Storage
73
open the soft top. The pass-through
Rear floor storage cover
flap must be closed in vertical
position.
Rear floor cover
Rear storage
Hooks for carrier bags
● Open the pass-through by
swivelling the flap upwards to
horizontal position. The flap is
fixed in opened or closed position
with a Velcro fastener.
The rear floor cover can be lifted and
removed. Under the cover there is the
● Fold down rear backrests by
spare wheel, vehicle tools or the tyre
pulling the release switches p in
repair kit.
the load compartment.
Use the hooks at the upper edge of
● To close the pass-through, swivel
the load compartment for hanging up
the flap downwards and fix it in
carrier bags. Maximum load: 5 kg.
vertical position with the Velcro
fastener.
Fold out the load compartment
partition by pulling the loop
downwards to the rear, in order to

-------------------------------------------------------------------------------------------------------------------------------------------------------------

74
Storage
Lashing eyes
Warning triangle
First aid kit
The lashing eyes are designed to
Warning triangle is stowed in the
The first aid kit is stowed on the right
secure items against slippage, e.g.
space on the inside of the boot lid
side in the load compartment behind
using lashing straps or luggage net.
behind the straps.
a strap.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Storage
75
● The load must not obstruct the
weights table at the front of this
Loading information
operation of the pedals, parking
manual.
brake and gear selector lever, or
Heavy objects in the load
The EC kerb weight includes
hinder the freedom of movement
compartment should be placed
weights for the driver (68 kg),
of the driver. Do not place any
as far forward as possible.
luggage (7 kg) and all fluids (fuel
unsecured objects in the interior.
Ensure that the backrests are
tank 90% full).
securely engaged. If objects can
● Do not place any objects on the
Optional equipment and
be stacked, heavier objects
covers of the roll bars behind the
accessories increase the kerb
should be placed at the bottom.
head restraints.
weight.
Secure objects with lashing
● Do not drive with an open load
straps attached to the lashing
compartment.
eyes 3 74.
9 Warning
Use the hooks in the load
compartment for hanging up
Always ensure that the load in the
carrier bags 3 73. Maximum
vehicle is securely stowed.
load: 5 kg per hook.
Otherwise objects can be thrown
Secure loose objects in the load
around inside the vehicle and
compartment to prevent them
cause personal injury or damage
from sliding.
to the load or vehicle.
When transporting objects in the
load compartment, the backrests
● The payload is the difference
of the rear seats must not be
between the permitted gross
angled forward.
vehicle weight (see identification
plate 3 236) and the EC kerb
Do not place any objects on the
weight.
instrument panel, and do not
cover the sensor on top of the
To calculate the payload, enter
instrument panel.
the data for your vehicle in the

-------------------------------------------------------------------------------------------------------------------------------------------------------------

76
Instruments and controls
Seat belt reminder
89
Fog light
94
Instruments and
Airbag, belt tensioners and roll
Rear fog light
94
controls
bars
89
Cruise control
94
Airbag deactivation
89
Vehicle detected ahead
94
Charging system
89
Door open
94
Malfunction indicator light
90
Information displays
95
Controls
77
Brake and clutch system
90
Driver Information Centre
95
Steering wheel adjustment
77
Operate pedal
90
Graphic-Info-Display, Colour-
Steering wheel controls
77
Electric parking brake
90
Info-Display
99
Heated steering wheel
77
Electric parking brake fault
91
Vehicle messages
101
Horn
78
Antilock brake system (ABS)
91
Warning chimes
102
Windscreen wiper/washer
78
Upshift
91
Battery voltage
103
Outside temperature
80
Power steering
91
Clock
80
Lane departure warning
91
Vehicle personalisation
103
Power outlets
82
Electronic Stability Control off . . . 92
OnStar
107
Cigarette lighter
82
Electronic Stability Control and
Ashtrays
83
Traction Control system
92
Warning lights, gauges and indi-
Traction Control system off
92
cators
83
Preheating
92
Instrument cluster
83
Diesel particle filter
92
Speedometer
83
AdBlue
92
Odometer
83
Tyre pressure monitoring
Trip odometer
84
system
93
Tachometer
84
Engine oil pressure
93
Fuel gauge
84
Low fuel
93
Engine coolant temperature
Immobiliser
93
gauge
85
Exterior light
94
Service display
85
High beam
94
Control indicators
86
High beam assist
94
Turn signal
88
Adaptive forward lighting
94

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Instruments and controls
77
Controls
Steering wheel controls
Heated steering wheel
Steering wheel adjustment
The Infotainment system, some driver
Activate heating by pressing *.
assistance systems and a connected
Activation is indicated by the LED in
Unlock lever, adjust steering wheel,
mobile phone can be operated via the
the button.
then engage lever and ensure it is
controls on the steering wheel.
fully locked.
Further information is available in the
Do not adjust steering wheel unless
Infotainment manual.
vehicle is stationary and steering
Driver assistance systems 3 157.
wheel lock has been released.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

78
Instruments and controls
The highlighted grip areas of the
Adjustable wiper interval
Windscreen wiper/washer
steering wheel are heated quicker
and to a higher temperature than the
Windscreen wiper
other areas.
Heating is operational when the
engine is running and during an
Autostop.
Stop-start system 3 138.
Horn
Wiper lever in position INT.
Turn the adjuster wheel to adjust the
HI
: fast
desired wipe interval:
LO
: slow
short interval
: turn adjuster
INT
: interval wiping
wheel upwards
or
long interval
: turn adjuster
automatic wiping with rain
wheel downwards
sensor
OFF : off
Press j.
For a single wipe when the
windscreen wiper is off, press the
lever down to position 1x.
Do not use if the windscreen is frozen.
Switch off in car washes.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Instruments and controls
79
Automatic wiping with rain sensor
Adjustable sensitivity of the rain
sensor
Keep the sensor free from dust, dirt
and ice.
INT : automatic wiping with rain
sensor
Turn the adjuster wheel to adjust the
Windscreen and headlight
sensitivity:
washer
The rain sensor detects the amount of
low sensitivity
: turn adjuster
water on the windscreen and
wheel downwards
automatically regulates the frequency
high sensitivity
: turn adjuster
of the windscreen wiper.
wheel upwards
If the wiper frequency is above
20 seconds, the wiper arm moves
slightly down to the park position.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

80
Instruments and controls
Pull lever. Washer fluid is sprayed
The illustration shows Graphic-Info-
If outside temperature drops to 3 °C,
onto the windscreen and the wiper
Display
a warning message is displayed in the
wipes a few times.
Driver Information Centre.
If the headlights are on, washer fluid
is also sprayed onto the headlights,
9 Warning
provided that the lever is pulled
sufficiently long. Afterwards, the
The road surface may already be
headlight washer system is
icy even though the display
inoperable for 5 wash cycles or until
indicates a few degrees above 0
engine or headlights have been
°C.
switched off and on again.
Clock
Outside temperature
Date and time are shown in the
Info-Display.
A drop in temperature is indicated
immediately and a rise in temperature
The illustration shows Colour-Info-
Time and date settings
after a time delay.
Display
CD 400plus/CD 400/CD 300
Press CONFIG. The menu Settings is
displayed.
Select Time Date.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Instruments and controls
81
the time. RDS time
Notice
synchronisation can take a few
If RDS Auto Time Adjust is activated,
minutes. Some transmitters do
time and date are automatically set
not send a correct time signal. In
by the system.
such cases, it is recommended to
See Infotainment manual for further
switch off automatic time
information.
synchronisation.
Set time
Vehicle personalisation 3 103.
To adjust the time settings, select the
Set Time menu item. Turn the
Time and date settings
multifunction knob to adjust the first
Navi 950/Navi 650/CD 600
setting.
Press Config then select the Time
Press the multifunction knob to
Selectable setting options:
and Date menu item to display the
confirm the input. The coloured
Set time:Changes the time
respective submenu.
background moves to the next
shown on the display.
setting.
Set date:Changes the date
Adjust all settings.
shown on the display.
Set date
Set time format: Changes
indication of hours between 12 h
To adjust the time settings, select the
and 24 h.
Set Date menu item. Turn the
multifunction knob to adjust the first
Set date format: Changes
setting.
indication of date between MM/
DD/YYYY and DD.MM.YYYY.
Press the multifunction knob to
confirm the input. The coloured
Display clock: Switches on/off
background moves to the next
indication of time on the display.
setting.
RDS clock synchronization: The
Adjust all settings.
RDS signal of most VHF
transmitters automatically sets

-------------------------------------------------------------------------------------------------------------------------------------------------------------

82
Instruments and controls
Time format
Do not connect any current-delivering
To choose the desired time format,
accessories, e.g. electrical charging
select 12 hr / 24 hr Format. Activate
devices or batteries.
12 Hour or 24 Hour.
Do not damage the outlet by using
Vehicle personalisation 3 103.
unsuitable plugs.
Stop-start system 3 138.
Power outlets
Cigarette lighter
A further 12 Volt power outlet is
located in the rear console. Fold the
cover downwards.
Do not exceed the maximum power
consumption of 120 watts.
With ignition off, the power outlets are
deactivated. Additionally the power
outlets are deactivated in the event of
A 12 Volt power outlet is located in the
low vehicle battery voltage.
front console.
The cigarette lighter is located in the
Electrical accessories that are
connected must comply with the
front console.
electromagnetic compatibility
Press in cigarette lighter. It switches
requirements laid down in
off automatically once the element is
DIN VDE 40 839.
glowing. Pull out lighter.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Instruments and controls
83
Ashtrays
Warning lights, gauges
Odometer
and indicators
Caution
Instrument cluster
To be used only for ash and not for
combustible rubbish.
In some versions, the needles of the
instruments briefly rotate to the end
position when the ignition is switched
on.
Speedometer
The bottom line displays the recorded
distance in miles.
The portable ashtray can be placed in
the cupholders.
Indicates vehicle speed.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

84
Instruments and controls
Trip odometer
Tachometer
Fuel gauge
W
displays the recorded distance
Displays the engine speed.
Displays the fuel level in the tank.
since the last reset.
Drive in a low engine speed range for
Control indicator i illuminates if the
Two trip odometer are selectable for
each gear as much as possible for
level in the tank is low. Refuel
different trips. Select between page
fuel saving reasons.
immediately if it flashes.
W1 and page
W2 by turning the
Never run the tank dry.
adjuster wheel on turn signal lever.
Caution
Because of the fuel remaining in the
Both trip odometer can be reset
tank, the top-up quantity may be less
If the needle is in the red warning
separately when ignition is on: select
than the specified tank capacity.
zone, the maximum permitted
respective page, press and hold the
engine speed is exceeded. Engine
reset knob for a few seconds or press
at risk.
SET/CLR on the turn signal lever.
Trip odometer counts up to a distance
of 2000 miles and then restarts at 0.
Driver Information Centre 3 95.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Instruments and controls
85
Engine coolant temperature
Caution
gauge
If engine coolant temperature is
too high, stop vehicle, switch off
engine. Danger to engine. Check
coolant level.
Service display
The engine oil life system lets you
know when to change the engine oil
and filter. Based on driving
conditions, the interval at which an
Press MENU to select the Vehicle
engine oil and filter change will be
Information Menu
X
indicated can vary considerably.
Turn the adjuster wheel to select
Displays the coolant temperature.
To display the remaining engine oil
Remaining Oil Life.
life duration use turn signal lever
left area
: engine operating
buttons:
temperature not yet
reached
central
: normal operating
area
temperature
right area
: temperature too high

-------------------------------------------------------------------------------------------------------------------------------------------------------------

86
Instruments and controls
The remaining engine oil life duration
Control indicators
is displayed in percent in the Driver
The control indicators described are
Information Centre.
not present in all vehicles. The
Reset
description applies to all instrument
versions. Depending on the
Press SET/CLR on turn signal lever
equipment, the position of the control
for several seconds to reset. The
indicators may vary. When the
remaining engine oil life duration
ignition is switched on, most control
page must be active. Switch on
indicators will illuminate briefly as a
ignition, but not the engine.
functionality test.
The system must be reset every time
The control indicator colours mean:
the engine oil is changed, to ensure
red
: danger, important reminder
proper functionality. Seek the
yellow : warning, information, fault
assistance of a workshop.
green
: confirmation of activation
blue
: confirmation of activation
Next service
white
: confirmation of activation
When the system has calculated that
engine oil life has diminished, a
warning message appears in the
Driver Information Centre. Have
engine oil and filter changed by a
workshop within one week or
300 miles (whichever occurs first).
Driver Information Centre 3 95.
Service information 3 233.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Instruments and controls
87
Control indicators in the instrument cluster

-------------------------------------------------------------------------------------------------------------------------------------------------------------

88
Instruments and controls
Control indicators in the centre
- Operate pedal 3 90
i Low fuel 3 93
console
m Electric parking brake 3 90
d Immobiliser 3 93
j
Electric parking brake fault
8
Exterior light 3 94
3 91
C High beam 3 94
u Antilock brake system (ABS)
l High beam assist 3 94
3 91
f
Adaptive forward lighting 3 94
R Upshift 3 91
> Fog light 3 94
c Power steering 3 91
r Rear fog light 3 94
)
Lane departure warning 3 91
m
Cruise control 3 94
a
Electronic Stability Control off
3 92
A Vehicle detected ahead 3 94
Overview
b
Electronic Stability Control and
h
Door open 3 94
O Turn signal 3 88
Traction Control system 3 92
X Seat belt reminder 3 89
k
Traction Control system off
Turn signal
3 92
v Airbag and belt tensioners and
O illuminates or flashes green.
roll bars 3 89
! Preheating 3 92
Illuminates briefly
V Airbag deactivation 3 89
% Diesel particle filter 3 92
The parking lights are switched on.
p Charging system 3 89
Y
AdBlue 3 92
Flashes
Z Malfunction indicator light
w
Tyre pressure monitoring
3 90
system 3 93
A turn signal or the hazard warning
flashers are activated.
R Brake and clutch system 3 90
I Engine oil pressure 3 93

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Instruments and controls
89
Rapid flashing: failure of a turn signal
Airbag, belt tensioners and
Airbag deactivation
light or associated fuse, failure of turn
roll bars
V illuminates yellow.
signal light on trailer.
v illuminates red.
The front passenger airbag is
Bulb replacement 3 195, Fuses
3 203.
When the ignition is switched on, the
activated.
control indicator illuminates for
* illuminates yellow.
Turn signals 3 120.
approx. 4 seconds. If it does not
The front passenger airbag is
illuminate, does not extinguish after
deactivated 3 61.
Seat belt reminder
4 seconds or illuminates whilst
driving, there is a fault in the airbag
9 Danger
Seat belt reminder on front seats
system, in the belt tensioner or the
deployable roll bars. The airbags, belt
X for driver's seat illuminates or
Risk of fatal injury for a child using
pretensioners and roll bars may fail to
flashes red.
a child restraint system together
trigger in the event of an accident.
k for front passenger seat illuminates
with activated front passenger
Deployment of the belt tensioners,
airbag.
or flashes red, when seat is occupied.
airbags or deployable roll bars is
Risk of fatal injury for an adult
Illuminates
indicated by continuous illumination
person with deactivated front
of v.
After the ignition has been switched
passenger airbag.
on until the seat belt has been
fastened.
9 Warning
Charging system
Flashes
Have the cause of the fault
p illuminates red.
After having started the engine for a
remedied immediately by a
Illuminates when the ignition is
maximum of 100 seconds until the
workshop.
switched on and extinguishes shortly
seat belt has been fastened.
after the engine starts.
Airbag system, belt tensioners 3 57,
3 54.
Rollover protection system 3 43.















Content      ..     3      4      5      6     ..
