FANUC Series 16i/160i/160is-MB, Series 18i/180i/180is-MB5, Series 18i/180i/180is-MB. Operator's Manual

SAFETY PRECAUTIONS

This section describes the safety precautions related to the use of CNC units. It is essential that these precautions

be observed by users to ensure the safe operation of machines equipped with a CNC unit (all descriptions in this

section assume this configuration). Note that some precautions are related only to specific functions, and thus

may not be applicable to certain CNC units.

Users must also observe the safety precautions related to the machine, as described in the relevant manual supplied

by the machine tool builder. Before attempting to operate the machine or create a program to control the operation

of the machine, the operator must become fully familiar with the contents of this manual and relevant manual

supplied by the machine tool builder.

Contents

1. DEFINITION OF WARNING, CAUTION, AND NOTE .

s-2

2. GENERAL WARNINGS AND CAUTIONS .

s-3

3. WARNINGS AND CAUTIONS RELATED TO PROGRAMMING .

s-5

4. WARNINGS AND CAUTIONS RELATED TO HANDLING .

s-7

5. WARNINGS RELATED TO DAILY MAINTENANCE .

s-9

s-1

SAFETY PRECAUTIONS

B-63534EN/02

DEFINITION OF WARNING, CAUTION, AND NOTE

This manual includes safety precautions for protecting the user and preventing damage to the

machine. Precautions are classified into Warning and Caution according to their bearing on safety.

Also, supplementary information is described as a Note. Read the Warning, Caution, and Note

thoroughly before attempting to use the machine.

WARNING

Applied when there is a danger of the user being injured or when there is a danger of both the user

being injured and the equipment being damaged if the approved procedure is not observed.

CAUTION

Applied when there is a danger of the equipment being damaged, if the approved procedure is not

observed.

NOTE

The Note is used to indicate supplementary information other than Warning and Caution.

` Read this manual carefully, and store it in a safe place.

s-2

B-63534EN/02

SAFETY PRECAUTIONS

GENERAL WARNINGS AND CAUTIONS

WARNING

Never attempt to machine a workpiece without first checking the operation of the machine.

Before starting a production run, ensure that the machine is operating correctly by performing

a trial run using, for example, the single block, feedrate override, or machine lock function or

by operating the machine with neither a tool nor workpiece mounted. Failure to confirm the

correct operation of the machine may result in the machine behaving unexpectedly, possibly

causing damage to the workpiece and/or machine itself, or injury to the user.

Before operating the machine, thoroughly check the entered data.

Operating the machine with incorrectly specified data may result in the machine behaving

unexpectedly, possibly causing damage to the workpiece and/or machine itself, or injury to the

user.

Ensure that the specified feedrate is appropriate for the intended operation. Generally, for each

machine, there is a maximum allowable feedrate. The appropriate feedrate varies with the

intended operation. Refer to the manual provided with the machine to determine the maximum

allowable feedrate. If a machine is run at other than the correct speed, it may behave

unexpectedly, possibly causing damage to the workpiece and/or machine itself, or injury to the

user.

When using a tool compensation function, thoroughly check the direction and amount of

compensation.

Operating the machine with incorrectly specified data may result in the machine behaving

unexpectedly, possibly causing damage to the workpiece and/or machine itself, or injury to the

user.

The parameters for the CNC and PMC are factory-set. Usually, there is not need to change them.

When, however, there is not alternative other than to change a parameter, ensure that you fully

understand the function of the parameter before making any change.

Failure to set a parameter correctly may result in the machine behaving unexpectedly, possibly

causing damage to the workpiece and/or machine itself, or injury to the user.

Immediately after switching on the power, do not touch any of the keys on the MDI panel until

the position display or alarm screen appears on the CNC unit.

Some of the keys on the MDI panel are dedicated to maintenance or other special operations.

Pressing any of these keys may place the CNC unit in other than its normal state. Starting the

machine in this state may cause it to behave unexpectedly.

The operator’s manual and programming manual supplied with a CNC unit provide an overall

description of the machine’s functions, including any optional functions. Note that the optional

functions will vary from one machine model to another. Therefore, some functions described

in the manuals may not actually be available for a particular model. Check the specification of

the machine if in doubt.

s-3

SAFETY PRECAUTIONS

B-63534EN/02

WARNING

8. Some functions may have been implemented at the request of the machine-tool builder. When

using such functions, refer to the manual supplied by the machine-tool builder for details of their

use and any related cautions.

CAUTION

Do not remove the internal parts, including the ATA card and compact flash card, from within

the CNC.

NOTE

Programs, parameters, and macro variables are stored in nonvolatile memory in the CNC unit.

Usually, they are retained even if the power is turned off. Such data may be deleted inadvertently,

however, or it may prove necessary to delete all data from nonvolatile memory as part of error

recovery.

To guard against the occurrence of the above, and assure quick restoration of deleted data, backup

all vital data, and keep the backup copy in a safe place.

s-4

B-63534EN/02

SAFETY PRECAUTIONS

WARNINGS AND CAUTIONS RELATED TO

PROGRAMMING

This section covers the major safety precautions related to programming. Before attempting to

perform programming, read the supplied operator’s manual and programming manual carefully

such that you are fully familiar with their contents.

WARNING

Coordinate system setting

If a coordinate system is established incorrectly, the machine may behave unexpectedly as a

result of the program issuing an otherwise valid move command.

Such an unexpected operation may damage the tool, the machine itself, the workpiece, or cause

injury to the user.

Positioning by nonlinear interpolation

When performing positioning by nonlinear interpolation (positioning by nonlinear movement

between the start and end points), the tool path must be carefully confirmed before performing

programming.

Positioning involves rapid traverse. If the tool collides with the workpiece, it may damage the

tool, the machine itself, the workpiece, or cause injury to the user.

Function involving a rotation axis

When programming polar coordinate interpolation or normal-direction (perpendicular) control,

pay careful attention to the speed of the rotation axis. Incorrect programming may result in the

rotation axis speed becoming excessively high, such that centrifugal force causes the chuck to

lose its grip on the workpiece if the latter is not mounted securely.

Such mishap is likely to damage the tool, the machine itself, the workpiece, or cause injury to

the user.

Inch/metric conversion

Switching between inch and metric inputs does not convert the measurement units of data such

as the workpiece origin offset, parameter, and current position. Before starting the machine,

therefore, determine which measurement units are being used. Attempting to perform an

operation with invalid data specified may damage the tool, the machine itself, the workpiece, or

cause injury to the user.

Constant surface speed control

When an axis subject to constant surface speed control approaches the origin of the workpiece

coordinate system, the spindle speed may become excessively high. Therefore, it is necessary

to specify a maximum allowable speed. Specifying the maximum allowable speed incorrectly

may damage the tool, the machine itself, the workpiece, or cause injury to the user.

s-5

SAFETY PRECAUTIONS

B-63534EN/02

WARNING

6. Stroke check

After switching on the power, perform a manual reference position return as required. Stroke

check is not possible before manual reference position return is performed. Note that when stroke

check is disabled, an alarm is not issued even if a stroke limit is exceeded, possibly damaging

the tool, the machine itself, the workpiece, or causing injury to the user.

7. Tool post interference check

A tool post interference check is performed based on the tool data specified during automatic

operation. If the tool specification does not match the tool actually being used, the interference

check cannot be made correctly, possibly damaging the tool or the machine itself, or causing

injury to the user.

After switching on the power, or after selecting a tool post manually, always start automatic

operation and specify the tool number of the tool to be used.

8. Absolute/incremental mode

If a program created with absolute values is run in incremental mode, or vice versa, the machine

may behave unexpectedly.

9. Plane selection

If an incorrect plane is specified for circular interpolation, helical interpolation, or a canned cycle,

the machine may behave unexpectedly. Refer to the descriptions of the respective functions for

details.

10. Torque limit skip

Before attempting a torque limit skip, apply the torque limit. If a torque limit skip is specified

without the torque limit actually being applied, a move command will be executed without

performing a skip.

11. Programmable mirror image

Note that programmed operations vary considerably when a programmable mirror image is

enabled.

12. Compensation function

If a command based on the machine coordinate system or a reference position return command

is issued in compensation function mode, compensation is temporarily canceled, resulting in the

unexpected behavior of the machine.

Before issuing any of the above commands, therefore, always cancel compensation function

mode.

s-6

B-63534EN/02

SAFETY PRECAUTIONS

WARNINGS AND CAUTIONS RELATED TO HANDLING

This section presents safety precautions related to the handling of machine tools. Before attempting

to operate your machine, read the supplied operator’s manual and programming manual carefully,

such that you are fully familiar with their contents.

WARNING

Manual operation

When operating the machine manually, determine the current position of the tool and workpiece,

and ensure that the movement axis, direction, and feedrate have been specified correctly.

Incorrect operation of the machine may damage the tool, the machine itself, the workpiece, or

cause injury to the operator.

Manual reference position return

After switching on the power, perform manual reference position return as required. If the

machine is operated without first performing manual reference position return, it may behave

unexpectedly. Stroke check is not possible before manual reference position return is performed.

An unexpected operation of the machine may damage the tool, the machine itself, the workpiece,

or cause injury to the user.

Manual numeric command

When issuing a manual numeric command, determine the current position of the tool and

workpiece, and ensure that the movement axis, direction, and command have been specified

correctly, and that the entered values are valid.

Attempting to operate the machine with an invalid command specified may damage the tool, the

machine itself, the workpiece, or cause injury to the operator.

Manual handle feed

In manual handle feed, rotating the handle with a large scale factor, such as 100, applied causes

the tool and table to move rapidly. Careless handling may damage the tool and/or machine, or

cause injury to the user.

Disabled override

If override is disabled (according to the specification in a macro variable) during threading, rigid

tapping, or other tapping, the speed cannot be predicted, possibly damaging the tool, the machine

itself, the workpiece, or causing injury to the operator.

Origin/preset operation

Basically, never attempt an origin/preset operation when the machine is operating under the

control of a program. Otherwise, the machine may behave unexpectedly, possibly damaging the

tool, the machine itself, the tool, or causing injury to the user.

s-7

SAFETY PRECAUTIONS

B-63534EN/02

WARNING

7. Workpiece coordinate system shift

Manual intervention, machine lock, or mirror imaging may shift the workpiece coordinate

system. Before attempting to operate the machine under the control of a program, confirm the

coordinate system carefully.

If the machine is operated under the control of a program without making allowances for any shift

in the workpiece coordinate system, the machine may behave unexpectedly, possibly damaging

the tool, the machine itself, the workpiece, or causing injury to the operator.

8. Software operator’s panel and menu switches

Using the software operator’s panel and menu switches, in combination with the MDI panel, it

is possible to specify operations not supported by the machine operator’s panel, such as mode

change, override value change, and jog feed commands.

Note, however, that if the MDI panel keys are operated inadvertently, the machine may behave

unexpectedly, possibly damaging the tool, the machine itself, the workpiece, or causing injury

to the user.

9. Manual intervention

If manual intervention is performed during programmed operation of the machine, the tool path

may vary when the machine is restarted. Before restarting the machine after manual intervention,

therefore, confirm the settings of the manual absolute switches, parameters, and

absolute/incremental command mode.

10. Feed hold, override, and single block

The feed hold, feedrate override, and single block functions can be disabled using custom macro

system variable #3004. Be careful when operating the machine in this case.

11. Dry run

Usually, a dry run is used to confirm the operation of the machine. During a dry run, the machine

operates at dry run speed, which differs from the corresponding programmed feedrate. Note that

the dry run speed may sometimes be higher than the programmed feed rate.

12. Cutter and tool nose radius compensation in MDI mode

Pay careful attention to a tool path specified by a command in MDI mode, because cutter or tool

nose radius compensation is not applied. When a command is entered from the MDI to interrupt

in automatic operation in cutter or tool nose radius compensation mode, pay particular attention

to the tool path when automatic operation is subsequently resumed. Refer to the descriptions of

the corresponding functions for details.

13. Program editing

If the machine is stopped, after which the machining program is edited (modification, insertion,

or deletion), the machine may behave unexpectedly if machining is resumed under the control

of that program. Basically, do not modify, insert, or delete commands from a machining program

while it is in use.

s-8

B-63534EN/02

SAFETY PRECAUTIONS

WARNINGS RELATED TO DAILY MAINTENANCE

WARNING

1. Memory backup battery replacement

Only those personnel who have received approved safety and maintenance training may perform

this work.

When replacing the batteries, be careful not to touch the high-voltage circuits (marked

and

fitted with an insulating cover).

Touching the uncovered high-voltage circuits presents an extremely dangerous electric shock

hazard.

NOTE

The CNC uses batteries to preserve the contents of its memory, because it must retain data such as

programs, offsets, and parameters even while external power is not applied.

If the battery voltage drops, a low battery voltage alarm is displayed on the machine operator’s panel

or screen.

When a low battery voltage alarm is displayed, replace the batteries within a week. Otherwise, the

contents of the CNC’s memory will be lost.

Refer to the maintenance section of the operator’s manual or programming manual for details of the

battery replacement procedure.

s-9

SAFETY PRECAUTIONS

B-63534EN/02

WARNING

2. Absolute pulse coder battery replacement

Only those personnel who have received approved safety and maintenance training may perform

this work.

When replacing the batteries, be careful not to touch the high-voltage circuits (marked

and

fitted with an insulating cover).

Touching the uncovered high-voltage circuits presents an extremely dangerous electric shock

hazard.

NOTE

The absolute pulse coder uses batteries to preserve its absolute position.

If the battery voltage drops, a low battery voltage alarm is displayed on the machine operator’s panel

or screen.

When a low battery voltage alarm is displayed, replace the batteries within a week. Otherwise, the

absolute position data held by the pulse coder will be lost.

Refer to the FANUC SERVO AMPLIFIER αi series Maintenance Manual or FANUC SERVO

AMPLIFIER α series Maintenance Manual for details of the battery replacement procedure.

s-10

B-63534EN/02

Table of Contents

SAFETY PRECAUTIONS .

s-1

I. GENERAL

1. GENERAL .

1.1

GENERAL FLOW OF OPERATION OF CNC MACHINE TOOL

1.2

NOTES ON READING THIS MANUAL

1.3

NOTES ON VARIOUS KINDS OF DATA

II. PROGRAMMING

GENERAL .

1.1

TOOL MOVEMENT ALONG WORKPIECE PARTS FIGURE-INTERPOLATION

1.2

FEED-FEED FUNCTION

1.3

PART DRAWING AND TOOL MOVEMENT

1.3.1

Reference Position (Machine-Specific Position)

1.3.2

Coordinate System on Part Drawing and Coordinate System Specified by

CNC - Coordinate System

1.3.3

How to Indicate Command Dimensions for Moving the Tool - Absolute,

Incremental Commands

1.4

CUTTING SPEED - SPINDLE SPEED FUNCTION

1.5

SELECTION OF TOOL USED FOR VARIOUS MACHINING - TOOL FUNCTION

1.6

COMMAND FOR MACHINE OPERATIONS - MISCELLANEOUS FUNCTION

1.7

PROGRAM CONFIGURATION

1.8

TOOL FIGURE AND TOOL MOTION BY PROGRAM

1.9

TOOL MOVEMENT RANGE - STROKE

CONTROLLED AXES .

2.1

CONTROLLED AXES

2.2

AXIS NAME

2.3

INCREMENT SYSTEM

2.4

MAXIMUM STROKE

PREPARATORY FUNCTION (G FUNCTION) .

INTERPOLATION FUNCTIONS .

4.1

POSITIONING (G00)

4.2

SINGLE DIRECTION POSITIONING (G60)

4.3

LINEAR INTERPOLATION (G01)

4.4

CIRCULAR INTERPOLATION (G02, G03)

4.5

HELICAL INTERPOLATION (G02, G03)

4.6

HELICAL INTERPOLATION B (G02, G03)

4.7

SPIRAL INTERPOLATION, CONICAL INTERPOLATION (G02, G03)

4.8

POLAR COORDINATE INTERPOLATION (G12.1, G13.1)

4.9

CYLINDRICAL INTERPOLATION (G07.1)

4.10

INVOLUTE INTERPOLATION (G02.2, G03.2)

c-1

Table of Contents

B–63534EN/02

4.11

EXPONENTIAL INTERPOLATION (G02.3, G03.3)

4.12

SMOOTH INTERPOLATION (G05.1)

4.13

NURBS INTERPOLATION (G06.2)

4.14

HYPOTHETICAL AXIS INTERPOLATION (G07)

4.15

THREAD CUTTING (G33)

4.16

SKIP FUNCTION (G31)

4.17

MULTISTAGE SKIP (G31)

4.18

HIGH SPEED SKIP SIGNAL (G31)

4.19

CONTINUOUS HIGH-SPEED SKIP FUNCTION (G31)

FEED FUNCTIONS .

5.1

GENERAL

5.2

RAPID TRAVERSE

5.3

CUTTING FEED

5.4

CUTTING FEEDRATE CONTROL

102

5.4.1

Exact Stop (G09, G61) Cutting Mode (G64) Tapping Mode (G63)

103

5.4.2

Automatic Corner Override

104

5.4.2.1 Automatic Override for Inner Corners (G62)

104

5.4.2.2 Internal Circular Cutting Feedrate Change

106

5.4.3

Automatic Corner Deceleration

107

5.4.3.1 Corner Deceleration According to the Corner Angle

107

5.4.3.2 Corner Deceleration According to the Feedrate Difference between Blocks Along Each Axis .

110

5.5

DWELL (G04)

114

REFERENCE POSITION .

115

6.1

REFERENCE POSITION RETURN

116

6.2

FLOATING REFERENCE POSITION RETURN (G30.1)

121

COORDINATE SYSTEM .

122

7.1

MACHINE COORDINATE SYSTEM

123

7.2

WORKPIECE COORDINATE SYSTEM

124

7.2.1

Setting a Workpiece Coordinate System

124

7.2.2

Selecting a Workpiece Coordinate System

125

7.2.3

Changing Workpiece Coordinate System

126

7.2.4

Workpiece Coordinate System Preset (G92.1)

129

7.2.5

Adding Workpiece Coordinate Systems (G54.1 or G54)

131

7.3

LOCAL COORDINATE SYSTEM

133

7.4

PLANE SELECTION

135

COORDINATE VALUE AND DIMENSION .

136

8.1

ABSOLUTE AND INCREMENTAL PROGRAMMING (G90, G91)

137

8.2

POLAR COORDINATE COMMAND (G15, G16)

138

8.3

INCH/METRIC CONVERSION (G20, G21)

141

8.4

DECIMAL POINT PROGRAMMING

142

c-2

B-63534EN/02

Table of Contents

9. SPINDLE SPEED FUNCTION (S FUNCTION) .

143

9.1

SPECIFYING THE SPINDLE SPEED WITH A CODE

144

9.2

SPECIFYING THE SPINDLE SPEED VALUE DIRECTLY (S5-DIGIT COMMAND)

144

9.3

CONSTANT SURFACE SPEED CONTROL (G96, G97)

145

9.4

SPINDLE SPEED FLUCTUATION DETECTION FUNCTION (G25, G26)

148

10.TOOL FUNCTION (T FUNCTION) .

151

10.1

TOOL SELECTION FUNCTION

152

10.2

TOOL LIFE MANAGEMENT FUNCTION

153

10.2.1

Tool Life Management Data

154

10.2.2

155

10.2.3

Tool Life Management Command in a Machining Program

158

10.2.4

Tool Life

161

11.AUXILIARY FUNCTION .

162

11.1

AUXILIARY FUNCTION (M FUNCTION)

163

11.2

MULTIPLE M COMMANDS IN A SINGLE BLOCK

164

11.3

M CODE GROUP CHECK FUNCTION

165

11.4

THE SECOND AUXILIARY FUNCTIONS (B CODES)

166

12.PROGRAM CONFIGURATION .

167

12.1

PROGRAM COMPONENTS OTHER THAN PROGRAM SECTIONS

169

12.2

PROGRAM SECTION CONFIGURATION

172

12.3

SUBPROGRAM (M98, M99)

178

12.4

8-DIGIT PROGRAM NUMBER

182

13.FUNCTIONS TO SIMPLIFY PROGRAMMING .

185

13.1

CANNED CYCLE

186

13.1.1

High-Speed Peck Drilling Cycle (G73)

190

13.1.2

Left-Handed Tapping Cycle (G74)

192

13.1.3

Fine Boring Cycle (G76)

194

13.1.4

Drilling Cycle, Spot Drilling (G81)

196

13.1.5

Drilling Cycle Counter Boring Cycle (G82)

198

13.1.6

Peck Drilling Cycle (G83)

200

13.1.7

Small-Hole Peck Drilling Cycle (G83)

202

13.1.8

Tapping Cycle (G84)

206

13.1.9

Boring Cycle (G85)

208

13.1.10

Boring Cycle (G86)

210

13.1.11

Back Boring Cycle (G87)

212

13.1.12

Boring Cycle (G88)

214

13.1.13

Boring Cycle (G89)

216

13.1.14

Canned Cycle Cancel (G80)

218

13.2

RIGID TAPPING

221

13.2.1

Rigid Tapping (G84)

222

13.2.2

Left-Handed Rigid Tapping Cycle (G74)

225

13.2.3

Peck Rigid Tapping Cycle (G84 or G74)

228

13.2.4

Canned Cycle Cancel (G80)

230

13.3

CANNED GRINDING CYCLE (FOR GRINDING MACHINE)

231

13.3.1

Plunge Grinding Cycle (G75)

232

13.3.2

Direct Constant-Dimension Plunge Grinding Cycle (G77)

234

c-3

Table of Contents

B–63534EN/02

13.3.3

Continuous-Feed Surface Grinding Cycle (G78)

236

13.3.4

Intermittent-Feed Surface Grinding Cycle (G79)

238

13.4

GRINDING-WHEEL WEAR COMPENSATION BY CONTINUOUS DRESSING

(FOR GRINDING MACHINE)

240

13.5

AUTOMATIC GRINDING WHEEL DIAMETER COMPENSATION AFTER DRESSING

241

13.5.1

Checking the Minimum Grinding Wheel Diameter (For Grinding Machine)

241

13.6

IN-FEED GRINDING ALONG THE Y AND Z AXES AT THE END OF TABLE SWING

(FOR GRINDING MACHINE)

242

13.7

OPTIONAL ANGLE CHAMFERING AND CORNER ROUNDING

243

13.8

EXTERNAL MOTION FUNCTION (G81)

246

13.9

FIGURE COPY (G72.1, G72.2)

247

13.10

THREE-DIMENSIONAL COORDINATE CONVERSION (G68, G69)

254

13.11

INDEX TABLE INDEXING FUNCTION

261

14.COMPENSATION FUNCTION .

264

14.1

TOOL LENGTH OFFSET (G43, G44, G49)

265

14.1.1

General

265

14.1.2

G53, G28, G30, and G30.1 Commands in Tool Length Offset Mode

270

14.2

AUTOMATIC TOOL LENGTH MEASUREMENT (G37)

273

14.3

TOOL OFFSET (G45-G48)

277

14.4

CUTTER COMPENSATION B (G39-G42)

282

14.4.1

Cutter Compensation Left (G41)

285

14.4.2

Cutter Compensation Right (G42)

287

14.4.3

Corner Offset Circular Interpolation (G39)

289

14.4.4

Cutter Compensation Cancel (G40)

290

14.4.5

Switch between Cutter Compensation Left and Cutter Compensation Right

291

14.4.6

Change of the Cutter Compensation Value

292

14.4.7

Positive/Negative Cutter Compensation Value and Tool Center Path

293

14.5

OVERVIEW OF CUTTER COMPENSATION C (G40-G42)

295

14.6

DETAILS OF CUTTER COMPENSATION C

301

14.6.1

General

301

14.6.2

Tool Movement in Start-up

302

14.6.3

Tool Movement in Offset Mode

306

14.6.4

Tool Movement in Offset Mode Cancel

320

14.6.5

Interference Check

326

14.6.6

Overcutting by Cutter Compensation

331

14.6.7

Input Command from MDI

334

14.6.8

G53, G28, G30, G30.1 and G29 Commands in Cutter Compensation C Mode

335

14.6.9

Corner Circular Interpolation (G39)

354

14.7

THREE-DIMENSIONAL TOOL COMPENSATION (G40, G41)

356

14.8

TOOL COMPENSATION VALUES, NUMBER OF COMPENSATION VALUES,

AND ENTERING VALUES FROM THE PROGRAM (G10)

360

14.9

SCALING (G50, G51)

362

14.10

COORDINATE SYSTEM ROTATION (G68, G69)

367

14.11

NORMAL DIRECTION CONTROL (G40.1, G41.1, G42.1 OR G150, G151, G152)

373

14.12

PROGRAMMABLE MIRROR IMAGE (G50.1, G51.1)

378

14.13

GRINDING WHEEL WEAR COMPENSATION

380

14.14

ROTARY TABLE DYNAMIC FIXTURE OFFSET

384

c-4

B-63534EN/02

Table of Contents

15.CUSTOM MACRO .

392

15.1

VARIABLES

393

15.2

SYSTEM VARIABLES

397

15.3

ARITHMETIC AND LOGIC OPERATION

406

15.4

MACRO STATEMENTS AND NC STATEMENTS

411

15.5

BRANCH AND REPETITION

412

15.5.1

Unconditional Branch (GOTO Statement)

412

15.5.2

Conditional Branch (IF Statement)

412

15.5.3

Repetition (While Statement)

413

15.6

MACRO CALL

416

15.6.1

Simple Call (G65)

417

15.6.2

Modal Call (G66)

421

15.6.3

Macro Call Using G Code

423

15.6.4

Macro Call Using an M Code

424

15.6.5

Subprogram Call Using an M Code

425

15.6.6

Subprogram Calls Using a T Code

426

15.6.7

Sample Program

427

15.7

PROCESSING MACRO STATEMENTS

429

15.7.1

Details of NC Statements and Macro Statements Execution

429

15.7.2

Caution for Using System Variables

431

15.8

REGISTERING CUSTOM MACRO PROGRAMS

434

15.9

LIMITATIONS

435

15.10

EXTERNAL OUTPUT COMMANDS

436

15.11

INTERRUPTION TYPE CUSTOM MACRO

440

15.11.1

Specification Method

441

15.11.2

Details of Functions

442

16.PATTERN DATA INPUT FUNCTION .

450

16.1

DISPLAYING THE PATTERN MENU

451

16.2

PATTERN DATA DISPLAY

455

16.3

CHARACTERS AND CODES TO BE USED

FOR THE PATTERN DATA INPUT FUNCTION

459

17.PROGRAMMABLE PARAMETER ENTRY (G10) .

461

18.MEMORY OPERATION USING FS15 TAPE FORMAT .

463

19.HIGH SPEED CUTTING FUNCTIONS .

464

19.1

HIGH-SPEED CYCLE CUTTING

465

19.2

FEEDRATE CLAMPING BY ARC RADIUS

467

19.3

HIGH-SPEED REMOTE BUFFER

468

19.3.1

High-Speed Remote Buffer A (G05)

468

19.3.2

High-Speed Remote Buffer B (G05)

471

19.4

DISTRIBUTION PROCESSING TERMINATION MONITORING FUNCTION

FOR THE HIGH-SPEED MACHINING COMMAND (G05)

472

19.5

HIGH-SPEED LINEAR INTERPOLATION (G05)

473

19.6

ADVANCED PREVIEW CONTROL (G08)

476

19.7

AI CONTOUR CONTROL FUNCTION/AI NANO CONTOUR CONTROL FUNCTION

478

c-5

Table of Contents

B–63534EN/02

19.8

HIGH-PRECISION CONTOUR CONTROL

500

19.9

LOOK-AHEAD BELL-SHAPED ACCELERATION/DECELERATION

BEFORE INTERPOLATION TIME CONSTANT CHANGE FUNCTION

508

19.10

OPTIMUM TORQUE ACCELERATION/DECELERATION

514

20.AXIS CONTROL FUNCTIONS .

527

20.1

SIMPLE SYNCHRONOUS CONTROL

528

20.2

ROTARY AXIS ROLL-OVER

531

20.2.1

Rotary Axis Roll-over

531

20.2.2

Rotary Axis Control

532

20.3

TOOL WITHDRAWAL AND RETURN (G10.6)

533

20.4

TANDEM CONTROL

536

20.5

ANGULAR AXIS CONTROL/ARBITRARY ANGULAR AXIS CONTROL

537

20.6

CHOPPING FUNCTION (G80, G81.1)

539

20.7

HOBBING MACHINE FUNCTION (G80, G81)

545

20.8

SIMPLE ELECTRIC GEAR BOX (G80, G81)

551

20.8.1

Simple Electric Gear Box (G80, G81)

551

20.8.2

Skip Function for EGB Axis (G31.8)

556

20.8.3

Spindle Electronic Gear Box

559

20.8.4

Electronic Gear Box Automatic Phase Synchronization

568

20.8.5

Electronic Gear Box 2 Pair

576

21.TWO-PATH CONTROL FUNCTION .

590

21.1

GENERAL

591

21.2

WAITING FOR PATHS

592

21.3

MEMORY COMMON TO PATH

594

21.4

COPYING A PROGRAM BETWEEN TWO PATHS

595

22.RISC PROCESSOR .

596

22.1

AI HIGH PRECISION CONTOUR CONTROL/AI NANO HIGH PRECISION

CONTOUR CONTROL

607

22.1.1

Look-ahead Acceleration/Deceleration Before Interpolation

608

22.1.2

Automatic Feedrate Control Function

613

22.1.3

Restrictions

622

22.1.4

The Function List which Can be Used

625

22.2

CYLINDRICAL INTERPOLATION CUTTING POINT CONTROL (G07.1)

633

22.3

TOOL CENTER POINT CONTROL

643

22.4

TOOL AXIS COMPENSATION IN TOOL AXIS DIRECTION

655

22.5

3-DIMENSIONAL CUTTER COMPENSATION

668

22.5.1

Tool Side Compensation

668

22.5.2

Leading Edge Offset

682

22.5.3

Restrictions

688

22.6

3-DIMENSIONAL CIRCULAR INTERPOLATION

693

III. OPERATION .

699

1. GENERAL .

701

1.1

MANUAL OPERATION

702

c-6

B-63534EN/02

Table of Contents

1.2

TOOL MOVEMENT BY PROGRAMING-AUTOMATIC OPERATION

704

1.3

AUTOMATIC OPERATION

705

1.4

TESTING A PROGRAM

707

1.4.1

Check by Running the Machine

707

1.4.2

How to View the Position Display Change without Running the Machine

708

1.5

EDITING A PART PROGRAM

709

1.6

DISPLAYING AND SETTING DATA

710

1.7

DISPLAY

713

1.7.1

Program Display

713

1.7.2

Current Position Display

714

1.7.3

Alarm Display

714

1.7.4

Parts Count Display, Run Time Display

715

1.7.5

Graphic Display

715

1.8

DATA INPUT/OUTPUT

716

OPERATIONAL DEVICES .

717

2.1

SETTING AND DISPLAY UNITS

718

2.1.1

7.2″/8.4″ LCD-Mounted Type CNC Control Unit

719

2.1.2

9.5″/10.4″ LCD-Mounted Type CNC Control Unit

719

2.1.3

Stand-Alone Type Small MDI Unit

720

2.1.4

Stand-Alone Type Standard MDI Unit

721

2.1.5

Stand-Alone Type 61 Full Key MDI Unit

722

2.2

EXPLANATION OF THE KEYBOARD

723

2.3

FUNCTION KEYS AND SOFT KEYS

725

2.3.1

General Screen Operations

725

2.3.2

Function Keys

726

2.3.3

Soft Keys

727

2.3.4

Key Input and Input Buffer

743

2.3.5

Warning Messages

744

2.3.6

Soft Key Configuration

745

2.4

EXTERNAL I/O DEVICES

746

2.4.1

FANUC Handy File

748

2.5

POWER ON/OFF

749

2.5.1

Turning on the Power

749

2.5.2

Screen Displayed at Power-on

750

2.5.3

Power Disconnection

751

MANUAL OPERATION .

752

3.1

MANUAL REFERENCE POSITION RETURN

753

3.2

JOG FEED

755

3.3

INCREMENTAL FEED

757

3.4

MANUAL HANDLE FEED

758

3.5

MANUAL ABSOLUTE ON AND OFF

761

3.6

TOOL AXIS DIRECTION HANDLE FEED/TOOL AXIS DIRECTION HANDLE FEED B

766

3.6.1

Tool Axis Direction Handle Feed

766

3.6.2

Tool Axis Normal Direction Handle Feed

769

3.7

MANUAL LINEAR/CIRCULAR INTERPOLATION

774

3.8

MANUAL RIGID TAPPING

779

3.9

MANUAL NUMERIC COMMAND

781

c-7

Table of Contents

B–63534EN/02

AUTOMATIC OPERATION .

789

4.1

MEMORY OPERATION

790

4.2

MDI OPERATION

793

4.3

DNC OPERATION

797

4.4

SIMULTANEOUS INPUT/OUTPUT

800

4.5

PROGRAM RESTART

802

4.6

SCHEDULING FUNCTION

809

4.7

SUBPROGRAM CALL FUNCTION (M198)

814

4.8

MANUAL HANDLE INTERRUPTION

816

4.9

MIRROR IMAGE

819

4.10

TOOL WITHDRAWAL AND RETURN

821

4.11

RETRACE FUNCTION

827

4.12

MANUAL INTERVENTION AND RETURN

835

4.13

DNC OPERATION WITH MEMORY CARD

837

4.13.1

Specification

837

4.13.2

Operations

838

4.13.2.1

DNC Operation

838

4.13.2.2

Subprogram Call (M198)

839

4.13.3

Limitation and Notes

840

4.13.4

Parameter

840

4.13.5

Connecting PCMCIA Card Attachment

841

4.13.5.1

Specification Number

841

4.13.5.2

Assembling

841

4.13.6

Recommended Memory Card

843

TEST OPERATION .

844

5.1

MACHINE LOCK AND AUXILIARY FUNCTION LOCK

845

5.2

FEEDRATE OVERRIDE

847

5.3

RAPID TRAVERSE OVERRIDE

848

5.4

DRY RUN

849

5.5

SINGLE BLOCK

850

SAFETY FUNCTIONS .

852

6.1

EMERGENCY STOP

853

6.2

OVERTRAVEL

854

6.3

STORED STROKE CHECK

855

6.4

STROKE LIMIT CHECK PRIOR TO PERFORMING MOVEMENT

859

ALARM AND SELF-DIAGNOSIS FUNCTIONS .

862

7.1

ALARM DISPLAY

863

7.2

ALARM HISTORY DISPLAY

865

7.3

CHECKING BY SELF-DIAGNOSTIC SCREEN

866

DATA INPUT/OUTPUT .

869

8.1

FILES

870

8.2

FILE SEARCH

872

c-8

B-63534EN/02

Table of Contents

8.3

FILE DELETION

874

8.4

PROGRAM INPUT/OUTPUT

875

8.4.1

Inputting a Program

875

8.4.2

Outputting a Program

878

8.5

OFFSET DATA INPUT AND OUTPUT

880

8.5.1

Inputting Offset Data

880

8.5.2

Outputting Offset Data

881

8.6

INPUTTING AND OUTPUTTING PARAMETERS AND

PITCH ERROR COMPENSATION DATA

882

8.6.1

Inputting Parameters

882

8.6.2

Outputting Parameters

883

8.6.3

Inputting Pitch Error Compensation Data

884

8.6.4

Outputting Pitch Error Compensation Data

885

8.7

INPUTTING/OUTPUTTING CUSTOM MACRO COMMON VARIABLES

886

8.7.1

Inputting Custom Macro Common Variables

886

8.7.2

Outputting Custom Macro Common Variable

887

8.8

DISPLAYING DIRECTORY OF FLOPPY CASSETTE

888

8.8.1

Displaying the Directory

889

8.8.2

Reading Files

892

8.8.3

Outputting Programs

893

8.8.4

Deleting Files

894

8.9

OUTPUTTING A PROGRAM LIST FOR A SPECIFIED GROUP

896

8.10

DATA INPUT/OUTPUT ON THE ALL IO SCREEN

897

8.10.1

Setting Input/Output-Related Parameters

898

8.10.2

Inputting and Outputting Programs

899

8.10.3

Inputting and Outputting Parameters

904

8.10.4

Inputting and Outputting Offset Data

906

8.10.5

Outputting Custom Macro Common Variables

908

8.10.6

Inputting and Outputting Floppy Files

909

8.11

DATA INPUT/OUTPUT USING A MEMORY CARD

914

8.12

DATA INPUT/OUTPUT BY EMBEDDED ETHERNET

926

8.12.1

FTP File Transfer Function

926

8.12.1.1 Host file list display

926

8.12.1.2 Host file search

929

8.12.1.3 Host file deletion

929

8.12.1.4 NC program input

930

8.12.1.5 NC program output

932

8.12.1.6 Input/output of various types of data

933

8.12.1.7 Checking and changing of the connection host

939

EDITING PROGRAMS .

942

9.1

INSERTING, ALTERING AND DELETING A WORD

943

9.1.1

Word Search

944

9.1.2

Heading a Program

946

9.1.3

Inserting a Word

947

9.1.4

Altering a Word

948

9.1.5

Deleting a Word

949

9.2

DELETING BLOCKS

950

9.2.1

Deleting a Block

950

9.2.2

Deleting Multiple Blocks

951

9.3

PROGRAM NUMBER SEARCH

952

c-9

Table of Contents

B–63534EN/02

9.4

SEQUENCE NUMBER SEARCH

953

9.5

DELETING PROGRAMS

955

9.5.1

Deleting One Program

955

9.5.2

Deleting All Programs

955

9.5.3

Deleting More than One Program by Specifying a Range

956

9.6

EXTENDED PART PROGRAM EDITING FUNCTION

957

9.6.1

Copying an Entire Program

958

9.6.2

Copying Part of a Program

959

9.6.3

Moving Part of a Program

960

9.6.4

Merging a Program

961

9.6.5

Supplementary Explanation for Copying, Moving and Merging

962

9.6.6

Replacement of Words and Addresses

964

9.7

EDITING OF CUSTOM MACROS

966

9.8

BACKGROUND EDITING

967

9.9

PASSWORD FUNCTION

968

9.10

COPYING A PROGRAM BETWEEN TWO PATHS

970

10.CREATING PROGRAMS .

975

10.1

CREATING PROGRAMS USING THE MDI PANEL

976

10.2

AUTOMATIC INSERTION OF SEQUENCE NUMBERS

977

10.3

CREATING PROGRAMS IN TEACH IN MODE (PLAYBACK)

979

10.4

CONVERSATIONAL PROGRAMMING WITH GRAPHIC FUNCTION

982

11.SETTING AND DISPLAYING DATA .

986

11.1

SCREENS DISPLAYED BY FUNCTION KEY

POS

993

11.1.1

Position Display in the Work Coordinate System

994

11.1.2

Position Display in the Relative Coordinate System

996

11.1.3

Overall Position Display

999

11.1.4

Presetting the Workpiece Coordinate System

1001

11.1.5

Actual Feedrate Display

1002

11.1.6

Display of Run Time and Parts Count

1004

11.1.7

Setting the Floating Reference Position

1005

11.1.8

Operating Monitor Display

1006

11.2

SCREENS DISPLAYED BY FUNCTION KEY

PROG

(IN MEMORY MODE OR MDI MODE)

1008

11.2.1

Program Contents Display

1009

11.2.2

Current Block Display Screen

1010

11.2.3

Next Block Display Screen

1011

11.2.4

Program Check Screen

1012

11.2.5

Program Screen for MDI Operation

1015

11.2.6

Stamping the Machining Time

1016

11.3

SCREENS DISPLAYED BY FUNCTION KEY

PROG

(IN THE EDIT MODE)

1024

11.3.1

Displaying Memory Used and a List of Programs

1024

11.3.2

Displaying a Program List for a Specified Group

1027

OFFSET

11.4

SCREENS DISPLAYED BY FUNCTION KEY

SETTING

1030

11.4.1

Setting and Displaying the Tool Offset Value

1031

c-10

B-63534EN/02

Table of Contents

11.4.2

Tool Length Measurement

1034

11.4.3

Displaying and Entering Setting Data

1036

11.4.4

Sequence Number Comparison and Stop

1038

11.4.5

Displaying and Setting Run Time, Parts Count, and Time

1040

11.4.6

Displaying and Setting the Workpiece Origin Offset Value

1042

11.4.7

Direct Input of Measured Workpiece Origin Offsets

1043

11.4.8

Displaying and Setting Custom Macro Common Variables

1045

11.4.9

Displaying Pattern Data and Pattern Menu

1046

11.4.10

Displaying and Setting the Software Operator’s Panel

1048

11.4.11

Displaying and Setting Tool Life Management Data

1050

11.4.12

Displaying and Setting Extended Tool Life Management

1053

11.4.13

Displaying and Setting Chopping Data

1058

11.4.14

Tool Length/Workpiece Origin Measurement B

1059

11.4.15

Displaying and Setting Rotary Table Dynamic Fixture Offset

1075

11.5

SCREENS DISPLAYED BY FUNCTION KEY

SYSTEM

1077

11.5.1

Displaying and Setting Parameters

1077

11.5.2

Displaying and Setting Pitch Error Compensation Data

1079

11.6

DISPLAYING THE PROGRAM NUMBER, SEQUENCE NUMBER, AND STATUS,

AND WARNING MESSAGES FOR DATA SETTING OR INPUT/OUTPUT OPERATION

1082

11.6.1

Displaying the Program Number and Sequence Number

1082

11.6.2

Displaying the Status and Warning for Data Setting or Input/Output Operation

1083

11.7

SCREENS DISPLAYED BY FUNCTION KEY

MESSAGE

1085

11.7.1

External Operator Message History Display

1085

11.8

CLEARING THE SCREEN

1087

11.8.1

Erase Screen Display

1087

11.8.2

Automatic Erase Screen Display

1088

12.GRAPHICS FUNCTION .

1090

12.1

GRAPHICS DISPLAY

1091

12.2

DYNAMIC GRAPHIC DISPLAY

1097

12.2.1

Path Drawing

1097

12.2.2

Solid Graphics

1106

12.3

BACKGROUND DRAWING

1118

13.HELP FUNCTION .

1121

14.SCREEN HARDCOPY .

1126

IV. MAINTENANCE

1. METHOD OF REPLACING BATTERY .

1131

1.1

REPLACING BATTERY FOR LCD-MOUNTED TYPE i SERIES

1132

1.2

REPLACING THE BATTERY FOR STAND-ALONE TYPE i SERIES

1135

1.3

BATTERY IN THE CNC DISPLAY UNIT WITH PC FUNCTIONS (3 VDC)

1138

1.4

BATTERY FOR SEPARATE ABSOLUTE PULSE CODERS (6 VDC)

1140

1.5

BATTERY FOR BUILT-IN ABSOLUTE PULSE CODERS (DC6V)

1141

1.5.1

Method of Replacing Battery for Servo Amplifier ai series

1141

1.5.2

Method of Replacing Battery for Servo Amplifier b series

1147

c-11

GENERAL

1. GENERAL

B-63534EN/02

GENERAL

This manual consists of the following parts:

About this manual

I. GENERAL

Describes chapter organization, applicable models, related manuals,

and notes for reading this manual.

II. PROGRAMMING

Describes each function: Format used to program functions in the NC

language, characteristics, and restrictions. When a program is created

through conversational automatic programming function, refer to the

manual for the conversational automatic programming function

(Table 1).

III. OPERATION

Describes the manual operation and automatic operation of a machine,

procedures for inputting and outputting data, and procedures for

editing a program.

IV. MAINTENANCE

Describes procedures for replacing batteries.

APPENDIX

Lists tape codes, valid data ranges, and error codes.

Some functions described in this manual may not be applied to some

products. For detail, refer to the DESCRIPTIONS manual(B-63522EN).

This manual does not describe parameters in detail. For details on

parameters mentioned in this manual, refer to the manual for parameters

(B-63530EN).

This manual describes all optional functions. Look up the options

incorporated into your system in the manual written by the machine tool

builder.

The models covered by this manual, and their abbreviations are:

Model name

Abbreviation

FANUC Series 16i-MB

16i-MB

Series 16i

FANUC Series 160i-MB

160i-MB

Series 160i

FANUC Series 160is-MB

160is-MB

Series 160is

FANUC Series 18i-MB5

18i-MB5

Series 18i

FANUC Series 180i-MB5

180i-MB5

Series 180i

FANUC Series 180is-MB5

180is-MB5

Series 180is

FANUC Series 18i-MB

18i-MB

Series 18i

1. GENERAL

GENERAL

B-63534EN/02

Model name

Abbreviation

FANUC Series 180i-MB

180i-MB

Series 180i

FANUC Series 180is-MB

180is-MB

Series 180is

Remark) The 18i-MB5, 180i-MB5, 180is-MB5, 18i-MB, 180i-MB, and

180is-MB may be collectively referred to as the

18i/180i/

180is-MB.

Special symbols

This manual uses the following symbols:

D IP

^: Indicates a combination of axes such as

X__ Y__ Z (used in PROGRAMMING.).

D ;

^: Indicates the end of a block. It actually corre-

sponds to the ISO code LF or EIA code CR.

Related manuals of Series

The following table lists the manuals related to Series 16i, Series 18i,

16i/18i/21i/160i/180i/210i/16

Series 21i, Series 160i, Series 180i, Series 210i, Series 160is, Series

180is, Series

210is-MODEL B. This manual is indicated by an

0is/180is/210is-MODEL B

asterisk(*).

Related manuals of

Series 16i/18i/21i/160i/180i/ 210i/160is/180is/210is MODEL B (1/2)

Specification

Manual name

number

DESCRIPTIONS

B-63522EN

CONNECTION MANUAL (HARDWARE)

B-63523EN

CONNECTION MANUAL (FUNCTION)

B-63523EN-1

Series 16i/18i/160i/180i/160is/180is-TB

B-63524EN

OPERATOR’S MANUAL

Series 16i/160i/160is-MB, Series 18i/180i/180is-MB5,

B-63534EN

Series 18i/180i/180is-MB OPERATOR’S MANUAL

Series 21i/210i/210is-TB OPERATOR’S MANUAL

B-63604EN

Series 21i/210i/210is-MB OPERATOR’S MANUAL

B-63614EN

MAINTENANCE MANUAL

B-63525EN

Series 16i/18i/160i/180i/160is/180is-MODEL B

B-63530EN

PARAMETER MANUAL

Series 21i/210i/210is-MODEL B PARAMETER MANUAL

B-63610EN

PROGRAMMING MANUAL

Macro Compiler/Macro Executor

B-61803E-1

PROGRAMMING MANUAL

C Language Executor PROGRAMMING MANUAL

B-62443EN-3

FAPT MACRO COMPILER (For Personal Computer)

B-66102E

PROGRAMMING MANUAL

GENERAL

1. GENERAL

B-63534EN/02

Related manuals of

Series 16i/18i/21i/160i/180i/ 210i/160is/180is/210is MODEL B (2/2)

Specification

Manual name

number

CAP (T series)

FANUC Super CAPi T OPERATOR’S MANUAL

B-63284EN

FANUC Symbol CAPi T OPERATOR’S MANUAL

B-63304EN

MANUAL GUIDE For Lathe PROGRAMMING MANUAL

B-63343EN

MANUAL GUIDE For Lathe OPERATOR’S MANUAL

B-63344EN

CAP (M series)

FANUC Super CAPi M OPERATOR’S MANUAL

B-63294EN

MANUAL GUIDE For Milling PROGRAMMING MANUAL

B-63423EN

MANUAL GUIDE For Milling OPERATOR’S MANUAL

B-63424EN

PMC

PMC Ladder Language PROGRAMMING MANUAL

B-61863E

PMC C Language PROGRAMMING MANUAL

B-61863E-1

Network

I/O Link-II OPERATOR’S MANUAL

B-62924EN

Profibus-DP Board OPERATOR’S MANUAL

B-62924EN

Ethernet Board/DATA SERVER Board

B-63354EN

OPERATOR’S MANUAL

FAST Ethernet Board/FAST DATA SERVER OPERA-

B-63644EN

TOR’S MANUAL

DeviceNet Board OPERATOR’S MANUAL

B-63404EN

PC function

Screen Display Function OPERATOR’S MANUAL

B-63164EN

Related manuals of

The following table lists the manuals related to SERVO MOTOR ai series

SERVO MOTOR ai series

Specification

Manual name

number

FANUC AC SERVO MOTOR ai seriesDESCRIPTIONS

B-65262EN

FANUC AC SERVO MOTOR ai series

B-65270EN

PARAMETER MANUAL

FANUC AC SPINDLE MOTOR ai seriesDESCRIPTIONS

B-65272EN

FANUC AC SPINDLE MOTOR ai series

B-65280EN

PARAMETER MANUAL

FANUC SERVO AMPLIFIER ai seriesDESCRIPTIONS

B-65282EN

FANUC SERVO MOTOR ai series

B-65285EN

MAINTENANCE MANUAL

FANUC Series 16i/160i/160is-MB, Series 18i/180i/180is-MB5, Series 18i/180i/180is-MB. Operator's Manual - page 1
