290

Self-help, vehicle care

Clean edges and folds on opened doors

and flaps as well as the areas they cover.
Thoroughly rinse off and leather-off the

vehicle. Rinse leather frequently. Use

separate leathers for paint and window

surfaces: remnants of wax on the windows

will impair vision.
Observe national regulations.
Waxing

Wax your vehicle regularly, in particular

after it has been washed using shampoo

and at the latest when water no longer

forms beads on the paintwork, otherwise

the paintwork will dry out.
Also wax edges and folds on opened doors

and flaps as well as the areas they cover.

Polishing

Polishing is necessary only if the paint has

become dull or if solid deposits have

become attached to it.
Paintwork polish with silicone forms a

protective film, making waxing

unnecessary.
Plastic body parts should not be treated

with wax and polish.
Use Metallic Paintwork Wax on vehicles

with a metallic-effect paint finish.
Sunroof 3

Never clean with solvents or abrasive

agents, fuels, aggressive media (e.g. paint

cleaner, acetone-containing solutions etc.),

acidic or highly alkaline media or abrasive

pads.
No stickers may be applied to the sunroof.
Wheels

Use a pH-neutral wheel cleaning agent to

clean the wheels.
Wheels are painted and can be treated

with the same agents as the body. For alloy

wheels we recommend use of Alloy Wheel

Preserver.

Paintwork damage

Repair minor paintwork damage such as

stone chips, scratches etc. immediately

using the touch-up pen or spray before rust

forms. If rust has already formed, have a

workshop eliminate the cause. Also check

the surfaces and edges facing the road

surface on which rust may have developed

unnoticed for some time.
Exterior lights

Headlight and other protective light bezels

are made of plastic. If they require

additional cleaning after the vehicle has

been washed, clean them with Car

Shampoo. Do not use any abrasive or

caustic agents, do not use an ice scraper,

and do not clean them dry.

291

Self-help, vehicle care

Plastic and rubber parts

For additional cleaning of plastic and

rubber parts use Cleaner. Do not use any

other agent, and in particular do not use

solvents or petrol.
Do not use high-pressure jet cleaners.
Wheels and tyres

Do not use high-pressure jet cleaners.
Interior and upholstery

Clean the vehicle interior, including the

instrument panel fascia, using interior

cleaner.
The instrument panel should only be

cleaned using a soft damp cloth.
Clean fabric upholstery with a vacuum

cleaner and brush. To remove stains, use

cleaner that is suitable for both fabrics and

vinyl.
Do not use cleaning agents such as

acetone, tetrachloride, paint thinner, paint

remover, nail varnish remover, washing

powder or bleach. Petrol is also unsuitable.

Open Velcro fasteners on clothing could

damage seat upholstery. Make sure Velcro

fasteners are closed.
Seat belts

Always keep seat belts clean and dry.
Clean only with lukewarm water or Cleaner.
Windows

When cleaning the heated rear window,

make sure that the heating element on the

inside of the window is not damaged.
Use a soft lint-free cloth or chamois leather

in conjunction with Window Cleaner and

Insect Remover.
Windscreen Wash Solvent is suitable for de-

icing windows.
For mechanical removal of ice, use a

commercially available sharp-edged ice

scraper. Press the scraper firmly against

the glass so that no dirt can get under it

and scratch the glass.

Windscreen wiper blades

Wax, such as that used in car washes, can

cause streaks to form on the windscreen

when the wiper is used.
Smearing wiper blades can be cleaned with

a soft cloth and Vauxhall Windscreen

Wash Solvent, and replaced if necessary,

see page 303.
Locks

The locks are factory-lubricated with a high

quality lock cylinder grease. This prevents

the locks from freezing. Only use de-icer in

urgent cases as this destroys the grease

and damages the function of the locks.

After using de-icer, have a workshop

regrease the locks.

292

Self-help, vehicle care

Engine compartment

Areas of the engine compartment that are

painted in the same colour as the vehicle

must be looked after like any other painted

surface.
It is advisable to wash the engine

compartment before and after winter and

preserve it with wax. Cover alternator and

brake fluid reservoir with plastic sheets

before washing the engine.
When washing the engine with a steam-jet

cleaner, do not direct the steam jet at

components of the anti-lock brake system,

the air conditioning system, the climate

control system or the belt drive and its

components.

Engine washing also removes subsequently

applied protective wax. Therefore after

washing, have a workshop protect the

engine, parts of the braking system in the

engine bay, axle elements with steering,

body elements and cavities, thoroughly

with protective wax.
An engine wash can be performed in the

spring in order to remove dirt that has

adhered to the engine compartment,

which may also have a high salt content.

Check protective wax layer and make good

if necessary.
Do not use high-pressure jet cleaners.

Underbody

PVC underbody protection is applied in the

factory in the areas that are affected by

wheel spray, including the longitudinal

sides of the underbody. This provides long-

term protection and does not require

special maintenance.
The areas of the vehicle underbody that

are not covered with PVC have a

permanent protective wax coating in

critical areas.
On vehicles which are washed frequently in

automatic car washes with underbody

washing facility, the protective wax

coating may be impaired by dirt-dissolving

additives.

293

Self-help, vehicle care

Check the underbody after washing and

have it waxed if necessary. Before the start

of the cold weather season, check the PVC

coating and protective wax coating. Have

them restored to perfect condition if

necessary.
Caution – commercially available bitumen/

rubber materials can damage the PVC

coating. We recommend that you have

underbody work carried out by a

workshop, who knows the prescribed

materials and has experience in the use

thereof.
The underbody should be washed

following the end of the cold weather

season to remove any dirt adhering to the

underbody since this may also contain salt.

Check protective wax coating and, if

necessary, have it restored to perfect

condition.

Astra TwinTop

Treat all seals, e. g. on the roof and

windscreen frame, with silicone oil from

time to time. Good contact between the

fine rubber lips and the sealing surfaces

prevents leaks and reduces clamping

forces.
The roof can be held in an intermediate

position for about 9 minutes by releasing

the operating switch in order to clean roof

spaces.
Intermediate roof position for cleaning –

see page 58.
Do not use high-pressure jet cleaners.

294

Service, maintenance

Service, maintenance

In our experience, the most common cause

of all complaints is the result of

misunderstanding or lack of

communication between the customer and

the Vauxhall Authorised Repairer.
We sincerely hope you will never have

cause to complain about your vehicle.

However, if things do go wrong, the best

course of action for you to take is to

contact your Vauxhall Authorised

Repairer’s Service Reception Staff and

explain the difficulty you are having. We

are confident they will do their utmost to

resolve the problem to your complete

satisfaction.
Sometimes, however, despite the best of

intentions of all concerned,

misunderstandings can occur. If your

problem has not been resolved to your

satisfaction, please make an appointment

to discuss the matter with the Manager of

the department concerned.
The majority of areas of concern can be

quickly resolved in this way.
Should you wish to pursue the matter

further, the Principal of the Vauxhall

Authorised Repairer should be made

aware of your concern. It is advisable in

cases such as this to write to him to confirm

your problem and the solutions that have

been offered.
You can be assured the Authorised

Repairer’s Principal will only be too anxious

to fully investigate your problems and

correct any errors made. After all, he has a

large investment in his business and is

proud of his reputation and

professionalism and fully realises that

satisfied customers are his key to success.
In the unlikely event that you are still not

happy with the answer your Vauxhall

Authorised Repairer has given, or the

action he proposes to correct the problem,

you may contact the Customer Care

Department

1)

 where a team of Customer

Care Consultants will spare no effort to

ensure your complete satisfaction.
Vauxhall Motors Ltd.

Customer Care,

Griffin House,

Osborne Road

LUTON,

Beds., LU1 3YT

Telephone: 0845 090 2044
They will review all the facts involved. Then

if it is felt some further action can be taken,

the Vauxhall Authorised Repairer will be

advised accordingly. In any case, your

contact will be acknowledged confirming

Vauxhall Motors’ position in the matter.
If you are not satisfied with the outcome,

you can if you wish, seek advice from an

independent third party such as:
Automobile Association (A.A.)

Fanum House, Basing View,

BASINGSTOKE,

Hants., RG21 4EA

Service, maintenance ..........................  294
Inspection system ................................  296
Genuine Vauxhall Parts and

Accessories ........................................ 297

A note on safety ..................................  297
Checking and topping up fluids.........  298
Engine oil..............................................  298
Diesel fuel filter ....................................  300
Coolant................................................. 300
Brake fluid ............................................  302
Windscreen wiper ................................  303
Windscreen and headlight wash

systems 3........................................... 305

Battery.................................................. 306
Protecting electronic components .....  306
Vehicle decommissioning....................  307
Vehicle recommissioning.....................  307

1)

Calls may be monitored and recorded for

training purposes.

295

Service, maintenance

Royal Automobile Club (R.A.C.),

R.A.C. Motoring Services Ltd..

89-91 Pall Mall,

LONDON, SW1Y 5HS
The Customer Relations Department,

Society of Motor Manufacturers and

Traders Ltd. (S.M.M.T.),

Forbes House, Halkin Street,

LONDON, SW1X 7DS
Customer Complaints Service,

Scottish Motor Trade Association,

(S.M.T.A.),

3 Palmerston Place,

EDINBURGH, EH12 5AQ
The National Conciliation Service,

Retail Motor Industry Federation,

9 North Street,

RUBGY, CV21 2AB
If you have a problem whilst abroad:

The Service Departments of ADAM OPEL

GmbH and General Motors branches

everywhere will provide information and

assistance:
In Luxembourg please contact the

General Motors Service Department in

Antwerp – Belgium

Telephone: 00 32-34 50 63 29
General Motors Austria GmbH

Groß-Enzersdorfer Str. 59

1220 Vienna – Austria

Tel. 00 43-1-2 88 77 444 or

00 43-1-2 88 77 0

General Motors Belgium N.V.

Noordelaan 401 - Haven 500

2030 Antwerp – Belgium

Tel. 00 32-34 50 63 29
General Motors Southeast Europe

org. složka

Olbrachtova 9

140 00 Prague – Czech Republic

Tel. 00 420-2 39 004 321
General Motors Danmark

Jaegersborg Alle 4

2920 Charlottenlund – Denmark

Tel. 00 45-39 97 85 00
Vauxhall Motors Ltd.

Customer Care

Griffin House, Osborne Road

Luton, Bedfordshire, LU1 3YT – England

Tel. 00 44-845 090 2044
General Motors Finland Oy

Pajuniityntie 5

00320 Helsinki – Finland

Tel. 00 358-9 817 101 47
General Motors France

1 – 9, avenue du Marais

Angle Quai de Bezons

95101 Argenteuil Cedex – France

Tel. 00 33-1-34 26 30 51
ADAM OPEL GmbH

Bahnhofsplatz 1

65423 Rüsselsheim – Germany

Tel. 00 49-61 42-77 50 00 or

00 49-61 42-7 70

General Motors Hellas S.A.

56 Kifisias Avenue & Delfon str.

Amarousion

151 25 Athens – Greece

Tel. 00 30-1-6 80 65 01
General Motors Southeast Europe Ltd.

Szabadsag utca 117

2040 Budaörs – Hungary

Tel. 00 36-23 446 100
General Motors India

Sixth Floor, Tower A

Global Business Park

Mehrauli – Gurgaon Road

Gurgaon 122 022, Haryana – India

Tel. 00 91-124 280 3333
General Motors Ireland Ltd.

Opel House, Unit 60, Heather Road

Sandyford, Dublin 18 – Ireland

Tel. 00 353 1-216 10 00
General Motors Italia Srl

Piazzale dell’Industria 40

00144 Rome – Italy

Tel. 00 39-06-5 46 51
General Motors Nederland B.V.

Lage Mosten 49 – 63

4822 NK Breda – Netherlands

Tel. 00 31-76-5 44 83 00
General Motors Norge AS

Kjeller-Vest 6

2027 Kjeller – Norway

Tel. 00 47-23 50 01 04
General Motors Poland Sp. z o. o.

Wołoska 5

06-675 Warsaw – Poland

Telephone 00 48-22-606 17 00

296

Service, maintenance

General Motors Portugal

Quinta da Fonte

Edificío Fernão Magalhães, Piso 2

2780-190 Paço d’Arcos – Portugal

Tel. 00 351- 21 440 75 00
General Motors Southeast Europe

org. zložka

Apollo Business Centre

Mlynské Nivy 45

821 09 Bratislava - Slovakia

Tel. 00 421-2 58 275 543
General Motors España S.L.

Paseo de la Castellana, 91

28046 Madrid – Spain

Tel. 00 34-902 25 00 25
General Motors Norden AB

Årstaängvägen 17

100 73 Stockholm – Sweden

Tel. 00 46-20 333 000
General Motors Suisse S.A.

Stelzenstraße 4

8152 Glattbrugg – Switzerland

Tel. 00 41-44 828 28 80
General Motors Türkiye Ltd. Sti.

Kemalpasa yolu üzeri

35861 Torbali / Izmir – Turkey

Tel. 00 90-2 32-8 53-14 53
In Albania, Bosnia-Herzegovina,

Bulgaria, Croatia, Estonia, Latvia,

Lithuania, Macedonia, Romania,

Serbia-Montenegro and Slovenia

please contact the

General Motors Service Department in

Budaörs – Hungary

Tel. 00 36-23 446 100

Inspection system

In order to guarantee economical and safe

vehicle operation and to maintain the

value of your vehicle, it is of vital

importance that all maintenance work is

carried out at the proper intervals as

specified.
In vehicles with a fixed engine oil change

and service interval, InSP appears in the

odometer display when the ignition is

switched on when the service work is due:

have the relevant service work carried out

by a workshop within one week or 300 miles

(500 km).

The service interval display takes account

of off-the-road periods during which the

battery is disconnected.
For vehicles with flexible engine oil change

and service intervals, the length of these

intervals is based on several parameters

stemming from usage. For this reason,

various engine-specific data is continually

gathered and is used to calculate the

remaining distance until the next service.
This remaining distance can be displayed

with the ignition off: briefly press the trip

odometer reset button, the mileage

reading shows. Press the button again for

around 2 seconds, InSP and the remaining

distance is shown.
If the remaining distance is less than

1000 miles (1500 km), InSP is displayed

with a remaining distance of 600 miles

(1000 km) when the ignition is switched on

and off. InSP is displayed for several

seconds if the remaining distance is less

than 600 miles (1000 km). Have the service

work that is due carried out within one

week or 300 miles (500 km). Have this work

carried out by a Vauxhall Authorised

repairer in order to avoid invalidation of

warranty claims.

297

Service, maintenance

Further information on maintenance and

the inspection system can be found in the

service booklet, which is in the glove

compartment.
Have service work – and repairs to the

bodywork and components – performed

properly by a workshop. We recommend

your Vauxhall Authorised repairer, who has

excellent knowledge of Vauxhall vehicles

and is in possession of the necessary tools

and current service instructions from

Vauxhall. To exclude the possibility of loss

of warranty, use of a Vauxhall Authorised

repairer is recommended in particular

during the warranty period. For further

information see the Service Booklet.
Separate anti-corrosion service

Have the work performed by a workshop at

the intervals specified in the Service

Booklet.

Genuine Vauxhall Parts and

Accessories

We recommend that you use "Genuine

Vauxhall Parts and Accessories" and

conversion parts expressly approved for

your vehicle type. These parts have

undergone special tests to establish their

reliability, safety and specific suitability for

Vauxhall vehicles. Despite continuous

market monitoring, we cannot assess or

guarantee these attributes for other

products, even if they have been granted

approval by the relevant authorities or in

some other form.
"Genuine Vauxhall Parts and Accessories"

and conversion parts approved by

Vauxhall can be obtained from your

Vauxhall Authorised repairer, who can

provide comprehensive advice about

permissible technical changes and ensure

that the part is installed correctly.

A note on safety

To avoid injury from moving parts and

cables conducting ignition voltage, only

carry out engine compartment checks

(e.g. checking brake fluid or engine oil

level) when the ignition is switched off.

9

 Warning

The cooling fan is controlled by a

thermoswitch and can therefore start

unexpectedly even if the ignition is

switched off. Risk of injury.
Electronic ignition systems generate very

high voltages. Do not touch the ignition

system; high voltage can be fatal.

298

Service, maintenance

Never carry out any repairs or adjustment

and maintenance work on the vehicle

yourself. This especially applies to the

engine, chassis and safety parts. You may

unwittingly infringe the provisions of the

law and, by not performing the work

properly, endanger yourself and other

road users.

Checking and topping up fluids

The caps that are used when topping up

engine oil, coolant and wash fluid as well

as the oil dipstick may be coloured yellow

to aid identification.

Engine oil

Information on engine oils is found in the

Service Booklet.
Engine oil level and consumption

Every engine consumes engine oil for

technical reasons. The engine oil

consumption cannot be assessed until a

fairly long distance has been driven, and

may be above the specified value when the

vehicle is first being driven (run-in period).

Frequent driving at high revs increases

engine oil consumption.

In vehicles with engine oil level monitoring 3

the engine oil level is monitored

automatically

1)

, see page 116. It is

advisable to check the engine oil level

before setting off on long journeys.

9

 Warning

Do not allow the engine oil level to drop

below the minimum level!

1)

Not on Z 14 XEP or Z 20 LEH engine.

Sales designation – see pages 310, 311.

299

Service, maintenance

Checking the engine oil level, topping up

engine oil

The pictures show the inspection of a petrol

and two diesel engines.
The oil level must be checked with the

vehicle on a level surface and with the

engine (which must be at operating

temperature) switched off. Wait at least

5 minutes before checking the level to

allow the normal engine oil accumulation

in the engine to drain into the oil pan.

To check the engine oil level, wipe the oil

from dipstick and insert dipstick into

handle as far as it will go. Top engine oil up

if the level has dropped into the range of

the top-up mark MIN.
The engine oil level must not exceed the

upper mark MAX on the dipstick. Excess

engine oil must be drained off or extracted.

If the engine oil level is above the MAX

mark there is a risk of damage to the

engine or the catalytic converter.
Capacity between MIN and MAX marks,

see pages 346, 347.

Top up with the same brand of engine oil

that was used during the previous oil

change, following the instructions in the

service booklet.
To close, position the cap and screw it into

place.
Capacities, see pages 346, 347.

9

 Warning

It is the owner’s responsibility to maintain

the correct level of an appropriate quality

oil in the engine.

300

Service, maintenance

Engine oil change, oil filter change

Have a workshop change the oil at the

specified service intervals.
We recommend that you use genuine

engine oil filters.

Diesel fuel filter

On each engine oil change, have the fuel

filter checked for any water residue by a

workshop.
Illumination of A indicates water in the

fuel filter 3.
Have fuel filter checked at shorter intervals

if the vehicle is subjected to extreme

operating conditions such as high humidity

(primarily in coastal areas), extremely high

or low outside temperatures and

substantially varying daytime and

night-time temperatures.

Coolant

The glycol-based coolant provides

excellent corrosion protection for the

heating and cooling systems as well as

antifreeze protection down to around

-28 °C. It remains in the cooling system

throughout the year and need not be

changed.
Use of certain antifreezes can lead to

engine damage. We therefore recommend

that you only use antifreezes that have

been approved.

9

 Warning

Empty engine oil cans do not belong in

the domestic rubbish. Please comply with

the legal, environmental and health

regulations as regards the disposal of

used oil and engine oil filters.

9

 Warning

Antifreeze is a danger to health; it must

therefore be kept in the original container

and out of the reach of children.

301

Service, maintenance

Antifreeze and corrosion protection

Before the start of winter, have a workshop

check the antifreeze protection. The

antifreeze level must guarantee protection

to approx. -28 °C. Insufficient antifreeze

will reduce the frost protection level and

the corrosion protection. If necessary add

antifreeze.
If coolant loss is topped up with water,

have concentration checked and add

antifreeze if necessary.

Coolant level

Hardly any losses occur since the cooling

system is sealed and it is thus rarely

necessary to top up the coolant.
The coolant should be a little above the

KALT/COLD mark in the expansion tank

with a cold cooling system. The coolant

level can also be read off from the outside

of the expansion tank.

When the engine is at operating

temperature, coolant level rises. It falls

again when the system cools. If it falls

below the KALT/COLD mark when the

system is cold, top up to just above the

mark.
Top up antifreeze. If no antifreeze is

available, top up with clean tap water. If

tap water is unavailable, distilled water

can be used.
After topping up with water or distilled

water, check the antifreeze concentration

and add antifreeze if necessary. Have a

workshop eliminate the cause of the

coolant loss.
Too low a coolant level can cause engine

damage.
To close, position the cap and screw it into

place.

9

 Warning

Allow engine to cool down before

removing coolant filler cap. Remove filler

cap carefully so that pressure can escape

slowly, otherwise there is a risk of

scalding.

302

Service, maintenance

Coolant temperature

Control indicator W illuminates when

coolant temperature is too high. Check

coolant level immediately:
z Coolant level too low:

Add coolant, see notes under "Antifreeze

and corrosion protection", and "Coolant

level". Have a workshop eliminate the

cause of the coolant loss.

z Coolant level OK:

Have the cause of the raised coolant

temperature eliminated. Contact a

workshop.

Brake fluid

Brake fluid level

The fluid level in the reservoir must be

neither higher than the MAX mark nor

lower than the MIN mark.

The use of certain brake fluids can cause

damage or loss of braking power. We

therefore recommend the use of high-

performance brake fluid that has been

approved.
When topping up, ensure maximum

cleanliness as contamination of the brake

fluid can lead to function problems in the

braking system.
After correcting the brake fluid level, have

a workshop eliminate the cause of the

brake fluid loss.

9

 Warning

Brake fluid is toxic and caustic. Keep

away from eyes, skin, textiles and

painted surfaces. Direct contact can

cause injuries and damage.

303

Service, maintenance

Brake fluid change

Brake fluid is hygroscopic, i.e. it absorbs

water. If the brakes become hot, such as

when driving on long downhill stretches,

vapour bubbles can occur in the water,

which can have an extremely adverse

effect on braking power (depending on the

proportion of water).
The fluid change intervals specified in the

Service Booklet must therefore be

observed.

Windscreen wiper

Clear vision is essential for safe driving.
Perform regular checks on the windscreen

wiper and headlight wash system 3 to

ensure they are operating correctly. We

recommend wiper blade replacement at

least once a year.
If the windscreen is dirty, operate the

windscreen wash system before switching

on the windscreen wiper or setting the

wiper to automatic operation with the rain

sensor 3. This will avoid wiper blade wear.
Do not switch on the windscreen wiper or

set them to automatic operation with the

rain sensor 3 if the windscreen is iced up as

this could damage the wiper blades or the

wiper system.

We recommend releasing frozen wiper

blades with defroster spray.
Smearing wiper blades can be cleaned with

a soft cloth and Vauxhall Windscreen

Wash Solvent.
Wiper blades whose lips have become

hardened, cracked or covered with silicone

must be replaced. This may be necessary

as a result of the effects of ice, thawing salt

or heat, or the incorrect use of cleaning

agents.
Switch off the windscreen wiper or

automatic wiper with rain sensor 3 in car

wash, see pages 12, 13, 141, 289.
Windscreen wiper care, see page 291.

9

 Warning

Have the brake fluid change performed

by a workshop. Please comply with the

legal, environmental and health

regulations as regards the disposal of

brake fluid.

304

Service, maintenance

To ensure proper operation of the rain

sensor 3 the sensor area must be free from

dust, dirt and ice, which is why the

windscreen wash system must be operated

at regular intervals and the sensor area

de-iced. Vehicles with rain sensor 3 can be

identified by the sensor area near the top

of the windscreen.

Service setting for front windscreen wiper

(e.g. for changing or cleaning the front

wiper blades).
Within 4 seconds from turning off the

ignition, with the key still in the lock 3 or for

the Open&Start System 3 after switching

off the ignition and before opening the

driver’s door, move the wiper stalk down.

Release wiper stalk as soon as the wiper is

vertical.

Wiper blades on the windscreen

Activate service setting – see previous

column. Raise wiper arm, tilt wiper blade

at 90° to the wiper arm and remove to the

side.

305

Service, maintenance

Wiper blade on the rear window 3

Lift wiper arm. Disengage wiper blade as

shown in Fig. 17318 T, and remove.

Windscreen and headlight wash

systems

3



The fluid reservoir filler neck for the

windscreen wash system and headlight

wash system 3 is located at the front, next

to the left headlight.
Capacities, see pages 346, 347.
Fill only with clean water to prevent the

nozzles from clogging. To improve

cleaning efficiency, we recommend that

you add a little Vauxhall Windscreen Wash

Solvent.

The windscreen wash system and

headlight wash system will not freeze in

winter:

When closing the reservoir, press the lid

firmly over the beaded edge all the way

round.

Frost protection

down to

Mixing ratio of

Vauxhall

Windscreen

Wash Solvent to

water

-5 °C

1 : 3

-10 °C

1 : 2

-20 °C

1 : 1

-30 °C

2 : 1
