Body and Accessories 3C-33
Removal/Installation of Interior Rear 1. Disconnect the negative cable of the battery. 2. Remove the rear doorsill. (Refer to Removal/ Installation of Doorsills of Four Doors) 3. Remove the door opening weatherstrips. (Refer to the Removal/ Installation of Door 4. Remove the rear wheel cover trim plate. (Refer to Removal/ Installation of Rear Wheel 5. Remove the left and right C-pillar trim plates (Refer to Removal/Installation of C-Pillar
6. Loosen 7 clips (4 lower clips and 3 upper clips) from the position ② of the body.
7. Remove the patch cord behind the high- mounted brake lamp and then the rear parcel Perform the installation in reverse order of the Removal/Installation of Side Trim Plates 1. Remove the trunk mat and the foam toolbox. 2. Remove the rear trim plate of the trunk. (Refer to the Removal/Installation of Rear 3. Remove the snap fasteners. (5 in total in the figure)
Right side
Left side
|
