FANUC Robotics SYSTEM R-30iA and R-30iB Controller. KAREL Reference Manual

A. KAREL LANGUAGE ALPHABETICAL DESCRIPTION

MARRC75KR07091E Rev D

dp_japanese

dp_french

dp_german

dp_spanish

• The default language should be used unless more than one language is required.

• add_option should be the following:

dp_dram Dictionary will be loaded to DRAM memory and retained until the next INIT START.

• status explains the status of the attempted operation. If not equal to 0, then an error occurred

adding the dictionary file.

See Also: READ_DICT, WRITE_DICT, REMOVE_DICT Built-In Procedures, Chapter 10

DICTIONARIES AND FORMS

Example: Refer to the following sections for detailed program examples:

Section B.12 , "Displaying a List From a Dictionary File" (DCLST_EX.KL)

Section B.12 , "Dictionary Files" (DCALPHEG.UTX)

A.2.11

ADD_INTPC Built-In Procedure

Purpose: To add an INTEGER value (type 16 - 10 HEX) into a KAREL byte data buffer.

Syntax : ADD_INTPC(dat_buffer, dat_index, number, status)

Input/Output Parameters :

[in] dat_buffer :ARRAY OF BYTE

[in,out] dat_index :INTEGER

[in] number :INTEGER

[out] status :INTEGER

%ENVIRONMENT Group :PC

Details:

• dat_buffer - an array of up to 244 bytes.

• dat_index - the starting byte number to place the integer value.

A-26

MARRC75KR07091E Rev D

A. KAREL LANGUAGE ALPHABETICAL DESCRIPTION

• number - the integer value to place into the buffer.

• status - the status of the attempted operation. If not 0, then an error occurred and data was

not put into the buffer.

The KAREL built-ins ADD_BYNAMEPC, ADD_INTPC, ADD_REALPC, and ADD_STRINGPC

can be used to format a KAREL byte buffer in the following way: INTEGER data is added to the

buffer as follows (buffer bytes are displayed in HEX):

beginning index = dat_index

2 bytes - variable type

4 bytes - the number

2 bytes of zero (0) - end of buffer marker

The following is an example of an INTEGER placed into a KAREL array of bytes starting at index = 1:

0 10 0 0 0 5 0 0

where:

0 10 = INTEGER variable type

0 0 0 5 = integer number 5

0 0 = end of data in the buffer

On return from the built-in, index = 7.

See Also: ADD_BYNAMEPC, ADD_INTPC, ADD_REALPC, ADD_STRINGPC

Example: Refer to the TESTDATA example in the built-in function SEND_DATAPC.

A.2.12

ADD_REALPC Built-In Procedure

Purpose: To add a REAL value (type 17 - 11 HEX) into a KAREL byte data buffer.

Syntax : ADD_REALPC(dat_buffer, dat_index, number, status)

Input/Output Parameters :

[in] dat_buffer :ARRAY OF BYTE

[in,out] dat_index :INTEGER

A-27

A. KAREL LANGUAGE ALPHABETICAL DESCRIPTION

MARRC75KR07091E Rev D

[in] number :REAL

[out] status :INTEGER

%ENVIRONMENT Group :PC

Details:

• dat_buffer - an array of up to 244 bytes.

• dat_index - the starting byte number to place the real value.

• number - the real value to place into the buffer.

• status - the status of the attempted operation. If not 0, then an error occurred and data was

not placed into the buffer.

The KAREL built-ins ADD_BYNAMEPC, ADD_INTPC, ADD_REALPC, and ADD_STRINGPC

can be used to format a KAREL byte buffer in the following way:

REAL data is added to the buffer as follows (buffer bytes are displayed in HEX):

beginning index = dat_index

2 bytes - variable type

4 bytes - the number

2 bytes of zero (0) - end of buffer marker

The following is an example of an REAL placed into a KAREL array of bytes starting at index = 1:

0 11 43 AC CC CD 0 0

where:

0 11 = REAL variable type

43 AC CC CD = real number 345.600006

0 0 = end of data in the buffer

On return from the built-in, index = 7.

See Also: ADD_BYNAMEPC, ADD_INTPC, ADD_REALPC, ADD_STRINGPC

Example: Refer to the TESTDATA example in the built-in function SEND_DATAPC.

A-28

MARRC75KR07091E Rev D

A. KAREL LANGUAGE ALPHABETICAL DESCRIPTION

A.2.13

ADD_STRINGPC Built-In Procedure

Purpose: To add a string value (type 209 - D1 HEX) into a KAREL byte data buffer.

Syntax : ADD_STRINGPC(dat_buffer, dat_index, item, status)

Input/Output Parameters :

[in] dat_buffer :ARRAY OF BYTE

[in,out] dat_index :INTEGER

[in] item :string

[out] status :INTEGER

%ENVIRONMENT Group :PC

Details:

• dat_buffer - an array of up to 244 bytes.

• dat_index - the starting byte number to place the string value.

• item - the string value to place into the buffer.

• status - the status of the attempted operation. If not 0, then an error occurred and data was

not placed into the buffer.

The KAREL built-ins ADD_BYNAMEPC, ADD_INTPC, ADD_REALPC, and ADD_STRINGPC

can be used to format a KAREL byte buffer in the following way:

STRING data is added to the buffer as follows:

beginning index = dat_index

2 bytes - variable type

1 byte - length of text string

text bytes

2 bytes of zero (0) - end of buffer marker

The following is an example of an STRING placed into a KAREL array of bytes starting at index = 1:

0 D1 7 4D 48 53 48 45 4C 4C 0 0 0

where:

A-29

A. KAREL LANGUAGE ALPHABETICAL DESCRIPTION

MARRC75KR07091E Rev D

0 D1 = STRING variable type

7 = there are 7 characters in string ’MHSHELL’

4D 48 53 48 45 4C 4C 0 = ’MHSHELL’ with end of string 0

0 0 = end of data in the buffer

On return from the built-in, index = 12.

See Also: ADD_BYNAMEPC, ADD_INTPC, ADD_REALPC, ADD_STRINGPC

Example: Refer to the TESTDATA example in the built-in function SEND_DATAPC.

A.2.14

%ALPHABETIZE Translator Directive

Purpose: Specifies that static variables will be created in alphabetical order when p-code is loaded.

Syntax : %ALPHABETIZE

Details:

• Static variables can be declared in any order in a KAREL program and %ALPHABETIZE

will cause them to be displayed in alphabetical order in the DATA menu or KCL> SHOW

VARS listing.

Example: Refer to the following sections for detailed program examples:

Section B.2 , "Copying Path Variables" (CPY_PTH.KL)

Section B.5 ,"Using Register Built-ins" (REG_EX.KL)

Section B.6 , "Path Variables and Condition Handlers Program" (PTH_MOVE.KL)

Section B.10 , "Using Dynamic Display Built-ins" (DYN_DISP.KL)

Section B.12 , "Displaying a List From a Dictionary File" (DCLST_EX.KL)

A.2.15

APPEND_NODE Built-In Procedure

Purpose: Adds an uninitialized node to the end of the PATH argument

Syntax : APPEND_NODE(path_var, status)

Input/Output Parameters :

A-30

MARRC75KR07091E Rev D

A. KAREL LANGUAGE ALPHABETICAL DESCRIPTION

[in] path_ var :PATH

[out] status :INTEGER

%ENVIRONMENT Group :PBCORE

Details:

• path_var is the path variable to which the node is appended.

• The appended PATH node is uninitialized. The node can be assigned values by directly

referencing its NODEDATA structure.

• status explains the status of the attempted operation. If not equal to 0, then an error occurred.

See Also: DELETE_NODE, INSERT_NODE Built-In Procedures

Example: Refer to Section B.2 , "Copying Path Variables" (CPY_PTH.KL), for a detailed program

example.

A.2.16

APPEND_QUEUE Built-In Procedure

Purpose: Appends an entry to a queue if the queue is not full

Syntax : APPEND_QUEUE(value, queue, queue_data, sequence_no, status)

Input/Output Parameters :

[in] value :INTEGER

[in,out] queue :QUEUE_TYPE

[in,out] queue_data :ARRAY OF INTEGER

[out] sequence_no :INTEGER

[out] status :INTEGER

%ENVIRONMENT Group :PBQMGR

Details:

• value specifies the value to be appended to the queue.

• queue specifies the queue variable for the queue.

• queue_data specifies the array used to hold the data in the queue. The length of this array

determines the maximum number of entries in the queue.

A-31

A. KAREL LANGUAGE ALPHABETICAL DESCRIPTION

MARRC75KR07091E Rev D

• sequence_no is returned with the sequence number of the entry just appended.

• status is returned with the zero if an entry can be appended to the queue. Otherwise it is returned

with 61001, ‘‘Queue is full.’’

See Also: DELETE_QUEUE, INSERT_QUEUE Built-In Procedures. Refer to Section 15.8 , "Using

Queues for Task Communication," for more information and an example.

A.2.17

APPROACH Built-In Function

Purpose: Returns a unit VECTOR representing the z-axis of a POSITION argument

Syntax : APPROACH(posn)

Function Return Type :VECTOR

Input/Output Parameters :

[in] posn :POSITION

%ENVIRONMENT Group :VECTR

Details:

• Returns a VECTOR consisting of the approach vector (positive z-axis) of the argument posn .

Example: This program allows you to create a position that is 500 mm away from another position

along the z-axis.

APPROACH Function

PROGRAM p_approach

VAR

start_pos

: POSITION

app_vector : VECTOR

BEGIN

app_vector = APPROACH (start_pos)

--sets app_vector equal to the

--z-axis of start_pos

start_pos.location = start_pos.location + app_vector *500

--creates start_pos + 500 mm

--in z direction

END p_approach

Note Approach has been left in for older versions of KAREL. You should now directly access the

vectors of a POSITION (i.e., posn. approach.)

A-32

MARRC75KR07091E Rev D

A. KAREL LANGUAGE ALPHABETICAL DESCRIPTION

A.2.18

ARRAY Data Type

Purpose: Defines a variable, function return type, or routine parameter as ARRAY data type

Syntax : ARRAY<[size{,size}]> OF data_type

where:

size : an INTEGER literal or constant

data_type : any type except PATH

Details:

•

size indicates the number of elements in an ARRAY variable.

•

size must be in the range 1 through 32767 and must be specified in a normal ARRAY variable

declaration. The amount of available memory in your controller might restrict the maximum

size of an ARRAY.

•

Individual elements are referenced by the ARRAY name and the subscript size . For example,

table[1] refers to the first element in the ARRAY table.

•

An entire ARRAY can be used only in assignment statements or as an argument in routine calls.

In an assignment statement, both ARRAY variables must be of the same size and data_type . If

size is different, the program will be translated successfully but will be aborted during execution,

with error 12304, "Array Length Mismatch."

•

size is not specified when declaring ARRAY routine parameters; an ARRAY of any size can be

passed as an ARRAY parameter to a routine.

•

size is not used when declaring an ARRAY return type for a function. However, the returned

ARRAY must be of the same size as the ARRAY to which it is assigned in the function call.

•

Each element is of the same type designated by data_type .

•

Valid ARRAY operators correspond to the valid operators of the individual elements in the

ARRAY.

•

Individual elements of an array can be read or written only in the format that corresponds to the

data type of the ARRAY.

•

Arrays of multiple dimensions can be defined. Refer to Chapter 2 for more information.

•

Variable-sized arrays can be defined. Refer to Chapter 2 for more information.

See Also: ARRAY_LEN Built-In Function, Chapter 5 ROUTINES , for information on passing

ARRAY variables as arguments in routine calls Chapter 7 FILE INPUT/OUTPUT OPERATIONS

Example: Refer to the following sections for detailed program examples:

Section B.2 , "Copying Path Variables" (CPY_PTH.KL)

A-33

A. KAREL LANGUAGE ALPHABETICAL DESCRIPTION

MARRC75KR07091E Rev D

Section B.8 , "Generating and Moving Along a Hexagon Path" (GEN_HEX.KL)

Section B.9 , "Using the File and Device Built-ins" (FILE_EX.KL)

Section B.12 , "Displaying a List From a Dictionary File" (DCLST_EX.KL)

Section B.14 , "Applying Offsets to a Copied Teach Pendant Program" (CPY_TP.KL)

A.2.19

ARRAY_LEN Built-In Function

Purpose: Returns the number of elements contained in the specified array argument

Syntax : ARRAY_LEN(ary_var)

Function Return Type :INTEGER

Input/Output Parameters :

[in] ary_var :ARRAY

%ENVIRONMENT Group :SYSTEM

• The returned value is the number of elements declared for ary_var , not the number of elements

that have been initialized in ary_var .

Example: Refer to Section B.7 , "Listing Files and Programs and Manipulating Strings"

(LIST_EX.KL), for a detailed program example.

A.2.20

ASIN Built-In Function

Purpose: Returns arcsine (sin-1) in degrees of the specified argument

Syntax : ASIN(x)

Function Return Type :REAL

Input/Output Parameters :

[in] x :REAL

%ENVIRONMENT Group :SYSTEM

Details:

• Returns the arcsine of x.

A-34

MARRC75KR07091E Rev D

A. KAREL LANGUAGE ALPHABETICAL DESCRIPTION

• x must be between -1 and 1, otherwise the program will abort with an error.

Example: The following example sets ans_r to the arcsine of -1 and writes this value to the screen.

The output for the following example is -90 degrees.

ASIN Built-In Function

ROUTINE take_asin

VAR

ans_r: REAL

BEGIN

ans_r = ASIN (-1)

WRITE (’asin -1 ’, ans_r, CR)

END take_asin

The second example causes the program to abort since the input value is less than -1 and not within

the valid range.

ASIN Built-In Function

ROUTINE take_asin

VAR

ans_r: REAL

BEGIN

ans_r = ASIN (-1.5) -- causes program to abort

WRITE (’asin -1.5 ’, ans_r, CR)

END take_asin

A.2.21

Assignment Action

Purpose: Sets the value of a variable to the result of an evaluated expression

Syntax : variable {[subscript{,subscript}]| . field} = expn

where:

variable : any KAREL variable

subscript : an INTEGER expression

expn : a valid KAREL expression

field : any field from a structured variable

Details:

A-35

A. KAREL LANGUAGE ALPHABETICAL DESCRIPTION

MARRC75KR07091E Rev D

• variable can be any user-defined variable, system variable with write access, or output port

array with write access.

• subscript is used to access elements of an array.

• field is used to access fields in a structure.

• expn must be of the same type as the variable or element of variable .

• An exception is that an INTEGER expression can be assigned to a REAL. Any positional types

can be assigned to each other.

• Only system variables with write access (listed as RW in Table 11-3, “System Variables

Summary”) can be used on the left side of an assignment statement. System variables with read

only (RO) or read write (RW) access can be used on the right side.

• Input port arrays cannot be used on the left side of an assignment statement.

See Also: Chapter 3 USE OF OPERATORS , for detailed information about expressions and their

evaluation Chapter 6 CONDITION HANDLERS , for more information about using assignment

actions.

Example: The following example uses the assignment action to turn DOUT[1] off and set port_var

equal to DOUT[2] when EVENT[1] turns on.

Assignment Action

CONDITION[1]:

WHEN EVENT[1] DO

DOUT[1] = OFF

port_var = DOUT[2]

ENDCONDITION

A.2.22

Assignment Statement

Purpose: Sets the value of a variable to the result of an evaluated expression

Syntax : variable {[subscript{,subscript}]| . field} = expn

where:

variable : any KAREL variable

subscript : an INTEGER expression

expn : a valid KAREL expression

field : any field from a structured variable

A-36

MARRC75KR07091E Rev D

A. KAREL LANGUAGE ALPHABETICAL DESCRIPTION

Details:

•

variable can be any user-defined variable, system variable with write access, or output port

array with write access.

•

subscript is used to access elements of an array.

•

field is used to access fields in a structure.

•

expn must be of the same type as the variable or element of variable .

•

An exception is that an INTEGER expression can be assigned to a REAL. Any positional types

can be assigned to each other. INTEGER, SHORT, and BYTE can be assigned to each other.

•

If variable is of type ARRAY, and no subscript is supplied, the expression must be an ARRAY of

the same type and size. A type mismatch will be detected during translation. A size mismatch

will be detected during execution and causes the program to abort with error 12304, "Array

Length Mismatch."

•

If variable is a user-defined structure, and no field is supplied, the expression must be a structure

of the same type.

•

Only system variables with write access (listed as RW in Table 11-3, ‘‘System Variables

Summary’’) can be used on the left side of an assignment statement. System variables with read

only (RO) or read write (RW) access can be used on the right side.

If read only system variables are passed as parameters to a routine, they are passed by value,

so any attempt to modify them (with an assignment statement) through the parameter in the

routine has no effect.

•

Input port arrays cannot be used on the left side of an assignment statement.

See Also: Chapter 3 USE OF OPERATORS , for detailed information about expressions and

their evaluation, Chapter 2 LANGUAGE ELEMENTS . Refer to Appendix B, "KAREL Example

Programs," for more detailed program examples.

Example: The following example assigns an INTEGER literal to an INTEGER variable and then

increments that variable by a literal and value.

Assignment Statement

int_var = 5

int_var = 5 + int_var

Example: The next example multiplies the system variable $SPEED by a REAL value. It is then

used to assign the ARRAY variable array_1 , element loop_count to the new value of the system

variable $SPEED.

Assignment Statement

$SPEED = $SPEED * .25

array_1[loop_count] = $SPEED

A-37

A. KAREL LANGUAGE ALPHABETICAL DESCRIPTION

MARRC75KR07091E Rev D

Example: The last example assigns all the elements of the ARRAY array_1 to those of ARRAY

array_2 , and all the fields of structure struc_var_1 to those of struc_var_2 .

Assignment Statement

array_2 = array_1

struc_var_2 = struc_var_1

A.2.23

ATAN2 Built-In Function

Purpose: Returns a REAL angle, measured counterclockwise in degrees, from the positive x-axis to

a line connecting the origin and a point whose x- and y- coordinates are specified as the x- and y-

arguments

Syntax : ATAN2(x1, y1)

Function Return Type :REAL

Input/Output Parameters :

[in] x1 :REAL

[in] y1 :REAL

%ENVIRONMENT Group :SYSTEM

Details:

• x1 and y1 specify the x and y coordinates of the point.

• If x1 and y1 are both zero, the interpreter will abort the program.

Example: The following example uses the values 100, 200, and 300 respectively for x, y, and z to

compute the orientation component direction . The position, p1 is then defined to be a position with

direction as its orientation component.

ATAN2

Built-In Function

PROGRAM p_atan2

VAR

p1 : POSITION

x, y, z, direction : REAL

BEGIN

x = 100

-- use appropriate values

y = 200

for x,y,z on

z = 300

your robot

direction = ATAN2(x, y)

p1 = POS(x, y, z, 0, 0, direction, ’n’) --r orientation component

A-38

MARRC75KR07091E Rev D

A. KAREL LANGUAGE ALPHABETICAL DESCRIPTION

--of POS equals angle

END p_atan2

--returned by ATAN2(100,200)

A.2.24

ATTACH Statement

Purpose: Gives the KAREL program control of motion for the robot arm and auxiliary and extended

axes

Syntax : ATTACH

Details:

• Used with the RELEASE statement. If motion control is not currently released from program

control, the ATTACH statement has no effect.

• If the teach pendant is still enabled, execution of the KAREL program is delayed until the teach

pendant is disabled. The task status will show a hold of "attach done."

• Stopped motions can only be resumed following execution of the ATTACH statement.

See Also: RELEASE Statement, Appendix E , “Syntax Diagrams,’’ for additional syntax information.

Example: Refer to Section B.1 , "Setting Up Digital Output Ports for Monitoring" (DOUT_EX.KL)

for a detailed program example.

A.2.25

ATT_WINDOW_D Built-In Procedure

Purpose: Attach a window to the screen on a display device

Syntax : ATT_WINDOW_D(window_name, disp_dev_nam, row, col, screen_name, status)

Input/Output Parameters :

[in] window_name :STRING

[in] disp_dev_nam :STRING

[in] row :INTEGER

[in] col :INTEGER

[out] screen_name :STRING

[out] status :INTEGER

A-39

A. KAREL LANGUAGE ALPHABETICAL DESCRIPTION

MARRC75KR07091E Rev D

%ENVIRONMENT Group :PBCORE

Details:

• Causes data in the specified window to be displayed or attached to the screen currently active on

the specified display device.

• window_name must be a previously defined window.

• disp_dev_nam must be one of the display devices already defined:

’CRT’ CRT Device

’TP’ Teach Pendant Device

• row and col indicate the position in the screen. Row 1 indicates the top row; col 1 indicates

the left-most column. The entire window must be visible in the screen where positioned. For

example, if the screen is 24 rows by 80 columns (as defined by its associated display device) and

the window is 2 rows by 80 columns, row must be in the range 1-23; col must be 1.

• The name of the active screen is returned in screen_name . This can be used to detach the

window later.

• It is an error if the window is already attached to the screen.

• status explains the status of the attempted operation. If not equal to 0, then an error occurred.

A.2.26

ATT_WINDOW_S Built-In Procedure

Purpose: Attach a window to a screen

Syntax : ATT_WINDOW_S(window_name, screen_name, row, col, status)

Input/Output Parameters :

[in] window_name :STRING

[in] screen_name :STRING

[in] row :INTEGER

[in] col :INTEGER

[out] status :INTEGER

%ENVIRONMENT Group :PBCORE

Details:

A-40

MARRC75KR07091E Rev D

A. KAREL LANGUAGE ALPHABETICAL DESCRIPTION

• Causes data in the specified window to be displayed or attached to the specified screen at a

specified row and column.

• window_name and screen_name must be previously defined window and screen names.

• row and col indicate the position in the screen. Row 1 indicates the top row; col 1 indicates the

left-most column. The entire window must be visible in the screen as positioned. For example, if

the screen is 24 rows by 80 columns (as defined by its associated display device) and the window

is 2 rows by 80 columns, row must be in the range 1-23; col must be 1.

• If the screen is currently active, the data will immediately be displayed on the device. Otherwise,

there is no change in the displayed data.

• It is an error if the window is already attached to the screen.

• status explains the status of the attempted operation. If not equal to 0, then an error occurred.

See Also: Section 7.10 , "User Interface Tips," DET_WINDOW Built-In

Example: Refer to Section B.12 , "Displaying a List From a Dictionary File" (DCLST_EX.KL), for a

detailed program example.

A.2.27

AVL_POS_NUM Built-In Procedure

Purpose: Returns the first available position number in a teach pendant program

Syntax : AVL_POS_NUM(open_id, pos_num, status)

Input/Output Parameters :

[in] open_id :INTEGER

[out] pos_num : INTEGER

[out] status : INTEGER

%ENVIRONMENT Group :TPE

Details:

• open_id specifies the opened teach pendant program. A program must be opened before calling

this built-in.

• pos_num is set to the first available position number.

• status explains the status of the attempted operation. If not equal to 0, then an error has occurred.

Example: Refer to Section B.14 , "Applying Offsets to a Copied Teach Pendant Program"

(CPY_TP.KL), for a detailed program example.

A-41

A. KAREL LANGUAGE ALPHABETICAL DESCRIPTION

MARRC75KR07091E Rev D

A.3

- B - KAREL LANGUAGE DESCRIPTION

A.3.1

BOOLEAN Data Type

Purpose: Defines a variable, function return type, or routine parameter as a BOOLEAN data type

Syntax : BOOLEAN

Details:

• The BOOLEAN data type represents the BOOLEAN predefined constants TRUE, FALSE,

ON, and OFF.

Table A-10 lists some examples of valid and invalid BOOLEAN values used to represent the

Boolean predefined constants.

Table

A-10.

Valid and Invalid BOOLEAN Values

VALID

INVALID

REASON

TRUE

Must use entire word

Cannot use INTEGER values

• TRUE and FALSE typically represent logical flags, and ON and OFF typically represent signal

states. TRUE and ON are equivalent, as are FALSE and OFF.

• Valid BOOLEAN operators are

— AND, OR, and NOT

— Relational operators (>, >=, =, <>, <, and <=)

• The following have BOOLEAN values:

— BOOLEAN constants, whether predefined or user-defined (for example, ON is a predefined

constant)

— BOOLEAN variables and BOOLEAN fields in a structure

— ARRAY OF BOOLEAN elements

— Values returned by BOOLEAN functions, whether user-defined or built-in (for example,

IN_RANGE(pos_var))

— Values resulting from expressions that use relational or BOOLEAN operators (for example,

x > 5.0)

— Values of digital ports (for example, DIN[2])

• Only BOOLEAN expressions can be assigned to BOOLEAN variables, returned from BOOLEAN

function routines, or passed as arguments to BOOLEAN parameters.

A-42

MARRC75KR07091E Rev D

A. KAREL LANGUAGE ALPHABETICAL DESCRIPTION

Example: Refer to the following sections for detailed program examples:

Section B.2 , "Copying Path Variables" (CPY_PTH.KL)

Section B.3 , "Saving Data to the Default Device" (SAVE_VR.KL)

Section B.5 , "Using Register Built-ins" (REG_EX.KL)

Section B.7 , "Listing Files and Programs and Manipulating Strings" (LIST_EX.KL)

Section B.9 , "Using the File and Device Built-ins" (FILE_EX.KL)

Section B.10 , "Using Dynamic Display Built-ins" (DYN_DISP.KL)

Section B.12 , "Displaying a List From a Dictionary File" (DCLST_EX.KL)

Section B.14 , "Applying Offsets to a Copied Teach Pendant Program" (CPY_TP.KL)

Section B.1 , "Setting Up Digital Output Ports for Monitoring" (DOUT_EX.KL)

A.3.2

BYNAME Built-In Function

Purpose: Allows a KAREL program to pass a variable, whose name is contained in a STRING, as a

parameter to a KAREL routine. This means the programmer does not have to determine the variable

name during program creation and translation.

Syntax : BYNAME (prog_name, var_name, entry)

Input/Output Parameters :

[in] prog_name :STRING

[in] var_name :STRING

[in,out] entry :INTEGER

%ENVIRONMENT Group :system

Details:

• This built-in can be used only to pass a parameter to a KAREL routine.

• entry returns the entry number in the variable data table where var_name is located. This variable

does not need to be initialized and should not be modified.

• prog_name specifies the name of the program that contains the specified variable. If prog_name

is equal to ’’ (double quotes), then the routine defaults to the task name being executed.

A-43

A. KAREL LANGUAGE ALPHABETICAL DESCRIPTION

MARRC75KR07091E Rev D

• var_name must refer to a static, program variable.

• If var_name does not contain a valid variable name or if the variable is not of the type expected as

a routine parameter, the program is aborted.

• System variables cannot be passed using BYNAME.

• The PATH data type cannot be passed using BYNAME. However, a user-defined type that is a

PATH can be used instead.

Example: Refer to Section B.2 , "Copying Path Variables" (CPY_PTH.KL), for a detailed program

example.

A.3.3

BYTE Data Type

Purpose: Defines a variable as a BYTE data type

Syntax : BYTE

Details:

• BYTE has a range of (0 n 255). No uninitialized checking is done on bytes.

• BYTEs are allowed only within an array or within a structure.

• BYTEs can be assigned to SHORTs and INTEGERs, and SHORTs and INTEGERs can be

assigned to BYTEs. An assigned value outside the BYTE range will be detected during execution

and cause the program to abort.

Example: The following example defines an array of BYTE and a structure containing BYTEs.

BYTE Data Type

PROGRAM byte_ex

%NOLOCKGROUP

TYPE

mystruct = STRUCTURE

param1: BYTE

param2: BYTE

param3: SHORT

ENDSTRUCTURE

VAR

array_byte: ARRAY[10] OF BYTE

myvar: mystruct

BEGIN

array_byte[1] = 254

myvar.param1 = array_byte[1]

END byte_ex

A-44

MARRC75KR07091E Rev D

A. KAREL LANGUAGE ALPHABETICAL DESCRIPTION

A.3.4

BYTES_AHEAD Built-In Procedure

Purpose: Returns the number of bytes of input data presently in the read-ahead buffer for a KAREL

file. Allows KAREL programs to check instantly if data has been received from a serial port and

is available to be read by the program. BYTES_AHEAD is also supported on socket messaging

and pipes.

Syntax : BYTES_AHEAD(file_id, n_bytes, status)

Input/Output Parameters :

[in] file_id :FILE

[out] n_bytes :INTEGER

[out] status :INTEGER

%ENVIRONMENT Group :FLBT

Details:

• file_id specifies the file that was opened.

• The file_id must be opened with the ATR_READAHD attribute set greater than zero.

• n_byte is the number of bytes in the read_ahead buffer.

• status explains the status of the attempted operation. If not equal to 0, then an error occurred.

• A non-zero status will be returned for non-serial devices such as files.

See Also: Section 7.3.1 , “File Attributes”

Example: The following example will clear Port 2 (FLPY:) from any bytes still remaining to be read.

BYTES_AHEAD Built-In Procedure

ROUTINE purge_port

VAR

: STRING[1]

n_try

: INTEGER

n_bytes

: INTEGER

stat

: INTEGER

BEGIN

stat=SET_PORT_ATR (port_2, ATR_READAHD, 1) -- sets FLPY: to have a read

-- ahead buffer of 128 bytes

OPEN FILE fi(’RO’, ’rdahd.tst’)

REPEAT

BYTES_AHEAD (fi, n_bytes, stat)

--Get number of bytes ready

--to be read

A-45

A. KAREL LANGUAGE ALPHABETICAL DESCRIPTION

MARRC75KR07091E Rev D

if (n_bytes = 0) then

--if there are no bytes then set stat

stat = 282

endif

if (n_bytes >= 1_) then

--there are bytes to be read

read fi(s1::1)

--read in one byte at a time

stat=io_status (fi)

--get the status of the read operation

endif

UNTIL stat <> 0

--continue until no more bytes are left

END purge_port

BEGIN

-- main program text here

END bytes_ahd

A.3.5

BYTES_LEFT Built-In Function

Purpose: Returns the number of bytes remaining in the current input data record

Syntax : BYTES_LEFT(file_id)

Function Return Type :INTEGER

Input/Output Parameters :

[in] file_id :FILE

%ENVIRONMENT Group :FLBT

Details:

• file_id specifies the file that was opened.

• If no read or write operations have been done or the last operation was a READ file_id (CR), a

zero is returned.

• If file_id does not correspond to an opened file or one of the pre-defined ‘‘files’’ opened to the

respective CRT/KB, teach pendant, and vision windows, the program is aborted.

Note An infeed character (LF) is created when the ENTER key is pressed, and is counted by

BYTES_LEFT.

• This function will return a non-zero value only when data is input from a keyboard (teach pendant

or CRT/KB), not from files or ports.

A-46

MARRC75KR07091E Rev D

A. KAREL LANGUAGE ALPHABETICAL DESCRIPTION

Warning

This function is used exclusively for reading from a window to

determine if more data has been entered. Do not use this function

with any other file device. Otherwise, you could injure personnel or

damage equipment.

See Also: Section 7.10.1 , "User Menu on the Teach Pendant," Section 7.10.2 , "User Menu on the

CRT/KB"

Example: The following example reads the first number, qd_field , and then uses BYTES_LEFT to

determine if the user entered any additional numbers. If so, these numbers are then read.

BYTES_LEFT Built-In Function

PROGRAM p_bytesleft

%NOLOCKGROUP

%ENVIRONMENT flbt

CONST

default_1 = 0

default_2 = -1

VAR rqd_field, opt_field_1, opt_field_2: INTEGER

BEGIN

WRITE(’Enter integer field(s): ’)

READ(rqd_field)

IF BYTES_LEFT(TPDISPLAY) > 0 THEN

READ(opt_field_1)

ELSE

opt_field_1 = default_1

ENDIF

IF BYTES_LEFT(TPDISPLAY) > 0 THEN

READ(opt_field_2)

ELSE

opt_field_2 = default_2

ENDIF

END p_bytesleft

A.4

- C - KAREL LANGUAGE DESCRIPTION

A.4.1

CALL_PROG Built-In Procedure

Purpose: Allows a KAREL program to call an external KAREL or teach pendant program. This

means that the programmer does not have to determine the program to be called until run time.

Syntax : CALL_PROG(prog_name, prog_index)

A-47

A. KAREL LANGUAGE ALPHABETICAL DESCRIPTION

MARRC75KR07091E Rev D

Input/Output Parameters :

[in] prog_name :STRING

[in,out] prog_index :INTEGER

%ENVIRONMENT Group :PBCORE

Details:

• prog_name is the name of the program to be executed, in the current calling task.

• prog_index returns the entry number in the program table where prog_name is located. This

variable does not need to be initialized and should not be modified.

• CALL_PROG cannot be used to run internal or external routines.

See Also: CURR_PROG and CALL_PROGLIN Built-In Functions

Example: Refer to Section B.2 , "Copying Path Variables" (CPY_PTH.KL), for a detailed program

example.

A.4.2

CALL_PROGLIN Built-In Procedure

Purpose: Allows a KAREL program to call an external KAREL or teach pendant program, beginning

at a specified line. This means that the programmer does not need to know, at creation and translation,

what program will be called. The programmer can decide this at run time.

Syntax : CALL_PROGLIN(prog_name, prog_line, prog_index, pause_entry)

Input/Output Parameters :

[in] prog_name :STRING

[in] prog_line :INTEGER

[in,out] prog_index :INTEGER

[in] pause_entry :BOOLEAN

%ENVIRONMENT Group :BYNAM

Details:

• prog_name is the name of the program to be executed, in the current calling task.

• prog_line specifies the line at which to begin execution for a teach pendant program. 0 or 1 is

used for the beginning of the program.

A-48

MARRC75KR07091E Rev D

A. KAREL LANGUAGE ALPHABETICAL DESCRIPTION

• KAREL programs always execute at the beginning of the program.

• prog_index returns the entry number in the program table where prog_name is located. This

variable does not need to be initialized and should not be modified.

• pause_entry specifies whether to pause program execution upon entry of the program.

• CALL_PROGLIN cannot be used to run internal or external routines.

See Also: CURR_PROG and CALL_PROG Built-In Function

Example: Refer to Section B.5 ,"Using Register Built-ins" (REG_EX.KL), for a detailed program

example.

A.4.3

CANCEL Action

Purpose: Terminates any motion in progress

Syntax : CANCEL <GROUP[n{,n}]>

Details:

• Cancels a motion currently in progress or pending (but not stopped) for one or more groups.

• CANCEL does not cancel motions that are already stopped. To cancel a motion that is already

stopped, use the CNCL_STP_MTN built-in routine.

• If the group clause is not present, all groups for which the task has control (when the condition is

defined) will be canceled. In particular, if the program containing the condition handler definition

contains the %NOLOCKGROUP directive, the CANCEL action will not cancel motion in any

group.

• If a motion that is canceled and is part of a SIMULTANEOUS or COORDINATED motion with

other groups, the motions for all groups are canceled.

• The robot and auxiliary or extended axes decelerate smoothly to a stop. The remainder of the

motion is canceled.

• Canceled motions are treated as completed and cannot be resumed.

• The CANCEL action in a global condition handler cancels any pending motions.

A.4.4

CANCEL Statement

Purpose: Terminates any motion in progress.

Syntax : CANCEL <GROUP[n{,n}]>

Details:

A-49

A. KAREL LANGUAGE ALPHABETICAL DESCRIPTION

MARRC75KR07091E Rev D

• Cancels a motion currently in progress or pending (but not stopped) for one or more groups.

• CANCEL does not cancel motions that are already stopped. To cancel a motion that is already

stopped, use the CNCL_STP_MTN built-in routine.

• If the group clause is not present, all groups for which the task has control will be canceled.

In particular, if the program using the CANCEL statement contains the %NOLOCKGROUP

directive, the CANCEL statement will not cancel motion in any group.

• If a motion that is canceled is part of a SIMULTANEOUS or COORDINATED motion with other

groups, the motions for all groups are canceled.

• The robot and auxiliary axes decelerate smoothly to a stop. The remainder of the motion is

canceled.

• Canceled motions are treated as completed and cannot be resumed.

• CANCEL does not affect stopped motions. Stopped motions can be resumed.

• If an interrupt routine executes a CANCEL statement and the interrupted statement was a motion

statement, when the interrupted program resumes, execution normally resumes with the statement

following the motion statement.

• CANCEL might not work as expected if it is used in a routine called by a condition handler. The

motion might already be put on the stopped motion queue before the routine is called. Use a

CANCEL action directly in the condition handler to be sure the motion is canceled.

• Motion cannot be cancelled for a different task.

See Also: Appendix E , ‘‘Syntax Diagrams,’’ for additional syntax information

A.4.5

CANCEL FILE Statement

Purpose: Cancels a READ or WRITE statement that is in progress.

Syntax : CANCEL FILE [file_var]

where:

file_var :a FILE variable

Details:

• Used to cancel input or output on a specified file

• The built-in function IO_STATUS can be used to determine if a CANCEL FILE operation was

successful or, if it failed to determine the reason for the failure.

See Also: IO_STATUS Built-In Function, Chapter 7 FILE INPUT/OUTPUT OPERATIONS ,

Appendix E , ‘‘Syntax Diagrams,’’ for additional syntax information

A-50

MARRC75KR07091E Rev D

A. KAREL LANGUAGE ALPHABETICAL DESCRIPTION

Example: The following example reads an integer, but cancels the read if the F1

key is pressed.

CANCEL FILE Statement

PROGRAM can_file_ex

%ENVIRONMENT FLBT

%ENVIRONMENT UIF

%NOLOCKGROUP

VAR

int_var: INTEGER

ROUTINE cancel_read

BEGIN

CANCEL FILE TPDISPLAY

END cancel_read

BEGIN

CONDITION[1]:

WHEN TPIN[ky_f1]+ DO

cancel_read

ENABLE CONDITION[1]

ENDCONDITION

ENABLE CONDITION[1]

REPEAT

-- Read an integer, but cancel if

pressed

CLR_IO_STAT(TPDISPLAY)

WRITE(CR, ’Enter an integer: ’)

READ(int_var)

UNTIL FALSE

end can_file_ex

A.4.6

CHECK_DICT Built-In Procedure

Purpose: Checks the specified dictionary for a specified element

Syntax : CHECK_DICT(dict_name, element_no, status)

Input/Output Parameters :

[in] dict_name :STRING

[in] element_no :STRING

[out] status :INTEGER

%ENVIRONMENT Group :UIF

A-51

A. KAREL LANGUAGE ALPHABETICAL DESCRIPTION

MARRC75KR07091E Rev D

Details:

• dict_name is the name of the dictionary to check.

• element_no is the element number within the dictionary.

• status explains the status of the attempted operation. If not equal to 0, then the element could not

be found.

See Also: ADD_DICT, READ_DICT, WRITE_DICT, REMOVE_DICT Built-In Procedures. Refer

to the program example for the DISCTRL_LIST Built-In Procedure and Chapter 10 DICTIONARIES

AND FORMS

Example: Refer to Section B.12 , "Displaying a List From a Dictionary File" (DCLST_EX.KL), for a

detailed program example.

A.4.7

CHECK_EPOS Built-In Procedure

Purpose: Checks that the specified position is valid and that no motion errors will be generated

when moving to this position

Syntax : CHECK_EPOS (eposn, uframe, utool, status <, group_no>)

Input/Output Parameters :

[in] eposn :XYZWPREXT

[in] uframe :POSITION

[in] utool :POSITION

[out] status :INTEGER

[in] group_no :INTEGER

%ENVIRONMENT Group :PBCORE

Details:

• eposn is the XYZWPREXT position to be checked.

• uframe specifies the uframe position to use with eposn.

• utool specifies the utool position to use with eposn.

• status explains the status of the check. If the position is reachable, the status will be 0.

• group_no is optional, but if specified will be the group number for eposn . If not specified the

default group of the program is used.

A-52

MARRC75KR07091E Rev D

A. KAREL LANGUAGE ALPHABETICAL DESCRIPTION

FANUC Robotics SYSTEM R-30iA and R-30iB Controller. KAREL Reference Manual - page 12
