6-1. Specifications

6

Veh

icle speci

fic

a

tions

Scion_xB_OM_OM12F03U_(U)

*

: Table 1

 Occupant loading and distribution for vehicle normal load

for various designated seating capacities

Tire related term

Meaning

Tread rib

A tread section running circumferentially
around a tire

Tread separation

Pulling away of the tread from the tire carcass

Treadwear indicators
(TWI)

The projections within the principal grooves
designed to give a visual indication of the
degrees of wear of the tread

Wheel-holding fixture

The fixture used to hold the wheel and tire
assembly securely during testing

Designated seating

capacity, Number of

occupants

Vehicle normal load,

Number of occupants

Occupant distribution in
a normally loaded vehi-

cle

2 through 4

2

2 in front

5 through 10

3

2 in front, 1 in second

seat

11 through 15

5

2 in front, 1 in second
seat, 1 in third seat, 1

in fourth seat

16 through 20

7

2 in front, 2 in second
seat, 2 in third seat, 1

in fourth seat

358

Scion_xB_OM_OM12F03U_(U)

6-2. Customization

Customizable features

Item

Function

Default setting

Customized

setting

Wireless
remote con-
trol (

P. 26)

Wireless remote control

On

Off

Unlocking operation

Driver’s door

unlocked in one

step, all doors

unlocked in two

steps

All doors

unlocked in one

step

Automatic door lock
function to be activated
if door is not opened
after being unlocked

On

Off

Time elapsed before
automatic door lock
function is activated if
door is not opened after
being unlocked

60 seconds

30 seconds

120 seconds

Operation signal
(Emergency flashers)

On

Off

Operation signal
(Buzzer)

On

Off

Open door reminder
buzzer (When locking
the vehicle)

On

Off

Panic function

On

Off

Your vehicle includes a variety of electronic features that can be per-

sonalized to your preferences. Programming these preferences

requires specialized equipment and may be performed by your Scion

dealer.

Some function settings are changed simultaneously with other functions
being customized. Contact your Scion dealer.

359

6-2. Customization

6

Veh

icle speci

fic

a

tions

Scion_xB_OM_OM12F03U_(U)

Door lock
(

P. 30)

Unlocking using a key

Driver’s door

unlocked in one

step, all doors

unlocked in two

steps

All doors

unlocked in one

step

Speed-detecting auto-
matic door lock function

Off

On

Opening driver’s door
unlocks all doors

Off

On

Shifting gears to P
unlocks all doors. (vehi-
cles with an automatic
transmission)

On

Off

Shifting gears to posi-
tion other than P locks
all doors. (vehicles with
an automatic transmis-
sion)

On

Off

Item

Function

Default setting

Customized

setting

360

6-2. Customization

Scion_xB_OM_OM12F03U_(U)

Illumination
(

P. 182)

Time elapsed before
lights turn off

15 seconds

7.5 seconds

30 seconds

Operation when the
doors are unlocked

On

Off

Operation after the
engine switch is turned
to the “LOCK” position

On

Off

Item

Function

Default setting

Customized

setting

361

6

Veh

icle speci

fic

a

tions

Scion_xB_OM_OM12F03U_(U)

6-3. Initialization

Items to initialize

Item

When to initialize

Reference

Maintenance required
reminder light
(U.S.A. only)

After the maintenance is performed.

P. 211

Tire pressure warning
system

When changing the tire size.

P. 239

The following items must be initialized for normal system operation

in cases such as after maintenance is performed on the vehicle.

For owners

7

363

Scion_xB_OM_OM12F03U_(U)

Reporting safety defects

for U.S. owners ..............  364

Seat belt instructions

for Canadian owners
(in French) .....................  365

SRS airbag instructions

for Canadian owners
(in French) .....................  367

364

Scion_xB_OM_OM12F03U_(U)

Reporting safety defects for U.S. owners

If you believe that your vehicle has a defect which could cause a
crash or could cause injury or death, you should immediately
inform the National Highway Traffic Safety Administration (NHTSA)
in addition to notifying Scion, a marque of Toyota Motor Sales,
U.S.A., Inc. (Toll-free: 1-866-707-2466).

If NHTSA receives similar complaints, it may open an investigation,
and if it finds that a safety defect exists in a group of vehicles, it
may order a recall and remedy campaign. However, NHTSA can-
not become involved in individual problems between you, your
dealer, or Scion, a marque of Toyota Motor Sales, U.S.A., Inc.

To contact NHTSA, you may call the Vehicle Safety Hotline
toll-free at 1-888-327-4236 (TTY: 1-800-424-9153); go to
http://www.safercar.gov; or write to: Administrator, NHTSA,
1200 New Jersey Ave, S.E., Washington, DC 20590. You can
also obtain other information about motor vehicle safety from
http://www.safercar.gov.

365

7

F

o

r o
w

ners

Scion_xB_OM_OM12F03U_(U)

Seat belt instructions for Canadian owners (in French)

The following is a French explanation of seat belt instructions

extracted from the seat belt section in this manual.

See the seat belt section for more detailed seat belt instructions in
English.

367

7

F

o

r o
w

ners

Scion_xB_OM_OM12F03U_(U)

SRS airbag instructions for Canadian owners (in French)

368

Scion_xB_OM_OM12F03U_(U)

Composants du système de coussins gonflables SRS

369

7

F

o

r o
w

ners

Scion_xB_OM_OM12F03U_(U)

Votre véhicule est doté de COUSSINS GONFLABLES ÉVOLUÉS
dont la conception s’appuie sur les normes de sécurité des véhicules
à moteur américains (FMVSS208). Le module de capteur de coussin
gonflable (ECU) contrôle le déploiement des coussins gonflables en
fonction des informations obtenues des capteurs et d’autres élé-
ments affichés dans le diagramme des composants du système ci-
dessus. Ces informations comprennent des données relatives à la
gravité de l’accident et aux occupants. Au moment du déploiement
des coussins gonflables, une réaction chimique se produit dans les
gonfleurs de coussin gonflable et les coussins gonflables se remplis-
sent rapidement d’un gaz non toxique pour aider à limiter le mouve-
ment des occupants.

Capteurs de coussin gon-
flable avant

Système de classification
de l’occupant du siège du
passager avant (ECU et
capteurs)

Capteur de position du
siège de passager avant

Coussin gonflable du pas-
sager avant

Capteurs d’impact latéral
(portière avant)

Coussins gonflables en
rideau

Voyants “AIR BAG ON” et
“AIR BAG OFF”

Capteurs de coussin gon-
flable latéral et de coussin
gonflable en rideau

Coussins gonflables laté-
raux

Limiteurs de force et dispo-
sitifs de tension des ceintu-
res de sécurité

Lampe témoin SRS

Coussin gonflable du con-
ducteur

Capteurs de coussin gon-
flable en rideau

Contacteur de boucle de
ceinture de sécurité du pas-
sager avant

Capteur de position du
siège du conducteur

Contacteur de boucle de
ceinture de sécurité du con-
ducteur

Module de capteur de cous-
sin gonflable

371

7

F

o

r o
w

ners

Scion_xB_OM_OM12F03U_(U)

373

7

F

o

r o
w

ners

Scion_xB_OM_OM12F03U_(U)

375

7

F

o

r o
w

ners

Scion_xB_OM_OM12F03U_(U)

Index

377

Scion_xB_OM_OM12F03U_(U)

Abbreviation list .....................  378

Alphabetical index..................  379

What to do if... ........................  386

378

Scion_xB_OM_OM12F03U_(U)

Abbreviation list

Abbreviation/Acronym list

ABBREVIATIONS

MEANING

A/C

Air Conditioning

ABS

Anti-lock Brake System

ACC

Accessory

ALR

Automatic Locking Retractor

CRS

Child Restraint System

DISP

Display

ECU

Electronic Control Unit

EDR

Event Data Recorder

ELR

Emergency Locking Retractor

EPS

Electric Power Steering

GAWR

Gross Axle Weight Rating

GVWR

Gross Vehicle Weight Rating

I/M

Emission inspection and maintenance

LATCH

Lower Anchors and Tethers for Children

LED

Light Emitting Diode

M + S

Mud and Snow

MMT

Methylcyclopentadienyl Manganese Tricarbonyl

MTBE

Methyl Tertiary Butyl Ether

OBD

On Board Diagnostics

SRS

Supplemental Restraint System

TIN

Tire Identification Number

TPMS

Tire Pressure Warning System

TRAC

Traction Control

VIN

Vehicle Identification Number

VSC

Vehicle Stability Control
