQA, (V)MOVNTPD, (V)MOVNTPS
(V)ADDPD, (V)ADDPS, (V)ADDSUBPD, (V)ADDSUBPS, (V)CMPPD, (V)CMPPS, (V)CVTDQ2PS, (V)CVTPD2DQ,
(V)CVTPD2PS, (V)CVTPS2DQ, (V)CVTTPD2DQ, (V)CVTTPS2DQ, (V)DIVPD, (V)DIVPS, (V)DPPD*, (V)DPPS*,
VFMADD132PD, VFMADD213PD, VFMADD231PD, VFMADD132PS, VFMADD213PS, VFMADD231PS,
VFMADDSUB132PD, VFMADDSUB213PD, VFMADDSUB231PD, VFMADDSUB132PS, VFMADDSUB213PS,
VFMADDSUB231PS, VFMSUBADD132PD, VFMSUBADD213PD, VFMSUBADD231PD, VFMSUBADD132PS,
Type 2
VFMSUBADD213PS, VFMSUBADD231PS, VFMSUB132PD, VFMSUB213PD, VFMSUB231PD, VFMSUB132PS,
VFMSUB213PS, VFMSUB231PS, VFNMADD132PD, VFNMADD213PD, VFNMADD231PD, VFNMADD132PS,
VFNMADD213PS, VFNMADD231PS, VFNMSUB132PD, VFNMSUB213PD, VFNMSUB231PD, VFNMSUB132PS,
VFNMSUB213PS, VFNMSUB231PS, (V)HADDPD, (V)HADDPS, (V)HSUBPD, (V)HSUBPS, (V)MAXPD, (V)MAXPS,
(V)MINPD, (V)MINPS, (V)MULPD, (V)MULPS, (V)ROUNDPD, (V)ROUNDPS, (V)SQRTPD, (V)SQRTPS, (V)SUBPD,
(V)SUBPS
(V)ADDSD, (V)ADDSS, (V)CMPSD, (V)CMPSS, (V)COMISD, (V)COMISS, (V)CVTPS2PD, (V)CVTSD2SI, (V)CVTSD2SS,
(V)CVTSI2SD, (V)CVTSI2SS, (V)CVTSS2SD, (V)CVTSS2SI, (V)CVTTSD2SI, (V)CVTTSS2SI, (V)DIVSD, (V)DIVSS,
VFMADD132SD, VFMADD213SD, VFMADD231SD, VFMADD132SS, VFMADD213SS, VFMADD231SS,
VFMSUB132SD, VFMSUB213SD, VFMSUB231SD, VFMSUB132SS, VFMSUB213SS, VFMSUB231SS,
Type 3
VFNMADD132SD, VFNMADD213SD, VFNMADD231SD, VFNMADD132SS, VFNMADD213SS, VFNMADD231SS,
VFNMSUB132SD, VFNMSUB213SD, VFNMSUB231SD, VFNMSUB132SS, VFNMSUB213SS, VFNMSUB231SS,
(V)MAXSD, (V)MAXSS, (V)MINSD, (V)MINSS, (V)MULSD, (V)MULSS, (V)ROUNDSD, (V)ROUNDSS, (V)SQRTSD,
(V)SQRTSS, (V)SUBSD, (V)SUBSS, (V)UCOMISD, (V)UCOMISS
(V)AESDEC, (V)AESDECLAST, (V)AESENC, (V)AESENCLAST, (V)AESIMC, (V)AESKEYGENASSIST, (V)ANDPD,
(V)ANDPS, (V)ANDNPD, (V)ANDNPS, (V)BLENDPD, (V)BLENDPS, VBLENDVPD, VBLENDVPS, (V)LDDQU***,
(V)MASKMOVDQU, (V)PTEST, VTESTPS, VTESTPD, (V)MOVDQU*, (V)MOVSHDUP, (V)MOVSLDUP, (V)MOVUPD*,
(V)MOVUPS*, (V)MPSADBW, (V)ORPD, (V)ORPS, (V)PABSB, (V)PABSW, (V)PABSD, (V)PACKSSWB, (V)PACKSSDW,
(V)PACKUSWB, (V)PACKUSDW, (V)PADDB, (V)PADDW, (V)PADDD, (V)PADDQ, (V)PADDSB, (V)PADDSW,
(V)PADDUSB, (V)PADDUSW, (V)PALIGNR, (V)PAND, (V)PANDN, (V)PAVGB, (V)PAVGW, (V)PBLENDVB,
(V)PBLENDW, (V)PCMP(E/I)STRI/M***, (V)PCMPEQB, (V)PCMPEQW, (V)PCMPEQD, (V)PCMPEQQ, (V)PCMPGTB,
(V)PCMPGTW, (V)PCMPGTD, (V)PCMPGTQ, (V)PCLMULQDQ, (V)PHADDW, (V)PHADDD, (V)PHADDSW,
(V)PHMINPOSUW, (V)PHSUBD, (V)PHSUBW, (V)PHSUBSW, (V)PMADDWD, (V)PMADDUBSW, (V)PMAXSB,
Type 4
(V)PMAXSW, (V)PMAXSD, (V)PMAXUB, (V)PMAXUW, (V)PMAXUD, (V)PMINSB, (V)PMINSW, (V)PMINSD,
(V)PMINUB, (V)PMINUW, (V)PMINUD, (V)PMULHUW, (V)PMULHRSW, (V)PMULHW, (V)PMULLW, (V)PMULLD,
(V)PMULUDQ, (V)PMULDQ, (V)POR, (V)PSADBW, (V)PSHUFB, (V)PSHUFD, (V)PSHUFHW, (V)PSHUFLW, (V)PSIGNB,
(V)PSIGNW, (V)PSIGND, (V)PSLLW, (V)PSLLD, (V)PSLLQ, (V)PSRAW, (V)PSRAD, (V)PSRLW, (V)PSRLD, (V)PSRLQ,
(V)PSUBB, (V)PSUBW, (V)PSUBD, (V)PSUBQ, (V)PSUBSB, (V)PSUBSW, (V)PSUBUSB, (V)PSUBUSW,
(V)PUNPCKHBW, (V)PUNPCKHWD, (V)PUNPCKHDQ, (V)PUNPCKHQDQ, (V)PUNPCKLBW, (V)PUNPCKLWD,
(V)PUNPCKLDQ, (V)PUNPCKLQDQ, (V)PXOR, (V)RCPPS, (V)RSQRTPS, (V)SHUFPD, (V)SHUFPS, (V)UNPCKHPD,
(V)UNPCKHPS, (V)UNPCKLPD, (V)UNPCKLPS, (V)XORPD, (V)XORPS, VPBLENDD, VPERMD, VPERMPS, VPERMPD,
VPERMQ, VPSLLVD, VPSLLVQ, VPSRAVD, VPSRLVD, VPSRLVQ, VPERMILPD, VPERMILPS, VPERM2F128
(V)CVTDQ2PD, (V)EXTRACTPS, (V)INSERTPS, (V)MOVD, (V)MOVQ, (V)MOVDDUP, (V)MOVLPD, (V)MOVLPS,
(V)MOVHPD, (V)MOVHPS, (V)MOVSD, (V)MOVSS, (V)PEXTRB, (V)PEXTRD, (V)PEXTRW, (V)PEXTRQ, (V)PINSRB,
Type 5
(V)PINSRD, (V)PINSRW, (V)PINSRQ, PMOVSXBW, (V)RCPSS, (V)RSQRTSS, (V)PMOVSX/ZX, VLDMXCSR*,
VSTMXCSR
VEXTRACTF128/VEXTRACTFxxxx, VBROADCASTSS, VBROADCASTSD, VBROADCASTF128, VINSERTF128,
Type 6
VMASKMOVPS**, VMASKMOVPD**, VPMASKMOVD, VPMASKMOVQ, VBROADCASTI128, VPBROADCASTB,
VPBROADCASTD, VPBROADCASTW, VPBROADCASTQ, VEXTRACTI128, VINSERTI128, VPERM2I128
(V)MOVLHPS, (V)MOVHLPS, (V)MOVMSKPD, (V)MOVMSKPS, (V)PMOVMSKB, (V)PSLLDQ, (V)PSRLDQ, (V)PSLLW,
Type 7
(V)PSLLD, (V)PSLLQ, (V)PSRAW, (V)PSRAD, (V)PSRLW, (V)PSRLD, (V)PSRLQ
Type 8
VZEROALL, VZEROUPPER
Type 11
VCVTPH2PS, VCVTPS2PH
VGATHERDPS, VGATHERDPD, VGATHERQPS, VGATHERQPD, VPGATHERDD, VPGATHERDQ, VPGATHERQD,
Type 12
VPGATHERQQ
(*) - Additional exception restrictions are present - see the Instruction description for details
2-24
Vol. 2A
INSTRUCTION FORMAT
(**) - Instruction behavior on alignment check reporting with mask bits of less than all 1s are the same as with mask bits of all 1s, i.e., no
alignment checks are performed.
(***) - PCMPESTRI, PCMPESTRM, PCMPISTRI, PCMPISTRM, and LDDQU instructions do not cause #GP if the memory operand is not
aligned to 16-Byte boundary.
Table 2-15 classifies exception behaviors for AVX instructions. Within each class of exception conditions that are
listed in Table 2-18 through Table 2-27, certain subsets of AVX instructions may be subject to #UD exception
depending on the encoded value of the VEX.L field. Table 2-17 provides supplemental information of AVX instruc-
tions that may be subject to #UD exception if encoded with incorrect values in the VEX.W or VEX.L field.
Table 2-16. #UD Exception and VEX.W=1 Encoding
#UD If VEX.W = 1 in
Exception Class
#UD If VEX.W = 1 in all modes
non-64-bit modes
Type 1
Type 2
Type 3
VBLENDVPD, VBLENDVPS, VPBLENDVB, VTESTPD, VTESTPS, VPBLENDD, VPERMD,
Type 4
VPERMPS, VPERM2I128, VPSRAVD, VPERMILPD, VPERMILPS, VPERM2F128
Type 5
VEXTRACTF128, VBROADCASTSS, VBROADCASTSD, VBROADCASTF128,
Type 6
VINSERTF128, VMASKMOVPS, VMASKMOVPD, VBROADCASTI128,
VPBROADCASTB/W/D, VEXTRACTI128, VINSERTI128
Type 7
Type 8
Type 11
VCVTPH2PS, VCVTPS2PH
Type 12
Vol. 2A
2-25
INSTRUCTION FORMAT
Table 2-17. #UD Exception and VEX.L Field Encoding
Exception
#UD If (VEX.L = 1 && AVX2 not present && AVX
#UD If (VEX.L = 1 && AVX2
#UD If VEX.L = 0
Class
present)
present)
Type 1
VMOVNTDQA
VDPPD
VDPPD
Type 2
Type 3
VMASKMOVDQU, VMPSADBW, VPABSB/W/D,
VPCMP(E/I)STRI/M,
VPACKSSWB/DW, VPACKUSWB/DW, VPADDB/W/D,
PHMINPOSUW
VPADDQ, VPADDSB/W, VPADDUSB/W, VPALIGNR, VPAND,
VPANDN, VPAVGB/W, VPBLENDVB, VPBLENDW,
VPCMP(E/I)STRI/M, VPCMPEQB/W/D/Q, VPCMPGTB/W/D/Q,
VPHADDW/D, VPHADDSW, VPHMINPOSUW, VPHSUBD/W,
VPHSUBSW, VPMADDWD, VPMADDUBSW, VPMAXSB/W/D,
Type 4
VPMAXUB/W/D, VPMINSB/W/D, VPMINUB/W/D,
VPMULHUW, VPMULHRSW, VPMULHW/LW, VPMULLD,
VPMULUDQ, VPMULDQ, VPOR, VPSADBW, VPSHUFB/D,
VPSHUFHW/LW, VPSIGNB/W/D, VPSLLW/D/Q, VPSRAW/D,
VPSRLW/D/Q, VPSUBB/W/D/Q, VPSUBSB/W,
VPUNPCKHBW/WD/DQ, VPUNPCKHQDQ,
VPUNPCKLBW/WD/DQ, VPUNPCKLQDQ, VPXOR
VEXTRACTPS, VINSERTPS, VMOVD, VMOVQ, VMOVLPD,
Same as column 3
VMOVLPS, VMOVHPD, VMOVHPS, VPEXTRB, VPEXTRD,
Type 5
VPEXTRW, VPEXTRQ, VPINSRB, VPINSRD, VPINSRW,
VPINSRQ, VPMOVSX/ZX, VLDMXCSR, VSTMXCSR
VEXTRACTF128,
VPERM2F128,
Type 6
VBROADCASTSD,
VBROADCASTF128,
VINSERTF128,
VMOVLHPS, VMOVHLPS, VPMOVMSKB, VPSLLDQ,
VMOVLHPS, VMOVHLPS
Type 7
VPSRLDQ, VPSLLW, VPSLLD, VPSLLQ, VPSRAW, VPSRAD,
VPSRLW, VPSRLD, VPSRLQ
Type 8
Type 11
Type 12
2-26
Vol. 2A
INSTRUCTION FORMAT
2.5.1
Exceptions Type 1 (Aligned Memory Reference)
Table 2-18. Type 1 Class Exception Conditions
Exception
Cause of Exception
X
X
VEX prefix.
VEX prefix:
X
X
If XCR0[2:1] ? ‘11b’.
If CR4.OSXSAVE[bit 18]=0.
Invalid Opcode,
Legacy SSE instruction:
#UD
X
X
X
X
If CR0.EM[bit 2] = 1.
If CR4.OSFXSR[bit 9] = 0.
X
X
X
X
If preceded by a LOCK prefix (F0H).
X
X
If any REX, F2, F3, or 66 prefixes precede a VEX prefix.
X
X
X
X
If any corresponding CPUID feature flag is ‘0’.
Device Not Avail-
X
X
X
X
If CR0.TS[bit 3]=1.
able, #NM
X
For an illegal address in the SS segment.
Stack, #SS(0)
X
If a memory address referencing the SS segment is in a non-canonical form.
VEX.256: Memory operand is not 32-byte aligned.
X
X
VEX.128: Memory operand is not 16-byte aligned.
X
X
X
X
Legacy SSE: Memory operand is not 16-byte aligned.
General Protec-
For an illegal memory operand effective address in the CS, DS, ES, FS or GS seg-
tion, #GP(0)
X
ments.
X
If the memory address is in a non-canonical form.
X
X
If any part of the operand lies outside the effective address space from 0 to FFFFH.
Page Fault
X
X
X
For a page fault.
#PF(fault-code)
Vol. 2A
2-27
INSTRUCTION FORMAT
2.5.2
Exceptions Type 2 (>=16 Byte Memory Reference, Unaligned)
Table 2-19. Type 2 Class Exception Conditions
Exception
Cause of Exception
X
X
VEX prefix.
X
X
X
X
If an unmasked SIMD floating-point exception and CR4.OSXMMEXCPT[bit 10] = 0.
VEX prefix:
X
X
If XCR0[2:1] ? ‘11b’.
If CR4.OSXSAVE[bit 18]=0.
Invalid Opcode,
Legacy SSE instruction:
#UD
X
X
X
X
If CR0.EM[bit 2] = 1.
If CR4.OSFXSR[bit 9] = 0.
X
X
X
X
If preceded by a LOCK prefix (F0H).
X
X
If any REX, F2, F3, or 66 prefixes precede a VEX prefix.
X
X
X
X
If any corresponding CPUID feature flag is ‘0’.
Device Not Avail-
X
X
X
X
If CR0.TS[bit 3]=1.
able, #NM
X
For an illegal address in the SS segment.
Stack, #SS(0)
X
If a memory address referencing the SS segment is in a non-canonical form.
X
X
X
X
Legacy SSE: Memory operand is not 16-byte aligned.
General Protec-
X
For an illegal memory operand effective address in the CS, DS, ES, FS or GS segments.
tion, #GP(0)
X
If the memory address is in a non-canonical form.
X
X
If any part of the operand lies outside the effective address space from 0 to FFFFH.
Page Fault
X
X
X
For a page fault.
#PF(fault-code)
SIMD Floating-
point Exception,
X
X
X
X
If an unmasked SIMD floating-point exception and CR4.OSXMMEXCPT[bit 10] = 1.
#XM
2-28
Vol. 2A
INSTRUCTION FORMAT
2.5.3
Exceptions Type 3 (<16 Byte Memory Argument)
Table 2-20. Type 3 Class Exception Conditions
Exception
Cause of Exception
X
X
VEX prefix.
X
X
X
X
If an unmasked SIMD floating-point exception and CR4.OSXMMEXCPT[bit 10] = 0.
VEX prefix:
X
X
If XCR0[2:1] ? ‘11b’.
If CR4.OSXSAVE[bit 18]=0.
Invalid Opcode, #UD
Legacy SSE instruction:
X
X
X
X
If CR0.EM[bit 2] = 1.
If CR4.OSFXSR[bit 9] = 0.
X
X
X
X
If preceded by a LOCK prefix (F0H).
X
X
If any REX, F2, F3, or 66 prefixes precede a VEX prefix.
X
X
X
X
If any corresponding CPUID feature flag is ‘0’.
Device Not Available,
X
X
X
X
If CR0.TS[bit 3]=1.
#NM
X
For an illegal address in the SS segment.
Stack, #SS(0)
X
If a memory address referencing the SS segment is in a non-canonical form.
For an illegal memory operand effective address in the CS, DS, ES, FS or GS seg-
X
ments.
General Protection,
X
If the memory address is in a non-canonical form.
#GP(0)
If any part of the operand lies outside the effective address space from 0 to
X
X
FFFFH.
Page Fault
X
X
X
For a page fault.
#PF(fault-code)
Alignment Check
For 2, 4, or 8 byte memory access if alignment checking is enabled and an
X
X
X
#AC(0)
unaligned memory access is made while the current privilege level is 3.
SIMD Floating-point
X
X
X
X
If an unmasked SIMD floating-point exception and CR4.OSXMMEXCPT[bit 10] = 1.
Exception, #XM
Vol. 2A
2-29
INSTRUCTION FORMAT
2.5.4
Exceptions Type 4 (>=16 Byte Mem Arg, No Alignment, No Floating-point Exceptions)
Table 2-21. Type 4 Class Exception Conditions
Exception
Cause of Exception
X
X
VEX prefix.
VEX prefix:
X
X
If XCR0[2:1] ? ‘11b’.
If CR4.OSXSAVE[bit 18]=0.
Legacy SSE instruction:
Invalid Opcode, #UD
X
X
X
X
If CR0.EM[bit 2] = 1.
If CR4.OSFXSR[bit 9] = 0.
X
X
X
X
If preceded by a LOCK prefix (F0H).
X
X
If any REX, F2, F3, or 66 prefixes precede a VEX prefix.
X
X
X
X
If any corresponding CPUID feature flag is ‘0’.
Device Not Available,
X
X
X
X
If CR0.TS[bit 3]=1.
#NM
X
For an illegal address in the SS segment.
Stack, #SS(0)
X
If a memory address referencing the SS segment is in a non-canonical form.
X
X
X
X
Legacy SSE: Memory operand is not 16-byte aligned.1
For an illegal memory operand effective address in the CS, DS, ES, FS or GS seg-
X
General Protection,
ments.
#GP(0)
X
If the memory address is in a non-canonical form.
If any part of the operand lies outside the effective address space from 0 to
X
X
FFFFH.
Page Fault
X
X
X
For a page fault.
#PF(fault-code)
NOTES:
1. LDDQU, MOVUPD, MOVUPS, PCMPESTRI, PCMPESTRM, PCMPISTRI, and PCMPISTRM instructions do not cause #GP if the memory
operand is not aligned to 16-Byte boundary.
2-30
Vol. 2A
INSTRUCTION FORMAT
2.5.5
Exceptions Type 5 (<16 Byte Mem Arg and No FP Exceptions)
Table 2-22. Type 5 Class Exception Conditions
Exception
Cause of Exception
X
X
VEX prefix.
VEX prefix:
X
X
If XCR0[2:1] ? ‘11b’.
If CR4.OSXSAVE[bit 18]=0.
Legacy SSE instruction:
Invalid Opcode, #UD
X
X
X
X
If CR0.EM[bit 2] = 1.
If CR4.OSFXSR[bit 9] = 0.
X
X
X
X
If preceded by a LOCK prefix (F0H).
X
X
If any REX, F2, F3, or 66 prefixes precede a VEX prefix.
X
X
X
X
If any corresponding CPUID feature flag is ‘0’.
Device Not Available,
X
X
X
X
If CR0.TS[bit 3]=1.
#NM
X
For an illegal address in the SS segment.
Stack, #SS(0)
X
If a memory address referencing the SS segment is in a non-canonical form.
For an illegal memory operand effective address in the CS, DS, ES, FS or GS seg-
X
ments.
General Protection,
X
If the memory address is in a non-canonical form.
#GP(0)
If any part of the operand lies outside the effective address space from 0 to
X
X
FFFFH.
Page Fault
X
X
X
For a page fault.
#PF(fault-code)
Alignment Check
For 2, 4, or 8 byte memory access if alignment checking is enabled and an
X
X
X
#AC(0)
unaligned memory access is made while the current privilege level is 3.
Vol. 2A
2-31
INSTRUCTION FORMAT
2.5.6
Exceptions Type 6 (VEX-Encoded Instructions without Legacy SSE Analogues)
Note: At present, the AVX instructions in this category do not generate floating-point exceptions.
Table 2-23. Type 6 Class Exception Conditions
Exception
Cause of Exception
X
X
VEX prefix.
If XCR0[2:1] ? ‘11b’.
X
X
If CR4.OSXSAVE[bit 18]=0.
Invalid Opcode, #UD
X
X
If preceded by a LOCK prefix (F0H).
X
X
If any REX, F2, F3, or 66 prefixes precede a VEX prefix.
X
X
If any corresponding CPUID feature flag is ‘0’.
Device Not Available,
X
X
If CR0.TS[bit 3]=1.
#NM
X
For an illegal address in the SS segment.
Stack, #SS(0)
X
If a memory address referencing the SS segment is in a non-canonical form.
For an illegal memory operand effective address in the CS, DS, ES, FS or GS seg-
General Protection,
X
ments.
#GP(0)
X
If the memory address is in a non-canonical form.
Page Fault
X
X
For a page fault.
#PF(fault-code)
Alignment Check
For 2, 4, or 8 byte memory access if alignment checking is enabled and an
X
X
#AC(0)
unaligned memory access is made while the current privilege level is 3.
2-32
Vol. 2A
INSTRUCTION FORMAT
2.5.7
Exceptions Type 7 (No FP Exceptions, No Memory Arg)
Table 2-24. Type 7 Class Exception Conditions
Exception
Cause of Exception
X
X
VEX prefix.
VEX prefix:
X
X
If XCR0[2:1] ? ‘11b’.
If CR4.OSXSAVE[bit 18]=0.
Legacy SSE instruction:
Invalid Opcode, #UD
X
X
X
X
If CR0.EM[bit 2] = 1.
If CR4.OSFXSR[bit 9] = 0.
X
X
X
X
If preceded by a LOCK prefix (F0H).
X
X
If any REX, F2, F3, or 66 prefixes precede a VEX prefix.
X
X
X
X
If any corresponding CPUID feature flag is ‘0’.
Device Not Available,
X
X
If CR0.TS[bit 3]=1.
#NM
2.5.8
Exceptions Type 8 (AVX and No Memory Argument)
Table 2-25. Type 8 Class Exception Conditions
Exception
Cause of Exception
Invalid Opcode, #UD
X
X
Always in Real or Virtual-8086 mode.
X
X
If XCR0[2:1] ? ‘11b’.
If CR4.OSXSAVE[bit 18]=0.
If CPUID.01H.ECX.AVX[bit 28]=0.
If VEX.vvvv ? 1111B.
X
X
X
X
If proceeded by a LOCK prefix (F0H).
Device Not Available,
X
X
If CR0.TS[bit 3]=1.
#NM
Vol. 2A
2-33
INSTRUCTION FORMAT
2.5.9
Exceptions Type 11 (VEX-only, Mem Arg, No AC, Floating-point Exceptions)
Table 2-26. Type 11 Class Exception Conditions
Exception
Cause of Exception
Invalid Opcode, #UD
X
X
VEX prefix.
X
X
VEX prefix:
If XCR0[2:1] ? ‘11b’.
If CR4.OSXSAVE[bit 18]=0.
X
X
X
X
If preceded by a LOCK prefix (F0H).
X
X
If any REX, F2, F3, or 66 prefixes precede a VEX prefix.
X
X
X
X
If any corresponding CPUID feature flag is ‘0’.
Device Not Avail-
X
X
X
X
If CR0.TS[bit 3]=1.
able, #NM
Stack, #SS(0)
X
For an illegal address in the SS segment.
X
If a memory address referencing the SS segment is in a non-canonical form.
General Protection,
X
For an illegal memory operand effective address in the CS, DS, ES, FS or GS seg-
#GP(0)
ments.
X
If the memory address is in a non-canonical form.
X
X
If any part of the operand lies outside the effective address space from 0 to
FFFFH.
Page Fault #PF
X
X
X
For a page fault.
(fault-code)
SIMD Floating-Point
X
X
X
X
If an unmasked SIMD floating-point exception and CR4.OSXMMEXCPT[bit 10] = 1.
Exception, #XM
2-34
Vol. 2A
INSTRUCTION FORMAT
2.5.10 Exceptions Type 12 (VEX-only, VSIB Mem Arg, No AC, No Floating-point Exceptions)
Table 2-27. Type 12 Class Exception Conditions
Exception
Cause of Exception
Invalid Opcode, #UD
X
X
VEX prefix.
X
X
VEX prefix:
If XCR0[2:1] ? ‘11b’.
If CR4.OSXSAVE[bit 18]=0.
X
X
X
X
If preceded by a LOCK prefix (F0H).
X
X
If any REX, F2, F3, or 66 prefixes precede a VEX prefix.
X
X
X
NA
If address size attribute is 16 bit.
X
X
X
X
If ModR/M.mod = ‘11b’.
X
X
X
X
If ModR/M.rm ? ‘100b’.
X
X
X
X
If any corresponding CPUID feature flag is ‘0’.
X
X
X
X
If any vector register is used more than once between the destination register,
mask register and the index register in VSIB addressing.
Device Not Available,
X
X
X
X
If CR0.TS[bit 3]=1.
#NM
Stack, #SS(0)
X
For an illegal address in the SS segment.
X
If a memory address referencing the SS segment is in a non-canonical form.
General Protection,
X
For an illegal memory operand effective address in the CS, DS, ES, FS or GS seg-
#GP(0)
ments.
X
If the memory address is in a non-canonical form.
X
X
If any part of the operand lies outside the effective address space from 0 to
FFFFH.
Page Fault #PF (fault-
X
X
X
For a page fault.
code)
2.6
VEX ENCODING SUPPORT FOR GPR INSTRUCTIONS
VEX prefix may be used to encode instructions that operate on neither YMM nor XMM registers. VEX-encoded
general-purpose-register instructions have the following properties:
Instruction syntax support for three encodable operands.
Encoding support for instruction syntax of non-destructive source operand, destination operand encoded via
VEX.vvvv, and destructive three-operand syntax.
Elimination of escape opcode byte (0FH), two-byte escape via a compact bit field representation within the VEX
prefix.
Elimination of the need to use REX prefix to encode the extended half of general-purpose register sets (R8-
R15) for direct register access or memory addressing.
Flexible and more compact bit fields are provided in the VEX prefix to retain the full functionality provided by
REX prefix. REX.W, REX.X, REX.B functionalities are provided in the three-byte VEX prefix only.
VEX-encoded GPR instructions are encoded with VEX.L=0.
Vol. 2A
2-35
INSTRUCTION FORMAT
Any VEX-encoded GPR instruction with a 66H, F2H, or F3H prefix preceding VEX will #UD.
Any VEX-encoded GPR instruction with a REX prefix proceeding VEX will #UD.
VEX-encoded GPR instructions are not supported in real and virtual 8086 modes.
2.6.1
Exceptions Type 13 (VEX-Encoded GPR Instructions)
The exception conditions applicable to VEX-encoded GPR instruction differs from those of legacy GPR instructions.
Table 2-28 lists VEX-encoded GPR instructions. The exception conditions for VEX-encoded GRP instructions are
found in Table 2-29 for those instructions which have a default operand size of 32 bits and 16-bit operand size is
not encodable.
Table 2-28. VEX-Encoded GPR Instructions
Exception Class
Instruction
Type 13
ANDN, BEXTR, BLSI, BLSMSK, BLSR, BZHI, MULX, PDEP, PEXT, RORX, SARX, SHLX, SHRX
(*) - Additional exception restrictions are present - see the Instruction description for details.
Table 2-29. Type 13 Class Exception Conditions
Exception
Cause of Exception
Invalid Opcode, #UD
X
X
X
X
If BMI1/BMI2 CPUID feature flag is ‘0’.
X
X
If a VEX prefix is present.
X
X
X
X
If VEX.L = 1.
X
X
X
X
If preceded by a LOCK prefix (F0H).
X
X
If any REX, F2, F3, or 66 prefixes precede a VEX prefix.
Stack, #SS(0)
X
X
X
For an illegal address in the SS segment.
X
If a memory address referencing the SS segment is in a non-canonical form.
General Protection,
X
For an illegal memory operand effective address in the CS, DS, ES, FS or GS seg-
#GP(0)
ments.
If the DS, ES, FS, or GS register is used to access memory and it contains a null
segment selector.
X
If the memory address is in a non-canonical form.
X
X
If any part of the operand lies outside the effective address space from 0 to
FFFFH.
Page Fault #PF(fault-
X
X
X
For a page fault.
code)
Alignment Check
X
X
X
For 2, 4, or 8 byte memory access if alignment checking is enabled and an
#AC(0)
unaligned memory access is made while the current privilege level is 3.
2.7
INTEL® AVX-512 ENCODING
The majority of the Intel AVX-512 family of instructions (operating on 512/256/128-bit vector register operands)
are encoded using a new prefix (called EVEX). Opmask instructions (operating on opmask register operands) are
encoded using the VEX prefix. The EVEX prefix has some parts resembling the instruction encoding scheme using
the VEX prefix, and many other capabilities not available with the VEX prefix.
2-36
Vol. 2A
INSTRUCTION FORMAT
The significant feature differences between EVEX and VEX are summarized below.
EVEX is a 4-Byte prefix (the first byte must be 62H); VEX is either a 2-Byte (C5H is the first byte) or 3-Byte
(C4H is the first byte) prefix.
EVEX prefix can encode 32 vector registers (XMM/YMM/ZMM) in 64-bit mode.
EVEX prefix can encode an opmask register for conditional processing or selection control in EVEX-encoded
vector instructions. Opmask instructions, whose source/destination operands are opmask registers and treat
the content of an opmask register as a single value, are encoded using the VEX prefix.
EVEX memory addressing with disp8 form uses a compressed disp8 encoding scheme to improve the encoding
density of the instruction byte stream.
EVEX prefix can encode functionality that are specific to instruction classes (e.g., packed instruction with
“load+op” semantic can support embedded broadcast functionality, floating-point instruction with rounding
semantic can support static rounding functionality, floating-point instruction with non-rounding arithmetic
semantic can support “suppress all exceptions” functionality).
2.7.1
Instruction Format and EVEX
The placement of the EVEX prefix in an IA instruction is represented in Figure 2-10. Note that the values contained
within brackets are optional.
# of bytes:
4
1
1
1
2, 4
1
[Prefixes]
EVEX
Opcode
ModR/M
[SIB]
[Disp16,32]
[Immediate]
1
[Disp8*N]
Figure 2-10. Intel® AVX-512 Instruction Format and the EVEX Prefix
The EVEX prefix is a 4-byte prefix, with the first two bytes derived from unused encoding form of the 32-bit-mode-
only BOUND instruction. The layout of the EVEX prefix is shown in Figure 2-11. The first byte must be 62H, followed
by three payload bytes, denoted as P0, P1, and P2 individually or collectively as P[23:0] (see Figure 2-11).
EVEX
62H
P0
P1
P2
7
6
5
4
3
2
1
0
R
X
B
R’
0
m
m
m
P[7:0]
P0
7
6
5
4
3
2
1
0
P1
W
v
v
v
v
1
p
p
P[15:8]
7
6
5
4
3
2
1
0
P2
z
L’
L
b
V’
a
a
a
P[23:16]
Figure 2-11. Bit Field Layout of the EVEX Prefix1
NOTES:
1. See Table 2-30 for additional details on bit fields.
Vol. 2A
2-37
INSTRUCTION FORMAT
Table 2-30. EVEX Prefix Bit Field Functional Grouping
Notation
Bit field Group
Position
Comment
EVEX.mmm
Access to up to eight decoding maps
P[2:0]
Currently, only the following decoding maps are supported: 1,
2, 3, 5, and 6.
--
Reserved
P[3]
Must be 0.
EVEX.R’
High-16 register specifier modifier
P[4]
Combine with EVEX.R and ModR/M.reg. This bit is stored in
inverted format.
EVEX.RXB
Next-8 register specifier modifier
P[7:5]
Combine with ModR/M.reg, ModR/M.rm (base, index/vidx). This
field is encoded in bit inverted format.
EVEX.X
High-16 register specifier modifier
P[6]
Combine with EVEX.B and ModR/M.rm, when SIB/VSIB absent.
EVEX.pp
Compressed legacy prefix
P[9:8]
Identical to VEX.pp.
--
Fixed Value
P[10]
Must be 1.
EVEX.vvvv
VVVV register specifier
P[14:11]
Same as VEX.vvvv. This field is encoded in bit inverted format.
EVEX.W
Operand size promotion/Opcode
P[15]
extension
EVEX.aaa
Embedded opmask register specifier
P[18:16]
EVEX.V’
High-16 VVVV/VIDX register specifier
P[19]
Combine with EVEX.vvvv or when VSIB present. This bit is
stored in inverted format.
EVEX.b
Broadcast/RC/SAE Context
P[20]
EVEX.L’L
Vector length/RC
P[22:21]
EVEX.z
Zeroing/Merging
P[23]
The bit fields in P[23:0] are divided into the following functional groups (Table 2-30 provides a tabular summary):
Reserved bits: P[3] must be 0, otherwise #UD.
Fixed-value bit: P[10] must be 1, otherwise #UD.
Compressed legacy prefix/escape bytes: P[1:0] is identical to the lowest 2 bits of VEX.mmmmm; P[9:8] is
identical to VEX.pp.
EVEX.mmm: P[2:0] provides access to up to eight decoding maps. Currently, only the following decoding maps
are supported: 1, 2, 3, 5, and 6. Map ids 1, 2, and 3 are denoted by 0F, 0F38, and 0F3A, respectively, in the
instruction encoding descriptions.
Operand specifier modifier bits for vector register, general purpose register, memory addressing: P[7:5] allows
access to the next set of 8 registers beyond the low 8 registers when combined with ModR/M register specifiers.
Operand specifier modifier bit for vector register: P[4] (or EVEX.R’) allows access to the high 16 vector register
set when combined with P[7] and ModR/M.reg specifier; P[6] can also provide access to a high 16 vector
register when SIB or VSIB addressing are not needed.
Non-destructive source /vector index operand specifier: P[19] and P[14:11] encode the second source vector
register operand in a non-destructive source syntax, vector index register operand can access an upper 16
vector register using P[19].
Op-mask register specifiers: P[18:16] encodes op-mask register set k0-k7 in instructions operating on vector
registers.
EVEX.W: P[15] is similar to VEX.W which serves either as opcode extension bit or operand size promotion to
64-bit in 64-bit mode.
Vector destination merging/zeroing: P[23] encodes the destination result behavior which either zeroes the
masked elements or leave masked element unchanged.
Broadcast/Static-rounding/SAE context bit: P[20] encodes multiple functionality, which differs across different
classes of instructions and can affect the meaning of the remaining field (EVEX.L’L). The functionality for the
following instruction classes are:
2-38
Vol. 2A
INSTRUCTION FORMAT
- Broadcasting a single element across the destination vector register: this applies to the instruction class
with Load+Op semantic where one of the source operand is from memory.
- Redirect L’L field (P[22:21]) as static rounding control for floating-point instructions with rounding
semantic. Static rounding control overrides MXCSR.RC field and implies “Suppress all exceptions” (SAE).
- Enable SAE for floating -point instructions with arithmetic semantic that is not rounding.
- For instruction classes outside of the afore-mentioned three classes, setting EVEX.b will cause #UD.
Vector length/rounding control specifier: P[22:21] can serve one of three options.
- Vector length information for packed vector instructions.
- Ignored for instructions operating on vector register content as a single data element.
- Rounding control for floating-point instructions that have a rounding semantic and whose source and
destination operands are all vector registers.
2.7.2
Register Specifier Encoding and EVEX
EVEX-encoded instruction can access 8 opmask registers, 16 general-purpose registers and 32 vector registers in
64-bit mode (8 general-purpose registers and 8 vector registers in non-64-bit modes). EVEX-encoding can support
instruction syntax that access up to 4 instruction operands. Normal memory addressing modes and VSIB memory
addressing are supported with EVEX prefix encoding. The mapping of register operands used by various instruction
syntax and memory addressing in 64-bit mode are shown in Table 2-31. Opmask register encoding is described in
Section 2.7.3.
Table 2-31. 32-Register Support in 64-bit Mode Using EVEX with Embedded REX Bits
41
3
[2:0]
Reg. Type
Common Usages
REG
EVEX.R’
REX.R
modrm.reg
GPR, Vector
Destination or Source
VVVV
EVEX.V’
EVEX.vvvv
GPR, Vector
2ndSource or Destination
RM
EVEX.X
EVEX.B
modrm.r/m
GPR, Vector
1st Source or Destination
BASE
0
EVEX.B
modrm.r/m
GPR
memory addressing
INDEX
0
EVEX.X
sib.index
GPR
memory addressing
VIDX
EVEX.V’
EVEX.X
sib.index
Vector
VSIB memory addressing
NOTES:
1. Not applicable for accessing general purpose registers.
The mapping of register operands used by various instruction syntax and memory addressing in 32-bit modes are
shown in Table 2-32.
Table 2-32. EVEX Encoding Register Specifiers in 32-bit Mode
[2:0]
Reg. Type
Common Usages
REG
modrm.reg
GPR, Vector
Destination or Source
VVVV
EVEX.vvv
GPR, Vector
2nd Source or Destination
RM
modrm.r/m
GPR, Vector
1st Source or Destination
BASE
modrm.r/m
GPR
Memory Addressing
INDEX
sib.index
GPR
Memory Addressing
VIDX
sib.index
Vector
VSIB Memory Addressing
Vol. 2A
2-39
INSTRUCTION FORMAT
2.7.3
Opmask Register Encoding
There are eight opmask registers, k0-k7. Opmask register encoding falls into two categories:
Opmask registers that are the source or destination operands of an instruction treating the content of opmask
register as a scalar value, are encoded using the VEX prefix scheme. It can support up to three operands using
standard modR/M byte’s reg field and rm field and VEX.vvvv. Such a scalar opmask instruction does not support
conditional update of the destination operand.
An opmask register providing conditional processing and/or conditional update of the destination register of a
vector instruction is encoded using EVEX.aaa field (see Section 2.7.4).
An opmask register serving as the destination or source operand of a vector instruction is encoded using
standard modR/M byte’s reg field and rm fields.
Table 2-33. Opmask Register Specifier Encoding
[2:0]
Register Access
Common Usages
REG
modrm.reg
k0-k7
Source
VVVV
VEX.vvvv
k0-k7
2nd Source
RM
modrm.r/m
k0-7
1st Source
{k1}
EVEX.aaa
k01-k7
Opmask
NOTES:
1. Instructions that overwrite the conditional mask in opmask do not permit using k0 as the embedded mask.
2.7.4
Masking Support in EVEX
EVEX can encode an opmask register to conditionally control per-element computational operation and updating of
result of an instruction to the destination operand. The predicate operand is known as the opmask register. The
EVEX.aaa field, P[18:16] of the EVEX prefix, is used to encode one out of a set of eight 64-bit architectural regis-
ters. Note that from this set of 8 architectural registers, only k1 through k7 can be addressed as predicate oper-
ands. k0 can be used as a regular source or destination but cannot be encoded as a predicate operand.
AVX-512 instructions support two types of masking with EVEX.z bit (P[23]) controlling the type of masking:
Merging-masking, which is the default type of masking for EVEX-encoded vector instructions, preserves the old
value of each element of the destination where the corresponding mask bit has a 0. It corresponds to the case
of EVEX.z = 0.
Zeroing-masking, is enabled by having the EVEX.z bit set to 1. In this case, an element of the destination is set
to 0 when the corresponding mask bit has a 0 value.
AVX-512 Foundation instructions can be divided into the following groups:
Instructions which support “zeroing-masking”.
- Also allow merging-masking.
Instructions which require aaa = 000.
- Do not allow any form of masking.
Instructions which allow merging-masking but do not allow zeroing-masking.
- Require EVEX.z to be set to 0.
- This group is mostly composed of instructions that write to memory.
Instructions which require aaa <> 000 do not allow EVEX.z to be set to 1.
— Allow merging-masking and do not allow zeroing-masking, e.g., gather instructions.
2-40
Vol. 2A
INSTRUCTION FORMAT
2.7.5
Compressed Displacement (disp8*N) Support in EVEX
For memory addressing using disp8 form, EVEX-encoded instructions always use a compressed displacement
scheme by multiplying disp8 in conjunction with a scaling factor N that is determined based on the vector length,
the value of EVEX.b bit (embedded broadcast) and the input element size of the instruction. In general, the factor
N corresponds to the number of bytes characterizing the internal memory operation of the input operand (e.g., 64
when the accessing a full 512-bit memory vector). The scale factor N is listed in Table 2-34 and Table 2-35 below,
where EVEX encoded instructions are classified using the tupletype attribute. The scale factor N of each tupletype
is listed based on the vector length (VL) and other factors affecting it.
Table 2-34 covers EVEX-encoded instructions which has a load semantic in conjunction with additional computa-
tional or data element movement operation, operating either on the full vector or half vector (due to conversion of
numerical precision from a wider format to narrower format). EVEX.b is supported for such instructions for data
element sizes which are either dword or qword (see Section 2.7.11).
EVEX-encoded instruction that are pure load/store, and “Load+op” instruction semantic that operate on data
element size less then dword do not support broadcasting using EVEX.b. These are listed in Table 2-35. Table 2-35
also includes many broadcast instructions which perform broadcast using a subset of data elements without using
EVEX.b. These instructions and a few data element size conversion instruction are covered in Table 2-35. Instruc-
tion classified in Table 2-35 do not use EVEX.b and EVEX.b must be 0, otherwise #UD will occur.
The tupletype will be referenced in the instruction operand encoding table in the reference page of each instruction,
providing the cross reference for the scaling factor N to encoding memory addressing operand.
Note that the disp8*N rules still apply when using 16b addressing.
Table 2-34. Compressed Displacement (DISP8*N) Affected by Embedded Broadcast
TupleType
EVEX.b
InputSize
EVEX.W
Broadcast
N (VL=128)
N (VL=256)
N (VL= 512)
Comment
0
32bit
0
none
16
32
64
1
32bit
0
{1tox}
4
4
4
Load+Op (Full Vector
Full
0
64bit
1
none
16
32
64
Dword/Qword)
1
64bit
1
{1tox}
8
8
8
0
32bit
0
none
8
16
32
Half
Load+Op (Half Vector)
1
32bit
0
{1tox}
4
4
4
Table 2-35. EVEX DISP8*N for Instructions Not Affected by Embedded Broadcast
TupleType
InputSize
EVEX.W
N (VL= 128)
N (VL= 256)
N (VL= 512)
Comment
Full Mem
N/A
N/A
16
32
64
Load/store or subDword full vector
8bit
N/A
1
1
1
16bit
N/A
2
2
2
Tuple1 Scalar
1Tuple
32bit
0
4
4
4
64bit
1
8
8
8
32bit
N/A
4
4
4
1 Tuple, memsize not affected by
Tuple1 Fixed
64bit
N/A
8
8
8
EVEX.W
32bit
0
8
8
8
Tuple2
Broadcast (2 elements)
64bit
1
NA
16
16
32bit
0
NA
16
16
Tuple4
Broadcast (4 elements)
64bit
1
NA
NA
32
Tuple8
32bit
0
NA
NA
32
Broadcast (8 elements)
Half Mem
N/A
N/A
8
16
32
SubQword Conversion
Quarter Mem
N/A
N/A
4
8
16
SubDword Conversion
Vol. 2A
2-41
INSTRUCTION FORMAT
Table 2-35. EVEX DISP8*N for Instructions Not Affected by Embedded Broadcast (Contd.)
TupleType
InputSize
EVEX.W
N (VL= 128)
N (VL= 256)
N (VL= 512)
Comment
Eighth Mem
N/A
N/A
2
4
8
SubWord Conversion
Mem128
N/A
N/A
16
16
16
Shift count from memory
MOVDDUP
N/A
N/A
8
32
64
VMOVDDUP
2.7.6
EVEX Encoding of Broadcast/Rounding/SAE Support
EVEX.b can provide three types of encoding context, depending on the instruction classes:
Embedded broadcasting of one data element from a source memory operand to the destination for vector
instructions with “load+op” semantic.
Static rounding control overriding MXCSR.RC for floating-point instructions with rounding semantic.
“Suppress All exceptions” (SAE) overriding MXCSR mask control for floating-point arithmetic instructions that
do not have rounding semantic.
2.7.7
Embedded Broadcast Support in EVEX
EVEX encodes an embedded broadcast functionality that is supported on many vector instructions with 32-bit
(double word or single precision floating-point) and 64-bit data elements, and when the source operand is from
memory. EVEX.b (P[20]) bit is used to enable broadcast on load-op instructions. When enabled, only one element
is loaded from memory and broadcasted to all other elements instead of loading the full memory size.
The following instruction classes do not support embedded broadcasting:
Instructions with only one scalar result is written to the vector destination.
Instructions with explicit broadcast functionality provided by its opcode.
Instruction semantic is a pure load or a pure store operation.
2.7.8
Static Rounding Support in EVEX
Static rounding control embedded in the EVEX encoding system applies only to register-to-register flavor of
floating-point instructions with rounding semantic at two distinct vector lengths: (i) scalar, (ii) 512-bit. In both
cases, the field EVEX.L’L expresses rounding mode control overriding MXCSR.RC if EVEX.b is set. When EVEX.b is
set, “suppress all exceptions” is implied. The processor behaves as if all MXCSR masking controls are set.
2.7.9
SAE Support in EVEX
The EVEX encoding system allows arithmetic floating-point instructions without rounding semantic to be encoded
with the SAE attribute. This capability applies to scalar and 512-bit vector lengths, register-to-register only, by
setting EVEX.b. When EVEX.b is set, “suppress all exceptions” is implied. The processor behaves as if all MXCSR
masking controls are set.
2.7.10 Vector Length Orthogonality
The architecture of EVEX encoding scheme can support SIMD instructions operating at multiple vector lengths.
Many AVX-512 Foundation instructions operate at 512-bit vector length. The vector length of EVEX encoded vector
instructions are generally determined using the L’L field in EVEX prefix, except for 512-bit floating-point, reg-reg
instructions with rounding semantic. The table below shows the vector length corresponding to various values of
the L’L bits. When EVEX is used to encode scalar instructions, L’L is generally ignored.
When EVEX.b bit is set for a register-register instructions with floating-point rounding semantic, the same two bits
P2[6:5] specifies rounding mode for the instruction, with implied SAE behavior. The mapping of different instruc-
tion classes relative to the embedded broadcast/rounding/SAE control and the EVEX.L’L fields are summarized in
Table 2-36.
2-42
Vol. 2A
INSTRUCTION FORMAT
Table 2-36. EVEX Embedded Broadcast/Rounding/SAE and Vector Length on Vector Instructions
Position
P2[4]
P2[6:5]
P2[6:5]
Broadcast/Rounding/SAE Context
EVEX.b
EVEX.L’L
EVEX.RC
Reg-reg, FP Instructions w/ rounding semantic or SAE
Enable static rounding
Vector length Implied
00b: SAE + RNE
control (SAE implied)
(512 bit or scalar)
01b: SAE + RD
10b: SAE + RU
11b: SAE + RZ
Load+op Instructions w/ memory source
Broadcast Control
00b: 128-bit
NA
01b: 256-bit
Other Instructions (
Must be 0 (otherwise
NA
10b: 512-bit
Explicit Load/Store/Broadcast/Gather/Scatter)
#UD)
11b: Reserved (#UD)
2.7.11 #UD Equations for EVEX
Instructions encoded using EVEX can face three types of UD conditions: state dependent, opcode independent and
opcode dependent.
2.7.11.1 State Dependent #UD
In general, attempts of execute an instruction, which required OS support for incremental extended state compo-
nent, will #UD if required state components were not enabled by OS. Table 2-37 lists instruction categories with
respect to required processor state components. Attempts to execute a given category of instructions while
enabled states were less than the required bit vector in XCR0 shown in Table 2-37 will cause #UD.
Table 2-37. OS XSAVE Enabling Requirements of Instruction Categories
Instruction Categories
Vector Register State Access
Required XCR0 Bit Vector [7:0]
Legacy SIMD prefix encoded Instructions (e.g SSE)
XMM
xxxxxx11b
VEX-encoded instructions operating on YMM
YMM
xxxxx111b
EVEX-encoded 128-bit instructions
ZMM
111xx111b
EVEX-encoded 256-bit instructions
ZMM
111xx111b
EVEX-encoded 512-bit instructions
ZMM
111xx111b
VEX-encoded instructions operating on opmask
k-reg
111xxx11b
2.7.11.2 Opcode Independent #UD
A number of bit fields in EVEX encoded instruction must obey mode-specific but opcode-independent patterns
listed in Table 2-38.
Table 2-38. Opcode Independent, State Dependent EVEX Bit Fields
Position
Notation
64-bit #UD
Non-64-bit #UD
P[3]
--
if > 0
if > 0
P[10]
--
if 0
if 0
P[2:0]
EVEX.mmm
if 000b, 100b, or 111b
if 000b, 100b, or 111b
P[7 : 6]
EVEX.RX
None (valid)
None (BOUND if EVEX.RX != 11b)
Vol. 2A
2-43
INSTRUCTION FORMAT
2.7.11.3 Opcode Dependent #UD
This section describes legal values for the rest of the EVEX bit fields. Table 2-39 lists the #UD conditions of EVEX
prefix bit fields which encodes or modifies register operands.
Table 2-39. #UD Conditions of Operand-Encoding EVEX Prefix Bit Fields
Notation
Position
Operand Encoding
64-bit #UD
Non-64-bit #UD
EVEX.R
P[7]
ModRM.reg encodes k-reg
If EVEX.R = 0
None (BOUND if
EVEX.RX != 11b)
ModRM.reg is opcode extension
None (ignored)
ModRM.reg encodes all other registers
None (valid)
EVEX.X
P[6]
ModRM.r/m encodes ZMM/YMM/XMM
None (valid)
ModRM.r/m encodes k-reg or GPR
None (ignored)
ModRM.r/m without SIB/VSIB
None (ignored)
ModRM.r/m with SIB/VSIB
None (valid)
EVEX.B
P[5]
ModRM.r/m encodes k-reg
None (ignored)
None (ignored)
ModRM.r/m encodes other registers
None (valid)
ModRM.r/m base present
None (valid)
ModRM.r/m base not present
None (ignored)
EVEX.R’
P[4]
ModRM.reg encodes k-reg or GPR
If 0
None (ignored)
ModRM.reg is opcode extension
None (ignored)
ModRM.reg encodes ZMM/YMM/XMM
None (valid)
EVEX.vvvv
P[14:11]
vvvv encodes ZMM/YMM/XMM
None (valid)
None (valid)
P[14] ignored
Otherwise
If != 1111b
If != 1111b
EVEX.V’
P[19]
Encodes ZMM/YMM/XMM
None (valid)
If 0
Otherwise
If 0
If 0
Table 2-40 lists the #UD conditions of instruction encoding of opmask register using EVEX.aaa and EVEX.z
Table 2-40. #UD Conditions of Opmask Related Encoding Field
Notation
Position
Operand Encoding
64-bit #UD
Non-64-bit #UD
EVEX.aaa
P[18:16]
Instructions do not use opmask for conditional processing1.
If aaa != 000b
If aaa != 000b
Opmask used as conditional processing mask and updated
If aaa = 000b
If aaa = 000b;
at completion2.
Opmask used as conditional processing.
None (valid3)
None (valid1)
EVEX.z
P[23]
Vector instruction using opmask as source or destination4.
If EVEX.z != 0
If EVEX.z != 0
Store instructions or gather/scatter instructions.
If EVEX.z != 0
If EVEX.z != 0
Instructions with EVEX.aaa = 000b.
If EVEX.z != 0
If EVEX.z != 0
VEX.vvvv
Varies
K-regs are instruction operands not mask control.
If vvvv = 0xxxb
None
NOTES:
1. E.g., VPBROADCASTMxxx, VPMOVM2x, VPMOVx2M.
2. E.g., Gather/Scatter family.
3. aaa can take any value. A value of 000 indicates that there is no masking on the instruction; in this case, all elements will be pro-
cessed as if there was a mask of ‘all ones’ regardless of the actual value in K0.
4. E.g., VFPCLASSPD/PS, VCMPB/D/Q/W family, VPMOVM2x, VPMOVx2M.
2-44
Vol. 2A
INSTRUCTION FORMAT
Table 2-41 lists the #UD conditions of EVEX bit fields that depends on the context of EVEX.b.
Table 2-41. #UD Conditions Dependent on EVEX.b Context
Notation
Position
Operand Encoding
64-bit #UD
Non-64-bit #UD
EVEX.L’Lb
P[22 : 20]
Reg-reg, FP instructions with rounding semantic.
None (valid1)
None (valid1)
Other reg-reg, FP instructions that can cause #XM.
None (valid2)
None (valid2)
Other reg-mem instructions in Table 2-34.
None (valid3)
None (valid3)
Other instruction classes4 in Table 2-35.
If EVEX.b = 1
If EVEX.b = 1
NOTES:
1. L’L specifies rounding control, see Table 2-36, supports {er} syntax.
2. L’L is ignored.
3. L’L specifies vector length, see Table 2-36, supports embedded broadcast syntax
4. L’L specifies either vector length or ignored.
2.7.12 Device Not Available
EVEX-encoded instructions follow the same rules when it comes to generating #NM (Device Not Available) excep-
tion. In particular, it is generated when CR0.TS[bit 3]= 1.
2.7.13 Scalar Instructions
EVEX-encoded scalar SIMD instructions can access up to 32 registers in 64-bit mode. Scalar instructions support
masking (using the least significant bit of the opmask register), but broadcasting is not supported.
2.8
EXCEPTION CLASSIFICATIONS OF EVEX-ENCODED INSTRUCTIONS
The exception behavior of EVEX-encoded instructions can be classified into the classes shown in the rest of this
section. The classification of EVEX-encoded instructions follow a similar framework as those of AVX and AVX2
instructions using the VEX prefix. Exception types for EVEX-encoded instructions are named in the style of
“E##” or with a suffix “E##XX”. The “##” designation generally follows that of AVX/AVX2 instructions. The
majority of EVEX encoded instruction with “Load+op” semantic supports memory fault suppression, which is repre-
sented by E##. The instructions with “Load+op” semantic but do not support fault suppression are named
“E##NF”. A summary table of exception classes by class names are shown below.
Table 2-42. EVEX-Encoded Instruction Exception Class Summary
Exception Class
Instruction set
Mem arg
(#XM)
Type E1
Vector Moves/Load/Stores
Explicitly aligned, w/ fault suppression
None
Type E1NF
Vector Non-temporal Stores
Explicitly aligned, no fault suppression
None
Type E2
FP Vector Load+op
Support fault suppression
Yes
Type E2NF
FP Vector Load+op
No fault suppression
Yes
Type E3
FP Scalar/Partial Vector, Load+Op
Support fault suppression
Yes
Type E3NF
FP Scalar/Partial Vector, Load+Op
No fault suppression
Yes
Type E4
Integer Vector Load+op
Support fault suppression
No
Type E4NF
Integer Vector Load+op
No fault suppression
No
Type E5
Legacy-like Promotion
Varies, Support fault suppression
No
Type E5NF
Legacy-like Promotion
Varies, No fault suppression
No
Vol. 2A
2-45
INSTRUCTION FORMAT
Table 2-42. EVEX-Encoded Instruction Exception Class Summary (Contd.)
Exception Class
Instruction set
Mem arg
(#XM)
Type E6
Post AVX Promotion
Varies, w/ fault suppression
No
Type E6NF
Post AVX Promotion
Varies, no fault suppression
No
Type E7NM
Register-to-register op
None
None
Type E9NF
Miscellaneous 128-bit
Vector-length Specific, no fault suppression
None
Type E10
Non-XF Scalar
Vector Length ignored, w/ fault suppression
None
Type E10NF
Non-XF Scalar
Vector Length ignored, no fault suppression
None
Type E11
VCVTPH2PS, VCVTPS2PH
Half Vector Length, w/ fault suppression
Yes
Type E12
Gather and Scatter Family
VSIB addressing, w/ fault suppression
None
Type E12NP
Gather and Scatter Prefetch Family
VSIB addressing, w/o page fault
None
Table 2-43 lists EVEX-encoded instruction mnemonic by exception classes.
Table 2-43. EVEX Instructions in Each Exception Class
Exception Class
Instruction
Type E1
VMOVAPD, VMOVAPS, VMOVDQA32, VMOVDQA64
Type E1NF
VMOVNTDQ, VMOVNTDQA, VMOVNTPD, VMOVNTPS
VADDPD, VADDPH, VADDPS, VCMPPD, VCMPPH, VCMPPS, VCVTDQ2PH, VCVTDQ2PS, VCVTPD2DQ, VCVTPD2PH,
VCVTPD2PS, VCVTPD2QQ, VCVTPD2UQQ, VCVTPD2UDQ, VCVTPH2DQ, VCVTPH2PD, VCVTPH2QQ, VCVTPH2UDQ,
VCVTPH2UQQ, VCVTPH2UW, VCVTPH2W, VCVTPS2DQ, VCVTPS2UDQS, VCVTQQ2PD, VCVTQQ2PH, VCVTQQ2PS,
VCVTTPD2DQ, VCVTTPD2QQ, VCVTTPD2UDQ, VCVTTPD2UQQ, VCVTTPH2DQ, VCVTTPH2QQ, VCVTTPH2UDQ,
VCVTTPH2UQQ, VCVTTPH2UW, VCVTTPH2W, VCVTTPS2DQ, VCVTTPS2UDQ, VCVTUDQ2PH, VCVTUDQ2PS,
VCVTUQQ2PD, VCVTUQQ2PH, VCVTUQQ2PS, VCVTUW2PH, VCVTW2PH, VDIVPD, VDIVPH, VDIVPS, VEXP2PD,
VEXP2PS, VFIXUPIMMPD, VFIXUPIMMPS, VFMADDxxxPD, VFMADDxxxPH, VFMADDxxxPS, VFMADDSUBxxxPD,
Type E2
VFMADDSUBxxxPH, VFMADDSUBxxxPS, VFMSUBADDxxxPD, VFMSUBADDxxxPH, VFMSUBADDxxxPS,
VFMSUBxxxPD, VFMSUBxxxPH, VFMSUBxxxPS, VFNMADDxxxPD, VFNMADDxxxPH, VFNMADDxxxPS,
VFNMSUBxxxPD, VFNMSUBxxxPH, VFNMSUBxxxPS, VGETEXPPD, VGETEXPPH, VGETEXPPS, VGETMANTPD,
VGETMANTPH, VGETMANTPS, VGETMANTSH, VMAXPD, VMAXPH, VMAXPS, VMINPD, VMINPH, VMINPS, VMULPD,
VMULPH, VMULPS, VRANGEPD, VRANGEPS, VREDUCEPD, VREDUCEPH, VREDUCEPS, VRNDSCALEPD,
VRNDSCALEPH, VRNDSCALEPS, VRCP28PD, VRCP28PS, VRSQRT28PD, VRSQRT28PS, VSCALEFPD, VSCALEFPS,
VSQRTPD, VSQRTPH, VSQRTPS, VSUBPD, VSUBPH, VSUBPS
VADDSD, VADDSH, VADDSS, VCMPSD, VCMPSH, VCMPSS, VCVTPS2QQ, VCVTPS2UQQ, VCVTPS2PD, VCVTSD2SH,
VCVTSD2SS, VCVTSH2SD, VCVTSH2SS, VCVTSS2SD, VCVTSS2SH, VCVTTPS2QQ, VCVTTPS2UQQ, VDIVSD, VDIVSH,
VDIVSS, VFMADDxxxSD, VFMADDxxxSH, VFMADDxxxSS, VFMSUBxxxSD, VFMSUBxxxSH, VFMSUBxxxSS,
VFNMADDxxxSD, VFNMADDxxxSH, VFNMADDxxxSS, VFNMSUBxxxSD, VFNMSUBxxxSH, VFNMSUBxxxSS,
Type E3
VFIXUPIMMSD, VFIXUPIMMSS, VGETEXPSD, VGETEXPSH, VGETEXPSS, VGETMANTSD, VGETMANTSH,
VGETMANTSS, VMAXSD, VMAXSH, VMAXSS, VMINSD, VMINSH, VMINSS, VMULSD, VMULSH, VMULSS, VRANGESD,
VRANGESS, VREDUCESD, VREDUCESH, VREDUCESS, VRNDSCALESD, VRNDSCALESH, VRNDSCALESS, VSCALEFSD,
VSCALEFSH, VSCALEFSS, VRCP28SD, VRCP28SS, VRSQRT28SD, VRSQRT28SS, VSQRTSD, VSQRTSH, VSQRTSS,
VSUBSD, VSUBSH, VSUBSS
VCOMISD, VCOMISH, VCOMISS, VCVTSD2SI, VCVTSD2USI, VCVTSH2SI, VCVTSH2USI, VCVTSI2SD, VCVTSI2SH,
Type E3NF
VCVTSI2SS, VCVTSS2SI, VCVTSS2USI, VCVTTSD2SI, VCVTTSD2USI, VCVTTSH2SI, VCVTTSH2USI, VCVTTSS2SI,
VCVTTSS2USI, VCVTUSI2SD, VCVTUSI2SH, VCVTUSI2SS, VUCOMISD, VUCOMISH, VUCOMISS
2-46
Vol. 2A
INSTRUCTION FORMAT
Table 2-43. EVEX Instructions in Each Exception Class (Contd.)
Exception Class
Instruction
VANDPD, VANDPS, VANDNPD, VANDNPS, VBLENDMPD, VBLENDMPS, VFCMADDCPH, VFCMULCPH, VFMADDCPH,
VFMULCPH, VFPCLASSPD, VFPCLASSPH, VFPCLASSPS, VORPD, VORPS, VPABSD, VPABSQ, VPADDD, VPADDQ,
VPANDD, VPANDQ, VPANDND, VPANDNQ, VPBLENDMB, VPBLENDMD, VPBLENDMQ, VPBLENDMW, VPCMPD,
VPCMPEQD, VPCMPEQQ, VPCMPGTD, VPCMPGTQ, VPCMPQ, VPCMPUD, VPCMPUQ, VPLZCNTD, VPLZCNTQ,
VPMADD52LUQ, VPMADD52HUQ, VPMAXSD, VPMAXSQ, VPMAXUD, VPMAXUQ, VPMINSD, VPMINSQ, VPMINUD,
Type E4
VPMINUQ, VPMULLD, VPMULLQ, VPMULUDQ, VPMULDQ, VPORD, VPORQ, VPROLD, VPROLQ, VPROLVD, VPROLVQ,
VPRORD, VPRORQ, VPRORVD, VPRORVQ, (VPSLLD, VPSLLQ, VPSRAD, VPSRAQ, VPSRAVW, VPSRAVD, VPSRAVW,
VPSRAVQ, VPSRLD, VPSRLQ)1, VPSUBD, VPSUBQ, VPSUBUSB, VPSUBUSW, VPTERNLOGD, VPTERNLOGQ,
VPTESTMD, VPTESTMQ, VPTESTNMD, VPTESTNMQ, VPXORD, VPXORQ, VPSLLVD, VPSLLVQ, VRCP14PD,
VRCP14PS, VRCPPH, VRSQRT14PD, VRSQRT14PS, VRSQRTPH, VXORPD, VXORPS
VCOMPRESSPD, VCOMPRESSPS, VEXPANDPD, VEXPANDPS, VMOVDQU8, VMOVDQU16, VMOVDQU32,
VMOVDQU64, VMOVUPD, VMOVUPS, VPABSB, VPABSW, VPADDB, VPADDW, VPADDSB, VPADDSW, VPADDUSB,
VPADDUSW, VPAVGB, VPAVGW, VPCMPB, VPCMPEQB, VPCMPEQW, VPCMPGTB, VPCMPGTW, VPCMPW, VPCMPUB,
E4.nb2
VPCMPUW, VPCOMPRESSD, VPCOMPRESSQ, VPEXPANDD, VPEXPANDQ, VPMAXSB, VPMAXSW, VPMAXUB,
VPMAXUW, VPMINSB, VPMINSW, VPMINUB, VPMINUW, VPMULHRSW, VPMULHUW, VPMULHW, VPMULLW,
VPSLLVW, VPSLLW, VPSRAW, VPSRLVW, VPSRLW, VPSUBB, VPSUBW, VPSUBSB, VPSUBSW, VPTESTMB,
VPTESTMW, VPTESTNMB, VPTESTNMW
VALIGND, VALIGNQ, VPACKSSDW, VPACKUSDW, VPCONFLICTD, VPCONFLICTQ, VPERMD, VPERMI2D, VPERMI2PS,
VPERMI2PD, VPERMI2Q, VPERMPD, VPERMPS, VPERMQ, VPERMT2D, VPERMT2PS, VPERMT2Q, VPERMT2PD,
Type E4NF
VPERMILPD, VPERMILPS, VPMULTISHIFTQB, VPSHUFD, VPUNPCKHDQ, VPUNPCKHQDQ, VPUNPCKLDQ,
VPUNPCKLQDQ, VSHUFF32X4, VSHUFF64X2, VSHUFI32X4, VSHUFI64X2, VSHUFPD, VSHUFPS, VUNPCKHPD,
VUNPCKHPS, VUNPCKLPD, VUNPCKLPS
VDBPSADBW, VPACKSSWB, VPACKUSWB, VPALIGNR, VPMADDWD, VPMADDUBSW, VMOVSHDUP, VMOVSLDUP,
VPSADBW, VPSHUFB, VPSHUFHW, VPSHUFLW, VPSLLDQ, VPSRLDQ, VPSLLW, VPSRAW, VPSRLW, (VPSLLD,
E4NF.nb2
VPSLLQ, VPSRAD, VPSRAQ, VPSRLD, VPSRLQ)3, VPUNPCKHBW, VPUNPCKHWD, VPUNPCKLBW, VPUNPCKLWD,
VPERMW, VPERMI2W, VPERMT2W
PMOVSXBW, PMOVSXBW, PMOVSXBD, PMOVSXBQ, PMOVSXWD, PMOVSXWQ, PMOVSXDQ, PMOVZXBW,
Type E5
PMOVZXBD, PMOVZXBQ, PMOVZXWD, PMOVZXWQ, PMOVZXDQ, VCVTDQ2PD, VCVTUDQ2PD, VMOVSH,
VPMOVSXxx, VPMOVZXxx,
Type E5NF
VMOVDDUP
VBROADCASTF32X2, VBROADCASTF32X4, VBROADCASTF64X2, VBROADCASTF32X8, VBROADCASTF64X4,
VBROADCASTI32X2, VBROADCASTI32X4, VBROADCASTI64X2, VBROADCASTI32X8, VBROADCASTI64X4,
VBROADCASTSD, VBROADCASTSS, VFPCLASSSD, VFPCLASSSS, VPBROADCASTB, VPBROADCASTD,
Type E6
VPBROADCASTW, VPBROADCASTQ, VPMOVQB, VPMOVSQB, VPMOVUSQB, VPMOVQW, VPMOVSQW, VPMOVUSQW,
VPMOVQD, VPMOVSQD, VPMOVUSQD, VPMOVDB, VPMOVSDB, VPMOVUSDB, VPMOVDW, VPMOVSDW,
VPMOVUSDW, VPMOVWB, VPMOVSWB, VPMOVUSWB
VEXTRACTF32X4, VEXTRACTF32X8, VEXTRACTF64X2, VEXTRACTF64X4, VEXTRACTI32X4, VEXTRACTI32X8,
Type E6NF
VEXTRACTI64X2, VEXTRACTI64X4, VINSERTF32X4, VINSERTF32X8, VINSERTF64X2, VINSERTF64X4,
VINSERTI32X4, VINSERTI32X8, VINSERTI64X2, VINSERTI64X4, VPBROADCASTMB2Q, VPBROADCASTMW2D
Type
VMOVHLPS, VMOVLHPS
E7NM.1284
(VPBROADCASTD, VPBROADCASTQ, VPBROADCASTB, VPBROADCASTW)5, VPMOVB2M, VPMOVD2M, VPMOVM2B,
Type E7NM.
VPMOVM2D, VPMOVM2Q, VPMOVM2W, VPMOVQ2M, VPMOVW2M
VEXTRACTPS, VINSERTPS, VMOVHPD, VMOVHPS, VMOVLPD, VMOVLPS, VMOVD, VMOVQ, VMOVW, VPEXTRB,
Type E9NF
VPEXTRD, VPEXTRW, VPEXTRQ, VPINSRB, VPINSRD, VPINSRW, VPINSRQ
VFCMADDCSH, VFMADDCSH, VFCMULCSH, VFMULCSH, VFPCLASSSH, VMOVSD, VMOVSS, VRCP14SD, VRCP14SS,
Type E10
VRCPSH, VRSQRT14SD, VRSQRT14SS, VRSQRTSH
Type E10NF
(VCVTSI2SD, VCVTUSI2SD)6
Type E11
VCVTPH2PS, VCVTPS2PH
Vol. 2A
2-47
INSTRUCTION FORMAT
Table 2-43. EVEX Instructions in Each Exception Class (Contd.)
Exception Class
Instruction
VGATHERDPS, VGATHERDPD, VGATHERQPS, VGATHERQPD, VPGATHERDD, VPGATHERDQ, VPGATHERQD,
Type E12
VPGATHERQQ, VPSCATTERDD, VPSCATTERDQ, VPSCATTERQD, VPSCATTERQQ, VSCATTERDPD, VSCATTERDPS,
VSCATTERQPD, VSCATTERQPS
VGATHERPF0DPD, VGATHERPF0DPS, VGATHERPF0QPD, VGATHERPF0QPS, VGATHERPF1DPD, VGATHERPF1DPS,
Type E12NP
VGATHERPF1QPD, VGATHERPF1QPS, VSCATTERPF0DPD, VSCATTERPF0DPS, VSCATTERPF0QPD,
VSCATTERPF0QPS, VSCATTERPF1DPD, VSCATTERPF1DPS, VSCATTERPF1QPD, VSCATTERPF1QPS
NOTES:
1. Operand encoding Full tupletype with immediate.
2. Embedded broadcast is not supported with the “.nb” suffix.
3. Operand encoding Mem128 tupletype.
4. #UD raised if EVEX.L’L !=00b (VL=128).
5. The source operand is a general purpose register.
6. W0 encoding only.
2-48
Vol. 2A
INSTRUCTION FORMAT
2.8.1
Exceptions Type E1 and E1NF of EVEX-Encoded Instructions
EVEX-encoded instructions with memory alignment restrictions, and supporting memory fault suppression follow
exception class E1.
Table 2-44. Type E1 Class Exception Conditions
Exception
Cause of Exception
X
X
If EVEX prefix present.
If CR4.OSXSAVE[bit 18]=0.
If any one of following conditions applies:
• State requirement, Table 2-37 not met.
• Opcode independent #UD condition in Table 2-38.
X
X
• Operand encoding #UD conditions in Table 2-39.
Invalid Opcode,
• Opmask encoding #UD condition of Table 2-40.
#UD
• EVEX.b encoding #UD condition of Table 2-41.
• Instruction specific EVEX.L'L restriction not met.
X
X
X
X
If preceded by a LOCK prefix (F0H).
X
X
If any REX, F2, F3, or 66 prefixes precede a EVEX prefix.
X
X
X
X
If any corresponding CPUID feature flag is ‘0’.
Device Not Avail-
X
X
X
X
If CR0.TS[bit 3]=1.
able, #NM
X
If fault suppression not set, and an illegal address in the SS segment.
Stack, #SS(0)
If fault suppression not set, and a memory address referencing the SS segment is in
X
a non-canonical form.
EVEX.512: Memory operand is not 64-byte aligned.
X
X
EVEX.256: Memory operand is not 32-byte aligned.
EVEX.128: Memory operand is not 16-byte aligned.
If fault suppression not set, and an illegal memory operand effective address in the
General Protection,
X
#GP(0)
CS, DS, ES, FS or GS segments.
X
If fault suppression not set, and the memory address is in a non-canonical form.
If fault suppression not set, and any part of the operand lies outside the effective
X
X
address space from 0 to FFFFH.
Page Fault
X
X
X
If fault suppression not set, and a page fault.
#PF(fault-code)
Vol. 2A
2-49
INSTRUCTION FORMAT
EVEX-encoded instructions with memory alignment restrictions, but do not support memory fault suppression
follow exception class E1NF.
Table 2-45. Type E1NF Class Exception Conditions
Exception
Cause of Exception
X
X
If EVEX prefix present.
If CR4.OSXSAVE[bit 18]=0.
If any one of following conditions applies:
• State requirement, Table 2-37 not met.
• Opcode independent #UD condition in Table 2-38.
X
X
• Operand encoding #UD conditions in Table 2-39.
Invalid Opcode,
• Opmask encoding #UD condition of Table 2-40.
#UD
• EVEX.b encoding #UD condition of Table 2-41.
• Instruction specific EVEX.L'L restriction not met.
X
X
X
X
If preceded by a LOCK prefix (F0H).
X
X
If any REX, F2, F3, or 66 prefixes precede a EVEX prefix.
X
X
X
X
If any corresponding CPUID feature flag is ‘0’.
Device Not Avail-
X
X
X
X
If CR0.TS[bit 3]=1.
able, #NM
X
For an illegal address in the SS segment.
Stack, #SS(0)
X
If a memory address referencing the SS segment is in a non-canonical form.
EVEX.512: Memory operand is not 64-byte aligned.
X
X
EVEX.256: Memory operand is not 32-byte aligned.
EVEX.128: Memory operand is not 16-byte aligned.
General Protection,
For an illegal memory operand effective address in the CS, DS, ES, FS or GS seg-
X
#GP(0)
ments.
X
If the memory address is in a non-canonical form.
X
X
If any part of the operand lies outside the effective address space from 0 to FFFFH.
Page Fault
X
X
X
For a page fault.
#PF(fault-code)
2-50
Vol. 2A
INSTRUCTION FORMAT
2.8.2
Exceptions Type E2 of EVEX-Encoded Instructions
EVEX-encoded vector instructions with arithmetic semantic follow exception class E2.
Table 2-46. Type E2 Class Exception Conditions
Exception
Cause of Exception
X
X
If EVEX prefix present.
X
X
X
X
If an unmasked SIMD floating-point exception and CR4.OSXMMEXCPT[bit 10] = 0.
If CR4.OSXSAVE[bit 18]=0.
If any one of following conditions applies:
• State requirement, Table 2-37 not met.
Invalid Opcode,
X
X
• Opcode independent #UD condition in Table 2-38.
#UD
• Operand encoding #UD conditions in Table 2-39.
• Opmask encoding #UD condition of Table 2-40.
• Instruction specific EVEX.L'L restriction not met.
X
X
X
X
If preceded by a LOCK prefix (F0H).
X
X
If any REX, F2, F3, or 66 prefixes precede a EVEX prefix.
X
X
X
X
If any corresponding CPUID feature flag is ‘0’.
Device Not Avail-
X
X
X
X
If CR0.TS[bit 3]=1.
able, #NM
X
If fault suppression not set, and an illegal address in the SS segment.
Stack, #SS(0)
If fault suppression not set, and a memory address referencing the SS segment is in a
X
non-canonical form.
If fault suppression not set, and an illegal memory operand effective address in the CS,
X
DS, ES, FS or GS segments.
General Protec-
X
If fault suppression not set, and the memory address is in a non-canonical form.
tion, #GP(0)
If fault suppression not set, and any part of the operand lies outside the effective
X
X
address space from 0 to FFFFH.
Page Fault
X
X
X
If fault suppression not set, and a page fault.
#PF(fault-code)
Alignment Check
For 2, 4, or 8 byte memory access if alignment checking is enabled and an unaligned
X
X
X
#AC(0)
memory access is made while the current privilege level is 3.
SIMD Floating-
If an unmasked SIMD floating-point exception, {sae} or {er} not set, and CR4.OSXMMEX-
point Exception,
X
X
X
X
CPT[bit 10] = 1.
#XM
Vol. 2A
2-51
INSTRUCTION FORMAT
2.8.3
Exceptions Type E3 and E3NF of EVEX-Encoded Instructions
EVEX-encoded scalar instructions with arithmetic semantic that support memory fault suppression follow exception
class E3.
Table 2-47. Type E3 Class Exception Conditions
Exception
Cause of Exception
X
X
If EVEX prefix present.
X
X
X
X
If an unmasked SIMD floating-point exception and CR4.OSXMMEXCPT[bit 10] = 0.
If CR4.OSXSAVE[bit 18]=0.
If any one of following conditions applies:
• State requirement, Table 2-37 not met.
X
X
• Opcode independent #UD condition in Table 2-38.
Invalid Opcode, #UD
• Operand encoding #UD conditions in Table 2-39.
• Opmask encoding #UD condition of Table 2-40.
• EVEX.b encoding #UD condition of Table 2-41.
X
X
X
X
If preceded by a LOCK prefix (F0H).
X
X
If any REX, F2, F3, or 66 prefixes precede a EVEX prefix.
X
X
X
X
If any corresponding CPUID feature flag is ‘0’.
Device Not Available,
X
X
X
X
If CR0.TS[bit 3]=1.
#NM
X
If fault suppression not set, and an illegal address in the SS segment.
Stack, #SS(0)
If fault suppression not set, and a memory address referencing the SS segment is
X
in a non-canonical form.
If fault suppression not set, and an illegal memory operand effective address in
X
the CS, DS, ES, FS or GS segments.
General Protection,
X
If fault suppression not set, and the memory address is in a non-canonical form.
#GP(0)
If fault suppression not set, and any part of the operand lies outside the effective
X
X
address space from 0 to FFFFH.
Page Fault #PF(fault-
X
X
X
If fault suppression not set, and a page fault.
code)
Alignment Check
For 2, 4, or 8 byte memory access if alignment checking is enabled and an
X
X
X
#AC(0)
unaligned memory access is made while the current privilege level is 3.
SIMD Floating-point
If an unmasked SIMD floating-point exception, {sae} or {er} not set, and CR4.OSX-
X
X
X
X
Exception, #XM
MMEXCPT[bit 10] = 1.
2-52
Vol. 2A
INSTRUCTION FORMAT
EVEX-encoded scalar instructions with arithmetic semantic that do not support memory fault suppression follow
exception class E3NF.
Table 2-48. Type E3NF Class Exception Conditions
Exception
Cause of Exception
X
X
EVEX prefix.
X
X
X
X
If an unmasked SIMD floating-point exception and CR4.OSXMMEXCPT[bit 10] = 0.
If CR4.OSXSAVE[bit 18]=0.
If any one of following conditions applies:
• State requirement, Table 2-37 not met.
X
X
• Opcode independent #UD condition in Table 2-38.
Invalid Opcode, #UD
• Operand encoding #UD conditions in Table 2-39.
• Opmask encoding #UD condition of Table 2-40.
• EVEX.b encoding #UD condition of Table 2-41.
X
X
X
X
If preceded by a LOCK prefix (F0H).
X
X
If any REX, F2, F3, or 66 prefixes precede a EVEX prefix.
X
X
X
X
If any corresponding CPUID feature flag is ‘0’.
Device Not Available,
X
X
X
X
If CR0.TS[bit 3]=1.
#NM
X
For an illegal address in the SS segment.
Stack, #SS(0)
X
If a memory address referencing the SS segment is in a non-canonical form.
For an illegal memory operand effective address in the CS, DS, ES, FS or GS seg-
X
ments.
General Protection,
X
If the memory address is in a non-canonical form.
#GP(0)
If any part of the operand lies outside the effective address space from 0 to
X
X
FFFFH.
Page Fault #PF(fault-
X
X
X
For a page fault.
code)
Alignment Check
For 2, 4, or 8 byte memory access if alignment checking is enabled and an
X
X
X
#AC(0)
unaligned memory access is made while the current privilege level is 3.
SIMD Floating-point
If an unmasked SIMD floating-point exception, {sae} or {er} not set, and CR4.OSX-
X
X
X
X
Exception, #XM
MMEXCPT[bit 10] = 1.
Vol. 2A
2-53
INSTRUCTION FORMAT
2.8.4
Exceptions Type E4 and E4NF of EVEX-Encoded Instructions
EVEX-encoded vector instructions that cause no SIMD FP exception and support memory fault suppression follow
exception class E4.
Table 2-49. Type E4 Class Exception Conditions
Exception
Cause of Exception
X
X
If EVEX prefix present.
If CR4.OSXSAVE[bit 18]=0.
If any one of following conditions applies:
• State requirement, Table 2-37 not met.
• Opcode independent #UD condition in Table 2-38.
X
X
• Operand encoding #UD conditions in Table 2-39.
• Opmask encoding #UD condition of Table 2-40.
Invalid Opcode, #UD
• EVEX.b encoding #UD condition of Table 2-41 and in E4.nb subclass (see E4.nb
entries in Table 2-43).
• Instruction specific EVEX.L'L restriction not met.
X
X
X
X
If preceded by a LOCK prefix (F0H).
X
X
If any REX, F2, F3, or 66 prefixes precede a EVEX prefix.
X
X
X
X
If any corresponding CPUID feature flag is ‘0’.
Device Not Available,
X
X
X
X
If CR0.TS[bit 3]=1.
#NM
X
If fault suppression not set, and an illegal address in the SS segment.
Stack, #SS(0)
If fault suppression not set, and a memory address referencing the SS segment is
X
in a non-canonical form.
If fault suppression not set, and an illegal memory operand effective address in
X
the CS, DS, ES, FS or GS segments.
General Protection,
#GP(0)
X
If fault suppression not set, and the memory address is in a non-canonical form.
If fault suppression not set, and any part of the operand lies outside the effective
X
X
address space from 0 to FFFFH.
Page Fault #PF(fault-
X
X
X
If fault suppression not set, and a page fault.
code)
Alignment Check
For 2, 4, or 8 byte memory access if alignment checking is enabled and an
X
X
X
#AC(0)
unaligned memory access is made while the current privilege level is 3.
2-54
Vol. 2A
INSTRUCTION FORMAT
EVEX-encoded vector instructions that do not cause SIMD FP exception nor support memory fault suppression
follow exception class E4NF.
Table 2-50. Type E4NF Class Exception Conditions
Exception
Cause of Exception
X
X
If EVEX prefix present.
If CR4.OSXSAVE[bit 18]=0.
If any one of following conditions applies:
• State requirement, Table 2-37 not met.
• Opcode independent #UD condition in Table 2-38.
X
X
• Operand encoding #UD conditions in Table 2-39.
• Opmask encoding #UD condition of Table 2-40.
Invalid Opcode, #UD
• EVEX.b encoding #UD condition of Table 2-41 and in E4NF.nb subclass (see
E4NF.nb entries in Table 2-43).
• Instruction specific EVEX.L'L restriction not met.
X
X
X
X
If preceded by a LOCK prefix (F0H).
X
X
If any REX, F2, F3, or 66 prefixes precede a EVEX prefix.
X
X
X
X
If any corresponding CPUID feature flag is ‘0’.
Device Not Available,
X
X
X
X
If CR0.TS[bit 3]=1.
#NM
X
For an illegal address in the SS segment.
Stack, #SS(0)
X
If a memory address referencing the SS segment is in a non-canonical form.
For an illegal memory operand effective address in the CS, DS, ES, FS or GS seg-
X
ments.
General Protection,
#GP(0)
X
If the memory address is in a non-canonical form.
If any part of the operand lies outside the effective address space from 0 to
X
X
FFFFH.
Page Fault #PF(fault-
X
X
X
For a page fault.
code)
Vol. 2A
2-55
INSTRUCTION FORMAT
2.8.5
Exceptions Type E5 and E5NF
EVEX-encoded scalar/partial-vector instructions that cause no SIMD FP exception and support memory fault
suppression follow exception class E5.
Table 2-51. Type E5 Class Exception Conditions
Exception
Cause of Exception
X
X
If EVEX prefix present.
If CR4.OSXSAVE[bit 18]=0.
If any one of following conditions applies:
• State requirement, Table 2-37 not met.
• Opcode independent #UD condition in Table 2-38.
X
X
• Operand encoding #UD conditions in Table 2-39.
Invalid Opcode, #UD
• Opmask encoding #UD condition of Table 2-40.
• EVEX.b encoding #UD condition of Table 2-41.
• Instruction specific EVEX.L'L restriction not met.
X
X
X
X
If preceded by a LOCK prefix (F0H).
X
X
If any REX, F2, F3, or 66 prefixes precede a EVEX prefix.
X
X
X
X
If any corresponding CPUID feature flag is ‘0’.
Device Not Available,
X
X
X
X
If CR0.TS[bit 3]=1.
#NM
X
If fault suppression not set, and an illegal address in the SS segment.
Stack, #SS(0)
If fault suppression not set, and a memory address referencing the SS segment is
X
in a non-canonical form.
If fault suppression not set, and an illegal memory operand effective address in the
X
CS, DS, ES, FS or GS segments.
General Protection,
X
If fault suppression not set, and the memory address is in a non-canonical form.
#GP(0)
If fault suppression not set, and any part of the operand lies outside the effective
X
X
address space from 0 to FFFFH.
Page Fault #PF(fault-
X
X
X
If fault suppression not set, and a page fault.
code)
Alignment Check
For 2, 4, or 8 byte memory access if alignment checking is enabled and an
X
X
X
#AC(0)
unaligned memory access is made while the current privilege level is 3.
EVEX-encoded scalar/partial vector instructions that do not cause SIMD FP exception nor support memory fault
suppression follow exception class E5NF.
2-56
Vol. 2A
INSTRUCTION FORMAT
Table 2-52. Type E5NF Class Exception Conditions
Exception
Cause of Exception
X
X
If EVEX prefix present.
If CR4.OSXSAVE[bit 18]=0.
If any one of following conditions applies:
• State requirement, Table 2-37 not met.
Opcode independent #UD condition in Table 2-38.
X
X •
• Operand encoding #UD conditions in Table 2-39.
Invalid Opcode, #UD
• Opmask encoding #UD condition of Table 2-40.
• EVEX.b encoding #UD condition of Table 2-41.
• Instruction specific EVEX.L'L restriction not met.
X
X
X
X
If preceded by a LOCK prefix (F0H).
X
X
If any REX, F2, F3, or 66 prefixes precede a EVEX prefix.
X
X
X
X
If any corresponding CPUID feature flag is ‘0’.
Device Not Available,
X
X
X
X
If CR0.TS[bit 3]=1.
#NM
X
If an illegal address in the SS segment.
Stack, #SS(0)
X
If a memory address referencing the SS segment is in a non-canonical form.
X
If an illegal memory operand effective address in the CS, DS, ES, FS or GS segments.
General Protection,
X
If the memory address is in a non-canonical form.
#GP(0)
If any part of the operand lies outside the effective address space from 0 to
X
X
FFFFH.
Page Fault #PF(fault-
X
X
X
For a page fault.
code)
Alignment Check
For 2, 4, or 8 byte memory access if alignment checking is enabled and an
X
X
X
#AC(0)
unaligned memory access is made while the current privilege level is 3.
Vol. 2A
2-57
INSTRUCTION FORMAT
2.8.6
Exceptions Type E6 and E6NF
Table 2-53. Type E6 Class Exception Conditions
Exception
Cause of Exception
X
X
If EVEX prefix present.
If CR4.OSXSAVE[bit 18]=0.
If any one of following conditions applies:
• State requirement, Table 2-37 not met.
Opcode independent #UD condition in Table 2-38.
X
X •
• Operand encoding #UD conditions in Table 2-39.
Invalid Opcode, #UD
• Opmask encoding #UD condition of Table 2-40.
• EVEX.b encoding #UD condition of Table 2-41.
• Instruction specific EVEX.L'L restriction not met.
X
X
If preceded by a LOCK prefix (F0H).
X
X
If any REX, F2, F3, or 66 prefixes precede a EVEX prefix.
X
X
If any corresponding CPUID feature flag is ‘0’.
Device Not Available,
X
X
If CR0.TS[bit 3]=1.
#NM
X
If fault suppression not set, and an illegal address in the SS segment.
Stack, #SS(0)
If fault suppression not set, and a memory address referencing the SS segment is
X
in a non-canonical form.
If fault suppression not set, and an illegal memory operand effective address in the
X
General Protection,
CS, DS, ES, FS or GS segments.
#GP(0)
X
If fault suppression not set, and the memory address is in a non-canonical form.
Page Fault #PF(fault-
X
X
If fault suppression not set, and a page fault.
code)
Alignment Check
For 2, 4, or 8 byte memory access if alignment checking is enabled and an
X
X
#AC(0)
unaligned memory access is made while the current privilege level is 3.
2-58
Vol. 2A
INSTRUCTION FORMAT
EVEX-encoded instructions that do not cause SIMD FP exception nor support memory fault suppression follow
exception class E6NF.
Table 2-54. Type E6NF Class Exception Conditions
Exception
Cause of Exception
Invalid Opcode, #UD
X
X
If EVEX prefix present.
If CR4.OSXSAVE[bit 18]=0.
If any one of following conditions applies:
• State requirement, Table 2-37 not met.
Opcode independent #UD condition in Table 2-38.
X
X •
• Operand encoding #UD conditions in Table 2-39.
• Opmask encoding #UD condition of Table 2-40.
• EVEX.b encoding #UD condition of Table 2-41.
• Instruction specific EVEX.L'L restriction not met.
X
X
If preceded by a LOCK prefix (F0H).
X
X
If any REX, F2, F3, or 66 prefixes precede a EVEX prefix.
X
X
If any corresponding CPUID feature flag is ‘0’.
Device Not Available,
X
X
If CR0.TS[bit 3]=1.
#NM
X
For an illegal address in the SS segment.
Stack, #SS(0)
X
If a memory address referencing the SS segment is in a non-canonical form.
For an illegal memory operand effective address in the CS, DS, ES, FS or GS seg-
X
General Protection,
ments.
#GP(0)
X
If the memory address is in a non-canonical form.
Page Fault #PF(fault-
X
X
For a page fault.
code)
Alignment Check
For 2, 4, or 8 byte memory access if alignment checking is enabled and an
X
X
#AC(0)
unaligned memory access is made while the current privilege level is 3.
Vol. 2A
2-59
INSTRUCTION FORMAT
2.8.7
Exceptions Type E7NM
EVEX-encoded instructions that cause no SIMD FP exception and do not reference memory follow exception class
E7NM.
Table 2-55. Type E7NM Class Exception Conditions
Exception
Cause of Exception
X
X
If EVEX prefix present.
If CR4.OSXSAVE[bit 18]=0.
If any one of following conditions applies:
• State requirement, Table 2-37 not met.
Opcode independent #UD condition in Table 2-38.
X
X •
• Operand encoding #UD conditions in Table 2-39.
Invalid Opcode, #UD
• Opmask encoding #UD condition of Table 2-40.
• EVEX.b encoding #UD condition of Table 2-41.
• Instruction specific EVEX.L’L restriction not met.
X
X
X
X
If preceded by a LOCK prefix (F0H).
X
X
If any REX, F2, F3, or 66 prefixes precede a EVEX prefix.
X
X
X
X
If any corresponding CPUID feature flag is ‘0’.
Device Not Available,
X
X
If CR0.TS[bit 3]=1.
#NM
2-60
Vol. 2A
INSTRUCTION FORMAT
2.8.8
Exceptions Type E9 and E9NF
EVEX-encoded vector or partial-vector instructions that do not cause no SIMD FP exception and support memory
fault suppression follow exception class E9.
Table 2-56. Type E9 Class Exception Conditions
Exception
Cause of Exception
X
X
If EVEX prefix present.
If CR4.OSXSAVE[bit 18]=0.
If any one of following conditions applies:
• State requirement, Table 2-37 not met.
Opcode independent #UD condition in Table 2-38.
X
X •
• Operand encoding #UD conditions in Table 2-39.
Invalid Opcode, #UD
• Opmask encoding #UD condition of Table 2-40.
• EVEX.b encoding #UD condition of Table 2-41.
• Instruction specific EVEX.L'L restriction not met.
X
X
X
X
If preceded by a LOCK prefix (F0H).
X
X
If any REX, F2, F3, or 66 prefixes precede a EVEX prefix.
X
X
X
X
If any corresponding CPUID feature flag is ‘0’.
Device Not Available,
X
X
X
X
If CR0.TS[bit 3]=1.
#NM
X
If fault suppression not set, and an illegal address in the SS segment.
Stack, #SS(0)
If fault suppression not set, and a memory address referencing the SS segment is
X
in a non-canonical form.
If fault suppression not set, and an illegal memory operand effective address in the
X
CS, DS, ES, FS or GS segments.
General Protection,
X
If fault suppression not set, and the memory address is in a non-canonical form.
#GP(0)
If fault suppression not set, and any part of the operand lies outside the effective
X
X
address space from 0 to FFFFH.
Page Fault #PF(fault-
X
X
X
If fault suppression not set, and a page fault.
code)
Alignment Check
For 2, 4, or 8 byte memory access if alignment checking is enabled and an
X
X
X
#AC(0)
unaligned memory access is made while the current privilege level is 3.
Vol. 2A
2-61
INSTRUCTION FORMAT
EVEX-encoded vector or partial-vector instructions that must be encoded with VEX.L’L = 0, do not cause SIMD FP
exception nor support memory fault suppression follow exception class E9NF.
Table 2-57. Type E9NF Class Exception Conditions
Exception
Cause of Exception
X
X
If EVEX prefix present.
If CR4.OSXSAVE[bit 18]=0.
If any one of following conditions applies:
• State requirement, Table 2-37 not met.
Opcode independent #UD condition in Table 2-38.
X
X •
• Operand encoding #UD conditions in Table 2-39.
Invalid Opcode, #UD
• Opmask encoding #UD condition of Table 2-40.
• EVEX.b encoding #UD condition of Table 2-41.
• Instruction specific EVEX.L'L restriction not met.
X
X
X
X
If preceded by a LOCK prefix (F0H).
X
X
If any REX, F2, F3, or 66 prefixes precede a EVEX prefix.
X
X
X
X
If any corresponding CPUID feature flag is ‘0’.
Device Not Available,
X
X
X
X
If CR0.TS[bit 3]=1.
#NM
X
If an illegal address in the SS segment.
Stack, #SS(0)
X
If a memory address referencing the SS segment is in a non-canonical form.
X
If an illegal memory operand effective address in the CS, DS, ES, FS or GS segments.
General Protection,
X
If the memory address is in a non-canonical form.
#GP(0)
If any part of the operand lies outside the effective address space from 0 to
X
X
FFFFH.
Page Fault #PF(fault-
X
X
X
For a page fault.
code)
Alignment Check
For 2, 4, or 8 byte memory access if alignment checking is enabled and an
X
X
X
#AC(0)
unaligned memory access is made while the current privilege level is 3.
2-62
Vol. 2A
INSTRUCTION FORMAT
2.8.9
Exceptions Type E10 and E10NF
EVEX-encoded scalar instructions that ignore EVEX.L’L vector length encoding, do not cause a SIMD FP exception,
and support memory fault suppression follow exception class E10.
Table 2-58. Type E10 Class Exception Conditions
Exception
Cause of Exception
X
X
If EVEX prefix present.
If CR4.OSXSAVE[bit 18]=0.
If any one of following conditions applies:
• State requirement, Table 2-37 not met.
X
X
• Opcode independent #UD condition in Table 2-38.
• Operand encoding #UD conditions in Table 2-39.
Invalid Opcode, #UD
• Opmask encoding #UD condition of Table 2-40.
• EVEX.b encoding #UD condition of Table 2-41.
X
X
X
X
If preceded by a LOCK prefix (F0H).
X
X
If any REX, F2, F3, or 66 prefixes precede a EVEX prefix.
X
X
X
X
If any corresponding CPUID feature flag is ‘0’.
Device Not Available,
X
X
X
X
If CR0.TS[bit 3]=1.
#NM
X
If fault suppression not set, and an illegal address in the SS segment.
Stack, #SS(0)
If fault suppression not set, and a memory address referencing the SS segment is
X
in a non-canonical form.
If fault suppression not set, and an illegal memory operand effective address in the
X
CS, DS, ES, FS or GS segments.
General Protection,
X
If fault suppression not set, and the memory address is in a non-canonical form.
#GP(0)
If fault suppression not set, and any part of the operand lies outside the effective
X
X
address space from 0 to FFFFH.
Page Fault #PF(fault-
X
X
X
If fault suppression not set, and a page fault.
code)
Alignment Check
For 2, 4, or 8 byte memory access if alignment checking is enabled and an
X
X
X
#AC(0)
unaligned memory access is made while the current privilege level is 3.
Vol. 2A
2-63
INSTRUCTION FORMAT
EVEX-encoded scalar instructions that ignore EVEX.L’L vector length encoding, do not cause a SIMD FP exception,
and do not support memory fault suppression follow exception class E10NF.
Table 2-59. Type E10NF Class Exception Conditions
Exception
Cause of Exception
X
X
If EVEX prefix present.
If CR4.OSXSAVE[bit 18]=0.
If any one of following conditions applies:
• State requirement, Table 2-37 not met.
X
X
• Opcode independent #UD condition in Table 2-38.
• Operand encoding #UD conditions in Table 2-39.
Invalid Opcode, #UD
• Opmask encoding #UD condition of Table 2-40.
• EVEX.b encoding #UD condition of Table 2-41.
X
X
X
X
If preceded by a LOCK prefix (F0H).
X
X
If any REX, F2, F3, or 66 prefixes precede a EVEX prefix.
X
X
X
X
If any corresponding CPUID feature flag is ‘0’.
Device Not Available,
X
X
X
X
If CR0.TS[bit 3]=1.
#NM
X
If fault suppression not set, and an illegal address in the SS segment.
Stack, #SS(0)
If fault suppression not set, and a memory address referencing the SS segment is
X
in a non-canonical form.
If fault suppression not set, and an illegal memory operand effective address in the
X
CS, DS, ES, FS or GS segments.
General Protection,
X
If fault suppression not set, and the memory address is in a non-canonical form.
#GP(0)
If fault suppression not set, and any part of the operand lies outside the effective
X
X
address space from 0 to FFFFH.
Page Fault #PF(fault-
X
X
X
If fault suppression not set, and a page fault.
code)
Alignment Check
For 2, 4, or 8 byte memory access if alignment checking is enabled and an
X
X
X
#AC(0)
unaligned memory access is made while the current privilege level is 3.
2-64
Vol. 2A
INSTRUCTION FORMAT
2.8.10 Exceptions Type E11 (EVEX-only, Mem Arg, No AC, Floating-point Exceptions)
EVEX-encoded instructions that can cause SIMD FP exception, memory operand support fault suppression but do
not cause #AC follow exception class E11.
Table 2-60. Type E11 Class Exception Conditions
Exception
Cause of Exception
Invalid Opcode, #UD
X
X
If EVEX prefix present.
X
X
If CR4.OSXSAVE[bit 18]=0.
If any one of following conditions applies:
• State requirement, Table 2-37 not met.
• Opcode independent #UD condition in Table 2-38.
• Operand encoding #UD conditions in Table 2-39.
• Opmask encoding #UD condition of Table 2-40.
• EVEX.b encoding #UD condition of Table 2-41.
• Instruction specific EVEX.L'L restriction not met.
X
X
X
X
If preceded by a LOCK prefix (F0H).
X
X
If any REX, F2, F3, or 66 prefixes precede a EVEX prefix.
X
X
X
X
If any corresponding CPUID feature flag is ‘0’.
Device Not Available,
X
X
X
X
If CR0.TS[bit 3]=1.
#NM
Stack, #SS(0)
X
If fault suppression not set, and an illegal address in the SS segment.
X
If fault suppression not set, and a memory address referencing the SS segment is
in a non-canonical form.
General Protection,
X
If fault suppression not set, and an illegal memory operand effective address in the
#GP(0)
CS, DS, ES, FS or GS segments.
X
If fault suppression not set, and the memory address is in a non-canonical form.
X
X
If fault suppression not set, and any part of the operand lies outside the effective
address space from 0 to FFFFH.
Page Fault #PF (fault-
X
X
X
If fault suppression not set, and a page fault.
code)
SIMD Floating-Point
X
X
X
X
If an unmasked SIMD floating-point exception, {sae} not set, and CR4.OSXMMEX-
Exception, #XM
CPT[bit 10] = 1.
Vol. 2A
2-65
INSTRUCTION FORMAT
2.8.11 Exceptions Type E12 and E12NP (VSIB Mem Arg, No AC, No Floating-point Exceptions)
Table 2-61. Type E12 Class Exception Conditions
Exception
Cause of Exception
Invalid Opcode, #UD
X
X
If EVEX prefix present.
X
X
If CR4.OSXSAVE[bit 18]=0.
If any one of following conditions applies:
• State requirement, Table 2-37 not met.
• Opcode independent #UD condition in Table 2-38.
• Operand encoding #UD conditions in Table 2-39.
• Opmask encoding #UD condition of Table 2-40.
• EVEX.b encoding #UD condition of Table 2-41.
• Instruction specific EVEX.L'L restriction not met.
• If vvvv != 1111b.
X
X
X
X
If preceded by a LOCK prefix (F0H).
X
X
If any REX, F2, F3, or 66 prefixes precede a VEX prefix.
X
X
X
NA
If address size attribute is 16 bit.
X
X
X
X
If ModR/M.mod = ‘11b’.
X
X
X
X
If ModR/M.rm != ‘100b’.
X
X
X
X
If any corresponding CPUID feature flag is ‘0’.
X
X
X
X
If k0 is used (gather or scatter operation).
X
X
X
X
If index = destination register (gather operation).
Device Not Available,
X
X
X
X
If CR0.TS[bit 3]=1.
#NM
Stack, #SS(0)
X
For an illegal address in the SS segment.
X
If a memory address referencing the SS segment is in a non-canonical form.
General Protection,
X
For an illegal memory operand effective address in the CS, DS, ES, FS or GS seg-
#GP(0)
ments.
X
If the memory address is in a non-canonical form.
X
X
If any part of the operand lies outside the effective address space from 0 to
FFFFH.
Page Fault #PF (fault-
X
X
X
For a page fault.
code)
2-66
Vol. 2A
INSTRUCTION FORMAT
EVEX-encoded prefetch instructions that do not cause #PF follow exception class E12NP.
Table 2-62. Type E12NP Class Exception Conditions
Exception
Cause of Exception
Invalid Opcode, #UD
X
X
If EVEX prefix present.
X
X
If CR4.OSXSAVE[bit 18]=0.
If any one of following conditions applies:
• State requirement, Table 2-37 not met.
• Opcode independent #UD condition in Table 2-38.
• Operand encoding #UD conditions in Table 2-39.
• Opmask encoding #UD condition of Table 2-40.
• EVEX.b encoding #UD condition of Table 2-41.
• Instruction specific EVEX.L'L restriction not met.
X
X
X
X
If preceded by a LOCK prefix (F0H).
X
X
If any REX, F2, F3, or 66 prefixes precede a VEX prefix.
X
X
X
NA
If address size attribute is 16 bit.
X
X
X
X
If ModR/M.mod = ‘11b’.
X
X
X
X
If ModR/M.rm != ‘100b’.
X
X
X
X
If any corresponding CPUID feature flag is ‘0’.
X
X
X
X
If k0 is used (gather or scatter operation).
Device Not Available,
X
X
X
X
If CR0.TS[bit 3]=1.
#NM
Vol. 2A
2-67
INSTRUCTION FORMAT
2.9
EXCEPTION CLASSIFICATIONS OF OPMASK INSTRUCTIONS, TYPE K20 AND
TYPE K21
The exception behavior of VEX-encoded opmask instructions are listed below.
2.9.1
Exceptions Type K20
Exception conditions of Opmask instructions that do not address memory are listed as Type K20.
Table 2-63. TYPE K20 Exception Definition (VEX-Encoded OpMask Instructions w/o Memory Arg)
Exception
Cause of Exception
Invalid Opcode, #UD
X
X
X
X
If relevant CPUID feature flag is ‘0’.
X
X
If a VEX prefix is present.
X
X
If CR4.OSXSAVE[bit 18]=0.
If any one of following conditions applies:
• State requirement, Table 2-37 not met.
• Opcode independent #UD condition in Table 2-38.
• Operand encoding #UD conditions in Table 2-39.
X
X
If any REX, F2, F3, or 66 prefixes precede a VEX prefix.
X
X
If ModRM:[7:6] != 11b.
Device Not Available,
X
X
X
X
If CR0.TS[bit 3]=1.
#NM
2-68
Vol. 2A
INSTRUCTION FORMAT
2.9.2
Exceptions Type K21
Exception conditions of Opmask instructions that address memory are listed as Type K21.
Table 2-64. TYPE K21 Exception Definition (VEX-Encoded OpMask Instructions Addressing Memory)
Exception
Cause of Exception
Invalid Opcode, #UD
X
X
X
X
If relevant CPUID feature flag is ‘0’.
X
X
If a VEX prefix is present.
X
X
If CR4.OSXSAVE[bit 18]=0.
If any one of following conditions applies:
• State requirement, Table 2-37 not met.
• Opcode independent #UD condition in Table 2-38.
• Operand encoding #UD conditions in Table 2-39.
Device Not Available,
X
X
X
X
If CR0.TS[bit 3]=1.
#NM
X
X
If any REX, F2, F3, or 66 prefixes precede a VEX prefix.
Stack, #SS(0)
X
X
X
For an illegal address in the SS segment.
X
If a memory address referencing the SS segment is in a non-canonical form.
General Protection,
X
For an illegal memory operand effective address in the CS, DS, ES, FS or GS seg-
#GP(0)
ments.
If the DS, ES, FS, or GS register is used to access memory and it contains a null
segment selector.
X
If the memory address is in a non-canonical form.
X
X
If any part of the operand lies outside the effective address space from 0 to
FFFFH.
Page Fault #PF(fault-
X
X
X
For a page fault.
code)
Alignment Check
X
X
X
For 2, 4, or 8 byte memory access if alignment checking is enabled and an
#AC(0)
unaligned memory access is made while the current privilege level is 3.
Vol. 2A
2-69
INSTRUCTION FORMAT
2.10
INTEL® AMX INSTRUCTION EXCEPTION CLASSES
Alignment exceptions: The Intel AMX instructions that access memory will never generate #AC exceptions.
Table 2-65. Intel® AMX Exception Classes
Class
Description
• #UD if preceded by LOCK, 66H, F2H, F3H or REX prefixes.
• #UD if CR4.OSXSAVE 1.
• #UD if XCR0[18:17] 0b11.
• #UD if IA32_EFER.LMA 1 OR CS.L 1.
• #UD if VVVV 0b1111.
AMX-E1
• #GP based on palette and configuration checks (see pseudocode).
• #GP if the memory address is in a non-canonical form.
• #SS(0) if the memory address referencing the SS segment is in a non-canonical form.
• #PF if a page fault occurs.
• #UD if preceded by LOCK, 66H, F2H, F3H or REX prefixes.
• #UD if CR4.OSXSAVE 1.
• #UD if XCR0[18:17] 0b11.
• #UD if IA32_EFER.LMA 1 OR CS.L 1.
AMX-E2
• #UD if VVVV 0b1111.
• #GP if the memory address is in a non-canonical form.
• #SS(0) if the memory address referencing the SS segment is in a non-canonical form.
• #PF if a page fault occurs.
• #UD if preceded by LOCK, 66H, F2H, F3H or REX prefixes.
• #UD if CR4.OSXSAVE 1.
• #UD if XCR0[18:17] 0b11.
• #UD if IA32_EFER.LMA 1 OR CS.L 1.
• #UD if VVVV 0b1111.
• #UD if not using SIB addressing.
• #UD if TILES_CONFIGURED == 0.
• #UD if tsrc or tdest are not valid tiles.
AMX-E3
• #UD if tsrc/tdest are palette_table[tilecfg.palette_id].max_names.
• #UD if tsrc.colbytes mod 4 0 OR tdest.colbytes mod 4 0.
• #UD if tilecfg.start_row tsrc.rows OR tilecfg.start_row tdest.rows.
• #GP if the memory address is in a non-canonical form.
• #SS(0) if the memory address referencing the SS segment is in a non-canonical form.
• #PF if any memory operand causes a page fault.
• #NM if XFD[18] == 1.
2-70
Vol. 2A
INSTRUCTION FORMAT
Table 2-65. Intel® AMX Exception Classes (Contd.)
Class
Description
• #UD if preceded by LOCK, 66H, F2H, F3H or REX prefixes.
• #UD if CR4.OSXSAVE 1.
• #UD if XCR0[18:17] 0b11.
• #UD if IA32_EFER.LMA 1 OR CS.L 1.
• #UD if srcdest == src1 OR src1 == src2 OR srcdest == src2.
• #UD if TILES_CONFIGURED == 0.
• #UD if srcdest.colbytes mod 4 0.
• #UD if src1.colbytes mod 4 0.
• #UD if src2.colbytes mod 4 0.
AMX-E4
• #UD if srcdest/src1/src2 are not valid tiles.
• #UD if srcdest/src1/src2 are palette_table[tilecfg.palette_id].max_names.
• #UD if srcdest.colbytes src2.colbytes.
• #UD if srcdest.rows src1.rows.
• #UD if src1.colbytes / 4 src2.rows.
• #UD if srcdest.colbytes > tmul_maxn.
• #UD if src2.colbytes > tmul_maxn.
• #UD if src1.colbytes/4 > tmul_maxk.
• #UD if src2.rows > tmul_maxk.
• #NM if XFD[18] == 1.
• #UD if preceded by LOCK, 66H, F2H, F3H or REX prefixes.
• #UD if CR4.OSXSAVE 1.
• #UD if XCR0[18:17] 0b11.
• #UD if IA32_EFER.LMA 1 OR CS.L 1.
AMX-E5
• #UD if VVVV 0b1111.
• #UD if TILES_CONFIGURED == 0.
• #UD if tdest is not a valid tile.
• #UD if tdest is palette_table[tilecfg.palette_id].max_names.
• #NM if XFD[18] == 1.
• #UD if preceded by LOCK, 66H, F2H, F3H or REX prefixes.
• #UD if CR4.OSXSAVE 1.
AMX-E6
• #UD if XCR0[18:17] 0b11.
• #UD if IA32_EFER.LMA 1 OR CS.L 1.
• #UD if VVVV 0b1111.
Vol. 2A
2-71
INSTRUCTION FORMAT
2-72
Vol. 2A
5. Updates to Chapter 3, Volume 2A
Change bars and violet text show changes to Chapter 7 of the Intel® 64 and IA-32 Architectures Software
Developer’s Manual, Volume 2A: Instruction Set Reference, A-L.
------------------------------------------------------------------------------------------
Changes to this chapter:
• Updated the CPUID instruction to remove “ECX = 0” from the Last Branch Records Information Leaf (1CH)
listing because this leaf does not support sub-leaves.
• Updated the CPUID instruction to add the enumeration of INVD execution prevention after BIOS Done.
• Updated the INVD instruction to add BIOS Done additions to the description and exception sections. Added an
exception to Real-Address Mode Exceptions regarding reserved memory protections.
Intel® 64 and IA-32 Architectures Software Developer’s Manual Documentation Changes
13
INSTRUCTION SET REFERENCE, A-L
CPUID-CPU Identification
Opcode
Instruction
Op/
64-Bit
Compat/
Description
En
Mode
Leg Mode
0F A2
CPUID
ZO
Valid
Valid
Returns processor identification and feature
information to the EAX, EBX, ECX, and EDX
registers, as determined by input entered in
EAX (in some cases, ECX as well).
Instruction Operand Encoding
Op/En
Operand 1
Operand 2
Operand 3
Operand 4
ZO
N/A
N/A
N/A
N/A
Description
The ID flag (bit 21) in the EFLAGS register indicates support for the CPUID instruction. If a software procedure can
set and clear this flag, the processor executing the procedure supports the CPUID instruction. This instruction
operates the same in non-64-bit modes and 64-bit mode.
CPUID returns processor identification and feature information in the EAX, EBX, ECX, and EDX registers.1 The
instruction’s output is dependent on the contents of the EAX register upon execution (in some cases, ECX as well).
For example, the following pseudocode loads EAX with 00H and causes CPUID to return a Maximum Return Value
and the Vendor Identification String in the appropriate registers:
MOV EAX, 00H
CPUID
Table 3-8 shows information returned, depending on the initial value loaded into the EAX register.
Two types of information are returned: basic and extended function information. If a value entered for CPUID.EAX
is higher than the maximum input value for basic or extended function for that processor then the data for the
highest basic information leaf is returned. For example, using some Intel processors, the following is true:
CPUID.EAX = 05H (* Returns MONITOR/MWAIT leaf. *)
CPUID.EAX = 0AH (* Returns Architectural Performance Monitoring leaf. *)
CPUID.EAX = 0BH (* Returns Extended Topology Enumeration leaf. *)2
CPUID.EAX =1FH (* Returns V2 Extended Topology Enumeration leaf. *)2
CPUID.EAX = 80000008H (* Returns linear/physical address size data. *)
CPUID.EAX = 8000000AH (* INVALID: Returns same information as CPUID.EAX = 0BH. *)
If a value entered for CPUID.EAX is less than or equal to the maximum input value and the leaf is not supported on
that processor then 0 is returned in all the registers.
When CPUID returns the highest basic leaf information as a result of an invalid input EAX value, any dependence
on input ECX value in the basic leaf is honored.
CPUID can be executed at any privilege level to serialize instruction execution. Serializing instruction execution
guarantees that any modifications to flags, registers, and memory for previous instructions are completed before
the next instruction is fetched and executed.
See also:
“Serializing Instructions” in Chapter 9, “Multiple-Processor Management,” in the Intel® 64 and IA-32 Architectures
Software Developer’s Manual, Volume 3A.
“Caching Translation Information” in Chapter 4, “Paging,” in the Intel® 64 and IA-32 Architectures Software Devel-
oper’s Manual, Volume 3A.
1. On Intel 64 processors, CPUID clears the high 32 bits of the RAX/RBX/RCX/RDX registers in all modes.
2. CPUID leaf 1FH is a preferred superset to leaf 0BH. Intel recommends first checking for the existence of CPUID leaf 1FH before
using leaf 0BH.
CPUID-CPU Identification
Vol. 2A
3-217
INSTRUCTION SET REFERENCE, A-L
Table 3-8. Information Returned by CPUID Instruction
Initial EAX
Value
Information Provided about the Processor
Basic CPUID Information
0H
EAX
Maximum Input Value for Basic CPUID Information.
EBX
“Genu”
ECX
“ntel”
EDX
“ineI”
01H
EAX
Version Information: Type, Family, Model, and Stepping ID (see Figure 3-6).
EBX
Bits 07-00: Brand Index.
Bits 15-08: CLFLUSH line size (Value ∗ 8 = cache line size in bytes; used also by CLFLUSHOPT).
Bits 23-16: Maximum number of addressable IDs for logical processors in this physical package*.
Bits 31-24: Initial APIC ID**.
ECX
Feature Information (see Figure 3-7 and Table 3-10).
EDX
Feature Information (see Figure 3-8 and Table 3-11).
NOTES:
* The nearest power-of-2 integer that is not smaller than EBX[23:16] is the number of unique initial APIC
IDs reserved for addressing different logical processors in a physical package. This field is only valid if
CPUID.1.EDX.HTT[bit 28]= 1.
** The 8-bit initial APIC ID in EBX[31:24] is replaced by the 32-bit x2APIC ID, available in Leaf 0BH and
Leaf 1FH.
02H
EAX
Cache and TLB Information (see Table 3-12).
EBX
Cache and TLB Information.
ECX
Cache and TLB Information.
EDX
Cache and TLB Information.
03H
EAX
Reserved.
EBX
Reserved.
ECX
Bits 00-31 of 96-bit processor serial number. (Available in Pentium III processor only; otherwise, the
value in this register is reserved.)
EDX
Bits 32-63 of 96-bit processor serial number. (Available in Pentium III processor only; otherwise, the
value in this register is reserved.)
NOTES:
Processor serial number (PSN) is not supported in the Pentium 4 processor or later. On all models, use
the PSN flag (returned using CPUID) to check for PSN support before accessing the feature.
CPUID leaves above 2 and below 80000000H are visible only when IA32_MISC_ENABLE[bit 22] has its default value of 0.
Deterministic Cache Parameters Leaf (Initial EAX Value = 04H)
04H
NOTES:
Leaf 04H output depends on the initial value in ECX.*
See also: “INPUT EAX = 04H: Returns Deterministic Cache Parameters for Each Level” on page 251.
EAX
Bits 04-00: Cache Type Field.
0 = Null - No more caches.
1 = Data Cache.
2 = Instruction Cache.
3 = Unified Cache.
4-31 = Reserved.
3-218
Vol. 2A
CPUID-CPU Identification
INSTRUCTION SET REFERENCE, A-L
Table 3-8. Information Returned by CPUID Instruction (Contd.)
Initial EAX
Value
Information Provided about the Processor
Bits 07-05: Cache Level (starts at 1).
Bit 08: Self Initializing cache level (does not need SW initialization).
Bit 09: Fully Associative cache.
Bits 13-10: Reserved.
Bits 25-14: Maximum number of addressable IDs for logical processors sharing this cache**, ***.
Bits 31-26: Maximum number of addressable IDs for processor cores in the physical
package**, ****, *****.
EBX
Bits 11-00: L = System Coherency Line Size**.
Bits 21-12: P = Physical Line partitions**.
Bits 31-22: W = Ways of associativity**.
ECX
Bits 31-00: S = Number of Sets**.
EDX
Bit 00: Write-Back Invalidate/Invalidate.
0 = WBINVD/INVD from threads sharing this cache acts upon lower level caches for threads sharing this
cache.
1 = WBINVD/INVD is not guaranteed to act upon lower level caches of non-originating threads sharing
this cache.
Bit 01: Cache Inclusiveness.
0 = Cache is not inclusive of lower cache levels.
1 = Cache is inclusive of lower cache levels.
Bit 02: Complex Cache Indexing.
0 = Direct mapped cache.
1 = A complex function is used to index the cache, potentially using all address bits.
Bits 31-03: Reserved = 0.
NOTES:
* If ECX contains an invalid sub leaf index, EAX/EBX/ECX/EDX return 0. Sub-leaf index n+1 is invalid if sub-
leaf n returns EAX[4:0] as 0.
** Add one to the return value to get the result.
***The nearest power-of-2 integer that is not smaller than (1 + EAX[25:14]) is the number of unique ini-
tial APIC IDs reserved for addressing different logical processors sharing this cache.
**** The nearest power-of-2 integer that is not smaller than (1 + EAX[31:26]) is the number of unique
Core_IDs reserved for addressing different processor cores in a physical package. Core ID is a subset of
bits of the initial APIC ID.
***** The returned value is constant for valid initial values in ECX. Valid ECX values start from 0.
MONITOR/MWAIT Leaf (Initial EAX Value = 05H)
05H
EAX
Bits 15-00: Smallest monitor-line size in bytes (default is processor's monitor granularity).
Bits 31-16: Reserved = 0.
EBX
Bits 15-00: Largest monitor-line size in bytes (default is processor's monitor granularity).
Bits 31-16: Reserved = 0.
ECX
Bit 00: Enumeration of Monitor-Mwait extensions (beyond EAX and EBX registers) supported.
Bit 01: Supports treating interrupts as break-event for MWAIT, even when interrupts disabled.
Bits 31-02: Reserved.
EDX
Bits 03-00: Number of C0* sub C-states supported using MWAIT.
Bits 07-04: Number of C1* sub C-states supported using MWAIT.
Bits 11-08: Number of C2* sub C-states supported using MWAIT.
Bits 15-12: Number of C3* sub C-states supported using MWAIT.
Bits 19-16: Number of C4* sub C-states supported using MWAIT.
Bits 23-20: Number of C5* sub C-states supported using MWAIT.
Bits 27-24: Number of C6* sub C-states supported using MWAIT.
Bits 31-28: Number of C7* sub C-states supported using MWAIT.
CPUID-CPU Identification
Vol. 2A
3-219
INSTRUCTION SET REFERENCE, A-L
Table 3-8. Information Returned by CPUID Instruction (Contd.)
Initial EAX
Value
Information Provided about the Processor
NOTE:
* The definition of C0 through C7 states for MWAIT extension are processor-specific C-states, not ACPI C-
states.
Thermal and Power Management Leaf (Initial EAX Value = 06H)
06H
EAX
Bit 00: Digital temperature sensor is supported if set.
Bit 01: Intel Turbo Boost Technology available (see description of IA32_MISC_ENABLE[38]).
Bit 02: ARAT. APIC-Timer-always-running feature is supported if set.
Bit 03: Reserved.
Bit 04: PLN. Power limit notification controls are supported if set.
Bit 05: ECMD. Clock modulation duty cycle extension is supported if set.
Bit 06: PTM. Package thermal management is supported if set.
Bit 07: HWP. HWP base registers (IA32_PM_ENABLE[bit 0], IA32_HWP_CAPABILITIES, IA32_HWP_RE-
QUEST, IA32_HWP_STATUS) are supported if set.
Bit 08: HWP_Notification. IA32_HWP_INTERRUPT MSR is supported if set.
Bit 09: HWP_Activity_Window. IA32_HWP_REQUEST[bits 41:32] is supported if set.
Bit 10: HWP_Energy_Performance_Preference. IA32_HWP_REQUEST[bits 31:24] is supported if set.
Bit 11: HWP_Package_Level_Request. IA32_HWP_REQUEST_PKG MSR is supported if set.
Bit 12: Reserved.
Bit 13: HDC. HDC base registers IA32_PKG_HDC_CTL, IA32_PM_CTL1, IA32_THREAD_STALL MSRs are
supported if set.
Bit 14: Intel® Turbo Boost Max Technology 3.0 available.
Bit 15: HWP Capabilities. Highest Performance change is supported if set.
Bit 16: HWP PECI override is supported if set.
Bit 17: Flexible HWP is supported if set.
Bit 18: Fast access mode for the IA32_HWP_REQUEST MSR is supported if set.
Bit 19: HW_FEEDBACK. IA32_HW_FEEDBACK_PTR MSR, IA32_HW_FEEDBACK_CONFIG MSR, IA32_PACK-
AGE_THERM_STATUS MSR bit 26, and IA32_PACKAGE_THERM_INTERRUPT MSR bit 25 are supported if
set.
Bit 20: Ignoring Idle Logical Processor HWP request is supported if set.
Bits 22-21: Reserved.
Bit 23: Intel® Thread Director supported if set. IA32_HW_FEEDBACK_CHAR and IA32_HW_FEEDBACK_-
THREAD_CONFIG MSRs are supported if set.
Bit 24: IA32_THERM_INTERRUPT MSR bit 25 is supported if set.
Bits 31-25: Reserved.
EBX
Bits 03-00: Number of Interrupt Thresholds in Digital Thermal Sensor.
Bits 31-04: Reserved.
ECX
Bit 00: Hardware Coordination Feedback Capability (Presence of IA32_MPERF and IA32_APERF). The
capability to provide a measure of delivered processor performance (since last reset of the counters), as
a percentage of the expected processor performance when running at the TSC frequency.
Bits 02-01: Reserved = 0.
Bit 03: The processor supports performance-energy bias preference if CPUID.06H:ECX.SETBH[bit 3] is set
and it also implies the presence of a new architectural MSR called IA32_ENERGY_PERF_BIAS (1B0H).
Bits 07-04: Reserved = 0.
Bits 15-08: Number of Intel® Thread Director classes supported by the processor. Information for that
many classes is written into the Intel Thread Director Table by the hardware.
Bits 31-16: Reserved = 0.
3-220
Vol. 2A
CPUID-CPU Identification
INSTRUCTION SET REFERENCE, A-L
Table 3-8. Information Returned by CPUID Instruction (Contd.)
Initial EAX
Value
Information Provided about the Processor
EDX
Bits 07-00: Bitmap of supported hardware feedback interface capabilities.
0 = When set to 1, indicates support for performance capability reporting.
1 = When set to 1, indicates support for energy efficiency capability reporting.
2-7 = Reserved
Bits 11-08: Enumerates the size of the hardware feedback interface structure in number of 4 KB pages;
add one to the return value to get the result.
Bits 31-16: Index (starting at 0) of this logical processor's row in the hardware feedback interface struc-
ture. Note that on some parts the index may be same for multiple logical processors. On some parts the
indices may not be contiguous, i.e., there may be unused rows in the hardware feedback interface struc-
ture.
NOTE:
Bits 0 and 1 will always be set together.
Structured Extended Feature Flags Enumeration Leaf (Initial EAX Value = 07H, ECX = 0)
07H
EAX
Bits 31-00: Reports the maximum input value for supported leaf 7 sub-leaves.
EBX
Bit 00: FSGSBASE. Supports RDFSBASE/RDGSBASE/WRFSBASE/WRGSBASE if 1.
Bit 01: IA32_TSC_ADJUST MSR is supported if 1.
Bit 02: SGX. Supports Intel® Software Guard Extensions (Intel® SGX Extensions) if 1.
Bit 03: BMI1.
Bit 04: HLE.
Bit 05: AVX2. Supports Intel® Advanced Vector Extensions 2 (Intel® AVX2) if 1.
Bit 06: FDP_EXCPTN_ONLY. x87 FPU Data Pointer updated only on x87 exceptions if 1.
Bit 07: SMEP. Supports Supervisor-Mode Execution Prevention if 1.
Bit 08: BMI2.
Bit 09: Supports Enhanced REP MOVSB/STOSB if 1.
Bit 10: INVPCID. If 1, supports INVPCID instruction for system software that manages process-context
identifiers.
Bit 11: RTM.
Bit 12: RDT-M. Supports Intel® Resource Director Technology (Intel® RDT) Monitoring capability if 1.
Bit 13: Deprecates FPU CS and FPU DS values if 1.
Bit 14: MPX. Supports Intel® Memory Protection Extensions if 1.
Bit 15: RDT-A. Supports Intel® Resource Director Technology (Intel® RDT) Allocation capability if 1.
Bit 16: AVX512F.
Bit 17: AVX512DQ.
Bit 18: RDSEED.
Bit 19: ADX.
Bit 20: SMAP. Supports Supervisor-Mode Access Prevention (and the CLAC/STAC instructions) if 1.
Bit 21: AVX512_IFMA.
Bit 22: Reserved.
Bit 23: CLFLUSHOPT.
Bit 24: CLWB.
Bit 25: Intel Processor Trace.
Bit 26: AVX512PF. (Intel® Xeon Phi™ only.)
Bit 27: AVX512ER. (Intel® Xeon Phi™ only.)
Bit 28: AVX512CD.
Bit 29: SHA. supports Intel® Secure Hash Algorithm Extensions (Intel® SHA Extensions) if 1.
Bit 30: AVX512BW.
Bit 31: AVX512VL.
CPUID-CPU Identification
Vol. 2A
3-221
INSTRUCTION SET REFERENCE, A-L
Table 3-8. Information Returned by CPUID Instruction (Contd.)
Initial EAX
Value
Information Provided about the Processor
ECX
Bit 00: PREFETCHWT1. (Intel® Xeon Phi™ only.)
Bit 01: AVX512_VBMI.
Bit 02: UMIP. Supports user-mode instruction prevention if 1.
Bit 03: PKU. Supports protection keys for user-mode pages if 1.
Bit 04: OSPKE. If 1, OS has set CR4.PKE to enable protection keys (and the RDPKRU/WRPKRU instruc-
tions).
Bit 05: WAITPKG.
Bit 06: AVX512_VBMI2.
Bit 07: CET_SS. Supports CET shadow stack features if 1. Processors that set this bit define bits 1:0 of the
IA32_U_CET and IA32_S_CET MSRs. Enumerates support for the following MSRs:
IA32_INTERRUPT_SPP_TABLE_ADDR, IA32_PL3_SSP, IA32_PL2_SSP, IA32_PL1_SSP, and
IA32_PL0_SSP.
Bit 08: GFNI.
Bit 09: VAES.
Bit 10: VPCLMULQDQ.
Bit 11: AVX512_VNNI.
Bit 12: AVX512_BITALG.
Bits 13: TME_EN. If 1, the following MSRs are supported: IA32_TME_CAPABILITY, IA32_TME_ACTIVATE,
IA32_TME_EXCLUDE_MASK, and IA32_TME_EXCLUDE_BASE.
Bit 14: AVX512_VPOPCNTDQ.
Bit 15: Reserved.
Bit 16: LA57. Supports 57-bit linear addresses and five-level paging if 1.
Bits 21-17: The value of MAWAU used by the BNDLDX and BNDSTX instructions in 64-bit mode.
Bit 22: RDPID and IA32_TSC_AUX are available if 1.
Bit 23: KL. Supports Key Locker if 1.
Bit 24: BUS_LOCK_DETECT. If 1, indicates support for OS bus-lock detection.
Bit 25: CLDEMOTE. Supports cache line demote if 1.
Bit 26: Reserved.
Bit 27: MOVDIRI. Supports MOVDIRI if 1.
Bit 28: MOVDIR64B. Supports MOVDIR64B if 1.
Bit 29: ENQCMD. Supports Enqueue Stores if 1.
Bit 30: SGX_LC. Supports SGX Launch Configuration if 1.
Bit 31: PKS. Supports protection keys for supervisor-mode pages if 1.
EDX
Bit 00: Reserved.
Bit 01: SGX-KEYS. If 1, Attestation Services for Intel® SGX is supported.
Bit 02: AVX512_4VNNIW. (Intel® Xeon Phi™ only.)
Bit 03: AVX512_4FMAPS. (Intel® Xeon Phi™ only.)
Bit 04: Fast Short REP MOV.
Bit 05: UINTR. If 1, the processor supports user interrupts.
Bits 07-06: Reserved.
Bit 08: AVX512_VP2INTERSECT.
Bit 09: SRBDS_CTRL. If 1, enumerates support for the IA32_MCU_OPT_CTRL MSR and indicates its bit 0
(RNGDS_MITG_DIS) is also supported.
Bit 10: MD_CLEAR supported.
Bit 11: RTM_ALWAYS_ABORT. If set, any execution of XBEGIN immediately aborts and transitions to the
specified fallback address.
Bit 12: Reserved.
Bit 13: If 1, RTM_FORCE_ABORT supported. Processors that set this bit support the
IA32_TSX_FORCE_ABORT MSR. They allow software to set IA32_TSX_FORCE_ABORT[0]
(RTM_FORCE_ABORT).
Bit 14: SERIALIZE.
Bit 15: Hybrid. If 1, the processor is identified as a hybrid part. If CPUID.0.MAXLEAF 1AH and
CPUID.1A.EAX 0, then the Native Model ID Enumeration Leaf 1AH exists.
Bit 16: TSXLDTRK. If 1, the processor supports Intel TSX suspend/resume of load address tracking.
3-222
Vol. 2A
CPUID-CPU Identification
INSTRUCTION SET REFERENCE, A-L
Table 3-8. Information Returned by CPUID Instruction (Contd.)
Initial EAX
Value
Information Provided about the Processor
Bit 17: Reserved.
Bit 18: PCONFIG. Supports PCONFIG if 1.
Bit 19: Architectural LBRs. If 1, indicates support for architectural LBRs.
Bit 20: CET_IBT. Supports CET indirect branch tracking features if 1. Processors that set this bit define
bits 5:2 and bits 63:10 of the IA32_U_CET and IA32_S_CET MSRs.
Bit 21: Reserved.
Bit 22: AMX-BF16. If 1, the processor supports tile computational operations on bfloat16 numbers.
Bit 23: AVX512_FP16.
Bit 24: AMX-TILE. If 1, the processor supports tile architecture.
Bits 25: AMX-INT8. If 1, the processor supports tile computational operations on 8-bit integers.
Bit 26: Enumerates support for indirect branch restricted speculation (IBRS) and the indirect branch pre-
dictor barrier (IBPB). Processors that set this bit support the IA32_SPEC_CTRL MSR and the
IA32_PRED_CMD MSR. They allow software to set IA32_SPEC_CTRL[0] (IBRS) and IA32_PRED_CMD[0]
(IBPB).
Bit 27: Enumerates support for single thread indirect branch predictors (STIBP). Processors that set this
bit support the IA32_SPEC_CTRL MSR. They allow software to set IA32_SPEC_CTRL[1] (STIBP).
Bit 28: Enumerates support for L1D_FLUSH. Processors that set this bit support the IA32_FLUSH_CMD
MSR. They allow software to set IA32_FLUSH_CMD[0] (L1D_FLUSH).
Bit 29: Enumerates support for the IA32_ARCH_CAPABILITIES MSR.
Bit 30: Enumerates support for the IA32_CORE_CAPABILITIES MSR.
IA32_CORE_CAPABILITIES is an architectural MSR that enumerates model-specific features. A bit being
set in this MSR indicates that a model specific feature is supported; software must still consult CPUID
family/model/stepping to determine the behavior of the enumerated feature as features enumerated in
IA32_CORE_CAPABILITIES may have different behavior on different processor models. Some of these
features may have behavior that is consistent across processor models (and for which consultation of
CPUID family/model/stepping is not necessary); such features are identified explicitly where they are
documented in this manual.
Bit 31: Enumerates support for Speculative Store Bypass Disable (SSBD). Processors that set this bit sup-
port the IA32_SPEC_CTRL MSR. They allow software to set IA32_SPEC_CTRL[2] (SSBD).
NOTE:
* If ECX contains an invalid sub-leaf index, EAX/EBX/ECX/EDX return 0. Sub-leaf index n is invalid if n
exceeds the value that sub-leaf 0 returns in EAX.
Structured Extended Feature Enumeration Sub-leaf (Initial EAX Value = 07H, ECX = 1)
07H
NOTES:
Leaf 07H output depends on the initial value in ECX.
If ECX contains an invalid sub leaf index, EAX/EBX/ECX/EDX return 0.
EAX
This field reports 0 if the sub-leaf index, 1, is invalid.
Bits 03-00: Reserved.
Bit 04: AVX-VNNI. AVX (VEX-encoded) versions of the Vector Neural Network Instructions.
Bit 05: AVX512_BF16. Vector Neural Network Instructions supporting BFLOAT16 inputs and conversion
instructions from IEEE single precision.
Bits 09-06: Reserved.
Bit 10: If 1, supports fast zero-length REP MOVSB.
Bit 11: If 1, supports fast short REP STOSB.
Bit 12: If 1, supports fast short REP CMPSB, REP SCASB.
Bits 21-13: Reserved.
Bit 22: HRESET. If 1, supports history reset via the HRESET instruction and the IA32_HRESET_ENABLE
MSR. When set, indicates that the Processor History Reset Leaf (EAX = 20H) is valid.
Bits 29-23: Reserved.
CPUID-CPU Identification
Vol. 2A
3-223
INSTRUCTION SET REFERENCE, A-L
Table 3-8. Information Returned by CPUID Instruction (Contd.)
Initial EAX
Value
Information Provided about the Processor
Bit 30: INVD_DISABLE_POST_BIOS_DONE. If 1, supports INVD execution prevention after BIOS Done.
Bit 31: Reserved.
EBX
This field reports 0 if the sub-leaf index, 1, is invalid.
Bit 00: Enumerates the presence of the IA32_PPIN and IA32_PPIN_CTL MSRs. If 1, these MSRs are sup-
ported.
Bits 31-01: Reserved.
ECX
This field reports 0 if the sub-leaf index, 1, is invalid; otherwise it is reserved.
EDX
This field reports 0 if the sub-leaf index, 1, is invalid.
Bits 17-00: Reserved.
Bit 18: CET_SSS. If 1, indicates that an operating system can enable supervisor shadow stacks as long as
it ensures that a supervisor shadow stack cannot become prematurely busy due to page faults (see Sec-
tion 17.2.3 of the Intel® 64 and IA-32 Architectures Software Developer’s Manual, Volume 1). When
emulating the CPUID instruction, a virtual-machine monitor (VMM) should return this bit as 1 only if it
ensures that VM exits cannot cause a guest supervisor shadow stack to appear to be prematurely busy.
Such a VMM could set the “prematurely busy shadow stack” VM-exit control and use the additional infor-
mation that it provides.
Bits 31-19: Reserved.
Structured Extended Feature Enumeration Sub-leaf (Initial EAX Value = 07H, ECX = 2)
07H
NOTES:
Leaf 07H output depends on the initial value in ECX.
If ECX contains an invalid sub leaf index, EAX/EBX/ECX/EDX return 0.
EAX
This field reports 0 if the sub-leaf index, 2, is invalid; otherwise it is reserved.
EBX
This field reports 0 if the sub-leaf index, 2, is invalid; otherwise it is reserved.
ECX
This field reports 0 if the sub-leaf index, 2, is invalid; otherwise it is reserved.
EDX
This field reports 0 if the sub-leaf index, 2, is invalid.
Bit 00: PSFD. If 1, indicates bit 7 of the IA32_SPEC_CTRL MSR is supported. Bit 7 of this MSR disables
Fast Store Forwarding Predictor without disabling Speculative Store Bypass.
Bit 01: IPRED_CTRL. If 1, indicates bits 3 and 4 of the IA32_SPEC_CTRL MSR are supported. Bit 3 of this
MSR enables IPRED_DIS control for CPL3. Bit 4 of this MSR enables IPRED_DIS control for CPL0/1/2.
Bit 02: RRSBA_CTRL. If 1, indicates bits 5 and 6 of the IA32_SPEC_CTRL MSR are supported. Bit 5 of this
MSR disables RRSBA behavior for CPL3. Bit 6 of this MSR disables RRSBA behavior for CPL0/1/2.
Bit 03: DDPD_U. If 1, indicates bit 8 of the IA32_SPEC_CTRL MSR is supported. Bit 8 of this MSR disables
Data Dependent Prefetcher.
Bit 04: BHI_CTRL. If 1, indicates bit 10 of the IA32_SPEC_CTRL MSR is supported. Bit 10 of this MSR
enables BHI_DIS_S behavior.
Bit 05: MCDT_NO. Processors that enumerate this bit as 1 do not exhibit MXCSR Configuration Depen-
dent Timing (MCDT) behavior and do not need to be mitigated to avoid data-dependent behavior for cer-
tain instructions.
Bits 31-06: Reserved.
Direct Cache Access Information Leaf (Initial EAX Value = 09H)
09H
EAX
Value of bits [31:0] of IA32_PLATFORM_DCA_CAP MSR (address 1F8H).
EBX
Reserved.
ECX
Reserved.
EDX
Reserved.
3-224
Vol. 2A
CPUID-CPU Identification
INSTRUCTION SET REFERENCE, A-L
Table 3-8. Information Returned by CPUID Instruction (Contd.)
Initial EAX
Value
Information Provided about the Processor
Architectural Performance Monitoring Leaf (Initial EAX Value = 0AH)
0AH
EAX
Bits 07-00: Version ID of architectural performance monitoring.
Bits 15-08: Number of general-purpose performance monitoring counter per logical processor.
Bits 23-16: Bit width of general-purpose, performance monitoring counter.
Bits 31-24: Length of EBX bit vector to enumerate architectural performance monitoring events. Archi-
tectural event x is supported if EBX[x]=0 && EAX[31:24]>x.
EBX
Bit 00: Core cycle event not available if 1 or if EAX[31:24]<1.
Bit 01: Instruction retired event not available if 1 or if EAX[31:24]<2.
Bit 02: Reference cycles event not available if 1 or if EAX[31:24]<3.
Bit 03: Last-level cache reference event not available if 1 or if EAX[31:24]<4.
Bit 04: Last-level cache misses event not available if 1 or if EAX[31:24]<5.
Bit 05: Branch instruction retired event not available if 1 or if EAX[31:24]<6.
Bit 06: Branch mispredict retired event not available if 1 or if EAX[31:24]<7.
Bit 07: Top-down slots event not available if 1 or if EAX[31:24]<8.
Bits 31-08: Reserved = 0.
ECX
Bits 31-00: Supported fixed counters bit mask. Fixed-function performance counter 'i' is supported if bit ‘i’
is 1 (first counter index starts at zero). It is recommended to use the following logic to determine if a
Fixed Counter is supported: FxCtr[i]_is_supported := ECX[i] || (EDX[4:0] > i);
EDX
Bits 04-00: Number of contiguous fixed-function performance counters starting from 0 (if Version ID >
1).
Bits 12-05: Bit width of fixed-function performance counters (if Version ID > 1).
Bits 14-13: Reserved = 0.
Bit 15: AnyThread deprecation.
Bits 31-16: Reserved = 0.
Extended Topology Enumeration Leaf (Initial EAX Value = 0BH)
0BH
NOTES:
CPUID leaf 1FH is a preferred superset to leaf 0BH. Intel recommends first checking for the existence
of Leaf 1FH before using leaf 0BH.
The sub-leaves of CPUID leaf 0BH describe an ordered hierarchy of logical processors starting from the
smallest-scoped domain of a Logical Processor (sub-leaf index 0) to the Core domain (sub-leaf index 1)
to the largest-scoped domain (the last valid sub-leaf index) that is implicitly subordinate to the
unenumerated highest-scoped domain of the processor package (socket).
The details of each valid domain is enumerated by a corresponding sub-leaf. Details for a domain
include its type and how all instances of that domain determine the number of logical processors and
x2 APIC ID partitioning at the next higher-scoped domain. The ordering of domains within the hierarchy
is fixed architecturally as shown below. For a given processor, not all domains may be relevant or
enumerated; however, the logical processor and core domains are always enumerated.
For two valid sub-leaves N and N+1, sub-leaf N+1 represents the next immediate higher-scoped
domain with respect to the domain of sub-leaf N for the given processor.
If sub-leaf index “N” returns an invalid domain type in ECX[15:08] (00H), then all sub-leaves with an
index greater than “N” shall also return an invalid domain type. A sub-leaf returning an invalid domain
always returns 0 in EAX and EBX.
EAX
Bits 04-00: The number of bits that the x2APIC ID must be shifted to the right to address instances of
the next higher-scoped domain. When logical processor is not supported by the processor, the value of
this field at the Logical Processor domain sub-leaf may be returned as either 0 (no allocated bits in the
x2APIC ID) or 1 (one allocated bit in the x2APIC ID); software should plan accordingly.
Bits 31-05: Reserved.
CPUID-CPU Identification
Vol. 2A
3-225
INSTRUCTION SET REFERENCE, A-L
Table 3-8. Information Returned by CPUID Instruction (Contd.)
Initial EAX
Value
Information Provided about the Processor
EBX
Bits 15-00: The number of logical processors across all instances of this domain within the next higher-
scoped domain. (For example, in a processor socket/package comprising “M” dies of “N” cores each, where
each core has “L” logical processors, the “die” domain sub-leaf value of this field would be M*N*L.) This
number reflects configuration as shipped by Intel. Note, software must not use this field to enumerate
processor topology*.
Bits 31-16: Reserved.
ECX
Bits 07-00: The input ECX sub-leaf index.
Bits 15-08: Domain Type. This field provides an identification value which indicates the domain as shown
below. Although domains are ordered, their assigned identification values are not and software should
not depend on it.
Hierarchy
Domain
Domain Type Identification Value
Lowest
Logical Processor
1
Highest
Core
2
(Note that enumeration values of 0 and 3-255 are reserved.)
Bits 31-16: Reserved.
EDX
Bits 31-00: x2APIC ID of the current logical processor.
NOTES:
* Software must not use the value of EBX[15:0] to enumerate processor topology of the system. The
value is only intended for display and diagnostic purposes. The actual number of logical processors avail-
able to BIOS/OS/Applications may be different from the value of EBX[15:0], depending on software and
platform hardware configurations.
Processor Extended State Enumeration Main Leaf (Initial EAX Value = 0DH, ECX = 0)
0DH
NOTES:
Leaf 0DH main leaf (ECX = 0).
EAX
Bits 31-00: Reports the supported bits of the lower 32 bits of XCR0. XCR0[n] can be set to 1 only if
EAX[n] is 1.
Bit 00: x87 state.
Bit 01: SSE state.
Bit 02: AVX state.
Bits 04-03: MPX state.
Bits 07-05: AVX-512 state.
Bit 08: Used for IA32_XSS.
Bit 09: PKRU state.
Bits 16-10: Used for IA32_XSS.
Bit 17: TILECFG state.
Bit 18: TILEDATA state.
Bits 31-19: Reserved.
EBX
Bits 31-00: Maximum size (bytes, from the beginning of the XSAVE/XRSTOR save area) required by
enabled features in XCR0. May be different than ECX if some features at the end of the XSAVE save area
are not enabled.
ECX
Bit 31-00: Maximum size (bytes, from the beginning of the XSAVE/XRSTOR save area) of the
XSAVE/XRSTOR save area required by all supported features in the processor, i.e., all the valid bit fields in
XCR0.
EDX
Bit 31-00: Reports the supported bits of the upper 32 bits of XCR0. XCR0[n+32] can be set to 1 only if
EDX[n] is 1.
Bits 31-00: Reserved.
3-226
Vol. 2A
CPUID-CPU Identification
INSTRUCTION SET REFERENCE, A-L
Table 3-8. Information Returned by CPUID Instruction (Contd.)
Initial EAX
Value
Information Provided about the Processor
Processor Extended State Enumeration Sub-leaf (Initial EAX Value = 0DH, ECX = 1)
0DH
EAX
Bit 00: XSAVEOPT is available.
Bit 01: Supports XSAVEC and the compacted form of XRSTOR if set.
Bit 02: Supports XGETBV with ECX = 1 if set.
Bit 03: Supports XSAVES/XRSTORS and IA32_XSS if set.
Bit 04: Supports extended feature disable (XFD) if set.
Bits 31-05: Reserved.
EBX
Bits 31-00: The size in bytes of the XSAVE area containing all states enabled by XCRO | IA32_XSS.
NOTES:
If EAX[3] is enumerated as 0 and EAX[1] is enumerated as 1, EBX enumerates the size of the XSAVE area
containing all states enabled by XCRO. If EAX[1] and EAX[3] are both enumerated as 0, EBX enumerates
zero.
ECX
Bits 31-00: Reports the supported bits of the lower 32 bits of the IA32_XSS MSR. IA32_XSS[n] can be
set to 1 only if ECX[n] is 1.
Bits 07-00: Used for XCR0.
Bit 08: PT state.
Bit 09: Used for XCR0.
Bit 10: PASID state.
Bit 11: CET user state.
Bit 12: CET supervisor state.
Bit 13: HDC state.
Bit 14: UINTR state.
Bit 15: LBR state (only for the architectural LBR feature).
Bit 16: HWP state.
Bits 18-17: Used for XCR0.
Bits 31-19: Reserved.
EDX
Bits 31-00: Reports the supported bits of the upper 32 bits of the IA32_XSS MSR. IA32_XSS[n+32] can
be set to 1 only if EDX[n] is 1.
Bits 31-00: Reserved.
Processor Extended State Enumeration Sub-leaves (Initial EAX Value = 0DH, ECX = n, n > 1)
0DH
NOTES:
Leaf 0DH output depends on the initial value in ECX.
Each sub-leaf index (starting at position 2) is supported if it corresponds to a supported bit in either the
XCR0 register or the IA32_XSS MSR.
* If ECX contains an invalid sub-leaf index, EAX/EBX/ECX/EDX return 0. Sub-leaf n (0 ≤ n ≤ 31) is invalid
if sub-leaf 0 returns 0 in EAX[n] and sub-leaf 1 returns 0 in ECX[n]. Sub-leaf n (32 ≤ n ≤ 63) is invalid if
sub-leaf 0 returns 0 in EDX[n-32] and sub-leaf 1 returns 0 in EDX[n-32].
EAX
Bits 31-00: The size in bytes (from the offset specified in EBX) of the save area for an extended state
feature associated with a valid sub-leaf index, n.
EBX
Bits 31-00: The offset in bytes of this extended state component’s save area from the beginning of the
XSAVE/XRSTOR area.
This field reports 0 if the sub-leaf index, n, does not map to a valid bit in the XCR0 register*.
ECX
Bit 00 is set if the bit n (corresponding to the sub-leaf index) is supported in the IA32_XSS MSR; it is clear
if bit n is instead supported in XCR0.
Bit 01 is set if, when the compacted format of an XSAVE area is used, this extended state component
located on the next 64-byte boundary following the preceding state component (otherwise, it is located
immediately following the preceding state component).
Bits 31-02 are reserved.
This field reports 0 if the sub-leaf index, n, is invalid*.
CPUID-CPU Identification
Vol. 2A
3-227
INSTRUCTION SET REFERENCE, A-L
Table 3-8. Information Returned by CPUID Instruction (Contd.)
Initial EAX
Value
Information Provided about the Processor
EDX
This field reports 0 if the sub-leaf index, n, is invalid*; otherwise it is reserved.
Intel® Resource Director Technology (Intel® RDT) Monitoring Enumeration Sub-leaf (Initial EAX Value = 0FH, ECX = 0)
0FH
NOTES:
Leaf 0FH output depends on the initial value in ECX.
Sub-leaf index 0 reports valid resource type starting at bit position 1 of EDX.
EAX
Reserved.
EBX
Bits 31-00: Maximum range (zero-based) of RMID within this physical processor of all types.
ECX
Reserved.
EDX
Bit 00: Reserved.
Bit 01: Supports L3 Cache Intel RDT Monitoring if 1.
Bits 31-02: Reserved.
L3 Cache Intel® RDT Monitoring Capability Enumeration Sub-leaf (Initial EAX Value = 0FH, ECX = 1)
0FH
NOTES:
Leaf 0FH output depends on the initial value in ECX.
EAX
Bits 07-00:The counter width is encoded as an offset from 24b. A value of zero in this field indicates that
24-bit counters are supported. A value of 8 in this field indicates that 32-bit counters are supported.
Bit 08: If 1, indicates the presence of an overflow bit in the IA32_QM_CTR MSR (bit 61).
Bit 09: If 1, indicates the presence of non-CPU agent Intel RDT CMT support.
Bit 10: If 1, indicates the presence of non-CPU agent Intel RDT MBM support.
Bits 31-11: Reserved.
EBX
Bits 31-00: Conversion factor from reported IA32_QM_CTR value to occupancy metric (bytes) and Mem-
ory Bandwidth Monitoring (MBM) metrics.
ECX
Maximum range (zero-based) of RMID of this resource type.
EDX
Bit 00: Supports L3 occupancy monitoring if 1.
Bit 01: Supports L3 Total Bandwidth monitoring if 1.
Bit 02: Supports L3 Local Bandwidth monitoring if 1.
Bits 31-03: Reserved.
Intel® Resource Director Technology (Intel® RDT) Allocation Enumeration Sub-leaf (Initial EAX Value = 10H, ECX = 0)
10H
NOTES:
Leaf 10H output depends on the initial value in ECX.
Sub-leaf index 0 reports valid resource identification (ResID) starting at bit position 1 of EBX.
EAX
Reserved.
EBX
Bit 00: Reserved.
Bit 01: Supports L3 Cache Allocation Technology if 1.
Bit 02: Supports L2 Cache Allocation Technology if 1.
Bit 03: Supports Memory Bandwidth Allocation if 1.
Bits 31-04: Reserved.
ECX
Reserved.
EDX
Reserved.
L3 Cache Allocation Technology Enumeration Sub-leaf (Initial EAX Value = 10H, ECX = ResID =1)
10H
NOTES:
Leaf 10H output depends on the initial value in ECX.
3-228
Vol. 2A
CPUID-CPU Identification
INSTRUCTION SET REFERENCE, A-L
Table 3-8. Information Returned by CPUID Instruction (Contd.)
Initial EAX
Value
Information Provided about the Processor
EAX
Bits 04-00: Length of the capacity bit mask for the corresponding ResID. Add one to the return value to
get the result.
Bits 31-05: Reserved.
EBX
Bits 31-00: Bit-granular map of isolation/contention of allocation units.
ECX
Bit 00: Reserved.
Bit 01: If 1, indicates L3 CAT for non-CPU agents is supported.
Bit 02: If 1, indicates L3 Code and Data Prioritization Technology is supported.
Bit 03: If 1, indicates non-contiguous capacity bitmask is supported. The bits that are set in the various
IA32_L3_MASK_n registers do not have to be contiguous.
Bits 31-04: Reserved.
EDX
Bits 15-00: Highest Class of Service (COS) number supported for this ResID.
Bits 31-16: Reserved.
L2 Cache Allocation Technology Enumeration Sub-leaf (Initial EAX Value = 10H, ECX = ResID =2)
10H
NOTES:
Leaf 10H output depends on the initial value in ECX.
EAX
Bits 04-00: Length of the capacity bit mask for the corresponding ResID. Add one to the return value to
get the result.
Bits 31-05: Reserved.
EBX
Bits 31-00: Bit-granular map of isolation/contention of allocation units.
ECX
Bits 01-00: Reserved.
Bit 02: CDP. If 1, indicates L2 Code and Data Prioritization Technology is supported.
Bit 03: If 1, indicates non-contiguous capacity bitmask is supported. The bits that are set in the various
IA32_L2_MASK_n registers do not have to be contiguous.
Bits 31-04: Reserved.
EDX
Bits 15-00: Highest COS number supported for this ResID.
Bits 31-16: Reserved.
Memory Bandwidth Allocation Enumeration Sub-leaf (Initial EAX Value = 10H, ECX = ResID =3)
10H
NOTES:
Leaf 10H output depends on the initial value in ECX.
EAX
Bits 11-00: Reports the maximum MBA throttling value supported for the corresponding ResID. Add one
to the return value to get the result.
Bits 31-12: Reserved.
EBX
Bits 31-00: Reserved.
ECX
Bits 01-00: Reserved.
Bit 02: Reports whether the response of the delay values is linear.
Bits 31-03: Reserved.
EDX
Bits 15-00: Highest COS number supported for this ResID.
Bits 31-16: Reserved.
Intel® SGX Capability Enumeration Leaf, Sub-leaf 0 (Initial EAX Value = 12H, ECX = 0)
12H
NOTES:
Leaf 12H sub-leaf 0 (ECX = 0) is supported if CPUID.(EAX=07H, ECX=0H):EBX[SGX] = 1.
CPUID-CPU Identification
Vol. 2A
3-229
INSTRUCTION SET REFERENCE, A-L
Table 3-8. Information Returned by CPUID Instruction (Contd.)
Initial EAX
Value
Information Provided about the Processor
EAX
Bit 00: SGX1. If 1, Indicates Intel SGX supports the collection of SGX1 leaf functions.
Bit 01: SGX2. If 1, Indicates Intel SGX supports the collection of SGX2 leaf functions.
Bits 04-02: Reserved.
Bit 05: If 1, indicates Intel SGX supports ENCLV instruction leaves EINCVIRTCHILD, EDECVIRTCHILD, and
ESETCONTEXT.
Bit 06: If 1, indicates Intel SGX supports ENCLS instruction leaves ETRACKC, ERDINFO, ELDBC, and ELDUC.
Bit 07: If 1, indicates Intel SGX supports ENCLU instruction leaf EVERIFYREPORT2.
Bits 09-08: Reserved.
Bit 10: If 1, indicates Intel SGX supports ENCLS instruction leaf EUPDATESVN.
Bit 11: If 1, indicates Intel SGX supports ENCLU instruction leaf EDECCSSA.
Bits 31-12: Reserved.
EBX
Bits 31-00: MISCSELECT. Bit vector of supported extended SGX features.
ECX
Bits 31-00: Reserved.
EDX
Bits 07-00: MaxEnclaveSize_Not64. The maximum supported enclave size in non-64-bit mode is
2^(EDX[7:0]).
Bits 15-08: MaxEnclaveSize_64. The maximum supported enclave size in 64-bit mode is 2^(EDX[15:8]).
Bits 31-16: Reserved.
Intel SGX Attributes Enumeration Leaf, Sub-leaf 1 (Initial EAX Value = 12H, ECX = 1)
12H
NOTES:
Leaf 12H sub-leaf 1 (ECX = 1) is supported if CPUID.(EAX=07H, ECX=0H):EBX[SGX] = 1.
EAX
Bit 31-00: Reports the valid bits of SECS.ATTRIBUTES[31:0] that software can set with ECREATE.
EBX
Bit 31-00: Reports the valid bits of SECS.ATTRIBUTES[63:32] that software can set with ECREATE.
ECX
Bit 31-00: Reports the valid bits of SECS.ATTRIBUTES[95:64] that software can set with ECREATE.
EDX
Bit 31-00: Reports the valid bits of SECS.ATTRIBUTES[127:96] that software can set with ECREATE.
Intel® SGX EPC Enumeration Leaf, Sub-leaves (Initial EAX Value = 12H, ECX = 2 or higher)
12H
NOTES:
Leaf 12H sub-leaf 2 or higher (ECX >= 2) is supported if CPUID.(EAX=07H, ECX=0H):EBX[SGX] = 1.
For sub-leaves (ECX = 2 or higher), definition of EDX,ECX,EBX,EAX[31:4] depends on the sub-leaf type
listed below.
EAX
Bit 03-00: Sub-leaf Type
0000b: Indicates this sub-leaf is invalid.
0001b: This sub-leaf enumerates an EPC section. EBX:EAX and EDX:ECX provide information on the
Enclave Page Cache (EPC) section.
All other type encodings are reserved.
Type
0000b. This sub-leaf is invalid.
EDX:ECX:EBX:EAX return 0.
3-230
Vol. 2A
CPUID-CPU Identification
INSTRUCTION SET REFERENCE, A-L
Table 3-8. Information Returned by CPUID Instruction (Contd.)
Initial EAX
Value
Information Provided about the Processor
Type
0001b. This sub-leaf enumerates an EPC sections with EDX:ECX, EBX:EAX defined as follows.
EAX[11:04]: Reserved (enumerate 0).
EAX[31:12]: Bits 31:12 of the physical address of the base of the EPC section.
EBX[19:00]: Bits 51:32 of the physical address of the base of the EPC section.
EBX[31:20]: Reserved.
ECX[03:00]: EPC section property encoding defined as follows:
If ECX[3:0] = 0000b, then all bits of the EDX:ECX pair are enumerated as 0.
If ECX[3:0] = 0001b, then this section has confidentiality and integrity protection.
If ECX[3:0] = 0010b, then this section has confidentiality protection only.
All other encodings are reserved.
ECX[11:04]: Reserved (enumerate 0).
ECX[31:12]: Bits 31:12 of the size of the corresponding EPC section within the Processor Reserved
Memory.
EDX[19:00]: Bits 51:32 of the size of the corresponding EPC section within the Processor Reserved
Memory.
EDX[31:20]: Reserved.
Intel® Processor Trace Enumeration Main Leaf (Initial EAX Value = 14H, ECX = 0)
14H
NOTES:
Leaf 14H main leaf (ECX = 0).
EAX
Bits 31-00: Reports the maximum sub-leaf supported in leaf 14H.
EBX
Bit 00: If 1, indicates that IA32_RTIT_CTL.CR3Filter can be set to 1, and that IA32_RTIT_CR3_MATCH
MSR can be accessed.
Bit 01: If 1, indicates support of Configurable PSB and Cycle-Accurate Mode.
Bit 02: If 1, indicates support of IP Filtering, TraceStop filtering, and preservation of Intel PT MSRs across
warm reset.
Bit 03: If 1, indicates support of MTC timing packet and suppression of COFI-based packets.
Bit 04: If 1, indicates support of PTWRITE. Writes can set IA32_RTIT_CTL[12] (PTWEn) and
IA32_RTIT_CTL[5] (FUPonPTW), and PTWRITE can generate packets.
Bit 05: If 1, indicates support of Power Event Trace. Writes can set IA32_RTIT_CTL[4] (PwrEvtEn),
enabling Power Event Trace packet generation.
Bit 06: If 1, indicates support for PSB and PMI preservation. Writes can set IA32_RTIT_CTL[56] (InjectPsb-
PmiOnEnable), enabling the processor to set IA32_RTIT_STATUS[7] (PendTopaPMI) and/or IA32_R-
TIT_STATUS[6] (PendPSB) in order to preserve ToPA PMIs and/or PSBs otherwise lost due to Intel PT
disable. Writes can also set PendToPAPMI and PendPSB.
Bit 07: If 1, writes can set IA32_RTIT_CTL[31] (EventEn), enabling Event Trace packet generation.
Bit 08: If 1, writes can set IA32_RTIT_CTL[55] (DisTNT), disabling TNT packet generation.
Bit 31-09: Reserved.
ECX
Bit 00: If 1, Tracing can be enabled with IA32_RTIT_CTL.ToPA = 1, hence utilizing the ToPA output
scheme; IA32_RTIT_OUTPUT_BASE and IA32_RTIT_OUTPUT_MASK_PTRS MSRs can be accessed.
Bit 01: If 1, ToPA tables can hold any number of output entries, up to the maximum allowed by the
MaskOrTableOffset field of IA32_RTIT_OUTPUT_MASK_PTRS.
Bit 02: If 1, indicates support of Single-Range Output scheme.
Bit 03: If 1, indicates support of output to Trace Transport subsystem.
Bit 30-04: Reserved.
Bit 31: If 1, generated packets which contain IP payloads have LIP values, which include the CS base com-
ponent.
EDX
Bits 31-00: Reserved.
CPUID-CPU Identification
Vol. 2A
3-231
INSTRUCTION SET REFERENCE, A-L
Table 3-8. Information Returned by CPUID Instruction (Contd.)
Initial EAX
Value
Information Provided about the Processor
Intel® Processor Trace Enumeration Sub-leaf (Initial EAX Value = 14H, ECX = 1)
14H
EAX
Bits 02-00: Number of configurable Address Ranges for filtering.
Bits 15-03: Reserved.
Bits 31-16: Bitmap of supported MTC period encodings.
EBX
Bits 15-00: Bitmap of supported Cycle Threshold value encodings.
Bit 31-16: Bitmap of supported Configurable PSB frequency encodings.
ECX
Bits 31-00: Reserved.
EDX
Bits 31-00: Reserved.
Time Stamp Counter and Nominal Core Crystal Clock Information Leaf (Initial EAX Value = 15H)
15H
NOTES:
If EBX[31:0] is 0, the TSC/”core crystal clock” ratio is not enumerated.
EBX[31:0]/EAX[31:0] indicates the ratio of the TSC frequency and the core crystal clock frequency.
If ECX is 0, the nominal core crystal clock frequency is not enumerated.
“TSC frequency” = “core crystal clock frequency” * EBX/EAX.
The core crystal clock may differ from the reference clock, bus clock, or core clock frequencies.
EAX
Bits 31-00: An unsigned integer which is the denominator of the TSC/”core crystal clock” ratio.
EBX
Bits 31-00: An unsigned integer which is the numerator of the TSC/”core crystal clock” ratio.
ECX
Bits 31-00: An unsigned integer which is the nominal frequency of the core crystal clock in Hz.
EDX
Bits 31-00: Reserved = 0.
Processor Frequency Information Leaf (Initial EAX Value = 16H)
16H
EAX
Bits 15-00: Processor Base Frequency (in MHz).
Bits 31-16: Reserved =0.
EBX
Bits 15-00: Maximum Frequency (in MHz).
Bits 31-16: Reserved = 0.
ECX
Bits 15-00: Bus (Reference) Frequency (in MHz).
Bits 31-16: Reserved = 0.
EDX
Reserved.
NOTES:
* Data is returned from this interface in accordance with the processor's specification and does not reflect
actual values. Suitable use of this data includes the display of processor information in like manner to the
processor brand string and for determining the appropriate range to use when displaying processor
information e.g. frequency history graphs. The returned information should not be used for any other
purpose as the returned information does not accurately correlate to information / counters returned by
other processor interfaces.
While a processor may support the Processor Frequency Information leaf, fields that return a value of
zero are not supported.
System-On-Chip Vendor Attribute Enumeration Main Leaf (Initial EAX Value = 17H, ECX = 0)
17H
NOTES:
Leaf 17H main leaf (ECX = 0).
Leaf 17H output depends on the initial value in ECX.
Leaf 17H sub-leaves 1 through 3 reports SOC Vendor Brand String.
Leaf 17H is valid if MaxSOCID_Index >= 3.
Leaf 17H sub-leaves 4 and above are reserved.
3-232
Vol. 2A
CPUID-CPU Identification
INSTRUCTION SET REFERENCE, A-L
Table 3-8. Information Returned by CPUID Instruction (Contd.)
Initial EAX
Value
Information Provided about the Processor
EAX
Bits 31-00: MaxSOCID_Index. Reports the maximum input value of supported sub-leaf in leaf 17H.
EBX
Bits 15-00: SOC Vendor ID.
Bit 16: IsVendorScheme. If 1, the SOC Vendor ID field is assigned via an industry standard enumeration
scheme. Otherwise, the SOC Vendor ID field is assigned by Intel.
Bits 31-17: Reserved = 0.
ECX
Bits 31-00: Project ID. A unique number an SOC vendor assigns to its SOC projects.
EDX
Bits 31-00: Stepping ID. A unique number within an SOC project that an SOC vendor assigns.
System-On-Chip Vendor Attribute Enumeration Sub-leaf (Initial EAX Value = 17H, ECX = 1..3)
17H
EAX
Bit 31-00: SOC Vendor Brand String. UTF-8 encoded string.
EBX
Bit 31-00: SOC Vendor Brand String. UTF-8 encoded string.
ECX
Bit 31-00: SOC Vendor Brand String. UTF-8 encoded string.
EDX
Bit 31-00: SOC Vendor Brand String. UTF-8 encoded string.
NOTES:
Leaf 17H output depends on the initial value in ECX.
SOC Vendor Brand String is a UTF-8 encoded string padded with trailing bytes of 00H.
The complete SOC Vendor Brand String is constructed by concatenating in ascending order of
EAX:EBX:ECX:EDX and from the sub-leaf 1 fragment towards sub-leaf 3.
System-On-Chip Vendor Attribute Enumeration Sub-leaves (Initial EAX Value = 17H, ECX > MaxSOCID_Index)
17H
NOTES:
Leaf 17H output depends on the initial value in ECX.
EAX
Bits 31-00: Reserved = 0.
EBX
Bits 31-00: Reserved = 0.
ECX
Bits 31-00: Reserved = 0.
EDX
Bits 31-00: Reserved = 0.
Deterministic Address Translation Parameters Main Leaf (Initial EAX Value = 18H, ECX = 0)
18H
NOTES:
Each sub-leaf enumerates a different address translation structure.
If ECX contains an invalid sub-leaf index, EAX/EBX/ECX/EDX return 0. Sub-leaf index n is invalid if n
exceeds the value that sub-leaf 0 returns in EAX. A sub-leaf index is also invalid if EDX[4:0] returns 0.
Valid sub-leaves do not need to be contiguous or in any particular order. A valid sub-leaf may be in a
higher input ECX value than an invalid sub-leaf or than a valid sub-leaf of a higher or lower-level struc-
ture.
* Some unified TLBs will allow a single TLB entry to satisfy data read/write and instruction fetches.
Others will require separate entries (e.g., one loaded on data read/write and another loaded on an
instruction fetch). See the Intel® 64 and IA-32 Architectures Optimization Reference Manual for details
of a particular product.
** Add one to the return value to get the result.
EAX
Bits 31-00: Reports the maximum input value of supported sub-leaf in leaf 18H.
CPUID-CPU Identification
Vol. 2A
3-233
INSTRUCTION SET REFERENCE, A-L
Table 3-8. Information Returned by CPUID Instruction (Contd.)
Initial EAX
Value
Information Provided about the Processor
EBX
Bit 00: 4K page size entries supported by this structure.
Bit 01: 2MB page size entries supported by this structure.
Bit 02: 4MB page size entries supported by this structure.
Bit 03: 1 GB page size entries supported by this structure.
Bits 07-04: Reserved.
Bits 10-08: Partitioning (0: Soft partitioning between the logical processors sharing this structure).
Bits 15-11: Reserved.
Bits 31-16: W = Ways of associativity.
ECX
Bits 31-00: S = Number of Sets.
EDX
Bits 04-00: Translation cache type field.
00000b: Null (indicates this sub-leaf is not valid).
00001b: Data TLB.
00010b: Instruction TLB.
00011b: Unified TLB*.
00100b: Load Only TLB. Hit on loads; fills on both loads and stores.
00101b: Store Only TLB. Hit on stores; fill on stores.
All other encodings are reserved.
Bits 07-05: Translation cache level (starts at 1).
Bit 08: Fully associative structure.
Bits 13-09: Reserved.
Bits 25-14: Maximum number of addressable IDs for logical processors sharing this translation cache.**
Bits 31-26: Reserved.
Deterministic Address Translation Parameters Sub-leaf (Initial EAX Value = 18H, ECX ≥ 1)
18H
NOTES:
Each sub-leaf enumerates a different address translation structure.
If ECX contains an invalid sub-leaf index, EAX/EBX/ECX/EDX return 0. Sub-leaf index n is invalid if n
exceeds the value that sub-leaf 0 returns in EAX. A sub-leaf index is also invalid if EDX[4:0] returns 0.
Valid sub-leaves do not need to be contiguous or in any particular order. A valid sub-leaf may be in a
higher input ECX value than an invalid sub-leaf or than a valid sub-leaf of a higher or lower-level struc-
ture.
* Some unified TLBs will allow a single TLB entry to satisfy data read/write and instruction fetches.
Others will require separate entries (e.g., one loaded on data read/write and another loaded on an
instruction fetch. See the Intel® 64 and IA-32 Architectures Optimization Reference Manual for details
of a particular product.
** Add one to the return value to get the result.
EAX
Bits 31-00: Reserved.
EBX
Bit 00: 4K page size entries supported by this structure.
Bit 01: 2MB page size entries supported by this structure.
Bit 02: 4MB page size entries supported by this structure.
Bit 03: 1 GB page size entries supported by this structure.
Bits 07-04: Reserved.
Bits 10-08: Partitioning (0: Soft partitioning between the logical processors sharing this structure).
Bits 15-11: Reserved.
Bits 31-16: W = Ways of associativity.
ECX
Bits 31-00: S = Number of Sets.
3-234
Vol. 2A
CPUID-CPU Identification
INSTRUCTION SET REFERENCE, A-L
Table 3-8. Information Returned by CPUID Instruction (Contd.)
Initial EAX
Value
Information Provided about the Processor
EDX
Bits 04-00: Translation cache type field.
0000b: Null (indicates this sub-leaf is not valid).
0001b: Data TLB.
0010b: Instruction TLB.
0011b: Unified TLB*.
All other encodings are reserved.
Bits 07-05: Translation cache level (starts at 1).
Bit 08: Fully associative structure.
Bits 13-09: Reserved.
Bits 25-14: Maximum number of addressable IDs for logical processors sharing this translation cache**
Bits 31-26: Reserved.
Key Locker Leaf (Initial EAX Value = 19H)
19H
EAX
Bit 00: Key Locker restriction of CPL0-only supported.
Bit 01: Key Locker restriction of no-encrypt supported.
Bit 02: Key Locker restriction of no-decrypt supported.
Bits 31-03: Reserved.
EBX
Bit 00: AESKLE. If 1, the AES Key Locker instructions are fully enabled.
Bit 01: Reserved.
Bit 02: If 1, the AES wide Key Locker instructions are supported.
Bit 03: Reserved.
Bit 04: If 1, the platform supports the Key Locker MSRs (IA32_COPY_LOCAL_TO_PLATFORM,
IA23_COPY_PLATFORM_TO_LOCAL, IA32_COPY_STATUS, and IA32_IWKEYBACKUP_STATUS) and backing
up the internal wrapping key.
Bits 31-05: Reserved.
ECX
Bit 00: If 1, the NoBackup parameter to LOADIWKEY is supported.
Bit 01: If 1, KeySource encoding of 1 (randomization of the internal wrapping key) is supported.
Bits 31-02: Reserved.
EDX
Reserved.
Native Model ID Enumeration Leaf (Initial EAX Value = 1AH, ECX = 0)
1AH
NOTES:
This leaf exists on all hybrid parts, however this leaf is not only available on hybrid parts. The following
algorithm is used for detection of this leaf:
If CPUID.0.MAXLEAF 1AH and CPUID.1A.EAX 0, then the leaf exists.
EAX
Enumerates the native model ID and core type.
Bits 31-24: Core type*
10H: Reserved
20H: Intel Atom®
30H: Reserved
40H: Intel® Core™
Bits 23-00: Native model ID of the core. The core-type and native model ID can be used to uniquely
identify the microarchitecture of the core. This native model ID is not unique across core types, and not
related to the model ID reported in CPUID leaf 01H, and does not identify the SOC.
* The core type may only be used as an identification of the microarchitecture for this logical processor
and its numeric value has no significance, neither large nor small. This field neither implies nor expresses
any other attribute to this logical processor and software should not assume any.
EBX
Reserved.
ECX
Reserved.
EDX
Reserved.
CPUID-CPU Identification
Vol. 2A
3-235
INSTRUCTION SET REFERENCE, A-L
Table 3-8. Information Returned by CPUID Instruction (Contd.)
Initial EAX
Value
Information Provided about the Processor
PCONFIG Information Sub-leaf (Initial EAX Value = 1BH, ECX ≥ 0)
1BH
For details on this sub-leaf, see “INPUT EAX = 1BH: Returns PCONFIG Information” on page 3-253.
NOTE:
Leaf 1BH is supported if CPUID.(EAX=07H, ECX=0H):EDX[18] = 1.
Last Branch Records Information Leaf (Initial EAX Value = 1CH)
1CH
NOTE:
This leaf pertains to the architectural feature.
EAX
Bits 07-00: Supported LBR Depth Values. For each bit n set in this field, the IA32_LBR_DEPTH.DEPTH
value 8*(n+1) is supported.
Bits 29-08: Reserved.
Bit 30: Deep C-state Reset. If set, indicates that LBRs may be cleared on an MWAIT that requests a C-state
numerically greater than C1.
Bit 31: IP Values Contain LIP. If set, LBR IP values contain LIP. If clear, IP values contain Effective IP.
EBX
Bit 00: CPL Filtering Supported. If set, the processor supports setting IA32_LBR_CTL[2:1] to non-zero
value.
Bit 01: Branch Filtering Supported. If set, the processor supports setting IA32_LBR_CTL[22:16] to non-
zero value.
Bit 02: Call-stack Mode Supported. If set, the processor supports setting IA32_LBR_CTL[3] to 1.
Bits 31-03: Reserved.
ECX
Bit 00: Mispredict Bit Supported. IA32_LBR_x_INFO[63] holds indication of branch misprediction
(MISPRED).
Bit 01: Timed LBRs Supported. IA32_LBR_x_INFO[15:0] holds CPU cycles since last LBR entry (CYC_CNT),
and IA32_LBR_x_INFO[60] holds an indication of whether the value held there is valid (CYC_CNT_VALID).
Bit 02: Branch Type Field Supported. IA32_LBR_INFO_x[59:56] holds indication of the recorded
operation's branch type (BR_TYPE).
Bits 31-03: Reserved.
EDX
Bits 31-00: Reserved.
Tile Information Main Leaf (Initial EAX Value = 1DH, ECX = 0)
1DH
NOTES:
For sub-leaves of 1DH, they are indexed by the palette id.
Leaf 1DH sub-leaves 2 and above are reserved.
EAX
Bits 31-00: max_palette. Highest numbered palette sub-leaf. Value = 1.
EBX
Bits 31-00: Reserved = 0.
ECX
Bits 31-00: Reserved = 0.
EDX
Bits 31-00: Reserved = 0.
Tile Palette 1 Sub-leaf (Initial EAX Value = 1DH, ECX = 1)
1DH
EAX
Bits 15-00: Palette 1 total_tile_bytes. Value = 8192.
Bits 31-16: Palette 1 bytes_per_tile. Value = 1024.
EBX
Bits 15-00: Palette 1 bytes_per_row. Value = 64.
Bits 31-16: Palette 1 max_names (number of tile registers). Value = 8.
ECX
Bits 15-00: Palette 1 max_rows. Value = 16.
Bits 31-16: Reserved = 0.
EDX
Bits 31-00: Reserved = 0.
3-236
Vol. 2A
CPUID-CPU Identification
INSTRUCTION SET REFERENCE, A-L
Table 3-8. Information Returned by CPUID Instruction (Contd.)
Initial EAX
Value
Information Provided about the Processor
TMUL Information Main Leaf (Initial EAX Value = 1EH, ECX = 0)
1EH
NOTE:
Leaf 1EH sub-leaves 1 and above are reserved.
EAX
Bits 31-00: Reserved = 0.
EBX
Bits 07-00: tmul_maxk (rows or columns). Value = 16.
Bits 23-08: tmul_maxn (column bytes). Value = 64.
Bits 31-24: Reserved = 0.
ECX
Bits 31-00: Reserved = 0.
EDX
Bits 31-00: Reserved = 0.
V2 Extended Topology Enumeration Leaf (Initial EAX Value = 1FH)
1FH
NOTES:
CPUID leaf 1FH is a preferred superset to leaf 0BH. Intel recommends using leaf 1FH when available
rather than leaf 0BH and ensuring that any leaf 0BH algorithms are updated to support leaf 1FH.
The sub-leaves of CPUID leaf 1FH describe an ordered hierarchy of logical processors starting from the
smallest-scoped domain of a Logical Processor (sub-leaf index 0) to the Core domain (sub-leaf index 1)
to the largest-scoped domain (the last valid sub-leaf index) that is implicitly subordinate to the
unenumerated highest-scoped domain of the processor package (socket).
The details of each valid domain is enumerated by a corresponding sub-leaf. Details for a domain
include its type and how all instances of that domain determine the number of logical processors and
x2 APIC ID partitioning at the next higher-scoped domain. The ordering of domains within the hierarchy
is fixed architecturally as shown below. For a given processor, not all domains may be relevant or
enumerated; however, the logical processor and core domains are always enumerated. As an example,
a processor may report an ordered hierarchy consisting only of “Logical Processor,” “Core,” and “Die.”
For two valid sub-leaves N and N+1, sub-leaf N+1 represents the next immediate higher-scoped
domain with respect to the domain of sub-leaf N for the given processor.
If sub-leaf index “N” returns an invalid domain type in ECX[15:08] (00H), then all sub-leaves with an
index greater than “N” shall also return an invalid domain type. A sub-leaf returning an invalid domain
always returns 0 in EAX and EBX.
EAX
Bits 04-00: The number of bits that the x2APIC ID must be shifted to the right to address instances of
the next higher-scoped domain. When logical processor is not supported by the processor, the value of
this field at the Logical Processor domain sub-leaf may be returned as either 0 (no allocated bits in the
x2APIC ID) or 1 (one allocated bit in the x2APIC ID); software should plan accordingly.
Bits 31-05: Reserved.
EBX
Bits 15-00: The number of logical processors across all instances of this domain within the next higher-
scoped domain relative to this current logical processor. (For example, in a processor socket/package
comprising “M” dies of “N” cores each, where each core has “L” logical processors, the “die” domain sub-
leaf value of this field would be M*N*L. In an asymmetric topology this would be the summation of the
value across the lower domain level instances to create each upper domain level instance.) This number
reflects configuration as shipped by Intel. Note, software must not use this field to enumerate processor
topology*.
Bits 31-16: Reserved.
CPUID-CPU Identification
Vol. 2A
3-237
INSTRUCTION SET REFERENCE, A-L
Table 3-8. Information Returned by CPUID Instruction (Contd.)
Initial EAX
Value
Information Provided about the Processor
ECX
Bits 07-00: The input ECX sub-leaf index.
Bits 15-08: Domain Type. This field provides an identification value which indicates the domain as shown
below. Although domains are ordered, as also shown below, their assigned identification values are not
and software should not depend on it. (For example, if a new domain between core and module is speci-
fied, it will have an identification value higher than 5.)
Hierarchy
Domain
Domain Type Identification Value
Lowest
Logical Processor
1
Core
2
Module
3
Tile
4
Die
5
DieGrp
6
Highest
Package/Socket
(implied)
(Note that enumeration values of 0 and 7-255 are reserved.)
Bits 31-16: Reserved.
EDX
Bits 31-00: x2APIC ID of the current logical processor. It is always valid and does not vary with the sub-
leaf index in ECX.
NOTES:
* Software must not use the value of EBX[15:0] to enumerate processor topology of the system. The
value is only intended for display and diagnostic purposes. The actual number of logical processors avail-
able to BIOS/OS/Applications may be different from the value of EBX[15:0], depending on software and
platform hardware configurations.
Processor History Reset Sub-leaf (Initial EAX Value = 20H, ECX = 0)
20H
EAX
Reports the maximum number of sub-leaves that are supported in leaf 20H.
EBX
Indicates which bits may be set in the IA32_HRESET_ENABLE MSR to enable reset of different compo-
nents of hardware-maintained history.
Bit 00: Indicates support for both HRESET’s EAX[0] parameter, and IA32_HRESET_ENABLE[0] set by the
OS to enable reset of Intel® Thread Director history.
Bits 31-01: Reserved = 0.
ECX
Reserved.
EDX
Reserved.
Unimplemented CPUID Leaf Functions
21H
Invalid. No existing or future CPU will return processor identification or feature information if the initial
EAX value is 21H. If the value returned by CPUID.0:EAX (the maximum input value for basic CPUID
information) is at least 21H, 0 is returned in the registers EAX, EBX, ECX, and EDX. Otherwise, the data
for the highest basic information leaf is returned.
40000000H
Invalid. No existing or future CPU will return processor identification or feature information if the initial
-
EAX value is in the range 40000000H to 4FFFFFFFH.
4FFFFFFFH
Extended Function CPUID Information
80000000H
EAX
Maximum Input Value for Extended Function CPUID Information.
EBX
Reserved.
ECX
Reserved.
EDX
Reserved.
3-238
Vol. 2A
CPUID-CPU Identification
INSTRUCTION SET REFERENCE, A-L
Table 3-8. Information Returned by CPUID Instruction (Contd.)
Initial EAX
Value
Information Provided about the Processor
80000001H
EAX
Extended Processor Signature and Feature Bits.
EBX
Reserved.
ECX
Bit 00: LAHF/SAHF available in 64-bit mode.*
Bits 04-01: Reserved.
Bit 05: LZCNT.
Bits 07-06: Reserved.
Bit 08: PREFETCHW.
Bits 31-09: Reserved.
EDX
Bits 10-00: Reserved.
Bit 11: SYSCALL/SYSRET.**
Bits 19-12: Reserved = 0.
Bit 20: Execute Disable Bit available.
Bits 25-21: Reserved = 0.
Bit 26: 1-GByte pages are available if 1.
Bit 27: RDTSCP and IA32_TSC_AUX are available if 1.
Bit 28: Reserved = 0.
Bit 29: Intel® 64 Architecture available if 1.
Bits 31-30: Reserved = 0.
NOTES:
* LAHF and SAHF are always available in other modes, regardless of the enumeration of this feature flag.
** Intel processors support SYSCALL and SYSRET only in 64-bit mode. This feature flag is always enumer-
ated as 0 outside 64-bit mode.
80000002H
EAX
Processor Brand String.
EBX
Processor Brand String Continued.
ECX
Processor Brand String Continued.
EDX
Processor Brand String Continued.
80000003H
EAX
Processor Brand String Continued.
EBX
Processor Brand String Continued.
ECX
Processor Brand String Continued.
EDX
Processor Brand String Continued.
80000004H
EAX
Processor Brand String Continued.
EBX
Processor Brand String Continued.
ECX
Processor Brand String Continued.
EDX
Processor Brand String Continued.
80000005H
EAX
Reserved = 0.
EBX
Reserved = 0.
ECX
Reserved = 0.
EDX
Reserved = 0.
80000006H
EAX
Reserved = 0.
EBX
Reserved = 0.
ECX
Bits 07-00: Cache Line size in bytes.
Bits 11-08: Reserved.
Bits 15-12: L2 Associativity field *.
Bits 31-16: Cache size in 1K units.
EDX
Reserved = 0.
CPUID-CPU Identification
Vol. 2A
3-239















Content      ..      1      2      3      ..
