CONTROLS
Opening and closing
Functional requirements
Profile management
For the system to be able to identify the driver
profile associated to a particular driver, the de-
Selecting a driver profile
tected remote control must be clearly allocated
Regardless of the remote control in use, a dif-
to the driver.
ferent driver profile may be activated. This al-
lows you to call up personal vehicle settings,
This is the case when:
even if you did not unlock the vehicle with your
The driver is only carrying his or her own re-
own remote control.
mote control.
Via the Central Information Display (CID):
The driver unlocks the vehicle.
1.
"My MINI"
The driver gets into the vehicle through the
driver's door.
2. "Driver profiles"
3. Select driver profile.
Settings
4. "OK"
The settings for the following systems and func-
All settings stored in the called-up driver
tions are stored in the active profile. The scope
profile are automatically applied.
of storable settings depends on country and
equipment.
The called-up driver profile is assigned to
the remote control being used at the time.
Unlocking and locking.
If the driver profile is already assigned to a
Lights.
different remote control, this driver profile
Radio.
will apply to both remote controls.
Instrument cluster.
Programmable memory buttons.
Using a guest profile
The guest profile is for individual settings that
Volumes, tone.
are stored in none of the three personal driver
Control Display.
profiles.
Climate control.
Via the Central Information Display (CID):
Navigation.
1.
"My MINI"
PDC Park Distance Control.
2. "Driver profiles"
Rearview camera.
3. "Drive off (guest)"
Head-up Display.
4. "OK"
MINI Driving Modes.
The guest profile cannot be renamed. It is not
Intelligent Safety.
assigned to the current remote control.
Driver's seat position, exterior mirror posi-
tion.
Renaming a driver profile
Both the positions saved via the seat mem-
A personal name can be assigned to the active
ory and the last position set are saved.
driver profile to avoid confusion between the
driver profiles.
Via the Central Information Display (CID):
1.
"My MINI"
2. "Driver profiles"
62

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Opening and closing
CONTROLS
3. Select driver profile.
The existing settings of the active driver profile
are overwritten with the settings of the im-
The driver profile marked with this sym-
ported driver profile.
bol can be renamed.
Via the Central Information Display (CID):
4. "Change driver profile name"
5. Enter profile name.
1.
"My MINI"
6.
Select the symbol.
2. "Driver profiles"
3. Select the driver profile to overwrite.
Resetting a driver profile
The driver profile marked with this sym-
The settings of the driver profile currently in use
bol can be overwritten.
are reset to their factory settings.
4. "Import driver profile (USB)"
Via the Central Information Display (CID):
Select USB storage device as needed.
1.
"My MINI"
5. Select the driver profile to be imported.
2. "Driver profiles"
3. Select driver profile.
Displaying driver profiles during start
The driver profiles can be displayed during each
The driver profile marked with this sym-
start to select the desired profile.
bol can be reset.
Via the Central Information Display (CID):
4. "Reset driver profile"
5. "OK"
1.
"My MINI"
2. "Driver profiles"
Exporting driver profiles
3. "Show driver profiles at startup"
Most settings of the active driver profile can be
exported.
System limits
Exporting is helpful when storing and retrieving
A clear assignment between the remote control
personal settings, for instance before delivering
and driver may not be possible in the following
the vehicle to a workshop. The stored driver
cases, for example.
profiles can be taken into another vehicle.
The passenger unlocks the vehicle with his
Via the Central Information Display (CID):
or her own remote control, but another
person is driving.
1.
"My MINI"
The driver unlocks the vehicle via Comfort
2. "Driver profiles"
Access and has multiple remote controls
3. Select driver profile.
with him or her.
The driver profile marked with this sym-
The driver changes, but the vehicle is not
bol can be exported.
locked and unlocked.
4. "Export driver profile (USB)"
Multiple remote controls are located out-
Select USB storage device as needed.
side of the vehicle.
Importing driver profiles
Profiles stored on a USB storage device can be
imported via the USB interface.
63

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS
Opening and closing
Depending on optional features and country
Settings
version, this setting is not offered in some
cases.
General information
Depending on your vehicle's equipment and
Adjusting the last seat and mirror
the country version, various settings for open-
position
ing and closing are possible.
Via the Central Information Display (CID):
These settings are stored for the driver profile,
refer to page 61, currently used.
1.
"My MINI"
2. "Driver profiles"
Unlocking
3. Select driver profile.
The setting can be made for the driver
Doors
profile marked with this symbol.
Via the Central Information Display (CID):
4. "Last seat position automatic"
1.
"My MINI"
When the vehicle is unlocked, the driver's seat
2. "Vehicle settings"
and exterior mirrors resume their last set posi-
3. "Doors/Key"
tions.
4. "Driver's door" or "All doors"
The most recent position is independent of the
positions saved via the seat memory.
5. Select desired setting:
"Driver's door only"
Automatic locking
Only the driver's door and the fuel filler
Via the Central Information Display (CID):
flap are unlocked. Pressing again un-
locks the entire vehicle.
1.
"My MINI"
"All doors"
2. "Vehicle settings"
The entire vehicle is unlocked.
3. "Doors/Key"
4. Select desired setting:
Tailgate
"Lock automatically"
Via the Central Information Display (CID):
The vehicle locks automatically after a
1.
"My MINI"
short period of time if no door is
opened after unlocking.
2. "Vehicle settings"
"Lock after starting to drive"
3. "Doors/Key"
The vehicle locks automatically after
4. Select desired setting:
you drive off.
"Tailgate"
Depending on your vehicle's optional
Automatic unlocking
features, the tailgate is either unlocked
Via the Central Information Display (CID):
or opened.
1.
"My MINI"
"Tailgate and door(s)"
2. "Vehicle settings"
Depending on your vehicle's optional
features, the tailgate is either unlocked
3. "Doors/Key"
or opened and the doors unlocked.
4. "Unlock at end of trip"
64

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Opening and closing
CONTROLS
After the engine is switched off by pressing
By flashing the daytime running lights.
the Start/Stop button, the locked vehicle is
automatically unlocked.
Overview
Confirmation signals from the vehicle
Via the Central Information Display (CID):
1.
"My MINI"
2. "Vehicle settings"
3. "Doors/Key"
4. Deactivate or activate the desired confir-
mation signals.
"Flash for lock/unlock"
Indicator light in the roof fin.
Unlocking is signaled by two flashes,
locking by one.
With alarm system:
"Acoustic signal for lock/unlock"
Unlocking is signaled by one honk of
the horn.
Alarm system
Indicator light on the interior mirror.
General information
When the vehicle is locked, the vehicle alarm
Switching on/off
system reacts to the following changes:
When you unlock and lock the vehicle, either
Unauthorized opening of a door, the hood
with the remote control or with Comfort Access,
or the tailgate.
the alarm system is switched off and on at the
same time.
Movements in the car's interior.
Changes in the vehicle tilt, e. g., during at-
Opening the doors with the alarm
tempts at stealing a wheel or when towing
system switched on
the vehicle.
The alarm system is triggered when a door is
Disconnected battery voltage.
opened if the door was unlocked using the
Improper use of the socket for Onboard Di-
integrated key in the door lock.
agnosis.
Switching off the alarm, refer to page 66.
The alarm system signals these changes visually
and acoustically:
Opening the tailgate with the alarm
Acoustic alarm.
system switched on
Depending on local regulations, the acous-
The tailgate can be opened even when the
tic alarm may be suppressed.
alarm system is switched on.
By switching on the hazard warning system.
65

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS
Opening and closing
After the tailgate is closed, it is locked and
Interior motion sensor
monitored again provided the doors are
The windows and the glass sunroof must be
locked. The hazard warning system flashes
closed for the system to function properly.
once.
Avoiding unintentional alarms
Panic mode
You can trigger the alarm system if you find
General information
yourself in a dangerous situation.
The tilt alarm sensor and interior motion sensor
Press button on the remote control
can trigger an alarm, although no unauthorized
and hold for at least 3 seconds.
action occurred.
Briefly press the button on the remote con-
Possible situations for an unwanted alarm:
trol three times in succession.
In automatic vehicle washes.
In duplex garages.
To switch off the alarm: press any button.
During transport on trains carrying vehicles,
Signals of the indicator lights
at sea or on a trailer.
The indicator light flashes briefly every
With animals in the vehicle.
2 seconds:
At the gas station: if the vehicle is locked af-
The alarm system is switched on.
ter refueling starts.
Indicator light flashes for approx. 10 sec-
The tilt alarm sensor and the interior motion
onds, then it flashes briefly every 2 sec-
sensor can be switched off in such situations.
onds:
Switching off the tilt alarm sensor and
Interior motion sensor and tilt alarm sensor
interior motion sensor
are not active, as doors, hood, or tailgate
are not correctly closed. Correctly closed
Press the remote control button again
access points are secured.
within 10 seconds as soon as the vehi-
When the still open access points are
cle is locked.
closed, interior motion sensor and tilt alarm
The indicator light lights up for approx. 2 sec-
sensor will be switched on.
onds and then continues to flash.
The indicator light goes out after unlocking:
The tilt alarm sensor and interior motion sensor
The vehicle has not been tampered with.
are switched off until the vehicle is locked
again.
The indicator light flashes after unlocking
until the engine ignition is switched on, but
no longer than approx. 5 minutes:
Switching off the alarm
An alarm has been triggered.
Unlock the vehicle with the remote control
or switch on the ignition, if needed through
Tilt alarm sensor
emergency detection of remote control, re-
fer to page 53.
The tilt of the vehicle is monitored.
With Comfort Access: If you have the re-
The alarm system responds in situations such as
mote control with you, unlock the vehicle
attempts to steal a wheel or when the vehicle is
using the button on the driver's side or pas-
towed.
senger side door.
66

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Opening and closing
CONTROLS
Convenient opening via the remote control, re-
Power windows
fer to page 51.
General information
Closing
If an accident of a certain severity occurs, the
windows are automatically closed except a
Pull the switch to the resistance point.
gap.
The window closes while the switch is being
held.
Safety information
WARNING
Pull the switch beyond the resistance
When operating the windows, body parts
point.
and objects can be jammed. There is a risk of
The window closes automatically if the door
injury or risk of damage to property. Make sure
is closed. Pulling the switch again stops the
that the area of movement of the windows is
motion.
clear during opening and closing.
Convenient closing via the remote control, refer
to page 51.
Overview
Closing via Comfort Access, refer to page 56.
Jam protection system
General information
If closing force exceeds a specific threshold as a
window closes, closing is interrupted.
The window opens slightly.
Safety information
Power windows
WARNING
Accessories on the windows such as an-
Safety switch
tennas can impact jam protection. There is a
risk of injury. Do not install accessories in the
area of movement of the windows.
Opening
Closing without the jam protection
Press the switch to the resistance
system
point.
In case of danger from the outside or if ice
The window opens while the switch is being
might prevent normal closing, proceed as fol-
held.
lows:
Press the switch beyond the resist-
ance point.
1.
Pull the switch past the resistance
point and hold it there.
The window opens automatically. Pressing
the switch again stops the motion.
67

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS
Opening and closing
The window closes with limited jam protec-
Initializing the system
tion. If the closing force exceeds a specific
The system can be initialized when the vehicle
threshold, closing is interrupted.
is stationary and the engine is running.
During initialization, the affected window
2.
Pull the switch past the resistance
closes without jam protection.
point again within approx. 4 seconds and
hold it there.
WARNING
The window closes without jam protection.
When operating the windows, body parts
and objects can be jammed. There is a risk of
Safety switch
injury or risk of damage to property. Make sure
that the area of movement of the windows is
General information
clear during opening and closing.
The safety switch in the driver's door can be
1. Open the affected window completely.
used to prevent children, for instance from
opening and closing the rear windows using
2.
Pull the switch to the resistance point
the switches in the rear.
and hold.
If an accident of a certain severity occurs, the
The window closes.
safety function is switched off automatically.
3.
Continue holding the switch pulled to
Switching on/off
the resistance point.
Press button.
The window opens and closes once or twice
The LED lights up if the safety function
after approx. 15 seconds, depending on the
is switched on.
vehicle's equipment.
4. Release switch.
Malfunction
General information
Panoramic glass sun-
In certain situations a window can only be op-
roof
erated to a limited extent.
After a power failure during the opening or
General information
closing process, the a window can only be
In the event of a severe accident, the glass sun-
operated to a limited extent. The system
roof is automatically closed.
must be initialized in this case.
The power window motors are equipped
Safety information
with overheating protection. If a window is
WARNING
opened and closed several times within a
Body parts can be jammed when operat-
short period of time, the overheating pro-
ing the glass sunroof. There is a risk of injury.
tection switches the motor off temporarily.
Make sure that the area of movement of the
Depending on the degree of overheating, it
glass sunroof is clear during opening and clos-
may only be possible to close the window
ing.
or it may not be possible to operate it at all.
In this case: allow the power window motor
to cool down.
68

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Opening and closing
CONTROLS
Overview
Comfort position
In some models, the wind noises in the car's in-
terior are lowest when the glass sunroof is not
fully open. In these models, the automatic
function initially only opens the glass sunroof
up to this comfort position.
Pressing the switch again opens the glass sun-
roof fully.
Closing glass sunroof
Tilting the glass sunroof
With the glass sunroof open
Press back the switch up to or
Slide switch forward to the
beyond the resistance point and
resistance point and hold.
release it.
The glass sunroof is closed as
The glass sunroof is raised.
long as the switch is pressed
and stops in the raised posi-
tion.
Opening glass sunroof
Press the switch forward beyond the resist-
ance point and release it.
When the glass sunroof is closed
The glass sunroof is closed and stops in the
Press the switch back beyond
raised position.
the resistance point and release
Pressing the switch again stops the motion.
it twice.
Press the switch forward beyond the resist-
The glass sunroof is opened.
ance point and release it twice.
Pressing the switch again stops
The glass sunroof is closed.
the motion.
Pressing the switch again stops the motion.
With the glass sunroof completely
With the glass sunroof completely
raised
raised
Slide switch back to the re-
Press the switch forward beyond
sistance point and hold.
the resistance point and release
The glass sunroof is opened
it.
as long as the switch is
The glass sunroof is closed.
pressed.
Press the switch back beyond the resist-
ance point and release it.
Jam protection system
The glass sunroof is opened.
General information
Pressing the switch again stops the motion.
If the closing force exceeds a specific value as a
glass sunroof closes, the closing action is inter-
rupted.
69

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS
Opening and closing
The glass sunroof opens slightly.
Closing without the jam protection
system
If there is an external danger, proceed as fol-
lows:
1. Push the switch forward past the resistance
point and hold it.
The glass sunroof closes with limited jam
protection. If the closing force exceeds a
specific threshold, closing is interrupted.
2. Push the switch forward again past the re-
sistance point and hold until the glass sun-
roof closes without jam protection. Make
sure that the closing area is clear.
Initializing after a power interruption
After a power failure during the opening or
closing process, the glass sunroof can only be
operated to a limited extent. The system must
be initialized in this case. MINI recommends
having this work performed only by a dealer's
service center or another qualified service cen-
ter or repair shop.
70

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Settings
CONTROLS
Settings
WARNING
Vehicle features and op-
With a backrest inclined too far to the
tions
rear, the efficacy of safety gear, including safety
This chapter describes all standard, country-
belts can no longer be ensured. There is a risk
specific and optional features offered with the
of sliding under the safety belt in an accident.
series. It also describes features that are not
There is a risk of injuries or danger to life. Ad-
necessarily available in your vehicle, e. g., due
just the seat prior to starting the trip. Adjust the
to the selected options or country versions. This
backrest so that it is in the most upright posi-
also applies to safety-related functions and sys-
tion as possible and do not adjust again while
tems. When using these functions and systems,
driving.
the applicable laws and regulations must be
WARNING
observed.
There is a risk of jamming when moving
the seats. There is a risk of injury or risk of dam-
age to property. Make sure that the area of
Sitting safely
movement of the seat is clear prior to any ad-
An ideal seating position that meets the needs
justment.
of the occupants can make a vital contribution
to relaxed, fatigue-free driving.
Manually adjustable seats
In the event of an accident, the correct seating
position plays an important role. Follow the in-
Overview
formation in the following chapters:
Seats, refer to page 71.
Safety belts, refer to page 75.
Head restraints, refer to page 76.
Airbags, refer to page 134.
Front seats
1
Forward/backward
Safety information
2
Thigh support
WARNING
3
Height
Seat adjustments while driving can lead
4
Backrest tilt
to unexpected movements of the seat. Vehicle
control could be lost. There is a risk of an acci-
dent. Only adjust the seat on the driver's side
when the vehicle is stationary.
71

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS
Settings
Forward/backward
Lumbar support
The curvature of the seat backrest can be ad-
justed in a way that it supports the lumbar re-
gion of the spine. The lower back and the spine
are supported for upright posture.
Pull the lever and slide the seat in the desired
direction.
After releasing the lever, move the seat forward
or back slightly making sure it engages prop-
erly.
Turn the wheel in order to increase or decrease
the curvature.
Height
Electrically adjustable seats
General information
The seat setting for the driver's seat is stored
for the profile currently used. When the vehicle
is unlocked via the remote control, the position
is automatically retrieved if the function, refer
to page 64, is activated for this purpose.
The current seat position can be stored using
the memory function, refer to page 79.
Pull the lever up or press it down as often as
needed to reach the desired height.
Overview
Backrest tilt
1
Memory function
2
Lumbar support
Pull the lever and apply your weight to the
backrest or lift it off, as necessary.
3
Backrest tilt
4
Forward/backward, height, seat tilt
72

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Settings
CONTROLS
Forward/backward
Backrest tilt
Push switch forward or backward.
Move switch forward or backward.
Height
Lumbar support
Concept
The curvature of the seat backrest can be ad-
justed in a way that it supports the lumbar re-
gion of the spine. The lower back and the spine
are supported for upright posture.
Settings
Press the front/rear section
Push switch up or down.
of the button:
The curvature is increased/
decreased.
Seat tilt
Press the upper/lower sec-
tion of the button:
The curvature is shifted up/
down.
Thigh support
Move switch up or down.
Pull the lever at the front of the seat and adjust
the thigh support.
73

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS
Settings
Front seat heating
WARNING
Unexpected movements of the backrest
Overview
while driving may occur due to unintentional
unlocking of the rear backrests by the straps.
There is a risk of injury. Do not fasten any ob-
jects to the straps for unlocking the rear back-
rests.
Forward/backward
General information
The rear seat is divided at a ratio of 60 to 40.
Seat heating
The left seat is connected to the center section.
Settings
Switching on
Press button once for each tempera-
ture level.
The maximum temperature is reached when
three LEDs are lit.
If the trip is continued within approx. 15 mi-
nutes after a stop, seat heating is activated au-
tomatically with the temperature selected last.
When GREEN Mode is activated, refer to
Pull the lever and slide the seat in the desired
page 210, the heater output is reduced.
direction.
After releasing the lever, move the seat forward
Switching off
or back slightly making sure it engages prop-
erly.
Press and hold the button, until the
LEDs go out.
Backrest tilt
Rear seats
Safety information
WARNING
There is a risk of jamming when folding
down the center armrest in the rear. There is a
risk of injury. Make sure that the area of move-
ment of the center armrest is clear during fold-
Pull the strap and apply your weight to the
ing down.
backrest or lift it off, as necessary.
74

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Settings
CONTROLS
during braking and evasive maneuvers. There is
Safety belts
a risk of injuries or danger to life. Make sure
that all occupants are wearing safety belts cor-
Number of safety belts and safety belt
rectly.
buckles
The vehicle is fitted with five safety belts to en-
WARNING
sure occupant safety. However, they can only
The efficacy of safety gear, including
offer protection when adjusted correctly.
safety belts, may not be fully functional or fail in
The two outer safety belt buckles of the rear
the following situations:
seat are intended for the persons sitting on the
The safety belts or safety belt buckles are
left and right.
damaged, soiled, or changed in any other
The center safety belt buckle of the rear seat is
way.
intended for the person sitting in the middle.
Belt tensioners or belt retractors were
modified.
General information
Safety belts can be imperceptibly damaged in
Always make sure that safety belts are being
the event of an accident. There is a risk of inju-
worn by all occupants before driving off. Al-
ries or danger to life. Do not modify safety
though airbags enhance safety by providing
belts, safety belt buckles, belt tensioners, belt
added protection, they are not a substitute for
retractors or belt anchors and keep them clean.
safety belts.
Have the safety belts checked after an accident
If needed, disengage the safety belt in the rear
at the dealer’s service center or another quali-
from the belt buckle on the side.
fied service center or repair shop.
The upper shoulder strap's anchorage point will
be correct for adult seat occupants of every
Correct use of safety belts
build if the seat is correctly adjusted.
Wear the safety belt twist-free and tight to
your body over your lap and shoulders.
Safety information
Wear the safety belt deep on your hips over
WARNING
your lap. The safety belt may not press on
Use of a safety belt to buckle more than
your stomach.
one person will potentially defeat the ability of
Do not rub the safety belt against sharp
the safety belt to serve its protective func-
edges, or guide it or jam it in across hard or
tion.There is a risk of injuries or danger to life.
fragile objects.
Do not allow more than one person to wear a
Avoid thick clothing.
single safety belt. Infants and children are not
Re-tighten the safety belt frequently up-
allowed on an occupant's lap, but must be
ward around your upper body.
transported and secured in designated child re-
straint systems.
Buckling the safety belt
WARNING
1. Slowly guide the safety belt out of the
The efficacy of safety gear, including
holder when fastening it.
safety belts, can be limited or lost when safety
belts are fastened incorrectly. An incorrectly
fastened safety belt can cause additional inju-
ries, for instance in the event of an accident or
75

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS
Settings
2. Insert the tongue plate into the safety belt
Unbuckling the safety belt
buckle. The safety belt buckle must engage
1. Hold the safety belt firmly.
audibly.
2. Press the red button in the belt buckle.
3. Use the buckle tongue, arrow 1, to open
the second safety belt buckle, arrow 2.
Unbuckling the safety belt
1. Hold the safety belt firmly.
4. Guide the safety belt to the mount in the
2. Press the red button in the belt buckle.
roofliner.
3. Guide the safety belt back into its roll-up
mechanism.
Safety belt reminder for driver's seat
and front passenger seat
Middle safety belt in the rear
Display in the instrument cluster
Buckling the safety belt
The indicator light lights up and a signal
sounds. Make sure that the safety belts
are positioned correctly. The safety belt
reminder can also be activated if objects are
placed on the front passenger seat.
Front head restraints
Safety information
1. Pull the buckle tongues out of the mounts
in the roof.
WARNING
2. Insert the lower buckle tongue in the belt
A missing protective effect due to re-
buckle, arrow 1.
moved or not correctly adjusted head restraints
3. Insert the upper buckle tongue in the belt
can cause injuries in the head and neck area.
buckle, arrow 2.
There is a risk of injury.
Safety belt buckles must audibly click into
Before driving, install the removed head re-
place.
straints on the occupied seats.
Adjust the head restraint so its center sup-
ports the back of the head at as close to
eye level as possible.
76

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Settings
CONTROLS
Adjust the distance so that the head re-
After setting the height, move the head re-
straint is as close as possible to the back of
straint up or down slightly, making sure it en-
the head. Adjust the distance via the back-
gages properly.
rest tilt as needed.
WARNING
Removing: John Cooper Works sport
Body parts can be jammed when moving
seat
the head restraint. There is a risk of injury.
The head restraints cannot be removed.
Make sure that the area of movement is clear
when moving the head restraint.
Removing
Only remove the head restraint if no one will be
WARNING
sitting in the seat in question.
Objects on the head restraint reduce the
protective effect in the head and neck area.
There is a risk of injury.
Do not use seat or head restraint covers.
Do not hang objects, for instance clothes
hangers, directly on the head restraint.
Only use accessories that have been deter-
mined to be safe for attachment to a head
restraint.
Do not use any accessories, for instance pil-
1. Fold the seat backrest forward if needed.
lows, while driving.
2. Pull head restraint up as far as possible.
3. Press the button, arrow 1, and pull the
Adjusting the height: John Cooper
head restraint out completely.
Works sport seat
The height of the head restraints cannot be ad-
Installing
justed.
Proceed in the reverse order to install the head
restraint.
Adjusting the height
Rear head restraints
Safety information
WARNING
A missing protective effect due to re-
moved or not correctly adjusted head restraints
can cause injuries in the head and neck area.
To lower: press the button, arrow 1, and
There is a risk of injury.
push the head restraint down.
Before driving, install the removed head re-
To raise: push the head restraint up.
straints on the occupied seats.
77

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS
Settings
Adjust the head restraint so its center sup-
Fold down
ports the back of the head at as close to
eye level as possible.
Adjust the distance so that the head re-
straint is as close as possible to the back of
the head. Adjust the distance via the back-
rest tilt as needed.
WARNING
Body parts can be jammed when moving
the head restraint. There is a risk of injury.
Make sure that the area of movement is clear
To fold down: press the button, arrow 1,
when moving the head restraint.
and press down the head restraint, arrow 2.
Forward: fold the head restraint toward the
WARNING
front as far as it will go. Make sure that the
Objects on the head restraint reduce the
head restraint engages correctly.
protective effect in the head and neck area.
There is a risk of injury.
Removing
Do not use seat or head restraint covers.
Only remove the head restraint if no one will be
Do not hang objects, for instance clothes
sitting in the seat in question.
hangers, directly on the head restraint.
Only use accessories that have been deter-
mined to be safe for attachment to a head
restraint.
Do not use any accessories, for instance pil-
lows, while driving.
Adjusting the height
1. Fold down the rear seat backrest, refer to
page 196, in question.
2. Pull head restraint up against the resist-
ance.
3. Press the button, arrow 1, and pull the
head restraint out completely.
Installing
To lower: press the button, arrow 1, and
Proceed in the reverse order to install the head
push the head restraint down.
restraint.
To raise: push the head restraint up.
After setting the height, move the head re-
straint up or down slightly, making sure it en-
gages properly.
78















Content      ..     2      3      4      5     ..
