Harmony - Radio Tuning

RADIO PRE-SET BUTTONS

Programming the pre-sets

• Select the required waveband (FM1, FM2, MW1, MW2 or

4

3

LW).

• Tune to the desired frequency using either automatic or manual

tuning.

• Press and hold one of the pre-set buttons. The radio will mute

while the frequency you have chosen is stored on the pre-set.

The display briefly shows the frequency and station name

(where appropriate) of the radio station previously stored on

the pre-set, and then the new frequency (and station name).

7

ICE0143

• Release the pre-set as soon as radio sound is restored and the

new frequency details are displayed.

The six pre-set buttons (7) can be used to manually store up to

twelve FM stations (six each on FM1 and FM2), twelve MW

NOTE: Once the pre-sets have been programmed, they will be retained

stations (six each on MW1 and MW2), and six LW stations.

by the unit until either; they are re-programmed, or power to the audio unit

is disturbed (car battery disconnection for example).

Operating the pre-sets

Once the pre-set buttons have been programmed, operation is

simple; select the desired waveband, then press the pre-set button

of your choice.

146

Harmony - Radio Tuning

AUTO-STORE

Programming auto-store

Press and hold the appropriate waveband selection button (3 or 4)

4

3

- the radio mutes and the display shows either

‘FM AUTOSTORE’ or ‘MW AUTOSTORE’.

Auto-store scans the waveband to find the six strongest frequencies

and then stores them on either the FM2 or MW2 pre-set buttons

in order of signal strength. Radio sound is restored once the

operation is complete.

If auto-store is unable to find six strong stations, the remaining pre-

sets are not used (display shows ‘NO STATION’).

7

ICE0144

NOTE: Auto-store overwrites any stations already stored on the FM2 or

Auto-store enables you to rapidly tune and store the strongest FM

3

MW2 pre-set buttons.

and MW radio signals in a single operation. This facility is

particularly useful if you are in an unfamiliar area and have little

NOTE: If FM auto-store is programmed with the traffic facility armed,

knowledge of local transmitter frequencies.

then programming will be limited to those stations capable of providing

traffic information only. For this reason, it is recommended that the traffic

information facility is switched off before the pre-set stations are stored and

before auto-store is programmed.

Operating auto-store

To tune to one of the auto-store frequencies, select FM2 or MW2,

then press the pre-set button of your choice.

147

Symphony - Radio

Symphony - Radio

SOUND CONTROLS

1. On/off and volume control

Press to switch on (display shows ‘ROVER’). Press again to switch

off.

Rotate steadily to right or left to adjust the volume.

The volume can also be adjusted using the remote switches on the

steering wheel (see ‘REMOTE AUDIO CONTROLS’,

page 125).

NOTE: The volume level automatically increases or decreases according to

road speed, thereby combating any additional road or wind noise that may

be experienced.

NOTE: If you have a car telephone with a mute signal output connected

1

2

ICE0151

to the stereo system, radio, tape or CD play automatically mutes when the

telephone is in use.

IMPORTANT

The audio unit has a 20 minute time-out function. This enables the

unit to be switched on and then used for up to 20 minutes after the

starter switch has been turned off and the key removed. After 20

minutes, the unit will switch off automatically.

150

Symphony - Radio

RADIO CONTROLS

4. AM waveband selector

Press briefly once, twice or three times to select one of the three

AM bands (MW1, MW2 and LW). Each can be used to store six

5

6

5

4

3

stations on the pre-set buttons.

Press and hold to activate auto-store (on MW only - see ‘AUTO-

STORE’, page 159).

5. Tuning buttons

Briefly press either button to search up or down the frequency

range (see ‘RADIO TUNING’, page 157).

6. Manual tuning selector

Press to select manual tuning mode (‘MAN’ is displayed) - use in

conjunction with the tuning buttons (see ‘Manual tuning’,

9

7

8

page 157). Press again to return to automatic tuning.

ICE0152

The frequency can also be selected using the remote switches on

3. FM waveband selector

the steering wheel (see ‘Remote audio controls’).

Press briefly once or twice to select FM frequencies. There are two

NOTE: Manual tuning defaults to automatic tuning if unused for more

FM bands (FM1 and FM2). Both have the same tuning range, and

than 14 seconds.

each one can be used to store six frequencies on the pre-set

buttons.

7. Pre-set buttons (1-6)

Use to store up to 6 radio stations on each waveband.

Press and hold to activate auto-store (see ‘AUTO-STORE’,

page 159).

Press briefly to select a stored frequency.

Press and hold (until radio bleeps) to store a frequency on a pre-set

(see ‘Programming the pre-sets’, page 158).

152

Symphony - Cassette Player

Symphony - Cassette Player

CASSETTE PLAYER CONTROLS

11. Tape mode selector

Press to select tape play (display shows ‘TAPE’ and either

‘SIDE-1’ or ‘SIDE-2’).

To change to radio reception during tape play, press either of the

waveband selection buttons (FM or AM) - tape play will stop and

the radio automatically selects the frequency last in use on

whichever waveband was selected.

To return to tape play, press the tape mode button.

NOTE: The remote switches on the steering wheel can also be used to

change to or from radio or tape play (see ‘Remote audio controls’).

12. Cassette eject button

12 13 15

14

10

14

11

16

ICE0153

Press to eject the tape (display shows ‘TAPE EJECT’). The unit

returns to radio mode, selecting the waveband and frequency last

10. Cassette compartment

in use.

Insert the tape with the open side to the right and push in carefully.

The radio mutes and tape play starts immediately (display shows

13. Tape reverse button

‘TAPE’ and ‘SIDE-1’ or ‘SIDE-2’).

Press to play the opposite side of the tape.

At the end of either side of the tape, play will automatically

14. Tape search controls

continue in the opposite direction.

Fast forward/rewind: With the unit in manual mode (‘MAN’

If the set is switched off during tape play, the cassette remains in

indicator in the display illuminated), press the appropriate search

stand-by mode. Play resumes when the set is switched on again.

button (‘TAPE FFWD’ or ‘TAPE FREW’ will appear in the

display). The tape will fast forward/rewind until either search

button is pressed again.

154

Symphony - Compact Disc Player

Symphony - Compact Disc Player

COMPACT DISC PLAYER CONTROLS

18. Disc selection buttons (1-6)

Press the appropriate button to select a disc.If an empty

19

compartment is selected, the next available disc is selected instead.

19. Track search buttons

Press the appropriate button once to skip to the beginning of the

next track, or to return to the start of the current track. Press either

button repeatedly to select other tracks on the disc. If a button is

pressed and held, the CD player continues to skip tracks (forwards

or backwards) until the button is released.

Search: Press the manual mode button (‘MAN’), then press and

hold the appropriate search button to move forward or backward

through the disc in play mode, but at increased speed (volume

reduces and display shows ‘FFWD’ or ‘FREW’).

18

17

20

ICE0154

20. Scan mode button (SCAN)

Press the SCAN button to listen to the first 10 seconds of every

17. CD mode selector

track on the selected disc. ‘SCN’ appears in the display, along with

Press to select CD player mode. Playback starts from the point on

the number of the disc and the scanned track. The scan continues

the disc at which play last stopped, or from the start of the first disc

until the button is pressed again or until another function is

if the magazine is newly inserted. The display shows disc and track

selected.

numbers (i.e. ‘DISC 3 TRACK 12’). If no magazine has been

inserted into the autochanger, ‘NO MAGAZINE’ is displayed.

By pressing and holding the SCAN button for approximately 2

seconds, random play mode is activated, whereby tracks from any

At the end of each disc, playback automatically continues with the

of the discs will be played in random order (‘RND’ and the disc

next disc (missing discs are skipped if less than six have been

and track numbers are displayed).

loaded).

NOTE: The compact disc player controls will operate only with the

NOTE: If a magazine compartment is empty or a disc has been inserted

optional CD changer unit.

into the magazine upside down, ‘NO DISC’ is displayed.

NOTE: Skip and mode selection can be operated using the remote

switches on the steering wheel (see ‘Remote audio controls’)

156

Symphony - Radio Tuning

Symphony - Radio Tuning

RADIO TUNING

Automatic tuning

Select the required waveband (FM or AM), then briefly press one

of the tuning buttons (5) - (‘SEEK’ and chevrons indicating the

direction of search appear in the display).

The radio automatically searches the frequency range (either up or

down depending upon which of the tuning buttons is pressed)

looking for a radio station of acceptable strength. Once a suitable

station is found, the search stops unless you choose to continue by

pressing the tuning button again.

NOTE: If you have a car telephone with a mute signal output connected

to the radio, the radio automatically mutes when the telephone is in use.

5

6

5

8

ICE0155

3

Waveband scan

Select the desired waveband (FM or AM) and press the SCAN

Manual tuning

button (8). The radio scans through the waveband, seeking stations

If you know the frequency of the radio station you are seeking, or

of acceptable strength. Each time a strong signal is found, the radio

you need to select a radio station that is too weak to be found by

plays that station for 5 seconds (the display shows waveband and

automatic tuning, use manual tuning, as follows:

frequency, accompanied by the word ‘SCAN’). After 5 seconds

Select the desired waveband (FM or AM), then press the manual

the radio mutes and scans for the next station, and so on.

tuning selector (6) (the ‘MAN’ indicator illuminates in the

To stop the scan, press the button again - the radio commences

display). By pressing either tuning button (5), the frequency

playing the station at which the scan was stopped.

changes (either up or down) in steps of 0.1 MHz for FM, or 9 kHz

for MW, or 1 kHz for LW.

MONO/STEREO

Fast manual tuning

Whenever the FM waveband is selected, the radio automatically

By keeping either tuning button depressed, the waveband is

reproduces stereo sound, provided a suitable signal is available.

scanned rapidly (up or down) until the button is released.

However, if a signal becomes too weak for good stereo reception,

only mono sound is produced until the signal strengthens

sufficiently for stereo sound reproduction.

157

Symphony - Radio Tuning

RADIO PRE-SET BUTTONS

Operating the pre-sets

Once the pre-set buttons have been programmed, operation is

simple; select the desired waveband, then press the pre-set button

of your choice.

7

4

3

ICE0160

The six pre-set buttons (7) can be used to manually store up to

twelve FM stations (six each on FM1 and FM2), twelve MW

stations (six each on MW1 and MW2), and six LW stations.

Programming the pre-sets

• Select the required waveband (FM1, FM2, MW1, MW2 or

LW).

• Tune to the desired frequency using either automatic or manual

tuning.

• Press and hold one of the pre-set buttons until a bleep sounds.

The frequency is now stored (the display shows the waveband

and frequency or name of the station to which you have tuned).

NOTE: Once the pre-sets have been programmed, they will be retained

by the unit until either; they are re-programmed, or power to the audio unit

is disturbed (car battery disconnection for example).

158

Symphony - Radio Tuning

AUTO-STORE

Programming auto-store

Press and hold the appropriate waveband selection button (3 or 4)

until a bleep sounds (the radio mutes and the display shows

‘AUTOSTORE’).

Auto-store scans the waveband to find the six strongest frequencies

and then stores them on either the FM2 or MW2 pre-set buttons

in order of signal strength. Radio play restores once the operation

is complete.

If auto-store is unable to find six strong stations, the remaining pre-

sets are not used.

NOTE: Auto-store overwrites any stations already stored on the FM2 or

3

MW2 pre-set buttons.

ICE0156

7

4

3

NOTE: If FM auto-store is programmed with the traffic facility armed,

Auto-store enables you to rapidly tune and store the strongest FM

then programming will be limited to those stations capable of providing

and MW radio signals in a single operation. This facility is

traffic information only. For this reason, it is recommended that the traffic

particularly useful if you are in an unfamiliar area and have little

information facility is switched off before the pre-sets are stored and before

knowledge of local transmitter frequencies.

auto-store is programmed.

Operating auto-store

To tune to one of the auto-store frequencies, select FM2 or MW2,

then press the pre-set button of your choice.

159

Content      ..     8      9      10      11     ..
