Settings
CONTROLS
Storing
Memory function
1. Switch on the ignition.
Concept
2. Set the desired position.
The following settings can be stored and, if
necessary, retrieved using the memory func-
3.
Press button. The LED in the button
tion:
lights up.
Seat position.
4. Press selected button 1 or 2 while the LED
is lit. The LED goes out.
Exterior mirror position.
Height of the Head-up Display.
Calling up settings
The stored position is called up automatically.
General information
Press selected button 1 or 2.
Different settings can be assigned to two mem-
ory locations.
The procedure stops when a switch for setting
the seat or one of the memory buttons is
The adjustment of the lumbar support is not
pressed.
stored.
While driving, the seat position adjustment on
Safety information
the driver's side is interrupted after a short
time.
WARNING
There is a risk of jamming when moving
Calling up of a seat position
the seats. There is a risk of injury or risk of dam-
deactivated
age to property. Make sure that the area of
After a brief period, calling up stored seat posi-
movement of the seat is clear prior to any ad-
tions is deactivated to save battery power.
justment.
To reactivate calling up of a seat position:
WARNING
Open or close the door or tailgate.
Using the memory function while driving
Press a button on the remote control.
can lead to unexpected movements of the seat.
Press the Start/Stop button.
Vehicle control could be lost. There is a risk of
an accident. Only retrieve the memory function
when the vehicle is stationary.
Mirrors
Overview
Exterior mirrors
General information
The mirror on the front passenger side is more
curved than the driver's side mirror.
The mirror setting is stored for the driver profile
currently in use. When the vehicle is unlocked
via the remote control, the position is automat-
ically retrieved if the function, refer to page 64,
is activated for this purpose.
79

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS
Settings
The current exterior mirror position can be
Folding in and out
stored using the memory function, refer to
NOTE
page 79.
Depending on the vehicle width, the ve-
hicle can be damaged in vehicle washes. There
Safety information
is a risk of damage to property. Before washing,
WARNING
fold in the mirrors by hand or with the button.
Objects reflected in the mirror are closer
Press button.
than they appear. The distance to the traffic
behind could be incorrectly estimated, for in-
stance while changing lanes. There is a risk of
Folding is only possible up to a speed of ap-
an accident. Estimate the distance to the traffic
prox. 15 mph/20 km/h.
behind by looking over your shoulder.
Folding the mirrors in and out is helpful in the
following situations:
Overview
In vehicle washes.
On narrow roads.
Mirrors that were folded in are folded out auto-
matically at a speed of approx.
25 mph/40 km/h.
Automatic heating
Both exterior mirrors are automatically heated
whenever the ignition is switched on.
1
Settings
Automatic dimming feature
2
Selecting a mirror, Automatic Curb Monitor
The exterior mirror on the driver's side is auto-
3
Folding in and out
matically dimmed. Photocells in the car's inte-
rior mirror, refer to page 81, are used to con-
trol this.
Selecting a mirror
To change over to the other mirror:
Automatic Curb Monitor, exterior mirror
Slide the switch.
Concept
If reverse gear is engaged, the mirror glass on
Adjusting electrically
the front passenger side is tilted downward.
Press button.
This improves your view of the curb and other
The mirror movement follows the but-
low-lying obstacles when parking, for instance.
ton movement.
Activating
Malfunction
1.
Slide the switch to the driver's side
In case of an electrical malfunction, adjust the
mirror position.
mirror by pressing the edges of the mirror
2. Engage selector lever position R.
glass.
80

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Settings
CONTROLS
Deactivating
Interior mirror, automatic dimming
feature
Slide the switch to the passenger's side
mirror position.
Overview
Interior mirror, manually dimmable
Flip lever
Photocells are used for control:
In the mirror glass.
On the back of the mirror.
To reduce the blinding effect of the interior
mirror, flip the lever forward.
Functional requirements
Keep the photocells clean.
Turn knob
Do not cover the area between the interior
mirror and the windshield.
Steering wheel
Safety information
WARNING
Steering wheel adjustments while driving
can lead to unexpected steering wheel move-
Turn the knob to reduce the blinding effect by
ments. Vehicle control could be lost. There is a
the interior mirror.
risk of an accident. Adjust the steering wheel
while the vehicle is stationary only.
81

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS
Settings
Settings
1. Fold the lever down.
2. Move the steering wheel to the preferred
height and angle to suit your seating posi-
tion.
3. Fold the lever back up.
82

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Transporting children safely
CONTROLS
Transporting children safely
necessarily available in your vehicle, e. g., due
Vehicle features and op-
to the selected options or country versions. This
tions
also applies to safety-related functions and sys-
tems. When using these functions and systems,
This chapter describes all standard, country-
the applicable laws and regulations must be
specific and optional features offered with the
observed.
series. It also describes features that are not
The right place for children
Safety information
system can no longer be used due to their age,
weight, and size.
WARNING
Unattended children or animals can
Safety information
cause the vehicle to move and endanger them-
WARNING
selves and traffic, for instance due to the fol-
lowing actions:
The safety belt cannot be fastened cor-
rectly on children shorter than 5 ft, 150 cm
Pressing the Start/Stop button.
without suitable additional child restraint sys-
Releasing the parking brake.
tems. The efficacy of safety gear, including
Opening and closing the doors or windows.
safety belts, can be limited or lost when safety
Engaging selector lever position N.
belts are fastened incorrectly. An incorrectly
fastened safety belt can cause additional inju-
Using vehicle equipment.
ries, for instance in the event of an accident or
There is a risk of accidents or injuries. Do not
during braking and evasive maneuvers. There is
leave children or animals unattended in the ve-
a risk of injuries or danger to life. Secure chil-
hicle. Take the remote control with you when
dren shorter than 5 ft, 150 cm using suitable
exiting and lock the vehicle.
child restraint systems.
Always transport children in the rear
Children on the front passenger seat
seat
General information
General information
Before using a child restraint system on the
Accident research shows that the safest place
front passenger seat, ensure that the front,
for children is in the rear seat.
knee, and side airbags on the front passenger
Transport children younger than 13 years of
side are deactivated. Automatic deactivation of
age or shorter than 5 ft/150 cm only in the rear
front-seat passenger airbags, refer to
seat in suitable child restraint systems designed
page 136.
for the age, weight and size of the child. Chil-
dren 13 years of age or older must wear a
safety belt as soon as a suitable child restraint
83

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS
Transporting children safely
Safety information
bly replaced by the dealer’s service center or
another qualified service center or repair
WARNING
shop.
Active front-seat passenger airbags can
injure a child in a child restraint system when
WARNING
the airbags are activated. There is a risk of in-
The stability of the child restraint system
jury. Make sure that the front-seat passenger
is limited or compromised with incorrect seat
airbags are deactivated and that the PASSEN-
adjustment or improper installation of the child
GER AIRBAG OFF indicator light lights up.
seat. There is a risk of injuries or danger to life.
Make sure that the child restraint system fits
WARNING
securely against the backrest. If possible, adjust
The stability of the child restraint system
the backrest tilt for all affected backrests and
is limited or compromised with incorrect seat
correctly adjust the seats. Make sure that seats
adjustment or improper installation of the child
and backrests are securely engaged or locked.
seat. There is a risk of injuries or danger to life.
If possible, adjust the height of the head re-
Make sure that the child restraint system fits
straints or remove them.
securely against the backrest. If possible, adjust
the backrest tilt for all affected backrests and
On the rear seats
correctly adjust the seats. Make sure that seats
and backrests are securely engaged or locked.
If the vehicle is equipped with a sliding rear
If possible, adjust the height of the head re-
seat row: move the seats to the rearmost posi-
straints or remove them.
tion before mounting a child restraint system.
On the front passenger seat
Installing child re-
Deactivating airbags
straint systems
WARNING
Active front-seat passenger airbags can
General information
injure a child in a child restraint system when
Pay attention to the specifications of the child
the airbags are activated. There is a risk of in-
restraint system manufacturer when selecting,
jury. Make sure that the front-seat passenger
installing, and using child restraint systems.
airbags are deactivated and that the PASSEN-
GER AIRBAG OFF indicator light lights up.
Safety information
After installing a child restraint system in the
WARNING
front passenger seat, make sure that the front,
The protective effect of damaged child
knee and side airbags on the front passenger
restraint systems or of child restraint systems
side are deactivated.
exposed to an accident and their fastening sys-
Deactivate the front-seat passenger airbags au-
tems can be limited or lost. A child can e.g.,not
tomatically, refer to page 136.
sufficiently restrained, for instance in the event
of an accident or braking and evasive maneu-
Seat position and height
vers. There is a risk of injuries or danger to life.
Before installing a child restraint system, move
Have damaged child restraint systems or of
the front passenger seat as far back as possible
child restraint systems exposed to an accident
and adjust its height to the highest and thus
and their fastening systems checked and possi-
84

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Transporting children safely
CONTROLS
best possible position for the belt and to offer
Locking the safety belt
optimal protection in the event of an accident.
1. Pull out the belt strap completely.
If the upper anchorage of the safety belt is lo-
2. Secure the child restraint system with the
cated in front of the belt guide of the child seat,
safety belt.
move the front passenger seat carefully for-
3. Allow the belt strap to be pulled in and pull
ward until the best possible belt guide position
it tight against the child restraint system.
is reached.
The safety belt is locked.
Child seat security
Unlocking the safety belt
1. Unbuckle the safety belt buckle.
2. Remove the child restraint system.
3. Allow the belt strap to be pulled in com-
pletely.
In some cases it may be necessary to separate
the lower belt attachment. Safety belts, refer to
page 75.
The rear safety belts and the front passenger
safety belt can be permanently locked to fasten
child restraint systems.
LATCH child restraint fixing system
General information
be limited. There is a risk of injuries or danger
to life. Make sure that the lower anchors are se-
LATCH: Lower Anchors and Tether for Children.
curely engaged and that the LATCH child re-
Pay attention to the operating and safety infor-
straint fixing system fits securely against the
mation of the child restraint system manufac-
backrest.
turer when installing and using LATCH child re-
straint fixing systems.
Mounts for the lower LATCH anchors
The lower anchors may be used to attach the
CRS to the vehicle seat up to a combined child
and CRS weight of 65 lb/30 kg when the child is
restrained by the internal harnesses.
Safety information
WARNING
If the LATCH child restraint fixing systems
are not correctly engaged, the protective effect
of the LATCH child restraint fixing system can
85

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS
Transporting children safely
Position
WARNING
If the rear backrest is not locked, the pro-
Symbol
Meaning
tective effect of the child restraint system is lim-
The corresponding symbol
ited or there is none. In particular situations, for
shows the mounts for the
instance braking maneuvers or in case of an ac-
lower LATCH anchors.
cident, the rear backrest can fold forward.
There is a risk of injuries or danger to life. Make
Seats equipped with lower an-
sure that the rear backrests are locked.
chors are marked with a pair,
2, of LATCH symbols.
NOTE
For vehicles equipped with a
The anchors for the upper retaining straps
middle seat:
of child restraint systems are only provided for
It is not recommended to use
these retaining straps. When other objects are
the inner lower anchors of
mounted, the anchors can be damaged. There
standard outer LATCH posi-
is a risk of damage to property. Only mount
tions to fasten a child restraint
child restraint systems to the upper retaining
system on the middle seat. Use
straps.
the vehicle safety belt instead
for the middle seat.
Anchors
The respective symbol shows the an-
Before installing LATCH child restraint
chor for the upper retaining strap. Seats
fixing systems
with an upper top tether are marked
Pull the safety belt away from the area of the
with this symbol. It can be found on the rear
child restraint system.
seat backrest or the rear window shelf.
Assembly of LATCH child restraint fixing
Routing the retaining strap
systems
1. Install child restraint system, see manufac-
turer's information.
2. Ensure that both LATCH anchors are prop-
erly connected.
Child restraint systems with tether strap
Safety information
WARNING
1
Direction of travel
If the upper retaining strap is incorrectly
2
Head restraint
used for the child restraint system, the protec-
tive effect can be reduced. There is a risk of in-
3
Hook for upper retaining strap
jury. Make sure that the upper retaining strap is
4
Anchor
not guided across sharp edges and without
5
Seat backrest
twisting to the upper retaining strap.
6
Upper retaining strap
86

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Transporting children safely
CONTROLS
Attaching the upper retaining strap to
the anchor
1. Raise the head restraint, if needed.
2. On the rear seat: Guide the upper retaining
strap between the supports of the head re-
straint.
3. Attach the hook of the retaining strap to
the anchor on the rear seat.
4. Tighten the retaining strap by pulling it
down.
Locking the doors and
windows
Doors
Push the locking lever on the rear doors up.
The door can now be opened from the outside
only.
Safety switch for the rear
Press button on the driver's door if
children are being transported in the
rear.
This locks various functions so that they cannot
be operated from the rear: safety switch, refer
to page 68.
87

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS
Driving
Driving
To save battery power when the engine is off,
Vehicle features and op-
switch off the ignition and any unnecessary
tions
electronic systems/power consumers.
This chapter describes all standard, country-
Ignition off
specific and optional features offered with the
series. It also describes features that are not
Manual transmission: press the Start/Stop but-
necessarily available in your vehicle, e. g., due
ton again without stepping on the clutch pedal.
to the selected options or country versions. This
Steptronic transmission: shift to selector lever
also applies to safety-related functions and sys-
position P, press the Start/Stop button again
tems. When using these functions and systems,
without stepping on the brake.
the applicable laws and regulations must be
All indicator lights in the instrument cluster go
observed.
out.
To save battery power when the engine is off,
switch off the ignition and any unnecessary
Start/Stop button
electronic systems/power consumers.
Concept
Safety measures
Pressing the Start/Stop button
The ignition is switched off automatically in the
switches the ignition on or off
following situations while the vehicle is station-
and starts the engine.
ary and the engine is off:
Steptronic transmission: the en-
When locking the vehicle, and when the
gine starts in selector lever posi-
low beams are switched on.
tion P or N with the brake pedal pressed when
Shortly before the battery is discharged
you press the Start/Stop button.
completely, so that the engine can still be
Manual transmission: the engine starts with the
started. This function is only available when
clutch pedal pressed when the Start/Stop but-
the low beams are switched off.
ton is pressed.
When opening or closing the driver door, if
the driver's safety belt is unbuckled and the
Ignition on
low beams are switched off.
Manual transmission: press the Start/Stop but-
While the driver's safety belt is unbuckled
ton without stepping on the clutch pedal.
with driver's door open and low beams off.
Steptronic transmission: press the Start/Stop
When the front doors are opened if there is
button, and do not press on the brake pedal at
no other person sitting in the front seats.
the same time.
The low beams switch to parking lights af-
All vehicle systems are ready for operation.
ter some minutes of no use.
Most of the indicator/warning lights in the in-
strument cluster light up for a varied length of
time.
88

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving
CONTROLS
Radio-ready state
Starting the engine
General information
Safety information
In the radio-ready state, certain power con-
DANGER
sumers remain ready for operation.
If the exhaust pipe is blocked or ventila-
Activating
tion is insufficient, harmful exhaust gases can
enter into the vehicle. The exhaust gases con-
With the engine running, press the Start/Stop
tain pollutants which are colorless and odorless.
button.
In enclosed areas, exhaust gases can also accu-
If the engine is not running and the ignition is
mulate outside of the vehicle. There is danger
switched on: the system automatically activates
to life. Keep the exhaust pipe free and ensure
radio-ready state when the door is opened if
sufficient ventilation.
the lights are switched off or the daytime run-
ning lights are switched on.
WARNING
The radio-ready state remains active if, for in-
An unsecured vehicle can begin to move
stance the ignition is automatically switched off
and possibly roll away. There is a risk of an acci-
for the following reasons:
dent. Before exiting, secure the vehicle against
Opening or closing the driver's door.
rolling.
Unfastening of the driver's safety belt.
In order to ensure that the vehicle is secured
against rolling away, follow the following:
When automatically switching from low
beams to parking lights.
Set the parking brake.
On uphill grades or on a downhill slope,
Switching off automatically
turn the front wheels in the direction of the
The radio-ready state is switched off automati-
curb.
cally in the following situations:
On uphill grades or on a downhill slope,
If the driver's or front passenger door is
also secure the vehicle, for instance with a
opened when exiting the vehicle, with the
wheel chock.
engine switched off manually.
NOTE
If the ignition is switched off manually with
In the case of repeated starting attempts
the Start/Stop button.
or repeated starting in quick succession, the
After approx. 8 minutes.
fuel is not burned or is inadequately burned.
The catalytic converter can overheat. There is a
When the vehicle is locked using the central
risk of damage to property. Avoid repeated
locking system.
starting in quick succession.
Shortly before the battery is discharged
completely, so that the engine can still be
Steptronic transmission
started.
Starting the engine
1. Depress the brake pedal.
2. Engage selector lever position P or N.
3. Press the Start/Stop button.
89

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS
Driving
The ignition is activated automatically for a
On uphill grades or on a downhill slope,
brief time and is stopped as soon as the engine
turn the front wheels in the direction of the
starts.
curb.
On uphill grades or on a downhill slope,
Manual transmission
also secure the vehicle, for instance with a
wheel chock.
Starting the engine
1. Depress the brake pedal.
Steptronic transmission
2. Press on the clutch pedal and shift to neu-
tral.
Switching off the engine
1. When the vehicle is stationary, apply the
3. Press the Start/Stop button.
parking brake.
The ignition is activated automatically for a
2. Engage selector lever position P.
brief time and is stopped as soon as the engine
starts.
3. Press the Start/Stop button.
The engine is switched off.
The radio-ready state is switched on.
Engine stop
Manual transmission
Safety information
WARNING
Switching off the engine
1. With the vehicle at a standstill, press the
Unattended children or animals can
Start/Stop button.
cause the vehicle to move and endanger them-
selves and traffic, for instance due to the fol-
The engine is switched off.
lowing actions:
The radio-ready state is switched on.
Pressing the Start/Stop button.
2. Shift into first gear or reverse.
Releasing the parking brake.
3. Set the parking brake.
Opening and closing the doors or windows.
Engaging selector lever position N.
Auto Start/Stop function
Using vehicle equipment.
There is a risk of accidents or injuries. Do not
Concept
leave children or animals unattended in the ve-
hicle. Take the remote control with you when
The Auto Start/Stop function helps save fuel.
exiting and lock the vehicle.
The system switches off the engine during a
stop, for instance in traffic congestion or at traf-
WARNING
fic lights. The ignition remains switched on. The
An unsecured vehicle can begin to move
engine starts automatically for driving off.
and possibly roll away. There is a risk of an acci-
After every start of the engine using the Start/
dent. Before exiting, secure the vehicle against
Stop button, the Auto Start/Stop function is in
rolling.
the last selected state, refer to page 92. When
In order to ensure that the vehicle is secured
the Auto Start/Stop function is active, it is avail-
against rolling away, follow the following:
able when the vehicle is traveling faster than
about 3 mph/5 km/h.
Set the parking brake.
90

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving
CONTROLS
Depending on the selected driving mode, refer
Functional limitations
to page 155, the system is automatically acti-
The engine is not switched off automatically in
vated or deactivated.
the following situations:
External temperature too low.
Engine stop
The external temperature is high and auto-
matic climate control is running.
Functional requirements
The engine is switched off automatically during
The car's interior has not yet been heated
a stop under the following conditions:
or cooled to the required level.
Manual transmission:
The engine is not yet at operating tempera-
ture.
Neutral is engaged and the clutch pedal is
not pressed.
The wheels are at a sharp angle or the
steering wheel is being turned.
The driver's safety belt is buckled or the
driver's door is closed.
After driving in reverse.
Steptronic transmission:
Fogging of the windows when the auto-
matic climate control is switched on.
The selector lever is in selector lever posi-
tion D.
The vehicle battery charge is very low.
The brake pedal remains depressed while
At higher elevations.
the vehicle is stopped.
The hood is unlocked.
The driver's safety belt is buckled or the
The parking assistant is activated.
driver's door is closed.
Stop-and-go traffic.
In order to be able to release the brake pedal,
Selector lever in selector lever position R, N
engage the selector lever in position P. The en-
or M/S.
gine remains off.
To continue driving depress the brake pedal.
Starting the engine
When a gear is engaged, the engine starts au-
The engine starts automatically under the fol-
tomatically.
lowing conditions:
The air flow from the air conditioner is reduced
Manual transmission: clutch pedal is
when the engine is switched off.
pressed.
Steptronic transmission: by releasing the
Displays in the instrument cluster
brake pedal.
The display indicates that the
After the engine starts, accelerate as usual.
Auto Start/Stop function is ready
for an Automatic engine start.
Safety mode
After the engine switches off automatically, it
will not start again automatically if any one of
The display indicates that the
the following conditions are met:
conditions for an automatic en-
The driver's safety belt is unbuckled and
gine stop have not been met.
the driver's door is open.
The hood was unlocked.
91

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS
Driving
Some indicator lights light up for a varied
LED comes on: auto Start/Stop function is
length of time.
deactivated.
The engine can only be started via the Start/
The engine is started during an automatic
Stop button.
engine stop.
The engine can only be stopped or started
Functional limitations
via the Start/Stop button.
Even if driving off was not intended, the deacti-
LED goes out: auto Start/Stop function is ac-
vated engine starts up automatically in the fol-
tivated.
lowing situations:
Excessive warming of the car's interior
Switching off the vehicle during an
when the air conditioning is switched on.
automatic engine stop
The steering wheel is turned.
During an automatic engine stop, the vehicle
can be switched off permanently, for instance
Steptronic transmission: change from selec-
when leaving it.
tor lever position D to R, N or M/S.
Steptronic transmission:
Steptronic transmission: change from selec-
tor lever position P to R, N, D or M/S.
1. Engage selector lever position P.
The vehicle begins rolling.
2. Press the Start/Stop button. The ignition is
Fogging of the windows when the auto-
switched off. The Auto Start/Stop function is
matic climate control is switched on.
deactivated.
The vehicle battery charge is very low.
3. Set the parking brake.
Excessive cooling of the car's interior when
Manual transmission:
the heating is switched on.
1. Press the Start/Stop button. The ignition is
Manual transmission: low brake vacuum
switched off. The Auto Start/Stop function is
pressure; this can occur, for instance if the
deactivated.
brake pedal is depressed a number of times
2. Shift into first gear or reverse.
in succession.
3. Set the parking brake.
Switching the system on/off
Engine start as usual via Start/Stop button.
Using the button
Automatic deactivation
In certain situations, the Auto Start/Stop func-
tion is deactivated automatically for safety rea-
sons, for instance if no driver is detected.
Malfunction
The Auto Start/Stop function no longer switches
off the engine automatically. A Check Control
message is displayed. It is possible to continue
driving. Have the system checked by a dealer’s
service center or another qualified service cen-
Press button.
ter or repair shop.
92

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving
CONTROLS
Overview
Parking brake
Concept
The parking brake is used to prevent the vehi-
cle from rolling when it is parked.
Safety information
WARNING
An unsecured vehicle can begin to move
and possibly roll away. There is a risk of an acci-
Parking brake
dent. Before exiting, secure the vehicle against
rolling.
In order to ensure that the vehicle is secured
Setting
against rolling away, follow the following:
Set the parking brake.
With a stationary vehicle
On uphill grades or on a downhill slope,
Pull the switch.
turn the front wheels in the direction of the
The LED lights up.
curb.
On uphill grades or on a downhill slope,
The indicator light lights up red. The
also secure the vehicle, for instance with a
parking brake is set.
wheel chock.
Depending on the stopping situation, the park-
WARNING
ing brake is engaged automatically.
Unattended children or animals can
Steptronic transmission: in some parking situa-
cause the vehicle to move and endanger them-
tions, the parking brake is automatically en-
selves and traffic, for instance due to the fol-
gaged, when selector lever position P is en-
lowing actions:
gaged. In these cases, the parking brake is
Pressing the Start/Stop button.
released automatically when you leave the se-
Releasing the parking brake.
lector lever position P.
Opening and closing the doors or windows.
While driving
Engaging selector lever position N.
To use as emergency brake while driving:
Using vehicle equipment.
Pull the switch and hold it. The vehicle brakes
There is a risk of accidents or injuries. Do not
hard while the switch is being pulled.
leave children or animals unattended in the ve-
hicle. Take the remote control with you when
The indicator light lights up red, a signal
exiting and lock the vehicle.
sounds and the brake lights light up.
A Check Control message is displayed.
If the vehicle is decelerated to a complete stop,
the parking brake is engaged.
93

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS
Driving
Releasing
using a wheel chock, for instance when leaving
it.
Releasing manually
1. Switch on the ignition.
After a power failure
Putting the parking brake into
2.
Manual transmission: press the switch
operation
while the brake pedal is pressed.
1. Switch on the ignition.
Steptronic transmission: press the
switch while the brake is pressed or selec-
2.
Press the switch while stepping on the
tor lever position P is set.
brake pedal or selector lever position P is
set.
The LED and indicator light go out.
It may take several seconds for the brake to be
The parking brake is released.
put into operation. Any sounds associated with
this are normal.
Automatic release in cars with
Steptronic transmission
The indicator light in the instrument
For automatic release, step on the accelerator
cluster goes out as soon as the parking
pedal.
brake is ready for operation.
The LED and indicator light go out.
The parking brake is automatically released
when you step on the accelerator under the
Turn signal, high beams,
following conditions:
headlight flasher
Engine on.
Drive mode engaged.
Turn signal
Driver buckled in and doors closed.
Using turn signals
Automatic release in cars with manual
transmission
Drive off as usual. The parking brake disen-
gages when the clutch pedal is released.
The LED and indicator light go out.
Under the following conditions, the parking
brake is automatically released:
Engine on.
Gear engaged.
Press the lever past the resistance point.
Driver buckled in and doors closed.
Canada: the lever returns into its starting posi-
Engine power is sufficient to drive off.
tion after actuation. To switch off manually,
slightly tap the lever to the resistance point.
Malfunction
In the event of a failure or malfunction of the
Triple turn signal activation
parking brake, secure the vehicle against rolling
Lightly tap the lever up or down.
94

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving
CONTROLS
The triple turn signal duration can be adjusted.
Safety information
Via the Central Information Display (CID):
WARNING
1.
"My MINI"
If the wipers start moving in the folded
away state, body parts can be jammed or dam-
2. "Vehicle settings"
age may occur to parts of the vehicle. There is a
3. "Lighting"
risk of injury or risk of damage to property.
4. "Exterior lighting"
Make sure that the vehicle is switched off when
5. "One-touch turn signal"
the wipers are in the folded away state and the
wipers are folded in when switching on.
6. Select the desired setting.
Settings are stored for the profile currently
NOTE
used.
If the wipers are frozen to the windshield,
the wiper blades can be torn off and the wiper
Signaling briefly
motor can overheat when switching on. There
Press the lever to the resistance point and hold
is a risk of damage to property. Defrost the
it there for as long as you want the turn signal
windshield prior to switching the wipers on.
to flash.
Switching on
Malfunction
Unusually rapid flashing of the indicator light
indicates that a turn signal bulb has failed.
High beams, headlight flasher
Push the lever forward or pull it backward.
Press the lever up until the desired position is
reached.
Resting position of the wipers, position 0.
Intermittent operation or rain sensor, posi-
tion 1.
Normal wiper speed, position 2.
High beams on, arrow 1.
Fast wiper speed, position 3.
High beams off/headlight flasher, arrow 2.
When travel is interrupted with the wiper sys-
tem switched on: when travel continues, the
wipers resume at their previous speed.
Washer/wiper system
General information
Do not use the wipers if the windshield is dry,
as this may damage the wiper blades or cause
them to become worn more quickly.
95















Content      ..     3      4      5      6     ..
