Vauxhall Tigra (2009 year). Manual - part 11
Service and Maintenance
167
z Park vehicle in dry and well ventilated
Putting the vehicle back into
place. With manual transmission select
service
first gear or reverse gear, and with
Perform the following work before
Easytronic 3 move selector lever to
recommissioning the vehicle:
centre position before switching ignition
off. Use wedges or the like to prevent
z Connect the clamp to the negative
vehicle from rolling.
terminal of the vehicle battery.
z Do not apply handbrake.
z Check tyre pressure 3 122, 3 176.
z Disconnect the clamp from the negative
z Top up windscreen washer system 3 165.
terminal of the vehicle battery.
z Check engine oil level 3 160.
z Check coolant level 3 163.
z Fit the number plate if necessary.
168
Technical Data
Technical Data
Vehicle data
168
Engine data
170
Vehicle data
In other versions, the identification plate is
Performance
171
attached to the right-hand front door
Fuel consumption, CO2 emissions
The technical data is determined in
172
frame.
accordance with European Community
Weights, payload and roof load
174
standards. We reserve the right to make
Tyres
176
modifications. Specifications in the vehicle
Capacities
178
documents always have priority over those
Dimensions
179
given in this manual.
The identification plate is located on the
right MacPherson strut tower in the engine
compartment.
Technical Data
169
Information on identification plate:
The vehicle identification number is
On some versions, the VIN can also
stamped on the identification plate and on
be found on the instrument panel.
1
Manufacturer
the right side of the floor of the vehicle
2
Type approval number
Engine identifier and engine number:
under a cover between the front door and
3
Vehicle identification number
Marked on left-hand side of engine in
the seat.
engine block.
4
Gross vehicle weight rating
5
Permissible gross train weight
6
Maximum permissible front axle load
7
Maximum permissible rear axle load
8
Vehicle-specific or country-specific
data
170
Technical Data
Engine data
Sales designation
1.4 TWINPORT
1.8
1.3 CDTI
Engine identifier code
Z 14 XEP
Z 18 XE
Z 13 DT
Number of cylinders
4
4
4
Piston displacement [cm3]
1364
1796
1248
Engine power [kW]
66
92
51
at rpm
5600
6000
4000
Torque [Nm]
125
165
170
at rpm
4000
4600
1750 to 2500
Type of fuel1)
Petrol
Petrol
Petrol
Octane rating RON2)
recommended
95 3)
95 3)
-
possible
98 3)
98 3)
-
possible
91 3)4)
91 3)4)
-
Cetane number (CN)2)
-
-
49 (D)5)
Max. permissible engine speed,
continuous operation (rpm) approx.
6200
6500
5100 to 5300
Oil consumption [l/1000 km]
0.6
0.6
0.6
1) Standard quality fuel, e.g. unleaded DIN EN 228, diesel DIN EN 590.
2) Standard quality fuels: D = Diesel; bold type: recommended fuel.
3) Knock control system automatically adjusts ignition timing according to type of fuel used (octane number).
4) Slight reduction in engine output and torque if 91 RON is used.
5) A lower value is possible with winter diesel fuels.
Technical Data
171
Performance
Z 14 XEP
Z 18 XE
Z 13 DT
Maximum speed1) [mph / km/h]
Sports transmission
112/180
127/204
104/167
Easytronic
111/178
-
-
1) The maximum speed is achievable with a maximum of half payload. Optional equipment may reduce the specified maximum speed of the vehicle.
172
Technical Data
Fuel consumption, CO2 emissions
The directive is oriented to actual driving
The figures given must not be taken as a
practices: Urban driving is rated at
guarantee for the actual fuel consumption
Directive 80/1268/EEC (last amended
approx.1/3 and extra-urban driving at
of a particular vehicle.
by 2004/3/EC) has been applicable to
approx. 2/3 (urban and extra-urban
the measurement of fuel consumption
All values are based on the EU base model
consumption).
since 1996.
with standard equipment.
Cold starts and acceleration phases are
The calculation of fuel consumption as
also taken into consideration.
specified by directive 2004/3/EC takes
account of the vehicle’s kerb weight,
The specification of CO2 emission is also
ascertained in accordance with the
a constituent of the directive.
aforementioned regulation. Optional
extras may result in slightly higher fuel
consumption and CO2 emission levels than
those quoted.
To convert l/100 km into mpg, divide 282
by number of litres/100 km.
Saving fuel, protecting the environment
3 108
Technical Data
173
Fuel consumption, CO2 emissions
Z 14 XEP
Z 18 XE
Z 13 DT
Sports transmission/Easytronic
Fuel consumption
urban [l/100 km]
8.1/ 8.0
10.4/-
5.8/-
rural [l/100 km]
5.0/ 4.9
5.8/-
3.9/-
total [l/100 km]
6.1/ 6.0
7.5/-
4.6/-
CO2 [g/km]
146/144
179/-
124/-
174
Technical Data
Weights, payload and roof load
Optional equipment and accessories
Roof loads are not permitted.
increase the kerb weight, which means that
The payload is the difference between the
Driving hints 3 106.
the payload will also change slightly.
permitted gross vehicle weight (see
identification plate 3 168) and the EC kerb
Note weight ranges in the vehicle
weight.
documents and on the rating plate.
The combined total of front and rear axle
loads must not exceed the permissible
gross vehicle weight. For example, if the
front axle is bearing its maximum
permissible load, the rear axle can only
bear a load that is equal to the gross
vehicle weight minus the front axle load.
Technical Data
175
Kerb weight1)
Tigra retractable steel
Engine
Sport transmission
Easytronic
roof
without air
Z 14 XEP
1235
1235
conditioning [kg]
Z 18 XE
1265
-
Z 13 DT
1278
-
with air conditioning [kg] Z 14 XEP
1260
1260
Z 18 XE
1290
-
Z 13 DT
1303
-
with maximum
Z 14 XEP
1305
1305
equipment [kg]
Z 18 XE
1335
-
Z 13 DT
1348
-
1) According to EC Directive 70/156/EC, including assumed weights for driver (68 kg), luggage (7 kg) and all fluids (tank 90% full).
176
Technical Data
Tyres
Winter tyres 3
Wheels
Restrictions
Tyres of size 185/60 R 15, 205/50 R 16
Wheel bolt tightening torque: 110 Nm.
Not all tyres available on the market
and 205/45 R 17 must not be used as
currently meet the structural requirements.
winter tyres.
Spare wheel 3
We recommend that you consult a
Depending on design, the spare wheel is
If you use winter tyres 3, the spare wheel
Vauxhall Authorised Repairer concerning
designed as a temporary spare wheel 3.
may still be fitted with a summer tyre. If you
suitable tyre makes.
When using the spare wheel, the driving
use the spare wheel the vehicle’s handling
These tyres have undergone special tests
may be altered. Obtain a replacement for
characteristics may be modified. Replace
to establish their reliability, safety and
the faulty tyre as soon as possible, and
the faulty tyre as soon as possible, balance
specific suitability for Vauxhall vehicles.
have the wheel balanced and fitted to the
the wheel and refit to vehicle. Follow the
Despite continuous market monitoring, we
vehicle.
notes on this page and 3 125, 3 131.
are unable to assess these attributes for
On vehicles with alloy wheels 3, the spare
Further information 3 121.
other tyres, even if they have been granted
wheel may have a steel rim.
approval by the relevant authorities or in
Tyre chains 3
The spare wheel may be fitted with a
some other form.
Tyre chains are only permitted on the front
smaller tyre1) and smaller wheel than the
Further information 3 121.
wheels. Tyre chains must not be used on
wheels fitted to the vehicle.
the temporary spare wheel 3.
Tyre pressure2)
Always use fine mesh chains that add no
more than 10 mm to the tyre tread and the
The specified tyre pressures are valid for
inboard sides (including chain lock).
cold tyres. Increased tyre pressure resulting
from extensive driving should not be
Tyre chains are not permitted on tyres
reduced. The pressures specified on the
of size 185/60 R 15, 205/50 R 16 or
next page apply to both summer and
205/45 R 17.
winter tyres.
Further information 3 121.
Further information 3 121 to 3 125.
1) Country-specific version: In some countries,
the spare wheel may only be used as a
temporary spare wheel.
2) 1 bar corresponds to 100 kPa / 14.5 psi.
Technical Data
177
Tyre pressure
Tyre pressure for load with one person
Tyre pressure for full load
and light luggage
Tyres
Front [psi/bar]
Rear [psi/bar]
Front [psi/bar]
Rear [psi/bar]
Z 14 XEP,
185/55 R 15
36/2.5
36/2.5
36/2.5
36/2.5
Z 18 XE,
185/60 R 15,
33/2.3
30/2.1
33/2.3
30/2.1
Z 13 DT
205/50 R 16,
205/45 R 17
Spare wheel 3
185/55 R 15
36/2.5
178
Technical Data
Capacities
Engine oil
Engine
Z 14 XEP
Z 18 XE
Z 13 DT
Inc. Filter [litres]
3.5
4.25
3.2
Between MIN and MAX [litres]
1.0
1.0
1.0
Fuel tank
Petrol/diesel, nominal capacity [litres]
45
45
45
Technical Data
179
Dimensions
Tigra
Length [mm]
3921
Width without exterior mirrors [mm]
1684
Width with two exterior mirrors [mm]
1905
Height [mm]
1376
Wheelbase [mm]
2491
Turning circle diameter [m]
11.00
