Vauxhall Astravan (2007 year). Manual - part 2

18

In brief

Releasing the handbrake:

Raise lever slightly,

press release button,

lower lever fully

6 Handbrake – see page 224.

Parking the vehicle

z Always apply handbrake without

pressing release button. Apply as firmly

as possible on a downhill slop or uphill

slope. Operate footbrake at same time

to reduce operating force.

z Switch engine off by turning ignition key

to 0. Remove ignition key and turn

steering wheel until steering lock is felt to

engage (anti-theft protection). With

Open&Start system 3 switch ignition off

and open driver’s door.
In vehicles with Open&Start system 3 the

engine can only be switched off when the

vehicle is stationary.
In vehicles with automatic transmission 3

the key can only be withdrawn when the

selector lever is in position P. With the

Open&Start System 3, "P" flashes in the

gear display for several seconds if P is

not selected or the handbrake is not

applied.

z If the vehicle is on a level surface or an

incline, with manual transmission or

Easytronic 3 select first gear before

switching the ignition off, with automatic

transmission 3 move selector lever to P.

Also turn wheels away from kerb on an

uphill slope.
If the vehicle is on a downhill slope, with

manual transmission or Easytronic 3

select reverse gear before turning

the ignition off, with automatic

transmission 3 move selector lever to P.

Also turn front wheels toward kerb.

z Lock doors and luggage compartment

using button p on remote control and

with Open&Start system 3 touch sensor

in door handle of front door.
To activate the anti-theft locking

system 3 and the Vauxhall alarm

system 3 press button p twice or with

Open&Start system 3 touch sensor in one

of the front door handles twice.

19

In brief

Advice when parking:

z Do not park the vehicle on an easy

flammable surface. The high temperature

of the exhaust system could ignite the

surface.

z On vehicles with Easytronic 3 control

indicator R flashes for a few seconds

after the ignition is switched off if the

handbrake has not been applied –

see page 182.

z Close the windows and sunroof 3 or

TwinTop 3.

z The engine cooling fans may run after

the engine has been switched off –

see page 297.

6 Remote control – see page 32,

Open&Start system – see page 34,

central locking system – see page 40,

Vauxhall alarm system 3 – see page 46,

TwinTop roof operation 3 – see page 56,

parking up the vehicle – see page 307.

That was the most important

information in brief for your first

drive in your vehicle.

The other pages of this chapter

contain a summary of the

noteworthy functions of your

vehicle.

The remaining chapters of the

Owner’s Manual contain

important information on

operation, safety and

maintenance as well as a

complete index.

20

In brief

Vauxhall Full Size airbag system

The Vauxhall Full Size airbag system

consists of several separate systems.
Front airbag system

The front airbag system will be triggered in

the event of a serious accident involving a

frontal impact and forms safety cushions

for the driver and front passenger. The

forward movement of the driver and front

passenger is checked and the risk of

injuries to the upper body and head

thereby substantially reduced.

Side airbag system 3

The side airbag is triggered in the event of

a side-on collision to form a safety cushion

for the driver or front passenger in the

respective door area. This substantially

reduces the risk of injury to the upper body

and pelvis.

Curtain airbag system 3

The curtain airbag system triggers in case

of a side-on collision and provides a safety

barrier in the head area on the respective

side of the vehicle. This reduces the risk of

injury to the head considerably in case of a

side-on collision.
6 Vauxhall Full Size airbag system –

see page 92.

21

In brief

Active headrests

3

 on front seats

In the event of a rear-end impact, the

active head restraints tilt forward a little.

The head is more effectively supported by

the head restraint

and the danger of

whiplash in the neck area is reduced

.

Active head restraints are identified by the

lettering ACTIVE on the head restraint

guide sleeves.
6 Headrests – see page 68.

Operating menus in the

information display

3



Menu options are selected using menus

and the arrow keys or the multi-function

button on the Infotainment system 3 or the

left-hand adjuster wheel 3 on the steering

wheel. The selected menu options are

shown on the display.
Selection using arrow keys 3:

Operate left or right arrow key.

Selection using multi-function button 3:

rotate and press multi-function button.
To exit a menu, turn the multi-function

button left or right to Return or Main and

select.

22

In brief

Selection with left adjuster wheel on

steering wheel 3: rotate adjuster wheel

and press.
6 Information Display – see page 122.

Trip computer

3



The trip computers provide information on

driving data, which is continually recorded

and evaluated electronically.
Functions:

z Range

z Instantaneous consumption

z Distance travelled

z Average speed

z Effective consumption

z Average consumption

z Stop watch

z Tyre pressure 3
6 Trip computer 3 – see pages 128, 134.

Check control

3



The check control software monitors
z Fluid levels
z Tyre pressure 3
z Remote control battery
z Vauxhall alarm system 3
z Important exterior lights, including

cables and fuses

6 Check Control 3 – see page 138.

2

Board Computer

19,5° 19:36

BC 1

All values

BC 2

257.0

miles

Timer

Ø

40

mph

Tyres

7.0

gal

Ø



31.0

mpg

1

8

Coolant level

check

OK

23

In brief

Remote control on steering

wheel

3



The functions of the infotainment system 3

and the information display can be

operated with the buttons and adjuster

wheels on the steering wheel.
Further information is available in the

infotainment system operating

instructions.
6 Remote control on steering wheel 3 –

see page 151,

Infotainment System – see page 151.

Twin Audio

3



Twin Audio allows rear seat occupants the

choice between the audio source played on

the infotainment system or a separate

audio source.
Only an audio source that is not currently

active on the infotainment system can be

controlled using Twin Audio.

Two headphone connections are available,

with separate volume controls.
Further information is available in the

infotainment system operating

instructions.
6 Twin Audio 3 – see page 152.

24

In brief

Open&Start system with

electronic key and remote

control

3

The Open&Start system allows the vehicle

to be locked and unlocked, including

anti-theft locking system 3 and the

Vauxhall alarm system 3 without a

mechanical key and the engine to be

started and stopped using a start/stop

button. All the driver has to do is carry the

electronic key around with him.
6 Open&Start System 3 – see page 34.

Sport mode

3



To activate

Press the SPORT button. The LED in the

button illuminates.
SPORT mode is used to change damping 3,

steering 3, throttle application and the

shift point for Easytronic 3 and automatic

transmission 3 while driving.

Damping and steering become more direct

and provide better contact with the road

surface. The engine reacts more quickly to

accelerator movements.
With Easytronic 3 and automatic

transmission 3, the shift times are

shortened and shifting takes place at

higher revs (not with cruise control

enabled 3).
6 Sport mode 3 – see page 212.

25

In brief

Deflation Detection System

(DDS)

3



The deflation detection system

continuously monitors the speed of all

wheels while driving. If a tyre loses

pressure, it grows smaller and therefore

rotates more quickly than the other wheels.

If the system detects a difference in speed,

the control indicator

w

 illuminates in red.

After tyre pressure is corrected or a tyre or

wheel is changed, the system must be

initialised by pressing the DDS button.
6 Tyre deflation detection system 3 –

see page 218.

Tyre pressure monitoring

system

3



The tyre pressure monitoring system

continually checks the pressure and speed

of all four wheels while driving.
A pressure sensor is installed in each wheel.

The inflation pressures of the individual

wheels are transmitted to a controller,

where they are compared.
The current tyre pressures can be

displayed on the graphical information

display or the colour information display 3.
Deviating tyre pressures are displayed in

the form of messages on the information

display whilst driving.
6 Tyre pressure monitoring system 3 –

see page 218.

2

 Board Computer

BC 1

BC 2

Timer

Tyres

26

In brief

Adaptive Forward Lighting

(AFL)

3



improves lighting in curves (curve lighting)

on vehicles with Bi-Xenon headlight

system.

Curve lighting

The Xenon light beam pivots based on

steering wheel position and speed

(from approx. 6 mph/10 km/h).
Motorway lighting

At higher speeds and continuous straight

ahead travel, the dipped beam

automatically raises slightly, thereby

increasing headlight range.
6 Adaptive driving lights 3 – see page 147.

Panoramic windscreen

3



To open:

Turn the handle to the right and move the

roof lining rearward to a suitable position.
To close:

Move the roof lining forward to a suitable

position. When moved all the way forward,

the roof lining engages in position.
6 Panoramic roof 3 – see page 53.

27

In brief

Parking distance sensor

3



When reverse gear is selected, the parking

distance sensor switches itself on

automatically.
The parking distance sensor can also be

activated at speeds of less than 15 mph

(25 km/h) by pressing the

r

 button on

the instrument panel.
If the vehicle approaches an obstacle when

reversing, a series of signals can be heard

in the vehicle interior. The interval between

the signals becomes shorter as the

distance is reduced. If the distance is less

than 30 cm, the signal will be continuous.
6 Parking distance sensor 3 –

see page 215.

Cargo box

3



Collapsible box to divide the luggage

compartment.
The cargo box may only be loaded when

the backrests are engaged in an upright

position.
When removing, start with the right half.
6 Cargo Box 3 – see page 81.

FlexOrganizer

3



The side walls contain retaining strips,

where various components can be

attached to divide the luggage

compartment or fasten loads.
The system consists of

z Adapters

z Variable partition net

z Mesh pockets for the side walls

z Hooks in the luggage compartment
6 FlexOrganizer 3 – see page 80.

28

In brief

Luggage compartment cover,

Estate

To open:

Press handle on luggage compartment

cover down. The cover automatically

unrolls.
6 Luggage compartment cover 3 –

see page 76.

Astra TwinTop

With TwinTop, a convertible hardtop, Astra

unites the benefits of a coupe with those of

a convertible.
To optimise safety, the Astra TwinTop is

equipped with a rollover protection system

with reinforced windscreen frame and the

choice of fixed or deployable anti-roll bars

in addition to the front and side airbag

systems.

The roof is operated with the buttons on

the roof console above the mirror or with

the remote control.
To improve luggage compartment

accessibility, the electric loading aid makes

it possible to raise the open roof when it is

stowed in the luggage compartment.
6 TwinTop – see page 56.

29

In brief

Diesel particle filter

3

The diesel particle filter system removes

polluting soot particles out of the engine

exhaust gases. The system includes a

self-cleaning function that operates

automatically while driving. The filter is

cleaned by burning the trapped soot

particles at a high temperature. There may

be an increase in fuel consumption,

exhaust smell, and engine cooling fan

operation 3 during the self-cleaning

operation.
The self-cleaning function cannot operate

automatically during certain driving

situations where the engine does not reach

its normal operating temperature. An

example of this would be short distance

driving in cold weather.

If the filter needs cleaning and recent

driving situations did not allow the function

to automatically operate, then the control

indicator

!

 will flash. If this occurs, then

you may continue to drive the vehicle

normally. The vehicle will not be damaged

and does not require service.
The self-cleaning function will

automatically operate while driving after

the engine has reached its normal

operating temperature. The control

indicator

!

 will continue to flash until the

self-cleaning operation is complete. This

may take up to 20 minutes of driving. The

time will be shorter at higher vehicle

speeds.
6 diesel particle filter – page 207.

30

Keys, doors, windows, TwinTop

Keys, doors, windows,

TwinTop

Replacement keys

The key number is specified in the vehicle

documents and in the Car Pass 3.
The key is a constituent of the electronic

immobiliser. Ordering keys from a Vauxhall

Authorised repairer guarantees problem-

free operation of the electronic

immobiliser.
When electronic keys of the Open&Start

system are being replaced, all keys must be

handed to the dealer for programming.
Keep the spare key in a safe spot.
Locks – see page 291,

Open&Start system, electronic keys –

see page 34.

Car Pass

The Car Pass contains all of the vehicle’s

data and should therefore not be kept in

the vehicle.
Have your Car Pass on hand when

consulting a Vauxhall Authorised repairer.

outboardKey with foldaway key

section

3



Press button to extend. Press button to

retract; key section engages audibly.

Replacement keys ...............................  30
Car Pass................................................  30
outboardKey with foldaway key

section 3 ............................................ 30

Electronic immobiliser..........................  31
Store personal vehicle settings in

the vehicle key 3............................... 32

Remote control 3 with mechanical

key...................................................... 32

Open&Start system 3 .......................... 34
Central locking system ........................  40
Fault when locking or unlocking.........  43
Luggage compartment.......................  44
Vauxhall alarm system 3.................... 46
Child safety locks 3 ............................. 49
Exterior mirrors.....................................  49
Interior mirror .......................................  51
Electric windows 3............................... 51
Panoramic windscreen 3 .................... 53
Sunroof 3 ............................................. 54
TwinTop................................................ 56

31

Keys, doors, windows, TwinTop

Electronic immobiliser

The system checks whether the vehicle may

be started with the mechanical key or

electronic key of the Open&Start system 3

that is being used. If the key is recognised

as "authorised" the vehicle can be started.

The check takes place via a transponder in

the key.
The electronic immobiliser activates itself

automatically after the key has been

removed from the ignition or, with the

Open&Start system 3, when the engine is

switched off by pressing the Start/Stop

button.
The code number of the electronic

immobiliser is given in the Car Pass.

Control indicator for immobiliser A

Control indicator A illuminates briefly

when the ignition is switched on.
If the control indicator flashes when the

ignition is on, there is a fault in the system;

the engine cannot be started. Switch off

the ignition and then repeat the start

attempt.
If the control indicator A continues to

flash, try to start the engine using the

second key and contact a workshop for

assistance.

If control indicator A illuminates after

the engine is started, there is a fault in

the engine electronics or transmission

electronics 3 (see pages 182, 188,

196, 206) or there is water in the diesel fuel

filter 3 (see page 300).
Note

The immobiliser does not lock the doors.

Therefore, after leaving the vehicle always

lock it and switch on the Vauxhall alarm

system 3 – see pages 40, 46.

32

Keys, doors, windows, TwinTop

Store personal vehicle settings in

the vehicle key

3



The last settings selected

z instrument illumination,
z information display 3,
z Infotainment system 3,
z for the climate control system 3
are stored automatically depending on the

vehicle key used.
Different settings stored for each vehicle

key are retrieved automatically on use of

the vehicle key concerned.
Each time the vehicle is locked, the settings

are saved again.

Remote control

3

 with mechanical

key

Depending on vehicle equipment level, one

of the remote controls shown on this page

will be used.
Remote control in version with Open&Start

system 3 – see page 34.
The remote control is integrated in the key.
Used to operate:

z central locking system,

z mechanical anti-theft locking system 3,

z Vauxhall alarm system 3.

On the Astra TwinTop, the roof can be

opened or closed using the remote

control 3.

33

Keys, doors, windows, TwinTop

The remote control has a range of approx.

5 metres. This range can be affected by

outside influences. Aim the remote control

at the vehicle to operate.
Handle the remote control with care,

protect it from moisture and high

temperatures and avoid unnecessary

operation.
The hazard warning lights come on to

indicate that the remote control is

operational.
Central locking system,

see page 40.
Mechanical anti-theft locking system 3,

see page 41.
Vauxhall alarm system 3,

see page 46.
Electric windows 3,

see page 51.
Astra TwinTop,

see page 56.

Fault

If the central locking system cannot be

operated with the remote control, it may be

due to the following:
z The range of the remote control has

been exceeded.

z Remote control battery voltage is too

low. Battery replacement – see next

page.

z Frequent, repeated operation of the

remote control outside the reception

range of the vehicle (e.g. too far from

vehicle, remote control is then no longer

recognised). Remote control

synchronisation – see next column.

z If the central locking system is

overloaded as a result of repeated

operation at short intervals. The power

supply is cut off for a brief period.

z Interference from higher-power radio

waves from other sources.

To eliminate the cause of a fault, we

recommend contacting a workshop for

assistance.
Open driver’s door with key – see page 43.
