338

Technical data

(ctd.)

Tyre pressure in bar / psi

1)





1)

1 bar corresponds to 100 kPa / 14.5 psi.

Hatch

Tyre pressure

for load of up to

3 persons

Tyre pressure ECO

1)

loaded with up to

3 people

Tyre pressure for

full load

Engine

2)

Tyres

Front

Rear

Front

Rear

Front

Rear

Z 14 XEP

185/65 R 15,

195/60 R 15

2.3/33

2.1/30

–

–

2.5/36

2.9/42

195/65 R 15,

205/55 R 16

2.0/29

2.0/29

2.5/36

2.5/36

2.1/30

2.5/36

Z 16 XER

185/65 R 15,

195/60 R 15,

215/45 R 17,

225/40 R 18

2.3/33

2.1/30

–

–

2.5/36

2.9/42

195/65 R 15,

205/55 R 16,

225/45 R 17

2.0/29

2.0/29

2.5/36

2.5/36

2.1/30

2.5/36

Z 16 LET

205/55 R 16,

225/45 R 17

2.3/33

2.1/30

2.7/39

2.5/36

2.5/36

2.9/42

215/45 R 17,

225/40 R 18

2.7/39

2.5/36

–

–

2.8/41

3.1/45

all

T 115/70 R 16

(temporary spare)

3)

4.2/61

4.2/61

–

–

4.2/61

4.2/61

1)

To achieve the smallest amount of fuel consumption possible. Not for use with run-flat tyres.

2)

Sales designation, see pages 310 and 311.

3)

For notes on the temporary spare wheel, see page 250.

339

Technical data

(ctd.)

Tyre pressure in bar / psi

1)



1)

1 bar corresponds to 100 kPa / 14.5 psi.

Hatch

Tyre pressure

for load of up to

3 persons

Tyre pressure

ECO

1)

loaded with

up to 3 people

Tyre pressure for

full load

Engine

2)

Tyres

Front

Rear

Front

Rear

Front

Rear

Z 18 XER

185/65 R 15,

195/60 R 15,

215/45 R 17,

225/40 R 18

2.3/33

2.1/30

–

–

2.5/36

2.9/42

195/65 R 15,

205/55 R 16

2.0/29

2.0/29

2.5/36

2.5/36

2.1/30

2.5/36

225/45 R 17

2.3/33

2.1/30

2.7/39

2.5/36

2.5/36

2.9/42

Z 20 LEH

205/50 R 17

3)

,

225/40 ZR 18,

235/35 ZR 19,

225/45 R 17

4)

2.4/35

2.4/35

–

–

2.5/36

2.9/42

all

T 115/70 R 16

(temporary spare)

5)

4.2/61

4.2/61

–

–

4.2/61

4.2/61

1)

To achieve the smallest amount of fuel consumption possible. Not for use with run-flat tyres.

2)

Sales designation, see pages 310 and 311.

3)



Only permitted as winter tyres.

4)

To guarantee a correct speed display, the electronic speedometer must be reprogrammed.

5)

For notes on the temporary spare wheel, see page 250.

340

Technical data

(ctd.)

Tyre pressure in bar / psi

1)



1)

1 bar corresponds to 100 kPa / 14.5 psi.

Hatch

Tyre pressure

for load of up to

3 persons

Tyre pressure

ECO

1)

loaded with

up to 3 people

Tyre pressure for

full load

Engine

2)

Tyres

Front

Rear

Front

Rear

Front

Rear

Z 17 DTH

195/65 R 15,

205/55 R 16,

225/45 R 17

2.1/30

2.1/30

2.5/36

2.5/36

2.5/36

2.9/42

215/45 R 17,

225/40 R 18

2.5/36

2.3/33

–

–

2.6/38

3.0/44

Z 19 DT,

Z 19 DTH

205/55 R 16,

225/45 R 17

2.3/33

2.1/30

2.7/39

2.5/36

2.5/36

2.9/42

215/45 R 17,

225/40 R 18

2.7/39

2.5/36

–

–

2.8/41

3.1/45

all

T 115/70 R 16

(temporary spare)

3)

4.2/61

4.2/61

–

–

4.2/61

4.2/61

1)

To achieve the smallest amount of fuel consumption possible. Not for use with run-flat tyres.

2)

Sales designation, see pages 310 and 311.

3)

For notes on the temporary spare wheel, see page 250.

341

Technical data

(ctd.)

Tyre pressure in bar / psi

1)



1)

1 bar corresponds to 100 kPa / 14.5 psi.

Estate

Tyre pressure

for load of up to

3 persons

Tyre pressure

ECO

1)

loaded with

up to 3 people

Tyre pressure for

full load

Engine

2)

Tyres

Front

Rear

Front

Rear

Front

Rear

Z 14 XEP

195/65 R 15,

205/55 R 16

2.0/29

2.0/29

2.5/36

2.5/36

2.1/30

2.6/38

185/65 R 15,

195/60 R 15

2.3/33

2.1/30

–

–

2.5/36

2.9/42

Z 16 XER

195/65 R 15,

205/55 R 16,

225/45 R 17

2.0/29

2.0/29

2.5/36

2.5/36

2.1/30

2.6/38

185/65 R 15,

195/60 R 15,

215/45 R 17,

225/40 R 18

2.3/33

2.1/30

–

–

2.5/36

2.9/42

Z 16 LET

205/55 R 16,

225/45 R 17

2.3/33

2.1/30

2.7/39

2.5/36

2.5/36

2.9/42

215/45 R 17,

225/40 R 18

2.7/39

2.5/36

–

–

2.8/41

3.1/45

all

T 115/70 R 16

(temporary spare)

3)

4.2/61

4.2/61

–

–

4.2/61

4.2/61

1)

To achieve the smallest amount of fuel consumption possible. Not for use with run-flat tyres.

2)

Sales designation, see pages 310 and 311.

3)

For notes on the temporary spare wheel, see page 250.

342

Technical data

(ctd.)

Tyre pressure in bar / psi

1)

1)

1 bar corresponds to 100 kPa / 14.5 psi.

Estate

Tyre pressure

for load of up to

3 persons

Tyre pressure

ECO

1)

loaded with

up to 3 people

Tyre pressure for

full load

Engine

2)

Tyres

Front

Rear

Front

Rear

Front

Rear

Z 18 XER

195/65 R 15,

205/55 R 16,

225/45 R 17

2.0/29

2.0/29

2.5/36

2.5/36

2.1/30

2.6/38

185/65 R 15,

195/60 R 15,

215/45 R 17,

225/40 R 18

2.3/33

2.1/30

–

–

2.5/36

2.9/42

Z 17 DTH

195/65 R 15

3)

,

205/55 R 16,

225/45 R 17

2.1/30

2.1/30

2.5/36

2.5/36

2.5/36

2.9/42

215/45 R 17,

225/40 R 18

2.5/36

2.3/33

–

–

2.6/38

3.0/44

Z 19 DT,

Z 19 DTH

205/55 R 16,

225/45 R 17

2.3/33

2.1/30

2.7/39

2.5/36

2.5/36

2.9/42

215/45 R 17,

225/40 R 18

2.7/39

2.5/36

–

–

2.8/41

3.1/45

all

T 115/70 R 16

(temporary spare)

3)

4.2/61

4.2/61

–

–

4.2/61

4.2/61

1)

To achieve the smallest amount of fuel consumption possible. Not for use with run-flat tyres.

2)

Sales designation, see pages 310 and 311.

3)

For notes on the temporary spare wheel, see page 250.

343

Technical data

(ctd.)

Tyre pressure in bar / psi

1)



1)

1 bar corresponds to 100 kPa / 14.5 psi.

Van

Tyre pressure

for load of up to

3 persons

Tyre pressure

ECO

1)

loaded with

up to 2 people

Tyre pressure for

full load

Engine

2)

Tyres

Front

Rear

Front

Rear

Front

Rear

Z 14 XEP

195/65 R 15,

205/55 R 16

2.0/29

2.0/29

2.5/36

2.5/36

2.1/30

2.6/38

185/65 R 15,

195/60 R 15

2.3/33

2.1/30

–

–

2.5/36

2.9/42

Z 17 DTH

195/65 R 15,

205/55 R 16,

225/45 R 17

2.1/30

2.1/30

2.5/36

2.5/36

2.5/36

2.9/42

215/45 R 17,

225/40 R 18

2.5/36

2.3/33

–

–

2.6/38

3.0/44

Z 19 DT,

Z 19 DTH

205/55 R 16,

225/45 R 17

2.3/33

2.1/30

2.7/39

2.5/36

2.5/36

2.9/42

215/45 R 17,

225/40 R 18

2.7/39

2.5/36

–

–

2.8/41

3.1/45

all

T 115/70 R 16

(temporary spare)

3)

4.2/61

4.2/61

–

–

4.2/61

4.2/61

1)

To achieve the smallest amount of fuel consumption possible. Not for use with run-flat tyres.

2)

Sales designation, see pages 310 and 311.

3)

For notes on the temporary spare wheel, see page 250.

344

Technical data

(ctd.)

Tyre pressure in bar / psi

1)



1)

1 bar corresponds to 100 kPa / 14.5 psi.

TwinTop

Tyre pressure

for load of up to

3 persons

Tyre pressure

ECO

1)

loaded with

up to 3 people

Tyre pressure for

full load

Engine

2)

Tyres

Front

Rear

Front

Rear

Front

Rear

Z 16 XER,

Z 18 XER

205/55 R 16,

225/45 R 17

2.1/30

2.1/30

2.5/36

2.5/36

2.2/32

2.6/38

225/40 R 18

2.3/33

2.1/30

–

–

2.4/35

2.8/41

Z 16 LET

205/55 R 16,

225/45 R 17

2.3/33

2.1/30

–

–

2.4/35

2.8/41

225/40 R 18

2.5/36

2.3/33

–

–

2.6/38

3.0/44

Z 19 DTH

205/55 R 16,

225/45 R 17

2.3/33

2.1/30

–

–

2.4/35

2.8/41

225/40 R 18

2.5/36

2.3/33

–

–

2.6/38

3.0/44

all

T 115/70 R 16

(temporary spare)

3)

4.2/61

4.2/61

–

–

4.2/61

4.2/61

1)

To achieve the smallest amount of fuel consumption possible. Not for use with run-flat tyres.

2)

Sales designation, see pages 310 and 311.

3)

For notes on the temporary spare wheel, see page 250.

345

Technical data

Electrical system

Battery

Voltage

12 Volt

Amp hours

36 Ah / 44 Ah 3 / 55 Ah 3 / 60 Ah 3 /

66 Ah 3 / 70 Ah 3 / 72 Ah 3

Battery for remote control of central locking

system and electronic key of Open&Start system CR 20 32

346

Technical data

Capacities

(approx. litres)

Engine

1)

1)

Sales designation, see pages 310 and 311.

Z 14 XEP

 Z 16 XER

Z 16 LET

Z 18 XER

Fuel tank (nominal content)

52

52

52

52

Engine oil with filter change

between MIN and MAX on oil dipstick

3.5

1.0

4.5

1.0

4.5

1.0

4.5

1.0

Container for windscreen wash system

with headlight wash system

2.4

4.0

2.4

4.0

2.4

4.0

2.4

4.0

Engine

1)

Z 17 DTH

Z 19 DT

Z 19 DTH

Fuel tank (nominal content)

52

52

52

Engine oil with filter change

between MIN and MAX on oil dipstick

5.0

1.0

4.3

1.0

4.3

1.0

Container for windscreen wash system

with headlight wash system

2.4

4.0

2.4

4.0

2.4

4.0

347

Technical data

Dimensions

(approx. mm)

Hatch 5-door

Hatch 3-door

Estate

Van

TwinTop

Overall length

4249

4290

4515

4515

4476

Width 1753

1753

1753

1753

1759

Width with two exterior mirrors

2032

2032

2032

2032

2021

Overall height

1)

1)

kerbweight with driver.

1460

1435

1500

1500

1411

Length of luggage compartment floor

819

819

1085

1825

805

Luggage compartment width

944

944

1088

1103

734

Height of luggage compartment opening

614

555

766

775

–

Wheelbase

2614

2614

2703

2703

2614

Turning circle diameter

2)



2)

In metres.

11.20

11.20

11.50

11.50

11.20

348

Technical data

Installation dimensions of

trailer towing equipment

with detachable coupling ball

bar, Hatch

1)



All dimensions refer to factory-fitted

towing equipment.

1)

Do not mount towing equipment to vehicles

with Z 20 LEH engine. Sales designation,

see page 310.

Dimension

mm

A

342.9

B

83

C

513.4

D

488.6

E

211.4

F

94.3

G

160

9

 Warning

Only use towing equipment approved for

your vehicle. We recommend entrusting

fitting of towing equipment at a later

date to a workshop.

349

Technical data

Installation dimensions of

trailer towing equipment

with detachable coupling ball

bar, Estate, Van

All dimensions refer to factory-fitted

towing equipment.
Dimension

mm

A

84.0

B

570.0

C

515.0

D

93.5

E

173.0

F

307.6

G

158.0

H

292.6

9

 Warning

Only use towing equipment approved for

your vehicle. We recommend entrusting

fitting of towing equipment at a later

date to a workshop.

350

Technical data

Installation dimensions of

towing equipment

with detachable coupling ball

bar, Astra TwinTop

All measurements refer to Vauxhall-

approved towing equipment.
Dimension

mm

A

68.8

B

570.0

C

515.0

D

485.0

E

93.5

F

288.0

G

245.0

9

 Warning

Only use towing equipment approved for

your vehicle. We recommend entrusting

fitting of towing equipment at a later

date to a workshop.

352

Index

Index

A

ABS (Anti-lock Brake System) ...............  224
Accessories....................................... 90, 247
Accessory socket ...................................  107
ActiveSelect..............................................  16
Adaptive Forward Lighting (AFL) .. 26, 147

Bulb replacement...............................  273
Driving abroad...................................  150

Air conditioning system................. 154, 161
Air intake ................................................  174
Air quality sensor...................................  169
Air recirculation system........  161, 165, 173
Air vents .................................................  156
Airbags .....................................................  92
Alarm system ...........................................  46
Alternator ...............................................  115
Antenna.................................  140, 151, 289
Anti-dazzle interior mirror.......................  51
Antifreeze....................................... 300, 301
Antifreeze protection .................... 301, 305
Anti-knock quality of fuel......................  202
Anti-theft locking system ........................  41

Towing equipment.............................  235

Anti-theft protection ...............................  18
Aquaplaning ..........................................  230
Armrest............................................. 70, 110
Ashtray ........................................... 108, 150
Aspherical exterior mirror .......................  49
Automatic air recirculation mode  169, 173
Automatic anti-dazzle interior mirror ....  51

Automatic transmission ....................  15, 16

Automatic mode........................ 184, 191
Control indicator........................ 185, 192
Driving programme ................... 185, 192
Fault............................................ 188, 196
Interruption of power supply .... 189, 197
Kickdown.................................... 187, 194
Manual mode.....................................  192
Selector lever.........  15, 16, 184, 191, 192
Winter programme .................... 186, 193

Automatic transmission

with ActiveSelect....................................  16

Automatic wiping ............................  12, 141

B

Battery.................................... 199, 306, 345

Interruption of
power supply...................... 183, 189, 197

Battery discharge protection ...............  150
Before starting off ...................................  16
Belt force limiters.....................................  86
Belt tensioners .........................................  86
Bleeding, diesel fuel system..................  241
Board information display............ 122, 128
Bonnet ....................................................  241
Boot, see Luggage compartment....  44, 71
Brake assist ............................................  223
Brake fluid..............................................  309
Brake system..........................................  222

Brakes

ABS .....................................................  224
Brake assist ........................................  223
Brake fluid..........................................  302
Brake lights ................................  277, 283
Brake servo unit.................................  198
Footbrake...........................................  223
Handbrake.........................................  224

Bulb replacement ..........................  267, 269
Bulbs...............................................  267, 269

C

Capacities ..............................................  346
Car Pass ...................................................  30
Caravan/trailer towing..................  198, 237
Cargo box ................................................  81
Catalytic converter........................  209, 242
CDC (Continuous Damping Control) ..  115,

211

Central locking system............................  40
Cetane numbers....................................  311
Changing the battery

Remote control ............................  34, 345

Changing tyre/wheel type ....................  225
Changing wheels...................................  252
Chassis number, see vehicle identification

number.................................................  309

Check control...................................  22, 138
Child restraint system .............................  90
Child safety locks ........................  49, 52, 53
Cigarette lighter ............................  107, 150
Climate control ......................................  154
Climate control system .................  155, 168
Clock.......................................................  120

353

Index

Clutch operation ....................................  199
CO2 emissions........................................  316
Cold start................................................  199
Colour information display ..  122, 130, 134
Continuous Damping

Control (CDC)............................... 115, 211

Contrast..................................................  133
Control indicators .................... 10, 112, 113

ABS (Anti-lock Brake System) ...........  225
Adaptive Forward Lighting (AFL) ... 118,
147
Airbag........................................... 98, 105
Belt tensioners......................................  87
Brake system ......................................  224
Cruise control .....................................  214
DDS .....................................................  219
Deflation detection system ...............  219
Engine electronics ..............................  206
ESP (Electronic Stability Program)....  210
Exhaust ...............................................  206
IDS+ ............................................. 212, 213
Immobiliser ...........................................  31
Parking distance sensor ....................  216
Transmission .............................. 185, 192
Tyre pressure monitoring system .....  221

Coolant........................................... 300, 309
Coolant level ..........................................  301
Coolant temperature.............................  115
Cooled glove compartment..................  156
Cooling ........................................... 162, 167
Correcting time .............................. 126, 132
Coupling socket load.............................  238

Courtesy light.........................................  148

Bulb replacement ..............................  287

Cruise control.........................................  213
Curtain airbags........................................  97
Curve lighting ..................................  26, 147

D

Dashboard, see Instrument panel ...........  7
Data..................................................  30, 308
Date................................................ 124, 127
Daytime running lights..........................  143
Decommissioning ..................................  307
Deflation detection system (DDS)..  25, 218
Demisting and defrosting

Windows.............................................  160
With climate control system .............  171
With the air conditioning
system......................................... 163, 167

Diesel ......................................................  311
Diesel fuel filter ......................................  300
Diesel fuel system .......................... 241, 300
Diesel particle filter................ 118, 157, 199
Dimensions.............................................  347
Dipped beam...........................................  11

Bulb replacement ...................... 270, 273

Display............................................ 121, 122
Documents.............................................  308
Door handle lighting .............................  149
Door locks ........................................  30, 291
Doors ......................................................  115
Door-to-door light function ..................  148
Driving abroad .............................. 202, 295

Headlights..........................................  150

Driving hints...........................................  198

E

Easy Load ................................................  82
Easytronic ................................................  15

Driving programmes .........................  179
Fault ...................................................  182
Interruption of power supply............  183
Kickdown............................................  180
Selector lever........................................  15
Starting off.........................................  178
Winter programme............................  180

Economical driving................................  200
Electric sunroof ........................................  54
Electrical exterior mirrors ........................... 6
Electrical system ............................  306, 345
Electro-hydraulic

power assisted steering ......................  198

Electronic components..........................  306
Electronic immobiliser .............................  31
Electronic Stability Program .................  210
Engine code ........................... 309, 310, 311
Engine control indicator .......................  206
Engine data ...................................  310, 311
Engine oil ...............................................  298
Engine oil change..................................  299
Engine oil consumption ........................  298
Engine oil filter.......................................  300
Engine oil level...............................  116, 298
Engine oil pressure ................................  113
Engine speed .........................................  199
Engine wash...........................................  292
Entry lighting .........................................  149
Environmental protection .....................  300
ESP (Electronic Stability Program) .......  210

354

Index

Exhaust control indicator......................  206
Exhaust gases ........................................  207
Exhaust system ......................................  207
Exterior lights ................................. 116, 143
Exterior mirrors............................. 6, 49, 157

F

Fan.................................................. 158, 297
Filling station

Capacities...........................................  346
Engine oil level ...................................  298
Fuel ....................................  202, 310, 311
Opening the bonnet ..........................  241
Tyre pressure.............................. 201, 337
Vehicle data .......................................  309
Windscreen wash system ..................  305

First-aid kit (cushion).............................  247
Flat tyre ..................................................  256
FlexOrganizer ..........................................  80
Fog lights................................................  145

Bulb replacement...............................  276

Fog tail light...........................................  145

Bulb replacement....................... 277, 283

Folding roof, see TwinTop ......................  56
Folding the backrest ...............................  66
Footbrake...............................................  223
Front airbags ...........................................  93
Front passenger airbag ..........................  93
Fuel ........................................  202, 310, 311
Fuel consumption . 200, 202, 316, 321, 324
Fuel filler cap..........................................  203
Fuel filter.................................................  300
Fuel gauge .............................................  119
Fuel level.................................................  119

Fuel system, diesel.................................  241
Fuse extractor........................................  261
Fuses.......................................................  259

G

Gears ........................................................  14
Generator, see Alternator.....................  115
Genuine Vauxhall Parts

and Accessories...................................  297

Glasses compartment ...........................  111
Glove compartment ..............................  110

Cooled ................................................  156

Glove compartment lighting ................  149

Bulb replacement ..............................  288

Graphical information

display .................................. 122, 130, 134

Gross vehicle weight..............................  325
Gross vehicle weight rating ..................  325

H

Halogen headlight system ...................  269

Bulb replacement ..............................  269
Driving abroad...................................  150

Handbrake.......................................  18, 224
Hazard warning lights ....................  11, 146
Head restraints..................................  21, 69
Head rests................................................  21
Headlight flash ......................................  144
Headlight range adjustment........ 146, 269
Headlight switch........................ 7, 143, 144
Headlight wash system........... 13, 142, 305

Headlights .................................................. 7

Daytime running lights......................  143
Driving abroad ..................................  150
Fog lights ...........................................  145
Reverse lights.....................................  145
Warning device..................................  140

Heated exterior mirrors ..................  13, 157
Heated front seats ................................  157
Heated rear window .......................  13, 157
Heating ..........................................  154, 159

Seats...................................................  157
With climate control system .............  170
with the air conditioning
system ........................................  163, 167

Height adjustment

Seat belts .............................................  88
Steering wheel ........................................ 7

High-pressure cleaners ......... 236, 291, 293
Hill Start Assist.......................................  223
Horn..........................................................  12

I

Identification plate................................  308
IDS+ (Interactive Driving System).  209, 211
Ignition logic ..................................  127, 134
Ignition system ..............................  297, 306
Ignition, see Starter switch ...................  6, 7
Immobiliser ..............................................  31
Information display...............................  122
Infotainment system .............................  151
Inspection system..................................  296
Instrument display ................................  119
