Lotus Evora. Manual - part 79





Lotus Service Notes





    Section OK

Notes - The PDI is subject to the following conditions:

Dealer stamp:

a) It is the responsibility of the supplying dealer to ensure that

    the car is delivered to the customer in the best possible co-

    ndition.

b) All costs incurred during the inspection process are the res-

    ponsibility of the dealer.

c) Failure to return a signed copy of this inspection to Lotus

    Cars Ltd. by the dealer, may result in warranty claims on

    the particular car being rejected.

ONCE COMPLETED, SEND ORIGINAL COPY OF PDI FORM, OWNER'S HANDBOOK MAINTENANCE RECORD

PAGES "P.D.I & REGISTRATION OF SALE", AND NEW CAR HANDOVER CHECKLIST (LSL486) TO:

Pre-Delivery Inspection Completed by:
Date:

Undertake complete vehicle valet.

Valet

Brake performance:

Additional Work Completed by:

Road Test Performance Check - Add comments as necessary
Engine performance:

Driveline/suspension noise/vibration:

Clutch operation:
Gearbox operation:
Steering performance:
Check wheel balance:

General Comments

Additional Work Required

NORFOLK,

NR14 8EZ,

ENGLAND

WARRANTY DEPARTMENT,

LOTUS CARS LTD.

POTASH LANE,

HETHEL,





Lotus Service Notes





    Section OK

lsl544

B BLISTERING

N SHADING

C CHIPS

O OVERSPRAY

D DISTORTION

P PRE-RELEASES

F FLAKING

R RUN

G GEL CRAZING

S SCRATCHES

H PIN HOLES

T THIN PAINT

K SINKAGE

U

M MAT CREASES

V VOIDS

DATE OF PDI

VIN

COLOUR

OWNER

PRE-DELIVERY PAINT MARK UP - EVORA

PAINT DEFECT CODE

DIRT UNDER PAINT





Lotus Service Notes





    Section OK

Licence Plate Fitment



Front

The mounting plinth for the front licence plate is screw fixed to the front clamshell, and is slightly curved in

plan.  Typically, the plate is secured using double sided tape in conjunction with two fixing screws with suitable

blind fix nuts (e.g. Rawlnuts).  The plate should be aligned with the bottom edge of the plinth to reduce potential

damage from grounding or kerbs, whilst providing the minimum restriction to radiator airflow.

Rear

The rear licence plate should be mounted on the surface of the rear transom recess using double sided

tape and/or fixing screws at the dealer's/customer's discretion.  Ensure that any holes drilled through the body

are suitably weather sealed.





Lotus Service Notes





    Section PN

AIR CONDITIONING, HEATING & VENTILATION

SECTION PN

                                                       Sub-Section   Page

      General Description                                    PN.1      3

      Heater/A.C. Airflow Overview                              PN.2      5

      Cooling Fans & Re-circulation Pump                          PN.3      9

      Refrigerant Handling                                    PN.4      10

      Refrigerant Pipework Precautions                            PN.5      10

      Refrigerant Oil                                        PN.6      12

      Compressor                                         PN.7      12

      Condenser                                          PN.8      14

      Receiver-Drier                                        PN.9      15

      Heater/Evaporator/Fan (HVAC) Unit                          PN.10     15

      Air Distribution Unit (ADU)                                PN.11     16



      Refrigerant Pipes                                      PN.12     17
