4-3. Bluetooth

®

● Voice input command list for voice recognition learning

When reading out, the following points must be observed:

• Read out the numbers one at a time correctly and naturally.

(For example, “1234” must be read out “one, two, three, four”
not “twelve, thirty four”.)

• Do not read out parentheses. “(” and hyphens “-” are used for

separating numbers in a phone number.

Ex.
“(888) 555-1212” must be spoken “Eight, eight, eight, five, five,
five, one, two, one, two.”

Phrase

Command

1

0123456789

2

(888) 555-1212

3

Call

4

Dial

5

Setup

6

Cancel

7

Continue

8

Help

iA_OM_OM99M17z_(U)

351

4-3. Bluetooth

®

4

In

te

rior Fea

tu

res

● Voice recognition learning on/off

Press the pick-up button or talk button with a short press.

Say: [Beep] “Voice training”

Prompt: “Enrollment is enabled/ disabled. Would you like to
disable/ enable or retrain?”

Say: [Beep] “Disable” or “Enable”

When “Disable” is spoken, the voice recognition learning is
turned off. When “Enable” is spoken, the voice recognition
learning is turned on.

Prompt: “Speaker Enrollment is disabled/enabled.”

■

Voice Recognition Learning Function (Speaker Enrollment) (Type A)

●

If an error occurred in the voice recognition learning, re-learning can be
done by pressing the talk button with a short press.

●

The applicable phrase appears in the audio display.

●

After user voice registration is completed, voice guidance “Speaker enroll-
ment is complete” is announced.

■

Device pairing

To use Bluetooth

®

 audio and Hands-Free, the device equipped with

Bluetooth

®

 has to be paired to the unit using the following proce-

dure. A maximum of seven devices including Bluetooth

®

 audio

devices and hands-free mobile phones can be paired.
● Pairing Procedure

Select the

 icon on the home screen and display the

Settings screen.

Select the

 tab.

Select .

Turn the Bluetooth

®

 setting on.

Select

 to display the message and switch to the

device operation.

Using your device, perform a search for the Bluetooth

®

 device

(Peripheral device).

Select “Scion” from the device list searched by the device.

Bluetooth

®

 Preparation (Type B)

1

2

3

4

5

6

1

2

3

4

5

6

7

352

iA_OM_OM99M17z_(U)

4-3. Bluetooth

®

(Device with Bluetooth

®

 version 2.0)

Input the displayed 4-digit pairing code into the device.
(Device with Bluetooth

®

 version 2.1 or higher)

Make sure the displayed 6-digit code on the audio is also dis-
played on the device, and touch the

.

Connection permission and phonebook access permission for
your mobile device may be required depending on the mobile
device.

If pairing is successful, the functions of the device connected
to Bluetooth

®

 are displayed.

(Devices compatible with Toyota/Scion Email/SMS function)
SMS (Short Message Service) messages, and E-mail for the
device are downloaded automatically. A download permission
operation for your device may be required depending on the
device.

After a device is registered, the system automatically identifies the
device. By activating Bluetooth

®

 Hands-Free again, or by activating

Bluetooth

®

 Hands-Free first after switching the ignition from OFF to

ACC, the device connection condition is indicated in the center dis-
play.
● IMPORTANT note about pairing and automatic reconnection:

• If pairing is redone on the same mobile phone device, first

clear “Scion” displayed on the Bluetooth

®

 setting screen of the

mobile device.

• When the OS of the device is updated, the pairing information

may be deleted. If this happens, reprogram the pairing infor-
mation to the Bluetooth

®

 unit.

• Before you pair your device, make sure that Bluetooth

®

 is

“ON”, both on your phone and on the vehicle.

8

9

10

iA_OM_OM99M17z_(U)

353

4-3. Bluetooth

®

4

In

te

rior Fea

tu

res

■

Device selection

If several devices have been paired, the Bluetooth

®

 unit links the

device last paired. If you would like to link a different paired device,
it is necessary to change the link. The order of device priority after
the link has been changed is maintained even when the ignition is
switched off.
● Connecting other devices

Select the

 icon on the home screen and display the

Settings screen.

Select the

 tab.

Select .

Turn the Bluetooth

®

 setting on.

Select the name of the device you would like to connect.

 selection

Connects both devices as hands-free and Bluetooth

®

 audio.

 selection

Connects as a hands-free device.

 selection

Connects as Bluetooth

®

 audio.

● Disconnecting a device

Select the

 icon on the home screen and display the

Settings screen.

Select the

 tab.

Select .

Turn the Bluetooth

®

 setting on.

Select the device name which is currently connected.

Select .

1

2

3

4

5

6

1

2

3

4

5

6

354

iA_OM_OM99M17z_(U)

4-3. Bluetooth

®

■

Deleting a device
● Selecting and deleting devices

Select the

 icon on the home screen and display the

Settings screen.

Select the

 tab.

Select .

Turn the Bluetooth

®

 setting on.

Select the device name which you would like to delete.

Select .

Select .

● Deleting all devices

Select the

 icon on the home screen and display the

Settings screen.

Select the

 tab.

Select .

Select .

Select .

Select .

■

Changing PIN code

PIN code (4 digits) can be changed.

Select the

 icon on the home screen and display the Set-

tings screen.

Select the

 tab.

Select .

Select .

Select .

Input the new PIN code to be set.

Select .

1

2

3

4

5

6

7

1

2

3

4

5

6

1

2

3

4

5

6

7

iA_OM_OM99M17z_(U)

355

4-3. Bluetooth

®

4

In

te

rior Fea

tu

res

■

Bluetooth

®

 Preparation (Type B)

The Bluetooth

®

 system may not operate for 1 or 2 minutes after the ignition is

switched to ACC or ON. However, this does not indicate a problem. If the
Bluetooth

®

 system does not connect automatically after 1 or 2 minutes have

elapsed, make sure that the Bluetooth

®

 setting on the device is normal and

attempt to reconnect the Bluetooth

®

 device from the vehicle side.

When Call history and messages are downloaded automatically, each auto-
matic download setting must be on.

Refer to Communication Settings on P. 382.

●

The following functions can be used for the Hands-free or audio.

• Hands-free: Phone calls and E-mail/ SMS
• Audio: Bluetooth

®

 audio, Pandora

®

, Aha™, Stitcher™ radio

The Bluetooth

®

 Hands-Free System applies to the following lan-

guages:
● English
● Spanish
● French
Refer to Settings on P. 295.

Available Language (Type B)

356

iA_OM_OM99M17z_(U)

4-3. Bluetooth

®

In this section, the basic operation of the voice recognition is
explained.

■

Activating Voice Recognition

Press the talk button.

■

Ending Voice Recognition

Use one of the following methods:
● Press the hang-up button.
● Say, “Cancel”.
● Operate the commander switch or the center display (only when

vehicle is stopped).

■

Skipping Voice Guidance (for faster operation)

Press and release the talk button.

■

Troubleshooting for Voice Recognition

If you do not understand an operation method while in the voice
recognition mode, say “Tutorial” or “Help”.

■

Commands useable anytime during voice recognition

“Go Back” and “Cancel” are commands which can be used at any-
time during voice recognition.
● Returning to previous operation

To return to the previous operation, say, “Go Back” while in voice
recognition mode.

● Cancel

To put the Bluetooth

®

 Hands-Free system in standby mode, say,

“Cancel” while in voice recognition mode.

Voice Recognition (Type B)

iA_OM_OM99M17z_(U)

357

4-3. Bluetooth

®

4

In

te

rior Fea

tu

res

■

To prevent a deterioration in the voice recognition rate and
voice quality, the following points should be observed:
● The voice recognition cannot be performed while voice guidance

or the beep sound is operating. Wait until the voice guidance or
the beep sound is finished before saying your commands.

● Phone related commands are available only when your phone is

connected via Bluetooth

®

. Make sure your phone is connected

via Bluetooth

®

 before you operate phone related voice com-

mands.

● Music play commands, such as Play Artist and Play Album can

be used only in USB audio mode.

● Do not speak too slowly or loudly (no loud voice).
● Speak clearly, without pausing between words or numbers.
● Dialects or different wording other than hands-free prompts can-

not be recognized by voice recognition. Speak in the wording
specified by the voice commands.

● It is not necessary to face the microphone or approach it. Speak

the voice commands while maintaining a safe driving position.

● Close the windows to reduce loud noises from outside the vehi-

cle, or turn down the airflow of the air-conditioning system while
Bluetooth

®

 Hands-Free is being used.

● Make sure the vents are not directing air up towards the micro-

phone.

If the voice recognition performance is not satisfactory.

Refer to Troubleshooting on P. 401.

358

iA_OM_OM99M17z_(U)

4-3. Bluetooth

®

■

Main audio operation

The below commands are examples of the available commands.

When the talk button is pressed and the following command is spo-
ken out, the audio can be operated. The commands in the () can be
omitted. The specified name and number are put into the {}.

Audio Operation Using Voice Recognition (Type B)

Voice command

Function

Corresponding

audio source

(Go to/Play) AM
(Radio)

Switches the audio source to
AM radio.

All

(Go to/Play) FM
(Radio)

Switches the audio source to
FM radio.

All

(Go to/Play) Bluetooth
(Audio)

Switches the audio source to
BT audio.

All

(Go to/Play) Pandora

Switches the audio source to
Pandora

®

All

(Go to/Play) Aha
(Radio)

Switches the audio source to
Aha™ Radio.

All

(Go to/Play) Stitcher

Switches the audio source to
Stitcher™ Radio.

All

(Go to/Play) USB 1

Switches the audio source to
USB 1.

All

(Go to/Play) USB 2

Switches the audio source to
USB 2.

All

Play Playlist {Playlist
name}

Plays the selected playlist.

USB

Play Artist {Artist name} Plays the selected artist.

USB

Play Album {Album
name}

Plays the selected album.

USB

Play Genre {Genre
name}

Plays the selected genre.

USB

Play Folder {Folder
name}

Plays the selected folder.

USB

iA_OM_OM99M17z_(U)

359

4-3. Bluetooth

®

4

In

te

rior Fea

tu

res

■

Main audio operation

●

Some commands cannot be used depending on devices and use condi-
tions.

●

If the Bluetooth

®

 device, USB, or AUX is not connected, the related com-

mands cannot be used.

360

iA_OM_OM99M17z_(U)

4-3. Bluetooth

®

Bluetooth

®

 Hands-Free (Type A)

● Phonebook Usage

Telephone calls can be made by saying the name of a person
(voice tag) whose phone number has been registered in Bluetooth

®

Hands-Free in advance. Refer to Phonebook registration.

Press the pick-up button or talk button with a short press.

Say: [Beep] “Call”

Prompt: “Name please.”

Say: [Beep] “XXXXX... (Ex. “John’s phone”)” (Say a voice tag
registered in the phonebook.)

Prompt: “Calling XXXXX... (Ex. “John’s phone”) XXXX (Ex. “at
home”). Is this correct?” (Voice tag and phone number location
registered in phonebook).

Say: [Beep] “Yes”

Prompt: “Dialing”

The “Call” command and the voice tag can be combined.

Ex. In Step 2, say, “Call John’s phone”, then, Steps 3 and 4 can be
skipped.

● Phonebook registration

Phone numbers can be registered to the Bluetooth

®

 Hands-Free

phonebook.

Do this function only when parked. It is too distracting to attempt while driv-
ing and you may make too many errors to be effective.

Press the pick-up button or talk button with a short press.

Say: [Beep] “Phonebook”

Prompt: “Select one of the following: New entry, edit, list names,
delete, erase all or import contact.”

Say: [Beep] “New entry”

Prompt: “Name please.”

Say: [Beep] “XXXXX... (Ex. “Mary’s phone”)” (Say a voice tag for
the name registered.)

Prompt: “Adding XXXXX... (Ex. “Mary’s phone”) (Registered
voice tag). Is this correct?”

Making a Call

1

2

3

4

5

6

7

1

2

3

4

5

6

7

iA_OM_OM99M17z_(U)

361

4-3. Bluetooth

®

4

In

te

rior Fea

tu

res

Say: [Beep] “Yes”

Prompt: “Home, Work, Mobile, or Other?”

Say: [Beep] “Mobile” (Say “Home”, “Work”, “Mobile”, or “Other”,
for the desired location to be registered.)

Prompt: “Mobile (Location to be registered). Is this correct?”

Say: [Beep] “Yes”

Prompt: “Number, please.”

Say: [Beep] “XXXXXXXXXXX” (Say the phone number to be reg-
istered.)

Prompt: “XXXXXXXXXXX (Phone number registration). After the
beep, continue to add numbers, or say Go-Back to re-enter the
last entered numbers, or press the Pick-Up button to save the
number.”

(Registration)
Press the pick-up button or say “Enter”, then go to Step 17.
(Adding/inputting telephone number)
Say, “XXXX” (desired telephone number), then go to Step 15.
(Telephone number correction)
Say, “Go Back”. The prompt replies, “Go Back. The last entered
numbers have been removed.”. Then go back to Step 13.

Prompt: “Number saved. Would you like to add another number
for this entry?”

Say: [Beep] “Yes” or “No”.

If “Yes”, an additional phone number registration can be made for
the same entry.
If “No”, the system returns to standby status.

8

9

10

11

12

13

14

15

16

17

18

19

362

iA_OM_OM99M17z_(U)

4-3. Bluetooth

®

Import contact:

Phonebook data from your device (Mobile phone) can be sent and
registered to your Bluetooth

®

 Hands-Free phonebook using Blue-

tooth

®

.

Press the pick-up button or talk button with a short press.

Say: [Beep] “Phonebook”

Prompt: “Select one of the following: New entry, edit, list names,
delete, erase all or import contact.”

Say: [Beep] “Import contact”

Prompt: “The hands free System is ready to receive a contact
from a phone. Only a home, a work, and a mobile number can be
imported, This process requires operation of a mobile phone.
refer to the phone’s manual for more information”

Device (Mobile phone) operation: Select one entry from the
phonebook and send it using Bluetooth

®

.

Prompt: “X (Number of locations which include data) numbers
have been imported. What name would you like to use for these
numbers?”

Say: [Beep] “XXXXX... (Ex. “Mary’s phone”)” (Say a voice tag for
the name registered.)

Prompt: “Adding XXXXX... (Ex. “Mary’s phone”) (Voice tag). Is
this correct?”

Say: [Beep] “Yes”

Prompt: “Number saved. Would you like to import another con-
tact?”

Say: [Beep] “Yes” or “No”

If “Yes”, the procedure proceeds to Step 5.
If “No”, the system returns to standby status.

● Editing phonebook

The data registered to the Bluetooth

®

 Hands-Free phonebook can

be edited.

Do this function only when parked. It is too distracting to attempt while driv-
ing and you may make too many errors to be effective.

1

2

3

4

5

6

7

8

9

10

11

12

13

iA_OM_OM99M17z_(U)

363

4-3. Bluetooth

®

4

In

te

rior Fea

tu

res

Press the pick-up button or talk button with a short press.

Say: [Beep] “Phonebook”

Prompt: “Select one of the following: New entry, edit, list names,
delete, erase all or import contact.”

Say: [Beep] “Edit”

Prompt: “Please say the name of the entry you would like to edit
or say, “List names”.”

Say: [Beep] “XXXXX... (Ex. “Mary’s phone”)” (Say the voice tag
for the registered name to be edited in the phonebook.)

Prompt: “Home, Work, Mobile, or Other?”

Say: [Beep] “Home” (Say the registered location to be edited:
“Home”, “Work”, “Mobile”, or “Other”.)

Prompt: “XXXXX... (Ex. “Mary’s phone”) (Registered voice tag)
XXXX (Ex. “Home”) (Registered location). Is this correct?”

Say: [Beep] “Yes”

Prompt: “The current number is XXXXXXXXXXX (Ex. “555-
1234”) (Currently registered number). New number, please.”

If there was no previous phone number registered to a location (Ex.
“Work”), the prompt will only read out “Number, please”

Say: [Beep] “XXXXXXXXXXX (Ex. “555-5678”)” (Say the new
phone number to be registered.)

Prompt: “XXXXXXXX (Telephone number) After the beep, con-
tinue to add numbers, or say Go-Back to re-enter the last entered
numbers, or press the Pick-Up button to save the number.”

(Number Change)
Press the pick-up button, then go to Step 15.
(Adding/inputting telephone number)
Say, “XXXX” (desired telephone number), then go to Step 13.
(Telephone number correction) Say, “Go Back”. The prompt
replies, “Go Back. The last entered numbers have been
removed. Number, please.”. Then go back to Step 12.

Prompt: “Number changed.”

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

364

iA_OM_OM99M17z_(U)

4-3. Bluetooth

®

● Phonebook data deletion

Erasing individual phonebook data

Individual data registered to the Bluetooth

®

 Hands-Free phonebook

can be cleared.

Do this function only when parked. It is too distracting to attempt while driv-
ing and you may make too many errors to be effective.

Press the pick-up button or talk button with a short press.

Say: [Beep] “Phonebook”

Prompt: “Select one of the following: New entry, edit, list names,
delete, erase all or import contact.”

Say: [Beep] “Delete”

Prompt: “Please say the name of the entry you would like to
delete or say, “List names”.”

Say: [Beep] “XXXXX... (Ex. “John’s phone”)” (Say the registered
voice tag to be deleted from the phonebook.)

Prompt: “Deleting XXXXX... (Ex. “John’s phone”) (Registered
voice tag) Home (Registered location). Is this correct?”

Say: [Beep] “Yes”

Prompt: “XXXXX... (Ex. “John’s phone”) (Registered voice tag)
Home (Registered location) deleted.”

Complete deletion of the phonebook data:

All data registered to the Bluetooth

®

 Hands-Free phonebook can

be erased.

Do this function only when parked. It is too distracting to attempt while driv-
ing and you may make too many errors to be effective.

Press the pick-up button or talk button with a short press.

Say: [Beep] “Phonebook”

Prompt: “Select one of the following: New entry, edit, list names,
delete, erase all or import contact.”

Say: [Beep] “Erase all”

Prompt: “Are you sure you want to erase everything from your
Hands Free system phonebook?”

Say: [Beep] “Yes”

Prompt: “You are about to delete everything from your Hands
Free system phonebook. Do you want to continue?”

Say: [Beep] “Yes”

1

2

3

4

5

6

7

8

9

1

2

3

4

5

6

7

8

iA_OM_OM99M17z_(U)

365

4-3. Bluetooth

®

4

In

te

rior Fea

tu

res

Prompt: “Please wait, erasing the Hands Free system phone-
book.”

Prompt: “Hands-Free system phonebook erased.”

● Read-out of names registered to the Bluetooth

®

 Hands-Free

phonebook

Bluetooth

®

 Hands-Free can read out the list of names registered to

its phonebook.

Press the pick-up button or talk button with a short press.

Say: [Beep] “Phonebook”

Prompt: “Select one of the following: New entry, edit, list names,
delete, erase all or import contact.”

Say: [Beep] “List names”

Prompt: “XXXXX..., XXXXX..., XXXXX... (Ex. “John’s phone”,
Mary’s phone, Bill’s phone)” (Voice guidance reads out the voice
tags registered to the phonebook.)
Press the talk button with a short press during the read-out at the
desired name, and then say one of the following voice com-
mands to execute it.
● “Continue”: Continues the list readout.
● “Call”: Calls the registered phonebook data when the talk but-

ton is short- pressed.

● “Edit”: Edits the registered phonebook data when the talk but-

ton is short- pressed.

● “Delete”: Deletes the registered phonebook data when the talk

button is short-pressed.

● “Previous”: Returns to the previous phonebook data in read-

out when the talk button is short-pressed.

Prompt: “End of list, would you like to start from the beginning?”

Say: [Beep] “No”

The procedure returns to Step 3.

9

10

1

2

3

4

5

6

7

8
