Boeing 737 - 600/700/800/900. Operations Manual (1997 year)

Supplementary Procedures -

Adverse Weather

Boeing 737 Operations Manual

ENG ANTI-ICE switches

COWL VALVE OPEN lights - illuminated dim

COWL ANTI-ICE lights - extinguished

Note:If COWL VALVE OPEN lights remain illuminated bright

with engines at IDLE, position APU BLEED air switch to

OFF and increase thrust slightly (up to a maximum of

30% N1).

CAUTION: Avoid prolonged operation in moderate to severe icing

conditions.

Severe icing can usually be avoided by a change in altitude and/or

airspeed. If flight in moderate to severe icing conditions cannot be

avoided accomplish the following, on both engines, one engine at a

time at approximately 15 minute intervals:

Thrust

Increase

Increase thrust to a minimum of 80% N1 to ensure the fan blades and

spinner are clear of ice.

Engine vibration may occur due to fan blade/spinner icing. If engine

vibration continues after increasing thrust, accomplish the

following on both engines, one engine at a time:

ENGINE START switch

FLT

Thrust

Adjust

Adjust thrust to 45% N1. After approximately five seconds,

increase thrust lever slowly to a minimum of 80% N1.

Note:Engine vibration may reduce to a low level before 80%

N1 is reached, however, thrust increase must continue to

a minimum of 80% N1 to remove ice from the fan blades.

Note:Engine vibration may indicate full scale prior to shedding

ice; however, this has no adverse effect on the engine.

If vibration does not decrease, accomplish the procedure for HIGH

ENGINE VIBRATION “If not in icing conditions.”

When engine anti-ice is no longer required:

ENG ANTI-ICE switches

OFF

COWL VALVE OPEN lights - extinguished

SP.16.8

Supplementary Procedures -

Adverse Weather

Boeing 737 Operations Manual

[Without automatic ignition]

ENGINE START switches

OFF

[Automatic ignition]

ENGINE START switches

AUTO

Wing Anti-Ice Operation - Inflight

The wing anti-ice system may be used as a de-icer or anti-icer in flight only. The

primary method is to use it as a de-icer by allowing ice to accumulate before

turning wing anti-ice on. This procedure provides the cleanest airfoil surface, the

least possible runback ice formation, and the least thrust and fuel penalty.

The secondary method is to use wing anti--ice prior to ice accumulation. Operate

the wing anti-ice system as an anti-icer only during extended operations in

moderate or severe icing conditions, such as holding.

Ice accumulation on the flight deck window frames, windshield center post or on

the windshield wiper arm may be used as an indication of structural icing

conditions and the need to turn on wing anti-ice.

Normally it is not necessary to shed ice periodically unless extended flight through

icing conditions is necessary (holding).

CAUTION: Use of wing anti-ice above approximately FL350 may

cause bleed trip off and possible loss of cabin

pressure.

When wing anti-ice is required:

WING ANTI-ICE switch

R and L VALVE OPEN lights - illuminated dim

When wing anti-ice is no longer required:

WING ANTI-ICE switch

OFF

Note: Prolonged operation in icing conditions with the leading edge

and trailing edge flaps extended is not recommended. Holding

in icing conditions with flaps extended is prohibited.

Approach and Landing

Use normal procedures and reference speeds unless a flaps 15 landing

is planned.

If a flaps 15 landing will be made:

Set VREF 15

SP.16.9

Supplementary Procedures -

Adverse Weather

Boeing 737 Operations Manual

If any of the following conditions apply, set VREF ICE = VREF

15 + 10:

• engine anti-ice will be used during landing

• wing anti-ice has been used any time during the flight

• icing conditions were encountered during the flight and the

landing temperature is below 10° C.

Taxi-In and Park

If prolonged operation in icing conditions with the leading and trailing

edge flaps extended was required:

Flaps

Retraction to less than flaps 15 is not recommended until ice has been

removed or a ground inspection has been made.

After landing in icing conditions:

Stabilizer trim

Set 0 to 2 units

Prevents melting snow and ice from running into balance bay areas and

prevents the stabilizer limit switch from freezing. With flaps retracted,

this requires approximately eight hand wheel turns of manual trim.

WARNING: To avoid personal injury, ensure that the stabilizer

trim wheel handle is stowed prior to using electric

trim.

Engine anti-ice

As required

If icing conditions exist, engine anti-ice must be ON.

Secure (Airplane Attended)

If warm air circulation through cargo and E/E compartments is desired:

APU

APU GEN switches

PACK switches

AUTO

ISOLATION VALVE switch

OPEN

Pressurization mode selector

MAN

SP.16.10

Supplementary Procedures -

Adverse Weather

Boeing 737 Operations Manual

Outflow valve switch

OPEN

Prevents aircraft pressurization.

Note: The airplane must be parked into the wind when the outflow

valve is full open.

APU BLEED switch

Secure (Airplane Unattended)

The flight crew should ensure that the following actions are accomplished as

required:

Pressurization mode selector

MAN

Outflow valve

Closed

Inhibits intake of snow and ice.

Wheel chocks

Check in place

Parking brakes

OFF

Eliminates the possibility of brakes freezing.

Protective covers and plugs

Installed

Water storage containers

Drained

Toilets

Drained

Battery

Removed

If the battery will be exposed to temperatures below -18° C (0° F), the

battery should be removed and stored in an area warmer than -18° C (0 °

F), but below 40° C (104° F). Subsequent installation of the warm battery

ensures the starting capability of the APU.

Doors and sliding windows

Closed

Hot Weather Operation

During ground operation the following considerations will help keep the airplane

as cool as possible:

• While the airplane is electrically powered, packs should be run or

cooling air supplied to the airplane when the OAT exceeds 40° C

(103° F) to protect the reliability of electrical and electronic

equipment in the airplane.

SP.16.11

Supplementary Procedures -

Adverse Weather

Boeing 737 Operations Manual

• If cooling air is available from an outside source, the supply should

be plugged in immediately after engine shutdown and should not

be removed until just prior to engine start.

• Keep all doors and windows, including cargo doors, closed as

much as possible.

• Electronic components which contribute to a high temperature

level in the flight deck should be turned off while not needed.

• Open all passenger cabin gasper outlets and close all window

shades on the sun-exposed side of the passenger cabin.

Brake temperature levels may be reached which can cause the wheel fuse plugs to

melt and deflate the tires. Consider the following actions:

• Be aware of brake temperature buildup when operating a series of

short flight sectors. The energy absorbed by the brakes from each

landing is accumulative.

• Extending the landing gear early during the approach provides

additional cooling for tires and brakes.

• In-flight cooling time can be determined from the “Brake Cooling

Schedule” in the Performance-Inflight section.

During flight planning consider the following:

• High temperatures inflict performance penalties which must be

taken into account on the ground before takeoff.

• Alternate takeoff procedures (No Engine Bleed Takeoff, Improved

Climb Performance, etc.)

Moderate to Heavy Rain

Flights should be conducted to avoid thunderstorm or hail activity by overflight or

circumnavigation. To the maximum extent possible, moderate to heavy rain

should also be avoided.

If heavy rain is encountered:

ENGINE START switches

CONT

Thrust Levers

Adjust Slowly

If thrust changes are necessary, move the thrust levers slowly. Avoid

changing thrust lever direction until engines have stabilized at a

selected setting.

SP.16.12

Supplementary Procedures -

Adverse Weather

Boeing 737 Operations Manual

Turbulence

During flight in light to moderate turbulence, the autopilot and/or autothrottle may

remain engaged unless performance is objectionable. Increased thrust lever

activity can be expected when encountering wind, temperature changes and large

pressure changes. Short-time airspeed excursions of 10 to 15 knots can be

expected.

Passenger signs

Advise passengers to fasten seat belts prior to entering areas of reported or

anticipated turbulence. Instruct flight attendants to check that all

passengers' seat belts are fastened.

Severe Turbulence

Autothrottle

DISENGAGE

AUTOPILOT

CWS

A/P status annunciators display CWS for pitch and roll.

Note: If sustained trimming occurs, disengage the autopilot.

ENGINE START switches

FLT

Thrust

Set

Set thrust as required for the phase of flight. Change thrust setting only if

required to modify an unacceptable speed trend.

SP.16.13

Supplementary Procedures -

Adverse Weather

Boeing 737 Operations Manual

PHASE OF FLIGHT

AIRSPEED

CLIMB

280 knots or .76 Mach

CRUISE

Use FMC recommended thrust settings. If the

FMC is inoperative, refer to the Unreliable

Airspeed page in the Performance-Inflight

section for approximate N1 settings that

maintain near optimum penetration airspeed.

DESCENT

.76 Mach/280/250 knots. If severe turbulence is

encountered at altitudes below 15,000 feet and

the airplane gross weight is less than the

maximum landing weight, the airplane may be

slowed to 250 knots in the clean configuration.

Note: If an approach must be made into an area of severe turbulence,

delay flap extension as long as possible. The airplane can

withstand higher gust loads in the clean configuration.

SP.16.14

Supplementary Procedures -

Adverse Weather

Boeing 737 Operations Manual

Windshear

Windshear is a change of wind speed and/or direction over a short distance along

the flight path. Severe windshear is that which produces airspeed changes greater

than 15 knots or vertical speed changes greater than 500 feet per minute.

Avoidance

The flight crew should search for any clues to the presence of windshear along the

intended flight path. Stay clear of thunderstorm cells and heavy precipitation and

areas of known windshear. If severe windshear is indicated, delay takeoff or do not

continue an approach.

The presence of windshear may be indicated by:

• Thunderstorm activity

• Virga (rain that evaporates before reaching the ground)

• PIREPS

• Low level windshear alerting system (LLWAS) warnings

Precaution

If windshear is suspected, be especially alert to any of the danger signals and be

prepared for the possibility of an inadvertent encounter. The following

precautionary actions are recommended if windshear is suspected:

Takeoff

•

Use maximum takeoff thrust instead of reduced thrust.

•

Use the longest suitable runway.

•

Be alert for any airspeed fluctuations during takeoff and initial

climb. Such fluctuations may be the first indication of windshear.

•

Know the all-engine initial climb pitch attitude. Rotate at the

normal rate to this attitude for all non-engine failure takeoffs.

Minimize reductions from the initial climb pitch attitude until

terrain and obstruction clearance is assured, unless stick shaker

activates.

•

Crew coordination and awareness are very important. Develop an

awareness of normal values of airspeed, attitude, vertical speed,

and airspeed build-up. Closely monitor vertical flight path

instruments such as vertical speed and altimeters. The pilot not

flying should be especially aware of vertical flight path

instruments and call out any deviations from normal.

•

Should airspeed fall below the trim airspeed, unusual control

column forces may be required to maintain the desired pitch

attitude. Stick shaker must be respected at all times.

SP.16.15

Supplementary Procedures -

Adverse Weather

Boeing 737 Operations Manual

• If windshear should be encountered near VR, and airspeed

suddenly decreases, there may not be sufficient runway left to

accelerate back to the normal VR. If there is insufficient runway

left to stop, initiate a normal rotation at least 2000 feet before the

end of the runway even if airspeed is low. Higher than normal

attitudes may be required to lift-off in the remaining runway.

Approach and Landing

• Select the minimum landing flap position consistent with field

length.

• Add an appropriate airspeed correction (correction applied in the

same manner as gust), the maximum command speed should not

exceed the lower of Vref + 20 knots or landing flap placard speed

minus 5 knots.

• Avoid large thrust reductions or trim changes in response to sudden

airspeed increases as these may be followed by airspeed decreases.

• Crosscheck flight director commands using vertical flight path

instruments.

• Crew coordination and awareness are very important, particularly

at night or in marginal weather conditions. Closely monitor the

vertical flight path instruments such as vertical speed, altimeters,

and glideslope displacement. The pilot not flying should call out

any deviations from normal. Use of the autopilot and autothrottle

for the approach may provide more monitoring and recognition

time.

Recovery

Accomplish the Windshear Escape Maneuver found in Non-Normal Maneuvers

section of this manual.

SP.16.16

Boeing 737 Operations Manual

Performance Dispatch -

Chapter PD

Table of Contents

Section 0

737-600 CFM56-7B22 KG FAA JAR CATD

Takeoff

PD.10.1

Takeoff Field Corrections - Dry Runway

PD.10.1

Takeoff Field & Climb Limit Weights - Dry Runway

PD.10.2

Takeoff Field Corrections - Wet Runway

PD.10.4

Takeoff Field & Climb Limit Weights - Wet Runway

PD.10.5

Takeoff Obstacle Limit Weight

PD.10.7

Enroute

PD.11.1

Long Range Cruise Maximum Operating Altitude

PD.11.1

Long Range Cruise Trip Fuel and Time

PD.11.2

Long Range Cruise Step Climb

PD.11.4

Short Trip Fuel and Time

PD.11.5

Holding Planning

PD.11.5

Crew Oxygen Requirements

PD.11.6

Net Level Off Weight

PD.11.7

Long Range Cruise Critical Fuel Reserves

PD.11.8

Landing

PD.12.1

Landing Field Limit Weight

PD.12.1

Landing Climb Limit Weight

PD.12.2

Go-Around Climb Gradient

PD.12.3

Quick Turnaround Limit Weight

PD.12.4

Text

PD.13.1

Introduction

PD.13.1

Takeoff

PD.13.1

Enroute

PD.13.2

Landing

PD.13.4

PD.TOC.0.1

Performance Dispatch -

Table of Contents

Boeing 737 Operations Manual

737-700 CFM56-7B24 LB FAA CATB

Takeoff

PD.20.1

Takeoff Field Corrections - Dry Runway

PD.20.1

Takeoff Field & Climb Limit Weights - Dry Runway

PD.20.2

Takeoff Field Corrections - Wet Runway

PD.20.4

Takeoff Field & Climb Limit Weights - Wet Runway

PD.20.5

Takeoff Obstacle Limit Weight

PD.20.7

Enroute

PD.21.1

Long Range Cruise Maximum Operating Altitude

PD.21.1

Long Range Cruise Trip Fuel and Time

PD.21.2

Long Range Cruise Step Climb

PD.21.4

Short Trip Fuel and Time

PD.21.5

Holding Planning

PD.21.5

Crew Oxygen Requirements

PD.21.6

Net Level Off Weight

PD.21.7

Long Range Cruise Critical Fuel Reserves

PD.21.8

Landing

PD.22.1

Landing Field Limit Weight

PD.22.1

Landing Climb Limit Weight

PD.22.2

Quick Turnaround Limit Weight

PD.22.3

Text

PD.23.1

Introduction

PD.23.1

Takeoff

PD.23.1

Enroute

PD.23.2

Landing

PD.23.4

737-800 CFM56-7B26 KG FAA CATC

Takeoff

PD.30.1

Takeoff Field Corrections - Dry Runway

PD.30.1

Takeoff Field & Climb Limit Weights - Dry Runway

PD.30.2

PD.TOC.0.2

Performance Dispatch -

Table of Contents

Boeing 737 Operations Manual

Takeoff Field Corrections - Wet Runway

PD.30.4

Takeoff Field & Climb Limit Weights - Wet Runway

PD.30.5

Takeoff Obstacle Limit Weight

PD.30.7

Enroute

PD.31.1

Long Range Cruise Maximum Operating Altitude

PD.31.1

Long Range Cruise Trip Fuel and Time

PD.31.2

Long Range Cruise Step Climb

PD.31.4

Short Trip Fuel and Time

PD.31.5

Holding Planning

PD.31.5

Crew Oxygen Requirements

PD.31.6

Net Level Off Weight

PD.31.7

Long Range Cruise Critical Fuel Reserves

PD.31.8

Landing

PD.32.1

Landing Field Limit Weight

PD.32.1

Landing Climb Limit Weight

PD.32.2

Quick Turnaround Limit Weight

PD.32.3

Text

PD.33.1

Introduction

PD.33.1

Takeoff

PD.33.1

Enroute

PD.33.2

Landing

PD.33.4

737-900 CFM56-7B26 LB FAA CATG

Takeoff

PD.40.1

Takeoff Field Corrections - Dry Runway

PD.40.1

Takeoff Field & Climb Limit Weights - Dry Runway

PD.40.2

Takeoff Field Corrections - Wet Runway

PD.40.5

Takeoff Field & Climb Limit Weights - Wet Runway

PD.40.6

Takeoff Obstacle Limit Weight

PD.40.9

Tire Speed Limit Weight

PD.40.11

Brake Energy Limits VMBE

PD.40.12

PD.TOC.0.3

737-600/CFM56-7B22

FAA/JAROPS

Category D Brakes

Boeing 737 Operations Manual

Performance Dispatch

Chapter PD

Takeoff

Section 10

Takeoff

Takeoff Field Corrections -ff

Dry Runway

Slope Corrections

FIELD LENGTH

SLOPE CORRECTED FIELD LENGTH (M)

AVAILABLE

RUNWAY SLOPE (%)

(M)

-2.0

-1.5

-1.0

-0.5

0.0

0.5

1.0

1.5

2.0

1200

1270

1250

1230

1220

1200

1170

1150

1120

1100

1400

1490

1470

1440

1420

1400

1360

1320

1280

1240

1600

1710

1680

1660

1630

1600

1550

1490

1440

1390

1800

1940

1900

1870

1830

1800

1730

1670

1600

1530

2000

2160

2120

2080

2040

2000

1920

1840

1760

1680

2200

2380

2340

2290

2250

2200

2110

2010

1920

1820

2400

2610

2560

2500

2450

2400

2290

2180

2080

1970

2600

2830

2770

2720

2660

2600

2480

2360

2240

2120

2800

3050

2990

2930

2860

2800

2670

2530

2400

2260

3000

3280

3210

3140

3070

3000

2850

2700

2550

2410

3200

3500

3430

3350

3280

3200

3040

2880

2710

2550

3400

3720

3640

3560

3480

3400

3220

3050

2870

2700

3600

3950

3860

3770

3690

3600

3410

3220

3030

2840

3800

4170

4080

3990

3890

3800

3600

3390

3190

2990

4000

4390

4300

4200

4100

4000

3780

3570

3350

3130

4200

4620

4510

4410

4300

4200

3970

3740

3510

3280

4400

4840

4730

4620

4510

4400

4160

3910

3670

3420

4600

5070

4950

4830

4720

4600

4340

4080

3830

3570

4800

5290

5170

5040

4920

4800

4530

4260

3990

3710

5000

5510

5380

5260

5130

5000

4710

4430

4140

3860

Wind Corrections

SLOPE CORR'D

SLOPE & WIND CORRECTED FIELD LENGTH (M)

FIELD LENGTH

WIND COMPONENT (KTS)

(M)

-15

-10

-5

1200

850

970

1080

1200

1270

1350

1420

1500

1400

1030

1150

1280

1400

1480

1560

1640

1720

1600

1210

1340

1470

1600

1680

1760

1850

1940

1800

1380

1520

1660

1800

1880

1970

2060

2160

2000

1560

1710

1850

2000

2090

2180

2280

2380

2200

1740

1890

2050

2200

2290

2380

2490

2610

2400

1910

2080

2240

2400

2490

2590

2700

2830

2600

2090

2260

2430

2600

2690

2800

2920

3050

2800

2270

2450

2620

2800

2900

3010

3130

3270

3000

2450

2630

2820

3000

3100

3210

3350

3490

3200

2620

2820

3010

3200

3300

3420

3560

3720

3400

2800

3000

3200

3400

3500

3630

3770

3940

3600

2980

3180

3390

3600

3710

3840

3990

4160

3800

3150

3370

3580

3800

3910

4040

4200

4380

4000

3330

3550

3780

4000

4110

4250

4410

4600

4200

3510

3740

3970

4200

4320

4460

4630

4820

4400

3690

3920

4160

4400

4520

4670

4840

5050

4600

3860

4110

4350

4600

4720

4870

5060

5270

4800

4040

4290

4550

4800

4920

5080

5270

5490

5000

4220

4480

4740

5000

5130

5290

5480

5710

PD.10.1

Performance Dispatch

737-600/CFM56-7B22

Takeoff

FAA/JAROPS

Category D Brakes

Boeing 737 Operations Manual

Takeoff

Takeoff Field & Climb Limit Weights - Dry Runway

Flaps 5

Sea Level Pressure Altitude

FIELD LIMIT WEIGHT (1000 KG)

CORR'D FIELD

OAT

LENGTH (M)

°C

-40

°F

-40

108

115

122

1220

58.1

53.4

53.0

52.7

52.5

52.3

52.2

52.0

47.9

46.7

45.4

1400

62.3

57.2

56.8

56.5

56.3

56.1

55.9

55.7

51.4

50.0

48.6

1600

66.5

61.1

60.7

60.3

60.1

59.9

59.7

59.5

54.8

53.4

51.9

1800

70.6

64.8

64.4

64.0

63.7

63.5

63.3

63.1

58.1

56.6

55.0

2000

72.5

68.7

68.2

67.8

67.6

67.4

67.1

66.9

61.6

60.0

58.4

2200

72.5

71.7

71.2

70.8

70.5

70.3

70.1

69.8

64.3

62.6

60.8

2400

72.5

66.7

64.9

63.0

2600

72.5

69.3

67.4

65.4

2800

72.5

71.6

69.7

67.6

3000

72.5

71.6

69.5

3200

72.5

71.4

3400

72.5

3600

72.5

3800

72.5

4000

72.5

4200

72.5

4400

72.5

4600

72.5

CLIMB LIMIT

68.8

68.2

68.1

68.0

67.9

67.8

60.4

58.1

55.8

WT (1000 KG)

1000 FT Pressure Altitude

FIELD LIMIT WEIGHT (1000 KG)

CORR'D FIELD

OAT

LENGTH (M)

°C

-40

°F

-40

108

115

122

1220

56.8

52.0

51.7

51.3

51.2

51.0

50.7

50.0

46.3

45.1

43.8

1400

60.9

55.8

55.4

55.0

54.9

54.6

54.3

53.6

49.7

48.4

47.0

1600

65.0

59.6

59.2

58.8

58.6

58.3

58.0

57.2

53.0

51.6

50.2

1800

69.0

63.2

62.8

62.3

62.1

61.9

61.5

60.7

56.2

54.7

53.2

2000

72.5

67.0

66.5

66.1

65.9

65.6

65.2

64.4

59.6

58.0

56.4

2200

72.5

69.9

69.4

69.0

68.7

68.4

68.0

67.2

62.1

60.4

58.7

2400

72.5

72.1

71.6

71.4

71.1

70.7

69.7

64.4

62.7

60.9

2600

72.5

66.9

65.1

63.2

2800

72.5

69.1

67.2

65.2

3000

72.5

71.1

69.1

67.1

3200

72.5

71.0

68.9

3400

72.5

70.6

3600

72.5

72.3

3800

72.5

4000

72.5

4200

72.5

4400

72.5

4600

72.5

CLIMB LIMIT

67.7

67.2

67.1

67.0

66.9

66.8

65.6

58.5

56.2

54.0

WT (1000 KG)

PD.10.2

737-600/CFM56-7B22

Performance Dispatch

FAA/JAROPS

Takeoff

Category D Brakes

Boeing 737 Operations Manual

Takeoff

Takeoff Field & Climb Limit Weights - Dry Runway

Flaps 5

2000 FT Pressure Altitude

FIELD LIMIT WEIGHT (1000 KG)

CORR'D FIELD

OAT

LENGTH (M)

°C

-40

°F

-40

108

115

122

1220

55.5

50.5

50.1

49.8

49.6

49.5

48.9

48.3

44.8

43.6

42.3

1400

59.4

54.1

53.8

53.4

53.2

53.0

52.4

51.8

48.0

46.7

45.4

1600

63.5

57.8

57.4

57.0

56.8

56.6

56.0

55.3

51.2

49.8

48.4

1800

67.4

61.3

60.9

60.5

60.3

60.1

59.4

58.7

54.3

52.8

51.3

2000

71.4

65.0

64.5

64.1

63.9

63.7

62.9

62.2

57.6

56.0

54.5

2200

72.5

67.8

67.3

66.9

66.6

66.4

65.6

64.8

60.0

58.3

56.7

2400

72.5

70.4

69.9

69.4

69.2

69.0

68.1

67.3

62.2

60.4

58.7

2600

72.5

72.2

71.9

71.7

70.8

69.9

64.6

62.7

60.9

2800

72.5

72.3

66.7

64.8

62.9

3000

72.5

68.6

66.6

64.6

3200

72.5

70.4

68.4

66.4

3400

72.5

72.2

70.1

68.1

3600

72.5

71.8

69.7

3800

72.5

71.3

4000

72.5

4200

72.5

4400

72.5

4600

72.5

CLIMB LIMIT

66.6

66.0

65.9

65.8

65.7

64.7

63.6

56.5

54.3

52.2

WT (1000 KG)

3000 FT Pressure Altitude

FIELD LIMIT WEIGHT (1000 KG)

CORR'D FIELD

OAT

LENGTH (M)

°C

-40

°F

-40

108

115

122

1220

54.2

49.2

48.9

48.6

48.4

47.8

47.3

46.7

43.2

42.1

40.9

1400

58.1

52.7

52.4

52.1

51.9

51.3

50.7

50.1

46.4

45.1

43.9

1600

62.0

56.3

55.9

55.6

55.4

54.7

54.1

53.4

49.5

48.1

46.8

1800

65.8

59.7

59.3

58.9

58.8

58.1

57.3

56.6

52.4

51.0

49.6

2000

69.7

63.3

62.9

62.5

62.3

61.6

60.8

60.1

55.6

54.1

52.6

2200

72.5

66.0

65.6

65.2

65.0

64.2

63.4

62.6

57.9

56.3

54.8

2400

72.5

68.5

68.1

67.6

67.4

66.6

65.8

64.9

60.0

58.3

56.7

2600

72.5

71.2

70.8

70.3

70.1

69.2

68.3

67.4

62.3

60.5

58.8

2800

72.5

72.4

71.5

70.6

69.7

64.3

62.4

60.7

3000

72.5

71.7

66.1

64.2

62.4

3200

72.5

67.9

65.9

64.0

3400

72.5

69.6

67.6

65.7

3600

72.5

71.3

69.2

67.3

3800

72.5

70.8

68.8

4000

72.5

72.4

70.3

4200

72.5

71.8

4400

72.5

4600

72.5

CLIMB LIMIT

65.6

65.1

65.0

64.9

63.7

62.6

61.4

54.6

52.4

50.4

WT (1000 KG)

PD.10.3

Performance Dispatch

737-600/CFM56-7B22

Takeoff

FAA/JAROPS

Category D Brakes

Boeing 737 Operations Manual

Takeoff

Takeoff Field Corrections - Wet Runway

Slope Corrections

FIELD LENGTH

SLOPE CORRECTED FIELD LENGTH (M)

AVAILABLE

RUNWAY SLOPE (%)

(M)

-2.0

-1.5

-1.0

-0.5

0.0

0.5

1.0

1.5

2.0

1200

1240

1230

1220

1210

1200

1180

1170

1150

1130

1400

1470

1450

1430

1420

1400

1370

1340

1310

1290

1600

1700

1670

1650

1620

1600

1560

1520

1480

1440

1800

1930

1900

1860

1830

1800

1750

1700

1650

1600

2000

2160

2120

2080

2040

2000

1940

1880

1810

1750

2200

2390

2340

2290

2250

2200

2130

2050

1980

1900

2400

2620

2560

2510

2450

2400

2310

2230

2140

2060

2600

2850

2790

2720

2660

2600

2500

2410

2310

2210

2800

3080

3010

2940

2870

2800

2690

2580

2480

2370

3000

3310

3230

3160

3080

3000

2880

2760

2640

2520

3200

3540

3460

3370

3290

3200

3070

2940

2810

2680

3400

3770

3680

3590

3490

3400

3260

3120

2970

2830

3600

4000

3900

3800

3700

3600

3450

3290

3140

2990

3800

4230

4120

4020

3910

3800

3640

3470

3310

3140

4000

4460

4350

4230

4120

4000

3820

3650

3470

3300

4200

4690

4570

4450

4320

4200

4010

3830

3640

3450

4400

4920

4790

4660

4530

4400

4200

4000

3800

3600

4600

5150

5020

4880

4740

4600

4390

4180

3970

3760

4800

5380

5240

5090

4950

4800

4580

4360

4140

3910

5000

5620

5460

5310

5150

5000

4770

4530

4300

4070

Wind Corrections

SLOPE CORR'D

SLOPE & WIND CORRECTED FIELD LENGTH (M)

FIELD LENGTH

WIND COMPONENT (KTS)

(M)

-15

-10

-5

1200

830

960

1080

1200

1280

1370

1450

1550

1400

1000

1130

1270

1400

1490

1580

1680

1770

1600

1170

1310

1460

1600

1690

1790

1900

2000

1800

1340

1490

1650

1800

1900

2010

2120

2230

2000

1510

1670

1840

2000

2110

2220

2340

2460

2200

1680

1850

2030

2200

2310

2430

2560

2690

2400

1850

2030

2220

2400

2520

2640

2780

2920

2600

2020

2210

2410

2600

2720

2860

3000

3140

2800

2190

2390

2600

2800

2930

3070

3220

3370

3000

2360

2570

2790

3000

3140

3280

3440

3600

3200

2520

2750

2970

3200

3340

3490

3660

3830

3400

2690

2930

3160

3400

3550

3710

3880

4060

3600

2860

3110

3350

3600

3750

3920

4100

4290

3800

3030

3290

3540

3800

3960

4130

4320

4520

4000

3200

3470

3730

4000

4170

4350

4540

4740

4200

3370

3650

3920

4200

4370

4560

4760

4970

4400

3540

3830

4110

4400

4580

4770

4980

5200

4600

3710

4010

4300

4600

4780

4980

5200

5430

4800

3880

4190

4490

4800

4990

5200

5420

5660

5000

4050

4360

4680

5000

5200

5410

5640

5890

PD.10.4

737-600/CFM56-7B22

Performance Dispatch

FAA/JAROPS

Takeoff

Category D Brakes

Boeing 737 Operations Manual

Takeoff

Takeoff Field & Climb Limit Weights - Wet Runway

Flaps 5

Sea Level Pressure Altitude

FIELD LIMIT WEIGHT (1000 KG)

CORR'D FIELD

OAT

LENGTH (M)

°C

-40

°F

-40

108

115

122

1450

63.3

57.7

57.3

56.9

56.7

56.5

56.3

56.1

51.7

50.3

49.0

1600

66.4

60.5

60.1

59.7

59.5

59.3

59.1

58.9

54.1

52.8

51.3

1800

70.4

64.0

63.6

63.2

63.0

62.7

62.5

62.3

57.3

55.9

54.4

2000

72.5

67.8

67.3

66.8

66.6

66.4

66.2

65.9

60.7

59.1

57.5

2200

72.5

70.7

70.2

69.7

69.5

69.3

69.0

68.8

63.2

61.6

60.0

2400

72.5

72.3

72.0

71.8

71.5

65.7

64.0

62.3

2600

72.5

68.3

66.6

64.7

2800

72.5

70.7

68.9

67.0

3000

72.5

71.0

69.1

3200

72.5

71.1

3400

72.5

3600

72.5

3800

72.5

4000

72.5

4200

72.5

4400

72.5

4600

72.5

4800

72.5

CLIMB LIMIT

68.8

68.2

68.1

68.0

67.9

67.8

60.4

58.1

55.8

WT (1000 KG)

1000 FT Pressure Altitude

FIELD LIMIT WEIGHT (1000 KG)

CORR'D FIELD

OAT

LENGTH (M)

°C

-40

°F

-40

108

115

122

1450

61.8

56.2

55.7

55.2

55.0

54.8

54.6

53.9

49.9

48.6

47.4

1600

64.8

58.9

58.3

57.9

57.7

57.5

57.2

56.5

52.3

51.0

49.6

1800

68.6

62.4

61.8

61.3

61.1

60.8

60.6

59.9

55.4

53.9

52.5

2000

72.5

66.0

65.4

64.8

64.6

64.4

64.2

63.3

58.6

57.1

55.6

2200

72.5

68.9

68.2

67.6

67.4

67.2

66.9

66.1

61.1

59.5

57.9

2400

72.5

71.6

70.9

70.3

70.1

69.8

69.6

68.7

63.4

61.8

60.1

2600

72.5

72.3

71.4

66.0

64.2

62.5

2800

72.5

68.3

66.5

64.7

3000

72.5

70.4

68.6

66.7

3200

72.5

70.5

68.6

3400

72.5

70.5

3600

72.5

72.3

3800

72.5

4000

72.5

4200

72.5

4400

72.5

4600

72.5

4800

72.5

CLIMB LIMIT

67.7

67.2

67.1

67.0

66.9

66.8

65.6

58.5

56.2

54.0

WT (1000 KG)

PD.10.5

Performance Dispatch

737-600/CFM56-7B22

Takeoff

FAA/JAROPS

Category D Brakes

Boeing 737 Operations Manual

Takeoff

Takeoff Field & Climb Limit Weights - Wet Runway

Flaps 5

2000 FT Pressure Altitude

FIELD LIMIT WEIGHT (1000 KG)

CORR'D FIELD

OAT

LENGTH (M)

°C

-40

°F

-40

108

115

122

1450

60.2

54.4

54.1

53.7

53.5

53.3

52.7

52.1

48.2

47.0

45.7

1600

63.1

57.1

56.7

56.3

56.1

55.9

55.3

54.6

50.5

49.2

47.9

1800

66.9

60.4

60.0

59.6

59.4

59.2

58.5

57.8

53.4

52.1

50.7

2000

70.8

63.9

63.5

63.1

62.9

62.7

61.9

61.2

56.6

55.1

53.7

2200

72.5

66.7

66.2

65.8

65.6

65.3

64.6

63.8

58.9

57.4

55.9

2400

72.5

69.3

68.8

68.4

68.1

67.9

67.1

66.3

61.2

59.6

58.0

2600

72.5

72.1

71.6

71.1

70.9

70.6

69.8

68.9

63.6

62.0

60.3

2800

72.5

72.2

71.3

65.8

64.1

62.4

3000

72.5

67.9

66.1

64.3

3200

72.5

69.9

68.1

66.2

3400

72.5

71.8

69.9

68.0

3600

72.5

71.7

69.7

3800

72.5

71.4

4000

72.5

4200

72.5

4400

72.5

4600

72.5

4800

72.5

CLIMB LIMIT

66.6

66.0

65.9

65.8

65.7

64.7

63.6

56.5

54.3

52.2

WT (1000 KG)

3000 FT Pressure Altitude

FIELD LIMIT WEIGHT (1000 KG)

CORR'D FIELD

OAT

LENGTH (M)

°C

-40

°F

-40

108

115

122

1450

58.7

53.0

52.7

52.3

52.2

51.5

50.9

50.3

46.5

45.4

44.2

1600

61.5

55.6

55.2

54.8

54.7

54.0

53.3

52.7

48.7

47.5

46.3

1800

65.2

58.8

58.5

58.1

57.9

57.2

56.5

55.8

51.6

50.3

49.0

2000

69.0

62.3

61.9

61.5

61.3

60.5

59.8

59.0

54.6

53.2

51.9

2200

72.0

64.9

64.5

64.1

63.9

63.1

62.3

61.5

56.9

55.4

54.0

2400

72.5

67.5

67.0

66.6

66.4

65.5

64.7

63.9

59.1

57.5

56.0

2600

72.5

70.2

69.7

69.2

69.0

68.1

67.3

66.4

61.4

59.8

58.2

2800

72.5

72.2

71.7

71.4

70.5

69.6

68.8

63.5

61.9

60.3

3000

72.5

71.8

70.9

65.5

63.8

62.1

3200

72.5

67.4

65.6

63.9

3400

72.5

69.2

67.4

65.6

3600

72.5

71.0

69.1

67.3

3800

72.5

70.8

68.9

4000

72.5

72.4

70.5

4200

72.5

72.0

4400

72.5

4600

72.5

4800

72.5

CLIMB LIMIT

65.6

65.1

65.0

64.9

63.7

62.6

61.4

54.6

52.4

50.4

WT (1000 KG)

PD.10.6

737-600/CFM56-7B22

Performance Dispatch

FAA/JAROPS

Takeoff

Category D Brakes

Boeing 737 Operations Manual

Takeoff

Takeoff Obstacle Limit Weight

Flaps 5

Sea Level 30°C & Below, Zero Wind

Based on engine bleed for packs on and anti-ice off

Reference Obstacle Limit Weight (1000 KG)

OBSTACLE

DISTANCE FROM BRAKE RELEASE (100 M)

HEIGHT (M)

67.8

70.8

61.6

65.4

68.0

69.8

71.1

56.6

60.3

63.2

65.5

67.2

68.5

69.6

70.5

71.2

71.8

52.8

56.6

59.6

62.0

63.9

65.5

66.8

67.8

68.7

69.5

70.1

49.7

53.6

56.6

59.1

61.1

62.8

64.3

65.5

66.5

67.4

68.1

100

47.1

50.9

54.0

56.6

58.7

60.5

62.0

63.4

64.5

65.5

66.3

120

44.8

48.6

51.8

54.4

56.6

58.4

60.0

61.4

62.6

63.7

64.6

140

42.8

46.6

49.7

52.4

54.6

56.5

58.2

59.6

60.9

62.0

63.0

160

41.0

44.8

47.9

50.6

52.9

54.8

56.5

58.0

59.3

60.5

61.5

180

39.4

43.1

46.3

48.9

51.2

53.2

55.0

56.5

57.8

59.0

60.1

200

41.6

44.7

47.4

49.7

51.7

53.5

55.1

56.5

57.7

58.8

220

40.2

43.3

46.0

48.3

50.4

52.1

53.7

55.2

56.4

57.6

240

39.0

42.0

44.7

47.0

49.1

50.9

52.5

53.9

55.2

56.4

260

40.8

43.5

45.8

47.8

49.7

51.3

52.8

54.1

55.3

280

39.7

42.3

44.6

46.7

48.5

50.2

51.7

53.0

54.2

300

41.3

43.5

45.6

47.4

49.1

50.6

52.0

53.2

Obstacle height must be calculated from lowest point of the runway to conservatively account for runway

slope. When using line-up allowances the obstacle distance from brake release must be reduced by the ASDA

adjustment.

OAT Adjustments

REFERENCE OBSTACLE LIMIT WEIGHT (1000 KG)

OAT (°C)

30 & BELOW

-0.7

-0.8

-0.9

-1.0

-1.1

-1.2

-1.3

-1.4

-1.6

-1.7

-1.9

-2.0

-2.2

-2.4

-2.5

-2.1

-2.4

-2.6

-2.8

-3.1

-3.3

-3.5

-3.8

-2.8

-3.2

-3.5

-3.8

-4.1

-4.4

-4.7

-5.0

-3.5

-3.9

-4.2

-4.6

-5.0

-5.4

-5.8

-6.2

-4.1

-4.6

-5.0

-5.5

-5.9

-6.4

-6.9

-7.3

-4.8

-5.3

-5.8

-6.3

-6.9

-7.4

-7.9

-8.5

-5.4

-6.0

-6.6

-7.2

-7.8

-8.4

-9.0

-9.6

-6.0

-6.7

-7.4

-8.0

-8.7

-9.4

-10.1

-10.7

-6.7

-7.4

-8.1

-8.9

-9.6

-10.4

-11.1

-11.9

Pressure Altitude Adjustments

OAT ADJUSTED OBSTACLE LIMIT WEIGHT (1000 KG)

ALT (FT)

S.L.& BELOW

1000

-1.5

-1.7

-1.8

-1.9

-2.0

-2.1

-2.3

-2.4

2000

-2.9

-3.2

-3.4

-3.6

-3.9

-4.1

-4.4

-4.6

3000

-4.3

-4.6

-5.0

-5.4

-5.7

-6.1

-6.4

-6.8

PD.10.7

Boeing 737 - 600/700/800/900. Operations Manual (1997 year) - page 15
