Bulb Replacement
Sidelight
Inboard headlights (main beam)
Replacement bulb: 5 watt.
Replacement bulb: H1 55 watt.
The sidelight holder is immediately below the headlight bulb (see
small inset on previous illustration). With the circular rubber cover
removed, pull the bulb holder from the light unit and pull the bulb
to remove it from the holder.
Replacing the access panel
Clip the protrusion at the top of the access panel into the aperture
in the wheel arch liner and push the panel upwards as far as it will
go. The smaller protrusion at the bottom of the panel can then be
2
clipped into the corresponding cut-out at the bottom of the wheel
1
arch liner aperture. Finally, engage the turnbuckle screw and turn
a quarter turn to left or right to fully secure the access panel.
H2739a
4
3
1. Remove the rubber cover from the rear of the headlight.
2. Unhook the wire securing clip (see small inset in illustration)
and pivot it away from the rear of the bulb.
3. Detach the electrical connector from the rear of the bulb.
4. Remove the bulb.
242
Bulb Replacement
FRONT DIRECTION INDICATORS (oval-shaped)
Twist the bulb holder a quarter turn anti-clockwise to release it
from the light unit. Push and twist the bulb one eighth of a turn to
Replacement bulb: 21 watt (amber).
release.
When replacing the light unit, insert the outboard side first (nearest
the side of the car), then carefully ease the inboard side of the light
into the aperture. Be sure it ‘clicks’ securely into position.
H2702
Using hand pressure, push the bottom of the outboard corner of
the lens very firmly towards the REAR of the car; at the same
5
time, push the inboard side of the lens firmly towards the SIDE of
the car. This will disengage the securing spring and enable the light
unit to be pulled from the front of the bumper.
Alternatively, use a flat-bladed screwdriver to carefully lever the
inboard side of the light unit from the bumper aperture.
243
Bulb Replacement
FRONT DIRECTION INDICATORS (circular type)
Replacement bulb: 21 watt (amber).
HB0300
Detach the electrical connector from the rear of the bulb holder by
squeezing the clips on both sides of the connector and pulling the
HB0299
connector away from the light unit.
To access the light unit, the small panel immediately below the
Twist the bulb holder a quarter turn anti-clockwise to release it
relevant light must be removed from the underside of the car. This
from the light unit. Push and twist the bulb one eighth of a turn to
is held in place by five Philips type screws, which must be removed
release.
before the panel can be released (see illustration for location of the
five screws).
244
Bulb Replacement
FRONT FOG LIGHTS (oval-shaped)
Remove the three retaining screws and pull the light unit forward
away from the bumper. Twist the bulb holder an eighth of a turn
Replacement bulb: H1 55 watt.
anti-clockwise to release it from the rear of the light unit. Holding
only the metal part of the bulb, pull to remove it from the bulb
holder.
NOTE: It may be necessary to insert the blade of a small screwdriver
under the metal flange at the base of the bulb, and use as a lever to separate
the bulb from the holder.
When replacing the bulb, note that the circular flange has a flat on
one side. The flat must align with the lug on the matching face of
the bulb holder. Similarly, note the three tabs on the perimeter of
the bulb holder (one small and two large); correct alignment of the
tabs will ensure the holder is replaced the right way round.
During use, Halogen headlight bulbs may shatter if the glass
has been scratched, or contaminated with oil or perspiration.
DO NOT touch the glass. If handled, clean with methylated spirits
and a clean cloth.
5
H2789
Pull the inboard side of the fog light surround away from the front
of the car - see illustration (gentle leverage using a flat-bladed
screwdriver behind the surround may be necessary).
245
Bulb Replacement
FRONT FOG LIGHTS (circular type)
anti-clockwise to release it from the rear of the light unit. Holding
only the metal part of the bulb, pull to remove it from the bulb
Replacement bulb: H1 55 watt.
holder.
To access the light unit, the small access panel immediately below
NOTE: It may be necessary to insert the blade of a small screwdriver
the relevant light must be removed from the underside of the car.
under the metal flange at the base of the bulb, and use as a lever to separate
Refer to ‘FRONT DIRECTION INDICATORS (circular type)’,
the bulb from the holder.
page 244 for information on how to remove this panel.
When replacing the bulb, note that the circular flange has a flat on
one side. The flat must align with the lug on the matching face of
the bulb holder. Similarly, note the three tabs on the perimeter of
the bulb holder (one small and two large); correct alignment of the
tabs will ensure the holder is replaced the right way round.
During use, Halogen headlight bulbs may shatter if the glass
has been scratched, or contaminated with oil or perspiration.
DO NOT touch the glass. If handled, clean with methylated spirits
and a clean cloth.
HB0301
Detach the electrical connector from the rear of the light unit by
lifting the lever on the side of the connector and pulling the
connector downward. Twist the bulb holder an eighth of a turn
246
Bulb Replacement
REAR LIGHTS (Saloon)
To access the bulbs, it is necessary to detach one of the scrivet
fixings and fold back the boot lining.
1
5
2
3
4
HB0497
Replacement bulbs:
HB0496
1. Brake light 21 watts
2. Tail light 5 watts
To remove the fixing: Use pliers or the flat blade of a screwdriver to
3. Fog guard light 21 watts
lever the head of the fixing away from the boot lining. The fixing
4. Reversing light 21 watts
can then be pulled from its mounting position.
5. Direction indicator light 21 watts (amber)
To replace the fixing: Fully open the fixing by pulling the head away
5
Press the lever (arrowed in main illustration) towards the side of
from the body (see inset). Align the fixing with the holes in the
the car to release the light unit. Remove light unit from the car.
boot lining and bodywork, then push the head fully in.
Push and twist the bulbs anti-clockwise to remove.
Detach the electrical connector from the rear of the light unit by
depressing the release catch on the underside (see inset in following
NOTE: When replacing the light unit, locate the upper part of the light
illustration), at the same time pulling the connector free.
unit first then ease the lower half into position. Make sure the release catch
‘clicks’ into position to securely retain the light unit.
247
Bulb Replacement
REAR LIGHTS (Tourer)
1
2
3
4
5
HB0041a
HB0019a
Replacement bulbs:
With the tailgate open, use the flat-bladed end of the screwdriver
1. Brake light 21 watts
(supplied in the tool kit) to prise open the two flaps on the inboard
2. Tail light 5 watts
side of the light unit (where indicated in illustration), to reveal two
3. Direction indicator light 21 watts (amber)
retaining screws.
4. Fog guard light 21 watts
Fully release both screws until the light unit can be pulled away
5. Reversing light 21 watts
from the rear of the car, then detach the electrical connector.
Twist the bulb holders one eighth of a turn anti-clockwise to
To replace the light unit, align the two metal pins protruding from
remove them from the rear of the light unit. With the exception
the rear with the corresponding bushes on the car. Push the light
of the (smaller) tail light bulb, which is a push/pull fit, push and
unit firmly onto the car, taking care to ensure that the two plastic
twist the bulbs anti-clockwise to remove.
lugs (at the base of the light unit) fit smoothly into the receiver
NOTE: The amber direction indicator bulb has off-set bayonet pins and
guides (arrowed in second illustration) on the car.
can only be fitted one way round.
248
Bulb Replacement
NUMBER PLATE LIGHTS (Saloon)
NUMBER PLATE LIGHTS (Tourer)
Replacement bulb: 5 watt.
Replacement bulb: 5 watt.
H2705
There are two number plate lights. On saloon models, remove the
HB0039a
5
two securing screws and the lens to access each bulb.
To access a bulb, use a small flat-bladed screwdriver to ease the lens
Pull the bulb to remove.
from the underside of the applique (see upper inset - the lever
NOTE: When replacing, ensure the lens is fitted the correct way round;
action of the screwdriver will compress the spring retaining clip
the curved face should point towards the rear.
and enable the lens to be pulled free). Prise the connectors apart to
remove the bulb.
When replacing the lens, fully insert the end opposite to the spring
clip, then push the side with the spring clip into place.
249
Bulb Replacement
SIDE REPEATER LIGHTS
GLOVEBOX LIGHT
Replacement bulb: 5 watt (amber).
Replacement bulb: 5 watt.
H2784
Insert a small flat-bladed screwdriver (preferably with a short
handle, due to limited access) into the indent on the left hand side
H2701
of the light unit, and carefully prise the unit from the glovebox
panel. Remove the bulb from its clips.
Push the lens firmly towards the front of the car to release the light
unit, then withdraw the light from the wing.
Twist anti-clockwise to release the bulb holder from the light unit.
Pull to remove the bulb from its socket.
When refitting the light unit, first locate the two tabs (arrowed in
illustration), ensuring that they are pointing towards the rear of the
car, then push the remainder of the light unit into the aperture.
250
Bulb Replacement
FRONT COURTESY & MAP READING LIGHTS
REAR COURTESY LIGHTS
Replacement bulb: 3 watt
Replacement bulb: 3 watt
H2695
H2694
Insert a small flat-bladed screwdriver into the indent at the rear of
Insert a small flat-bladed screwdriver into the indent at the rear of
the lens (see inset) and gently prise the lens from the light unit. Pull
the lens (see inset) and gently prise the lens from the light unit. Pull
the bulbs from their mountings to remove.
the bulbs from their mountings to remove.
5
When replacing the lens, locate the single ‘prong’ at the front of
When replacing, locate and position the ‘prongs’ at the front of the
the lens first, then carefully flex the lens to locate and position the
lens first, then carefully push the rear of the lens into the light unit
remaining four prongs into the light unit. Push the lens upwards
until it ‘clicks’ into position.
into the light unit until it ‘clicks’ into position.
251
Bulb Replacement
BOOT LIGHT (Saloon)
LOADSPACE LIGHT (Tourer)
Replacement bulb: 10 watt
Replacement bulb: 5 watt
H2783
HB0038
Insert a small flat-bladed screwdriver into the indent on one of the
narrow sides of the lens (see arrow in illustration) and carefully
Insert a small flat-bladed screwdriver into the indent on the rear
prise the unit from its location. Push and twist the bulb to remove.
edge of the lens (see inset) and carefully prise the lens from the light
unit. Gently spread the flexible contacts to release the bulb.
When replacing, locate one side of the lens, then push firmly on
the other side, until the lens ‘clicks’ into position.
252
Bulb Replacement
UNDERFLOOR LOADSPACE LIGHT (Tourer)
Replacement bulb: 5 watt
HB0027
Insert a small flat-bladed screwdriver into the indent on one of the
short sides of the lens (see inset in illustration) and carefully prise
the lens and bulb carrier from its location. Ease open one of the
5
bulb connectors and pull the bulb to remove.
253
Technical Data
256
Technical Data
271
Fuel Consumption
274
Declaration of Conformity
6
Technical Data
Technical Data
Technical Data
ENGINES
1.8 litre petrol
2.0 litre petrol
Fuel
UNLEADED 95 RON to EN 228
Fuel
UNLEADED 95 RON to EN 228
specification is recommended †
specification is recommended †
Capacity
1796 cm3
Capacity
1997 cm3
Firing order
1-3-4-2
Firing order
1-6-5-4-3-2
Idle speed
750 ± 50 rev/min
Idle speed
750 ± 50 rev/min
Bore
80 mm
Bore
80 mm
Stroke
89.3 mm
Stroke
66.2 mm
Number of cylinders
4 in-line
Number of cylinders
6 V-arrangement
Compression ratio:
Compression ratio
10.5:1
- Turbo engines
9.2:1
Ignition system
Siemens engine management system
- Non-turbo engines
10.5:1
Spark plugs
GSP 66527
Ignition system
MEMS3 breakerless, electronic
Spark plug gap
1.0 mm ± 0.05
Spark plugs
GSP 66527
Spark plug gap
1.0 mm ± 0.05
† Unleaded fuels of 95 - 98 RON can be used.
† Unleaded fuels of 95 - 98 RON can be used.
256
Technical Data
2.5 litre petrol
2.0 litre diesel
Fuel
UNLEADED 95 RON to EN 228
Fuel
Diesel to EN 590 specification
specification is recommended †
Capacity
1951 cm3
Capacity
2497 cm3
Firing order
1-3-4-2
Firing order
1-6-5-4-3-2
Idle speed
780 ± 50 rev/min
Idle speed
750 ± 50 rev/min
Bore
84.0 mm
Bore
80 mm
Stroke
88.0 mm
Stroke
82.8 mm
Number of cylinders
4 in-line
Number of cylinders
6 V-arrangement
Compression ratio
18.0:1
Compression ratio
10.25:1
Ignition system
Siemens engine management system
Spark plugs
GSP 66527
Spark plug gap
1.0 mm ± 0.05
† Unleaded fuels of 95 - 98 RON can be used.
6
257
