Lotus Service Notes

Section OK

MAINTENANCE & LUBRICATION

SECTION OK

Page

Recommended Lubricants

Maintenance Schedule

Pre-Delivery Inspection

Pre-Delivery Paint Mark Up

Licence Plate Fitment

Lotus Service Notes

Section OK

RECOMMENDED LUBRICANTS

Engine

In order to ensure the longevity and reliability of the vehicle, it is most important that

only the specified

lubricants are used. It is an entirely false economy to try to save money by using lower quality oils, which

may break down before the next change interval and provide inadequate protection before the end of the term.

High oil consumption may also result.

For topping up purposes during the running-in period prior to the First After Sales Service, the recom-

mended lubricant is Havoline Ultra 5W/40 semi-synthetic. If this is unavailable, a top quality semi-synthetic

5W/30 or 5W/40 oil should be used.

At the First After Sales Service and completion of the running-in period, a fully synthetic oil should then

be used throughout the life of the vehicle. A top quality fully synthetic 5W/40, such as 'Havoline Synthetic' is

suitable for all climatic conditions likely to be encountered, and provides ease of cranking, smooth cold running

and fuel economy at low temperatures, in combination with good wear protection at elevated temperatures and

at high engine speeds. Note that no oil additives are approved by Lotus.

Viscosity: ambient above -20°C SAE 5W/40

Quality standard API SL/CF; ACEA A3/B3-04

Capacity: refill inc. filter: 6.1 litre

dry - no heat exchanger 6.8 litre

dry - with heat exchanger 7.1 litre

Difference between high & low dipstick marks 1.0 litre

Oil change interval Refer to Maintenance Schedule

Transmission (gearbox & final drive)

Viscosity SAE 75W/80

Quality standard API GL-4

Approved product Havoline Multigear MTF 75W-80 (semi-synthetic)

Capacity 2.3 litre

Oil change interval Refer to Maintenance Schedule

Brake & Clutch System

Type Non-mineral (non-petroleum) hydraulic fluid

Specification DOT 4

Capacity - inc. brake and clutch systems 580 cc

Fluid change interval 24 months

Power Steering System (PAS)

Fluid type: PAS or Automatic Transmission Fluid (ATF)

Specification: Dexron III

Capacity: 1.5 litres

Fluid change interval: Not routine

Engine Coolant Additive

Approved product Havoline XLC

Type Ethylene glycol antifreeze with OAT corrosion inhibitors

Colour Orange

Quantity reqd. @ 50% concentration 8.5 litres

Coolant change interval 4 years

Lotus Service Notes

Section OK

'Severe Service’ Conditions

Certain operating conditions can cause rapid degradation of the oil quality, either by the accumulation

of dirt particles, or by the absorption of water from condensation. If any of the ‘severe service’ conditions de-

scribed below apply, it is recommended that the oil and filter be changed twice as frequently as is listed in the

Maintenance Schedule.

•

Driving in dusty areas (e.g. on unmetalled roads); Change the oil and filter as soon as possible after driv-

ing in a dust storm.

•

Stop/start driving with frequent short trips where the engine rarely warms up thoroughly (especially in cold

weather/climates); and/or frequent or prolonged idling.

•

Track use, with repeated high rpm, wide throttle openings and high oil temperatures. In these circumstances,

individual judgement must be made regarding appropriate servicing. Note that use of the car off road or in

a competitive manner, including timed runs or laps, will invalidate warranty and require appropriate levels

of expert car preparation and servicing.
