Kia Soul (2024 year). Manual in english

Driving your vehicle

ISG (Idle Stop and Go) system

• Under some conditions your parking

brake can freeze in the engaged posi

tion. This is most likely to happen
when there is an accumulation of snow
or ice around or near the rear brakes or
if the brakes are wet. If there is a risk
that the parking brake may freeze,
apply it only temporarily while you put
the shifter dial in P and block the rear
wheels so the vehicle cannot roll. Then
release the parking brake.

• Do not hold the vehicle on an incline

with the accelerator pedal. This can
cause the reduction gear to overheat.
Always use the brake pedal or parking
brake.

ISG (Idle Stop and Go) system

Your vehicle may be equipped with the
ISG system, which reduces fuel con

sumption by automatically shutting down
the engine, when the vehicle is at a
standstill. (For example: red light, stop
sign and traffic jam)

The engine starts automatically as soon
as the starting conditions are met.

The ISG system is ON whenever the
engine is running.

NOTICE

When the engine automatically starts by
the ISG system, some warning lights
(ABS, ESC, ESC OFF, EPS or Parking
brake warning light) may turn on for a
few seconds.

This happens because of low battery
voltage. It does not mean the system has
malfunctioned.

Auto stop

To stop the engine in idle stop
mode

Stop the vehicle completely by pressing
the brake pedal when the shift lever is in
the D (Drive) or N (Neutral) position.

OSK3042497N

Driving your vehicle

ISG (Idle Stop and Go) system

The engine will stop and the green

AUTO STOP (

) indicator on

the instrument cluster will appear.

A: Auto Stop is Off. Start vehicle man

ually

NOTICE

If you open the engine hood in auto stop
mode, the following will happen:
• The ISG system will deactivate (the

light on the ISG OFF button will
appear).

• A message will appear on the LCD dis

play.

A: Press brake pedal for Auto Start

• If you move the transmission lever from

N to D (manual mode) or R with

out

depressing the brake pedal after

stopping engine automatically, the
engine does not restart automatically
and a warning chime alarms. When
this happens, press the brake pedal
for auto start.

Auto start

To restart the engine from idle
stop mode

• Release the brake pedal.
or
• Move the shift gear to the R (Reverse)

position or the manual mode while
depressing the brake pedal.

The engine will start and the green

AUTO STOP indicator (

) on

the instrument cluster will go out.

The engine will also restart auto

matically without any driver actions
if the following occurs:

• The brake vacuum pressure is low.

僅

The engine has stopped for about 5
minutes.

• The air conditioning is ON with the fan

speed set to the highest position.

• The front defroster is ON

僅

The battery is weak.

OSK3052428N

OSK3052427N

OSK3042498N

Driving your vehicle

ISG (Idle Stop and Go) system

• The cooling and heating performance

of the climate control system is unsat

isfactory.

Condition of ISG system opera

tion

The ISG system will operate
under the following condition:

• The driver’s seatbelt is fastened
• The driver’s door and hood are closed

僅

The brake vacuum pressure is ade

quate

• The battery sensor is activated and

the battery is sufficiently charged

• Outside temperature is not too low or

too high

• The vehicle is driven over a constant

speed and stops

• The climate control system satisfies

the conditions

• The vehicle is sufficiently warmed up

僅

The incline is gradual

• The steering wheel is turned less than

180 degrees and then the vehicle
stops

NOTICE

• If the ISG system does not meet the

operation condition, the ISG system is
deactivated. The light on the ISG OFF
button will appear and a message
"Auto Stop conditions not met" will
appear on the LCD display.

• If the light or notice comes on contin

uously, please check the operation
condition.

ISG system deactivation

• If you wish to deactivate the ISG sys

tem, press the ISG OFF button (1). The
light on the ISG OFF button will
appear.

• If you press the ISG OFF button again,

the system will be activated and the
light on the ISG OFF button will turn
off.

ISG system malfunction

The system may not operate
when:

The system may not operate when an
ISG related sensor or system error
occurs.

The following will happen:

OSK3051122N

OSK3042497N

Driving your vehicle

Drive mode integrated control system

• The AUTO STOP ( ) indicator on

the instrument cluster will stay on
after blinking for 5 seconds.

• The light on the ISG OFF button will

appear.

NOTICE

If the ISG OFF button light is not turned
off by pressing the ISG OFF button again
or if the ISG system continuously does
not work correctly, have your vehicle
inspected by an authorized Kia dealer.

When the engine is in Idle Stop mode, it's
possible to restart the engine without the
driver taking any action. Before leav

ing

the car or doing anything in the engine
compartment, stop the engine by turning
the ignition switch to the LOCK/ OFF
position or removing the ignition key.

NOTICE

If the AGM battery is reconnected or
replaced, ISG function will not operate
immediately. If you want to use the ISG
function, the battery sensor needs to be
calibrated for approximately 4 hours with
the ignition off. After calibration, turn the
engine on and off 2 or 3 times.

Drive mode integrated control
system

The drive mode may be selected accord

ing to the driver's preference or road
condition.

The mode changes whenever the
DRIVE MODE button is pressed.
• NORMAL mode: NORMAL mode

pro

vides smooth driving.

• SPORT mode: SPORT mode

provides sporty driving.

The driving mode will be set to NORMAL
mode when the engine is restarted. If it is
in NORMAL mode this mode will be set,
when the engine is restarted.

SPORT mode

SPORT mode focuses

on dynamic driving.
• When the DRIVE MODE button is

pressed and the SPORT mode is
selected, the SPORT indicator will
appear.

• When the SPORT mode is activated,

and the ENGINE START/STOP
button is turned off and on it will
change to NORMAL mode. To turn on
the SPORT mode press DRIVE
MODE but

ton again.

OSK3052022L

Driving your vehicle

Economical operation

• If the system is activated:

- After increasing speed and taking

your foot off the accelerator pedal it
maintains the gear and rpm for a
short time even though the acceler

ator pedal is not depressed.

- Up-shifting is delayed.

NOTICE

In Sport drive mode, the fuel efficiency
may decrease.

Economical operation

Your vehicle's fuel economy depends
mainly on your style of driving, where
you drive and when you drive.

Each of these factors affects how many
miles (kilometers) you can get from a
gallon (liter) of fuel.To operate your vehi

cle as economically as possible, use the
following driving suggestions to help save
money in both fuel and repairs:
• Drive smoothly. Accelerate at a mod

erate rate. Don't make "jackrabbit"
starts or full-throttle shifts and main

tain a steady cruising speed. Don't
race between stoplights. Try to adjust
your speed to the traffic so you don't
have to change speeds unnecessar

ily. Avoid heavy traffic whenever pos

sible. Always maintain a safe distance
from other vehicles so you can avoid
unnecessary braking. This also
reduces brake wear.

• Drive at a moderate speed. The faster

you drive, the more fuel your vehicle
uses. Driving at a moderate speed,
especially on the highway, is one of
the most effective ways to reduce fuel
consumption.

• Don't "ride" the brake pedal. This can

increase fuel consumption and also
increase wear on these components. In
addition, driving with your foot rest

ing

on the brake pedal may cause the
brakes to overheat, which reduces
their effectiveness and may lead to
more serious consequences.

• Take care of your tires. Keep them

inflated to the recommended pres

sure. Incorrect inflation, either too
much or too little, results in unneces

sary tire wear. Check the tire pres

sures at least once a month.

Driving your vehicle

Economical operation

• Be sure that the wheels are aligned

correctly. Improper alignment can result
from hitting curbs or driving too fast
over irregular surfaces. Poor alignment
causes faster tire wear and may also
result in other problems as well as
greater fuel consumption.

• Keep your vehicle in good condition.

For better fuel economy and reduced
maintenance costs, maintain your
vehicle in accordance with "Scheduled
maintenance service" on page 8-8. If
you drive your vehicle in severe con

ditions, more frequent maintenance is
required (Refer to "Maintenance
Under Severe Usage Conditions" on
page 8-11 for details).

• Keep your vehicle clean. For maxi

mum service, your vehicle should be
kept clean and free of corrosive mate

rials. It is especially important that mud,
dirt, ice, etc. not be allowed to
accumulate on the underside of the
vehicle. This extra weight can result in
increased fuel consumption and also
contribute to corrosion.

• Travel lightly. Don't carry unnecessary

weight in your vehicle.Weight reduces
fuel economy.

• Don't let the engine idle longer than

necessary. If you are waiting (and not
in traffic), turn off your engine and
restart only when you're ready to go.

• Remember, your vehicle does not

require extended warm-up. After the
engine has started, allow the engine
to run for 10 to 20 seconds prior to
placing the vehicle in gear. In very
cold weather, however, give your
engine a slightly longer warm-up
period.

• Don't "lug" or "over-rev" the engine.

Lugging is driving too slowly in a very

high gear resulting in engine bucking.
If this happens, shift to a lower gear.
Over-revving is racing the engine
beyond its safe limit. This can be
avoided by shifting at the recom

mended speed.

• Use your air conditioning sparingly.

The air conditioning system is oper

ated by engine power so your fuel
economy is reduced when you use it.

• Open windows at high speeds can

reduce fuel economy.

• Fuel economy is less in crosswinds

and headwinds. To help offset some
of this loss, slow down when driving in
these conditions.

Keeping a vehicle in good operating
condition is important both for economy
and safety. Therefore, have an autho

rized Kia dealer perform scheduled
inspections and maintenance.

W ARNING

Engine off during motion
Never turn the engine off to coast down
hills or anytime the vehicle is in motion.
The power steering and power brakes
will not function properly without the
engine running. In addition, turning off the
ignition while driving could engage the
steering wheel lock resulting in loss of
vehicle steering. Keep the engine on and
downshift to an appropriate gear for
engine braking effect.

Driving your vehicle

Special driving conditions

If driving conditions deteriorate due to
poor weather or road conditions, you
should pay even more attention than
usual to your driving.

Hazardous driving conditions

When hazardous driving conditions are
encountered such as water, snow, ice,
mud, sand, or similar hazards, follow
these suggestions:
• Drive cautiously and allow extra dis

tance for braking.

• Avoid sudden braking or steering.
• When braking with non-ABS brakes

pump the brake pedal with a light up-
and-down motion until the vehicle is
stopped.

• Do not pump the brake pedal on a

vehicle equipped with ABS.

• If stalled in snow, mud, or sand, use

the second gear. Accelerate slowly to
avoid spinning the drive wheels.

• Use sand, rock salt, or other nonslip

material under the drive wheels to
provide traction when stalled in ice,
snow, or mud.

Reducing the risk of a rollover

This multi-purpose passenger vehicle is
defined as a Sports Utility Vehicle (SUV).
Utility vehicles have a significantly higher
rollover rate than other types of vehicles.
SUV's have higher ground clearance
and a narrower track to make them
capable of performing in a wide variety of
offroad applications.

Specific design characteristics give them
a higher center of gravity than ordinary
vehicles. An advantage of the higher
ground clearance is a better view of the

road, which allows you to anticipate
problems.

They are not designed for cornering at
the same speeds as conventional pas

senger vehicles, any more than low-
slung sports vehicles are designed to
perform satisfactorily in off-road condi

tions. Due to this risk, driver and passen

gers are strongly recommended to buckle
their seat belts.

In a rollover crash, an unbelted person is
significantly more likely to die than a
person wearing a seat belt. There are
steps that a driver can make to reduce
the risk of a rollover.

If at all possible, avoid sharp turns or
abrupt maneuvers, do not load your roof
rack with heavy cargo, and never modify
your vehicle in any way.

W ARNING

Rollover
As with other Sports Utility Vehicle
(SUV), failure to operate this vehicle cor

rectly may result in loss of control, an
accident or vehicle rollover.
• SUVs have a significantly higher roll

over rate than other types of vehicles.

• Specific design characteristics (higher

ground clearance, narrower track, etc.)
give this vehicle a higher center of
gravity than ordinary vehicles.

• A SUV is not designed for cornering at

the same speeds as conventional
vehicles.

• Avoid sharp turns or abrupt maneu

vers.

• In a rollover crash, an unbelted person

is significantly more likely to die than a
person wearing a seat belt. Make sure
everyone in the vehicle is prop

erly

buckled up.

Driving your vehicle

Special driving conditions

W ARNING

Your vehicle is equipped with tires
designed to provide safe riding and han

dling capability. Do not use a size and
type of tire and wheel that is different
from the one that is originally installed on
your vehicle. It can affect the safety and
performance of your vehicle, which could
lead to steering failure or rollover and
serious injury. When replacing the tires,
be sure to equip all four tires with the tire
and wheel of the same size, type, tread,
brand and load-carrying capacity.

Rocking the vehicle

If it is necessary to rock the vehicle to
free it from snow, sand, or mud, first turn
the steering wheel right and left to clear
the area around your front wheels. Then,
shift back and forth between R
(Reverse) and any forward gear.

Do not race the vehicle, and spin the
wheels as little as possible. If you are still
stuck after a few tries, have the vehicle
pulled out by a tow vehicle to avoid vehi

cle overheating and possible damage to
the reduction gear.

W ARNING

Sudden Vehicle Movement
Do not attempt to rock the vehicle if
people or objects are nearby. The vehi

cle may suddenly move forward or
backwards as it becomes unstuck.

CAUTION

Vehicle rocking
Prolonged rocking may cause vehicle
overheating, reduction gear damage or
failure, and tire damage.

W ARNING

Spinning tires
Do not spin the wheels, especially at
speeds more than 35 mph (56 km/h).
Spinning the wheels at high speeds
when the vehicle is stationary could
cause tires to overheat, which could
result in tire damage that may injure
bystanders.

The ESC should be turned OFF prior
to rocking the vehicle.

Smooth cornering

Avoid braking or gear changing in cor

ners, especially when roads are wet. Ide

ally, corners should always be taken
under gentle acceleration. If you follow
these suggestions, tire wear will be held
to a minimum.

Driving at night

Because night driving presents more
hazards than driving in the daylight,
here are some important tips to remem

ber:
• Slow down and keep more distance

between you and other vehicles, as it
may be more difficult to see at night,
especially in areas where there may
not be any street lights.

• Adjust your mirrors to reduce the

glare from other driver's headlights.

• Keep your headlights clean and prop

erly aimed. (On vehicles not equipped
with the automatic headlight aiming
feature.) Dirty or improperly aimed
headlights will make it much more dif

ficult to see at night.

• Avoid staring directly at the head

lights of oncoming vehicles. You could
be temporarily blinded, and it will take

Driving your vehicle

Special driving conditions

several seconds for your eyes to read

just to the darkness.

Driving in the rain

Rain and wet roads can make driving
dangerous, especially if you're not pre

pared for the slick pavement.

Here are a few things to consider when
driving in the rain:
• A heavy rainfall will make it harder to

see and will increase the distance
needed to stop your vehicle, so slow
down.

• Keep your windshield wiping equip

ment in good shape. Replace your
windshield wiper blades when they
show signs of streaking or missing
areas on the windshield.

• If your tires are not in good condition,

making a quick stop on wet pavement
can cause a skid and possibly lead to
an accident. Be sure your tires are in
good shape.

• Turn on your headlights to make it

easier for others to see you.

• Driving too fast through large puddles

can affect your brakes. If you must go
through puddles, try to drive through
them slowly.

• If you believe you may have gotten

your brakes wet, apply them lightly
while driving until normal braking
operation returns.

Driving in flooded areas

Avoid driving through flooded areas
unless you are sure the water is no
higher than the bottom of the wheel
hub. Drive through any water slowly.
Allow adequate stopping distance
because brake performance may be
affected.

After driving through water, dry the
brakes by gently applying them several
times while the vehicle is moving slowly.

Driving off-road

Drive carefully off-road because your
vehicle may be damaged by rocks or
roots of trees. Become familiar with the
off-road conditions where you are going
to drive before you begin driving.

Highway driving

Tires

Adjust the tire inflation pressures to
specification. Low tire inflation pressures
will result in overheating and possible
failure of the tires.

Avoid using worn or damaged tires
which may result in reduced traction or
tire failure.

Never exceed the maximum tire inflation
pressure shown on the tires.

W ARNING

Under/over inflated tires
Always check the tires for proper infla

tion before driving. Underinflated or
overinflated tires can cause poor han

dling, loss of vehicle control, and sudden
tire failure leading to accidents, injuries,
and even death. For proper tire pres

sures, refer to "Tires and wheels" on
page 9-5.

Driving your vehicle

Winter driving

W ARNING

Tire tread
Always check the tire tread before driv

ing your vehicle. Worn-out tires can result
in loss of vehicle control. Worn-out tires
should be replaced as soon as pos

sible.

For further information and tread limits,
refer to "Tires and wheels" on page 8-28.

Fuel, engine coolant and engine
oil

High speed travel consumes more fuel
than urban motoring. Do not forget to
check both the engine coolant and
engine oil.

Drive belt

A loose or damaged drive belt may
result in overheating of the engine.

Winter driving

Severe weather conditions in the winter
result in greater wear and other prob

lems.

To minimize the problems of winter driv

ing, you should follow these sugges

tions:

Snowy or icy conditions

To drive your vehicle in deep snow, it
may be necessary to use snow tires or to
install tire chains on your tires.

If snow tires are needed, it is necessary
to select tires equivalent in size and type
of the original equipment tires. Failure to
do so may adversely affect the safety
and handling of your vehicle. Further

more, speeding, rapid acceleration, sud

den brake applications, and sharp turns
are potentially very hazardous practices.

During deceleration, use vehicle braking
to the fullest extent. Sudden brake appli

cations on snowy or icy roads may cause
skids to occur. You need to keep suffi

cient distance between the vehicle in
operation in front of your vehicle. Also,
apply the brake gently. It should be noted
that installing tire chains on the tire will
provide a greater driving force, but will not
prevent side skids.

Tire chains are not legal in all states.
Check state laws before fitting tire
chains.

Snow tires

If you mount snow tires on your vehicle,
make sure they are radial tires of the
same size and load range as the original
tires. Mount snow tires on all four wheels
to balance your vehicle's handling in all
weather conditions. Keep in mind that the
traction provided by snow tires on

Driving your vehicle

Winter driving

dry roads may not be as high as your
vehicle's original equipment tires. You
should drive cautiously even when the
roads are clear. Check with the tire
dealer for maximum speed recommen

dations.

Do not install studded tires without first
checking local, state and municipal reg

ulations for possible restrictions against
their use.

W ARNING

Snow tire size
Snow tires should be equivalent in size
and type to the vehicle's standard tires.
Otherwise, the safety and handling of
your vehicle may be adversely affected.

Tire chains

When using tire chains, install tire chains
only on the front tires.

Since the sidewalls of radial tires are
thinner, they can be damaged by
mounting some types of snow chains on
them. Therefore, the use of snow tires is
recommended instead of snow chains.
Do not mount tire chains on vehicles
equipped with aluminum wheels; snow
chains may cause damage to the
wheels. If snow chains must be used, use

wire-type chains with a thickness of less
than 0.47 in (12 mm). Damage to your
vehicle caused by improper snow chain
use is not covered by your vehicle man

ufacturer's warranty.

Install tire chains only on the front tires.
Always check chain installation for
proper mounting after driving approxi

mately 0.3 to 0.6 miles (0.5 to 1 km) to
ensure safe mounting. Retighten or
remount the chains if they are loose.

Chain installation

When installing chains, follow the manu

facturer's instructions and mount them as
tightly possible. Make sure the snow
chains are SAE class "S" certified. Drive
slowly (less than 20 mph (30 km/h) with
chains installed. If you hear the chains
contacting the body or chassis, stop and
tighten them. If they still make contact,
slow down until it stops. Remove the
chains as soon as you begin driving on
cleared roads.

When mounting snow chains, park the
vehicle on level ground away from traf

fic. Turn on the vehicle Hazard Warning
flashers and place a triangular emer

gency warning device behind the vehicle
if available. Always place the vehicle in P
(Park), apply the parking brake and turn
off the vehicle before installing snow
chains.
• The use of chains may adversely

affect vehicle handling.

• Do not exceed 20 mph (30 km/h) or

the chain manufacturer's recom

mended speed limit, whichever is
lower.

• Drive carefully and avoid bumps,

holes, sharp turns, and other road
hazards, which may cause the vehicle
to bounce.

OSK3052045N

Driving your vehicle

Winter driving

• Avoid sharp turns or locked-wheel

braking.

CAUTION

Snow chains
• Chains that are the wrong size or

improperly installed can damage your
vehicle's brake lines, suspension,
body and wheels.

• Stop driving and retighten the chains

any time you hear them hitting the
vehicle.

Use high quality ethylene glycol
coolant

Your vehicle is delivered with high qual

ity ethylene glycol coolant in the cooling
system. It is the only type of coolant that
should be used because it helps prevent
corrosion in the cooling system, lubri

cates the water pump and prevents
freezing. Be sure to replace or replenish
your coolant refer to "Normal mainte

nance schedule" on page 8-9. Before
winter, have your coolant tested to
assure that its freezing point is sufficient
for the temperatures anticipated during
the winter.

Check battery and cables

Winter puts additional burdens on the
battery system. Visually inspect the bat

tery and cables (refer to "For best bat

tery service" on page 8-26). The level of
charge in your battery can be checked
by an authorized Kia dealer or a service
station.

Check spark plugs and ignition
system

Inspect your spark plugs as described in
"Scheduled maintenance service" on
page 8-8 and replace them if necessary.
Also check all ignition wiring and compo

nents to be sure they are not cracked,
worn or damaged in any way.

To keep locks from freezing

To keep the locks from freezing, squirt
an approved de-icer fluid or glycerine
into the key opening. If a lock is covered
with ice, squirt it with an approved de-
icing fluid to remove the ice. If the lock is
frozen internally, you may be able to
thaw it out by using a heated key. Han

dle the heated key with care to avoid
injury.

Use approved window washer
anti-freeze in system

To keep the water in the window washer
system from freezing, add an approved
window washer anti-freeze solution in
accordance with instructions on the con

tainer. Window washer anti-freeze is
available from an authorized Kia dealer
and most auto parts outlets. Do not use
vehicle coolant or other types of anti-
freeze as these may damage the paint
finish.

Don't let your parking brake
freeze

Under some conditions your parking
brake can freeze in the engaged posi

tion. This is most likely to happen when
there is an accumulation of snow or ice
around or near the rear brakes or if the
brakes are wet. If there is a risk the park

ing brake may freeze, apply it only tem

Driving your vehicle

Trailer towing

porarily while you put the gear shift dial
in P (Park) and block the rear wheels so
the vehicle cannot roll. Then release the
parking brake.

Don't let ice and snow accumu

late underneath

Under some conditions, snow and ice
can build up under the fenders and
interfere with the steering. When driving
in severe winter conditions where this
may happen, you should periodically
check underneath the vehicle to be sure
the movement of the front wheels and
the steering components are not
obstructed.

Carry emergency equipment

Depending on the severity of the
weather, you should carry appropriate
emergency equipment. Some of the
items you may want to carry include tow
straps or chains, flashlight, emergency
flares, sand, shovel, jumper cables, win

dow scraper, gloves, ground cloth, cov

eralls, blanket, etc.

Drive your vehicle when water
vapor condenses and accumu

lates inside the exhaust pipes

When the vehicle is stopped for a long
time in winter while the engine is run

ning, water vapor may condense and
accumulate inside the exhaust pipes.

Water in the exhaust pipes may cause
noise, etc., but it is drained driving at
medium to high speed.

Trailer towing

We do not recommend using this vehicle
for trailer towing.

Driving your vehicle

Vehicle load limit

The vehicle load limit is displayed on the
tire and loading information label on the
driver's door.

Tire and loading information
label

The label located on the driver's door sill
gives the original tire size, cold tire pres

sures recommended for your vehicle,
the number of people that can be in
your vehicle and vehicle capacity weight.

Vehicle capacity weight:

860 lbs. (390 kg)
Vehicle capacity weight is the maximum
combined weight of occupants and
cargo. If your vehicle is equipped with a
trailer, the combined weight includes the
tongue load.

Seating capacity:

Total: 5 persons (Front seat: 2 persons,
Rear seat: 3 persons)

Seating capacity is the maximum num

ber of occupants including a driver, your
vehicle may carry.

However, the seating capacity may be
reduced based upon the weight of all of

the occupants, and the weight of the
cargo being carried or towed.

Do not overload the vehicle as there is a
limit to the total weight, or load limit
including occupants and cargo, the vehi

cle can carry.

Towing capacity:

We do not recommend using this vehi

cle for trailer towing.

Cargo capacity:

The cargo capacity of your vehicle will
increase or decrease depending on the
weight and the number of occupants.

Steps for Determining Correct
Load Limit -

(1)Locate the statement "The combined
weight of occupants and cargo should
never exceed XXX kg or XXX lbs." on
your vehicle's placard.

(2) Determine the combined weight of
the driver and passengers that will be
riding in your vehicle.

(3) Subtract the combined weight of the
driver and passengers from XXX kg or
XXX lbs.

(4) The resulting figure equals the avail

able amount of cargo and luggage load
capacity. For example, if the "XXX"
amount equals 1400 lbs. and there will
be five 150 lb passengers in your vehi

cle, the amount of available cargo and
luggage load capacity is 650 lbs. (1400-
750 (5

× 150) = 650 lbs.)

(5) Determine the combined weight of
luggage and cargo being loaded on the
vehicle. That weight may not safely
exceed the available cargo and luggage
load capacity calculated in Step 4.

(6) If your vehicle will be towing a trailer,
load from your trailer will be transferred

OSK3068034NR

Driving your vehicle

Vehicle load limit

to your vehicle. Consult this manual to
determine how this reduces the avail

able cargo and luggage load capacity of
your vehicle.

W ARNING

Loose cargo
Do not travel with unsecured blunt
objects in the passenger compartment of
your vehicle (e.g. suit cases or unse

cured child seats). These items may
strike an occupant during a sudden stop
or crash.

Example
1

Example 2

Item

Description

Total

Vehicle Capacity

Weight

849 lbs.

(385 kg)

Subtract Occupant

Weight

150 lbs. (68 kg)

×2

300 lbs.

(136 kg)

Available Cargo and

Luggage weight

549 lbs.

(249 kg)

ODEEV078137NR

Item

Description

Total

Vehicle Capacity

Weight

849 lbs.

(385 kg)

Subtract Occupant

Weight

150 lbs. (68 kg)

×5

750 lbs.

(340 kg)

Available Cargo and

Luggage weight

99 lbs.

(45 kg)

ODEEV078138NR

Driving your vehicle

Vehicle load limit

Example 3

Refer to your vehicle's tire and loading
information label for specific information
about your vehicle's capacity weight and
seating positions. The combined weight
of the driver, passengers and cargo
should never exceed your vehicle's
capacity weight.

Certification label

The certification label is located on the
driver's door sill at the center pillar.

This label shows the maximum allowable
weight of the fully loaded vehicle. This is
called the GVWR (Gross Vehicle Weight
Rating). The GVWR includes the weight
of the vehicle, all occupants and cargo.

This label also tells you the maximum
weight that can be supported by the
front and rear axles, called Gross Axle
Weight Rating (GAWR).

To find out the actual loads on your front
and rear axles, you need to go to a
weigh station and weigh your vehicle.
Your dealer can help you with this. Be
sure to spread out your load equally on
both sides of the centerline.

W ARNING

Over loading
Never exceed the GVWR for your vehi

cle, the GAWR for either the front or rear
axle and vehicle capacity weight.
Exceeding these ratings can affect your
vehicle's handling and braking ability.

The label will help you decide how much
cargo and installed equipment your
vehicle can carry.

Item

Description

Total

Vehicle Capacity

Weight

849 lbs.

(385 kg)

Subtract Occupant

Weight

161 lbs. (73 kg)

×5

805 lbs.

(365 kg)

Available Cargo and

Luggage weight

44 lbs.

(20 kg)

ODEEV078139NR

OSK3053472N

Driving your vehicle

Vehicle weight

If you carry items inside your vehicle -
like suitcases, tools, packages, or any

thing else - they are moving as fast as
the vehicle. If you have to stop or turn
quickly, or if there is a crash, the items
will keep going and can cause an injury
if they strike the driver or a passenger.

W ARNING

Over loading
Do not overload your vehicle. Overload

ing your vehicle can cause heat buildup
in your vehicle's tires and possible tire
failure, increased stopping distances and
poor vehicle handling--all of which
may result in a crash.

NOTICE

Overloading your vehicle may cause
damage. Repairs would not be covered
by your warranty. Do not overload your
vehicle.

Vehicle weight

This chapter will guide you in the proper
loading of your vehicle and/or trailer, to
keep your loaded vehicle weight within
its design rating capability, with or with

out a trailer.

Properly loading your vehicle will pro

vide maximum return of the vehicle
design performance. Before loading
your vehicle, familiarize yourself with the
following terms for determining your
vehicle's weight ratings, with or without a
trailer, from the vehicle's specifications
and the compliance label:

Base curb weight This is the weight of

the vehicle including a full tank of fuel

and all standard equipment. It does not
include passengers, cargo, or optional
equipment.
Vehicle curb weight This is the weight
of your new vehicle when you picked it
up from your dealer plus any aftermar

ket equipment.

Cargo weight This figure includes all
weight added to the Base Curb Weight,
including cargo and optional equipment.

GAW (Gross axle weight) This is the
total weight placed on each axle (front
and rear) - including vehicle curb weight
and all payload.

GAW R (Gross axle weight rating) This
is the maximum allowable weight that
can be carried by a single axle (front or
rear). These numbers are shown on the
compliance label. The total load on each
axle must never exceed its GAWR.

GVW (Gross vehicle weight) This is the
Base Curb Weight plus actual Cargo
Weight plus passengers.

Driver assistance system

Forward Collision-Avoidance Assist (FCA)
(Front Camera Only) .....................................................................6-4

•

Forward Collision-Avoidance Assist settings ....................................... 6-
4

•

Forward Collision-Avoidance Assist operation ................................... 6-7

僅

Forward Collision-Avoidance Assist

malfunction and limitations ......................................................................... 6-9

Forward Collision-Avoidance Assist (FCA)
(Sensor Fusion) ............................................................................ 6-16

•

Forward Collision-Avoidance Assist settings ..................................... 6-
17

•

Forward Collision-Avoidance Assist operation ................................. 6-19

僅

Forward Collision-Avoidance Assist

malfunction and limitations ....................................................................... 6-23

Lane Keeping Assist (LKA)........................................................ 6-30

•

Lane Keeping Assist settings ................................................................... 6-
30

•

Lane Keeping Assist operation................................................................. 6-
32

•

Lane Keeping Assist malfunction and limitations........................... 6-34

Blind-Spot Collision-Avoidance Assist (BCA) ..........................6-36

•

Blind-Spot Collision-Avoidance Assist settings.................................6-37

•

Blind-Spot Collision-Avoidance Assist operation .............................6-39

僅

Blind-Spot Collision-Avoidance Assist

malfunction and limitations .......................................................................6-42

Safe Exit Warning (SEW) ........................................................... 6-46

•

Safe Exit Warning settings ........................................................................ 6-
46

•

Safe Exit Warning operation .................................................................... 6-
48

•

Safe Exit Warning malfunction and limitations ............................... 6-49

Manual Speed Limit Assist (MSLA) .......................................... 6-50

•

Manual Speed Limit Assist operation................................................... 6-50

Intelligent Speed Limit Assist (ISLA).........................................6-53

•

Intelligent Speed Limit Assist settings...................................................6-53

•

Intelligent Speed Limit Assist operation...............................................6-56

Driver assistance system

•

Intelligent Speed Limit Assist malfunction and limitations..........6-58

Driver Attention Warning (DAW ) ............................................. 6-6 0

•

Leading Vehicle Departure Alert............................................................ 6-
60

•

Driver Attention Warning operation ...................................................... 6-61

僅

Driver Attention Warning malfunction and limitations ................. 6-62

Cruise Control (CC)..................................................................... 6-65

•

Cruise Control operation ............................................................................6-
65

Smart Cruise Control (SCC) ....................................................... 6-69

•

Smart Cruise Control settings ..................................................................6-
69

•

Smart Cruise Control operation.............................................................. 6-70

•

Smart Cruise Control malfunction and limitations..........................6-78

Navigation-based Smart Cruise Control (NSCC) .................... 6-83

•

Navigation-based Smart Cruise Control settings ........................... 6-84

•

Navigation-based Smart Cruise Control operation ....................... 6-84

僅

Limitations of Navigation-based Smart Cruise Control ................6-86

Lane Following Assist (LFA) ...................................................... 6-89

•

Lane Following Assist settings .................................................................6-
89

•

Lane Following Assist operation............................................................. 6-
90

•

Lane Following Assist malfunction and limitations.........................6-92

Highway Driving Assist (HDA).................................................. 6-92

•

Highway Driving Assist settings ..............................................................6-
93

•

Highway Driving Assist operation ..........................................................6-
94

•

Highway Driving Assist malfunction and limitations......................6-97

Rear View Monitor (RVM).......................................................... 6-99

•

Rear View Monitor settings .......................................................................6-
99

•

Rear View Monitor operation.................................................................. 6-
101

•

Rear View Monitor malfunction and limitations............................ 6-103

Rear Cross-Traffic Collision-Avoidance Assist (RCCA) ....... 6-104

僅

Rear Cross-Traffic Collision-Avoidance Assist settings ............. 6-105

僅

Driver assistance system

•

Rear Cross-Traffic Collision-Avoidance Assist malfunction and lim

itations

..............................................................................................................

109

Reverse Parking Distance Warning (PDW ) ............................ 6-113

•

Reverse Parking Distance Warning settings.................................... 6-
113

•

Reverse Parking Distance Warning operation ................................ 6-

114

僅

Reverse Parking Distance Warning

malfunction and precautions .................................................................. 6-115

Forward/Reverse Parking Distance Warning (PDW ) ............6-117

僅

Forward/Reverse Parking Distance Warning settings..................6-117

僅

Parking Distance Warning operation .................................................. 6-118

•

Parking Distance Warning malfunction and limitations ............ 6-120

Declaration of conformity ........................................................ 6-122

Driver assistance system

Forward Collision-Avoidance Assist (FCA) (Front Camera Only)

Driver assistance system

Forward Collision-Avoidance
Assist (FCA) (Front Camera
Only) (if equipped)

Forward Collision-Avoidance Assist is
designed to help detect and monitor the
vehicle ahead or help detect pedestrian
or cyclist in the roadway and warn the
driver that a collision is imminent with a
warning message and an audible warn

ing, apply emergency braking.

Detecting sensor

Front view camera

Refer to the picture above for the
detailed location of the detecting sen

sors.

CAUTION

• Never disassemble the detecting sen

sor or sensor assembly, or cause any
damage to it.

• If the detecting sensors have been

replaced or repaired, have the vehicle
inspected by an authorized Kia dealer.

• Never install any accessories or stick

ers on the front windshield, or tint the
front windshield.

• Pay extreme caution to keep the front

view camera dry.

• Never place any reflective objects (for

example, white paper, mirror) over the
dashboard.

• Do not place any objects near the front

windshield or install any acces

sories

on the front windshield. It can affect the
performance of the defog

ging and

defrosting function of the cli

mate

control system, which may prevent the
Driver Assistance systems from
operating.

Forward Collision-Avoidance
Assist settings

Forward safety

OSK3052373L

OSK3052374L

OSK3053296N

Driver assistance system

Forward Collision-Avoidance Assist (FCA) (Front Camera Only)

A: Driver Assistance

1 Driving Safety

2 Forward Safety
With the vehicle on, select Settings

→

Driver Assistance

→ Driving Safety on

the instrument cluster or Settings

→

Vehicle

→ Driver Assistance → Driving

Safety on the infotainment system. The
initial warning activation timing of For

ward Collision-Avoidance Assist can be
changed.
• Forward Safety: Depending on the

collision risk levels, an audible warn

ing will sound, and the braking will be
assisted. If the following menu is
deactivated, Forward Collision-Avoid

ance Assist will turn off and the warn

ing light (

) will appear on the

cluster.

The driver can monitor Forward Colli

sion-Avoidance Assist On/Off status
from the Settings menu. If the warning
light (

) remains ON when Forward

Collision-Avoidance Assist is on, have
the vehicle inspected by an authorized
Kia dealer.

W ARNING

When the vehicle is restarted, Forward
Collision-Avoidance Assist will always
turn on. However, if Forward Safety is
deselected, the driver should always be
aware of the surroundings and drive
safely.

CAUTION

When the trailer is connected, Forward
Collision-Avoidance Assist automatically
turns off (if equipped). In this case, you
cannot get help from Forward Collision-
Avoidance Assist. Always drive with care.

Forward Safety Warning Timing

A: Driving Safety

OSK3052297N

OSK3052420L

OSK3052421N

Driver assistance system

Forward Collision-Avoidance Assist (FCA) (Front Camera Only)

1 Forward Safety Warning Timing

2 Standard

3 Late
With the vehicle on, select Settings

→

Driver Assistance

→ Driving Safety →

Forward Safety Warning Timing on the
instrument cluster or Settings

→ Vehicle

→ Driver Assistance → Driving Safety
→ Forward Safety Warning Timing on
the infotainment system to change the
initial warning activation tim

ing of

Forward Collision-Avoidance Assist.
• Use Standard in normal driving con

ditions. If the Warning Timing seems
sensitive, change it to Late.

• If Late is selected, Forward Collision-

Avoidance Assist, warns the driver
more slowly.

CAUTION

• Even though Normal is selected for

Warning Timing, if the front vehicle
suddenly stops, the warning may
seem late.

• Select Late for Warning Timing when

traffic is light and when driving speed
is slow.

INFORMATION

Warning timing will maintain its last set

ting even if the vehicle is restarted.

Warning methods

A: Driver Assistance

1 Warning Volume

2 Driving Safety Priority

3 High

4 Medium

5 Low
With the vehicle on, select Settings

→

Driver Assistance

→ Warning Volume

on the instrument cluster or Settings

→

Vehicle

→ Driver Assistance → Warn

ing Methods on the infotainment sys

tem to change the Warning Sound.
• Warning Volume: You can adjust the

Warning Volume.

• Driving Safety Priority: For safe driv

ing, the audio volume will temporarily

OSK3053320N

OMQ4A052388

Driver assistance system

Forward Collision-Avoidance Assist (FCA) (Front Camera Only)

decrease to warn the driver with the
audible warning.

CAUTION

• Ensure that Warning Methods you

have set may apply to the Warning
Methods of other Driver Assistance
systems.

• Warning Methods will maintain its last

setting even if the vehicle is restarted.

• The setting menu may not be avail

able for your vehicle depending on
the vehicle features and specifica

tions.

Forward Collision-Avoidance
Assist operation

Basic function

The basic function for Forward Collision-
Avoidance Assist is warned and con

trolled by the following level.
• Collision warning
• Emergency braking
• Stopping vehicle and ending brake

control

Collision warning

A: Collision Warning

Collision warning will be activated
depending on the detected object and
your vehicle driving speed.

Collision Warning will be activated in the
following conditions.
• Vehicle: approximately 6~112 mph

(10~180 km/h)

• Pedestrian or cyclist: approximately

6~50 mph (10~80 km/h)

Emergency braking

A: Emergency Braking
The warning message, and an audible
warning will warn the driver that emer

gency braking will be assisted. The
brake assist will be activated and it helps
avoiding collision of a vehicle, pedestrian
and cyclist.

Emergency braking will be activated
depending on the detected object and
your vehicle driving speed.
• Vehicle: approximately 6~37 mph

(10~60 km/h)

• Pedestrian or cyclist: approximately

6~37 mph (10~60 km/h)

CAUTION

The function operation range may
decrease due to the front traffic condi

tion or the surroundings of the vehicle.

OSK3052298N

OSK3052299N

Driver assistance system

Forward Collision-Avoidance Assist (FCA) (Front Camera Only)

Stopping vehicle and ending
brake control

A: Drive carefully
When the vehicle is stopped due to
emergency braking, the warning mes

sage will appear on the cluster.

For your safety, the driver should
depress the brake pedal immediately
and check the surroundings.
• Brake control will end after the vehicle

is stopped by emergency braking for
approximately 2 seconds.

W ARNING

• For your safety, change the Settings

after parking the vehicle at a safe
location.

• The driver should hold the responsi

bility to control the vehicle. Do not
solely depend on Forward Collision-
Avoidance Assist. Rather, maintain a
safe braking distance, and if neces

sary, depress the brake pedal to
reduce driving speed or to stop the
vehicle.

• Never deliberately operate Forward

Collision-Avoidance Assist on people,
objects, etc. It may cause serious
injury or death.

• Forward Collision-Avoidance Assist

may not operate if the driver

depresses the brake pedal to avoid
collision.

• Depending on the road and driving

conditions, Forward Collision-Avoid

ance Assist may warn the driver late
or may not warn the driver.

• During Forward Collision-Avoidance

Assist operation, the vehicle may stop
suddenly injuring passengers and
shifting loose objects. Always have the
seat belt on and keep loose objects
secured.

• If any other function's warning mes

sage is displayed or audible warning
is generated, Forward Collision-Avoid

ance Assist warning message may not
be displayed and audible warning
may not be generated.

• You may not hear the warning sound

of Forward Collision-Avoidance Assist
if the surrounding is noisy.

• Forward Collision-Avoidance Assist

may turn off or may not operate prop

erly or may operate unnecessarily
depending on the road conditions and
the surroundings.

• Even if there is a problem with For

ward Collision-Avoidance Assist, the
vehicle's basic braking performance
will operate properly.

• During emergency braking, braking

control by Forward Collision-Avoid

ance Assist will automatically cancel
when the driver excessively depresses
the accelerator pedal or sharply steers
the vehicle.

CAUTION

• The operating of Forward Collision-

Avoidance Assist may be limited or
disabled due to reduced speed range
or recognition distance depending on
the condition of vehicles, pedestrians,

OSK3052319L

Driver assistance system

Forward Collision-Avoidance Assist (FCA) (Front Camera Only)

cyclists, and the surrounding environ

ment ahead.

• Forward Collision-Avoidance Assist

will operate under certain conditions
by judging the risk level based on the
condition of the oncoming vehicle,
driving direction, speed and sur

roundings.

• The operation of function may be lim

ited or disabled when the driving
speed is too high or there is a signifi

cant speed difference with the oppos

ing vehicle.

NOTICE

• When a collision is imminent, the For

ward Collision-Avoidance Assist may
assist the driver with brakes if the
driver fails to brake enough.

• The images and colors in the instru

ment cluster may differ depending on
the cluster type or theme selected
from the settings menu.

Forward Collision-Avoidance Assist
malfunction and limitations

Forward Collision-Avoidance
Assist malfunction

A: Check forward safety systems

When Forward Collision-Avoidance
Assist is not working properly, the warn

ing message will appear, and the (

)

and (

) warning lights will appear on the

cluster. Have the vehicle inspected by an
authorized Kia dealer.

Forward Collision-Avoidance
Assist disabled

A: Forward safety systems disabled.
Camera obscured

When the front windshield where the front
view camera is located, or the sen

sor is

covered with foreign material, such as
snow or rain, it can reduce the detecting
performance due to weather conditions
such as fog or heavy rain.

If this occurs the warning message, and
the (

) and (

) warning lights will

appear on the cluster.

Forward Collision-Avoidance Assist will
operate properly when snow, rain or for

eign material is removed.

If Forward Collision-Avoidance Assist
does not operate properly after obstruc

tion (snow, rain, or foreign material) is
removed, have the vehicle inspected by
an authorized Kia dealer.

W ARNING

• Even though the warning message or

warning light does not appear on the

OSK3052300N

OSK3052301N

Driver assistance system

Forward Collision-Avoidance Assist (FCA) (Front Camera Only)

cluster, Forward Collision-Avoidance
Assist may not properly operate.

• Forward Collision-Avoidance Assist

may not properly operate in an area
(for example, open terrain), where any
objects are not detected after turning
ON the vehicle.

• Even after starting the engine again,

Forward Collision-Avoidance Assist
may not function properly when the
obstruction or malfunction condition
persists.

Limitations of Forward Collision-
Avoidance Assist

Forward Collision-Avoidance Assist may
not operate properly, or it may operate
unexpectedly under the following cir

cumstances:
• The detecting sensor or the surround

ings are contaminated or damaged

• The temperature around the front view

camera is high or low due to sur

rounding environment

• The camera lens is contaminated due

to tinted, filmed or coated windshield,
damaged glass, or sticky foreign
material (sticker, bug, etc.) on the
glass

• Moisture is not removed or frozen on

the windshield

• Washer fluid is continuously sprayed,

or the wiper is on

• Driving in heavy rain or snow, or thick

fog

• The field of view of the front view

camera is obstructed by sun glare

• Street light or light from an oncoming

traffic is reflected on the wet road sur

face, such as a puddle on the road

• An object is placed on the dashboard

僅

Your vehicle is being towed

• The surrounding is very bright or the

surrounding is very dark, such as in a
tunnel, etc.

• The brightness changes suddenly, for

example when entering or exiting a
tunnel

• The brightness outside is low, and the

headlamps are not on or are not bright

• Only part of the vehicle, pedestrian or

cyclist is detected

• The vehicle in front is a bus, heavy

truck, truck with an unusually shaped
cargo, trailer, etc.

• The vehicle in front has no tail lights,

tail lights are located unusually, etc.

• The brightness outside is low, and the

tail lamps are not on or are not bright

• The rear of the front vehicle is small or

the vehicle does not look normal, such
as when the vehicle is tilted, over

turned, or the side of the vehicle is vis

ible, etc.

• The front vehicle's ground clearance

is low or high

• A vehicle, pedestrian or cyclist sud

denly cuts in front

• The vehicle in front is detected late

僅

The vehicle in front is suddenly
blocked by an obstacle

• The vehicle in front suddenly changes

lane or suddenly reduces speed

• The vehicle in front is bent out of

shape

• The front vehicle speed is fast or slow

僅

The vehicle in front steers in the
opposite direction of your vehicle to
avoid a collision

• With a vehicle in front, your vehicle

changes lane at low speed

Driver assistance system

Forward Collision-Avoidance Assist (FCA) (Front Camera Only)

• The vehicle in front is covered with

snow

• You are departing or returning to the

lane

• Unstable driving
• You are on a roundabout and the

vehicle in front is not detected

• You are continuously driving in a cir

cle

• The vehicle in front has an unusual

shape

• The vehicle in front is driving uphill or

downhill

• The pedestrian or cyclist is not fully

detected, for example, if the pedes

trian is leaning over or is not fully
walking upright

• The pedestrian or cyclist is wearing

clothing or equipment that makes it
difficult to detect

The illustration above shows the image
the front view camera and front radar
are capable of detecting as a vehicle,
pedestrian and cyclist.
• The pedestrian or cyclist in front is

moving very quickly

• The pedestrian or cyclist in front is

short or is posing a low posture

• The pedestrian or cyclist in front has

impaired mobility or moving inter

sected with the driving direction

• There is a group of pedestrians,

cyclists or a large crowd in front

• The pedestrian or cyclist is wearing

clothing that easily blends into the
background, making it difficult to
detect

• The pedestrian or cyclist is difficult to

distinguish from the similarly shaped
structure in the surroundings

• You are driving by a pedestrian,

cyclist, traffic signs, structures, etc.,
near the intersection

• When driving in the following places

- Driving through steam, smoke or

shadow

- Driving through a tunnel or iron

bridge

- Driving in large areas where there

are few vehicles or structures (i.e.
desert, meadow, suburb, etc.)

- Driving in a parking lot
- Driving through toll gate, construc

tion areas, partially paved roads,
bumpy roads, speed bumps, etc.

- Driving near areas containing metal

substances, such as a construction
zone, railroad, etc.

- Driving on an incline road, curved

road, etc.

- Driving through a roadside with

trees or streetlights

- Driving through a narrow road where

trees or grass are overgrown

- There is interference by electro

magnetic waves, such as driving in
an area with strong radio waves or
electrical noise

• The adverse road conditions cause

excessive vehicle vibrations while
driving

OADAS044

Driver assistance system

Forward Collision-Avoidance Assist (FCA) (Front Camera Only)

• Your vehicle height is low or high due

to heavy loads, abnormal tire pres

sure, etc.

W ARNING

• Driving on a curved road

Forward Collision-Avoidance Assist
may not detect other vehicles, pedes

trians or cyclists in front of you when
driving on curved roads adversely
affecting the performance of the sen

sors. This may result in no warning,
braking assist when necessary.

When driving on a curve, you must
maintain a safe braking distance, and
if necessary, steer the vehicle and
depress the brake pedal to reduce
your driving speed in order to main

tain a safe distance.

OSK3052375L

OCD059188

OKA4041601L

OCD059191

OCD059190

Driver assistance system

Forward Collision-Avoidance Assist (FCA) (Front Camera Only)

Forward Collision-Avoidance Assist
may detect a vehicle, pedestrian or
cyclist in the next lane or outside the
lane when driving on a curved road.

If this occurs, Forward Collision-Avoid

ance Assist may unnecessarily warn
the driver and control the brake.
Always check the traffic conditions
around the vehicle.

• Driving on an inclined road

Forward Collision-Avoidance Assist
may not detect other vehicles, pedes

trians or cyclists in front of you while
driving uphill or downhill, adversely
affecting the performance of the sen

sors.

This may result in unnecessary warn

ing, braking assist or no warning,
braking assist when necessary.

Also, vehicle speed may rapidly
decrease when a vehicle, pedestrian
or cyclist ahead is suddenly detected.

Always have your eyes on the road
while driving uphill or downhill and if
necessary, steer your vehicle and
depress the brake pedal to reduce
your driving speed in order to main

tain a safe distance.

OKA4041602L

ODL3059040

OCD059192

OKA4041603L

Kia Soul (2024 year). Manual in english - page 8
